Samsung EM-W1100 User manual

sanyo.fm Page 1 Thursday, January 6, 2005 5:52 PM

2
S AVE T HESE I NSTRUCTIONS
Safety
P RECAUTIONS TO A VOID
P OSSIBLE E XPOSURE TO
E
XCESSIVE M ICROWAVE
E
NERGY:
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure to
microwave energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face and the
door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there is
no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
WARNING
Always observe Safety Precautions when using your
oven. Never try to repair the oven on your own – there is
dangerous voltage inside.
IMPORTANT SAFETY
INSTRUCTIONS
When using any electrical appliance, basic safety precautions
should be followed, including the following:
WARNING
To reduce risk of burns, electric shock, fire, personal
injury or exposure to excessive microwave energy:
• Read all safety instructions before using the appliance.
• Read and follow the specific “
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
” on this page.
• This appliance must be grounded. Connect only to properly
grounded outlets. See “
IMPORTANT GROUNDING INSTRUCTIONS ” on
page 4 of this manual.
• Install or place this appliance only in accordance with the installation
instructions provided.
• Some items, like whole eggs and food in sealed containers, may
explode if heated in this oven.
• Use this appliance only for its intended use as described in the
manual. Do not use corrosive chemicals or vapors in this appliance.
This type of oven is specifically designed to heat, cook, or dry food. It
is not designed for industrial or laboratory use.
• As with any appliance, close supervision is necessary when used by
children.
sanyo.fm Page 2 Thursday, January 6, 2005 5:52 PM

3
S AVE T HESE I NSTRUCTIONS
Safety
Important Safety Instructions, continued
• Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged.
• This appliance should be serviced only by qualified service
personnel. Contact the nearest authorized service facility for
examination, repair, or adjustment.
• Do not cover or block any of the openings on this appliance.
• Do not store this appliance outdoors. Do not use near water – for
example, near a kitchen sink, in a wet basement, or near a swimming
pool, etc.
• Keep the inside of the oven clean. Food particles or spattered oils
stuck to the oven walls or floor can cause paint damage and reduce
the efficiency of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• When cleaning door and oven surfaces, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance carefully if paper, plastic,
or other combustible materials are inside.
b. Remove wire twist-ties from plastic cooking bags before placing
bags in oven.
c. If materials inside the oven ignite, keep the oven door closed, turn
the oven off, disconnect the power cord, or shut off the power at
the fuse or circuit breaker panel.
d. Do not use the oven compartment for storage purposes. Do not
leave paper products, cooking utensils, or food in the oven when
not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the oven floor. Food will
not cook properly without the tray.
• Do not defrost frozen beverages in narrow-necked bottles. The
containers can break.
• Dishes and containers can become hot. Handle with care.
• Carefully remove container coverings, directing steam away from
hands and face.
• Remove lids from baby food before reheating. After heating baby
food, stir well and test temperature by tasting before serving.
• A short power-supply cord is provided to reduce the risk of becoming
entangled in or tripping over a longer cord. Longer cord sets or
extension cords are available and may be used with caution.
• Do not operate any other heating or cooking appliance beneath this
appliance.
• Do not mount unit over or near any portion of a heating or cooking
appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appliance when it is in
operation.
• If materials inside oven should ignite, keep the oven door closed, turn
the oven off and disconnect the power cord, or shut off power at the
fuse or circuit breaker panel. If the door is opened, the fire may
spread.
sanyo.fm Page 3 Thursday, January 6, 2005 5:52 PM

4
S AVE T HESE I NSTRUCTIONS
Safety
Important Grounding
Instructions
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electrical current. This appliance
is equipped with a cord that includes a grounding wire and a
grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded.
Plug the three-prong power cord into a properly grounded outlet
of standard 115-120 voltage, 60 Hz. Your oven should be the
only appliance on this circuit.
WARNING
Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualified electrician or servicer if
you do not understand the grounding instructions or if you
are not sure if the appliance is properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce the risk of
becoming entangled in or tripping over a longer cord. Longer
cord sets or extension cords are available and may be used if
care is exercised in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of the
appliance.
2. The extension cord must be a grounding-type
3-wire cord and it must be plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on by
children or tripped over accidentally. If you use an extension
cord, the interior light may flicker and the blower may vary
when the microwave oven is on. Cooking times may be
longer, too.
WARNING
Do not cut or remove the third (ground) prong from the
power cord under any circumstances.
sanyo.fm Page 4 Thursday, January 6, 2005 5:52 PM

5
Contents
Safety .......................................................................................................2
Your New Microwave Oven ....................................................................5
Checking Parts ......................................................................................5
Control Panel Buttons ...........................................................................5
Operation .................................................................................................6
Selecting the Weight System ................................................................6
Using the Stop/Clear Button ..................................................................6
Setting the Clock ...................................................................................7
Setting Cooking Times & Power Levels ................................................7
Memory Programming ...........................................................................8
Using Memory Programming .................................................................9
Using the Start/30 sec.+ button .............................................................9
Using the Auto Defrost button .............................................................10
Using the Double Quantity button .......................................................10
Using the Check button .......................................................................11
Resetting each Memory Program’s Cycle Counter .............................11
Resetting the Memory Program Cycle Counter ...................................12
Setting the Sound ................................................................................12
Cooking Instructions ............................................................................12
Cooking Utensils ................................................................................. 12
Recommended ....................................................................................12
Use Caution .........................................................................................12
Unsafe .................................................................................................13
Testing Utensils ...................................................................................13
Guide for Cooking Meat in Your Microwave ........................................13
Cooking & Reheating Guide ................................................................13
Appendix ................................................................................................15
Troubleshooting Guide ........................................................................15
Care and Cleaning ..............................................................................16
Cleaning method for oven feet ............................................................16
Specifications ......................................................................................16
Your New Microwave Oven
Checking Parts
Unpack your microwave oven and check to make sure that you have all
the parts shown here. If any part is missing or broken, call your dealer.
Control Panel Button
instruction manual
Microwave Oven
Auto Defrost (p. 10)
Sets weight of food to be defrosted.
Power Level
Used to select power leve
Number Buttons
Set cooking time, weight and memory
programming.
Double Quantity (p. 10)
Press for additional portion heating.
Program (p. 8~9)
Press to set Memory Programming.
Press to memorize the cooking. It is
possible to select a program number
from 1 to 20.
Stop/Clear (p. 6)
Press to stop oven or correct a
mistake.
Start/30sec.+ (p. 9)
Press to start cooking or press once for
every 30 sec. of cooking at High
power.
Check (p. 11)
Press to confirm the Program.
Clock (p. 7)
Sets current time.
Sound (p. 12)
Press to adjust sound volume.
sanyo.fm Page 5 Thursday, January 6, 2005 5:52 PM

6
Operation
Selecting the Weight System
1The first time the power cord is plugged into an outlet, or after there
has been an interruption in power, all digits and indicators will be
displayed. At this point, the weight system can be selected by using
the “ 0 “ button. By pressing “ 0 “ once, kilograms will be selected.
2To select pounds, quickly press “0” again.
3After selecting the weight system, two seconds standing time is
required before the setting is automatically completed.
Using the Stop/Clear Button
The Stop/Clear button allows you to clear instructions you have
entered. It also allows you to pause the oven's cooking cycle, so that you
can check the food.
• To pause the oven during cooking, press Stop/Clear once. To
restart, press Start.
• To correct a mistake you have just entered, press Stop/Clear once,
then re-enter the instructions.
sanyo.fm Page 6 Thursday, January 6, 2005 5:52 PM

77
Operation
Setting the Clock
1Press the Clock button. The display will show:
2Use the Number buttons to enter the current time. You must press
at least three numbers to set the clock. If the current time is 5:00,
enter 5,0,0.
3Press Clock again. A blinking colon will appear, indicating that the
time is set.
If there is a power interruption, you will need to reset the clock.
You can check the current time while cooking is in progress by
pressing the Clock button.
Setting Cooking Times & Power Levels
One-Stage Cooking
1Press the Power Level button to select power.
By pressing the Power Level button repeatedly, you can select the
power level - HI, MED, or LO.
2Use the Number buttons to set a cooking time. You can set a time
from one second to 30 minutes. To set a time over one minute,
enter the seconds as well.
For example, to set 10 minutes, enter 1, 0, 0, 0.
3Press Start button to begin cooking.
Note: The maximum allowable cooking time is 30 min. If the
time exceeds 30 min, the display will show “E3”. Press the
Stop/Clear button and retry the steps.
sanyo.fm Page 7 Thursday, January 6, 2005 5:52 PM

8
Operation
Multi-Stage Cooking
1Press the Power Level button to select power.
By pressing the Power Level button repeatedly, you can select the
power level - HI, MED, or LO.
2Use the Number buttons to enter the cooking time. You can set a
time from one second to 30 minutes. To set a time over one minute,
enter the second as well. For example, to set 10 minutes, enter 1,
0, 0, 0.
3Repeat steps 1 - 2 for stage II or III cooking.
4Press Start button to begin cooking.
Note: The maximum allowable cooking time is 30 min. The sum
of programmed stage cooking time must not exceed 30
min. If the time exceeds 30 min, the display will show
“E3”. Press the Stop/Clear button and retry the steps.
Memory Programming
One-Stage Cooking
1Upon pressing the Program button, the oven will enter the
Program mode. The display will be cleared.
2Using the Number buttons, enter the program number from 1 to
20.
3Then, press the Power Level button to select power. By pressing the
Power Level button repeatedly, you can select the power level - HI,
MED, or LO.
4After selecting the power level, Use the Number buttons to enter
the cooking time. You can set a time from one second to 30
minutes. To set a time over one minute, enter the seconds as well.
For example, to set 10 minutes, enter 1, 0, 0, 0.
5Press the Program button to complete setting the memory.
The display will show " :0" or the present time (If the time is set)
Note: The maximum allowable cooking time is 30 min. If the
time exceeds 30 min, the display will show “E3”. Press the
Stop/Clear button and retry the steps.
Power Level Percentage Output
HI 100% 1100W
MED 70% 770W
LO 50% 550W
sanyo.fm Page 8 Thursday, January 6, 2005 5:52 PM

9
Operation
Multi-Stage Cooking
1Upon pressing the Program button, the oven will enter the
Program mode. The display will be cleared.
2Using the Number buttons, enter the program number from 1 to 20.
3Then, press the Power Level button to select power. By pressing
the Power Level button repeatedly, you can select the power level
- HI, MED, or LO.
4Use the Number buttons to enter the cooking time. You can set a
time from one second to 30 minutes. To set a time over one minute,
enter the seconds as well. For example, to set 10 minutes, enter 1,
0, 0, 0.
5Repeat steps 3 and 4 for stage II or III memory programming.
6Press the Program button to complete setting the memory. The
display will show “0” or the present time (if the time is set).
Note: The maximum allowable cooking time is 30 min. The sum
of programmed memory stage cooking time must not
exceed 30 min. If the time exceeds 30 min, the display will
show “E3”. Press the Stop/Clear button and retry the
steps.
Using Memory Programming
1Press the Number buttons to select user-programmed memory
functions (please refer to Memory Programming) from 1 to 20. The
oven will start instantly without pressing the Start button.
Using the Start/30 sec.+ button
This button offers a convenient way to heat food in 30 sec. increments at
the High power level.
1Press the Start/30 sec.+ button once for each 30 sec. you wish to
cook the food.
For example, press it twice for one minute. The time will display,
and the oven starts automatically.
Add 30 seconds to a program in progress by pressing the Start/30
sec.+ button for each 30sec. you want to add.
sanyo.fm Page 9 Thursday, January 6, 2005 5:52 PM

10
Operation
Using the Auto Defrost button
1Press the Auto Defrost button. If you have set your oven for metric
measure, the display shows "0.2Kg".
If you have set your oven for weight measure, the display shows
"0.5 LB"
2To set the weight of your food, press the Auto Defrost repeatedly or
Number buttons. The Auto Defrost button increases the weight by
0.2Kg increments up to 2.6Kg. (by 0.5lb increments up to 6.0lbs). If
you want to input 1.2Kg by Number buttons, press 1,2 in turn.
3The oven calculates the defrosting time and starts automatically.
Twice during defrosting, the oven will beep.
4Press the Stop/Clear button, open the oven door, and turn the food
over.
5Press the Start/30 sec.+ button to resume defrosting.
Using the Double Quantity button
1Press the Double Quantity button.
2By using the Number buttons, enter the Memory Program number
from 1 to 20. For example, suppose you press “5”, for Memory
Program 5 which is Stage I HI Power Level with cooking time of 6
minutes and 30 seconds.
3The Memory Program then operates for double the user-
programmed time, which in this case is 13 minutes.
Note: The maximum allowable cooking time is 30 min. If the
program time is doubled and exceeds 30 minutes, the
display will show “E3”, then press Stop/Clear button.
sanyo.fm Page 10 Thursday, January 6, 2005 5:52 PM
