Samsung HW-H600 User manual

Wireless Audio - SoundStand
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register your product at
www.samsung.com/register
User manual
'This Nanum Gothic Eco font is provided by NAVER'
HW-H600
HW-H610
HW-H600_H610_USA_ENG_141028.indd 1HW-H600_H610_USA_ENG_141028.indd 1 2014-10-28  5:36:282014-10-28  5:36:28

2
FEATURES
FEATURES
TV SoundConnect
TV SoundConnect lets you listen to audio from your TV on your SoundStand via a Bluetooth connection and
lets you control the sound.
HDMI
HDMI transmits video and audio signals simultaneously, and provides a clearer picture.
The unit is also equipped with the ARC function which lets you listen to sound from your TV through the
SoundStand via an HDMI cable. This function is only available if you connect the unit to an ARC compliant TV.
Surround Sound Expansion
The Surround Sound Expansion feature adds depth and spaciousness to your listening experience. Surround
Sound Expansion is powered by Sonic Emotion.
Special Sound Modes
You can select different sound modes - CINEMA / SPORTS / VOICE / MUSIC / STANDARD (OFF) - depending
on the type of content you want to enjoy.
Multi-function Remote Control
You can use the supplied remote control to control various operations with the simple press of a button.
USB Host Support
You can connect and play music files from external USB storage devices such as MP3 players, USB flash
memory, etc. using the SoundStand's USB HOST function.
Bluetooth Function
You can use connect a Bluetooth device to the SoundStand and enjoy music with high quality stereo sound,
all without wires!
NFC (ONLY HW-H610 MODEL)
Connect your NFC compatible device via Bluetooth to the SoundStand using this simple set-up procedure and
play music on the device through the SoundStand.
HW-H600_H610_USA_ENG_141028.indd 2HW-H600_H610_USA_ENG_141028.indd 2 2014-10-28  5:36:392014-10-28  5:36:39

3
ENG
SAFETY INFORMATION
1) Read these instructions.
2) Keep these Instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachment/accessories specified
by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
SAFETY INFORMATION
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK DO
NOT OPEN
The lighting flash and arrowhead within the
triangle indicates that there is dangerous
voltage Inside the product.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The explanation point within the triangle
indicates that there are important instructions
accompanying the product.
WARNING
• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• This product contains chemicals known to the State of California to cause cancer and reproductive toxicity.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the
apparatus.
• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the
power plug must be easily and readily accessible at all times.
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use
shielded cables and connectors for connections.
FCC NOTE (for U.S.A):
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet that is on a different circuit than the radio or TV.
• Consult the dealer or an experienced radio/TV technician for help.
Caution : FCC regulations state that any unauthorized changes or modifications to this equipment may void the user's
authority to operate it.
Important Safety Instructions
Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep
these operating instructions handy for future reference.
HW-H600_H610_USA_ENG_141028.indd 3HW-H600_H610_USA_ENG_141028.indd 3 2014-10-28  5:36:392014-10-28  5:36:39

4
FEATURES
During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
Protect the product from moisture (i.e. vases), and
excess heat (e.g. a fireplace) or equipment creating
strong magnetic or electric fields. Disconnect the
power cable from the AC supply if the unit
malfunctions. Your product is not intended for
industrial use. It is for personal use only.
Condensation may occur if your product has been
stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until
the unit has reached room temperature before using.
Do not expose the unit to direct sunlight or other
heat sources. This could lead to overheating and
cause the unit to malfunction.
The batteries used with this product contain
chemicals that are harmful to the environment.
Do not dispose of batteries in the general household
trash.
Do not dispose of batteries in a fire.
Do not short circuit, disassemble, or overheat the
batteries.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
During thunderstorms disconnect the AC
p
Do not expose the unit to direct sunlight o
PRECAUTIONS
Ensure that the AC power supply in your house complies with the power requirements listed on the
identification sticker located on the back of your product. Install your product horizontally, on a suitable base
(furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots are not
covered. Do not place the unit on amplifiers or other equipment which may become hot. This unit is designed
for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if
you intend to leave it unused for a long period of time.
l
i
hli
i
hh
i
li
d
3.9 inch 3.9 inch
2.7 inch
3.9 inch
WARNING, DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD, The remote control supplied
with this product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death. Keep new and used
batteries away from children. If the battery compartment does not close securely, stop using the
product and keep it away from children. If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
HW-H600_H610_USA_ENG_141028.indd 4HW-H600_H610_USA_ENG_141028.indd 4 2014-10-28  5:36:402014-10-28  5:36:40

5
ENG
CONTENTS
2 FEATURES
3 SAFETY INFORMATION
3 Safety warnings
4 Precautions
6 GETTING STARTED
6 Before reading the user’s manual
6 What’s included
7 DESCRIPTIONS
7 Top/front panel
8 Rear panel
9 REMOTE CONTROL
9 Remote control buttons and functions
11 INSTALLATION
11 SoundStand installation
12 CONNECTIONS
12 Connecting an external device using an
HDMI cable
13 Connecting an external device using
OPTICAL (DIGITAL) cable or AUDIO
(ANALOG) cable
CONTENTS
14 FUNCTIONS
14 Input mode
14 ARC (HDMI OUT)
15 Bluetooth
17 NFC (Only HW-H610 model)
18 TV SoundConnect
19 USB
20 Software upgrade
21 TROUBLESHOOTING
22 APPENDIX
22 Specifications
22 License
Figures and illustrations in this User Manual are
provided for reference only and may differ from
actual product appearance.
HW-H600_H610_USA_ENG_141028.indd 5HW-H600_H610_USA_ENG_141028.indd 5 2014-10-28  5:36:412014-10-28  5:36:41

6
GETTING STARTED
GETTING STARTED
BEFORE READING THE USER’S MANUAL
Note the following terms before reading the user manual.
▶ Icons used in this manual
Icon Term Definition
Caution
Indicates a situation where a function does not operate or settings may be
canceled.
Note
Indicates tips or instructions on the page that help you operate a function.
▶ Safety Instructions and Troubleshooting
1) Be sure to familiarize yourself with the Safety Instructions before using this product. (See page 3)
2) If a problem occurs, check Troubleshooting. (See page 21)
▶ Copyright
©2014 Samsung Electronics Co.,Ltd.
All rights reserved; no part of this user’s manual may be reproduced or copied without the prior written
permission of Samsung Electronics Co.,Ltd.
WHAT’S INCLUDED
Check for the supplied accessories shown below.
( Protection pad : 4ea)
Remote Control /
Lithium Battery (3V : CR2032)
(AH59-02615A/
4301-001042)
User Manual/
(AH68-02697A)/
Quick Guide
(AH68-02707A)
AUX Cable
(BN39-01286A)
Pad
(AH67-00739A)
Adapter
(BN44-00461A)
Power Cord
(3903-000598)
USB Cable
(AH39-01178A)
NFC Sticker
(Only HW-H610 Model)
(BN96-32164A)
● The appearance of the accessories may differ slightly from the illustrations above.
● Use the dedicated USB cable to connect external USB devices to the unit.
HW-H600_H610_USA_ENG_141028.indd 6HW-H600_H610_USA_ENG_141028.indd 6 2014-10-28  5:36:412014-10-28  5:36:41

7
ENG
DESCRIPTIONS
DESCRIPTIONS
TOP/FRONT PANEL
POWER BUTTON
Turns the power on and off.
REMOTE CONTROL SENSOR
The remote control can operate
SoundStands made by SAMSUNG only.
VOLUME +/-
Controls the volume level.
The numeric value of the volume
level appears in the front panel
display.
DISPLAY
Displays the current mode.
FUNCTION BUTTON
Selects the D.IN, AUX, HDMI, BT, TV, USB
input.
● While the unit is powered on, pressing
the ( ) button for more than 3
seconds sets the button to act as MUTE
button. To cancel MUTE button setup,
press the ( ) button for more than 3
seconds again.
● When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
● If you want to enjoy the sound only from the SoundStand, you must turn off the TV's speakers in
the Audio Setup menu of your TV. Refer to the owner's manual supplied with your TV.
HW-H600_H610_USA_ENG_141028.indd 7HW-H600_H610_USA_ENG_141028.indd 7 2014-10-28  5:36:422014-10-28  5:36:42

8
GETTING STARTED
REAR PANEL
Power Supply IN
Connect the AC power adaptor to
the power supply jack, and then
connect the AC power adaptor
plug to a wall outlet.
USB PORT
Connect USB devices such as
MP3 players here to the play files
on the devices.
AUX IN
Connect to the Analog output
of an external device.
HDMI IN Jack
Inputs digital video and audio
signals simultaneously using an
HDMI cable. Use when
connecting a supported external
device.
HDMI OUT Jack
Outputs digital video and audio
signals simultaneously using an
HDMI cable.
OPTICAL IN
Connect to the digital (optical)
output of an external device.
● When disconnecting the power cable of the AC power adaptor from the wall outlet, pull the plug.
Do not pull the cable.
● Do not connect this unit or other components to an AC outlet until all connections between
components are complete.
HW-H600_H610_USA_ENG_141028.indd 8HW-H600_H610_USA_ENG_141028.indd 8 2014-10-28  5:36:422014-10-28  5:36:42

9
ENG
REMOTE CONTROL
REMOTE CONTROL
REMOTE CONTROL BUTTONS AND FUNCTIONS
Play/Pause
Press the
► button to pause playing the file temporarily.
Press the
► button again to play the selected file.
SOURCE
MUTE
SYNC
SYNC
POWER
SOUND
EFFECT
REPEAT
Bluetooth
POWER
VOL
WOOFER
LEVEL
Surr.
Sound
DIMMER
SOURCE
Press to select a source connected to the SoundStand.
Skip Forward
If there is more than one file on the device you are playing, and
you press the $ button, the next file is selected.
REPEAT
You can set the REPEAT function during music playback from a
USB device.
REPEAT OFF : Cancels Repeat Playback.
REPEAT FILE : Repeatedly play a track.
REPEAT ALL : Repeatedly play all tracks.
REPEAT RANDOM : Plays tracks in random order. (A track that
has already been played may be played again.)
DIMMER/ANYNET+
DIMMER : Press the DIMMER/ANYNET+ button on the remote to
control the brightness of the display.
ANYNET+ : Turns on the ANYNET+ function which lets the
remote from your Anynet+ Samsung TV control the SoundStand.
The ANYNET+ function toggles on and off each time the
DIMMER/ANYNET+ button is pressed and held for more than 5
seconds.
Surr.Sound (Surround Sound Expansion)
Surr.Sound adds depth and spaciousness to the sound. Pressing
the Surr.Sound button repeatedly cycles through the Surr.Sound
settings: AUTO, ON, OFF.
SURROUND SOUND AUTO : If the sound source is more than 2
channels then SURROUND SOUND ON turns on automatically. On
the other hand, if the sound source is less than 2 channels (STEREO),
then mode is automatically set to SURROUND SOUND OFF.
WOOFER LEVEL
You can control the woofer volume.
Press or button on the WOOFER LEVEL button to increase or
decrease the woofer volume. You can set it from SW -6 to SW +6.
● SoundStand is a Samsung proprietary name.
● Operate the TV using the TV's remote control.
HW-H600_H610_USA_ENG_141028.indd 9HW-H600_H610_USA_ENG_141028.indd 9 2014-10-28  5:36:422014-10-28  5:36:42

10
REMOTE CONTROL
Bluetooth POWER
Press the Bluetooth POWER button on the remote to turn the
Bluetooth Power function on and off.
See pages 16 and 18 for details.
POWER
Turns the SoundStand on and off.
VOLUME
Adjusts the volume level of the unit.
SOUND EFFECT
Press to select a sound effect mode.
Select the STANDARD mode if you want to enjoy the original sound.
When you choose a Sound Effect mode (except STANDARD),
Surround Sound Expansion will automatically be turned OFF.
Skip Back
If there is more than one file on the device you are playing, and
you press the # button, the previous file is selected.
MUTE
You can turn the volume down to 0 with the push of a button.
Press again to restore the sound to the previous volume level.
SOURCE
MUTE
SYNC
SYNC
POWER
SOUND
EFFECT
REPEAT
Bluetooth
POWER
VOL
WOOFER
LEVEL
Surr.
Sound
DIMMER
AUDIO SYNC
If the SoundStand is connected to a digital TV and the video
appears out of sync with the audio, press the Audio Sync buttons
to sync the audio with the video.
Press the AUDIO SYNC +/- buttons to set the audio delay from 0
to 300 ms. In USB mode, TV mode, or BT mode, the Audio Sync
function may not work.
▶ Installing the Batteries in the Remote Control
1. Use a suitable coin to turn
the remote control's
battery cover
counterclockwise to
remove it as shown in the
figure above.
2. Insert a 3V lithium battery. Keep
the positive (+) pole facing up
when inserting the battery. Put the
battery cover on and align the '●'
marks side by side as shown in the
figure above.
3. Use a suitable coin to turn the
remote control's battery cover
counterclockwise to remove it
as shown in the figure above.
HW-H600_H610_USA_ENG_141028.indd 10HW-H600_H610_USA_ENG_141028.indd 10 2014-10-28  5:36:432014-10-28  5:36:43

11
ENG
INSTALLATION
INSTALLATION
SOUNDSTAND INSTALLATION
If you want to place your TV on top of the SoundStand, please make sure that your TV satisfies the two
conditions below:
- Maximum TV weight : 77.2 lb (35 kg)
- Maximum TV stand dimension : Smaller than 28.4 inches (720 mm) X 12.6 inches (320 mm)
 Fits most TVs up to 60" and up to 77lbs (*TV screen size and stand type may vary)
▶ How to install the SoundStand
Correct installation Do not place the TV to one side on the SoundStand
Do not place the SoundStand near the edge of a TV
shelf, table, or entertainment center.
Do not place a TV whose base is bigger than the
SoundStand’s top surface on the SoundStand.
● Do not place the TV to one side on the SoundStand. The TV may tip over and may cause physical
injury.
● Make sure to place the SoundStand in the center of the shelf, table, etc., when you install it. Do not
place it near an edge.
● If the TV is bigger than the SoundStand, consider a wall-mounted TV installation or place the
SoundStand on a stable surface.
● Keep the SoundStand at least two inches (5 cm) away from the wall when you install it.
▶ Using the protection pads
Place the included protective pads
pads on top of the product and then
place the TV stand on top of them to
prevent scratches on the product’s
surface.
HW-H600_H610_USA_ENG_141028.indd 11HW-H600_H610_USA_ENG_141028.indd 11 2014-10-28  5:36:432014-10-28  5:36:43

12
CONNECTIONS
CONNECTIONS
CONNECTING AN EXTERNAL DEVICE USING AN HDMI CABLE
HDMI is the standard digital interface for connecting to such devices as a TVs, projectors, DVD players, Blu-ray
players, set top boxes, and more.
HDMI prevents any degradation to the signal due to conversion to analog and maintains the video and
audio quality of the original digital source.
HDMI OUTHDMI IN
HDMI Cable
(not supplied)
HDMI Cable
(not supplied)
Digital Devices
HDMI IN
Connect an HDMI cable (not supplied) from the
HDMI IN jack on the back of the product to the
HDMI OUT jack on your digital device.
and,
HDMI OUT (HDMI)
Connect an HDMI cable (not supplied) from the
HDMI OUT jack on the back of the product to the
HDMI IN jack on your TV.
● HDMI is an interface that enables the
digital transmission of video and audio
data with just a single connector.
HDMI OUT (ARC)
The ARC function allows digital audio to output via
the HDMI OUT(ARC) port.
It can be enabled only when the SoundStand is
connected to a TV that supports the ARC function
● ANYNET+ must be turned on.
● This function is not available if the HDMI
cable does not support ARC.
HW-H600_H610_USA_ENG_141028.indd 12HW-H600_H610_USA_ENG_141028.indd 12 2014-10-28  5:36:432014-10-28  5:36:43

13
ENG
CONNECTIONS
CONNECTING AN EXTERNAL DEVICE USING OPTICAL (DIGITAL)
CABLE OR AUDIO (ANALOG) CABLE
This unit comes equipped with one optical in digital jack and one audio analog in jack, giving you two ways to
connect it to a TV.
AUX IN
AUDIO
OUT
OPTICAL IN
OPTICAL
OUT
Audio Cable
or
Optical Cable
(not supplied)
BD/ DVD player/
Set-top box/
Game console
OPTICAL IN
Connect OPTICAL IN (Audio) on the main unit to the
OPTICAL OUT jack of the TV or Source Device.
Change the function to D.IN.
● Do not connect the power cord of this
product or your TV to the wall outlet until
all connections between components are
complete.
● Before moving or installing this product,
be sure to turn off the power and
disconnect the power cord
or,
AUX IN
Connect AUX IN (Audio) on the main unit to the
AUDIO OUT jack of the TV or Source Device.
Change the function to AUX.
HW-H600_H610_USA_ENG_141028.indd 13HW-H600_H610_USA_ENG_141028.indd 13 2014-10-28  5:36:432014-10-28  5:36:43

14
FUNCTIONS
INPUT MODE
Press the SOURCE button on the remote control or the ( ) button on the product's top panel to select
the mode you want.
SOURCE
MUTE
POWER
VOL
WOOFER
SOURCE
FUNCTIONS
Input mode Display
Optical Digital input D.IN
AUX input AUX
HDMI input HDMI
BLUETOOTH mode BT
TV SoundConnect TV
USB mode USB
▶ Auto Power Down function
The unit turns off automatically in the following
situations.
● D.IN/HDMI/BT/TV/USB/ARC Mode
- If there is no audio signal for 25 minutes.
● AUX Mode
- If the AUX cable is disconnected for
25 minutes.
- If there is no KEY input for 8 hours when the
AUX cable is connected. (Auto Power Down
function can be turned off only in that case.)
To turn off Auto Power Down function, while in
AUX mode, press and hold the
& button for
5 seconds. AUTO POWER DOWN ON / OFF
appears on the display.
ARC (HDMI OUT)
HDMI Cable
● The ARC function allows digital audio to output via the HDMI OUT (ARC) port.
It can be enabled only when the SoundStand is connected to a TV that supports the ARC function.
● ANYNET+ must be turned on.
● This function is not available if the HDMI cable does not support ARC.
● The ARC function is activated in D.IN mode if you have connected the unit to a TV that supports
ARC.
● To turn off the ARC function, turn ANYNET+ off.

15
ENG
FUNCTIONS
BLUETOOTH
You can use a Bluetooth device to enjoy music with high quality stereo sound, all without wires!
▶ To connect the SoundStand to a Bluetooth device
Check if the Bluetooth device supports the Bluetooth compliant stereo headset function.
Bluetooth device
Connect
1. Press the
SOURCE button on the remote
control or the ( ) button on the product's top
panel
to display the BT message.
2. Select the Bluetooth menu on the Bluetooth
device you want to connect. (Refer to the
Bluetooth device's user manual.)
3. Select the Stereo headset menu on the Bluetooth
device.
● You will see a list of scanned devices.
4. Select "[Samsung] SoundStand" from the list.
● When the SoundStand is connected to the
Bluetooth device, it will display [Bluetooth
device name]
➞ BT on the front display.
● The device name can only be displayed in
English. An underline " _ " will be displayed if
the name is not in English.
● If the Bluetooth device has failed to pair with
the SoundStand, delete the previous
"[Samsung] SoundStand" found by the
Bluetooth device and have it search for the
SoundStand again.
5. Play music on the connected device.
● You can listen to the music playing on the
connected Bluetooth device over the
SoundStand.
● In BT mode, the Play/Pause/Next/Prev
functions are not available. However, these
functions are available in Bluetooth devices
supporting AVRCP.
● If asked for PIN code when connecting a
Bluetooth device, enter <0000>.
● Only one Bluetooth device can be paired
at a time.
● Bluetooth connection will be terminated
when you turn the SoundStand off.
● The SoundStand may not perform
Bluetooth search or connection correctly
under the following circumstances:
- If there is a strong electrical field around
the SoundStand.
- If several Bluetooth devices are
simultaneously paired with
SoundStand.
- If the Bluetooth device is turned off,
not in place, or malfunctions.
- Note that such devices as microwave
ovens, wireless LAN adaptors,
fluorescent lights, and gas stoves use
the same frequency range as the
Bluetooth device, which can cause
electric interference.
● The SoundStand supports SBC data
(44.1kHz, 48kHz).
● Connect only to a Bluetooth device that
supports the A2DP (AV) function.
● You cannot connect the SoundStand to a
Bluetooth device that supports only the HF
(Hands Free) function.
HW-H600_H610_USA_ENG_141028.indd 15HW-H600_H610_USA_ENG_141028.indd 15 2014-10-28  5:36:442014-10-28  5:36:44

16
FUNCTIONS
▶ Bluetooth POWER on (Bluetooth
POWER)
When the Bluetooth Power On function is on and
the SoundStand is turned off, if a previously paired
Bluetooth device tries to pair with the SoundStand,
the SoundStand turns on automatically.
1. Press the Bluetooth POWER button on the
remote control.
2. Bluetooth POWER on appears on the
SoundStand's display.
● Available only if the SoundStand is listed
among the Bluetooth device’s paired
devices. (The Bluetooth device and the
SoundStand must have been previously
paired at least once.)
● SoundStand will appear in the Bluetooth
device’s searched devices list only when
the SoundStand is displaying [BT READY].
● In the TV SoundConnect mode, the
SoundStand cannot be paired to another
Bluetooth device.
▶ To disconnect the Bluetooth
device from the SoundStand
You can disconnect the Bluetooth device from the
SoundStand. For instructions, see the Bluetooth
device's user manual.
● The SoundStand will be disconnected.
● When the SoundStand is disconnected from the
Bluetooth device, the SoundStand will display
BT DISCONNECTED on the front display.
▶ To disconnect the SoundStand
from the Bluetooth device
Press the SOURCE button on the remote control or
the ( ) button on the product's top panel
to
switch from BT to another mode or turn off the
SoundStand.
● The connected Bluetooth device will wait a
certain amount of time for a response from the
SoundStand before terminating the connection.
(Disconnection time may differ, depending on
the Bluetooth device)
● In Bluetooth connection mode, the
Bluetooth connection will be lost if the
distance between the SoundStand and
the Bluetooth device exceeds 16.25 ft.
(5m).
● The SoundStand automatically turns off
after 25 minutes in the Ready state.
More About Bluetooth
Bluetooth is a technology that enables Bluetooth-
compliant devices to interconnect easily with each
other using a short wireless connection.
● A Bluetooth device may cause noise or
malfunction, depending on usage, when:
- A part of your body is in contact with the
receiving/transmitting system of the
Bluetooth device or the SoundStand.
- It is subject to electrical variation from
obstructions caused by a wall, corner, or
office partition.
- It is exposed to electrical interference from
same frequency-band devices including
medical equipment, microwave ovens, and
wireless LANs.
● Pair the SoundStand with the Bluetooth device
while they are close together.
● The further the distance between the
SoundStand and Bluetooth device, the worse the
quality is.
If the distance exceeds the Bluetooth operational
range, the connection is lost.
● In poor reception-sensitivity areas, the Bluetooth
connection may not work properly.
● The Bluetooth connection only works when it is
close to the unit. The connection will be
automatically cut off if the Bluetooth device is
out of range. Even within range, the sound
quality may be degraded by obstacles such as
walls or doors.
● This wireless device may cause electric
interference during its operation.
HW-H600_H610_USA_ENG_141028.indd 16HW-H600_H610_USA_ENG_141028.indd 16 2014-10-28  5:36:442014-10-28  5:36:44

17
ENG
FUNCTIONS
NFC (ONLY HW-H610 MODEL)
You can connect your SoundStand to an NFC-enabled smart device through a Bluetooth connection with a
simple setup. Once connected, you can enjoy music stored in your smart device through the SoundStand.
▶ Connecting with NFC and smart devices
1. Detach the NFC sticker label from the package and attach it to a desired spot.
● Putting the NFC sticker within a 3m radius from the unit is recommanded.
● Do not attach the NFC sticker on a metallic surface including the SoundStand.
Metallic object may interfere with communication and the NFC sticker may not work properly.
2. Press the
( ) button on the main unit’s top panel or the SOURCE button on the remote control to select
the BT mode.
3. Enable the NFC function of your smart device.
4. Bring your smart device’s NFC antenna close to the NFC label.
5. When the connection prompt appears on your smart device’s display, select <Yes>.
● Once the connection is established, the completion message appears.
 To reconnect once the initial connection had been successful, start from step 3.
▶ Disconnecting NFC
Bring your smart device’s NFC antenna close to the NFC label on the SoundStand again. The disconnection
message appears on the smart device's display.
▶ To connect another smart device to the SoundStand which is already
connected to another NFC compatible device
Bring the new smart device close to the NFC label of the SoundStand.
● The NFC function is implemented in Android v4.1.2 Jelly Bean and later operating systems.
- To make NFC connections, your smart device needs both Android OS 4.1.2 Jelly Bean or later and
the NFC tag for NFC function execution. You also need to download the “Samsung NFC
Connection” application from the Google Playstore and install it on your smart device. For further
details, please refer to the smart device’s user manual.
● The location of the NFC antenna is different in different devices. Confirm the location of your smart
device’s antenna in the device's user manual before attempting to pair it with the SoundStand.
● If your smart device is in a thick housing or case, the NFC connection may not be stable.
● The N-mark is a trade mark or registered trade mark of the NFC Forum Inc. in the United States and
other countries.
● If you have trouble with an NFC connection
- Actually touching your smart device to the NFC label can cause NFC connection failure.
- If the “Empty tag” error is displayed on the smart device, please try again.
- Check whether your smart device’s antenna is close enough to the NFC logo.
● If you turn off the SoundStand when the Bluetooth Power On feature is ON, and then try to
connect a Bluetooth device that has been previously connected using NFC, the SoundStand will
turn on automatically when the device connects.
To set the Bluetooth Power On option, see page16.
HW-H600_H610_USA_ENG_141028.indd 17HW-H600_H610_USA_ENG_141028.indd 17 2014-10-28  5:36:442014-10-28  5:36:44

18
FUNCTIONS
TV SOUNDCONNECT
You can enjoy TV sound through your SoundStand connected to a Samsung TV that supports the TV
SoundConnect function.
▶ Connecting a TV to the SoundStand
Connect
1. Turn on the TV and SoundStand.
● Turn on the menu of the TV.
● Move to Speaker Settings on "Sound" tab.
● Set the "Add New Device" menu to "On".
2. Press the ( ) button on the main unit’s top panel
or the SOURCE button on the remote control to
select the TV mode.
3. On the TV, a message asking whether to enable the
TV SoundConnect function. "[Samsung]
SoundStand" is displayed on the TV screen.
4. Select <Yes> to finish connecting the TV and
SoundStand by TV remote control.
● Switching the SoundStand’s mode from TV
to another automatically terminates TV
SoundConnect.
● To connect the SoundStand to another TV,
the existing connection must be terminated.
● Terminate the connection to the existing TV,
then press the button on the remote
control for 5 seconds to connect to another
TV.
● The TV SoundConnect (SoundShare) function
is supported by some Samsung TVs released
from 2012 on. Check whether your TV
supports the TV SoundConnect(SoundShare)
function before you begin. (For further
information, refer to the TV’s user manual.)
● If your Samsung TV is released before 2014,
check the SoundShare setting menu.
● If the distance between the TV and
SoundStand exceeds 16.25 ft. (5m), the
connection may not be stable or the audio
may stutter. If this occurs, relocate the TV or
SoundStand so that they are within
operational range, and then re-establish the
TV SoundConnect connection.
● TV SoundConnect Operational Range
- Recommended pairing range: within
20 inches (within 50cm)
- Recommended operational range:
within 16.25 ft. (5m)
● Play/Pause, Next, Prev buttons are not
operable in TV SoundConnect mode.
▶ Using the Bluetooth POWER On
function
The Bluetooth POWER On function is available after
you have successfully connected the SoundStand to
a Bluetooth compatible TV using TV SoundConnect.
When the Bluetooth POWER On function is ON,
turning the connected TV on or off will turn the
SoundStand's power on and off as well.
1. Connect the TV with your SoundStand using the
TV SoundConnect function.
2. Press the Bluetooth POWER button on the
SoundStand remote. "BLUETOOTH POWER ON"
appears on the SoundStand's display.
● BLUETOOTH POWER ON : The SoundStand
turns on and off when you turn the TV on or
off.
● BLUETOOTH POWER OFF : The SoundStand
only turns off when you turn the TV off.
● This function is supported only by some
Samsung TVs released from 2013 on.
HW-H600_H610_USA_ENG_141028.indd 18HW-H600_H610_USA_ENG_141028.indd 18 2014-10-28  5:36:522014-10-28  5:36:52

19
ENG
FUNCTIONS
USB
You can play music files located on USB storage devices through the SoundStand.
Display
USB port
1. Connect the USB device to the USB port on the
back of the product.
2. Press the
SOURCE button on the remote
control or the ( ) button on the product's top
panel
repeatedly until USB appears.
3. USB appears on the display screen.
● The SoundStand connection to the USB
device is complete.
● The SoundStand automatically turns off (Auto
Power Off) if no USB device has been
connected for more than 25 minutes.
▶ Before you connect a USB device
Be aware of the following:
● If the file name of a file or folder on a USB device
exceeds 10 characters, it is not displayed on the
SoundStand's display.
● This product may not be compatible with certain
types of USB storage media.
● The SoundStand supports the FAT16 and FAT32
file systems.
- The NTFS file system is not supported.
● Connect USB devices directly to the USB port of
the product. Otherwise, you may encounter a
USB compatibility problem.
● Do not connect multiple storage devices to the
product via a multi-card reader. It may not
operate properly.
● Digital camera PTP protocols are not supported.
● Do not remove the USB device while it is being
read.
● DRM-protected music files (MP3, WMA) from a
commercial web site cannot be played.
● External HDDs are not supported.
● Mobile phone devices are not supported.
● File Format Type Compatibility list:
Format Codec Sampling Rate
*.mp3
MPEG 1 Layer2
16KHz ~ 48KHz
MPEG 1 Layer3
MPEG 2 Layer3
MPEG 2.5 Layer3
*.wma
Wave_Format_
MSAudio1
Wave_Format_
MSAudio2
*.aac
AAC 16KHz ~ 96KHz
AAC-LC
HE-AAC 24KHz ~ 96KHz
*.wav
- 16KHz ~ 48KHz
*.ogg
OGG 1.1.0
*.flac
FLAC 1.1.0,
FLAC 1.2.1 16KHz ~ 96KHz
HW-H600_H610_USA_ENG_141028.indd 19HW-H600_H610_USA_ENG_141028.indd 19 2014-10-28  5:36:522014-10-28  5:36:52

20
FUNCTIONS
Samsung may offer upgrades for the
SoundStand's system firmware in the future.
If an upgrade is offered, you can upgrade the
firmware by connecting a USB device with the
firmware upgrade stored on it to the USB port on
your SoundStand.
Note that if there are multiple upgrade files, you
must load them onto the USB device singly and use
them to upgrade the firmware one at a time.
Please visit samsung.com or contact the Samsung
call center to receive more information about
downloading upgrades files.
● Insert a USB device containing the
firmware upgrade into the USB port on
the main unit.
● Do not disconnect the power or remove
the USB device while upgrades are being
applied. The main unit will turn off
automatically after completing the
firmware upgrade.
When software is upgraded, all settings
are reset to their factory default settings.
We recommend you write down your
settings so that you can easily reset them
after the upgrade.
● Once the software upgrade is completed,
turn off the product and then press and
hold the (►) button for a while to reset
the product.
● If the firmware fails to upgrade, we
recommend formatting the USB device in
FAT16 and trying again.
● Do not format the USB device in the NTFS
format. The SoundStand does not support
the NTFS file system.
● Depending on the manufacturer, some
USB devices may not be supported.
SOFTWARE UPGRADE
HW-H600_H610_USA_ENG_141028.indd 20HW-H600_H610_USA_ENG_141028.indd 20 2014-10-28  5:36:522014-10-28  5:36:52
