Reva L-ion User manual
owner’s manual
IMPORTANT
Please read this manual and follow the
instructions carefully.
Signal words CAUTION and NOTE
have special meanings.
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in injury or
property damage.
CAUTION
NOTE indicates information to assist
maintenance and instructions.
NOTE
Obey all safety messages that follow
these symbols.
: This asterisk in the manual
signifies that an item is an optional /
extra.
All information, illustrations and
specifications in this Owner’s Manual
were in effect at the time of printing.
Reva in the course of product
development reserves the right to
discontinue or change specifications or
design at any time without notice and
without incurring any obligation
whatsoever.
2
Congratulations ! You have made a wise decision by choosing to own this
automatic electric vehicle!
Reva is a whole new concept in city mobility, a step forward towards a pollution
free environment – something our future generations will thank us for. And with it,
Reva will provide you with years of hassle free ownership.
Please read this Owner’s Manual carefully. It has been structured to provide you
with all information you need on the operation and maintenance of your vehicle.
Please keep it safe, as it will be of helpful should you require any assistance.
We also encourage you to carefully read the Warranty terms and conditions. It will
help you to understand the warranty coverage and responsibilities for ensuring
warranty protection for your vehicle.
Your Reva Maintenance schedule is also provided in this manual. Following the
schedule will help to keep your driving hassle free and also preserve your
investment.
Everyone here at Service centre is dedicated to ensure your driving satisfaction.
Please email us at customercare@reva-ev.com should you have any questions or
concerns at anytime.
We wish you the joy of commuting without polluting!
FOREWORD
1
IMPORTANT
Please read this manual and follow the
instructions carefully.
Signal words CAUTION and NOTE
have special meanings.
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in injury or
property damage.
CAUTION
NOTE indicates information to assist
maintenance and instructions.
NOTE
Obey all safety messages that follow
these symbols.
: This asterisk in the manual
signifies that an item is an optional /
extra.
All information, illustrations and
specifications in this Owner’s Manual
were in effect at the time of printing.
Reva in the course of product
development reserves the right to
discontinue or change specifications or
design at any time without notice and
without incurring any obligation
whatsoever.
2
Congratulations ! You have made a wise decision by choosing to own this
automatic electric vehicle!
Reva is a whole new concept in city mobility, a step forward towards a pollution
free environment – something our future generations will thank us for. And with it,
Reva will provide you with years of hassle free ownership.
Please read this Owner’s Manual carefully. It has been structured to provide you
with all information you need on the operation and maintenance of your vehicle.
Please keep it safe, as it will be of helpful should you require any assistance.
We also encourage you to carefully read the Warranty terms and conditions. It will
help you to understand the warranty coverage and responsibilities for ensuring
warranty protection for your vehicle.
Your Reva Maintenance schedule is also provided in this manual. Following the
schedule will help to keep your driving hassle free and also preserve your
investment.
Everyone here at Service centre is dedicated to ensure your driving satisfaction.
Please email us at customercare@reva-ev.com should you have any questions or
concerns at anytime.
We wish you the joy of commuting without polluting!
FOREWORD
1
Main Controls ..................................................
1.0 Instrument Cluster & Controls .........................
2.0 Climate Control Seats........................................
3.0 Charging Your Reva ..........................................
4.0 Driving Your Reva .............................................
5.0 Tyres .................................................................
6.0 Do’s and Don’ts ................................................
7.0 Troubleshooting ...............................................
8.0 Maintenance .....................................................
9.0 Service Schedule ...............................................
10.0 Reva’s Safety Features .......................................
11.0 Key Technologies ..............................................
12.0 Power Pack .......................................................
13.0 Technical Specifications .....................................
14.0 Vehicle identification numbers ..........................
15.0 Index ................................................................
4
5&6
33
35
43
49
57
63
69
81
85
87
91
95
99
101
CONTENTS
3
MAIN CONTROLS
Main controls
ROOF LIGHT SWITCH
DOOR LOCK
DOOR OPENING
LEVER
SEAT-RECLINING
LEVER
HATCH OPENING
LEVER
SEAT-SLIDING
LEVER
HAZARD WARNING
SWITCH
CONTROL KNOB
HEAD LIGHTS +TURN
SIGNAL LEVER
PARKING BRAKE
FUSE BOX
ACCELERATOR PEDAL
BRAKE PEDAL
4
Main Controls ..................................................
1.0 Instrument Cluster & Controls .........................
2.0 Climate Control Seats........................................
3.0 Charging Your Reva ..........................................
4.0 Driving Your Reva .............................................
5.0 Tyres .................................................................
6.0 Do’s and Don’ts ................................................
7.0 Troubleshooting ...............................................
8.0 Maintenance .....................................................
9.0 Service Schedule ...............................................
10.0 Reva’s Safety Features .......................................
11.0 Key Technologies ..............................................
12.0 Power Pack .......................................................
13.0 Technical Specifications .....................................
14.0 Vehicle identification numbers ..........................
15.0 Index ................................................................
4
5&6
33
35
43
49
57
63
69
81
85
87
91
95
99
101
CONTENTS
3
MAIN CONTROLS
Main controls
ROOF LIGHT SWITCH
DOOR LOCK
DOOR OPENING
LEVER
SEAT-RECLINING
LEVER
HATCH OPENING
LEVER
SEAT-SLIDING
LEVER
HAZARD WARNING
SWITCH
CONTROL KNOB
HEAD LIGHTS +TURN
SIGNAL LEVER
PARKING BRAKE
FUSE BOX
ACCELERATOR PEDAL
BRAKE PEDAL
4
Instrument cluster
5
INSTRUMENT CLUSTER
TURN SIGNALS
LOW BEAM LIGHT POWER GAUGE
PARKING BRAKE / LOW
BRAKE FLUID LIGHT
BATTERY LOW WATER
LIGHT (Not used)
HIGH BEAM LIGHT
TEMPERATURE LIGHT
SPEEDOMETER
ODOMETER /
TRIP METER
ENCODER FAULT
= NEUTRAL (drive sequence)
= CHARGING
= LOW BATTERY
= SERVICE
= (GREEN) REGEN (RED) EXTRA
POWER USAGE (Dual
colored LED)
Kms / MilesKms / Miles
1.1 Indicator Lights ....................................................
1.2 Gauges..................................................................
1.3 Steering Wheel Controls........................................
1.4 Control Knob .......................................................
1.5 Climate Control System.........................................
1.6 Keys / Key switches...............................................
1.7 Door Locks ..........................................................
1.8 Seat Adjustment....................................................
1.9 Hood ....................................................................
1.10 Rear Hatch ...........................................................
1.11 Parking Brake .......................................................
1.12 Roof Lights ..........................................................
1.13 Compartments.......................................................
1.14 Mirrors, Audio system, sunvisor, 12V socket..........
7
12
13
15
16
20
21
24
28
29
30
30
31
32
6
Instrument cluster
5
INSTRUMENT CLUSTER
TURN SIGNALS
LOW BEAM LIGHT POWER GAUGE
PARKING BRAKE / LOW
BRAKE FLUID LIGHT
BATTERY LOW WATER
LIGHT (Not used)
HIGH BEAM LIGHT
TEMPERATURE LIGHT
SPEEDOMETER
ODOMETER /
TRIP METER
ENCODER FAULT
= NEUTRAL (drive sequence)
= CHARGING
= LOW BATTERY
= SERVICE
= (GREEN) REGEN (RED) EXTRA
POWER USAGE (Dual
colored LED)
Kms / MilesKms / Miles
1.1 Indicator Lights ....................................................
1.2 Gauges..................................................................
1.3 Steering Wheel Controls........................................
1.4 Control Knob .......................................................
1.5 Climate Control System.........................................
1.6 Keys / Key switches...............................................
1.7 Door Locks ..........................................................
1.8 Seat Adjustment....................................................
1.9 Hood ....................................................................
1.10 Rear Hatch ...........................................................
1.11 Parking Brake .......................................................
1.12 Roof Lights ..........................................................
1.13 Compartments.......................................................
1.14 Mirrors, Audio system, sunvisor, 12V socket..........
7
12
13
15
16
20
21
24
28
29
30
30
31
32
6
1.1 INDICATOR LIGHTS
Instrument Cluster and Controls
IV. TEMPERATURE LIGHT
If the light glows while
driving/charging, it indicates
overheating in either or all of the
following components:
1. Motor
2. Motor Controller
3. Power Pack
4. Charger
In cold climate, the temperature light
will flash during charge or drive, if
battery temperature is less than 10°C.
This indicates that the range of the
Reva is likely to be low.
When Vehicle is not in use, keeping it
plugged in to the utility supply under
this condition will activate the battery
heaters and warm up the batteries.
While in charge, if the light
continues to glow/flash, it
indicates increased charging time
due to high Power Pack /
Charger temperature.
NOTE
Do not charge your Reva in high
ambient temperature conditions
or in direct sunlight.This will
reduce the life of your Power
Pack.
CAUTION
.III. EQUALIZATION (Shunting
process) Batteries are programmed to
automatically perform “Equalization
Charge” in every charge cycle. This
ensures all individual batteries of
power pack are equalized when in
need. This process is not indicated to
the user.
8
1.1 INDICATOR LIGHTS
When the key is turned ON or
OFF, some of the lights of the IP
cluster glow for short time.
This is part of the Vehicle’s self
test program.
If case you notice any change in
this behavior during usage,
please contact Service centre
or customercare@reva-ev.com
NOTE I. CHARGE LIGHT (Green)
This light should come on and flash
green when your Reva is put on
charge. This indicates that charging is
taking place. When the Power Pack is
fully charged, the light stops flashing
and glows green permanently.
The light disappears when the charge
cable is removed from the charge port.
.II. LOW BATTERY LIGHT (Red)
When the State-Of-Charge (SOC) in
the Power Pack drops to about 25%,
this light starts flashing. The
AC/Heating will automatically switch
OFF (if it is ON) at 25% soc
The light turns solid red once the SOC
goes down to 15%. This is a warning
and at this stage it is advisable to
charge at the first opportunity. Speed
of vehicle will be limited while if driving
in ‘B’ mode
Instrument Cluster and Controls
CHARGE LIGHT
Driving at conditions of 10% SOC
or less will reduce Power Pack life,
cause damage and affect its
warranty.
CAUTION
LOW BATTERY LIGHT
7
1.1 INDICATOR LIGHTS
Instrument Cluster and Controls
IV. TEMPERATURE LIGHT
If the light glows while
driving/charging, it indicates
overheating in either or all of the
following components:
1. Motor
2. Motor Controller
3. Power Pack
4. Charger
In cold climate, the temperature light
will flash during charge or drive, if
battery temperature is less than 10°C.
This indicates that the range of the
Reva is likely to be low.
When Vehicle is not in use, keeping it
plugged in to the utility supply under
this condition will activate the battery
heaters and warm up the batteries.
While in charge, if the light
continues to glow/flash, it
indicates increased charging time
due to high Power Pack /
Charger temperature.
NOTE
Do not charge your Reva in high
ambient temperature conditions
or in direct sunlight.This will
reduce the life of your Power
Pack.
CAUTION
.III. EQUALIZATION (Shunting
process) Batteries are programmed to
automatically perform “Equalization
Charge” in every charge cycle. This
ensures all individual batteries of
power pack are equalized when in
need. This process is not indicated to
the user.
8
1.1 INDICATOR LIGHTS
When the key is turned ON or
OFF, some of the lights of the IP
cluster glow for short time.
This is part of the Vehicle’s self
test program.
If case you notice any change in
this behavior during usage,
please contact Service centre
or customercare@reva-ev.com
NOTE I. CHARGE LIGHT (Green)
This light should come on and flash
green when your Reva is put on
charge. This indicates that charging is
taking place. When the Power Pack is
fully charged, the light stops flashing
and glows green permanently.
The light disappears when the charge
cable is removed from the charge port.
.II. LOW BATTERY LIGHT (Red)
When the State-Of-Charge (SOC) in
the Power Pack drops to about 25%,
this light starts flashing. The
AC/Heating will automatically switch
OFF (if it is ON) at 25% soc
The light turns solid red once the SOC
goes down to 15%. This is a warning
and at this stage it is advisable to
charge at the first opportunity. Speed
of vehicle will be limited while if driving
in ‘B’ mode
Instrument Cluster and Controls
CHARGE LIGHT
Driving at conditions of 10% SOC
or less will reduce Power Pack life,
cause damage and affect its
warranty.
CAUTION
LOW BATTERY LIGHT
7
1.1 INDICATOR LIGHTS
Instrument Cluster and Controls
V. SERVICE LIGHT
When the start-up key is turned ON,
this light should glow red and
disappear immediately. In the event it
stays on, it indicates that your Reva
requires attention by Service centre
The appearance of service light can
be due to a temporary condition
detected by EMS (On board
computer). Please continue using
the vehicle and inform your service
center at the earliest opportunity.
CAUTION
VI. NEUTRAL LIGHT
This light will be on when BFNR knob
is at ‘N’ position. This light will blink if
the key is switched on with control
knob in either B, F and R position. If
this light is blinking car will not move,
please turn the control knob to N and
then to desired mode to drive the
Reva.
Ensure knob position in NEUTRAL
before start-up
NOTE
N
VII. POWER INDICATOR
This light will come on GREEN during
regen and will glow RED when ever
more power is drawn from the battery.
This is an indication to driver to
achieve an optimum mileage out of
Reva by gradual acceleration
VIII. ENCODER FAULT LIGHT
This light glows during driving which
indicates a Drive system fault. Please
call service centre for needful.
10
1.1 INDICATOR LIGHTS
Instrument Cluster and Controls
If you attempt to drive with the
light glowing red, you will notice
that the performance of your
vehicle is reduced.
If you still continue to drive, the
temperature light will flash and
your vehicle will soon stop to
protect its drive system.
CAUTION
9
A flashing (ON/OFF) temperature
light during drive indicates a
severe over temperature condition
and may completely restrain the
vehicle.
If you continue driving the vehicle,
electronics may reduce the speed
and power in order to limit the
heating of components.
In any such a situation, switch the
vehicle off and start again
approximately after 15 min. If it
continues to glow, it is advisable to
contact Service centre
1.1 INDICATOR LIGHTS
Instrument Cluster and Controls
V. SERVICE LIGHT
When the start-up key is turned ON,
this light should glow red and
disappear immediately. In the event it
stays on, it indicates that your Reva
requires attention by Service centre
The appearance of service light can
be due to a temporary condition
detected by EMS (On board
computer). Please continue using
the vehicle and inform your service
center at the earliest opportunity.
CAUTION
VI. NEUTRAL LIGHT
This light will be on when BFNR knob
is at ‘N’ position. This light will blink if
the key is switched on with control
knob in either B, F and R position. If
this light is blinking car will not move,
please turn the control knob to N and
then to desired mode to drive the
Reva.
Ensure knob position in NEUTRAL
before start-up
NOTE
N
VII. POWER INDICATOR
This light will come on GREEN during
regen and will glow RED when ever
more power is drawn from the battery.
This is an indication to driver to
achieve an optimum mileage out of
Reva by gradual acceleration
VIII. ENCODER FAULT LIGHT
This light glows during driving which
indicates a Drive system fault. Please
call service centre for needful.
10
1.1 INDICATOR LIGHTS
Instrument Cluster and Controls
If you attempt to drive with the
light glowing red, you will notice
that the performance of your
vehicle is reduced.
If you still continue to drive, the
temperature light will flash and
your vehicle will soon stop to
protect its drive system.
CAUTION
9
A flashing (ON/OFF) temperature
light during drive indicates a
severe over temperature condition
and may completely restrain the
vehicle.
If you continue driving the vehicle,
electronics may reduce the speed
and power in order to limit the
heating of components.
In any such a situation, switch the
vehicle off and start again
approximately after 15 min. If it
continues to glow, it is advisable to
contact Service centre
1.1 INDICATOR LIGHTS
XI. PARKING BRAKE / LOW
BRAKE FLUID LIGHT
Parking brake light (P) with continous
alarm chime indicates you are driving
with the parking brake engaged.
Low brake fluid light (!) with
intermittent chime indicates low brake
fluid level. Please top up the brake
fluid at the first oppurtunity.
Instrument Cluster and Controls
IX. HIGH BEAM
This lamp glows when the high beam
headlights are turned on.
XII. TURN INDICATOR
The turn indicator light on the cluster
will flash when either right turn or left
turn indicator is turned ON and for
hazards warning light.
X. LOW BEAM
This lamp glows when the headlights
are turned to low beam.
In the event this light continues to
glow irrespective of the above,
please contact Reva service centre.
NOTE
11
1.2 GAUGES
I. POWER GAUGE
This gauge, like the fuel gauge in a
conventional automobile, indicates
your possible range of transportation
with the energy source available.
(Refer chapter on “Driving Your
Reva”).
Instrument Cluster and Controls
II. SPEEDOMETER
The outer perimeter (white) indicates
the speed of your car in Kilometers
(Kmph) and the inner perimeter
indicates speed of your vehicle in miles
(Mph).
III. ODOMETER
The odometer records the total distance
in Kilometers that your vehicle has
completed.
IV. TRIP METER
Trip meter can be used to measure the
distance traveled on short trips between
stops.
Keep track of your odometer
reading and check the
maintenance schedule regularly for
required services. Increased wear
or damage to certain parts can
result from failure to perform
required services at the proper
mileage intervals and your
warranty rights may be affected.
CAUTION
Display Length
Total - 0 to 999999 Kms
Trip A- 0.0 to 9999.9 Kms
Trip B- 0.0 to 9999.9 Kms
ƒ Total odometer will be displayed by
default.
ƒ Push the reset button under 1-2
seconds, you can select Total ---> TRIP
A ---> TRIP B
ƒ Push the reset button over 1-2 seconds,
display data is reset. Count start from
switch ON --->OFF (Only at trip
odometer display)
12
SPEEDOMETER
ODOMETER
ODO TRIP
AB
88888.8
Reset
button
Kms / Miles
1.1 INDICATOR LIGHTS
XI. PARKING BRAKE / LOW
BRAKE FLUID LIGHT
Parking brake light (P) with continous
alarm chime indicates you are driving
with the parking brake engaged.
Low brake fluid light (!) with
intermittent chime indicates low brake
fluid level. Please top up the brake
fluid at the first oppurtunity.
Instrument Cluster and Controls
IX. HIGH BEAM
This lamp glows when the high beam
headlights are turned on.
XII. TURN INDICATOR
The turn indicator light on the cluster
will flash when either right turn or left
turn indicator is turned ON and for
hazards warning light.
X. LOW BEAM
This lamp glows when the headlights
are turned to low beam.
In the event this light continues to
glow irrespective of the above,
please contact Reva service centre.
NOTE
11
1.2 GAUGES
I. POWER GAUGE
This gauge, like the fuel gauge in a
conventional automobile, indicates
your possible range of transportation
with the energy source available.
(Refer chapter on “Driving Your
Reva”).
Instrument Cluster and Controls
II. SPEEDOMETER
The outer perimeter (white) indicates
the speed of your car in Kilometers
(Kmph) and the inner perimeter
indicates speed of your vehicle in miles
(Mph).
III. ODOMETER
The odometer records the total distance
in Kilometers that your vehicle has
completed.
IV. TRIP METER
Trip meter can be used to measure the
distance traveled on short trips between
stops.
Keep track of your odometer
reading and check the
maintenance schedule regularly for
required services. Increased wear
or damage to certain parts can
result from failure to perform
required services at the proper
mileage intervals and your
warranty rights may be affected.
CAUTION
Display Length
Total - 0 to 999999 Kms
Trip A- 0.0 to 9999.9 Kms
Trip B- 0.0 to 9999.9 Kms
ƒ Total odometer will be displayed by
default.
ƒ Push the reset button under 1-2
seconds, you can select Total ---> TRIP
A ---> TRIP B
ƒ Push the reset button over 1-2 seconds,
display data is reset. Count start from
switch ON --->OFF (Only at trip
odometer display)
12
SPEEDOMETER
ODOMETER
ODO TRIP
AB
88888.8
Reset
button
Kms / Miles
1.3 STEERING WHEEL
II. LOW BEAM / HIGH BEAM
To change between low beam and
high beam, pull the turn signal lever
until you hear a click, then let go. To
flash the high beam, pull the lever
slightly towards you and release it in a
quick action. Flashing the high beam is
necessary at times to warn traffic in
the front about your presence,
especially while overtaking at night.
Instrument Cluster and Controls
III. TURN SIGNALS
The turn signal lights blink when you
signal a lane change or turn.
Turn the side indicator lever upwards
for left turn and downwards for right
turn respectively.
I. HEADLIGHTS
This lever operating the headlights has
three positions. They are:
1. OFF - In this position, all lights are
off.
2. Middle Position - Front parking
lights, tail lights, registration plate
lights and dashboard backlighting
is lit but headlights remain off.
3. Third Position - The headlight also
comes on when the lever is turned
to this position.
OFF
OFF
F
OF
13
1.3 STEERING WHEEL
IV. WINDSCREEN WIPER
To operate the windscreen wiper, twist
the lever from OFF position to any of
the operating positions as required.
The speed of the wiper can be varied
to intermittent*, low and high by
operating the lever switch.
To spray windscreen washer fluid, pull
the lever towards you, the wiper will
come ON for a few seconds/ wipes.
Instrument Cluster and Controls
V. HAZARD WARNING
Pull up the switch to activate the
hazard warning lights. All six external
turn signal indicators will flash
simultaneously. To turn off the lights,
push the switch down. These lights
can be used to warn the traffic in the
event of any emergency.
VI. HORN
The horn is integrated in the center
pad of the steering wheel. Press
anywhere on this pad to sound horn.
PUL
L
PUL
L
14
*Applicable model*Applicable model
1.3 STEERING WHEEL
II. LOW BEAM / HIGH BEAM
To change between low beam and
high beam, pull the turn signal lever
until you hear a click, then let go. To
flash the high beam, pull the lever
slightly towards you and release it in a
quick action. Flashing the high beam is
necessary at times to warn traffic in
the front about your presence,
especially while overtaking at night.
Instrument Cluster and Controls
III. TURN SIGNALS
The turn signal lights blink when you
signal a lane change or turn.
Turn the side indicator lever upwards
for left turn and downwards for right
turn respectively.
I. HEADLIGHTS
This lever operating the headlights has
three positions. They are:
1. OFF - In this position, all lights are
off.
2. Middle Position - Front parking
lights, tail lights, registration plate
lights and dashboard backlighting
is lit but headlights remain off.
3. Third Position - The headlight also
comes on when the lever is turned
to this position.
OFF
OFF
F
OF
13
1.3 STEERING WHEEL
IV. WINDSCREEN WIPER
To operate the windscreen wiper, twist
the lever from OFF position to any of
the operating positions as required.
The speed of the wiper can be varied
to intermittent*, low and high by
operating the lever switch.
To spray windscreen washer fluid, pull
the lever towards you, the wiper will
come ON for a few seconds/ wipes.
Instrument Cluster and Controls
V. HAZARD WARNING
Pull up the switch to activate the
hazard warning lights. All six external
turn signal indicators will flash
simultaneously. To turn off the lights,
push the switch down. These lights
can be used to warn the traffic in the
event of any emergency.
VI. HORN
The horn is integrated in the center
pad of the steering wheel. Press
anywhere on this pad to sound horn.
PUL
LPUL
L
14
*Applicable model*Applicable model
1.4 CONTROL KNOB
Instrument Cluster and Controls
CONTROL KNOB
The control knob of your Reva enables
you to choose the direction and speed
of movement.
It has the following positions:
Forward [F]:
This is the normal driving mode
position which enables you to move
forward. (max speed is 75kmph) and
driving in this will give the best driving
range out of your vehicle.
Power Boost [B]:
This mode is to be used ‘only’ if ‘Boost
Power’ is required. This position also
enables you to move forward direction,
will give you addition speed for more
acceleration and hill climbing.
Neutral [N]:
The RNFB knob should be in this
position at the time of Key on and
should be used while parking your
Reva, or when you place your Reva in
a stationary position.
Reverse [R]:
When you rotate the control knob to
this position, your Reva would move in
the reverse direction. Your speed in
this position is limited to 20 Kmph.
(To know more about how to derive the
maximum range from your vehicle,
please refer to section 4.0 on “Driving
your Reva”)
RR
BB
FF
NN
While climbing steep gradients, it
is advisable to switch over to ‘B’
mode for better gradeability.
NOTE
15
1.5 CLIMATE CONTROL SYSTEM - CONTROLS
Instrument Cluster and Controls
1122
33
44
BLOWER/DEFROSTER
SELECTOR LEVER
BLOWER/HEATER
KNOB
12V D.C.
SOCKET
DEFOGGER
SWITCH
REAR FOG
LAMP SWITCH
A/C VARIABLE
THERMOSTAT KNOB
16
1.4 CONTROL KNOB
Instrument Cluster and Controls
CONTROL KNOB
The control knob of your Reva enables
you to choose the direction and speed
of movement.
It has the following positions:
Forward [F]:
This is the normal driving mode
position which enables you to move
forward. (max speed is 75kmph) and
driving in this will give the best driving
range out of your vehicle.
Power Boost [B]:
This mode is to be used ‘only’ if ‘Boost
Power’ is required. This position also
enables you to move forward direction,
will give you addition speed for more
acceleration and hill climbing.
Neutral [N]:
The RNFB knob should be in this
position at the time of Key on and
should be used while parking your
Reva, or when you place your Reva in
a stationary position.
Reverse [R]:
When you rotate the control knob to
this position, your Reva would move in
the reverse direction. Your speed in
this position is limited to 20 Kmph.
(To know more about how to derive the
maximum range from your vehicle,
please refer to section 4.0 on “Driving
your Reva”)
RR
BB
FF
NN
While climbing steep gradients, it
is advisable to switch over to ‘B’
mode for better gradeability.
NOTE
15
1.5 CLIMATE CONTROL SYSTEM - CONTROLS
Instrument Cluster and Controls
1122
33
44
BLOWER/DEFROSTER
SELECTOR LEVER
BLOWER/HEATER
KNOB
12V D.C.
SOCKET
DEFOGGER
SWITCH
REAR FOG
LAMP SWITCH
A/C VARIABLE
THERMOSTAT KNOB
16
Instrument Cluster and Controls
V. A/C VARO SYSTEM*
This is an optional feature.
To operate the air conditioner, turn on
the Blower and rotate the Varo Knob
for desired cooling position. Cool air
will be Blown through the main vents
gradually.
The A/C Varo knob is located below
the Blower switch and has a blue back
light in the ON condition. The Varo
system allows you to steplessly set the
amount of cooling you need and has
an added advantage in getting more
mileage by setting at low cooling.
11
22
33
44
IV. HEATER *
To operate the Heater, pull the Blower
knob gently towards yourself and turn
it to desired position.
The ‘HEAT’ symbol (in the center of
the knob) will light up.
Heater will automatically switch off
when SOC goes less than 25%.
1.5 CLIMATE CONTROL SYSTEM -
III. BLOWER/ DEFROSTER-
DEMISTER SELECTOR
The direction of air flow from the
blower can be changed by positioning
the Blower/ Defroster-Demister
Selector Lever.
Positioning this lever to the right -
directs air towards the cabin.
Positioning it to the left - directs air
towards the windshield and window -
acting as Defroster and Demister
respectively in Heater ON position.
Use on low setting to increase
mileage during drive
NOTE
18
*Applicable model*Applicable model
11
22
3344
1.5 CLIMATE CONTROL SYSTEM - CONTROLS
Instrument Cluster and Controls
I. AIR FLOW VENTS
The Reva is equipped with a blower
system with air flow vents provided to
circulate air in the vehicle.
1. The central (circular) vents direct air
towards the cabin.
2. The vents near the windshield
directs air towards it.
3. The vents at the two corners of the
dashboard directs air onto the
windows.
II. BLOWER OPERATION
The Blower can be operated by turning
the knob from OFF position to any of
the desired 4 operating positions.
The louvers of the central vents can be
adjusted to direct the air for better
comfort.
Do not switch the blower on
before switching the Reva on.
Continuous use of the blower can
effect the range of the vehicle.
Always switch the blowers off
before turning the vehicle off.
CAUTION
17
NOTE
Instrument Cluster and Controls
V. A/C VARO SYSTEM*
This is an optional feature.
To operate the air conditioner, turn on
the Blower and rotate the Varo Knob
for desired cooling position. Cool air
will be Blown through the main vents
gradually.
The A/C Varo knob is located below
the Blower switch and has a blue back
light in the ON condition. The Varo
system allows you to steplessly set the
amount of cooling you need and has
an added advantage in getting more
mileage by setting at low cooling.
11
22
33
44
IV. HEATER *
To operate the Heater, pull the Blower
knob gently towards yourself and turn
it to desired position.
The ‘HEAT’ symbol (in the center of
the knob) will light up.
Heater will automatically switch off
when SOC goes less than 25%.
1.5 CLIMATE CONTROL SYSTEM -
III. BLOWER/ DEFROSTER-
DEMISTER SELECTOR
The direction of air flow from the
blower can be changed by positioning
the Blower/ Defroster-Demister
Selector Lever.
Positioning this lever to the right -
directs air towards the cabin.
Positioning it to the left - directs air
towards the windshield and window -
acting as Defroster and Demister
respectively in Heater ON position.
Use on low setting to increase
mileage during drive
NOTE
18
*Applicable model*Applicable model
11
22
3344
1.5 CLIMATE CONTROL SYSTEM - CONTROLS
Instrument Cluster and Controls
I. AIR FLOW VENTS
The Reva is equipped with a blower
system with air flow vents provided to
circulate air in the vehicle.
1. The central (circular) vents direct air
towards the cabin.
2. The vents near the windshield
directs air towards it.
3. The vents at the two corners of the
dashboard directs air onto the
windows.
II. BLOWER OPERATION
The Blower can be operated by turning
the knob from OFF position to any of
the desired 4 operating positions.
The louvers of the central vents can be
adjusted to direct the air for better
comfort.
Do not switch the blower on
before switching the Reva on.
Continuous use of the blower can
effect the range of the vehicle.
Always switch the blowers off
before turning the vehicle off.
CAUTION
17
NOTE
III. CHIME
The chime comes on under the
following circumstances:
1. Door/s is opened while the Key
Switch is ON.
2. Door/s is opened while the
headlights are ON (though Key
Switch is OFF.)
3. If Parking Brake is engaged, Key
Switch is ON and accelerator is
pressed.
4. Brake Fluid is low during charge
and drive. (An intermittent chime
comes on in this case).
5. When you leave the Reva without
applying parking brake i.e. Key
Switch is OFF, door is open and
Parking Brake is not applied.
6. Drive stop error / HPD sequence
fault with key On condition.
1.6 KEYS / KEY SWITCH / CHIME
I. KEYS
Your Reva comes with two identical
keys. They fit all the locks on your
vehicle - Key Switch and Doors. Each
key has an identification number
stamped on it.
In the event of any loss or theft, in
order to provide you with a new set of
keys by the service centre, it is
suggested to note down the key
number and store it in a safe place.
Instrument Cluster and Controls
II. KEY SWITCH
The key switch is on the right side of
the steering column.
It has 2 positions:
1. Lock (OFF):
The key can be inserted and removed
only in this position.
2. ON:
When you turn the key to this
position all electrical features in your
vehicle will come on.
KEY SWITCH
20
Always remember to switch OFF
the Defogger switch once the hatch
gets cleared OR after 10 mins of
continuous operation.
Not doing so will reduce your
driving range significantly.
* optional
NOTE
Instrument Cluster and Controls
VI. REAR FOG LAMP*
The Reva is fitted with a rear fog lamp
to enable other vehicles (coming from
the rear) to pin-point your car in foggy
weather conditions.
The rear fog lamp can be activated by
pressing the rear fog lamp switch
provided on the dashboard. Switch
symbol gets backlit when ON.
Press again to switch it OFF.
VII. REAR DEFOGGER*
The rear hatch defogger will clear the
fog, frost or thin ice, to give you a clear
rear view.
The defogger can be activated by
pressing the defogger switch provided
on the dashboard. Switch symbol gets
backlit when ON.
Press again to switch it OFF.
1.5 CLIMATE CONTROL SYSTEM - CONTROLS
In case both - the Heater and the
A/C are ON at the same time ,
only the A/C will function.
(i.e. the A/C overrides the Heater
and the Blower)
NOTE
!Heater or A/C will not operate
when the vehicle's soc is less
than 25% (Low Battery light starts
flashing).
!Heater or A/C will not operate
when the Reva is in the
Equalisation mode.
NOTE
19
*Applicable model*Applicable model
