Hongqi HS5 User manual

Foreword
Thank you for choosing Hongqi HS5!
All FAW vehicle models have passed China Compulsion Certification (CCC Certification) and
Gulf Cooperation Council Certification (GCC Certification).
Hongqi HS5sedan carries multiple luxury equipment and advanced technology. To take full
advantage of these equipment and technology, FAW recommends you read this manual
thoroughly to know Hongqi HS5 sedan quickly and comprehensively.
In addition to introducing the use of the vehicle, this manual explains the driving safety, vehicle
maintenance and emergency countermeasures in detail to help you drive this vehicle safely
and comfortably, and meanwhile maintain the value ofthe vehicle tothe maximum degree.
The documents provided with the vehicle include this Owner's Manual, Maintenance Manual,
which contain the important maintenance information for HS5Sedan. FAW suggests you keep
the documents provided inside the vehicle for reference at any time.
This manual is compiled in accordance with the product situations at the time of printing. It will
be modified into a second edition for the subsequent products. FAW will reserve the right to
make changes atany time without notice. Thank you for your understanding.
First Automobile Works (FAW)

1
Contents
Pictorial Index
Search by illustration
1
Safety Instructions
One must read through the safety instructions.
2
Instrument Cluster
How to read instruments, various alarm lights and
indicators, etc.
3
Operating the Components
The opening/closing of windows and doors, adjustments
before driving, etc.
4
Driving
Required operations and advice while driving
5
Audio System
Audio system operation
6
Interior Equipment
Usage of interior equipment, etc.
7
Maintenance
Steps of vehicle maintenance
8
When Failure Arises
Measures for failures or emergencies
9
Vehicle specification:
Details of the vehicle
Other information List the abbreviations contained in this manual
10 Additional information
Additional information on sales to other countries and regions
except for the mainland of China

Contents
Index
2
1
Safety Instructions
1.1. Instructions for Safe Use
Safe driving ........................................................... 24
Seat belt ................................................................. 25
Airbag .................................................................... 31
Child safety information ........................................ 42
Children restraint device........................................ 43
Install the child restraint device ............................. 47
Precautions for Exhaust Gas .................................. 50
1-2. Anti-theft system
Engine anti-theft system ........................................ 51
Body anti-theft system ........................................... 52
2
Instrument Cluster
Combination instrument ........................................ 54
Alarm light ............................................................ 56
Indicator ................................................................ 58
Multi-function display screen of instrument cluster
............................................................................... 60
Head up display* ................................................... 70
3
Operating the Components
3.1. Key information
Key ........................................................................ 74
3.2. Opening, closing and locking of doors and
trunk lid
Doors ..................................................................... 77
Trunk lid ................................................................ 81
Intelligent entry & start system ............................. 85
3-3. Adjusting the Seats
Front seats ............................................................. 90
Rear seats ............................................................... 92
Head restraints ....................................................... 94
Seat memory* ........................................................ 96
3-4. Adjusting the Steering Wheel and Rear-view
Mirrors
Steering wheel ....................................................... 98
Anti-glare inner rear view mirror ........................ 100
Exterior mirrors ................................................... 102
3-5. Opening and Closing the Windows
Power windows ................................................... 105
Panorama sunroof* .............................................. 108
4
Driving
4-1. Before Driving
Driving a vehicle ................................................. 112
Goods and luggage .............................................. 118
Trailer towing ...................................................... 119
4-2. Driving regulations
Engine (start) switch ............................................ 120
Transmission........................................................ 123
Driving mode ....................................................... 128

3
1
2
3
4
5
6
7
8
9
Turn signal lamp control handle .......................... 131
Electronic parking brake (EPB) system ............... 132
AUTO HOLD* .................................................... 134
4-3. Operating lights and wipers
Front headlamp switch ........................................ 136
Intelligent high beam control (IHC) system* ...... 138
Fog lamp switch .................................................. 140
Front windshield wipers and washer ................... 141
Rear windshield wiper and washer ...................... 144
4-4. Fill the fuel
Opening the fuel tank lid ..................................... 145
4-5. Using Other Driving Systems
Fixed speed cruise control* ................................. 148
Adaptive cruise control (ACC) function* ........... 151
Super Adaptive Cruise Control (SACC) function*
............................................................................. 157
Front and rear parking radar ................................ 164
Rear view camera system* .................................. 169
Panoramic image system* ................................... 174
Tire pressure monitor system (TPMS) ................ 179
LDW/LKA Lane keeping assist system* ............. 181
Driver Status Monitoring (DSM)* ...................... 184
Forward collision warning (FCW) system* ........ 185
Autonomous emergency brake (AEB) system* .. 187
Blind Spot Detection (BSD)* .............................. 190
Traffic Sign Recognition (TSR)* ........................ 194
Idling start/stop system ........................................ 196
Auto Parking Assist (APA)* ................................ 200
Driver assistance system ..................................... 206
4-6. Driving information
Key points for driving in winter .......................... 209
5
Audio System
5-1. Basic Operations
Multimedia display .............................................. 212
Multimedia switch on the steering wheel ............ 215
USB interface ...................................................... 216
5-2. Settings
System settings .................................................... 217
Vehicle settings .................................................... 222
5-3. Navigation
Basic functions .................................................... 228
Using the navigation ............................................ 230
5-4. Radio
Using the radio .................................................... 234
5-5. Music
My music play ..................................................... 237


Contents
Index
4
5-6. Bluetooth Music
Bluetooth music play ........................................... 241
5-7. Video
Video play............................................................ 243
5-8. Images
Image viewing ..................................................... 246
5-9. Hands-free System
Using the hands-free system ................................ 249
5-10. Bluetooth Telephone
Using Bluetooth® phone ..................................... 252
5-11. Speech recognition
Using the voice recognition function................... 256
5-12. Mobile phone APP
Using the mobile phone APP ............................... 258
5-13. Hongqi Smart Connect
Using Hongqi Smart Connect .............................. 261
6
Interior Equipment
6-1. Using the A/C System
Fully automatic air conditioning system ............. 270
· Using the automatic A/C system ....................... 272
• Manual adjustment setting ................................ 273
• Other functions .................................................. 276
• Adjust the air outlet direction and open and close
the air vents ......................................................... 278
Windshield heating .............................................. 280
6-2. Using the Interior Lamps
List of interior lights ............................................ 281
•Front row of interior lights ................................. 282
• Front reading light ............................................. 282
• Rear reading light .............................................. 283
• Vanity mirror lighting ........................................ 283
6-3. Using the Storage Units
Storage device list ............................................... 284
• Glove box .......................................................... 285
• Front central storage box................................... 286
• Left lower guard plate sundries box .................. 286
• Cup holder ......................................................... 287
• Bottle rack and sundry bucket ........................... 288
• Document pocket .............................................. 288
• Glasses box ....................................................... 289
Trunk device ........................................................ 290
• Cargo hook ........................................................ 290
• Luggage net ....................................................... 290
6-4. Other Interior Equipment
On-board wireless charging* ............................... 291
Sun visor .............................................................. 292
Paper holder ......................................................... 293
Vanity mirror ....................................................... 294
Cigarette lighter ................................................... 295
Power socket ....................................................... 296
Seat temperature control* .................................... 298
Rear center armrest .............................................. 300
Roof grab handle ................................................. 301
Coat hook ............................................................ 302




5
1
2
3
4
5
6
7
8
9
7
Maintenance
7-1. Maintenance and Servicing
Cleaning and protecting vehicle exterior trim ..... 304
Cleaning and protecting vehicle interior trim ...... 306
7-2. Maintenance
Maintenance instructions ..................................... 308
7-3. Do-It-Yourself Maintenance
Precautions for do-it-yourself maintenance ......... 310
Hood .................................................................... 312
Engine compartment ............................................ 313
Tire ...................................................................... 326
Tire pressure ........................................................ 329
Wheel .................................................................. 331
Air conditioning filter .......................................... 332
Replace key battery ............................................. 334
Check and replace fuse ........................................ 336
8
When Failure Arises
8-1. Important information
Hazard warning lamps ......................................... 340
SOS warning........................................................ 341
8-2. Measures to Be Taken in Emergencies
If the vehicle needs to be towed .......................... 342
If any abnormality is found on the vehicle .......... 347
If a warning lamp turns on or a warning buzzer
sounds .................................................................. 348
In the case of a flat tire ........................................ 354
If the engine cannot be started ............................. 362
If the key is lost ................................................... 363
If the key does not work properly........................ 364
If the battery is low .............................................. 366
If the vehicle is overheating ................................ 369
In case of the vehicle stuck .................................. 371
If you drive on water-covered roads .................... 372
In case of a punctured tire ................................... 373
If an accident occurs ............................................ 374
Trunk lid emergency open ................................... 375
9
Vehicle specification:
9. Specifications
Maintenance data ................................................. 378
Fuel information .................................................. 390
Other information
List of Abbreviations ......................................... 394
Additional information
10
Additional information on sales to other
countries and regions except for the mainland
of China. ........................................................... 392

6
Pictorial Index
Exterior
Engine compartment
cover
Front windshield wipers
Sunroof
Exterior rear
mirror
Side turn
signal lamp
Front Turn
signal
Low beam / high beam
Front Fog
Lamp
Day and night
driving lights
Front position
lamp
Towing eye cover

7
Rear position lamp
High-level brake lamp
Rear windshield
Wipers
Trunk lid
Reversing lamp
License plate l
amp
Rear fog lamp
Filler cap
Vehicle
door
Tire
Transpos
ition
Replace
Tire pressure
Brake lamp
Turn back
signal
Trunk lid, electric
Close button

8
Pictorial Index
Interior
Eyeglasses box
Front seat belt
Curtain airbag
Front head
restraint
Front seat
Front cup holder
Glove box
Front passenger airbag
Driver airbag
Front seat center storage
compartment

9
Central door lock
switch
Exterior rearview mirror
adjusting button
Interior door handle
Power window locking switch
Power window switch
Bottleholder and side pocket

10
Pictorial Index
Interior
Front interior
lamp
Front map
lamp
Front map lamp
switch
Electric sunshade
curtain switch
Roof grab
handle
Rear map lamp
Rear map lamp switch
Vanity
mirror lamp
Sun visor
SOS switch
Sunroof
switch
Front interior lamp switch
Interior anti-glare rear
view mirrors

11
Pictorial Index
Instrument Panel
Combination instrument
display
Headlamp
Turn lamp
Fog lamp
Wiper control lever
Multimedia display
Hazard warning lamp
switch
Steering wheel
adjustment
handle
Steering wheel
electric adjustment
button
Cruise control lever
Constant speed
cruise
Adaptive cruise
control
Advanced cruise
Lamp control lever

12
Pictorial Index
Instrument Panel
Forced defrosting of
windshield
/Defrost (defrost)
button
AUTO button
Driver side
temperature display
Driver side
temperature setting
button
OFF button
Idling Start-Stop Off button
ESC deactivation button
Auto parking button
Multimedia display switch button
Blind spot detection close button
Radar/image switch button
LDW/LKA switch button
Air volume decrease
button
Front passenger side
temperature setting key
Front passenger side
temperature display
Air volume increase
button
Windshield heating button
Internal / external circulation
button

13
Engine switch Shift lever knob
Driving mode switch button
Shift unlock button P gear button
Automatic parking
button
Electronic parking brake
switch
Driver's seat
heating key
Front passenger’s seat
heating key
Driver's seat
ventilation key
Wireless charging area
Front passenger side
seat ventilating button

14
Pictorial Index
Instrument Panel
Hang up Gear up paddle
Gear down paddle
Call answer key
Volume adjustment/mute
button
Voice recognition
button
MOD button
Combination instrument
display operation button

15
Heads up display setting button
Steering wheel heating button
Opening button inside the trunk lid
Hill descent control button
Mileage setting button
Left lower panel glove box

16
Pictorial Index
Rear of the Vehicle
Rear central armrest
Rear head restraint
Rear seats
Rear seat heating button
Rear seat belt
Rear cup holder
Rear power window switch

17
For Your Information
Instructions for the User’s Manual
Only after getting a driving license can the owner drive this vehicle on road. This manual specifically targets
at qualified drivers.
In this manual, "*" means that the configuration and function may vary by and are only available in certain
countries, regions, and vehicle models. Any equipment shall be subject to the real vehicle configuration.
All specifications provided in this manual are up-to-date as of the time the manual is delivered to print.
However, due to FAW’s constant efforts in re-modelling and improving, the equipments and performance of
subsequent models may vary. Accordingly, contents of this manual will be updated at any time without notice.
It's not suggested you compare the contents in other Manual versions with the equipments and performance of
the vehicle you purchased, and demand additional gears in light of differences between versions. If you are
unclear about the purchased vehicle or the User’s Manual, please contact FAW authorized Hongqi dealers.
Accessories, Spare Parts and Modification of the Vehicle
The FAW authorized Hongqi dealers possess advanced tools, equipments and genuine accessories required for
providing maintenance and service for your vehicle. We suggest you use the qualified genuine accessories and
spare parts.
FAW cannot accept any liability nor can it guarantee spare parts and accessories which are not genuine FAW
accessories and spare parts, neither for replacement nor installation involving such parts. In addition, damages
or performance problems resulting from the use of non-genuine FAW spare parts or accessories may not be
covered under warranty.
Do not use products which are not authorized by FAW to modify the vehicle, otherwise it will affect the
vehicle's maneuverability, safety and durability, and may even violate local government regulations. Besides,
any problems caused by the modification are not covered under warranty.
Read the vehicle identification number
Use the diagnostic instrument to connect to the vehicle OBD port. When the ECU information is being read,
you can read the vehicle VIN code. Reading tools are available on the market and must conform to IS014229,
IS015765, ISO15031 and IS011898 standards.

18
Install the RF Transmitter System
Installing a radio frequency transmitter system on the vehicle may affect electronic systems, such as:
● Anti-lock braking system
● Cruise control system
● Airbag system
● Seat belt pre-loading system
Please contact FAW authorized Hongqi dealers before you install the RF transmitter system.
Please confirm with FAW authorized Hongqi dealers to learn about preventive measures or special
instructions for installing a RF transmitter system.
For details on RF bands, power levels, antenna locations and RF transmitter installation regulations, please
contact FAW authorized Hongqi dealers.
Excessive noise may occur when receiving radio frequency from other radio frequency transmitting channels
(RF transmitters).
Vehicle Scrapping
Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by FAW
authorized Hongqi dealers before you scrap the vehicle. The SRS airbag and seat belt pretensioner devices in
the vehicle contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners
intact, it may cause injury or fire, etc.
