Rapnas MF-1 User manual

Network audio system(built-in amplifier)
OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS
• Explanation of Graphical Symbols
12 Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when unused for long periods of
time.
14 Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
We Want You Listening For A Lifetime
We group want you to get the most out of your equipment by playing it at a safe
level. One that lets the sound come through loud and clear without annoying
blaring or distortion –and, most importantly, without affecting your sensitive
hearing.
Since hearing damage from loud sounds is often undetectable until it is too late,
We recommend you to avoid prolonged exposure from excessive volume levels.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert you to the presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert you to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly at plugs, convenience
Receptacles, and the point where they exit from the apparatus.
11 Only use attachments/accessories specified by the manufacturer.

FCC, IC and CE Statement
FCC requirements
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator and your body.
Declaration Of Conformity Hereby, Machine Technology (SZ)
Co. , Ltd. Declares that this RAPNAS MF-1 is in compliance
with the essential requirements and other relevant provisions
of Directive 2014/53/EU.
IC warning statements
This device complies with Industry Canada’s license-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
The device for operation in the band 5150–5250 MHz is only for indoor
use to reduce the potential for harmful interference to co-channel mobile
satellite systems;
les dispositifs fonctionnant dans la bande de 5150 à 5250MHz sont
réservés uniquement pour une utilisation à l'intérieur afin de réduire les
risques de brouillage préjudiciable aux systèmes de satellites mobiles
utilisant les mêmes canaux;
This equipment complies with Canada radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator & your
body.
Cet équipement est conforme Canada limites d'exposition aux radiations
dans un environnement non contrôlé. Cet équipement doit être installé et
utilisé à distance minimum de 20cm entre le radiateur et votre corps.
The digital apparatus complies with Canadian CAN ICES-3 (B)/NMB-3(B).
Cet conforme à la norme NMB-003 du Canada.

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
1. To assure the finest performance, please read this manual carefully. Keep it in a safe place for future
reference.
2. Install this sound system in a well ventilated, cool, dry, clean place - away from direct sunlight,
heat sources, vibration, dust, moisture, and/or cold. For proper ventilation, allow the following
minimum clearances.
Top: 10 cm (4 in.), Rear: 10 cm (4 in.), Sides: 6 cm (2.5 in.)
3. Locate this unit away from other electrical appliances, motors, or transformers to avoid humming
sounds.
4. Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit
in an environment with high humidity (i.e. a room with a humidifier) to prevent condensation inside
this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury.
5. Avoid installing this unit where foreign object may fall onto this unit and/or this unit may be exposed
to liquid dripping or splashing. On the top of this unit, do not place:
–Other components, as they may cause damage and/or discoloration on the surface of this unit.
–Burning objects (i.e. candles), as they may cause fire, damage to this unit, and/or personal injury.
–Containers with liquid in them, as they may fall and liquid may cause electrical shock to the user
and/or damage to this unit.
6. Do not cover this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radiation.
If the temperature inside this unit rises, it may cause fire, damage to this unit, and/or personal injury.
7. Do not plug in this unit to a wall outlet until all connections are complete.
8. Do not operate this unit upside-down. It may overheat, possibly causing damage.
9. Do not use force on switches, knobs and/or cords.
10. When disconnecting the power cable from the wall outlet, grasp the plug; do not pull the cable.
11. Do not clean this unit with chemical solvents; this might damage the finish. Use a clean, dry cloth.
12. Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is
dangerous and may cause fire, damage to this unit, and/or personal injury. We will not be held
responsible for any damage resulting from use of this unit with a voltage other than specified.
13. To prevent damage by lightning, keep the power cable and outdoor antennas disconnected from a wall
outlet or this unit during a lightning storm.
14. Do not attempt to modify or fix this unit. Contact qualified service personnel when any service is
needed. The cabinet should never be opened for any reasons.
15. When not planning to use this unit for long periods of time (i.e. vacation), disconnect the AC power
plug from the wall outlet.
16. Be sure to refer to the “Troubleshooting” section for common operating errors before concluding that
this unit is faulty.
17. Before moving this unit, press A to set it to standby mode and disconnect the AC power plug from the
wall outlet.
18. Condensation will form when the surrounding temperature changes suddenly. Disconnect the power
cable from the outlet, then leave this unit alone.
19. When using this unit for a long time, this unit may become warm. Turn the power off, then leave this
unit alone for cooling.
20. Install this unit near the AC outlet and where the AC power plug can be reached easily.
21. The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. When you
dispose of batteries, follow your regional regulations.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.
This unit is not disconnected from the AC power source as long as it is connected to the wall
outlet, even if this unit itself is turned off by A. This state is called the standby mode. In this
state, this unit is designed to consume a very small quantity of power.
Radio waves may affect electro-medical devices. Do not use this unit near medical devices or
inside medical facilities.
Do not use this unit within 20cm (8.5 inches) of persons with a heart pacemaker implant
or defibrillator implant.
•Do not spill water or other liquids on the remote control.
•Do not drop the remote control.
•Do not leave or store the remote control in the following conditions:
–places of high humidity, such as near a bath
–places of high temperatures, such as near a heater or stove
–places of extremely low temperatures
–dusty places
•Insert the battery according to the polarity markings (+ and -).
•Change all batteries if you notice the following conditions:
–the operation range of the remote control narrows
–the transmit indicator does not flash or is dim
•If the batteries run out, immediately remove them from the remote control to prevent an explosion or
acid leak.
•If you find leaking batteries, discard the batteries immediately, taking care not to touch the leaked
material. If the leaked material comes into contact with your skin or gets into your eyes or mouth, rinse
it away immediately and consult a doctor. Clean the battery compartment thoroughly before installing
new batteries.
•Do not use old batteries together with new ones. This may shorten the life of the new batteries or cause
old batteries to leak.
•Do not use different types of batteries (such as alkaline and manganese batteries) together.
Specification of batteries may be different even though they look the same. Danger of explosion may
happen if batteries are incorrectly replaced.
•Before inserting new batteries, wipe the compartment clean.
•Dispose of batteries according to your regional regulations.
•Keep batteries away from children. If a battery is accidentally swallowed, contact your doctor
immediately.
•When not planning to use the remote control for long periods of time, remove the batteries from the
remote control.
•Do not charge or disassemble the supplied batteries.
Notes on remote controls and batteries

Table of Contents
Important safety instructions 2
Caution: Read this before operating your unit 3
FCC, IC and CE Statement 4
Table of Contents 5
What you can do with this unit (Network Audio) 6
What you can do with this unit (Wire connection input) 7
What you can do with this unit (USB-DAC) 8
Accessories 9
Remote control preparation 10
Names and functions of parts (remote control) 11
Part name (Front) 12
Part name (Rear) 13
Part name (Side) 14
Connecting speakers 15
Connecting headphone 16
Connecting to a network (PC/NAS/Internet connection) 17
Basic connection of this unit 18
Stand by before use 19
Power ON 20
Mode and initial display of DAC 21
Front panel OLED display (page1) 22
Front panel OLED display (page2) 23
Front panel OLED display (page3) 24
Front panel OLED display (exception) 25
Launch Web UI 26
Volumio Web UI 27
Queue screen function 28
Select storage 29
Playback LR Stereo Test 30
Playback from USB storage 31
DSD Native Playback 32
Change DAC mode 33
Playback from AUX-IN 34
DAC output 35
AirPlay Receive Playback 36
Playback from SPDIF 37
Used as external player's USB-DAC 38
Additional Information 39
System Reboot 40
Normal Power Off 41
Forced Power Off 42
Appearance dimension 43
Specification sheet1 44
Specification sheet2 45

What you can do with this unit (NetworkAudio)
• This unit as a player with built-in amplifier, can be used not only for USB storage playback but also as a network player.
You can play from a media server (PC,NAS,etc.) on the same network or connect to an AirPlay / DLNA device.
In addition, Internet radio and streaming service can be received in an environment connected to the Internet.
①Playback the Internet radio and Spotify etc. streaming
②Play back music files stored on your PC (support Roon bridge)
③Play back music files stored on your NAS
④Play back your mobile with AirPlay or dlna connect
⑤Play back music in an USB device
⑥You can operate this unit on the PC
⑦You can operate this unit on the Mobile phone
⑧If it is easy operation you can do it from the remote control
①Internet
②⑥PC
③NAS
Broadband router
④⑦Mobile phone
(AirPlay or DLNA)
Modem
⑧Remote control
⑤
USB flash drive
USB hard disk drive
Speakers
Note
If you use streaming services such as Spotify, you will need to subscribe to the service (charged) by yourself.

What you can do with this unit (Wire connection input)
• By wired connection to an external playback device, this unit can be used as a Integrated amplifier.
①Playback music in an external digital(SPDIF) device
②Playback music in an external analog device
③With this use method, only the reboot of this unit and the
power off and digital volume up / down can be operated with
the remote control.
③Remote control
②
AUX-IN
Speakers
①
SPDIF-IN
Note
In case of digital (SPDIF) input, you can use digital volume of DAC, digital volume can not be used with analog input.

What you can do with this unit (USB-DAC)
• This unit can be used as a USB-DAC by connecting PC with a USB conversion cable B and C.
①Support foobar2000
②Support JRiver Media Center
③Support Audirvana Plus
USB conversion
cable B
Speaker
①②
USB conversion
cable C

Accessories
• Confirm the package contents and useful points of this manual.
• Instructions and illustrations used in this manual refer to the
RAPNAS MF-1, unless otherwise specified.
• How to operate this unit is described mainly using the WindowsPC
and remote control.
• iOS and Android mobile devices are collectively referred to as
“mobile devices.”
Supplied accessories About this manual
CD-ROM
•MicroSD card Backup (image file)
•Owner’s manual (PDF file)
Micro SD card
(volumio2 based rapnas distribution)
USB conversion cable A USB conversion cable B
Power cable Remote control
USB conversion cable C
AAA battery

Remote control preparation
Installing batteries
R03/AAA batteries
Remove the cover from the back of the remote control and insert
two AAA batteries with their (+) (-) ends oriented in the case as
shown. Replace the cover.
If the distance required between the remote and the main unit
decreases or if the unit stops responding to the remote buttons,
replace both batteries with new ones.
Dispose of the used batteries according to the instructions on them
or requirements set by your local municipality.
30°30°
About 6 meters
Operation range
Aim the remote control directly at the remote control
sensor on the main unit during operation.

Names and functions of parts (remote control)
A) Power off or Reboot Decision button *1
B) Skip backward button
C) Fast-reverse button
D) Fast-forward button
E) Skip forward button
F) Play/Pause button
G) Change display button
H) Stop or Power off selection button
I) Reboot selection button
J) Volume down button *2
K) Volume up button *2
*1: Pressing the (I) button first, pressing this button shifts the
system to power off.
Pressing the (J) button first, pressing this button shifts the
system to reboot.
*2: With these buttons you can raise or lower the DAC's digital
volume (display volume value).It has nothing to do with amp
volume at the latter stage.
A
F
C D
B
G
H
E
I
K
J
• Familiarize yourself with all parts and these functions.

Part name (Front)
①Power Switch
②microSD card slot
③Pre-Amplifier Volume knob
④Headphones jack (3.5mm stereo) mini plug
⑤Front panel OLED display
⑥Remote control sensor
• Familiarize yourself with all parts and these functions.
Front panel
①②
⑥
③
⑤④

Part name (Rear )
①Wired LAN (RJ-45x1)
②USB-DAC IN (micro USB B)
③USB expansion port (USB type A ×4)
④DC5V OUT (micro USB B)
⑤Power supply (AC 100-120V or AC200-240V)
⑥Exhaust port 1
⑦Speaker terminal
⑧SPDIF-Digital IN (RCA coaxial plug)
⑨AUX-Analog IN (3.5mm stereo mini plug)
⑩Exhaust port 2
⑪DAC-Analog OUT (3.5mm stereo mini plug)
Rear panel
②④
⑪
①
⑧⑥
③
⑨
⑤
⑦⑩
• Familiarize yourself with all parts and these functions.

Part name (Side)
①ACTION-LED (MicroSD card read or write indicator)
②DC5V IN (For special use : microUSB B)
③HDMI TYPE A (Video and audio output)
④3.5mm 4section mini plug (Video and audio output)
⑤Exhaust port 3
Side panel
②④①
⑤
③
• Familiarize yourself with all parts and these functions.

Connecting speakers
・Connection method A (Recommendation)
Insert a 4 mm banana clip (not included) to the end of the cable
and insert it into the speaker terminal hole of this instrument.
Attention How to connect speakers
・This unit is compatible with speakers that have 4–8Ω nominal
impedance. If speakers with impedance of less than 4 Ω are used,
the protection circuit could operate, causing sound output to
stop. In some cases, this unit or the speakers could be damaged.
・The red speaker terminals are positive (+) and the black speaker
terminals are negative (-). Generally, the (+) wire of the speaker
cable is marked to distinguish it from the (-) wire of the cable.
Connect the marked wire to the red (+) terminal and the
unmarked wire to the black (-) terminal.
・If the exposed core wires at the tips of the speaker cables
should touch other cables or terminals, an electrical short might
occur.
・Never allow speaker cables to cause a short.
・To prevent hum and noise, avoid bundling the cables together
with the AC power cord or other cables.
・Connection method B
Remove about one centimeter of insulation from the end of the
speaker cable and twist the core wires well.
Turn the terminal cap counterclockwise to loosen it.
Insert the wire into the hole in the terminal post and turn the
terminal cap clockwise to securely connect it.
Banana Plug
Diameter 4mm
Left SpeakerRight Speaker

Connecting headphone
◆CAUTION
While wearing headphones, do not connect or disconnect them,
turn the unit on or off, or switch the headphone amp gain.
Doing so could result in a sudden loud noise that could harm your
hearing.
Always set the amplifier volume to minimum before connecting
and unconnecting headphones on. (Left rotating end is minimum
volume)
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
PHONES jack
This headphone amp circuit uses a three-pole connector with
Common left and right for grounding. Ordinary 3.5mm stereo
mini plugs with 3 poles can be used.
Left rotating end is minimum volume

Connecting to a network (PC/NAS/Internet connection)
CAUTION
•For details on Internet connection, refer to the owner’s manuals
of your network devices.
•If you are using a router that supports DHCP, you do not need to
configure any network settings for the unit.
•Wired connections are recommended for devices other than the
mobile to ensure high sound quality.
•Some security software installed on your PC or the firewall
settings of network devices (such as a router) may block the
access of the unit to the network devices or the Internet. In this
case, change the setting of the security software or network
devices.
•When setting the subnet manually, each server must be
connected to the same subnet as the unit .wearing headphones,
do not connect or disconnect them, turn the unit on or off, or
switch the headphone amp gain. Doing so could result in a
sudden loud noise that could harm your hearing. Always set the
amplifier volume to minimum before connecting and un
connecting headphones on. (Left rotating end is minimum
volume) To prevent hearing loss, do not raise the volume level
excessively when using headphones.
Connecting to a network
(PC/NAS/Internet connection)
You can play back music files stored on your PC or NAS, audio
contents on the Internet radio, by connecting this unit to
a network.
Connect with a commercially available STP (shielded twisted pair)
network cable (CAT-5 or higher, straight-through)
Network cable
Broadband router
Modem Internet

Basic connection of this unit
①Connect with your home router and LAN cable.
②Connect USB storage that saved the music source. (USB flash
memory, USB external hard disk etc.)
③Connect the right speaker cable.
④Connect the left speaker cable.
⑤Connect the Included power cord. (Do not connect to
household outlet yet.)
• Below is a description of the basic connection state that should be done before turning on the power supply.
Rear panel
③①⑤②④

Stand by before use
②Finally connect the power plug to the household outlet.
• Familiarize yourself with all parts and these functions.
Front panel
①
②
①Insert the supplied micro SD card into the card slot. Be sure to
insert with electrode slit face up. (To remove the card, push it
again and it will be discharged in front.)
Connect the power plug
Caution
Before connecting the plug, check that the
power supply voltage of the home matches
the voltage specification of this unit. It can
be confirmed at the end A or B of the serial
number.
A corresponds to AC 100 - 120V
B corresponds to AC 200 - 240V
If it is different, you should never connect.

Power ON
①Press and release the POWER button on the panel for about
0.5 seconds. When the power turns on, the back of the
amplifier volume knob glows blue. Wait approximately
40 seconds from the power ON until the startup is completed.
②The letter of Figure 1 is displayed on the front panel OLED,
After a few seconds the start up completed when Figure 2 is
displayed.
• Familiarize yourself with all parts and these functions.
◆Front panel
②
R A P N A S
M
F - 1
b y V o l u
m
i o 2
①
Figure 1
Figure 2
