Scanstrut SC24 User manual
Product Page no.
Radar Guards 3
Cable Conduit 4
Deck Flood Light 5
Nav Light, GPS & VHF Mount 6
Nav Light, GPS & VHF Extender Mounts 8
Lifting Crane 9
Mast Mount Adapter Kit 11
Adjustable Base Wedge 12
4° Base Wedge 14
Gantry Mount for Dual PowerTower® 15
Gantry Mount for PowerTower® 17
CONTENTS
®
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Radar Guard - SC24, SC25, SC26, SC27, SC28
Installation Instructions
Fitting Radar Guards SC24, SC25, SC26, SC27, SC28
1. Once mast mount is fitted to the mast, install radar and radar guard.
2. Use the long fixing bolts supplied with the radar to attach the radar guard
and radar to the mast mount.
3. We advise the use of large washers under the bolt heads to spread the
load. We also advise the use of spring washers to prevent the fixing bolts
from loosening.
4. Fully tighten all fixings.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Cable Conduit - SC33 / SC66
Installation Instructions
Kit Contents:
SC66 and SC33 supplied in lengths of 1.5m.
Each pack contains 10 lengths.
Also Required:
Rivets and Rivet Gun
OR
Self Tapping screws
Fitting SC66 and SC33 Cable Conduit
1. Plan cable route down the mast and cut conduit to appropriate lengths.
2. We recommend that the joints are staggered so that the joints are
covered.
3. This will help the installation to appear neat, with little bending.
4. Fixings can be either Rivets or Self Tapping Screws.
5. We recommend 4 fixings per length.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Deck Flood Light - SC117
Installation Instructions
Before starting this installation read the Hella Oval 100 mounting
instructions supplied. Consult a qualified marine electrician before starting
this installation.
SC117 Kit Contents:
- 1x Hella Deck Flood Light + nut/bolt
- 1x 3” Tube Clamp assembly
- 1x Stainless Steel bracket
- 1x M8x50 bolt
- 1x M8 washer
- 1x M8 Nyloc nut
- 2x M6x20 Hex Head Bolts
- 2x M6 Nyloc Nuts
- 4x M6 White nut/bolt covers
- 8x M6 Nylon Washers
Also Required:
- 2x 10mm Spanners
- 1x 13mm Spanner
- Ø6mm / 15/16” drill bit
Fitting SC117 during SC100 pole installation (following point 7 on the SC100 pole
instruction sheet):
1. SC117 is designed to mount on the SC100 pole and is attached using the 3” clamps
provided. Assemble the 3” clamps and light mounting bracket around the pole at the
height at which you wish to mount the deck light (see Figure 1).
2. Drill a clearance hole in the UPVC cover strip for the light cable. Ø 6mm / ¼”.
3. Attach the light to the light mounting bracket using the fastenings provided.
* The deck light is factory fitted with 200mm of cable. This will need to be extended for
connection into the boat.
Hella Deck Flood Light
Please note the use of
spacer washers
3” Clamps
Light Bracket
Figure 1 Figure 2
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Nav Light Mount – SC110/SC113
GPS/VHF Antenna Mount – SC111/SC112
Installation Instructions
Please note that the SC113 comes with Hella NaviLED 360 all round white light pre-fitted and hard wired with
1.45m of cable.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Fitting SC110 and SC113
Note: Steps 1 and 2 for SC110 only.
1. SC110 is pre-drilled to fit Perko 200, Aqua Signal 25 & 45 series and Hella Marine
2984 Series lights.
2. Fit light to top mount plate as per mounting instructions for your light. The cable
should be routed down through the SC110 and out through the slot on the underside
of the tube.
3. The SC110 and SC113 fit to the underside of the PowerTower at the port side.
4. Remove the two fixing bolts that hold your radar in place and use them to loosely
secure the SC110/SC113 to the underside of the PowerTower. We advise placing
some Stainless Steel washers under the heads of the fixing bolts to spread load over
a greater area.
5. With the fixing bolts loosely secured, slide the SC110/SC113 fore/aft to your
preferred position. Tighten the fixing bolts securely.
6. The cable can now be routed through the rubber grommet in the rear of the
PowerTower.
Fitting SC111 and SC112
The SC111 and SC112 are designed for the installation of GPS antenna and ‘Whip’ type VHF,
HF/SSB, AM/FM, and cellular antenna of up to 1m in height, that have the standard 1” x 14TPI
thread as their fixing. SC111 and SC112 are designed to work with Pacific Aerials P6161/P6162
adapter for their Pro range of antennas.
1. Thread the cable of your antenna down through the threaded boss at the top of the
SC111/SC112 and out of the slot on the underside of the tube.
2. Attach your antenna to the threaded boss at the top of the tube.
3. The SC111 and SC112 fit to the underside of the PowerTower. SC111 on the
starboard side, the SC112 to the port side.
4. Remove the two fixing bolts that hold your radar in place and use them to loosely
secure the SC111/SC112 to the underside of the PowerTower. We advise placing
some Stainless Steel washers under the heads of the fixing bolts to spread load over
a greater area.
5. With the fixing bolts loosely secured, slide the SC111/SC112 fore/aft to your
preferred position. Tighten the fixing bolts securely.
6. The cable can now be routed through the rubber grommet in the rear of the
PowerTower.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Nav Light, GPS & VHF Antenna Mount Extensions
Installation Instructions
Please note that the EXT-LED comes with Hella NaviLED 360 all round white light pre-fitted and hard wired
with 1.45m of cable.
Fitting EXT-LIGHT and EXT-LED
Note: Steps 1 and 2 for EXT-LIGHT only.
1. EXT-LIGHT is pre-drilled to fit Perko 200, Aqua Signal 25 & 45 series and Hella
Marine 2984 Series lights.
2. Fit light to top mount plate as per mounting instructions for your light. The cable
should be routed down through the EXT-LIGHT.
3. Thread the cable of the light down through the top of the EXT-LIGHT, then down
through the SC111/2 and out of the slot on the underside of the tube.
4. Screw EXT-LIGHT/LED onto the threaded boss at the top of your SC111/2.
5. Continue with installation as per SC111/2 instructions.
Fitting EXT-GPS
EXT-GPS is designed for the installation of GPS antenna that has the standard 1” x 14TPI
thread as their fixing. It elevates the antenna 300mm above the standard SC111 and SC112
for maximum performance where required.
1. Thread the cable of your antenna down through the threaded boss at the top of the EXT-
GPS, then down through the SC111/2 and out of the slot on the underside of the tube.
2. Attach your antenna to the threaded boss at the top of the EXT-GPS.
3. Continue with installation as per SC111/2 instructions.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
SC120 Lifting Crane Fitting Instructions
Installation Instructions
Do not exceed a maximum working load of 30kg/66lbs
SC120 Kit Contents:
[ ] 1 x SC120 lifting Crane
[ ] 2 x 3” Clamp Pairs
[ ] 2 x 3” Clamp Fixing
Packs:
[ ] 4 x M6 x 20 Bolts
[ ] 4 x Nylock M6 Nuts
[ ] 8 x Nylon Washers
[ ] 8 x Nut Covers
[ ] 2 x Ferrule Plates
[ ] 1 x R Clip
[ ] 1 x 4:1 Lifting Tackle Rig
[ ] 8 x Rivets - 4.8 x 16
Also Required:
5mm [3/16”] Drill
Rivet Gun
2 x 10mm Spanners
Packed and checked…
SC120
Ferrule
Plates
R-Clip
4:1 Lifting Tackle 3” Clamp
Pairs
Fig 2.
Fig 3.
Fig 1.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Installation Procedure – Clamp and Ferrule Set-up
1. To ensure safe operation of the SC120 system, rivet the 3” clamps provided to the
modular pole as follows.
2. Assemble 3” Clamps around the Modular Pole and fit a Ferrule Plate to each
Clamp set by positioning it between the 3”Clamp flats. Using M6 Bolts, Nylock M6
Nuts and Nylon Washers from Fixing Pack, loosely tighten the clamp assembly into
positions similar to that shown in Fig. 1 above.
3. The modular pole has four vertical grooves running along its length. Each 3”
clamp assembly has a pair of holes either side of the Ferrule plate. Align these holes
with a pair of vertical grooves to position as desired. Aligning the 3” Clamps and
Ferrules in this way ensures the Crane will hang rotate correctly.*
4. Set the top edge of the Upper Ferrule and Clamp Assembly at the desired height.
Tighten into place.
5. Set the top edge of the Lower Ferrule and Clamp Assembly at exactly 400mm
from the top edge of the Upper Ferrule and Clamp Assembly. Tighten into place
ensuring the clamp is still aligned on the vertical grooves. See Fig 3.
6. Mark a drill centre through each of the 4 holes in each 3”Clamp.
7. Remove each 3”Clamp and Ferrule assembly and using the 5mm [3/16”] drill, drill
through the pole at each mark made in 5.
8. Fix each 3” Clamp to the pole as previously set up, ensuring alignment of the
holes created in 6. and fully tighten.
9. Using the rivets provided fix the clamps permanently to the pole.
* If retro fitting the SC120 to a modular pole system older than spring 2005
version, you will not have the vertical grooves on your pole. Fit the clamps in the
same way, 400mm apart as described in 4. Take care to align the Ferrules directly
above one another accurately.
Crane Set-up
1. To fit the Crane to the Pole simply insert the pins on the Crane into the Ferrules.
The crane should swing freely.
2. To secure the Crane in place, insert the R-Clip through the hole in the bottom of
the pin showing through under the lower Ferrule. Release this pin to remove the
Crane for stowage.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Mast Mount Adapter Kits –50100
Installation Instructions
Contents
4 x adapter rings
8 x M6 x 35mm SS bolts
8 x M6 nyloc SS nuts
8 x M6 washers
16 x nut covers
This adapter kit is designed to mount Scanstrut radar mounts where a standard
installation is not possible. This will include installation onto Isomat and Z-Spar
masts which have an integral spinnaker pole track at the front of the section, or any
other situation where a wider mounting foot position is required.
NB. These guidance notes are supplementary to the installation instructions included
with your Scanstrut mast mount. Please read both carefully before installation.
Mast Platforms: M92722, M92698; SC61; SC71.
1. Mount one adapter ring above and one below the top
mast platform mounting lugs. This utilises the two
inner holes on the adapter ring and effectively
sandwiches the mast platform mounting lugs between
the two adapter rings. Ensure washers are used
under the head of the bolts and under the nyloc nut
to prevent damage to the painted surface.
2. Repeat step 1 for the bottom mast platform mounting lugs.
3. Using the outer holes of the adapter ring, mount the Scanstrut mounting feet
(supplied with the mast platform). Only hand tighten the fastenings to allow
the feet to move when positioning the radar mount onto the mast.
4. From this stage, follow the standard mounting instructions provided with your
Scanstrut mast mount.
5. Complete the installation by tightening the fastenings and adding the nut
covers to all bolt heads and nuts.
Mast Platforms: SC12; SC14; SC18.
1. Mount two adapter rings, sandwiched together, above
the top mounting lugs and below the bottom lugs on
the mast platform.
2. Repeat steps 2 – 5 as above.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Adjustable Base Wedge for Satcom Mount - SC50
Installation Instructions
SC50 Kit Contents:
Satcom Wedge assembly – Including Satcom Wedge Bottom Half,
Satcom Wedge Top Half,
Satcom Wedge Base Seal,
4 x pairs of 6° Washers.
Also Required:
Scanstrut SC45 or SC56 Satcom adapter.
4 x M8 Stainless Steel bolts, large washers and nuts to attach SC50 and SC45/65
installation assembly to deck/arch. Length to suit deck/arch thickness.
8.5mm Drill
Hole Cutter for cable loom; approx 50mm dia.
SC50 and Satcom Adapter Installation (shown at 12°)
See over for Installation Procedure.
Satcom Adapter – SC45 or SC65
Satcom Wedge Assy
6° Washer pairing
Deck / Arch
Bolt Through
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Installation Procedure
1. Place the SC50 wedge assembly in the required position with the wedge base
seal downwards on the deck/arch.
2. Counter rotate the two halves of the Satcom Wedge assembly until a
horizontal plane is created.
3. Place the Satcom adapter onto the horizontal plane created on top of the
SC50 wedges. Correctly align the Satcom adapter fore and aft with respect to
the desired orientation of your Satcom Antenna.
4. Mark through the adapter and SC50 Wedges to the deck with the position of
the 4 mounting holes in the Satcom adapter base.
5. Drill clearance holes for 8mm bolts vertically through the deck/arch so that
the bolt heads will be aligned with the inner surface of the Satcom Adapter.
6. Secure the assembly to the deck using 8mm bolts, the 6° Washer pairings
and lock nuts. When tightening the nuts, the 6° Washers should counter
rotate in a similar way to the SC50 wedges to create a plane perpendicular to
the bolts for the nuts to tighten up against.
7. With the SC50 and Satcom adapter assembly complete, install the antenna as
described in the Satcom Adapter mounting instructions.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
4° Base Wedge for PowerTower – PT3010, PT2010
Installation Instructions
PT3010, PT2010 Kit Contents:
•PT3010 or PT2010 Base Wedge
•Wedge Base Seal
Also Required:
•For PT3010 Base Wedge either a Composite or Aluminium PowerTower.
•For PT2010 Base Wedge a Stainless Steel PowerTower.
•4 x M8 Stainless Steel bolts, large washers and nuts to attach PowerTower
and Base Wedge assembly to the deck. Length to suit deck/arch thickness.
•Ø8.5mm Drill
•Hole Cutter for cable loom; approx Ø50mm.
•Spanners/sockets to suit.
1. Place the PowerTower, wedge and seals in the required position with the
wedge seal on the deck and the PowerTower seal between the base of the
PowerTower and the top surface of the wedge.
2. Mark the deck with the position of the 4 mounting holes.
3. Drill clearance holes for 8mm (5/16 inch) bolts remembering to incline the
drill at 4 degrees to the vertical so that the bolt heads will be aligned with the
top surface of the PowerTower.
4. Secure the assembly to the deck using 8mm or 5/16 inch bolts, washers and
lock nuts. Tighten the nuts until seals are crushed to about 1/3 of their
original thickness or the PowerTower feels secure. Do not over tighten bolts.
5. Install the antenna as described in the PowerTower mounting instructions.
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
Dual PowerTower Gantry Mount – SC114-40
Installation Instructions
Fitting SC114-40
1. Install all lights prior to fitting the SC114-40 to the Dual PowerTower.
2. Gather cables into looms and route through the nearest hole to mounting location,
then out of the holes in the horizontal arms of the SC114-40. The cable looms can
then be routed into one of the water tight cable glands in the back of the Dual
PowerTower.
3. The SC114-40 fits to the underside of the top plate of the Dual PowerTower. One set
of fixing holes on the SC114-40 will match up with fixing holes of your Satcom
Dome.
4. With the addition of large washers to spread load use the fixings for the Satcom
Dome to connect the SC114-40, Dual PowerTower Top plate and Satcom Dome
together. Fully tighten all fixings. We also recommend spring washers to ensure
bolts/nuts stay fully tightened.
Kit Contents
[ ] 1 x SC114-40 Gantry
[ ] 1 x Fore Light Plate
[ ] 2 x Ø23mm End Caps
[ ] 3 x PVC Grommets
[ ] 1 x SC114-60 Gantry (SC114-60)
[ ] 1 x Fore Light Plate
[ ] 2 x 25mm End Cap (101811)
[ ] 3 x Black Grommet (101808)
[ ] 1 x Fastening Pack
[ ] 4 x M8 x 30 C/S Slotted Bolt (60830)
[ ] 4 x M8 Nyloc nut (60080)
[ ] 4 x M8 Washer (60085)
SSccaannssttrruutt LLttdd.. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH TTeell:: +44(0)1803 863800 FFaaxx::+44(0)1803 862223
ee--mmaaiill:: [email protected] wweebbssiittee:: www.scanstrut.com
Dual PowerTower Gantry Mount – SC114-60
Installation Instructions
Fitting SC114-60
Kit Contents
Install all lights prior to fitting the SC114-60 to the Dual PowerTower.
Gather cables into looms and route through the nearest hole to mounting location, then
out of the holes in the horizontal arms of the SC114-60. The cable looms can then be
routed into one of the water tight cable glands in the back of the Dual PowerTower.
The SC114-60 fits to the underside of the top plate of the Dual PowerTower. Position
the lugs of the gantry under the top plate, in line with the four countersunk holes. Use
the M8 bolts, nuts and washers provided to fasten the gantry in place, as shown in the
above diagram.
Tools Required
1 x Large Flat Head Screwdriver
1 x 13mm Spanner
1.
2.
3.
Fits the following:
Perko 100/200, Aqua Signal 25 & 40
series lights, Hella NaviLED Pro series
(using NaviLED 360 surface mount).
®
Fits the following dual PowerTowers® only:
DPT-SR 1-60 DPT-SO 1-60
DPT-SR 2-60 DPT-SO 2-60
Also compatible with Satcom/tv
PowerTower® when installed with a 60cm
satcom (excl. Fleet 33 & 55).
Scanstrut Ltd. 1 Malt Mill, Totnes, Devon, UK TQ9 5NH Tel: +44(0)1803 863800 Fax: +44(0)1803 862223
PowerTower Gantry Mount – SC118
Installation Instructions
Fitting SC118
Please Note: The threaded GPS bosses on the SC118 are designed for the installation of
GPS antenna and ‘Whip’ type VHF, HF/SSB, AM/FM, and cellular antenna of up to 1m in
height, that have the standard 1” x 14TPI thread as their fixing. The bosses are designed to
work with Pacific Aerials P6161/P6162 adapter for their Pro range of antennas.
1. Install all lights and aerials prior to fitting the SC118 to the PowerTower.
2. Gather cables into looms and route through the nearest hole to mounting location,
then out of the holes in the horizontal arms of the SC118. The cable looms can then
be routed into one of the water tight cable glands in the back of the PowerTower.
3. The SC118 fits to the underside of the top plate of the PowerTower. One set of fixing
holes on the SC118 will match up with fixing holes of your Radome.
4. With the addition of large washers to spread load use the fixings for the radar to
connect the SC118, PowerTower Top plate and Radome together. Fully tighten all
fixings. We also recommend spring washers to ensure bolts/nuts stay fully
tightened.
This manual suits for next models
4
Table of contents
