RYTEC Turbo-Slide User manual

R Y T E C
P.O. Box 403, One Cedar Parkway, Jackson, WI 53037
Phone: [phone] Fax: [phone]
Rytec Website: www.rytecdoors.com, Rytec On-line store: www.rytecparts.com
Rytec E-mail: [e-mail], Parts E-mail: [e-mail]
[Revision: AA (2017-09-13), R1091004-0, ©Rytec Corporation 2017]
Turbo-Slide®
Owner’s Manual

RYTECTURBO-SLIDELIMITEDWARRANTY
Rytec Corporation (“Seller”), an Illinois corporation with its principal place of business at One Cedar Parkway,
PO Box 403, Jackson, WI 53037, warrants to the original registered end-user commercial purchaser
(“Buyer”) that the Turbo-Slide model (“Product”) sold to the Buyer will be free of defects in materials and
workmanship (ordinary wear and tear excepted) for the time periods set forth below:
•Mechanical components for a period of One (1) Year from the date of shipment of the Product from the
Seller’s plant (“Shipment”).
•Electrical components for a period of One (1) Year from Shipment.
•Standard door panel for Five (5) Years from Shipment.
•Seals, including sweep seal, bulb seal and leading edge seals are considered wear items and are
not covered under this Limited Warranty.
•Aftermarket parts, accessories and assemblies for a period of ninety (90) days from the date of
Shipment
Remedies. Seller’s obligation under this Limited Warrantyis limited to repairing or replacing, at Seller’s option,
any part which is determined by Seller to be defective during the applicable warranty period. Such repair or
replacement shall be the Seller’s sole obligation and the Buyer’s exclusive remedy under this Limited Warranty.
Labor. Except in the case of aftermarket parts, accessories and assemblies, labor is warranted for one year.
This means that Seller will provide warranty service without charge for labor in the first year of the warranty
period. Thereafter,a charge will apply in to any repair or replacement under this Limited Warranty. In the case of
aftermarket parts, accessories and assemblies, Seller will provide replacement parts only.
Claims. Claims under this LimitedWarrantymust be made (i) within 30 (thirty) days after discovery and (ii) prior
to expiration of the applicable warrantyperiod. Claims shall be made in writing delivered to the Seller at the
address provided in the first paragraph of this warranty. Buyer must allow Seller and Dealer, or their agents, a
reasonable opportunityto inspect any Product claimed to be defective and shall, at Seller’s option, either (x)
grant Seller and Dealer or their agents access to Buyer’s premises for the purpose of repairing or replacing the
Product or (y) return of the Product to the Seller, f.o.b. Seller’s factory.
Original Buyer. This Limited Warranty is made to the original Buyer of the Product and is not assignable or
transferable. This Limited Warranty shall not be altered or amended except in a written instrument signed by
Buyer and Seller.
Not Warranted. Seller does not warrant against and is not responsible for, and no implied warranty shall be
deemed to cover, damages that result directly or indirectly from: (i) the unauthorized modification or repair of the
Product, (ii) damage due to misuse, neglect, accident, failure to provide necessary maintenance, or normal wear
and tear of the Product, (iii) failure to follow Seller’s instructions for installation, operation or maintenance of the
Product, (iv) use of the Product in a manner that is inconsistent with Seller’sguidelines or local building codes,
(v) movement,settling,distortion,or collapseof the ground,or of improvements to which the Products are affixed,
(vi) fire, flood, earthquake, elements of nature or acts of God, riots, civil disorder, war, or any other cause beyond
the reasonable control of Seller, (vii) improper handling, storage, abuse, or neglect of the Product by Buyer or by
any third party.
DISCLAIMERS. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER REPRESENTATIONS AND
WARRANTIES,EXPRESS OR IMPLIED, AND THE SELLER EXPRESSLY DISCLAIMS AND EXCLUDES ANY
IMPLIED WARRANTIES OF MERCHANTABILITYOR FITNESS FOR PURPOSE. SELLER SHALL NOT BE
SUBJECT TO ANY OTHER OBLIGATIONSOR LIABILITIES,WHETHER ARISING OUT OF BREACH OF
CONTRACT,WARRANTY, TORT (INCLUDING NEGLIGENCE AND STRICT LIABILITY) OR OTHER
THEORIES OF LAW, WITH RESPECT TO THE PRODUCTS SOLD OR SER- VICES RENDERED BY THE
SELLER, OR ANY UNDERTAKINGS,ACTS, OR OMISSIONS RELATING THERETO.
LIMITATION OF LIABILITY. IN NO EVENT WILL SELLER BE RESPONSIBLE FOR, OR LIABLE TO ANY- ONE
FOR, SPECIAL, INDIRECT, COLLATERAL, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN
IF SELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Such excluded damages
include, but are not limited to, personal injury, damage to property, loss of goodwill, loss of profits, loss of use,
cost of cover with any substitute product, interruption of business, or other similar indirect financial loss.

Product Descriptions. Any description of the Products, whether in writing or made orally by the Seller or the
Seller’s agents, including specifications,samples, models, bulletins, drawings, diagrams, engineering or similar
materials used in connection with the Buyer’s order, are for the sole purpose of identifying the Product and shall
not be construed as an express warranty. Any suggestions by the Seller or the Seller’s agents regarding the use,
application, or suitability of the Product shall not be construed as an express warranty unless confirmed to be
such in writing by the Seller.
Limited Warranty Void. This Limited Warranty shall be void in its entirety if:
a. The Product is modified in a manner not approved in writing by Seller; or
b. Buyer fails to maintain the Product in accordance with instructions contained in the Owner’s Manual for
the Product.

TABLE OF CONTENTS
PAGE
INTRODUCTION............................................................................................1
HOW TO USE MANUAL................................................................................................1
DOOR SERIAL NUMBER..............................................................................................1
GENERAL ARRANGEMENT OF DOOR COMPONENTS.............................................2
OPERATION ..................................................................................................3
CONTROL PANEL.........................................................................................................3
POWER DRIVE SYSTEM..............................................................................................3
MANUAL OPERATION .................................................................................................3
PHOTO EYES................................................................................................................4
DOOR PANEL RETENTION SYSTEM ..........................................................................4
DEFROST SYSTEM (OPTIONAL SYSTEM) .................................................................4
Heat Tape Circuit.......................................................................................................................5
DOOR PANEL SEALING SYSTEM...............................................................................5
PLANNED MAINTENANCE...........................................................................5
RECOMMENDED SCHEDULE......................................................................................5
DAILY INSPECTION .....................................................................................................5
Visual Damage Inspection........................................................................................................5
Door Retention Inspection .......................................................................................................6
Door Operation Inspection.......................................................................................................6
Photo Eye Inspection................................................................................................................7
QUARTERLY INSPECTION..........................................................................................7
Electrical Inspection .................................................................................................................7
CONTROL PANEL, ENCODER, AND MOTOR WIRING .......................................................7
UPPER JUNCTION BOX ........................................................................................................7
Mounting Hardware Inspection................................................................................................8
Door Retention Inspection .......................................................................................................8
Drive Chain Inspection .............................................................................................................9
Trolley Assembly Inspection....................................................................................................9
Lubrication...............................................................................................................................10
Electric Brake Inspection .......................................................................................................10
Insulated Door Panel and Door Seal Inspection.......................................................................11
BI-PARTING DOOR CENTER SEAL INSPECTION....................................................12
Cleaning Panels and Seals.....................................................................................................12
Control Panel and Activator Inspection................................................................................12
Defrost System (Optional System)........................................................................................12
HEAT TAPE INSPECTION ...................................................................................................12
Wall Anchor Inspection ..........................................................................................................13

TABLE OF CONTENTS
PAGE
Chain Release Mechanism Inspection..................................................................................13
ADJUSTMENTS.......................................................................................... 14
LIMIT SWITCHES........................................................................................................14
DRIVE CHAIN ADJUSTMENT..................................................................................... 14
DOOR PANEL ALIGNMENT AND ADJUSTMENT .....................................................14
DOOR RETENTION/BULB SEAL ADJUSTMENT ......................................................15
Top/Head-Door Bulb Seal Adjustment..................................................................................16
Door Retention/Stay Roller-Door Bulb Seal Adjustment ....................................................16
DOOR LEADING EDGE SEAL ADJUSTMENT BI-PARTING DOORS .......................17
DOOR PANEL FLOOR SWEEP SEAL ADJUSTMENT...............................................17
PHOTO EYE ADJUSTMENT-ALIGNMENT.................................................................18
Testing Photo Eyes.................................................................................................................18
Troubleshooting Photo Eyes .................................................................................................18
MOTOR BRAKE ADJUSTMENT.................................................................................19
CHAIN RELEASE ASSEMBLY ALIGNMENT AND ADJUSTMENT............................19
PARTS LIST................................................................................................ 22
PARTS ORDERING INFORMATION............................................................................22
How to Order Parts..................................................................................................................22
Substitute Parts.......................................................................................................................22
Return of Parts ........................................................................................................................22
DOOR SERIAL NUMBER............................................................................................22
RYTEC TECHNCIAL KNOWLEDGE CENTER............................................................23
RYTEC ON-LINE WEBSTORE....................................................................................23
RETURNS POLICY FOR ON-LINE WEBSTORE........................................................23
Instructions to return items to webstore:.............................................................................23
BI-PARTING DOOR ASSEMBLY................................................................................24
BI-PARTING DOOR ASSEMBLY BOM.......................................................................25
SINGLE SLIDE DOOR ASSEMBLY............................................................................26
SINGLE SLIDE DOOR ASSEMBLY BOM...................................................................27
BI-PARTING DOOR HEAD ASSEMBLY.....................................................................28
BI-PARTING DOOR HEAD ASSEMBLY BOM............................................................29
SINGLE SLIDE DOOR HEAD ASSEMBLY.................................................................30
SINGLE SLIDE DOOR HEAD ASSEMBLY BOM........................................................31
BI-PARTING DOOR PANEL ASSEMBLY...................................................................32
BI-PARTING DOOR PANEL ASSEMBLY BOM..........................................................33
SINGLE SLIDE DOOR PANEL ASSEMBLY...............................................................34
SINGLE SLIDE DOOR PANEL ASSEMBLY BOM......................................................34

TABLE OF CONTENTS
PAGE
TURBO SLIDE MOTOR ASSEMBLY..........................................................................35
TURBO SLIDE MOTOR ASSEMBLY BOM.................................................................35
TURBO SLIDE CHAIN RELEASE ASSEMBLY ..........................................................36
TURBO SLIDE CHAIN RELEASE ASSEMBLY BOM.................................................36
TURBO SLIDE CHAIN RETURN IDLER ASSEMBLY.................................................37
TURBO SLIDE CHAIN RETURN IDLER ASSEMBLY BOM........................................37
TURBO SLIDE DOOR SWIVEL HANGER ASSEMBLY..............................................38
TURBO SLIDE DOOR SWIVEL HANGER ASSEMBLY BOM.....................................38
TURBO SLIDE DOOR TROLLEY ASSEMBLY...........................................................39
TURBO SLIDE DOOR TROLLEY ASSEMBLY BOM..................................................39
TURBO SLIDE STAY ROLLER ASSEMBLY ..............................................................40
TURBO SLIDE STAY ROLLER ASSEMBLY BOM.....................................................40
TURBO SLIDE UNIVERSAL CAM STAY ROLLER ASSEMBLY................................41
TURBO SLIDE UNIVERSAL CAM STAY ROLLER ASSEMBLY BOM.......................41
TURBO SLIDE DOOR BULB SEAL ASSEMBLYS.....................................................42
TURBO SLIDE DOOR BULB SEAL ASSEMBLYS BOM............................................42

1
INTRODUCTION—HOW TO USE MANUAL
INTRODUCTION
The information contained in this manual will allow
you to operate and maintain your Rytec Turbo
Slide™ Door in a manner which will ensure
maximum life and trouble-free operation.
Any unauthorized changesin procedure, orfailureto
follow the steps as outlined in this manual, will
automatically void our warranty. Any changes in the
working parts, assemblies, or specifications as
written that are not authorizedbyRytec Corporation
willalsocancelour warranty.The responsibility forthe
successfuloperation and performance of this door is
yours.
DO NOT OPERATE OR PERFORM MAINTENANCE
ON THIS DOOR UNTIL YOU READ AND UNDER-
STAND THE INSTRUCTIONS CONTAINED IN THIS
MANUAL.
If you have any questions,contact your Rytec
representative or call the Rytec Customer Support
Department at 800-628-1909. Always refer to the
serial number of the door when calling your
representative or Customer Support. The serial
number is located in several locations-see DOOR
SERIAL NUMBER section.
A wiring schematic is provided with each individual
door specifically covering the control panel and
electrical components of that door. See the Rytec
System 4 Drive & Control Installation & Owner’s
Manual.
HOW TO USE MANUAL
Throughout this manual, the following key words are
used to alert the reader to potentially hazardous
situations, or situations where additional information
to successfully perform the procedure is presented:
WARNING is used to indicate the potential
for personal injury, if the procedure is not
performed as described.
CAUTION is used to indicate the potential
for damage to the product or property
damage, if the procedure is not followed
as described.
IMPORTANT: IMPORTANT is used to relay
information CRITICAL to the
successful completion of the
procedure.
NOTE: NOTE is used to provide additional infor-
mation to aid in the performance of the
procedureor operation of the door, but not
necessarily safety related.
DOOR SERIAL NUMBER
Each RYTEC door is uniquely identified with a serial
number. You will need this when contacting RYTEC
for any service. To obtain your door’s DOOR SERIAL
NUMBER, there are several typical locations where
the DOOR SERIAL NUMBER can be found; on the
cover of the RYTEC System 4 control panel, the front
side outside edge of each door panel at
approximately eye level, and the drive motor/head
assembly. (See Figure 1)
IMPORTANT: When installing multiple doors of
the same model, verify and match
the serial number of the control
panel with those on all the other
components of each door
assembly. Failure to do this will
void the manufacturer’s warranty
and may lead to catastrophic
failure and/or personal injury!
Figure 1
eyes
Rytec
Control
Panel
Rytec
Door
Panels
Rytec
Motor
Drive
Rytec
Control
Panel
Rytec
Door/Head
Assembly
Rytec
Motor
Drive
Rytec
Door
Panels
Photo eyes
Door
S/N
stickers

2
INTRODUCTION—GENERAL ARRANGEMENT OF DOOR COMPONENTS
GENERAL ARRANGEMENT OF DOOR
COMPONENTS
Figure 2 - Figure 5 show the location of the major
components of the door and the general placement
of the associated control sub-assemblies for a typical
installation.
These illustrations are provided to you for
informational purposes only. They should not be
solely relied upon for the operation and maintenance
of your door and its sub-assemblies.
Figure 2
Figure 3
NOTE: Figure 2 and Figure 3 show the front side of
the door. Left and right are determined when
facing/viewing the front side of the door.
This is the side that the door assembly is
mounted on/the same side the head
assembly is on. All views shown on this
page are showing the “Front” side of the
door assembly.
Figure 4, Exploded View
Figure 5
Head
Assembly
Insulated
Rytec
Door
Panels
System 4
Control
Panel
Fused
Disconnect
Photo eyes
Stay
Rollers
Head
Assembly
Insulated
Rytec
Door
Panel
Fused
Disconnect
System 4
Control
Panel
Photo eyes
Stay
Rollers
One-Way Door
Bi-Parting Door
Rytec
Control
Panel
Bulb Seal
Assembly’s
(Top & Sides)
Main Door
Assembly
See Figure 5
Adjustable/replaceable
door panel sweep
Bi-Parting Door Shown
One-Way Door Is Similar
Stay-
Roller

3
OPERATION—CONTROL PANEL/POWER DRIVE SYSTEM/MANUAL OPERATION
OPERATION
CONTROL PANEL
The Turbo Slide door is equipped with a Rytec
System 4 Drive & Control. It is a solid-state,
microprocessor-based, high-speeddoor control
system designed exclusively to operate Rytec high
performance doors.It provides connections for
multiple activators, close delay timers, status
indicators, as well as a means for programming and
controlling the door and displays statusandalarm
messages. All command functions to operate the
drive and control system are software controlled. For
information on control panel operation, seethe Rytec
System4Drive & Control Installation & Owner’s
Manual. (See Figure 6)
POWER DRIVE SYSTEM
The power drive system for the Turbo Slide door
consists of a motor, a gearbox, tensioners, and an
electric brake. The power drive system can be
mounted on either side of the head assembly. The
location of the drive system is determined at the time
the door is ordered from the manufacturer. Additional
drive components include idler gear assemblies, a
drive chain, chain reverser assembly (Bi-Parting
Door), and trolleys. (See Figure 6)
Figure 6
One end of the drive chain loop is connected to the
drive gear on the motor. The other end is connected
to the return idler-tensioner assembly that includes
an adjustable gear used to tension the drive chain.
The door panel(s) are connected to the drive chain
via the chain release mechanism and hang from
trolleys. The trolleys roll along tracks in the head
assembly to move the door panel(s) back and forth to
open and close the door.
On Bi-Parting Door systems, the drive chain moves
the door panels/trolleys toward each other to close
the door or away from each other to open the door by
passing through the chain reverser assembly in the
center of the door.
MANUAL OPERATION
When the motor is not operating the door, during a
power loss, or when routine maintenance calls for
power to be disconnected, the motor is automatically
locked in place by an electric brake on the motor
assembly that, in turn, locks the door.
An electric brake is used to halt the door if power to
the door is shut off for any reason. A manual door
chain drive release assembly connected to a rotating
handle (via cable) is provided to release the door
from the drive chain allowing the door to be manually
opened and/or closed. During a power failure, when
routine maintenance calls for power to be
disconnected, or when needing to get through the
door from the rear/non-activated side, this manual
release handle can be used. (See Figures 7 and 8)
Figure 7
Figure 8
Insulated
Rytec Door
Panels
Drive
Pulley
Fused
Disconnect
Door Panel
Trolleys
Stay
Rollers
Bi-Parting Door Shown
One-Way Door Is Similar
Return Idler-
Tensioner
Assembly
Drive
Chain
Manual
Door Chain
Release
Handle
RYTEC
System 4
Control
Panel
Drive Motor/
Gearbox
Assembly

4
OPERATION—PHOTO EYES/DOOR RETENTION/DEFROST
The disconnect must be in the OFF
position and properly locked and tagged
before performing the following procedure.
To manually open the door from the front, safety
protocols must be followed first. Once the drive
system has been de-energized and locked out, the
Chain Release Assembly lever must be pulled down
to disengage the door panel(s) from the drive chain.
Then the door panel(s) can be moved freely. To re-
engage the door panel(s), simply move the panel(s)
back to where the Chain Release Assembly locks
back into place on the drive chain. (See Figure 9)
Figure 9
PHOTO EYES
This safety system consists of a single set of photo
eyes. Each set of photo eyes consists of a
transmitter module and a receiver module. Each
module is mounted in a heavy-duty bracket installed
on the front side of the door. (See Figure 10 & 11)
The purpose of these photo eyes is to hold the door
open or, if the door is closing, reverse the direction of
the door if a person or object crosses the path of the
photo eye beam. The door will remain parked in the
open position until the beam is restored (object
removed).
Figure 10
IMPORTANT: The photo eyes are not intended to
be used as a door activator and will
not open the door when it is closed.
Figure 11
After the object breaking the beam of light is
removed:
If the door was opened by a non-automatic
activator (push button, pull cord, radio control,
etc.), the door will remain open until it is
closed by a non-automatic activator.
If the door was opened by an automatic
activator (floor loop, motion detector, etc.), the
door will close automatically.
The photo eyes are powered and properly aligned
when the power indicator on each eye is lit; amber on
the receiver, and green on the transmitter. When the
light beam is interrupted, the alignment indicator on
the receiver will go out but the transmitter will remain
green. Restoring the beam relights the alignment
indicator on the receiver.
DOOR PANEL RETENTION SYSTEM
The door retention system is designed to secure the
panels along the floor during a negative pressure
situation. It is also designed to guide the door panel
when opening/closing. The retention system consists
of stay roller assemblies for each door and are
mounted in front of each door panel. With the door
closed a properly positioned stay roller presses the
door slightly against the bulb seal, depressing it ¼-½
inch. (See Figures 11, 15, and/or 16)
DEFROST SYSTEM (OPTIONAL SYSTEM)
The optional defrost system is designed to help
prevent frost build-up in/on the door frame bulb seal
assembly and door panel surfaces, and keep the
seals flexible and pliable in cold temperature
conditions to attain the best seal. A door configured
with a defrost system includes a heat tape circuit and
heat tape strips which are mounted in each bulb seal
section (sides and top).
Rytec
Door
Panels
Rytec
Door
Assembly
Photo eyes
Rytec
Motor
Drive
Rytec
Control
Panel
Photo eye
Stay rollers
Photo eye bracket
Chain
release
lever
Insulated
Rytec Door
Panels
RYTEC
System 4
Control
Panel
RYTEC
Motor
Drive
RYTEC
Door
Assembly

5
PLANNED MAINTENANCE—RECOMMENDED SCHEDULE
Heat Tape Circuit
The heat tape circuit is designed to help prevent frost
from building up along the bulb seal sections of the
door assembly that create the seal w/ the door panel.
The heat tape also helps keep the rubber seals
pliable in a cold environment to maintain a tight
barrier between the door panel and the wall.
The heat tape circuit consists of two self-regulating
heat tapes (1 Long and 1 Short) that are installed
around the door opening. The heat tapes pass
through the door bulb seals that line the door jamb
and header surrounding the door opening. Each tape
runs along the entire vertical length of its respective
jamb frame and across the header frame. From a
hole in the bulb seal foam end block, each tape is
routed to a junction box located below the head
assembly. (See Figure 12)
Figure 12
When this self-regulating circuit is powered up, the
exposed lengths of heat tape running from the
header seal to the junction box will be warm to the
touch.
DOOR PANEL SEALING SYSTEM
The door is equipped with a sealing system which
provides insulation and prevents air infiltration
between the 2 sides of the wall. It consists of 2 or 3
separate systems working together to provide the
seal depending on the door type. The 1st is the door
panel(s) mating and pressing up against a bulb seal
assembly that is mounted on the door wall sides and
top jamb. The 2nd is the bottom door panel sweep
seals that are mounted to each door panel and form
a seal between the floor and panel. The 3rd is the
leading edge mating seals that are mounted to each
Bi-Parting panel leading edge and form a seal
between the panels when the door is closed. To
adjust the door panel seals, follow the procedures in
the Adjustments section.
PLANNED MAINTENANCE
RECOMMENDED SCHEDULE
NOTE: The following maintenance schedule is
recommended. (See Table 1)
Table 1
DAILY INSPECTION
Visual Damage Inspection
Visually inspect the door components such as the
head assembly, side panels, door panels, and door
seals. (See Figure 13 and Figure 14)
Head Assembly: Inspect the head for dents,
damage, or missing/loose items that may prevent
the door from operating properly.
Insulated Door Panels: Ensure the insulated
door panels are clean. Inspect them for holes,
tears, and worn areas. Clean, repair, or replace
the panels as required. They can be cleaned with
general cleaning or caustic wash down solution.
A repair kit is available for rips or tears to the
thermoplastic exoskeleton.
Door Seals: Inspect all seals for holes, tears,
and worn areas. Ensure the seals form a tight
barrier between the door, floor, and wall and are
ice free. Repair or replace the seals as required.
Door Retainers: Inspect all retainers/stay rollers
for damage, wear, and proper function.
Reposition or replace the retainers as required.
Daily
Quarterly
Visual Damage Inspection
Door Retention Inspection
Door Operation Inspection
Photo Eye Inspection
Electrical Inspection
Mounting Hardware Inspection
Door Retention Inspection
Drive Chain Inspection
Trolley Assembly Inspection
Lubrication
Electric Brake Inspection
Insulated Door Panel and Door
Seal Inspection
Cleaning Panels and Seals
Control Panel and Activator
Inspection
Heat Tape Inspection (Optional
Defrost System)
Wall Anchor Inspection
Chain Release Mechanism
Heat Tape
wire routing
in bulb seal
Heat Tape wire
ends to J-Box
by others

6
PLANNED MAINTENANCE—DAILY INSPECTION
Figure 13
Figure 14
Door Retention Inspection
Move the door to the fully closed position and then
verify that each door panel is properly positioned to
the respective door panel. Excessive pressure on the
door panel from the stay rollers can cause door
malfunction and premature wear of the gasket
system while not enough allows air infiltration,
increasing energy use.
Refer to “DOOR PANEL RETENTION SYSTEM” on
page 4 for additional information on the retention
system. See “DOOR RETENTION/ STAY ROLLER-
DOOR BULB SEAL ADJUSTMENT” on page 15 for
adjustment procedures. (See Figures 15 and 16)
Figure 15
Figure 16
Door Operation Inspection
Run the door through four or five full open/close
cycles to make sure it is operating smoothly and
efficiently. There should be no binding or unusual
noises as the door travels across the head assembly.
Also, as the door opens and closes, verify that the
panels remain in contact with the door retention
system and seal properly.
IMPORTANT: DO NOT continue to operate the
door if it is not running properly.
This could further complicate any
problem.
Refer to “OPERATION” on page 3 for additional
information on control panel operation.
9” (R17-4” Thick Panel)
11” (R25-6”Thick Panel)
Rytec
Control
Panel
Rytec
Motor
Drive
Head
Assembly
Insulated
Rytec
Door
Panels
System 4
Control
Panel
Fused
Disconnect
Photo eyes
Stay
Rollers
Bi-Parting Door
Head
Assembly
Insulated
Rytec Door
Panel
Fused
Disconnect
System 4
Control
Panel
Photo eyes
Stay
Rollers
One-Way Door
Door Panel
Bottom
Sweeps
Door Panel
Bottom Sweeps
Door Jamb
Bulb Seal
Door Jamb
Bulb Seal
Drive Motor/
Gearbox
Assembly
Drive Motor/
Gearbox
Assembly
Anchor base
to concrete
through slots
Align stay roller
with door jamb
Door Opening
Wall
Stay Roller
Base
Approx:
9” (R17-4” Thick Panel)
11” (R25-6”Thick Panel)
Standard F81 Stay Roller Bracket Placement
Anchor base
to concrete
through slots
Offset stay roller
from door jamb
Door
Opening
Wall
Stay Roller
Base for Right
Hand Door
F0091 Universal Cam Stay Roller Bracket Placement
Wall
Stay Roller
Base for Left
Hand Door
3/8”
TYP.

7
PLANNED MAINTENANCE—QUARTERLY INSPECTION
Photo Eye Inspection
Inspect the photo eye mounting brackets and photo
eyes for visible damage or misalignment. Verify that
the photo eyes operate as described below:
Personnel and objects should not be in the path of
the door when the following inspection is
performed. If the photo eyes are not working
properly, the door could strike an individual
or object in its path.
1. Open the door to the fully open position by
pressing the open (▲) key located on the Rytec
System 4 Drive & Control Panel.
2. Place an object between the photo eyes to
interrupt the light beam between the photo eye
transmitter and receiver.
3. Press the close (▼) key on the Rytec System 4
Drive & Control Panel. The door should not move
or close at all.
4. Remove the object and cycle the door to verify
that the front set of eyes is working properly.
5. If the photo eyes on the door front are not
working properly, the photo eyes may be dirty.
Clean the lens of each eye as required, using
window cleaner and a clean, soft cloth. If this
does not resolve the problem, see “PHOTO EYE
ADJUSTMENT-ALIGNMENT” on page 17 for
adjustment procedures.
Refer to “PHOTO EYES” on page 4 for additional
information on how the photo eyes operate.
QUARTERLY INSPECTION
Electrical Inspection
CONTROL PANEL, ENCODER, AND MOTOR
WIRING
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
1. Inspect electrical connections to the power drive
assembly and encoder assembly.
2. Inspect control panel wiring. See Rytec System 4
Drive & Control Installation & Owner’s Manual for
control panel inspection procedure.
UPPER JUNCTION BOX
NOTE: The upper junction box is an optional item
that may have been installed during the
installation of your door. If an upper junc-
tion box was installed, it was most likely
mounted on the wall, just above the control
panel. If your door has an upper junction
box, it must be inspected.
1. Move the door to the fully closed position.
2. Remove power to the control panel by placing
the fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
3. Remove the cover from the upper junction box
located above the door opening. (See Figure 17)
4. Inspect all electrical connections in the upper
junction box. All connections must be tightly
secured.
5. Check for pinched, kinked, cracked, or damaged
wires and insulation. Repair or replace wires as
needed.
6. If the door is configured with the optional defrost
system (heat tapes), inspect all associated
electrical wiring and connections. Repair or
replace wires as needed.
Figure 17
7. Replace the cover.
8. Apply power to the door.
Rework this
Figure
Bi-Parting Door Shown
One-Way Door Is Similar
System 4
Control
Panel
Upper
Junction
Box
Fused
Disconnect

8
PLANNED MAINTENANCE—QUARTERLY INSPECTION
Mounting Hardware Inspection
1. Move the door to the fully closed position.
2. Remove power to the control panel by placing
the fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
3. Check that the mounting hardware securing the
door header assembly and photo eye mounting
brackets to the wall are in place and tight.
Tighten and replace any loose or missing
hardware, such as wall fasteners, floor anchors,
nuts, bolts, and screws. (See Figure 18)
Figure 18
4. Check that all the self-tapping screws used to
secure the bulb seals are tight and in place.
Tighten and replace any loose or missing
hardware. (See Figure 19)
Figure 19
5. Check that all mounting hardware, such as nuts,
bolts, and screws, etc., throughout the head
assembly, drive motor gearbox assembly, idler
assembly, trolleys, mounting brackets, etc. are
secure and tight. Tighten and replace any loose
or missing hardware as necessary. (See Figure
20)
Figure 20
Door Retention Inspection
1. Check all mounting hardware associated with the
stay roller door retention system. Check that it is
properly placed. Impact from forklifts, hand
trucks, or other machinery can degrade the
ability of the door system to seal.
2. Tighten and replace any loose or missing
hardware as necessary. (See Figure 21.)
Figure 21
3. Place the door in the fully closed position.
4. With the stay roller resting on the door panel
closure wedge, the bulb seal should be
depressed ¹/₄-¹/2inch.
5. As the door opens, the gap at the door bottom
will increase but stay relatively constant at the
top. With the door panel held against the stay
roller, the gap along the entire remaining length
of the bulb seal should remain relatively constant
but increase slightly more as the door opens.
The trolley tracks in the head assembly are
designed to move the door panel up and away
from the bulb seal as it opens.
6. If the door does not meet the above
requirements, refer to “DOOR RETENTION/
STAY ROLLER-DOOR BULB SEAL
ADJUSTMENT” on page 15.
Wall
Fasteners
Bulb Seal
Fasteners
½ of Bi-Parting Door Shown/One-Way Door Is Similar
Bulb Seals
Fasteners
(2 shown)

9
PLANNED MAINTENANCE—QUARTERLY INSPECTION
Drive Chain Inspection
1. Move the door to the fully closed position.
2. Remove power to the control panel by placing
the fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
The drive chain, motor drive gear, and all
idler gears must be lubricated according to
the Drive Chain Lubrication section on
page 10.
3. Gain access to head assembly and drive chain.
4. Inspect the drive chain. Check that the chain is
routed properly through the head assembly. The
chain should not be cracked, worn, too loose, or
damaged. Also check for any damaged or
missing links/connectors. Replace any drive
chain parts as necessary. (See Figure 22 and
Figure 23.)
Figure 22
5. With the door in the fully closed position, check
the tension of the drive chain by measuring the
offset of the chain tensioner banana guide. A
properly tensioned chain will have a slight
amount of deflection at its midpoint and the
deflection of the banana guide when the drive
chain is installed on it must be ¼ inch. The chain
should be taught but not tight. (See Figure 24)
6. Inspect the hardware that secures the drive
motor, drive gear, idlers, and tensioners to the
head assembly. Tighten or replace any loose,
missing, or damaged hardware.
Figure 23
Figure 24
IMPORTANT: Excessive chain tension can result
in accelerated chain wear.
Inadequate tension can cause the
drive pulley to jump a tooth on the
chain, jump off completely, and/or
excessive chain wear, and may
result in possible damage to the
chain and/or door.
To adjust the tension of the drive belt, see
“DRIVE CHAIN ADJUSTMENT” on page 14.
Trolley Assembly Inspection
The trolley assembly is installed on the head
assembly and tracks preset for each specific door
assembly at the factory. No adjustment is required.
1. Move the door to the fully closed position. Then
remove power to the control panel by placing the
fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
2. Inspect the door swivel hangers securing the
door panel(s) to each trolley for loose or missing
hardware. The hardware clamping the plate to
the door must be in place and tightly secured.
Replace/tighten hardware as required. (See
Figure 25)
Figure 25
Return Idler-Tensioner Assembly
Door
hanger
trolley
Door
swivel
hanger
Door
trolley
tracks
Chain
Release
Assembly
Fasteners
Ø1/2” x 2.25” Long
Clevis Pin with
Ø1/8” Cotter Pin
Loaded
Deflection: ¼
inch Min.
Sectioned ½ of Bi-Parting Door
Shown, One-Way Door Is Similar
Chain centered
on Banana Chain
Guide Tensioner
Drive
Chain
Banana
Chain
Guide

10
PLANNED MAINTENANCE—QUARTERLY INSPECTION
3. Inspect the door hanger trolley assemblies for
any loose or missing hardware. Tighten or
replace hardware as required. (See Figure 26)
Figure 26
Do not use a petroleum-based solvent or
abrasive cleaner to clean the rollers or track
they travel along, otherwise, damage/
premature wear to the rollers could result.
4. Clean all dirt and grit from the track using an all-
purpose household cleaner and a clean, soft
cloth.
Also clean all dirt and grit from the surface and
sides of each track roller to ensure they travel
smoothly. There are four roller wheels on the
trolley assembly at each end of each door panel.
NOTE: When cleaning the track and rollers, it may
be necessary for you to reposition the door
to gain access to the entire surface of the
track and all sides of each roller.
5. While manually moving the door back and forth
along the track, observe the bearings as each
roller travels along the track. The bearings
should allow the rollers to travel smoothly and
effortlessly without noise or binding.
6. If the trolley rollers are making noise or do not
move freely, inspect each roller assembly after
removing them from the head assembly. Be sure
the snap rings securing the rollers are all in
place. Verify that each wheel on the rollers are
not cracked, worn, or damaged. Clean or replace
roller assemblies as necessary.
Lubrication
1. Move the door to the fully closed position. Then
remove power to the control panel by placing the
fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
2. Lubricate the following items as required:
a. Gearbox: The motor gearbox is filled with
synthetic oil, which does not need to be
changed but should be checked regularly for
proper oil level. The level can be checked at
the plug located on the lower section of the
gearbox.
Recommended oil for refill is as follows:
Mobil SHC 630 Synthetic Gear Oil
Fill the gearbox by removing the breather
toward the top of the gearbox and add oil
through the exposed hole. Add oil until it
starts draining from the check plug hole.
(See Figure 27)
Figure 27
b. Drive Chain: RYTEC recommends
lubrication of the drive chain, drive chain gear,
idler gear(s), and sprockets with high quality
heavy lubricating chain oil every six months.
RYTEC also recommends that the chain be
visually inspected for wear and proper tension
at the same interval.
Electric Brake Inspection
The motor brake assembly is designed to stop the
door panel travel at the locations indicated in the limit
inspection section. Check that the brake is operating
properly. If the limits are set properly and the door
drifts past the set limits or isn’t holding the door
securely, etc., adjust the brake.
If adjustment to the motor brake is necessary, see
“MOTOR BRAKE ADJUSTMENT” on page 19.
¾-10NC bolt
¾-10NC
lock nut
¾-10NC drilled
& tapped rod
Snap Rings
Remove Plug to
Check Oil Level
Remove Breather
to Add Oil

11
PLANNED MAINTENANCE—QUARTERLY INSPECTION
Insulated Door Panel and Door Seal Inspection
Door panels and bulb seals should be regularly
checked for ice buildup, damage, and wear. Ice
buildup in and around the bulb seal gaskets and door
path can impede the door seal and performance,
cause erratic operation, potentially damage
mechanical systems, allow air infiltration, and
increase energy use. Bulb seals should last 36-48
months with proper stay roller pressure/adjustment.
A repair kit is available for rips or tears to the
thermoplastic exoskeleton of the door panel.
1. Move the door to the fully closed position.
IMPORTANT: Operate the door with the drive
motor to ensure the panels and
seals are positioned and com-
pressed as in normal use.
2. Remove power to the control panel by placing
the fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
3. Release the door panel(s) from the drive chain
with the chain release assembly to allow manual
movement of the panel(s) for inspection.
4. Inspect the hardware used to attach each panel
to its respective trolleys and both sides of each
door panel for loose, worn, missing, and
damaged items.
Replace or repair any missing, worn, or damaged
hardware, components, or seals. (See Figure 25,
26, and 28)
5. Inspect the end seal around the perimeter of
each panel. The end seals must be securely
adhered to the panels, not cracked or damaged.
Repair as necessary. (See Figure 28)
Figure 28
6. Inspect the floor sweep along the bottom edge of
each door panel. The cover should not be frayed,
torn, or loose. Replace or adjust as necessary.
Figure 29
7. Make sure a short foam block is installed in the
end of each top panel bulb seal. Replace any
block if it’s missing, torn, or damaged. (See
Figure 29)
8. Manually move the door to the fully open
position.
9. Inspect the bulb seals along the back side of
each panel. The seals should not be worn, torn
or damaged. Replace as necessary. (See Figure
30)
Figure 30
10. Check the floor sweep seal along the bottom
edge of each panel. Because there is a sweep
around each panel face, you will need to use
your fingers to verify the seal along the floor on
both sides of the panel. The seal below the door
panel should be a full seal with the floor and no
gaps along the entire width of the panel.
Floor sweep seals are normal wear items and will
need to be replaced approximately every two
years, depending on usage and local
environment. Replace as necessary.
If an adjustment to any floor sweep seal is
necessary, see “DOOR PANEL FLOOR SWEEP
SEAL ADJUSTMENT” on page 17 for adjustment
procedures.
11. Verify that there is a tight seal between the bulb
seals and the back side of each door panel. The
door panels should depress the bulb seals
between ¼” – ½”.
Standard Perimeter
Elastomer seal
Top bulb seal
foam end block
Bulb Seal
Top bulb seal
foam end block
Bulb Seal
Bulb Seal

12
PLANNED MAINTENANCE—QUARTERLY INSPECTION
If adjustment is necessary, see “DOOR PANEL
ALIGNMENT AND ADJUSTMENT” on page 14 and
“DOOR RETENTION/BULB SEAL ADJUSTMENT”
on page 15.
12. Reconnect the door panel(s) to the drive chain.
13. Apply power and move the door to the fully
closed position.
IMPORTANT: Operate and cycle the door with the
drive motor to ensure the panels
and seals are positioned and com-
pressed as in normal use.
14. Confirm that the door is operating properly.
BI-PARTING DOOR CENTER SEAL INSPECTION
1. Move the door to the fully closed position.
2. Remove power to the control panel by placing
the fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
3. Inspect the Bi-Parting door panel leading edge
seals. It should form a seal tight barrier along the
entire center vertical edge of the panels. They
are normal wear items and will need to be
replaced when worn to insure proper door seal
depending on usage and local environment.
Replace or adjust as necessary. (See Figure 31)
Figure 31
4. Apply power to the control panel by placing the
fused disconnect in the ON position.
5. Restore power to the door and return to service.
If adjustment to the Bi-Parting panel leading edge
seal is necessary see “DOOR LEADING EDGE
SEAL ADJUSTMENT BI-PARTING DOORS” on
page 17.
Cleaning Panels and Seals
Do not use an abrasive cleaner or a
petroleum-based solvent to clean the rollers
or the track they travel along, otherwise,
damage to the rollers could result.
1. Inspect the panels and seals for dirt and grime.
Clean as required using an all-purpose
household cleaner and a clean, soft cloth. Then
thoroughly rinse the panels and seals with fresh,
clean water.
2. Once the door is dry, apply power to the door.
3. Operate the door several times to verify that it
works properly.
Control Panel and Activator Inspection
1. Ensure all associated warning and safety labels
are intact, clean, and easy to read. Replace as
needed.
2. Check the control panel for proper operation.
Make any adjustments or repairs as necessary.
3. Operate the door five or six complete cycles with
each activator installed and used with the door. A
typical activator may be a floor loop, pull cord,
push button, motion detector, radio control, etc.
The open cycle is controlled by an activator. The
close cycle is controlled by an activator or by a
programmable timer internal to the control panel.
If a repair or adjustment is necessary, refer to the
operating instructions provided by the manufac-
turer of that particular activator. To set the auto-
matic timer, refer to the Rytec System 4 Drive &
Control Installation & Owner’s Manual.
Defrost System (Optional System)
HEAT TAPE INSPECTION
1. Remove power to the control panel by placing
the fused disconnect in the OFF position.
The disconnect must be in the OFF position and
properly locked and tagged before performing the
followingprocedure.
NOTE: The bi-parting door is shown. The one-way
door is the same.
Male Panel
Center Edge
Seal
Female Panel
Center Edge
Seal
