Roberts Gorden Combat UHD[S] 150-400 User manual

Quality in Any LanguageTM
82% eciency with use of tubular heat
exchangers and inshot burners
Reliable ignition with direct spark ignition
burners.
Installation and operation exibility with rear
or top air and ue connections (Models UHD[S]
75 - 125 only).
Helps reduce dirt build-up on burners and helps
extend life of heat exchanger with separated
combustion units.
Longer life and less maintenance with optional
stainless steel heat exchangers.
Install downstream of refrigeration system with
option stainless steel heat exchangers and drain
pan (Models UHD[S] 150-400 only).
Combat®UHD[S] - Series
Tubular Duct Furnaces
1.800.828.7450
www.rg-inc.com
tUHD[S] Models 75 - 125
UHD[S] Models 150 - 400 u

Clearances to Combustibles - Low Prole UHD[S] Range (Models 75 - 125)
Above Heater Below Heater To Side of Heater Access Side Door To Flue
1" 1" 1" 18" Access Clearance 2"
Dimension Data - Low-Prole UHD[S] Range (Models 75 - 125)
Model 75 100 125
'A' Height [in] 17.75 23 23
'B' Duct Connectors [in] 1.25 1.25 1.25
'C' Center of Flue [Top Option] [in] 5.2 6.9 6.9
'D' Center of Flue [in] 2.5 2.5 2.5
Combat®UHD[S] 75 - UHD[S] 125 Clearances and Dimension Data
B
20.25”
1.8”
A
D
Flue
28.5”
1.5”
3.3”
4 x 3/8” Captive Nuts Provided
16.63"
B
17.63"
Rear View
Top View
Gas Supply
6.75”
Air Intake
(UHDS only)
Side View
C
Air Intake
(UHDS only; Optional Position)
Flue
(Optional Position)
18.25”
Electrical
Supply
Thermostat
Connection
6"
6.75”
6”
6”

Combat®UHD[S] 150 - UHD[S] 400 Clearances and Dimension Data
Dimension Data - Standard UHD[S] Range (Models 150 - 400)
Model 150 175 200 225 250 300 350 400
'A' Width [in] 43 43 43 43 43 50 50 50
'B' Height [in] 27 27 35.25 35.25 35.25 43.5 43.5 43.5
'C' Duct Connectors [in] 1.25 1.25 1.25 1.25 1.25 1.25 1.25 1.25
'D' Support Spacing [in] 17.6 17.6 17.6 17.6 17.6 24.7 24.7 24.7
'F' Center of Flue [in] 9.5 9.5 17 17 17 13.6 13.6 13.6
'G' Flue Center to
Air Intake Center [in] 66666777
'H' Position of Flue [in] 4.5 4.5 4.75 4.75 4.75 4.9 4.9 4.9
'J' Gas Inlet Position [in] 5.9 5.9 5.9 5.9 5.9 8.7 8.7 8.7
'K' Electrical Supply Position [in] 3.4 3.4 3.4 3.4 3.4 6.2 6.2 6.2
K
B
C
25.5”
A
J
2.4”
6.5”
4 x 3/8” Captive Nuts Provided
C
F
D
19.4”
Support
Centers
Rear View
End View
G
H
Top View Heater must be supported
at these points from above
or below.
Electrical
Supply
Air Intake
(UHDS only)
Flue
Thermostat
Connection
Gas
Supply
Clearances to Combustibles - Low Prole UHD[S] Range (Models 75 - 125)
Above Heater Below Heater To Side of Heater Access Side Door To Flue
6" 6" 6" 31" Access Clearance 2"

Model 75 100 125 150 175 200 225 250 300 350 400
Total Input [Btu/h] x [1000] 75 100 125 150 175 200 225 250 300 350 385
Total Output [Btu/h] x [1000] 61.5 82 102.5 123 143.5 164 184.5 205 246 288.6 315.7
Eciency 82% - All Models
Number of Burners 5 6 7 7 8 9 10 11 12 14 14
Gas Connection [in] ½ ½ ½ ½ ½ ½ ¾ ¾ ¾ ¾ ¾
Inlet Pressure [in wc] NG Min. 5
LPG Propane Min. 12
NG & LPG Propane Max. 14
Electrical Supply 115 V / 60 Hz / 1 Ø - All Models
Minimum Air Volume [CFM] 850 950 1020 1360 1400 2050 2100 2350 2700 3120 3420
Temperature Rise @
Minimum Air Volume [°F] 68 78 92 83 95 73 80 80 86 86 86
Heat Exchanger Pressure Drop
@ Minimum Air Volume [in wc] 0.06 0.05 0.06 0.02 0.03 0.025 0.035 0.05 0.02 0.03 0.04
Maximum Air Volume [CFM] 2650 3660 4750 5800 6850 7750 8300 8850 10200 13600 14200
Temperature Rise @
Maximum Air Volume [°F] 22 22 20 20 20 20 20 22 23 22 22
Heat Exchanger Pressure Drop
@ Maximum Air Volume [in wc] 0.36 0.55 0.98 0.16 0.29 0.163 0.253 0.35 0.27 0.48 0.53
Flue Size [in] 4 - All Models
Air Intake [in] 4 4 4 4 4 4 4 4 5 5 5
Weight [lb] 81 92 97 191 211 239 249 254 325 345 345
