Reliance 3000 User manual

OWNERS MANUAL
INSTALLATION AND
OPERATING INSTRUCTIONS
MODEL 3000
CHAIR

QUALITY MANAGEMENT
SYSTEM
REGISTERED TO
ISO 9001
ISO 13485
MADE IN AMERICA
Reliance® Medical Products Inc. • 3535 Kings Mills Road • Mason, Ohio 45040-2303 • 1-800-735-0357 • www.reliance-medical.com
SERIAL NUMBER
For your future reference, mark the serial number
in the space provided.

TABLE OF CONTENTS
IMPORTANT INFORMATION............................................4
1. INTRODUCTION........................................................5
IMPORTANT USER WARNINGS.........................................5
2. INSTALLATION...........................................................6
2.1. Unpacking........................................................6
Chair.......................................................................6
2.2. Assembly.........................................................6
Mounting the Headrest..............................................6
3. OPERATION..............................................................6
3.1. Chair Lift........................................................7
3.2. Revolving........................................................7
3.3. Reposistioning the Chair Back.........................7
3.4. Arm Movements...............................................7
3.5. Headrest.........................................................8
Operation-No. 11 Headrest......................................8
Adjustment-No. 11 Headrest....................................8
Operation-No. 10 Headrest......................................8
Operation-No. 18 Headrest......................................8
Adjustment-No. 18 Headrest....................................9
3.6. Chair Back Cover Removal (for servicing unit)...9
3.7. Gas Spring Adjustment......................................9
3.8. Replacement of Chair Back Cover.........................10
3.9. Removal of Lift (for servicing unit)....................10
TROUBLESHOOTING GUIDE..........................................11
CLEANING AND MAINTENANCE....................................12
PARTS LIST....................................................................13
Model 3000 Chair Assembly....................................14
Chair Top Assembly...............................................16
Chair Base Assembly.............................................18
Lift Assembly.........................................................20
#11 Headrest Assembly...........................................22
#18 Headrest Assembly.........................................24
#10 Headrest Assembly.........................................26
LIMITED WARRANTY.....................................................27

IN-30004
TRANSPORTATION / STORAGE CONDITIONS
Temperature: Operating: 59 to 104º F
15 to 40º C
Storage: -22 to +140º F
-30 to +60º C
Relative Humidity: Operating: 5%RH to 95%RH
without condensation
Storage: 10%RH to 100%RH,
including condensation
Atmospheric Pressure:
Operating: 700hPa - 1060hPa
Storage: 500hPa - 1060hPa
IMPORTANT INFORMATION
SAFETY SYMBOLS
Safe Working Load
“Attention, Consult Accompanying
Documents”
Burn Hazard/Hot Surface
!
“DANGER”, “WARNING”, or “CAUTION”
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in this
Installation and Operating Instructions.
“NOTE”
Amplie une procédure, pratique ou condition.
« DANGER », « AVERTISSEMENT », ou
«PRÉCAUTION »
Le point d’exclamation à l’intérieur d’un
triangle équilatéral vise à alerter l’utilisateur
à la présence d’importantes instructions
de fonctionnement et de maintenance
(service) dans ce manuel d’installation et
d’instructions de fonctionnement.
“NOTE”
Amplies a procedure, practice, or condition.

“NOTE”- Note indicates points of particular or
additional information.
“NOTE” - la note indique des remarques
d’information particulière ou supplémentaire.
1.3 Should your product not perform properly, or if
you have any questions concerning the use and care
of any Reliance® product, contact the Reliance®
Distributor, where you purchased this product or contact
the Technical Service Department, Reliance® Medical
Products, Inc., 3535 Kings Mills Road, Mason, Ohio
45040-2303, or call [phone].
NOTE: Always have the model number and
serial number available before contacting
Reliance® or your Authorized Reliance®
Distributor.
REMARQUE : Ayez toujours le numéro de
modèle et le numéro de série à portée de la
main avant de contacter Reliance® ou votre
distributeur Reliance® autorisé.
“CLASSIFIED BY CANADIAN STANDARDS
ASSOCIATION® WITH RESPECT TO ELECTRIC
SHOCK, FIRE AND MECHANICAL HAZARDS
ONLY IN ACCORDANCE WITH UL 60601-1.”
• The degree of protection against harmful ingress of
water: ORDINARY DEGREE
• The mode of operation: CONTINUOUS OPERATION
1. INTRODUCTION
1.1. This manual contains information applicable only
to the Reliance® Model 3000 Chair.
1.2. Whenever you see the symbols shown below,
heed their instructions! Always follow safe operating
and maintenance practices.
“DANGER”- THE DANGER SYMBOL
IDENTIFIES SPECIAL INSTRUCTIONS OR
PROCEDURES WHICH, IF NOT CORRECTLY
FOLLOWED, COULD RESULT IN LOSS OF
LIFE OR PERSONAL INJURY.
« DANGER » : LE SYMBOLE DANGER
IDENTIFIE DES INSTRUCTIONS OU
PROCÉDURES SPÉCIALES QUI, SI ELLES
NE SONT PAS SUIVIES CORRECTEMENT,
POURRAIENT CAUSER UNE PERTE DE VIE
OU UNE BLESSURE.
“WARNING”- THE WARNING SYMBOL
IDENTIFIES SPECIAL INSTRUCTIONS
OR PROCEDURES WHICH, IF NOT
CORRECTLY FOLLOWED, COULD RESULT
IN PERSONAL INJURY.
« AVERTISSEMENT » : LE SYMBOLE
AVERTISSEMENT IDENTIFIE DES
INSTRUCTIONS OU PROCÉDURES SPÉCIALES
QUI, SI ELLES NE SONT PAS SUIVIES
CORRECTEMENT, POURRAIENT CAUSER
UNE BLESSURE.
“CAUTION”- This caution symbol identifies
special instructions or procedures which,
if not strictly observed, could result in
damage to or destruction of equipment.
« PRÉCAUTION » : Ce symbole de
précaution identifie des instructions ou
procédures spéciales qui, si elles ne sont pas
strictement suivies, pourraient causer un
dommage ou la destruction de l’équipement.
IN-3000 5
IMPORTANT USER WARNINGS
WARNING - STORAGE OF THIS EQUIPMENT
BELOW 40°F (4.4ºC) WILL CAUSE THE
HYDRAULIC OIL TO BECOME THICK. THIS MAY
CAUSE UNUSUAL NOISES WHEN THE BASE
PUMP IS OPERATED. IT IS RECOMMENDED
THAT THE EQUIPMENT STAY AT A
TEMPERATURE OF 60°F (15.6ºC) OR ABOVE
FOR AT LEAST 8 HOURS BEFORE OPERATING.
AVERTISSANT - LE STOCKAGE DE CET
ÉQUIPEMENT AU-DESSOUS DE 40°F (4.4ºC)
FERA DEVENIR L’HUILE HYDRAULIQUE
PROFONDÉMENT. CECI PEUT CAUSER DES
BRUITS PEU COMMUNS QUAND LA POMPE
BASSE EST ACTIONNÉE. ON LUI RECOMMANDE
QUE LE SÉJOUR D’ÉQUIPEMENT À UNE
TEMPÉRATURE DE 60°F (15.6ºC) OU EN HAUT
PENDANT AU MOINS 8 HEURES AVANT LE
FONCTIONNEMENT.

IN-30006
2. INSTALLATION
2.1. Unpacking
2.1.1. Chair
2.1.1.1. Open the shipping carton carefully and record any
shipping damage to the carton or to the contents.
2.1.1.2. Remove the upper portion of the crate from the skid
and unbolt the base clamping boards. It is recommended
that the Chair be located in position before unpacking the
upper structure.
2.1.1.3. Do not lift the Chair by the upper structure,
although the Chair may be tipped or slid by pushing or
pulling the upper structure.
2.1.1.4. A small tool packet containing three hexagon allen
wrenches, Sizes 1/8, 3/32 and 5/32 have been included
in the installation packet.
2.2. Assembly
Remove all wrappings. Only the headrest has been removed
for shipment.
2.2.1. Mounting the Headrest
2.2.1.1. Remove the Back Cushion assembly by pulling
straight out from the Chair. The Seat Cushions are both
attached with Velcro strips. This will permit access to the
seat-back.
2.2.1.2. Slide the Pivot Bracket on the Headrest into the
slot in the top of the Back Cover (Figure 1), and into the
bracket mounted under the Chair Back Cover.
2.2.1.3. lf the Pivot Bracket does not drop in smoothly, the
mounting screw (slightly off-center in the Chair Back) may
need to be backed out to allow the bracket to t. This screw
is a socket head set screw which requires a 1/8 hexagon
key allen wrench (included in the tool packet shipped with
the Chair) to loosen.
2.2.1.4. When the Pivot Bracket has been installed, tighten
the screw until it is snug. Replace the Back Cushion.
3. OPERATION
CAUTION- Caution should be taken to observe
that there are no obstructions (instruments,
trays, or tables) to impede the movement of
the Chair.
PRÉCAUTION : On devrait faire attention
pour s’assurer qu’il n’y a pas d’obstructions
(instruments, plateaux, tables) empêchant le
mouvement de la chaise.
WARNING- Chair capacity in the reclined
position 300 pounds; exceeding this limit may
result in insufficient stability.
AVERTISSANT- Présidez la capacité en
position reposée 136 kilogrammes ; dépasser
cette limite peut avoir comme conséquence
la stabilité insuffisante.
WARNING- Chair capacity in the upright
position 500 pounds.
AVERTISSANT- Présidez la capacité en
position droite 227 kilogrammes.
FIGURE 1
HEAD REST SLOT
RELEASE LEVER

IN-3000 7
3.1. Chair Lift
3.1.1. Raising & Lowering the Chair
3.1.1.1. A pedal-operated hydraulic lift is used to raise and
lower the Reliance® Model 3000 Chair. The Chair may be
raised by pumping the Foot Pedal until the desired height is
reached (Refer to Figure 2). Note that a stop can be felt at the
bottom of the pumping stroke. By exerting enough force to
move the pedal beyond this stop (pumping once and holding
the pedal down), a lowering valve is opened which allows the
Chair to descend (Figure 2). The Chair will stop automatically
when it reaches the lowest position available.
3.2. Revolving
3.2.1. The Chair upper structure may be revolved 360°. Pull
up on the Foot Pedal to lock the rotational movement of the
Chair with respect to the base (Figure 2).
3.3. Repositioning the Chair Back
3.3.1. The Chair back may be reclined or raised by either
pushing downward or pulling upward on the Release Lever
(Figure 1). While the back of the Chair will recline to a horizontal
position, the Foot Rest will always remain stationery.
3.4. Arm Movements
3.4.1. The Chair arms may be moved to provide better access
to the patient, or to permit entrance to or exit from the Chair.
The movements of both arms are identical and completely
independent of each other.
FIGURE 2
LOCKED
POSITION
LOWERING
POSITION
CAUTION-This exam Chair is designed
for use with a specific maximum patient
weight as a static (non-moving) load.
Sudden weight shifts or impact loads
can exceed the safe static load rating of
this Chair, and may result in insufficient
stability.
PRÉCAUTION : Cette chaise d’examen
est conçue pour utilisation avec un poids
de patient maximum spécifique comme
charge statique (sans mouvement). Les
déplacements de poids soudains ou les
charges dynamiques peuvent excéder
la norme de charge statique sécuritaire
de la chaise, ce qui pourrait causer une
stabilité insuffisante.
CAUTION-This exam Chair is designed
for use with a patient properly positioned
in the Chair. Prior to reclining the Chair,
ensure that the patient is seated in the
Chair and that the patient position does
not move to an extreme position either
toward the head of the Chair or toward
the foot of the Chair, since this may result
in insufficient stability.
PRÉCAUTION : Cette chaise d’examen est
conçue pour utilisation avec un patient
correctement positionné dans la chaise.
Avant d’incliner la chaise, assurez-vous
que le patient est assis dans la chaise et
que la position du patient ne se déplace
pas vers une position extrême soit vers
la tête, soit vers le pied de la chaise,
puisque cela pourrait causer une stabilité
insuffisante

FIGURE 4
No. 11 Headrest
3.5.4. Operation-No. 10 Headrest
3.5.4.1. The No. 10 Headrest has a xed, rigid upholstered
backboard which supports a sliding, center pillow section.
For patient comfort simply move this pillow to a desired
position.
3.5.5. Operation-No. 18 Headrest
3.5.5.1. The No. 18 headrest is designed so it can be
operated with just one hand. To unlock, squeeze the clear
plastic actuator into Lock Housing. This will allow both pivots
of the articulating arm to rotate so the Headrest can be
moved to a new desired position. Once in the new position,
release the actuator. Make sure the actuator expands to its
original position fully exposing black dot on handle to insure a
positive lock. The headrest pad is free to rotate at all times.
(See Figure 5).
WARNING: IF THE NO. 18 HEADREST
RECEIVES AN IMPACT OR STRIKES AN
OBJECT WITH FORCE, CONTACT RELIANCE®
TECHNICAL SERVICE IMMEDIATELY..
AVERTISSEMENT : SI L’APPUIE-TÊTE # 18
REÇOIT UN CHOC OU FRAPPE UN OBJET
AVEC FORCE, CONTACTEZ IMMÉDIATEMENT
LE SERVICE TECHNIQUE RELIANCE®.
IN-30008
HANDLE
SCREW
3.4.2. To raise an arm simply lift upward. A stop limits upward
motion of the arm to a point parallel to the plane of the back
(Figure 3). At its lowest position, the arm will always be parallel
to the oor or horizontal (Figure 1). There is no lock in either
the upper or lower position. Both arms will articulate when
the Chair is reclined. In other words, the arms will remain in
a horizontal position regardless of how far back the Chair is
reclined.
3.5. Headrest
3.5.1. The No. 11 Headrest is the standard Headrest for
the Model 3000 Chair.
3.5.2. Operation-No. 11 Headrest
3.5.2.1. A single handle on the rear of the No. 11 Headrests
controls the locking mechanism. To unlock, grasp the handle
and turn counter clockwise. Change the tilt of the Headrest
until it is in the desired position. To lock, turn the handle
clockwise until snug. (Figure 4)
3.5.3. Adjustment-No. 11 Headrest
3.5.3.1. The handle on the outermost knob can be adjusted
to any preferred, locked position. Simply push in on the large
screw while pulling out on the handle. Rotate as desired,
and release. (Figure 4)
FIGURE 3

IN-3000 9
3.5.6. Adjustment-No. 18 Headrest
3.5.6.1. There are two adjustments provided on the No.
18 headrest. The rst is the tension on the pad rotation.
By tightening the two hex acorn nuts on the pad pivots with
a 3/8” open end wrench, the tension will be increased. To
adjust the drag on the pivots of the articulating arm, loosen
the set screw in the center of the pivot (Figure 5, item 1)
with a 3/32” hexagon key wrench. Next, tighten the pivot
screw on the other side of the pivot, with a 1/8” hexagon
key wrench. Now, retighten the set screw to retain the pivot
screw at the new adjustment. Either pivot may be adjusted.
FIGURE 5
No. 18 Headrest
3.6. Chair Back Cover Removal (for servicing
unit)
3.6.1. Remove the front of the seat-cushion assembly by
pulling straight out from the Chair. The seat cushions are
both attached with Velcro strips. This will permit access
to the seat-back.
3.6.2. Loosen the mounting screw (Figure 7, Item 6)
(slightly off-center in the Chair back). This screw is a
socket head set screw which requires a 1/8 hexagon key
allen wrench (included in the tool packet shipped with the
Chair) to loosen. Lift out the headrest.
3.6.3. Next, the Release Levers and Release Bar must
be removed from the Chair Back (Figure 7 Items 42, 43).
On both sides of the release lever, loosen the allen screw
about two turns using a 3/32” hexagon allen wrench.
1
2
Actuator
Black Dot
Acorn Nuts
NOTE: DO NOT TRY TO REMOVE SCREWS
COMPLETELY.
NOTE: N’ESSAYEZ PAS D’ENLEVER DES VIS
COMPLÈTEMENT.
3.6.4. Remove the release bar (Figure 7, Item 40) from
the release levers by pulling straight out.
3.6.5. On both sides of the release lever (Figure 7, Item
43) (closest to seat back), remove the allen screws
(Figure 7, Item 42) using a 1/8” hexagon allen wrench.
Pull the right side of the lever off, and then pull off the left
side (Figure 7).
3.6.6. From inside the seat back, remove the four lock
nuts (Figure 7, Item 28) using a 1/2” standard wrench.
3.7. Gas Spring Adjustment
3.7.1. Remove the Chair back cover per instruction 3.6.
3.7.2. Using a 9/16” or a 17 mm open-end wrench, turn
the jam nut clockwise to loosen on turn.
3.7.3. If Chair will not release:
a. Turn Gas Spring counter-clockwise (looking down on it)
until Seat Back can be reclined.
NOTE: BE SURE GAS SPRING ROD IS NOT
BACKING OUT OF MOUNTING CLEVIS (FIGURE
7, ITEM 25).
NOTE: SOYEZ SÛR QUE TIGE D’AMORTISSEUR
N’EST PAS SOUTENIR DE LA CHAPE DE
SUPPORT (LE SCHÉMA 7, POINT 25).
b. Turn Gas Spring clockwise just until SeatBack locks,
then another turn clockwise.
c. Test the mechanism by temporarily replacing one of
the Release Levers. Test the travel of the Chair back.
d. lf actuation is not correct, turn Gas Spring counter-
clockwise, working 1/8 turn at a time.
e. lf satised with actuation; tighten the jam nut up
against the Gas Spring pivot block. Remove the release
lever that was used for testing.

IN-300010
3.9.6. Using a 3/32 hex allen wrench, remove the two
machine screws from the Base (Figure 8, Item 12).
3.9.7. Remove Cap (Figure 8, Item 6).
3.9.8. Pop off the Retaining Ring with a small screwdriver
(Figure 8, Item 5).
3.9.9. Remove the Roller-Pin by lightly tapping out with a
hammer. The Roller will come off as well.
3.9.10. Using a 1/8” allen wrench, remove the set-
screws from the Pedal shaft. Remove the Pedal by sliding
it toward the oor.
3.9.11. Roll the O-ring up from the Base and remove it
(Figure 8, Item 3). Up-end the Base.
3.9.12. Using a 1/2” wrench, remove the three bolts and
washers (Figure 8, Items 9, 10) from the Base.
CAUTION: DO NOT REMOVE THE BRASS PIPE
PLUG. REMOVAL WILL RELEASE OIL.
ATTENTION: N’ENLEVEZ PAS LA PRISE EN
LAITON DE PIPE. LE DÉPLACEMENT LIBÉRERA
L’HUILE.
3.9.13. Pull the lift away from the Base.
3.9.14. To re-assemble, reverse order of the above
instructions.
3.7.4. lf Chair will not lock:
a. Turn Gas Spring clockwise just until Seat Back locks,
then another turn clockwise.
b. Test the mechanism by temporarily replacing one of
the Release Levers. Test the travel of the Chair back.
c. lf actuation is not correct, turn gas spring counter-
clockwise, working 1/8 turn at a time.
d. lf satised with actuation, tighten the jam nut up
against the Gas Spring Pivot Block. Remove the Release
Lever that was used for testing.
3.8. Replacement of Chair Back Cover
3.8.1. From inside the seat back, replace the four lock
nuts using a 1/2” standard wrench (Figure 7, item 28).
3.8.2, Replace both Release Levers (Figure 7, item 28).
NOTE: DO NOT TIGHTEN SCREWS.
NOTE: NE SERREZ PAS LES VIS.
3.8.3. Replace the release bar by sliding into the release
lever until the allen holes line up. Tighten both set screws.
3.8.4. Tighten the screws on the release levers. It may be
necessary to slide the release bar cover out of the way
while replacing the bar.
3.8.5. Re-mount the headrest as directed in instruction
2.2.1.
3.9. Removal of Lift (for servicing unit)
3.9.1. Be sure that swivel lock is engaged. Remove seat
cushion by pulling straight up from the Chair. This will
permit access to the Chair frame.
3.9.2. Remove the Chair top from the base by removing
the piston rod bolt. Use a 3/4” socket wrench through the
hole in the seat or use a 3/4” box-end wrench under the
seat. Turn counter-clockwise about two turns.
3.9.3. Lift up on the Chair top while tapping the piston
rod bolt lightly with a hammer to free the piston rod from
the Chair top assembly.
3.9.4. Completely remove the bolt from the unit.
3.9.5. Lift the Chair off of the base.

IN-3000 11
TROUBLESHOOTING GUIDE
PROBLEM PROBLEM CAUSE SOLUTION
Chair will not lower
Chair will not raise
Chair "stutters" during ascent
Chair seat wobbles
Chair back will not recline
when release bar activated
Chair back will not lock in the
reclined or upright position
Headrest wobbles
Too much drag on swivel
1) Not holding foot pedal down past
the stop
1) Foot pedal is being held down past
the stop when pumped
1) Low on hydraulic uid
1) Seat mount screws loose
2) Piston rod bolt too loose
1) Lock not releasing due to gas
spring out of adjustment
1) Lock not releasing due to gas
spring out of adjustment
1) Mounting screw loose
1) Swivel lock partially engaged
1) Pump the foot pedal once and hold
down past stop - release when
desired height is reached
1) Pump the foot pedal lightly until the
desired height is reached
1) Contact dealer or factory for
information on addition of uid
1) Tighten screws
2) Remove seat cushion and tighten
bolt
1) Re-adjust gas spring (see
instruction 3.7)
1) Re-adjust gas spring (see
instruction 3.7)
1) Tighten mounting screw
1) Push down on the foot pedal to
release swivel lock

IN-300012
CLEANING AND MAINTENANCE
Cleaning the Upholstery
When cleaning upholstery, it is suggested that you use all
recommended commercial cleaning agents in an inconspicu-
ous spot to check for potential damage to the upholstery
material before applying to the entire area to be cleaned.
Day to Day soil:
Remove ordinary dirt and smudges with a mild soap and
warm water solution. Dry with a soft, lint-free cloth or towel.
For more difcult stains, use of a stronger detergent is
recommended; however, follow the detergent manufacturer’s
instructions closely.
Disinfecting Material:
In order to disinfect, use a 1:9 solution of bleach and water
(1 part bleach to 9 parts water). Wipe surface with damp
cloth then rinse with water immediately, using a damp cloth.
Special cleaning problems:
The following methods are recommended to clean stains
on PreFixx-protected vinyl upholstery. Most stains will be
removed when these cleaning agents are used in the fol-
lowing order.
Type 1 Cleaners: Nonabrasive household cleaners to be
used with water and a soft cloth.
• Formula 409®~ All-Purpose Spray Cleaner
• Fantastik® Spray Cleaner
• Other similar household cleaners and bleaches
Type 2 Cleaners: Solvent-type cleaner to be liberally
applied with a soft cloth. Dry area with another cloth, rinse
with clean water and dry.
• Rubbing alcohol (isopropyl alcohol)
• Lighter uid (naptha)
Type 3 Cleaners: Strong, active solvent cleaners such
as nail polish remover (acetone/water) to be applied with
a soft cloth. Stain should be removed with less than six (6)
rubs; if stain persists after six rubs, contact manufacturer.
Dry area with another cloth, rinse with clean water and dry.
“CAUTION”- These solvents are highly
flammable. Exercise proper care in cleaning
and notify personnel in area of danger. Wear
rubber gloves during all cleaning activity. Use
caution in cleaning around buttons, stitching
and wooden or other decorative trim, since
these solvents could seriously damage such
areas.
PRÉCAUTION : Ces solvants sont
extrêmement inflammables. Faites très
attention lors du nettoyage et avisez le
personnel dans la zone de tout danger.
Portez des gants de caoutchouc durant toute
activité de nettoyage. Faites attention en
nettoyant autour des boutons, des coutures
et autres finitions de bois ou décoratives,
puisque ces solvants pourraient endommager
sérieusement ces endroits.
Cleaning Painted Surfaces
The painted metal surfaces are covered in durable, powder-
coated paint which is resistant to scratching and scufng.
It may be cleaned with a clean cloth dampened with mild,
soapy water or equivalent household product that uses spray
application.
Recommended Infection Control Products
The disinfectant/cleaner products that we have tested and
recommend for our upholstery, painted items and plastic
covers are as follows.
• Cavicide® Hospital Disinfectant
• Precise® Hospital Foam Cleaner Disinfectant
“CAUTION”-Follow manufacturer’sdirections
forconcentrationandapplicationofdisinfecting
cleaner. Avoid prolonged application of any
disinfectant/cleaner products, because
they may cause staining or discoloration of
material.
PRÉCAUTION : Suivez les instructions
du fabricant pour la concentration et
l’application de nettoyeurs désinfectants.
Évitez une application prolongée de tout
produit désinfectant/nettoyant, parce que
ceux-ci pourraient causer des taches ou une
décoloration du matériel.

IN-3000 13
PARTS LIST
RELIANCE® MODEL 3000
EXAMINATION AND TREATMENT CHAIR
Note: When ordering parts, please:
1. Advise dealer or factory of model and serial number of unit. These numbers are on the
plate that is located at rear, near bottom, of Chair back.
2. Specify color of painted parts. Painted parts have an asterisk(*) behind the part description.
Note : Quand pièces de commande, s’il vous plaît :
1. Informez le distributeur ou l’usine du modèle et du numéro de série de l’ensemble. Ces
numéros sont de la plaque qui est située à l’arrière, près du bas, de l’arriére, présidence.
2. Indiquez la couleur des pièces peintes. Les pièces peintes ont un astérisque (*) derrière la
description de pièce.
Should your Exam Chair not perform properly, or if replacement parts
are needed, contact the Reliance® Distributor, where you purchased this
product or contact the Technical Service Department, Reliance® Medical
Products, Inc., 3535 Kings Mills Road, Mason, Ohio 45040-2303, or call
[phone].

IN-300014
** Please specify upholstery color when ordering.
To o r d e r c o m p l e t e U p h o l s t e r y S e t u s e P / N .
2764373 Cushion Set - 3000 - FX
FIGURE 6
3000 CHAIR ASSEMBLY
3
2
5
1
46
MODEL NUMBER AND
SERIAL NUMBER PLATE
87°
3°
11.50”
38.00”±.25
21.00”±.25
(9.00 TRAVEL)
23.97”
33.00”
54.00”
ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION
1 Chair Top Assembly* (See Figure 7) 5
2 Base Assembly* (See Figure 8) 6
3 Headrest Assemblies (See Figures 10 thru 12) 7
4 3101273 Upholstered Back Assembly** 8
3101373 Upholstered Seat Assembly**
1555773 Upholstered Arm Assembly**

IN-3000 15
(NOTES)

IN-300016
FIGURE 7
3000 CHAIR TOP ASSEMBLY
1
2
3
4
15
10
7
9
8
11
12
39
41
43 40
38
13
11
14
16
17
22
18
19
22
31
28
28
23
35
32
30
33
20
23
25
22 36
45
27
26
27
47
48
42
29
44
22 21
34
34
37
6
46
5
24

IN-3000 17
*Please specify paint color when ordering.
Table Figure 7
3000 CHAIR TOP ASSEMBLY
ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION
1
1553676 Foot Rest Extrusion
1571899 Standoff - Long
1523699 Truss H.M.S., 5/16 - 18 X 3/8
0824999 Hex Nut, 5/16 - 18
1571799 Standoff - Short
0729999 Washer, Flat 1/4
0397999 Washer, Fiber
1037399 R.H.M.S. 1/4 - 20 X 2”
Pivot Block Pin
25 Gas Spring Assembly1512392
Arm Rest Weldment Assembly1556187
Roll Pin - .38 Dia x 1”1639299
Arm Rest Pivot Bar Assembly, RH
Arm Rest Pivot Bar Assembly, LH
Arm Rest Pivot Block
Release Bar
Release Bar Cover
S.H.S.S., 10 - 24 X 1/2
Release Lever
Gas Spring Mounting Bracket
Gas Spring Release Pivot
Gas Spring Pivot Block
Nut, Jam - M10 X 1
Ball, Steel, 5/8” Dia
Gas Spring Release Actuator
1558692
1558792
1556587
1556699
1556799
1556899
1572087
1557095
1572199
1472195
1531999
0978499
1572295
1509199
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
20711999 R.H.M.S. 1/4-20 X 1/2
3 1571387 Foot Rest Bar - RH
1571487 Foot Rest Bar - LH4
1571999 F.H.M.S #10-24 X 3/4
0284599 S.H.S.S., 1/4 - 28 X .38
22
23
24
5
H.H.C.S. 5/16 - 18 X 2"
6
0282199
Washer 5/160730199
Split Lock Washer - 5/16
7
0728399
Nut, Hex 5/16 - 180704899
Seat/Back Plate
8
1554187
Seat Support, Mach - 30001554287
Pivot, Gas Spring
9
1571599
Sleeve Bearing
10
H.H.C.S. 5/16 - 18 X 1”
11
Bracket, Hinge - RH
12
Bracket, Hinge - LH
13
Pin, Dowel 1/2 X 1”
Pin - Hanger Hinge
Plate, Arm Rest
Roll Pin, 3/16 X 1”
Retaining Ring
Arm Link
Back Cover*
14
15
16
17
18
19
20
21
1554799
0707199
1300387
1300487
1481799
0602999
1571687
0761899
0732599
1554887
1554997
3084703 Foot Rest - 3000*

IN-300018
FIGURE 8
CHAIR BASE ASSEMBLY
7
5
4
3
2
11
1
10
13
12
8
6
9

IN-3000 19
To order complete Base Assembly use P/N.
2828592 Base Assembly - 3000
ITEM PART NO. DESCRIPTION
1See Fig 9 Lift Assembly - 3000
21990087 3000 Stamped Base
3 0592499 O-Ring
1552980 Pedal4
0732499 Retaining Ring - “E” Type
0544787 Cap
5
Roller
6
0486599
Roller Pin0532299
B.H.C.S., 5/16-24 x 1.25
7
0808799
Washer, 5/16 SAE0730199
S.H.S.S., 1/4-20 x .38 KCP
8
0722899
9
10
11
163349912 B.H.C.S., - 8-32 X 3/8
052779913 Nut, Flex Loc - 5/16-24
Table Figure 8
CHAIR BASE ASSEMBLY

IN-300020
FIGURE 9
CHAIR LIFT ASSEMBLY
