RoyalTek GPS SPEED CAMERA WARNING DEVICE RCD-1000 User manual

English 1
RoyalTek
GPS Speed Camera Warning Device
RCD-1000
Offline version
Users Manual

English 2
Content
1.Product Introduction .........................................................................................................................3
1.1 Overview................................................................................................................................3
1.2 Check the Package Content....................................................................................................3
1.3 Install RCD-1000 in your vehicle..........................................................................................4
1.4 Product Notification- Using Tips...........................................................................................4
2.Specification......................................................................................................................................5
2.1 Specification...........................................................................................................................5
2.2 Hardware Overview...............................................................................................................6
2.3 LED Display & Audio Alarm ................................................................................................6
3.Software Installation and Usage .......................................................................................................8
3.1 Start to use “Speed Camera Detector Utility”........................................................................8
3.2 POI Management Procedure................................................................................................10
3.3 SCDB and POI import setting..............................................................................................14
3.4 SCDB Setting.......................................................................................................................18
3.5 Utility Revision information................................................................................................18

English 3
1
1. .P Pr ro od du uc ct t I In nt tr ro od du uc ct ti io on n
1.1 Overview
The Device is equipped with the latest generation SiRF Star III digital processor specially designed for fast
and accurate fix on GPS signals. It had been designed to help you drive safety within the confines of today’s
speed limits, by alerting you quickly and easily to the presence of Police speed traps, often located at
Accident black spots, electronically indicating potentially dangerous and hazardous situations. The RCD-1000
will help you to drive safely, when the database has been downloaded, the device will compare your position
using its built-in GPS antenna with the position of every known danger locations and give you an audible and
visual warning as you approach them.
- READ FIRST -
The RCD-1000 comes with a database of cameras pre-loaded. However you must register your RCD-1000 to
receive Account and password. Please note that the database on the device will have been downloaded at
the time of production so may not be 100% accurate at the time of purchase. To ensure that your RCD-1000
works affectively we recommend that you download it as soon as possible after purchase.
Feature:
zEasy installation and put on the dashboard, just plug into the cigarette lighter.
zSupport Navigation via USB for NB
zUpdate database via mini USB connector on PC/NB. (Internet Connection)
zBright LED lights for Speed Limit, GPS, POI status, and adjustable audible alarms.
zAutomatic system warning with audible and visual alerts to reduce your speed
zKnow your exact position and current speed, use the database to continue checking if you are
approaching a risk area and warns you before you enter a risk area.
1.2 Check the Package Content
Before using RCD-1000, please make sure the package includes the items listed below. Please contact the
reseller immediately for any missing/damaged items.
1. RCD-1000 Device
2. USB cable
3. Car Charger
4. CD (user manual, SW utility)
5. Dashboard Pad

English 4
1.3 Install RCD-1000 in your vehicle
zPlace the Dashboard Pad on your dashboard as close to the windscreen as possible in clear view of the driver’s line
of sight.
zPlace your RCD-1000 device on the dashboard pad, which is designed to hold it firmly in place.
zNow connect the USB cable to the cigar lighter adapter provided and insert the other end to socket (A). Plug the
adapter into the vehicle’s cigar lighter. RCD-1000 powers on once you turn your ignition key and the green and red
LEDs will sweep backwards and forwards with one beep tells you that the unit is functioning correctly.
1.4 Product Notification- Using Tips
1. Use the supplied dashboard pad, remove the backing from the base, fix it on the dashboard as close to
the windscreen as possible in clear view of the driver’s line of the sight and place your Detector onto the
pad
2. Cars that are equipped with heat dissipation films for the windshield and windows will degrade the GPS
performance.
3. For the most accurate position fix results and quickest acquisition time, please make sure that your device
is not in motion but stationary and in open spaces.
4. Connect to PC or Notebook for “Speed Camera Detector Utility”
@User can update the Camera database and manage the POI points using the supplied “Speed Camera
Detector Utility”.Refer to the software installation and usage to install the software utility. *POI: point of
interest
5. We invite the driver to respect the driving rule and the law. We assume no any responsibility for any
damage or injury resulting from the wrong use of the product.
(E) POI Button
(A) Mini USB Port
(B) External Antenna Port
(C) Volume Control
(D) Speed Limit button

English 5
2
2. .S Sp pe ec ci if fi ic ca at ti io on n
2.1 Specification
GPS
GPS Chipset - Sirf GSC3f/LP
Frequency - L1, 1,575.42 MHz
Channel - 20 parallel
C/A Code - 1,023 MHz
Chipset TTFF
(Open SKY,typical) - Reacquisition: less than 1s
- Hot start: less than 1s
- Warm start: less than 35s
- Cold start: less than 35s
Accuracy - Position: within 10m for 90%
- Velocity: 0.1m/s
Dynamics
Altitude - 18,000 meter maximum
Velocity - 514 meter/second maximum
Internal Antenna
Type -Build in PatchAntenna
External Antenna
Type -MMCX
Camera database storage
Flash Type - 16Mb Serial Flash
Device Interface
(External Connector
port)
-USB 1.1
Mini USB (5pin) for Car charger and data
transfer
Button -POI Setting x1
-Speed Limit Setting x1
Volume Control -VR Type
LED -3X Tri-Color for GPS, Speed Limit setting, POI
Setting
Power Source -Power from Car charger 5V 500 mAh
Temperature -Operating : -20℃~ + 60 ℃
-Storage : -20℃~ + 85 ℃
Size - Dimension: 65mm X 65mmX18.5mm
Weight ≦45g
Voltage Type - 5V 500mAh

English 6
2.2 Hardware Overview
(1) The POI record Button:
Press for more than 2 seconds to record current position.
A short beep sound and blinking LED will inform you that the POI has been successfully store.
Note: The user must use the software to carry out the POI management.
Note: The POI Record Button function will be enabled after GPS is fixed and the Speed Camera
database was successful pre-uploaded into memory.
(2) The Speed limit setting Button:
Press for more than 4 seconds to record current speed of your vehicle. A short beep sound and glowing LED will
inform you that current speed limit has been successfully done. If you exceed the speed limit, the device will beep
until your speed fall below the limit. To revise the speed you can push this button for one second then the speed
limit will change to the current speed. To cancel the setting, press the button for more than 4 seconds again.
Note: The Speed limit setting value will be cancelled after removing the charger power.
(3) Volume control:
Rotate forward and backward to adjust the volume.
2.3 LED Display & Audio Alarm
Front View

English 7
*Depending on local SCDB conditions.
Event LED Display Audio Alarm
1 System Initialize Green+Red (No 1+No 2+No3), Sweeping 1 beep
2 GPS Search Green (No 1), Blinking
3 GPS is fixed Green (No 1), Glowing 2 beeps after GPS Fixed
4 Memory full /Erase Not available for this model X
Not exceed speed Glowing 3 beeps
5
Approach Fix Camera Zone and
pre-alert (distance less than* 1500
meter- Notification range) Over speed Red (No 2+No3) Blinking 1 time per second
Continuous Beeps continuously
Not exceed speed Glowing 3 beeps6 Approach Fix Camera Zone and
pre-alert (distance less than *500
meter- Critical range) Over speed Red (No 1+No
2+No3) Blinking 1 time per second
Continuous 3 beeps per second continuously
Not exceed speed Glowing 3 beeps
7 Approach Mobile Camera Zone or
User defined POI and pre-alert
(distance less than *1500 meter-
Notification range) Over speed Amber (No 2+No3) Blinking 1 time per second
Continuous Beeps continuously
Not exceed speed Glowing 3 beeps
8 Approach Mobile Camera Zone or
User defined POI and pre-alert
(distance less than *500 meter-
Critical range) Over speed Amber (No 1+No
2+No3) Blinking 1 time per second
Continuous Beeps continuously
9 User Defined POI Function activated Green (No 1+No 2+No3), Flashing once 1 beep
10 User Defined POI full Amber (No.2), Glowing X
11 Speed Limit function enable Red (No.3), Glowing 1 beep
12 Speed Limit function Disable X 3 beeps
13 Over Speed only (W/O Camera or POI Zone) Amber (No.3), Blinking Beeps continuously

English 8
3
3. .S So of ft tw wa ar re e I In ns st ta al ll la at ti io on n a an nd d U Us sa ag ge e
3.1 Start to use “Speed Camera Detector Utility”
Check the COM port of RCD-1000 first. Click “Start” Æ“Control Panel”Æ”Performance and
Maintenance”Æ“System”, and you will see the System Properties dialog box; click on
“Hardware” tab and then the “Device Manager” button. Expand the “Ports (COM & LPT)” item,
and the “Prolific USB-to-Serial Comm Port” is the COM port of your RCD-1000.
The user should connect the device first. (Connect device with PC via USB Cable)
Please select comm. port and press the “connect” button.
When you execute the program, the following Figure 1 is shown.
Note: (1) System will download the POI points from device automatically.
Please wait the “Get All Datalogger Head” finished. The following figure 3 is
shown.
(2) If user wants to upload SCDB data, please be sure to pre download datalog
data in advance.
(3) Datalog data will be deleted after upload SCDB process is done.
Figure1
Figure2 and Figure3 show when you press the button “Connect”, the utility notifies the user
that the device will enter the operation mode, all functions of the device are disabled.

English 9
Figure2
Figure3
Figure 4 is shown System will download the POI points from device automatically.
POI data will be erased from device after POI load process done.
Figure 4
If the figure 5 dialog is shown, it means there is no POI data in the device.

English 10
Figure 5
3.2 POI Management Procedure
When proceed the POI Management, system will auto create the POI folder for POI data
download.
Note:POI data are stored in the PC side and named POI.csv and stored in the subdirectory
/POI/.
User can load POI data, delete POI data or Save POI data by using the Utility.
Note:
◆Load POI: User can edit the POI points by click the button ”Load POIs”.
There are 5 types of status will show on the Utility screen after loading POI action is done.
*Duplicated with No. X: means the distance between the current POI point and No. X
POI point less than 1km.
*Out of SCDB range: means the current POI point is not in the SCDB coverage range.
*OK: means the valid POI point.
*Speed is out of range: means the POI’s speed is over the spec " the speed range is
from 0 to 300km/hr”
*Surpass 255 characters: means the POI’s comments are over the spec.
◆Delete POI: User can select the POI by click the checkbox and press the button “Delete
POI” to delete the POIs that user selected. If user delete POIs, confirmation message will be
shown to user as Figure 8.
◆Save POI: When user finishes the POI points edition, user can press the button ”Save
POI” to save the modification and integrate the POI to speed camera data base. Please refer
to Figure 11 (The function “integrate POI with SCDB “ will be enabled).
Check the page “POI management”, and theAP will go to the page “POI management”,
