Salton CF-2032 User manual

®
Compact Freezer
Instruction Booklet
Model: CF-2032

IIMMPPOORRTTAANNTTSSAAFFEEGGUUAARRDDSS
Before the appliance is used, it must be properly positioned and installed as per
the instruction in the “Installation” section. To reduce the risk of fire, electric shock
or injury, follow basic precautions including the following:
1. Read all instructions before using the appliance.
2. Plug into a grounded 3-prong outlet, DO NOT remove grounding prong,
DO NOT use an adapter, and DO NOT use an extension cord.
3. DO NOT place any other household appliances on top of the unit.
4. It is recommended that a separate circuit, serving only your appliance be
provided. Use receptacles that cannot be turned off by a switch or pull chain.
5. Never clean appliance parts with flammable fluids. DO NOT store or use
gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
6. Failure to unplug the appliance during cleaning or light bulb replacement
could result in electrical shock or personal injury.
7. DO NOT connect or disconnect the plug when your hands are wet.
8. DO NOT operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner. DO NOT
repair or replace any part of the Freezer. Return appliance to SWG Canada
for examination, repair or adjustment. See “Warranty” section.
9. To ensure proper ventilation for your appliance, follow the instructions in the
“Installation” section for proper clearances. Choose a well-ventilated area
with temperatures above 55°F (13°C) and below 90°F (32°C).
10. DO NOT use outdoors.
11. The appliance should not be located next to ovens,grills or other sources
of high heat.
12. It is important for the appliance to be leveled to work properly.
13. Never allow children to operate,play with or crawl inside the unit.
14. DO NOT use this appliance for other than its intended use.
15. DANGER - Risk of child entrapment:
Before disposing of your appliance, ensure that the door (s) are removed.
Shelves should also be left in place to help avoid children climbing inside.
Never allow a child to operate, play with or climb inside the appliance.
SSAAVVEETTHHEESSEEIINNSSTTRRUUCCTTIIOONNSS
HOUSEHOLD USE ONLY 2

GROUNDED PLUG
To reduce the risk of electric shock this appliance has a grounded plug (2 blades
and 1 pin). If the plug does not fit fully into the electrical outlet contact a qualified
electrician. D
DO ON NO OT Tmodify the plug in any way or use an adaptor.
Use an exclusive wall outlet. Do not connect your freezer to extension cords or
together with any other appliance in the same wall outlet. If the power cord is
too short, have a qualified electrician or service technician install an outlet
near the appliance.
DESCRIPTION OF PARTS
1. Adjustable Thermostat
2. Slide-Out Drawers
3. Leveling Legs
4. Reversible Door
BEFORE FIRST USE
1. Remove all packaging and labels. If there is any glue residue rub a small
amount of liquid dish soap with your fingers then wipe with warm water. Dry.
NOTE: DO NOT use any sharp instruments, rubbing alcohol, flammable
fluids or abrasive cleaners to remove tape or glue.
2. Follow the instructions in the “Care and Cleaning” section.
INSTALLATION
1. Remove all packaging.
2. Check to be sure you have all of the following parts:
4 Drawers
1 Thermostat Key
1 Plastic Scraper
1 Ice Cube Tray
3
3
1
4
2
o

3. Let the Freezer stand upright for approximately 2 hours before plugging
in to the power source. This will reduce the possibility of a malfunction
in the cooling system from handling during transportation.
4. This Freezer is designed to be free standing. It was not designed for
recessed or enclosed area installation.
5. Place your Freezer on a floor that is strong enough to support the Freezer
when it is fully loaded.
6. Locate the Freezer away from direct sunlight and sources of heat (stove,
heater, radiator, etc). Direct sunlight may affect the acrylic coating and
heat sources may decrease cooling efficiency.
7. Ensure there is a minimum 20 cm (8”) clearance on both sides,10 cm (4”)
at the back wall and 30 cm (12”) above the unit for proper air circulation.
NOTE: If you are installing your Freezer next to a fixed wall, leave sufficient
space on the hinge side to allow for the door to swing open.
8. Level the Freezer by adjusting the legs at the bottom. Turn the Leg clockwise
to raise that side of the Freezer or turn counterclockwise to lower that
side. While adjusting the Legs, have someone push against the top
of the Freezer to take some weight off the front leveling legs.
NOTE: To help with door closure, position legs with a 1/8" (3 mm) tilt
to the back.
9. DO NOT use in any location not properly insulated or heated, e.g. garage
etc. Your Freezer was not designed to operate in temperatures below
12.8°C (55°F). In extreme cold ambient temperatures the Freezer will
not perform properly. Avoid locating the Freezer in damp or moist areas.
Excessive moisture may cause frost to form quickly on the evaporator.
This would require more frequent defrosting of the Freezer.
10. Make sure all shelves and other parts listed in the Description of Parts
are in place.
11. Once the Freezer has been plugged in, allow the Freezer’s interior to cool
for 2-3 hours before putting food into the compartments.
4

REVERSING THE DOOR
Your Freezer has been built to open from the right; however, it has been
designed to open from either side and can easily be changed by following
the procedure below. You will need a screwdriver and putty knife or other
thin flat device to remove the hinge covers. Use care to prevent scratching
the surfaces.
1. Unplug the Freezer from the wall outlet and empty, including the shelves.
2. Remove the 2 top hinge covers and the screw-hole cover on the door and
set aside.
3. Place protective padding behind the Freezer. Turn the Freezer on its back
onto the protective padding.
4. Remove the screws from the current hinges.
5. Transfer the hinges into the receptacle on the other side of the door, and
thread and secure the screws in their new location. Replace the hinge
covers appropriately.
HOW TO USE
Setting the Temperature Control Dial
1. The Temperature Control Dial is located underneath the countertop
on the front side of the cabinet.
2. The first time you turn the unit on set the temperature control to
the maximum position, using the thermostat key provided. (If the key
is misplaced you may also use a coin or flathead screwdriver.)
3. The temperature range is from “1” the warmest, to “6” the coldest.
4. After 24 – 48 hours, adjust the temperature to suit your needs.
The setting of “4” should be appropriate for most needs.
5. To turn the Freezer off, turn the Temperature Control Dial to the “OFF”
position. NOTE: This only turns off the cooling cycle – not the power.
6. If the Freezer is unplugged, turned off, or without power for any reason,
DO NOT re-connect for at least five minutes to allow the circuits to reset.
Damage may occur if it is re-connected too soon.
7. The inside temperature of the Freezer will vary depending on the frequency
of the door opening and the amount of food.
5

TROUBLESHOOTING
CARE AND CLEANING
Cleaning the Freezer
1. Unplug the freezer and remove the food and shelves/drawers.
2. Wipe the inside of the freezer and the Door Gasket with a cloth or
sponge dampened in a warm water and baking soda solution, 30 ml
(2 tbsp) baking soda to 1 liter/quart of water.
3. Wash the shelf with mild detergent.
4. The exterior should be cleaned with a soft cloth dampened in mild
detergent and warm water.
5. Wring excess water out of the cloth before cleaning any areas that have
the controls or electrical parts.
6
PROBLEM POSSIBLE CAUSE
Appliance does not operate. • Check if the Freezer is plugged in.
• Check if there is power at the AC outlet.
• Check thermostat control setting.
Appliance turns on and
off frequently.
• The room temperature is hotter than normal.
• Large amount of food has been added.
• Frequent door openings.
• Door not closed properly.
• Temperature control not properly set.
• Check gaskets for proper seal.
• Check clearances around Freezer.
Appliance is vibrating. • Ensure that the Freezer is level.
Appliance making noise. • Rattling noise from flow of coolant is normal.
• May hear gurgling sounds at end of each cycle
from coolant which is normal.
• Contraction and expansion of inside walls may
cause crackling and popping noises which is normal.
• Ensure that the Freezer is level
• Check that nothing inside is wobbling.
• Check that nothing has fallen behind the Freezer.
Appliance door not shutting properly. • Ensure that the Freezer is level.
• Door not properly installed after reversing.
• Check door gaskets for proper seal.
• Check for blockages .e.g. food containers,
shelves, bins, etc.

6. DO NOT use abrasive cleansers, which can damage or scratch the finish.
7. Clean Door Gaskets every three months. Gaskets must be kept clean
and pliable to assure a proper seal.
Power Failure
Most power failures are corrected within a few hours and should not affect
the temperature of your appliance if you minimize the number of times
the door is opened.
NOTE: If the unit is unplugged, has lost power, or is turned off; you must wait
3 to 5 minutes before restarting the unit. If you attempt to restart before this
time delay, damage may occur and or the appliance may not start.
Vacations
•Short vacations: Leave the appliance operating during vacations of less
than 3-4 weeks.
•Long vacations: If the appliance will not be used for over one month,
remove all items and unplug the power cord. Clean and dry the interior
thoroughly. To prevent odor and mold growth, leave the door open slightly:
blocking it open if necessary.
Moving your Freezer
1. Remove all contents and store properly.
2. Securely tape down all loose items inside your appliance.
3. Turn the leveling screws up to the base to avoid damage.
4. Tape the door shut.
5. Be sure the appliance stays secure in the upright position during
transportation. Also protect the outside of appliance with a blanket,
or similar item.
7

Defrosting the Freezer
1. Defrost when the Freezer frost exceeds 1 cm (1/4”) thick.
2. CAUTION
•DO NOT use boiling water; this could damage the plastic parts.
•DO NOT use sharp or metallic instruments to remove frost as it
could damage the cooling coils and may void the warranty.
Use only the plastic scraper included with this Freezer.
3. Remove frozen food from Freezer and keep frozen.
4. Turn thermostat dial to “OFF” and unplug the Freezer. The defrosting
process may take several hours.
5. After defrosting discard the melted water, dry the interior of the Freezer
and return the thermostat dial to the previous temperature.
Ice Cube Tray
1. Recommended thermostat setting for ice making is position 6.
2. Fill the ice cube tray 2/3 full, with cold water or with any liquid suitable for
freezing and place the tray on the bottom of the Freezer to freeze properly.
3. Dry the bottom of the tray, to avoid it sticking to the bottom of the Freezer.
4. The best method to get ice cubes out of the tray is to hold the tray under
cold tap water for a second.
5. To eject the ice cubes from the tray, place over the ice bucket and
twist slightly.
Freezing Fresh Foods
1. The quality of frozen food can be compromised by improper use of
the Freezer, poorly packed food, incorrect temperatures and unhygienic
preparation of foods.
2. This Freezer has been designed for long-term storage of frozen food.
3. The storage life of frozen foods varies and the recommended storage
time should not be exceeded.
4. Pre-packed commercially frozen food should be stored in accordance
with the frozen foods manufacturer’s instructions.
8

5. Place frozen food into the Freezer as quickly as possible after purchase.
If there are instructions on the packet, carefully follow these instructions
regarding storage times.
6. Carefully select food you intend to freeze; it should be of adequate
quality and suitable for freezing.
7. Use correct packaging and wrap it tight.
8. The packaging should be airtight and shouldn’t leak since this could
cause substantial vitamin loss and dehydration of foods.
9. Foils and bags should be soft enough to tightly wrap around the foods.
10. When preparing foods to be frozen, consider sanitary precautions.
11. Mark packages with following data: kind and amount of foods and
the date of loading.
12. It is most important that the food is frozen as quickly as possible.
13. If the loading amount is too large, the quality of freezing is reduced
which affects the quality of frozen foods.
HELPFUL HINTS
1. Locate the Freezer in the coolest area of the room, away from heat
producing appliances and out of direct sunlight.
2. Let hot foods cool before putting into Freezer. Foods that freeze too
slowly may lose quality, or spoil.
3. Overloading the Freezer causes the compressor to run longer, and uses
more electricity.
4. Freezer storage baskets should not be lined with aluminum foil, wax
paper, or paper toweling. Liners interfere with cold air circulation, making
the Freezer less efficient.
5. Reduce door openings and extended searches, remove as many items
as required at one time, and close the door as soon as possible.
6. If there is a short power interruption keep door closed to help foods stay
frozen. If the power will be out for a longer period of time, check food
before using. If food has thawed do not refreeze.
9

10
Use an exclusive wall outlet. Do not connect your Freezer to extension cords or
together with any other appliance in the same wall outlet. If the power cord is too
short, have a qualified electrician or service technician install an outlet near the
appliance.
LIMITED WARRANTY
SWG Canada warrants that this appliance shall be free from defects in material
and workmanship for a period of one year from the date of purchase. During this
‘in-warranty’ period, defective products will be repaired or replaced at the discretion
of the retailer and/or SWG Canada. This warranty covers normal domestic usage
and does not cover damage which occurs in shipment or failure which results
from alteration, accident, misuse, abuse, glass breakage, neglect, commercial use or
improper maintenance.
A defective product should be returned to the original place of purchase within
the retailer’s stipulated return/exchange period*. If you are unable to have a defective
product replaced under warranty by the retailer, please check our website
at “www.salton.com” for the service centre nearest you. You may also contact us
for assistance by mail, e-mail, fax or telephone as listed below.
To ensure prompt ‘in-warranty’ service securely package and return the product to us
prepaid. Be sure to include the original proof of purchase and a description of the defect
along with your address and zip/postal code.
For repairs not covered by the warranty, please contact us for assistance.
®
S
SW WG GC CA AN NA AD DA A
Division of Salton Appliances (1985) Corp.
Customer Service Department
81A Brunswick
Dollard-des-Ormeaux
Quebec, Canada H9B 2J5
Website: www.salton.com
E-mail: [email protected]
Fax: [phone]
Tel: [phone]
* Return/exchange policies at each retailer vary and may differ from the SWG Canada 1 year limited warranty
period.
