Robberechts XTS3-desk User manual

Robberechts NV | Slachthuisstraat 21 | 2300 Turnhout | [e-mail] | www.robberechts.be
Tel: [phone] | Fax: [phone]
RPR: Turnhout | BTW: BE 0423.718.170 | NR registratie aannemer: 022312
BELFIUS: 068-2299845-02 | IBAN: BE32 0682 2998 4502 | BIC: GKCCBEBB
User information:
Brand: Robberechts
Type: XTS3-desk (sit-stand desk)
This desk is height adjustable from 65-130 cm with electronic motor, for improved ergonomics in
the workplace. Alternating sitting and standing, your body stays in motion, which is beneficial
for your concentration.
Area of use: office environment
Publication date: January 2020
Specifications:
Length: 1200mm - 2000mm (steps of 200mm)
Depth: 800mm and 900 mm
Height: adjustable from 650mm to 1300mm
Speed: 38mm/s
Maximal load: 80 kg (desktop inclusive)
Power consumption operating: 132W
Power consumption stand by: 0.3W
Noise level: <50 dB
Operation: 2 minutes on / 18minutes off
Use:
The XTS3-desk is height adjustable with a control unit.
The unit is mounted under the top on the right-hand side.
Choice of control unit
Simple J05: Up/Down with display
Advanced J02: Up/Down with display with memory function
Installation:
Structure:
manual T-frame: G006297
manual H-frame: G006298
Manuals included by the fittings.
Options:
Profile for cabling: screwed under the top. Is hinged on both sides for better accessibility.
CPU-holder: screwed under the top.
Cable channel: screwed under the top, flexible, moves up and down with the desk.
Contact your dealer for more options and further information.

Robberechts NV | Slachthuisstraat 21 | 2300 Turnhout | [e-mail] | www.robberechts.be
Tel: [phone] | Fax: [phone]
RPR: Turnhout | BTW: BE 0423.718.170 | NR registratie aannemer: 022312
BELFIUS: 068-2299845-02 | IBAN: BE32 0682 2998 4502 | BIC: GKCCBEBB
Safety information:
- During the installation:
The desk may not be connected to the power grid.
For the cabling, follow the instruction in the manual.
The cabling may not be tensed for the risk of disconnection while moving up.
- During use:
Mind your hands while moving up and down! (symbol A)
Around the desk there should be space of minimum 25mm with other objects to avoid crushing.
(symbol B)
Always be aware of possible obstructions while moving the desk up and down.
Place the desk in an environment where there is sufficient space to move up and down.
Third party hardware: The cabling may not be tensed for the risk of disconnection and falling off.
(symbol C)
Safety symbols:
Symbol A - Mind your hands
Symbol B - Keep clear around desk
Symbol C - Cabling

Robberechts NV | Slachthuisstraat 21 | 2300 Turnhout | [e-mail] | www.robberechts.be
Tel: [phone] | Fax: [phone]
RPR: Turnhout | BTW: BE 0423.718.170 | NR registratie aannemer: 022312
BELFIUS: 068-2299845-02 | IBAN: BE32 0682 2998 4502 | BIC: GKCCBEBB
Ergonomic Advice
Ergonomic positioning for both sitting and standing
Regular postural breaks, every 20-30 minutes when sitting or standing
Alternating between sitting and standing on a regular basis, every 45-60 minutes
Using a footstool to alternate weight bearing while standing
Wearing flat, supportive footwear and use of an anti-fatigue mat
Declaration of Conformity
We herewith confirm that the appliance complies with the governing EU-directives as mentioned in
the Declaration of Conformity (v20191115) and bulk production will be manufactured
accordingly.
