Samsung CS21D8 User manual

COLOUR
TELEVISION
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
REMOTE CONTROL
ON-SCREEN MENUS
TELETEXT FUNCTION (depending on the model)
ELECT
KS1A(TM75)UK 11/14/03 11:23 PM Page 1

2
ENG
Safety Instructions
Caution
CAUTION: TO PREVENT ELECTRICAL SHOCK, DO
NOT REMOVE REAR COVER, NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
CAUTION
The lightning flash and arrow head
within the triangle is a warning sign
alerting you of “dangerous voltage”
inside the product.
The exclamation point within the
triangle is a warning sign alerting
you of important instructions
accompanying the product.
☛The main voltage is indicated on the rear
of the TV set and the frequency is 50 or
60Hz.
!
WARNING: TO PREVENT DAMAGE WHICH MAY
RESULT IN FIRE OR SHOCK HAZARD. DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
◆Do not expose the television to extreme temperature conditions or to extreme humidity conditions.
◆Do not expose the television to direct sunlight and other sources of heat.
◆Do not expose the television to any liquids.
◆Never put objects of any kind into the television, and do not place a water-containing vessel on the
television.
◆During a storm conditions (especially when there is lightning) unplug the television from the mains
socket and aerial.
◆Do not step on or twist the power cord.
◆Do not overload wall outlets or extension cords as this can result in a risk of fire or electric shock.
◆Please use a soft and dry cloth (not containing volatile matter) when you clean the TV.
◆If the television is broken, do not try to repair it yourself. Contact qualified service personnel.
◆If the remote control is not used for a long period of time, remove the batteries and store it in a
cool, dry place.
◆Do not drop the remote control.
This device is not for use in industrial environments.
KS1A(TM75)UK 11/14/03 11:23 PM Page 2

3
ENG
Contents
◆PREPARING YOUR TELEVISION
■Safety Instructions ......................................................................................... 2
■Caution .......................................................................................................... 2
■Front Panel Controls (depending on the model)............................................ 4
■Using the Buttons on the Front Panel............................................................ 4
■Connection Panels ........................................................................................ 5
■Infrared Remote Control (All Functions Except Teletext) .............................. 6
■Infrared Remote Control (Teletext Functions) ............................................... 7
■Inserting the Batteries in the Remote Control................................................ 8
■Connecting the Aerial or Cable Television Network ...................................... 8
■Switching Your Television On and Off........................................................... 9
■Placing Your Television in Standby mode ..................................................... 9
■Plug & Play Feature (depending on the model)............................................. 10
■Choosing Your Language.............................................................................. 11
◆SETTING UP THE CHANNELS
■Storing the Channels Automatically............................................................... 12
■Selecting a Channel Numbered Ten or Over ................................................ 12
■Storing the Channels Manually...................................................................... 13
■Skipping Unwanted Channels ....................................................................... 14
■Fine tuning Channel Reception ..................................................................... 15
■Sorting the Stored Channels ......................................................................... 16
◆USING THE TELEVISION
■Changing the Picture Standard ..................................................................... 17
■Selecting the Picture Format (depending on the model) ............................... 17
■Adjusting the Picture Settings ....................................................................... 18
■Changing the Sound Standard (depending on the model) ............................ 19
■Adjusting the Sound Settings (depending on the model) .............................. 20
■Adjusting the Volume..................................................................................... 20
■Extra Sound Settings (depending on the model)
(Auto Volume/Melody/Pseudo Stereo/Turbo Sound) .................................... 21
■Selecting the Sound Mode (depending on the model) .................................. 22
■Switching the Sound Off Temporarily ............................................................ 23
■Setting the Sleep Timer ................................................................................. 24
■Setting and Displaying the Current Time (depending on the model)............. 25
■
Switching the Television On and Off Automatically (depending on the model) ... 26
■Activating the Child Lock ............................................................................... 27
■Setting the Blue Screen Mode....................................................................... 28
◆USING THE TELETEXT FUNCTION (depending on the model)
■Teletext Decoder (depending on the model) ................................................. 29
■Displaying Teletext Information (depending on the model) ........................... 29
■Selecting a Specific Teletext Page (depending on the model)...................... 30
■Using FLOF to Select a Teletext Page (depending on the model)................ 31
■Storing Teletext Pages (depending on the model) ........................................ 32
◆INFORMATION ON CONNECTIONS AND RECOMMENDATIONS FOR USE
■Viewing Picture From External Sources ........................................................ 32
■Connecting to the Audio/Video Input/Outputs ............................................... 33
■Automatic Degaussing to Remove Color Patches......................................... 34
■Troubleshooting: Before Contacting Service Personnel................................ 34
■Wiring the Mains Power Supply Plug (UK Only)............................................ 35
☛➢
Symbols
Press Important Note
KS1A(TM75)EU_eng(03120A) 11/17/03 9:56 AM Page 3

4
ENG
Front Panel Controls (depending on the model)
➣Buttons and markings are subject to change.
Using the Buttons on the Front Panel
If your remote control no longer works or you have lost it, you can
use the controls on the front panel of the television to:
◆Switch on the television when it is in Standby mode and
select channels ()
◆Access the main menu ()
◆Adjust the volume ()
Buttons on the front panel have the same function as corresponding
buttons on the remote control.
4
15
6
23
4
156
23
1235
6
4
!!MENU DISPLAY
@@VOLUME ADJUSTMENT
##CHANNEL SELECTION
$$REMOTE CONTROL SENSOR
%%STAND-BY INDICATOR
^^POWER
KS1A(TM75)UK 11/14/03 11:23 PM Page 4

5
ENG
Connection Panels
➢The actual configuration on your TV may be different, depending on
your model.
Rear of TV
A) SCART AUDIO/VIDEO INPUT/OUTPUT CONNECTOR
B) 75ΩCOAXIAL CONNECTOR FOR AERIAL/CABLE NETWORK
C) RCA AUDIO/VIDEO INPUT/OUTPUT CONNECTORS
RCA AUDIO/VIDEO INPUT
CONNECTORS
Front (or Side) of TV
➢Connecting earphones ( ) /headphones ( )
◆You can connect a set of earphones/headphones to your television if you wish to watch a
television programme without disturbing the other people in the room.
◆Prolonged use of earphones/headphones at a high volume may damage your hearing.
OUTPUT
INPUT
VIDEO AUDIO
OUTPUT
INPUT
VIDEO AUDIO
INPUT
MONITOR
-OUT
VIDEO AUDIO
INPUT
MONITOR
-OUT
VIDEO
(MONO)
L-AUDIO-R
B
A
C
CB
C
B
C
BB
KS1A(TM75)UK 11/14/03 11:23 PM Page 5

6
ENG
Infrared Remote Control (All Functions Except Teletext)
➣ Operation of remote control may be affected by bright artificial light near to the TV set.
➣Buttons and markings are subject to change.
POWER
SOUND MENU DISPLAY
(OPTION)
ONE/TWO-DIGIT CHANNEL
SELECTION
TURBO SOUND ON/PLUS/OFF
(OPTION)
TEMPORARY SOUND SWITCH-
OFF
VOLUME DECREASE PREVIOUS CHANNEL
DIRECT CHANNEL SELECTION
TUNER/CABLE NETWORK
SELECTION
EXTERNAL INPUT SELECTION
ON-SCREEN DISPLAY
AUTOMATIC SWITCH-OFF
PICTURE SIZE
NEXT CHANNEL
VOLUME INCREASE
PICTURE STANDARD
SOUND STANDARD (OPTION)
SOUND MODE SELECTION
(OPTION)
MENU DISPLAY
MOVE TO THE REQUIRED MENU
OPTION/
ADJUST AN OPTION VALUE
RESPECTIVELY
SWITCH REPEATEDLY
BETWEEN THE LAST TWO
CHANNELS DISPLAYED
EXIT FROM ANY DISPLAY
CHANGE CONFIRMATION
KS1A(TM75)UK 11/14/03 11:23 PM Page 6

7
ENG
Infrared Remote Control (Teletext Functions)
➣Buttons and markings are subject to change.
TELETEXT HOLD
FASTEXT TOPIC SELECTION
TELETEXT NEXT PAGE
TELETEXT PREVIOUS PAGE
TELETEXT DISPLAY/MIX
LIST/FLOF MODE SELECTION
TELETEXT REVEAL
TELETEXT STORE
PICTURE SIZE
PROGRAMME SELECTION BY
NAME
TELETEXT SUB-PAGE
KS1A(TM75)UK 11/14/03 11:23 PM Page 7

8
ENG
You must insert or replace the batteries in the remote control when
you :
◆Purchase the television.
◆Find that the remote control is no longer operating
correctly.
1Remove the cover of the remote control by pressing the symbol
()and pulling the cover in the direction of the arrow.
2Insert batteries, taking care to respect the polarities:
◆+on the battery with +on the remote control
◆ - on the battery with - on the remote control
3Replace the cover by pushing it in the direction of the arrow.
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
Plug the aerial or cable network input cable to the 75Ωcoaxial socket
on the rear of the television.
Inserting the Batteries in the Remote Control
Connecting the Aerial or Cable Television Network
75Ω
Cable
Television
Network
or
Rear of TV
KS1A(TM75)UK 11/14/03 11:23 PM Page 8

9
ENG
The mains lead is attached to the rear of the television.
☛If you have purchased this television in the United
Kingdom, refer to page 35 for further instructions on
plug wiring.
1Plug the mains lead into an appropriate socket.
➢The main voltage is indicated on the rear of the TV set and
the frequency is 50 or 60Hz.
2Press the “ ” (ON/OFF) button on the front of the television.
Result:The Standby indicator lights up on the front panel.
3Press the POWER ()button on the remote control to switch the
television on.
Result:The programme that you were watching last is re-
selected automatically.
4To switch your television off, press the “ ” (ON/OFF) button again
on the front of the television.
Placing Your Television in Standby mode
Your television can be placed in Standby mode, in order to reduce:
◆Power consumption
◆Wear of the cathode ray tube
The Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
The television is placed automatically in Standby mode when you
turn it on.
1Press the POWER ()button on the remote control.
Result: The screen is turned off and the Standby indicator on
the front of the television lights up.
2To switch the screen back on, simply press the POWER ()button
again on the remote control.
➣You can also switch on by pressing the Por button.
➣Do not leave your television in standby mode for long
periods of time (when you are away on holiday, for example).
In this case, you should switch it off completely.
Switching Your Television On and Off
KS1A(TM75)UK 11/14/03 11:23 PM Page 9

10
ENG
Plug & Play Feature (depending on the model)
When the television is initially powered ON, three basic customer
settings proceed automatically and subsequently: setting the
language, channel and clock.
1If the television is in Standby mode, press the POWER ()button
on the remote control.
Result: The message Plug & Play is displayed. It flickers for a
little while and then the “Language” menu is automatically
displayed.
2Press the ▲or ▼button to select required language. Press the
MENU () button to enter the language, and then the message
Ant. Input : Check is displayed.
➣If any language is not selected on the
Language menu, the
“Language” menu will be displayed about 30 seconds later.
3Make sure that the antenna is connected to the TV. And then press
the œor √button to store the channels (refer to “Storing the
Channels Automatically” on page 12).
Result: The horizontal bar is displayed, and then channels are
stored in an order which reflects their positions in the
frequency range.
4When searching and storing is complete, the Time menu is
displayed.
5Press the œor √button to move to the hour or minute. Set the
hour or minute by pressing the ▲or ▼button (refer to “Setting and
Displaying the Current Time” on page 25).
6When you have finished, press the MENU ()button.
Result: The message ENJOY YOUR WATCHING is displayed, and
then the channel which has been stored will be
activated.
7If you want to reset this feature...
1Press the MENU () button.
2Press the ▲or ▼button to select the Function , and then
press the œor √button.
3Select the Plug & Play by pressing the ▲or ▼button, and
then press the œor √button.
Result: The message
Plug & Play is displayed.
Function
Language : English
Time √
Plug & Play √
Blue Screen : Off
Child Lock √
Plug & Play
ENJOY YOUR WATCHING
Select Enter Exit
P 1
471 MHz 48 %
Ant. Input : Check
Auto Store Exit
Time
Clock 11 : 35
Move Exit
Exit
KS1A(TM75)EU_eng(03120A) 11/17/03 11:37 AM Page 10

11
ENG
Choosing Your Language
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU () button.
2Press the ▲or ▼button to select the Function .
3Press the œor √button to select the Language .
4Select a particular language by pressing the œor √button
repeatedly.
5When you have finished, press the EXIT ()button or press the
MENU ()button repeatedly to return to normal viewing.
Mode ¦¦Custom 
Adjust 
Size : Normal
Select Enter Exit
Function
Language : English
Time √
Plug & Play √
Blue Screen : Off
Child Lock √
Select Adjust Exit
KS1A(TM75)EU_eng(03120A) 11/17/03 9:56 AM Page 11

12
ENG
Storing the Channels Automatically
Selecting a Channel Numbered Ten or Over
When using the numeric buttons to select a channel stored at
programme position ten or higher, follow the instructions below.
1Press the -/-- button.
Result: The “
-- ” symbol is displayed.
2Enter the two-digit channel number.
Example:To select channel 42, press 4, followed by 2.
You can scan the frequency ranges available on your television and
in your country and store all the channels found automatically.
The channels are stored in the order in which they appear in the
frequency bands. It is possible that the automatically allocated
numbers may not correspond to those by which you wish to
identify the channels. If this is the case, refer to “Sorting the Stored
Channels” on page 16.
1Press the MENU () button.
2Press the ▲or ▼button to select the Channel .
3Press the œor √button to select the Auto Store .
4Press the œor √button again.
Result: The horizontal bar is displayed, and then channels are
stored in an order which reflects their positions in the
frequency range. Finally, the search will end automatically.
5When searching and storing is complete, the Sort menu is
displayed.
To... Then...
Sort the stored channels Go to Step 4of the “Sorting
into the desired numerical order the Stored Channels”
procedure on page 16.
Exit the channel store function Press the MENU ()
sorting the channels button without repeatedly
until the menus disappear.
➣If sound does not work regularly after storing channels, select
the sound system which best corresponds in Manual Store
menu (refer to the opposite page).
Mode ¦¦Custom 
Adjust 
Size : Normal
Select Enter Exit
Channel
Auto Store √
Manual Store √
Add/Erase √
Fine Tune √
Sort √
Select Enter Exit
Channel
Sort
From : P 1
To : P
--
Store : ?
Select Adjust Exit
P 1
471 MHz 48 %
Exit
KS1A(03120A)EU_eng 11/19/03 10:35 AM Page 12

13
ENG
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found.
◆The number by which you wish to identify each stored
channel.
1Press the MENU () button.
2Press the ▲or ▼button to select the Channel and press the œor
√button.
3Press the ▲or ▼button to select the Manual Store and press the
œor √button.
Result: The
Manual Store menu is displayed with the Color
System selected.
4Press the œor √button repeatedly until the color is of the best
quality.
Result: The
Color System is changed (depending on the
model).
AUTO ➞PAL ➞SECAM ➞ NTSC4.43
➣NTSC4.43 is a “trick” playback mode used by
special VCR’s to play PAL-recorded videos in
NTSC mode.
5Press the ▲or ▼button to select the Sound System and press the
œor √button repeatedly until the sound is of the best quality.
Result: The Sound System is changed (depending on the
model).
B/G ➞D/K ➞I ➞L/L’ (option)
➣If sound does not work regularly after storing
channels, select the sound system which best
corresponds.
6To start the search, select the Search and then press the œor √
button.
Result: The tuner scans the frequency range until the first
channel or the channel that you selected is received on
your screen.
7To assign a programme number to the channel, select the
Prog.No. . Press the œor √button until you find the correct
number.
8To store the channel and associated programme number, select
the
Store and press the œor √button.
Result:
OK is displayed.
9Repeat Steps 6to 8for each channel to be stored.
10 When you have finished manual storage, press the EXIT ()
button or press the MENU ()button repeatedly to return to
normal viewing
Storing the Channels Manually
➞➞
Channel
Auto Store √
Manual Store √
Add/Erase √
Fine Tune √
Sort √
Select Enter Exit
Channel
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Select Adjust Exit
Channel
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Select Adjust Exit
Channel
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Select Adjust Exit
Channel
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : ?
Select Adjust Exit
Channel
Manual Store
Color System : AUTO
Sound System : B/G
Search : -/+
Prog.No. : 18
Store : OK
Select Adjust Exit
KS1A(TM75)UK 11/14/03 11:23 PM Page 13

You can exclude the channels of your choice from the channel scan
operation. When you scan through the stored channels, those you
have chosen to skip are not displayed.
All channels that you do not specifically choose to skip are
displayed during scanning.
1Press the MENU () button.
2Press the ▲ or ▼ button to select the Channel and press the œor
√button.
3Press the ▲ or ▼ button to select the Add/Erase and press the œ
or √button.
Result: The Add/Erase menu is displayed.
4Press the ▲ or ▼button to select the required channel.
5To add or erase the desired channel by pressing the œor √button.
6When you have finished adding and erasing channels, press the
EXIT ()button or press the MENU ()button repeatedly to
return to normal viewing
14
ENG
Skipping Unwanted Channels
Channel
Auto Store √
Manual Store √
Add/Erase √
Fine Tune √
Sort √
Select Enter Exit
Channel
Add/Erase
P 1 : Added
P 2 : Added
P 3 : Added
P 4 : Added
Select Adjust Exit
Channel
Add/Erase
P 1 : Erased
P 2 : Added
P 3 : Added
P 4 : Added
Select Adjust Exit
KS1A(TM75)UK 11/14/03 11:23 PM Page 14

15
ENG
If the reception is clear, you do not have to fine-tune the channel,
as this is done automatically during the search and store operation.
If however the signal is weak or distorted, you may have to fine-
tune the channel manually.
1Press the MENU () button.
2Press the ▲ or ▼ button to select the Channel and press the œor
√button.
3Press the ▲ or ▼ button to select the Fine Tune and press the œ
or √button.
Result: The Fine Tune menu is displayed with the Tune
selected.
4To... Press the...
obtain a sharp and ◆œor √button.
clear picture and Result: The horizontal bar’s
good sound quality cursor moves to the left
or right.
memorise adjusted ◆▲or ▼button to select the Store .
picture or sound ◆œor √button.
Result: OK is displayed.
erase adjusted ◆▲or ▼button to select the Erase .
picture or sound ◆œor √button.
Result: OK is displayed.
5When you have finished, press the EXIT ()button or press the
MENU ()button repeatedly to return to normal viewing.
Fine tuning Channel Reception
Channel
Auto Store √
Manual Store √
Add/Erase √
Fine Tune √
Sort √
Select Enter Exit
Channel
Fine Tune
Tune : -/+
Store : ?
Erase : ?
Select Adjust Exit
Channel
Fine Tune
Tune : -/+
Store : OK
Erase : ?
Select Adjust Exit
Channel
Fine Tune
Tune : -/+
Store : ?
Erase : OK
Select Adjust Exit
Fine Tune
KS1A(TM75)UK 11/14/03 11:23 PM Page 15

You can exchange the numbers of two channels, in order to:
◆Modify the numeric order in which the channels have
been automatically stored.
◆Give easily remembered numbers to the channels that
you watch most often.
1Press the MENU () button.
2Press the ▲ or ▼ button to select the Channel and press the œor
√button.
3Press the ▲ or ▼ button to select the Sort and press the œor √
button.
Result: The Sort menu is displayed with the From selected.
4Press the œor √button until the channel number that you wish to
change is displayed.
Result: The selected channel’s picture is displayed.
5Press the ▲ or ▼ button to select the To .
6Press the œor √button until the new number by which you wish to
identify the channel is displayed.
Result: The selected channel is exchanged with the one
previously stored to the chosen number.
Example: If you select P 1 for the From and P 3 for the To :
◆Channel 1 becomes channel 3.
◆Channel 3 becomes channel 1.
7To... Press the...
Confirm the exchange ◆▲or ▼button to select the Store .
of channel numbers ◆œor √button.
Result: OK is displayed.
➣You can exchange other
channel numbers by selecting
From and returning to step 4.
8When you have finished sorting channels, press the EXIT ()
button or press the MENU ()button repeatedly to return to
normal viewing
16
ENG
Sorting the Stored Channels
Channel
Auto Store √
Manual Store √
Add/Erase √
Fine Tune √
Sort √
Select Enter Exit
Channel
Sort
From : P 1
To : P
--
Store : ?
Select Adjust Exit
Channel
Sort
From : P 1
To : P 3
Store : ?
Select Adjust Exit
Channel
Sort
From : P 3
To : P 1
Store : OK
Select Adjust Exit
KS1A(TM75)UK 11/14/03 11:23 PM Page 16

17
ENG
You can select the type of picture which best corresponds to your
viewing requirements. The following picture effects are available in
the order given:
◆Custom, Standard, Sports, Natural, Mild.
1Press the MENU () button.
Result: The
Picture menu is displayed.
2Press the œor √button.
Result: The
Mode menu is selected.
3Select to satisfy your preference by pressing the œor √button.
4When you have been finished, press the EXIT ()button or press
the MENU ()button repeatedly to return to normal viewing.
➣You can select the required picture effect by simply
pressing the “P.MODE” (Picture Mode) button on the
remote control.
Changing the Picture Standard
Selecting the Picture Format (depending on the model)
You can select the picture format which best corresponds to your
viewing requirements. The following picture formats are available
in the order given:
◆Normal
◆Zoom (expansion of a 16:9 picture to full screen format)
◆16:9
1Press the MENU ()button.
Result: The
Picture menu is displayed.
2Press the œor √button.
3Press the ▲ or ▼ button to select the Size .
4Select to satisfy your preference by pressing the œor √button.
5When you have been finished, press the EXIT ()button or press
the MENU ()button repeatedly to return to normal viewing.
➣You can select the required picture format by simply
pressing the “P.SIZE( )”(Picture Size) button on the
remote control.
Mode œœCustom √
Adjust √
Size : Normal
Select Adjust Exit
Mode œœCustom √
Adjust √
Size : Normal
Select Adjust Exit
KS1A(03120A)EU_eng 11/21/03 10:10 PM Page 17

18
ENG
Adjusting the Picture Settings
Your television has several settings which allow you to control picture
quality:
◆Color Tone, Contrast, Brightness, Sharpness, Color, Tint
(NTSC only)
1Press the MENU () button.
Result: The
Picture menu is displayed.
2Press the œor √button.
3Press the ▲ or ▼ button to select the Adjust , and then press the œ
or √button.
Result: When select the
Mode to Custom , the Adjust menu is
displayed.
4To adjust the... Press the...
◆Color Tone ◆œor √button.
Result: You select the required option
( Normal , Warm1/2 , Cool1/2 ).
◆Contrast ◆œor √button.
◆Brightness Result: The horizontal bar is displayed.
◆Sharpness
◆Color
◆Tint (NTSC only)
5When you are satisfied with the settings, press the EXIT ()button
or press the MENU ()button repeatedly to return to normal
viewing.
➣The television has an “automatic degaussing” system that is
activated if magnetic interference is present. To degauss the
television screen, switch power off by pressing the “ ”
(ON/OFF) button on the front panel (refer to “Automatic
Degaussing to Remove Color Patches” on page 34).
➣If you make any changes to the Adjust settings, the picture
standard is automatically switched to Custom.
Mode œœCustom √
Adjust √
Size : Normal
Select Enter Exit
Adjust
Color Tone : Normal
Contrast 90
Brightness 50
Sharpness 50
Color 50
Select Adjust Exit
Adjust
Color Tone : Normal
Contrast 90
Brightness 50
Sharpness 50
Color 50
Select Adjust Exit
Contrast 91
KS1A(TM75)UK 11/14/03 11:23 PM Page 18

You can select the type of special sound effect to be used when
watching a given broadcast. The following sound effects are
available in the order given:
◆Custom, Standard, Music, Movie, Speech.
1Press the MENU () button.
2Press the ▲ or ▼ button to select the Sound and press the œor √
button.
Result: The
Mode menu is selected.
3Select to satisfy your preference by pressing the œor √button.
4When you have been finished, press the EXIT ()button or press
the MENU ()button repeatedly to return to normal viewing.
➣You can select the required sound effect by simply pressing
the “S.MODE” (Sound Mode) button on the remote
control.
19
ENG
Changing the Sound Standard (depending on the model)
Sound
Mode œœCustom √
Adjust √
Auto Volume : Off
Melody : On
Pseudo Stereo : Off
Turbo Sound : Off
Select Adjust Exit
KS1A(TM75)UK 11/14/03 11:23 PM Page 19

20
ENG
Adjusting the Sound Settings (depending on the model)
The sound settings can be adjusted to suit your personal preferences.
1Press the MENU () button.
2Press the ▲ or ▼ button to select the Sound and press the œor √
button.
3Press the ▲ or ▼ button to select the Adjust and press the œor √
button.
Result: When select the
Mode to Custom , the Adjust menu is
displayed.
4Select the required option by pressing the ▲ or ▼ button and
adjust to satisfy your preference by pressing the œor √button.
5Press the œor √button.
Result: The horizontal bar is displayed.
6When you are satisfied with the settings, press the EXIT ()button
or press the MENU ()button repeatedly to return to normal
viewing.
➢You can display the sound adjust menu directly by pressing
the “S.MENU” (Sound menu) button on the remote control.
Adjusting the Volume
You can adjust the volume by pressing the or button on the
remote control.
◆Press the button to increase the volume.
(cursor moves to the right)
◆Press the button to decrease the volume.
(cursor moves to the left)
➣The volume setting is retained:
◆When you switch the television to standby mode
◆When you switch the television off using the “”
(ON/OFF) button on the front panel
◆If there is a power failure.
Sound
Mode œœCustom √
Adjust √
Auto Volume : Off
Melody : On
Pseudo Stereo : Off
Turbo Sound : Off
Select Enter Exit
Sound
Adjust
Bass 50
Treble 50
Balance L 50 R 50
Select Adjust Exit
Balance L 49 R 51
KS1A(TM75)UK 11/14/03 11:23 PM Page 20
