Qlink Rodeo 90 User manual

Thank you foryour selection ofthis QLINK mechanismseries. It represents high technology and reliability,
the emission ofthis vehicle hasreached the latestnational emission standard,therefore it isa really environment
-friendly mechanism that may satisfy the demands of modern society. It has been manufactured technically in
accordance with a lot of experience that our company obtained in manufacturing sports, rac eing a nd tourist
etc.vehicles. And it is just these experiences that have made this mechanism take a large percent in the like
products.This User's Manual will help you get to know the operating method of this model of mechanism, and
obtain the knowledge relating to operation, basic check-up, service and maintenance etc.. Please contactyour
dealer orappointed maintenance stationwhen you haveproblems in usingand maintenance.
All configurations and parameters are forreference only, notcontracted ones. Please refer to the actual
configuration of themanufacturer.
USER'S MANUAL
INTRODUCTION

This manual should be considered as permanent part of the vehicle and should remain with
the vehicle when resold or transferred to a new user or operator , Themanual contains
important safety information and instructions which should be read carefully beforeoperating
the vehicle .
USER'S MANUAL
WARNING

CONTENTS
IMPORTANT........................................... ........1 STARTING THE ENGINE....................... ........ 17
FOREWORD................................................... 1 STARTING OFF.................................. ........... 18
NOTICE TOTHE USER........................... .. ......2 BRAKING...................................................... 23
EDGE 90-ATV .................................................5 TURNING.......................................................24
FUELAND OIL................................................6 SKIDDING OR SLIDING.................................25
LOCATION OF LABELS...................................7 OPERATION ON HILLS...................................26
HANDLE BAR &SWITCH................................9 RIDING OVER OBSTACLES...........................30
LEFT HANDLE BAR.........................................9 RIDING THROUGH WATER............................30
RIGHT HANDLEBAR.......................................9 ACCESSORY USE AND
HAND- VEHICLE LOADING.......................................35
DRAUGHTFLAMEOUTSWITCH.....................9 INSPECTION AND
FUEL VALVE.................................................10 MAINTENANCE.............................................37
FUEL TANK CAP............................................10 TOOLS............................................................39
SEAT LOCK................................................... 11 SPARKPLUG..................................................39
RIDING YOUR ATV....................................... 12 THROTTLE CABLE
WHAT YOU SHOULD KNOW ADJUSTMENT................................................41
BEFORE RIDING.......................................... 12 IDLE SPEED ADJUSTMENT........................ ...42
INSPECTION BEFORE RIDING......................13 FUEL HOSE....................................................43
UNDER RIDING......................15 TRANSMISSION OIL......................................43
BREAK-IN.....................................................16 AIR CLEANER................................................45
PROTECTION
USER'S MANUAL

DRIVE CHAIN...............................................48
DRIVE CHAIN CLEANING
AND OILING.................................................49
TIRES............................................................50
BRAKE..........................................................53
FRONT BRAKE ADJUSTMENT......................54
REAR DISH BRAKE......................................54
BATTERY............................................... .......55
MUFFLER..................................................... 55
GENERAL LUBRICATION.............................57
TROUBLESHOOTING...................................58
TRANSPORTING...........................................60
CLEANING PROCEDURE..............................61
STORAGE PROCEDURE................................63
SERIAL NUMBERLOCATION.......................65
SPECIFICATIONS..........................................66
USER'S MANUAL
TABLE OF CONTENTS

USER'S MANUAL
IMPORTANTINSTRUCTION
Please read thismanual and follow its instructions carefully, To emphasize thespecial information, the symbol
andthe wordsWARNING orCAUTION have some specialMeanings. Pay great attention tothe messages
Indicates a potential hazard that could result in death or injury .
Indicates a potential hazard that could result in vehicle damage .
NOTE : Indicating special information which is to make maintenance easier or instructions clearer .WARNING
and CAUTION arearranged like this:
The first part will identify a POTENTIAL HAZARD. The second part will descri be WHAT COULD HAPPE N
if you ignore the WARNING or CAUTION . The third part will describe HOW TO AVOID THE HAZARD .
FOREWORD
,
•This users manual contains important safety and maintenance imformation. Read if carefully before riding.
Failing to followthe warnings containedin this manual could result in INJURY or DEATH.
•It is important that this manual remain with the venicle when you sell it. The next owner need this manual too.
•All informations,illustrati ons,phot ographs and specifications contained in this manual arebased on thelatest
product information availableat the time of publication. Due to improvements or other changes,there will be
some discrepancies inthis manual. Wereserve the right to make product changes at any time, without notice
and without incurring any obligation to makd the same or similar changes to vehicles previously built or sokd.
CAUTION
1
WARNING - or - CAUTION
WARNING

USER'S MANUAL
,
We believe in conservation and protection of theearths natural resource.We encourage the everyvehicle owner
to recycle the vehicle,Oreven trade itfor several handsif it ison good condition.Make good useof the vehicle
by using properfuel, oil, coolant,battery and tires.
NOTICE TO THE USERS
ATVIS NOT ATOY, IT COULD BE HAZARDOUS TO THE OPERATER The ATV is different from other
vehicle including motorcycles and cars. A collision or rollover could occur quickly, even during routine
maneuvers such as turning and driving on hills or over obstacles if you fail to take proper precautions.
SEVERE IN JURY OR DEATH can result you do not follow these instructions
•Read this manual and labels of ATV carefully,follow the operation procedures as described.
•Never operate the ATV without proper instruction.TAKEATRAINING COURSE . Beginners shouldhave
been trained by a licensed instructor.Always follow this age recommendation:
•Never carry apassenger on anATV.
•Always avoid operating an ATV on paved surfaces,including sidewalks, paths, parking lots,driveways,and
streets.
•Never operate anATV without wearing an approvedcrash helmet that fits properly. You should also wear eye
protection(goggles or face shield),gloves, boots,long-sleeved shirt or jacket,and long trousers.
•Never operate at excessive speed.Always go at a speed that is proper for the terrain,visibility, operating
conditions, your skillsand experience.
•Never attempt wheelies,jumps, or other stunts.
2
CAUTION

USER'S MANUAL
•Always inspect your ATV each time before you use it to make sure it is in safe operating condition. Always
follow the inspectionand maintenance proceduresand schedule described in this manual.
•Always keep both hands on the handlebar and both feet on the footrest of the ATVduring operating.
•Always go slowlyand be extremely carefulwhen operating on unfamiliarterrain. Always be alert to the changing
terrain conditions whenoperating theATV
•Never operate onexcessively rough, slipperyor loose terrainuntil you havelearned and practised the necessary
skills to control the ATV on such terrain.
•Always follow properprocedures for turningas described in this manual. Practise turning at the low speed
before attempting to turn at faster speed. Do not turn at excessive speed.
•Never operate theATV on hills that is too steep for the ATV orfor your abilities.Practise on smaller hill before
attempting larger hills.
•Always follow properprocedures for climbinghills as describedin this manual.Checkthe terrain carefully
before you start up any hill. Never climb hills with excessively slippery or loose surfaces.Shift your weight
forward. Never open the throttle suddenly. Never go over the top lf the hill at high speed.
•Always follow properprocedures for goingdown hills andfor braking onhills as describedin this manual.
Check the terrain carefully before you start to go down any hill.Shift your weight backward. Never go down
a hill at high speed.Avoidgoing down ahill at anangle that wouldcause the vehicleto lean sharplyto one side.
Go down the hillif possible.
•Always follow properprocedures for crossingthe side ofa hill asdescribed in thismanual. Avoid running in
hills with excessively slippery or loose surfaces,shift your weight to the uphill sideof theATV .Neverattempt
to turn the ATV around on any hill until youhave mastered theturning technique describedin this manualon level
ground.Avoid crossing the side ofa steep hillif possible
straight
3

•Always use properprocedures if youstall or rollbackwards when climbinga hill. Toavoid stalling,maintain
a steady speed when climbing a hill . If you stall or roll backwards, follow the special procedure for braking
described in thismanual. Dismount onthe uphill sideor to aside if pointedstraight to uphill.Turn the ATV
around and remount,following the proceduredescribed in thismanual,
•Always check forobstacles before operatingin a newarea. Never attempt tooperateoverlargeobstacles,such
as large rocks or fallentrees.Always follow proper procedures when operating over obstaclesas describedin
this manual.
•Always be careful whe n skidding or sliding .Learn to safelycontrol skidding or sliding by practising at low
speeds and on level, smooth terrain . On extremelyslippery surfaces, such as,ice, go slowly and be very cautious
in order to avoid out of control when skidding or sliding.
•Never operate anATV in fast flowing wateror in water deeper than that specified in thismanual. Remember
that wet brakes can rekuce stopping ability. Test your brakes afterleavingwater. If necessary, apply them for
several times tolet friction liningsdry out.
•Always be surethere are noobstacles or peoplebehind you whenyou operate inreverse. Whenit is safeto proceed
in reverse, goslowly.
•Always use the tires with propersize and type tiresspecified in this manual. Always main tain pr oper tire pre ssure
as described inthis manual.
•Never modify anATV through improper installation oraccessories,
•Never exceed thestated load capacityfor an ATV.Cargo should be distributedproperlyand attachedsecurely.
Reduce speed and fpllow instructions in this manual for carrying cargo. Allow longer distance for braking.
,
•The combined weightof the rider,and any accessoriesor cargo must never exceed the vehicle s loadcapacity
of 200lbs,
•Do not towa trailer. This vehicle is notdesigned for suchuse.
USER'S MANUAL
4

USER'S MANUAL
LEFT RIGHT
5

USER'S MANUAL
FUEL ANEOIL
FUEL
The proper fuel is very important for the engine,it is forbidden that there is dust mixingin the fuel. Please use
the regular unleaded gasoline with the octane number90& upwards of 90.
ENGINE OIL
Special four-strokeengine oil is required.It will realize the best lubricating
affect and the engine will run in a proper condition. On the other hand the
deposit carbon will be least and the service life will be longer too,
Use the chart to select a viscosity rating based on the temperature range in your area,
NOTE: In very cold weather below 5°F(-15°C), use SAE10W -50 for good starting
and smooth operation.
6

USER'S MANUAL
LOCATION OF LABELS
Read and follow all of the warnings labeled on your ATV. Make sure youunderstand all the labels.Keep the labels
on the ATV.Do not remove them for any reason . If a label comes off orbecomes difficult to read, you should get
a replacement by contacting your dealer.
7
WARNING
WARNING

USER'S MANUAL
8
WARNING
WARNING

USER'S MANUAL
HANDLEBAR&SWITCH
LEFT HANDLEBAR
9
Engine stop switch 1
"OFF"position
The engine can not be
started,
"RUN"position
The engine can be started.
Rear brake lever 2
Apply the rear brake by squeezing the rear brake lever
towards the grip.
Electric starting button 3
to increase eng in e rot ati ng
speed. Release itto decrease
engine speed.
Front brakelever 2
Throttle adjusting
screw 3
This switch is on left side
lf theframe.When you pull
out it,theengine can not be
started.On the contrary,
the engine can be started
normally after you insert
the switch
RIGHT HANDLEBAR
Throttle lever 1
Control the engine
rotating speed with the
throttle lever.
Operate this lever with
your thumb.Push itforward
Use the throttle adjusting screw to restrict maximum
speed of the ATV Adjust this limiter according to the
,
rider s skill andexperience.
HAND-DRAUGHT FLAMEOUT SWITCH

USER'S MANUAL
10
Adjusting procedures:
1. Loose the nut 4
2. Turn the throttleadjusting screw 3 clockwise to restrictmaximum speed
of theATV.
3. Turn the throttle adjusting screw 3 counterclock wise to increase the
maximum speed ofthe ATV.
4. After finished it tighten the lock nut 4 .
FUEL VALVE
This vehicle has a manually operated fuelvalve, There are two positions: " "
and " • " .
" "posltlon
In this position,fuelwill flow to the carburetor when the engine is running or being
started.
" • "posltlon
No fuel will flow into the carburetor.
FUEL TANK CAP
To open the fuel tank cap, take the end of the vent tube out from the vehicle body , turn the fuel tank cap

USER'S MANUAL
11
counterclockwise. To closethe fuel tank cap, turnit clolkwise and tighten it secur ely.
Be sure that the vent tube securely connects to the cap as shown.
Overfilling the fuel tank could be hazardous.
lf you overfil l the fuel tank,fuel may overflow when it expandingexpanse
duetoheat from engineor sunOverheated fuel could easily catch fire.
Stop adding fuel when the fuel level reaches the bottom of the filler neck.
Improper fueling ofthe ATV couldbe hazardous.Failing tofollow safety precautions when refueling could result
in a fire orlet you breathe toxic fume. Refuel in a wellventilated area. Make sure the engine is offand avoid spilling
fuel on a hot engine. Do not smoke, and make sure there are no open flames or sparks in the area. Avoid breathing
gasoline vapors. Keepchildren and petsaway when youare refueling theATV.
WARNING
SEATLOCK
Toremove the seat, movetheseatlock lever backword. Raise the rear end of the
seat and slide itback.Tolock theseat, slide thesear lever intoits retainer and
push down firmly.
WARNING

USER'S MANUAL
Improperly installing the seat could behazardous. Failing toinstall the seatproperly couldallowtheseattomove
and cause the riderlosing control. Makesure you arein proper positionand the seatis attached securelywhen
you install it.
RIDING YOURATV
WHATYOU SHOULD KNOW BEFORE RIDING
Before riding, youshould read allthe following informationscarefully.If you are properlyprepared, you will
have a safer and more enjoyable ride. Before riding, you should find a good place to pratise the skills. Find a
flat, open area with enough space to practise the new skills. Make sure that it is legal to ride in the area you
selected. Review the local law to make sure you are not trespassing. Check with your ATV dealer or call the p
olice if youdo not knowwhere you can ride.
,
Protect your riding areas. When you are riding, remember to keep the terrain in good condition.Dont destroy
,,
plant.Don t litter anddon t bother wildlife. With your help, yourriding area can remain open for you to use in
the futur e. After you have found a good placeto practise, review the control system on your ATV before riding.
Learm to find these controls without looking for them. Because you will not have time to look for them when you
are riding.
12
Operating thisATV withoutproper instruction cou ld be h azardous.The ri sk of ridin g could incre ases greatly if you
do not know how to operate the ATV properly underdifferent situations and on different types of terrain.
Beginners and inexperienced operators should complete the certifie d training course. You should
,
regularly practise the skills learnedin thecourse and the operating techniques described in this user s manual.
For more information about the training course,contactyour authorized dealer.
WARNING
WARNING

USER'S MANUAL
13
INSPECTION BEFORE RIDING
ITEM TOCHECK
Steering
Brakes
Tires
Fuel
Engine stop switch
Engine oil
CONTENT
Smoothness no restrictionof movement no play or looseness
Proper brake leverfree play enough brake force parking brake effectiveness
Proper air pressureenough tread depthno cracks, rips, or other damages
Enough fuel forthe intended tripfuel hose connected securely no damageto
fuel tank orcap fuel tankcap closed securely
Proper operation
Proper level
USER'S MANUAL
13
INSPECTION BEFORE RIDING
ITEM TO CHECK
Steering
Brakes
Tires
Fuel
Engine stop switch
Engine oil
CONTENT
Smoothness no restriction of movement no play or looseness
Proper brake lever free play enough brake force parking brake effectiveness
Proper air pressure enough tread depth no cracks, rips, or other damages
Enough fuel for the intended trip fuel hose connected securely no damage to
fuel tank or cap fuel tank cap closed securely
Proper operation
Proper level
In normal instance,the position of engine oil in window should bebetween upper
limit (H) and lower limit (L).
If the position ofengine oil in window is under the lower limit (L), please complement
engine oil intime.

USER'S MANUAL
14
Throttle Proper free play of throttle lever smooth response quick return to idle position
Drive chain Proper tension adequate lubrication no excessive wear or damage
General condition Bolts and nuts are tight no rattle from any parts of the engine when running
No visible evidence of Damage
Failing to inspect the ATV before operating could be hazardous. Failing to perform proper maintenance could
also be hazardous. Failing to inspect and maintain your ATV could increases the chances of an accident or
equipment damage. Always inspect your ATV each time before riding, and make sure it is in safe operating
condition.Refer to theINSPECTION AND MAINTENANCE sectionin this manual.
Operating thisATV with improper tires,or eventire air pressurecould be hazardous.If you useimproper tires
or improper air pressure, you may lose control ofthe ATV. Thiswill cause anaccident. Always use thetires with
size and type tires specified in this user's manual. Always maintain proper tire air pressure as described in the
INSPECTION AND MAINTENANCE section.
Overloading could be hazardous .Overloading could cause changesin vehiclehandling and couldlead an accident.
Never exceed the stated load capacity for this ATV.Refer to the ACCESSORY USE AND VEHICLE LOADING
section in thismanual.
WARNING
WARNING
WARNING

15
USER'S MANUAL
Operating this ATV with improper modifications could be hazardous. Improper installation of accessories or
modification to this vehicle may cause changes in handling. In some situations, this could lead an accident.
Never modify this ATV through improper installation oruse of accessories.Refer to the ACCESSORY USE
AND LOADING sectionin this manual.
Checking maintenance items when the engine is running could be hazardous. You could be severely injuredif
your hands or clothing get caught in movingATV parts. Shut the engine off when performing maintenance
checks, except checkingthe engine stopswitch and throttle.
Check the condition of the ATV to make sure that the ATV do not have mechanical problemsor get stranded
somewhere when you ride. Before ridingtheATV, be sure to check the above items. Andbe sure your ATV is in
good condition tokeep the safetyof the rider.
PROTECTION UNDER RIDING
A crash helmet is the most importantpart which you should wear. A crash helmet can help preventing a serious
head injury. Choose a helmet that fits snugly. Askyour dealer forhelp to selecta good qualitycrash helmet that
fits properly.
Operating this ATV without wearing an approved crash helmet, eye protection and protective clothing could be
hazardous.
Operating without an approved crash helmet or eye protection increases your chances of a severe head injury
WARNING
WARNING
WARNING

16
USER'S MANUAL
or death inan accident. Operatingwithout protective clothingalso increases yourchances of severeinjury in
an accident.Always wear an approved crash helmet that fits properly.
Always wear eye protection (goggles or face shield) .You should also wear gloves, boots, long sleeve shirtjacket,
and long trousers.
You should wear eye protection when you ride. If rock or branch hits your eyes, you could be severely injured.
Wear goggles or a face shield.
Wearproper clothing whenyou ride. The proper clothescan protect youfrom injury. Wear a goodpair of gloves,
strong boots thatover the ankle,long trousers, anda long sleeveshirt.
BREAK-IN
The first month is the most important in the life of your vehicle. Proper operation during this break-in period
will be helpfulfor assuring maximumlife and performanceof your newvehicle. The following guidelines explain
proper break-in procedures.
Maximum Throttle Opening Recommendation
During the first 10 hours of operation,you should always use less than 1/2 throttle opening.
Varythe Engine RotatingSpeed
Vary the enginerotating speed during the break-in period. This allows the parts to "load" and then "unload"
(allowing the parts to cool).Although it is essential to place some stress on the engine components during
break-in,you must be careful not to load the engine too much.
