SCC TS-3B Series Owner's manual

SCCInc.TechnicalInstructions

DocumentNo.TS‐4500
TS‐3BSeries February11,2019

SCCInc.
TS…3BStand‐AloneBoiler/BurnerThreePhaseEnclosures
ForSingleorDualFuelBoiler/Burners






Description

T
S‐3B…seriesthreephaseenclosuresaresuitedforanyboiler
burnerstand‐alone480VACpanels.Providesasinglepointpower
entrytoboilers/burnersandconnectstocombustionenclosures
utilizingSiemensLMVlinkagelesscontrolsystems.

T
heTS‐3B…threephaseenclosuresaresuitedforsingleordualfuel
boilers/burners



FeaturesSingleordualfuelstartersorVFDprotectedconnections
Upto125HPblowermotorstarterorVFDprotectedconnection,
upto20HPcompressorstarter,andupto5HPoilpumpstarter
Controlpanel120VACfusedpowerconnection
Controlpanelcommandandfeedbackconnections
Upto150HPblowermotor
NEMA12/4X
UL508listed




TechnicalInstructions TSSeries
DocumentNo.TS‐4500

Page2SCCInc. 
Application

T
heTS‐3B…threephaseenclosuresaresuitedforsingle
ordualfuelboilers/burners,with480VACandupto
125HPblowermotors.


Components

TS…3phasepanelmayincludethefollowingcomponents:
Threephasemainfuseddisconnect
FusesforVFDsandStartersabove20HP
Powerdistributionblocks
Blower,oilpump,andcompressormotorstarters
BlowermotorVFDconnection
1000VAcontrolcircuitfusedtransformer
120VACpowerconnectionterminals
Starterscontrolandfeedbackconnectionterminals
Powerindicationlight(s)




TSSeriesTechnicalInstructions
DocumentNo.TS‐4500


SCCInc. Page3
ProductPartNumbers
TS‐ 3B‐ 2MLCD‐4Y11
Boiler/BurnerThreePhaseStand‐Alone
Enclosure            
SingleorDualFuelBoiler/Burner480VAC         
1=SingleFuel        
2=DualFuel 
       
BlowerMotorStarterorVSDControlled       
M=MotorStarter       
V=VFDControl 
      
BlowerMotorHPSize       
A=Blowermotor2HPI=Blowermotor30HP
B=Blowermotor3HPJ=Blowermotor40HP
C=Blowermotor5HPK=Blowermotor50HP
D=Blowermotor7.5HPL=Blowermotor60HP
E=Blowermotor10HPM=Blowermotor75HP
F=Blowermotor15HPN=Blowermotor100HP
G=Blowermotor20HPO=Blowermotor125HP
H=Blowermotor25HP
OilPumpMotorHPSize     
X=Nooilpumpstarter 
A=Oilpumpmotorstarterfor½HP 
B=Oilpumpmotorstarterfor¾HP 
C=Oilpumpmotorstarterfor1HP 
D=Oilpumpmotorstarterfor1½HP 
E=Oilpumpmotorstarterfor2HP 
F=Oilpumpmotorstarterfor3HP 
G=Oilpumpmotorstarterfor5HP 
    
AtomizationCompressorMotorStarterHPSize 
X=Nocompressormotorstarter 
A=Compressormotorstarterfor3HP 
B=Compressormotorstarterfor5HP 
C=Compressormotorstarterfor7.5HP 
D=Compressormotorstarterfor10HP 
E=Compressormotorstarterfor15HP 
F=Compressormotorstarterfor20HP  
   
Enclosureoptions  
S=AllEnclosureswithoutthecoolingfansareNEMA12/4Xindoorrated
1=NEMA1withcoolingfan  
2=NEMA12withcoolingfanincludeshoodoverfan
4=NEMA4Xwithcoolingfanincludeshoodoverfan  
  
RunIndicatorGreenLights  
Y=Providedinenclosure 
N=Notprovidedinenclosure 
 
MainThreePhaseFusedDisconnect     
1=Providedinenclosure

ControlTransformer480VACto120VAC           
1=1000VAcontroltransformer480VACto120VACprovidedinenclosure

TechnicalInstructions TSSeries
DocumentNo.TS‐4500

Page4SCCInc. 
Specifications
All

Electrical
characteristics

MainPowerVoltage

MainOperatingFrequency

ThreePhasePartsPowerVoltage


480VAC

50–60HZ

460‐480VAC
ComponentControlOperating
Voltage

120VAC
PowerConsumption

SCCR(ShortCircuitCurrentRating)


HPDependent

50to200KARMS



OperatingenvironmentOperatingTemperature

‐10to131°F
[‐23to55°C]
Humidity

Max.85%withno
condensation


TSSeriesTechnicalInstructions
DocumentNo.TS‐4500


SCCInc. Page5
FieldConnections


TechnicalInstructions TSSeries
DocumentNo.TS‐4500

Page6SCCInc. 
FieldConnections(continued)
PowerPanel120VACConnectionwithSCCLMV5xCombustionPanel

PowerPanel120VACConnectionwithSCCLMV3xCombustionPanel



TSSeriesTechnicalInstructions
DocumentNo.TS‐4500


SCCInc. Page7
FieldConnections(continued)
PowerPanel120VACDirectConnectionwithLMV5x


PowerPanel120VACDirectConnectionwithLMV3x



TechnicalInstructions TSSeries
DocumentNo.TS‐4500

Page8SCCInc. 
PartsDescription
Single/DuelFuelStarterControl


1‐MainFusedDisconnectSwitch
2‐1000VA,480VACto120VACcontroltransformer
3‐Threephasepowerdistributionblocks
4‐Controlpanelcontrol/powerterminals
5‐Oilpumpmotorstarter


6‐Compressormotorstarter
7‐Blowermotorstarter
8‐Powerindicationlight
9‐Mainfuseddisconnecthandle
10‐MotorONindicationlights
Single/DualFuelBlowerVFDControl





1‐MainFusedDisconnectSwitch
2‐1000VA,480VACto120VACcontroltransformer
3‐Threephasepowerdistributionblocks
4‐Controlpanelcontrol/powerterminals
5‐Oilpumpmotorstarter

6‐Compressormotorstarter
7‐Blowermotorfusedconnection
8‐Powerindicationlight
9‐Mainfuseddisconnecthandle
10‐MotorONindicationlights


TSSeries TechnicalInstructions
DocumentNo.TS‐4500
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
2 3.4 0 0 0 0 7.1 7 30 NotReq'd 24"X24"X10"
2 3.4 0 0 3 4.8 11.9 12 30 NotReq'd 24"X24"X10"
2 3.4 0.5 1.1 0 0 8.2 10 30 NotReq'd 24"X24"X10"
2 3.4 0.5 1.1 3 4.8 13 15 30 NotReq'd 24"X24"X10"
2 3.4 0.75 1.6 0 0 8.7 10 30 NotReq'd 24"X24"X10"
2 3.4 0.75 1.6 3 4.8 13.5 15 30 NotReq'd 24"X24"X10"
2 3.4 1 2.1 0 0 9.2 10 30 NotReq'd 24"X24"X10"
2 3.4 1 2.1 3 4.8 14 15 30 NotReq'd 24"X24"X10"
2 3.4 1.5 3 0 0 10.1 10 30 NotReq'd 24"X24"X10"
2 3.4 1.5 3 3 4.8 14.9 15 30 NotReq'd 24"X24"X10"
34.80 0 0 0 9.2 10 30 NotReq'd 24"X24"X10"
3 4.8 0 0 3 4.8 14 15 30 NotReq'd 24"X24"X10"
3 4.8 0.5 1.1 0 0 10.3 10 30 NotReq'd 24"X24"X10"
3 4.8 0.5 1.1 3 4.8 15.1 15 30 NotReq'd 24"X24"X10"
3 4.8 0.75 1.6 0 0 10.8 12 30 NotReq'd 24"X24"X10"
3 4.8 0.75 1.6 3 4.8 15.6 17.5 30 NotReq'd 24"X24"X10"
3 4.8 1 2.1 0 0 11.3 12 30 NotReq'd 24"X24"X10"
3 4.8 1 2.1 3 4.8 16.1 17.5 30 NotReq'd 24"X24"X10"
3 4.8 1.5 3 0 0 12.2 12 30 NotReq'd 24"X24"X10"
3 4.8 1.5 3 3 4.8 17 17.5 30 NotReq'd 24"X24"X10"
3 4.8 2 3.4 0 0 12.6 15 30 NotReq'd 24"X24"X10"
3 4.8 2 3.4 3 4.8 17.4 17.5 30 NotReq'd 24"X24"X10"
5 7.6 0 0 0 0 13.4 15 30 NotReq'd 24"X24"X10"
5 7.6 0 0 3 4.8 18.2 20 30 NotReq'd 24"X24"X10"
5 7.6 0 0 5 7.6 21 20 30 NotReq'd 24"X24"X10"
5 7.6 0.5 1.1 0 0 14.5 15 30 NotReq'd 24"X24"X10"
5 7.6 0.5 1.1 3 4.8 19.3 20 30 NotReq'd 24"X24"X10"
5 7.6 0.5 1.1 5 7.6 22.1 25 30 NotReq'd 24"X24"X10"
5 7.6 0.75 1.6 0 0 15 15 30 NotReq'd 24"X24"X10"
5 7.6 0.75 1.6 3 4.8 19.8 20 30 NotReq'd 24"X24"X10"
5 7.6 0.75 1.6 5 7.6 22.6 25 30 NotReq'd 24"X24"X10"
5 7.6 1 2.1 0 0 15.5 15 30 NotReq'd 24"X24"X10"
5 7.6 1 2.1 3 4.8 20.3 20 30 NotReq'd 24"X24"X10"
5 7.6 1 2.1 5 7.6 23.1 25 30 NotReq'd 24"X24"X10"
5 7.6 1.5 3 0 0 16.4 17.5 30 NotReq'd 24"X24"X10"
5 7.6 1.5 3 3 4.8 21.2 25 30 NotReq'd 24"X24"X10"
5 7.6 1.5 3 5 7.6 24 25 30 NotReq'd 24"X24"X10"
5 7.6 2 3.4 0 0 16.8 17.5 30 NotReq'd 24"X24"X10"
5 7.6 2 3.4 3 4.8 21.6 25 30 NotReq'd 24"X24"X10"
5 7.6 2 3.4 5 7.6 24.4 25 30 NotReq'd 24"X24"X10"
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
SCCInc. Page9

TechnicalInstructions
DocumentNo.TS‐4500
TSSeries
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
5 7.6 3 4.8 0 0 18.2 20 30 NotReq'd 24"X24"X10"
5 7.6 3 4.8 3 4.8 23 25 30 NotReq'd 24"X24"X10"
5 7.6 3 4.8 5 7.6 25.8 25 30 NotReq'd 24"X24"X10"
7.5 11 0 0 0 0 18.5 20 30 NotReq'd 24"X24"X10"
7.5 11 0 0 3 4.8 23.3 25 30 NotReq'd 24"X24"X10"
7.5 11 0 0 5 7.6 26.1 30 30 NotReq'd 24"X24"X10"
7.5 11 0 0 7.5 11 29.5 30 30 NotReq'd 24"X24"X10"
7.5 11 0.5 1.1 0 0 19.6 20 30 NotReq'd 24"X24"X10"
7.5 11 0.5 1.1 3 4.8 24.4 25 30 NotReq'd 24"X24"X10"
7.5 11 0.5 1.1 5 7.6 27.2 30 30 NotReq'd 24"X24"X10"
7.5 11 0.5 1.1 7.5 11 30.6 30 30 NotReq'd 24"X24"X10"
7.5 11 0.75 1.6 0 0 20.1 20 30 NotReq'd 24"X24"X10"
7.5 11 0.75 1.6 3 4.8 24.9 25 30 NotReq'd 24"X24"X10"
7.5 11 0.75 1.6 5 7.6 27.7 30 30 NotReq'd 24"X24"X10"
7.5 11 0.75 1.6 7.5 11 31.1 35 60 NotReq'd 24"X24"X10"
7.5 11 1 2.1 0 0 20.6 20 30 NotReq'd 24"X24"X10"
7.5 11 1 2.1 3 4.8 25.4 25 30 NotReq'd 24"X24"X10"
7.5 11 1 2.1 5 7.6 28.2 30 30 NotReq'd 24"X24"X10"
7.5 11 1 2.1 7.5 11 31.6 35 60 NotReq'd 24"X24"X10"
7.5 11 1.5 3 0 0 21.5 25 30 NotReq'd 24"X24"X10"
7.5 11 1.5 3 3 4.8 26.3 30 30 NotReq'd 24"X24"X10"
7.5 11 1.5 3 5 7.6 29.1 30 30 NotReq'd 24"X24"X10"
7.5 11 1.5 3 7.5 11 32.5 35 60 NotReq'd 24"X24"X10"
7.5 11 2 3.4 0 0 21.9 25 30 NotReq'd 24"X24"X10"
7.5 11 2 3.4 3 4.8 26.7 30 30 NotReq'd 24"X24"X10"
7.5 11 2 3.4 5 7.6 29.5 30 30 NotReq'd 24"X24"X10"
7.5 11 2 3.4 7.5 11 32.9 35 60 NotReq'd 24"X24"X10"
7.5 11 3 4.8 0 0 23.3 25 30 NotReq'd 24"X24"X10"
7.5 11 3 4.8 3 4.8 28.1 30 30 NotReq'd 24"X24"X10"
7.5 11 3 4.8 5 7.6 30.9 30 30 NotReq'd 24"X24"X10"
7.5 11 3 4.8 7.5 11 34.3 35 60 NotReq'd 24"X24"X10"
7.5 11 5 7.6 0 0 26.1 30 30 NotReq'd 24"X24"X10"
7.5 11 5 7.6 3 4.8 30.9 30 30 NotReq'd 24"X24"X10"
7.5 11 5 7.6 5 7.6 33.7 35 60 NotReq'd 24"X24"X10"
7.5 11 5 7.6 7.5 11 37.1 40 60 NotReq'd 24"X24"X10"
10 14 0 0 0 0 23 25 30 NotReq'd 24"X24"X10"
10 14 0 0 3 4.8 27.8 30 30 NotReq'd 24"X24"X10"
10 14 0 0 5 7.6 30.6 30 30 NotReq'd 24"X24"X10"
10 14 0 0 7.5 11 34 35 60 NotReq'd 24"X24"X10"
10 14 0 0 10 14 37 40 60 NotReq'd 24"X24"X10"
Page10 SCCInc.

TSSeries TechnicalInstructions
DocumentNo.TS‐4500
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
10 14 0.5 1.1 0 0 24.1 25 30 NotReq'd 24"X24"X10"
10 14 0.5 1.1 3 4.8 28.9 30 30 NotReq'd 24"X24"X10"
10 14 0.5 1.1 5 7.6 31.7 35 60 NotReq'd 24"X24"X10"
10 14 0.5 1.1 7.5 11 35.1 35 60 NotReq'd 24"X24"X10"
10 14 0.5 1.1 10 14 38.1 40 60 NotReq'd 24"X24"X10"
10 14 0.75 1.6 0 0 24.6 25 30 NotReq'd 24"X24"X10"
10 14 0.75 1.6 3 4.8 29.4 30 30 NotReq'd 24"X24"X10"
10 14 0.75 1.6 5 7.6 32.2 35 60 NotReq'd 24"X24"X10"
10 14 0.75 1.6 7.5 11 35.6 35 60 NotReq'd 24"X24"X10"
10 14 0.75 1.6 10 14 38.6 40 60 NotReq'd 24"X24"X10"
10 14 1 2.1 0 0 25.1 25 30 NotReq'd 24"X24"X10"
10 14 1 2.1 3 4.8 29.9 30 30 NotReq'd 24"X24"X10"
10 14 1 2.1 5 7.6 32.7 35 60 NotReq'd 24"X24"X10"
10 14 1 2.1 7.5 11 36.1 40 60 NotReq'd 24"X24"X10"
10 14 1 2.1 10 14 39.1 40 60 NotReq'd 24"X24"X10"
10 14 1.5 3 0 0 26 25 30 NotReq'd 24"X24"X10"
10 14 1.5 3 3 4.8 30.8 30 30 NotReq'd 24"X24"X10"
10 14 1.5 3 5 7.6 33.6 35 60 NotReq'd 24"X24"X10"
10 14 1.5 3 7.5 11 37 40 60 NotReq'd 24"X24"X10"
10 14 1.5 3 10 14 40 40 60 NotReq'd 24"X24"X10"
10 14 2 3.4 0 0 26.4 30 30 NotReq'd 24"X24"X10"
10 14 2 3.4 3 4.8 31.2 35 60 NotReq'd 24"X24"X10"
10 14 2 3.4 5 7.6 34 35 60 NotReq'd 24"X24"X10"
10 14 2 3.4 7.5 11 37.4 40 60 NotReq'd 24"X24"X10"
10 14 2 3.4 10 14 40.4 40 60 NotReq'd 24"X24"X10"
10 14 3 4.8 0 0 27.8 30 30 NotReq'd 24"X24"X10"
10 14 3 4.8 3 4.8 32.6 35 60 NotReq'd 24"X24"X10"
10 14 3 4.8 5 7.6 35.4 35 60 NotReq'd 24"X24"X10"
10 14 3 4.8 7.5 11 38.8 40 60 NotReq'd 24"X24"X10"
10 14 3 4.8 10 14 41.8 45 60 NotReq'd 24"X24"X10"
10 14 5 7.6 0 0 30.6 30 30 NotReq'd 24"X24"X10"
10 14 5 7.6 3 4.8 35.4 35 60 NotReq'd 24"X24"X10"
10 14 5 7.6 5 7.6 38.2 40 60 NotReq'd 24"X24"X10"
10 14 5 7.6 7.5 11 41.6 45 60 NotReq'd 24"X24"X10"
10 14 5 7.6 10 14 44.6 45 60 NotReq'd 24"X24"X10"
15 21 0 0 0 0 33.5 35 60 NotReq'd 24"X24"X10"
15 21 0 0 3 4.8 38.3 40 60 NotReq'd 24"X24"X10"
15 21 0 0 5 7.6 41.1 45 60 NotReq'd 24"X24"X10"
15 21 0 0 7.5 11 44.5 45 60 NotReq'd 24"X24"X10"
15 21 0 0 10 14 47.5 50 60 NotReq'd 24"X24"X10"
SCCInc. Page11

TechnicalInstructions
DocumentNo.TS‐4500
TSSeries
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
15 21 0 0 15 21 54.5 60 60 NotReq'd 24"X24"X10"
15 21 0.5 1.1 0 0 34.6 35 60 NotReq'd 24"X24"X10"
15 21 0.5 1.1 3 4.8 39.4 40 60 NotReq'd 24"X24"X10"
15 21 0.5 1.1 5 7.6 42.2 45 60 NotReq'd 24"X24"X10"
15 21 0.5 1.1 7.5 11 45.6 45 60 NotReq'd 24"X24"X10"
15 21 0.5 1.1 10 14 48.6 50 60 NotReq'd 24"X24"X10"
15 21 0.5 1.1 15 21 55.6 60 60 NotReq'd 24"X24"X10"
15 21 0.75 1.6 0 0 35.1 35 60 NotReq'd 24"X24"X10"
15 21 0.75 1.6 3 4.8 39.9 40 60 NotReq'd 24"X24"X10"
15 21 0.75 1.6 5 7.6 42.7 45 60 NotReq'd 24"X24"X10"
15 21 0.75 1.6 7.5 11 46.1 50 60 NotReq'd 24"X24"X10"
15 21 0.75 1.6 10 14 49.1 50 60 NotReq'd 24"X24"X10"
15 21 0.75 1.6 15 21 56.1 60 60 NotReq'd 24"X24"X10"
15 21 1 2.1 0 0 35.6 35 60 NotReq'd 24"X24"X10"
15 21 1 2.1 3 4.8 40.4 40 60 NotReq'd 24"X24"X10"
15 21 1 2.1 5 7.6 43.2 45 60 NotReq'd 24"X24"X10"
15 21 1 2.1 7.5 11 46.6 50 60 NotReq'd 24"X24"X10"
15 21 1 2.1 10 14 49.6 50 60 NotReq'd 24"X24"X10"
15 21 1 2.1 15 21 56.6 60 60 NotReq'd 24"X24"X10"
15 21 1.5 3 0 0 36.5 40 60 NotReq'd 24"X24"X10"
15 21 1.5 3 3 4.8 41.3 45 60 NotReq'd 24"X24"X10"
15 21 1.5 3 5 7.6 44.1 45 60 NotReq'd 24"X24"X10"
15 21 1.5 3 7.5 11 47.5 50 60 NotReq'd 24"X24"X10"
15 21 1.5 3 10 14 50.5 50 60 NotReq'd 24"X24"X10"
15 21 1.5 3 15 21 57.5 60 60 NotReq'd 24"X24"X10"
15 21 2 3.4 0 0 36.9 40 60 NotReq'd 24"X24"X10"
15 21 2 3.4 3 4.8 41.7 45 60 NotReq'd 24"X24"X10"
15 21 2 3.4 5 7.6 44.5 45 60 NotReq'd 24"X24"X10"
15 21 2 3.4 7.5 11 47.9 50 60 NotReq'd 24"X24"X10"
15 21 2 3.4 10 14 50.9 50 60 NotReq'd 24"X24"X10"
15 21 2 3.4 15 21 57.9 60 60 NotReq'd 24"X24"X10"
15 21 3 4.8 0 0 38.3 40 60 NotReq'd 24"X24"X10"
15 21 3 4.8 3 4.8 43.1 45 60 NotReq'd 24"X24"X10"
15 21 3 4.8 5 7.6 45.9 45 60 NotReq'd 24"X24"X10"
15 21 3 4.8 7.5 11 49.3 50 60 NotReq'd 24"X24"X10"
15 21 3 4.8 10 14 52.3 60 60 NotReq'd 24"X24"X10"
15 21 3 4.8 15 21 59.3 60 60 NotReq'd 24"X24"X10"
15 21 5 7.6 0 0 41.1 45 60 NotReq'd 24"X24"X10"
15 21 5 7.6 3 4.8 45.9 45 60 NotReq'd 24"X24"X10"
15 21 5 7.6 5 7.6 48.7 50 60 NotReq'd 24"X24"X10"
Page12 SCCInc.

TSSeries TechnicalInstructions
DocumentNo.TS‐4500
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
15 21 5 7.6 7.5 11 52.1 60 60 NotReq'd 24"X24"X10"
15 21 5 7.6 10 14 55.1 60 60 NotReq'd 24"X24"X10"
15 21 5 7.6 15 21 62.1 70 100 NotReq'd 32"X32"X10"
20 27 0 0 0 0 42.5 45 60 NotReq'd 24"X24"X10"
20 27 0 0 3 4.8 47.3 50 60 NotReq'd 24"X24"X10"
20 27 0 0 5 7.6 50.1 50 60 NotReq'd 24"X24"X10"
20 27 0 0 7.5 11 53.5 60 60 NotReq'd 24"X24"X10"
20 27 0 0 10 14 56.5 60 60 NotReq'd 24"X24"X10"
20 27 0 0 15 21 63.5 70 100 NotReq'd 32"X32"X10"
20 27 0 0 20 27 69.5 70 100 NotReq'd 32"X32"X10"
20 27 0.5 1.1 0 0 43.6 45 60 NotReq'd 24"X24"X10"
20 27 0.5 1.1 3 4.8 48.4 50 60 NotReq'd 24"X24"X10"
20 27 0.5 1.1 5 7.6 51.2 50 60 NotReq'd 24"X24"X10"
20 27 0.5 1.1 7.5 11 54.6 60 60 NotReq'd 24"X24"X10"
20 27 0.5 1.1 10 14 57.6 60 60 NotReq'd 24"X24"X10"
20 27 0.5 1.1 15 21 64.6 70 100 NotReq'd 32"X32"X10"
20 27 0.5 1.1 20 27 70.6 70 100 NotReq'd 32"X32"X10"
20 27 0.75 1.6 0 0 44.1 45 60 NotReq'd 24"X24"X10"
20 27 0.75 1.6 3 4.8 48.9 50 60 NotReq'd 24"X24"X10"
20 27 0.75 1.6 5 7.6 51.7 50 60 NotReq'd 24"X24"X10"
20 27 0.75 1.6 7.5 11 55.1 60 60 NotReq'd 24"X24"X10"
20 27 0.75 1.6 10 14 58.1 60 60 NotReq'd 24"X24"X10"
20 27 0.75 1.6 15 21 65.1 70 100 NotReq'd 32"X32"X10"
20 27 0.75 1.6 20 27 71.1 70 100 NotReq'd 32"X32"X10"
20 27 1 2.1 0 0 44.6 45 60 NotReq'd 24"X24"X10"
20 27 1 2.1 3 4.8 49.4 50 60 NotReq'd 24"X24"X10"
20 27 1 2.1 5 7.6 52.2 60 60 NotReq'd 24"X24"X10"
20 27 1 2.1 7.5 11 55.6 60 60 NotReq'd 24"X24"X10"
20 27 1 2.1 10 14 58.6 60 60 NotReq'd 24"X24"X10"
20 27 1 2.1 15 21 65.6 70 100 NotReq'd 32"X32"X10"
20 27 1 2.1 20 27 71.6 70 100 NotReq'd 32"X32"X10"
20 27 1.5 3 0 0 45.5 45 60 NotReq'd 24"X24"X10"
20 27 1.5 3 3 4.8 50.3 50 60 NotReq'd 24"X24"X10"
20 27 1.5 3 5 7.6 53.1 60 60 NotReq'd 24"X24"X10"
20 27 1.5 3 7.5 11 56.5 60 60 NotReq'd 24"X24"X10"
20 27 1.5 3 10 14 59.5 60 60 NotReq'd 24"X24"X10"
20 27 1.5 3 15 21 66.5 70 100 NotReq'd 32"X32"X10"
20 27 1.5 3 20 27 72.5 80 100 NotReq'd 32"X32"X10"
20 27 2 3.4 0 0 45.9 45 60 NotReq'd 24"X24"X10"
20 27 2 3.4 3 4.8 50.7 50 60 NotReq'd 24"X24"X10"
SCCInc. Page13

TechnicalInstructions
DocumentNo.TS‐4500
TSSeries
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
20 27 2 3.4 5 7.6 53.5 60 60 NotReq'd 24"X24"X10"
20 27 2 3.4 7.5 11 56.9 60 60 NotReq'd 24"X24"X10"
20 27 2 3.4 10 14 59.9 60 60 NotReq'd 24"X24"X10"
20 27 2 3.4 15 21 66.9 70 100 NotReq'd 32"X32"X10"
20 27 2 3.4 20 27 72.9 80 100 NotReq'd 32"X32"X10"
20 27 3 4.8 0 0 47.3 50 60 NotReq'd 24"X24"X10"
20 27 3 4.8 3 4.8 52.1 60 60 NotReq'd 24"X24"X10"
20 27 3 4.8 5 7.6 54.9 60 60 NotReq'd 24"X24"X10"
20 27 3 4.8 7.5 11 58.3 60 60 NotReq'd 24"X24"X10"
20 27 3 4.8 10 14 61.3 60 60 NotReq'd 24"X24"X10"
20 27 3 4.8 15 21 68.3 70 100 NotReq'd 32"X32"X10"
20 27 3 4.8 20 27 74.3 80 100 NotReq'd 32"X32"X10"
20 27 5 7.6 0 0 50.1 50 60 NotReq'd 24"X24"X10"
20 27 5 7.6 3 4.8 54.9 60 60 NotReq'd 24"X24"X10"
20 27 5 7.6 5 7.6 57.7 60 60 NotReq'd 24"X24"X10"
20 27 5 7.6 7.5 11 61.1 60 60 NotReq'd 24"X24"X10"
20 27 5 7.6 10 14 64.1 70 100 NotReq'd 32"X32"X10"
20 27 5 7.6 15 21 71.1 70 100 NotReq'd 32"X32"X10"
20 27 5 7.6 20 27 77.1 80 100 NotReq'd 32"X32"X10"
25 34 0 0 0 0 53 60 60 NotReq'd 24"X24"X10"
25 34 0 0 3 4.8 57.8 60 60 NotReq'd 24"X24"X10"
25 34 0 0 5 7.6 60.6 60 60 NotReq'd 24"X24"X10"
25 34 0 0 7.5 11 64 70 100 60 32"X32"X10"
25 34 0 0 10 14 67 70 100 60 32"X32"X10"
25 34 0 0 15 21 74 80 100 60 32"X32"X10"
25 34 0 0 20 27 80 80 100 60 32"X32"X10"
25 34 0.5 1.1 0 0 54.1 60 60 NotReq'd 24"X24"X10"
25 34 0.5 1.1 3 4.8 58.9 60 60 NotReq'd 24"X24"X10"
25 34 0.5 1.1 5 7.6 61.7 60 60 NotReq'd 24"X24"X10"
25 34 0.5 1.1 7.5 11 65.1 70 100 60 32"X32"X10"
25 34 0.5 1.1 10 14 68.1 70 100 60 32"X32"X10"
25 34 0.5 1.1 15 21 75.1 80 100 60 32"X32"X10"
25 34 0.5 1.1 20 27 81.1 80 100 60 32"X32"X10"
25 34 0.75 1.6 0 0 54.6 60 60 NotReq'd 24"X24"X10"
25 34 0.75 1.6 3 4.8 59.4 60 60 NotReq'd 24"X24"X10"
25 34 0.75 1.6 5 7.6 62.2 70 100 60 32"X32"X10"
25 34 0.75 1.6 7.5 11 65.6 70 100 60 32"X32"X10"
25 34 0.75 1.6 10 14 68.6 70 100 60 32"X32"X10"
25 34 0.75 1.6 15 21 75.6 80 100 60 32"X32"X10"
25 34 0.75 1.6 20 27 81.6 80 100 60 32"X32"X10"
Page14 SCCInc.

TSSeries TechnicalInstructions
DocumentNo.TS‐4500
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
25 34 1 2.1 0 0 55.1 60 60 NotReq'd 24"X24"X10"
25 34 1 2.1 3 4.8 59.9 60 60 NotReq'd 24"X24"X10"
25 34 1 2.1 5 7.6 62.7 70 100 60 32"X32"X10"
25 34 1 2.1 7.5 11 66.1 70 100 60 32"X32"X10"
25 34 1 2.1 10 14 69.1 70 100 60 32"X32"X10"
25 34 1 2.1 15 21 76.1 80 100 60 32"X32"X10"
25 34 1 2.1 20 27 82.1 90 100 60 32"X32"X10"
25 34 1.5 3 0 0 56 60 60 NotReq'd 24"X24"X10"
25 34 1.5 3 3 4.8 60.8 60 60 NotReq'd 24"X24"X10"
25 34 1.5 3 5 7.6 63.6 70 100 60 32"X32"X10"
25 34 1.5 3 7.5 11 67 70 100 60 32"X32"X10"
25 34 1.5 3 10 14 70 70 100 60 32"X32"X10"
25 34 1.5 3 15 21 77 80 100 60 32"X32"X10"
25 34 1.5 3 20 27 83 90 100 60 32"X32"X10"
25 34 2 3.4 0 0 56.4 60 60 NotReq'd 24"X24"X10"
25 34 2 3.4 3 4.8 61.2 60 60 NotReq'd 24"X24"X10"
25 34 2 3.4 5 7.6 64 70 100 60 32"X32"X10"
25 34 2 3.4 7.5 11 67.4 70 100 60 32"X32"X10"
25 34 2 3.4 10 14 70.4 70 100 60 32"X32"X10"
25 34 2 3.4 15 21 77.4 80 100 60 32"X32"X10"
25 34 2 3.4 20 27 83.4 90 100 60 32"X32"X10"
25 34 3 4.8 0 0 57.8 60 60 NotReq'd 24"X24"X10"
25 34 3 4.8 3 4.8 62.6 70 100 60 32"X32"X10"
25 34 3 4.8 5 7.6 65.4 70 100 60 32"X32"X10"
25 34 3 4.8 7.5 11 68.8 70 100 60 32"X32"X10"
25 34 3 4.8 10 14 71.8 70 100 60 32"X32"X10"
25 34 3 4.8 15 21 78.8 80 100 60 32"X32"X10"
25 34 3 4.8 20 27 84.8 90 100 60 32"X32"X10"
25 34 5 7.6 0 0 60.6 60 60 NotReq'd 24"X24"X10"
25 34 5 7.6 3 4.8 65.4 70 100 60 32"X32"X10"
25 34 5 7.6 5 7.6 68.2 70 100 60 32"X32"X10"
25 34 5 7.6 7.5 11 71.6 70 100 60 32"X32"X10"
25 34 5 7.6 10 14 74.6 80 100 60 32"X32"X10"
25 34 5 7.6 15 21 81.6 80 100 60 32"X32"X10"
25 34 5 7.6 20 27 87.6 90 100 60 32"X32"X10"
30 40 0 0 0 0 62 60 60 NotReq'd 24"X24"X10"
30 40 0 0 3 4.8 66.8 70 100 NotReq'd 32"X32"X10"
30 40 0 0 5 7.6 69.6 70 100 NotReq'd 32"X32"X10"
30 40 0 0 7.5 11 73 80 100 70 32"X32"X10"
30 40 0 0 10 14 76 80 100 70 32"X32"X10"
SCCInc. Page15

TechnicalInstructions
DocumentNo.TS‐4500
TSSeries
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
30 40 0 0 15 21 83 90 100 70 32"X32"X10"
30 40 0 0 20 27 89 90 100 70 32"X32"X10"
30 40 0.5 1.1 0 0 63.1 70 100 NotReq'd 32"X32"X10"
30 40 0.5 1.1 3 4.8 67.9 70 100 NotReq'd 32"X32"X10"
30 40 0.5 1.1 5 7.6 70.7 70 100 NotReq'd 32"X32"X10"
30 40 0.5 1.1 7.5 11 74.1 80 100 70 32"X32"X10"
30 40 0.5 1.1 10 14 77.1 80 100 70 32"X32"X10"
30 40 0.5 1.1 15 21 84.1 90 100 70 32"X32"X10"
30 40 0.5 1.1 20 27 90.1 90 100 70 32"X32"X10"
30 40 0.75 1.6 0 0 63.6 70 100 NotReq'd 32"X32"X10"
30 40 0.75 1.6 3 4.8 68.4 70 100 NotReq'd 32"X32"X10"
30 40 0.75 1.6 5 7.6 71.2 70 100 NotReq'd 32"X32"X10"
30 40 0.75 1.6 7.5 11 74.6 80 100 70 32"X32"X10"
30 40 0.75 1.6 10 14 77.6 80 100 70 32"X32"X10"
30 40 0.75 1.6 15 21 84.6 90 100 70 32"X32"X10"
30 40 0.75 1.6 20 27 90.6 90 100 70 32"X32"X10"
30 40 1 2.1 0 0 64.1 70 100 NotReq'd 32"X32"X10"
30 40 1 2.1 3 4.8 68.9 70 100 NotReq'd 32"X32"X10"
30 40 1 2.1 5 7.6 71.7 70 100 NotReq'd 32"X32"X10"
30 40 1 2.1 7.5 11 75.1 80 100 70 32"X32"X10"
30 40 1 2.1 10 14 78.1 80 100 70 32"X32"X10"
30 40 1 2.1 15 21 85.1 90 100 70 32"X32"X10"
30 40 1 2.1 20 27 91.1 90 100 70 32"X32"X10"
30 40 1.5 3 0 0 65 70 100 NotReq'd 32"X32"X10"
30 40 1.5 3 3 4.8 69.8 70 100 NotReq'd 32"X32"X10"
30 40 1.5 3 5 7.6 72.6 80 100 70 32"X32"X10"
30 40 1.5 3 7.5 11 76 80 100 70 32"X32"X10"
30 40 1.5 3 10 14 79 80 100 70 32"X32"X10"
30 40 1.5 3 15 21 86 90 100 70 32"X32"X10"
30 40 1.5 3 20 27 92 90 100 70 32"X32"X10"
30 40 2 3.4 0 0 65.4 70 100 NotReq'd 32"X32"X10"
30 40 2 3.4 3 4.8 70.2 70 100 NotReq'd 32"X32"X10"
30 40 2 3.4 5 7.6 73 80 100 70 32"X32"X10"
30 40 2 3.4 7.5 11 76.4 80 100 70 32"X32"X10"
30 40 2 3.4 10 14 79.4 80 100 70 32"X32"X10"
30 40 2 3.4 15 21 86.4 90 100 70 32"X32"X10"
30 40 2 3.4 20 27 92.4 100 100 70 32"X32"X10"
30 40 3 4.8 0 0 66.8 70 100 NotReq'd 32"X32"X10"
30 40 3 4.8 3 4.8 71.6 70 100 NotReq'd 32"X32"X10"
30 40 3 4.8 5 7.6 74.4 80 100 70 32"X32"X10"
Page16 SCCInc.

TSSeries TechnicalInstructions
DocumentNo.TS‐4500
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
30 40 3 4.8 7.5 11 77.8 80 100 70 32"X32"X10"
30 40 3 4.8 10 14 80.8 80 100 70 32"X32"X10"
30 40 3 4.8 15 21 87.8 90 100 70 32"X32"X10"
30 40 3 4.8 20 27 93.8 100 100 70 32"X32"X10"
30 40 5 7.6 0 0 69.6 70 100 NotReq'd 32"X32"X10"
30 40 5 7.6 3 4.8 74.4 80 100 70 32"X32"X10"
30 40 5 7.6 5 7.6 77.2 80 100 70 32"X32"X10"
30 40 5 7.6 7.5 11 80.6 80 100 70 32"X32"X10"
30 40 5 7.6 10 14 83.6 90 100 70 32"X32"X10"
30 40 5 7.6 15 21 90.6 90 100 70 32"X32"X10"
30 40 5 7.6 20 27 96.6 100 100 70 32"X32"X10"
40 52 0 0 0 0 80 80 100 NotReq'd 32"X32"X10"
40 52 0 0 3 4.8 84.8 90 100 NotReq'd 32"X32"X10"
40 52 0 0 5 7.6 87.6 90 100 NotReq'd 32"X32"X10"
40 52 0 0 7.5 11 91 90 100 NotReq'd 32"X32"X10"
40 52 0 0 10 14 94 100 100 NotReq'd 32"X32"X10"
40 52 0 0 15 21 101 100 100 NotReq'd 32"X32"X10"
40 52 0 0 20 27 107 110 200 100 40"X32"X10"
40 52 0.5 1.1 0 0 81.1 80 100 NotReq'd 32"X32"X10"
40 52 0.5 1.1 3 4.8 85.9 90 100 NotReq'd 32"X32"X10"
40 52 0.5 1.1 5 7.6 88.7 90 100 NotReq'd 32"X32"X10"
40 52 0.5 1.1 7.5 11 92.1 100 100 NotReq'd 32"X32"X10"
40 52 0.5 1.1 10 14 95.1 100 100 NotReq'd 32"X32"X10"
40 52 0.5 1.1 15 21 102.1 110 200 100 40"X32"X10"
40 52 0.5 1.1 20 27 108.1 110 200 100 40"X32"X10"
40 52 0.75 1.6 0 0 81.6 80 100 NotReq'd 32"X32"X10"
40 52 0.75 1.6 3 4.8 86.4 90 100 NotReq'd 32"X32"X10"
40 52 0.75 1.6 5 7.6 89.2 90 100 NotReq'd 32"X32"X10"
40 52 0.75 1.6 7.5 11 92.6 100 100 NotReq'd 32"X32"X10"
40 52 0.75 1.6 10 14 95.6 100 100 NotReq'd 32"X32"X10"
40 52 0.75 1.6 15 21 102.6 110 200 100 40"X32"X10"
40 52 0.75 1.6 20 27 108.6 110 200 100 40"X32"X10"
40 52 1 2.1 0 0 82.1 90 100 NotReq'd 32"X32"X10"
40 52 1 2.1 3 4.8 86.9 90 100 NotReq'd 32"X32"X10"
40 52 1 2.1 5 7.6 89.7 90 100 NotReq'd 32"X32"X10"
40 52 1 2.1 7.5 11 93.1 100 100 NotReq'd 32"X32"X10"
40 52 1 2.1 10 14 96.1 100 100 NotReq'd 32"X32"X10"
40 52 1 2.1 15 21 103.1 110 200 100 40"X32"X10"
40 52 1 2.1 20 27 109.1 110 200 100 40"X32"X10"
40 52 1.5 3 0 0 83 90 100 NotReq'd 32"X32"X10"
SCCInc. Page17

TechnicalInstructions
DocumentNo.TS‐4500
TSSeries
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
40 52 1.5 3 3 4.8 87.8 90 100 NotReq'd 32"X32"X10"
40 52 1.5 3 5 7.6 90.6 90 100 NotReq'd 32"X32"X10"
40 52 1.5 3 7.5 11 94 100 100 NotReq'd 32"X32"X10"
40 52 1.5 3 10 14 97 100 100 NotReq'd 32"X32"X10"
40 52 1.5 3 15 21 104 110 200 100 40"X32"X10"
40 52 1.5 3 20 27 110 110 200 100 40"X32"X10"
40 52 2 3.4 0 0 83.4 90 100 NotReq'd 32"X32"X10"
40 52 2 3.4 3 4.8 88.2 90 100 NotReq'd 32"X32"X10"
40 52 2 3.4 5 7.6 91 90 100 NotReq'd 32"X32"X10"
40 52 2 3.4 7.5 11 94.4 100 100 NotReq'd 32"X32"X10"
40 52 2 3.4 10 14 97.4 100 100 NotReq'd 32"X32"X10"
40 52 2 3.4 15 21 104.4 110 200 100 40"X32"X10"
40 52 2 3.4 20 27 110.4 110 200 100 40"X32"X10"
40 52 3 4.8 0 0 84.8 90 100 NotReq'd 32"X32"X10"
40 52 3 4.8 3 4.8 89.6 90 100 NotReq'd 32"X32"X10"
40 52 3 4.8 5 7.6 92.4 100 100 NotReq'd 32"X32"X10"
40 52 3 4.8 7.5 11 95.8 100 100 NotReq'd 32"X32"X10"
40 52 3 4.8 10 14 98.8 100 100 NotReq'd 32"X32"X10"
40 52 3 4.8 15 21 105.8 110 200 100 40"X32"X10"
40 52 3 4.8 20 27 111.8 110 200 100 40"X32"X10"
40 52 5 7.6 0 0 87.6 90 100 NotReq'd 32"X32"X10"
40 52 5 7.6 3 4.8 92.4 100 100 NotReq'd 32"X32"X10"
40 52 5 7.6 5 7.6 95.2 100 100 NotReq'd 32"X32"X10"
40 52 5 7.6 7.5 11 98.6 100 100 NotReq'd 32"X32"X10"
40 52 5 7.6 10 14 101.6 100 100 NotReq'd 32"X32"X10"
40 52 5 7.6 15 21 108.6 110 200 100 40"X32"X10"
40 52 5 7.6 20 27 114.6 125 200 100 40"X32"X10"
50 65 0 0 0 0 99.5 100 100 NotReq'd 32"X32"X10"
50 65 0 0 3 4.8 104.3 110 200 NotReq'd 40"X32"X10"
50 65 0 0 5 7.6 107.1 110 200 NotReq'd 40"X32"X10"
50 65 0 0 7.5 11 110.5 110 200 NotReq'd 40"X32"X10"
50 65 0 0 10 14 113.5 125 200 NotReq'd 40"X32"X10"
50 65 0 0 15 21 120.5 125 200 NotReq'd 40"X32"X10"
50 65 0 0 20 27 126.5 125 200 NotReq'd 40"X32"X10"
50 65 0.5 1.1 0 0 100.6 100 100 NotReq'd 32"X32"X10"
50 65 0.5 1.1 3 4.8 105.4 110 200 NotReq'd 40"X32"X10"
50 65 0.5 1.1 5 7.6 108.2 110 200 NotReq'd 40"X32"X10"
50 65 0.5 1.1 7.5 11 111.6 110 200 NotReq'd 40"X32"X10"
50 65 0.5 1.1 10 14 114.6 125 200 NotReq'd 40"X32"X10"
50 65 0.5 1.1 15 21 121.6 125 200 NotReq'd 40"X32"X10"
Page18 SCCInc.

TSSeries TechnicalInstructions
DocumentNo.TS‐4500
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
50 65 0.5 1.1 20 27 127.6 125 200 NotReq'd 40"X32"X10"
50 65 0.75 1.6 0 0 101.1 100 100 NotReq'd 32"X32"X10"
50 65 0.75 1.6 3 4.8 105.9 110 200 NotReq'd 40"X32"X10"
50 65 0.75 1.6 5 7.6 108.7 110 200 NotReq'd 40"X32"X10"
50 65 0.75 1.6 7.5 11 112.1 125 200 NotReq'd 40"X32"X10"
50 65 0.75 1.6 10 14 115.1 125 200 NotReq'd 40"X32"X10"
50 65 0.75 1.6 15 21 122.1 125 200 NotReq'd 40"X32"X10"
50 65 0.75 1.6 20 27 128.1 125 200 NotReq'd 40"X32"X10"
50 65 1 2.1 0 0 101.6 100 100 NotReq'd 32"X32"X10"
50 65 1 2.1 3 4.8 106.4 110 200 NotReq'd 40"X32"X10"
50 65 1 2.1 5 7.6 109.2 110 200 NotReq'd 40"X32"X10"
50 65 1 2.1 7.5 11 112.6 125 200 NotReq'd 40"X32"X10"
50 65 1 2.1 10 14 115.6 125 200 NotReq'd 40"X32"X10"
50 65 1 2.1 15 21 122.6 125 200 NotReq'd 40"X32"X10"
50 65 1 2.1 20 27 128.6 125 200 NotReq'd 40"X32"X10"
50 65 1.5 3 0 0 102.5 110 200 NotReq'd 40"X32"X10"
50 65 1.5 3 3 4.8 107.3 110 200 NotReq'd 40"X32"X10"
50 65 1.5 3 5 7.6 110.1 110 200 NotReq'd 40"X32"X10"
50 65 1.5 3 7.5 11 113.5 125 200 NotReq'd 40"X32"X10"
50 65 1.5 3 10 14 116.5 125 200 NotReq'd 40"X32"X10"
50 65 1.5 3 15 21 123.5 125 200 NotReq'd 40"X32"X10"
50 65 1.5 3 20 27 129.5 125 200 NotReq'd 40"X32"X10"
50 65 2 3.4 0 0 102.9 110 200 NotReq'd 40"X32"X10"
50 65 2 3.4 3 4.8 107.7 110 200 NotReq'd 40"X32"X10"
50 65 2 3.4 5 7.6 110.5 110 200 NotReq'd 40"X32"X10"
50 65 2 3.4 7.5 11 113.9 125 200 NotReq'd 40"X32"X10"
50 65 2 3.4 10 14 116.9 125 200 NotReq'd 40"X32"X10"
50 65 2 3.4 15 21 123.9 125 200 NotReq'd 40"X32"X10"
50 65 2 3.4 20 27 129.9 125 200 NotReq'd 40"X32"X10"
50 65 3 4.8 0 0 104.3 110 200 NotReq'd 40"X32"X10"
50 65 3 4.8 3 4.8 109.1 110 200 NotReq'd 40"X32"X10"
50 65 3 4.8 5 7.6 111.9 110 200 NotReq'd 40"X32"X10"
50 65 3 4.8 7.5 11 115.3 125 200 NotReq'd 40"X32"X10"
50 65 3 4.8 10 14 118.3 125 200 NotReq'd 40"X32"X10"
50 65 3 4.8 15 21 125.3 125 200 NotReq'd 40"X32"X10"
50 65 3 4.8 20 27 131.3 150 200 125 40"X32"X10"
50 65 5 7.6 0 0 107.1 110 200 NotReq'd 40"X32"X10"
50 65 5 7.6 3 4.8 111.9 110 200 NotReq'd 40"X32"X10"
50 65 5 7.6 5 7.6 114.7 125 200 NotReq'd 40"X32"X10"
50 65 5 7.6 7.5 11 118.1 125 200 NotReq'd 40"X32"X10"
SCCInc. Page19

TechnicalInstructions
DocumentNo.TS‐4500
TSSeries
Blower
Motor
HP
Blower
Motor
FLA(A)
Oil
Pump
HP
OilPump
FLA(A)
Compressor
MotorHP
Compressor
MotorFLA
(A)
Total
FLA(A)
Main
Disconnect
FuseLPJ(A)
Main
Disconnect
Size(A)
Independent
Blower
motorFuse
LPJ(A)
EnclosureSize
Boiler/BurnerThreePhaseEnclosureswithBlowerMotorStarterControl
Note:Fusessizesmayvaryslightlyfromthistable.Anelectricaldiagramwillbeprovidedwitheachordershowingexact
fusesizes.
50 65 5 7.6 10 14 121.1 125 200 NotReq'd 40"X32"X10"
50 65 5 7.6 15 21 128.1 125 200 NotReq'd 40"X32"X10"
50 65 5 7.6 20 27 134.1 150 200 125 40"X32"X10"
60 77 0 0 0 0 117.5 125 200 NotReq'd 40"X32"X10"
60 77 0 0 3 4.8 122.3 125 200 NotReq'd 40"X32"X10"
60 77 0 0 5 7.6 125.1 125 200 NotReq'd 40"X32"X10"
60 77 0 0 7.5 11 128.5 125 200 NotReq'd 40"X32"X10"
60 77 0 0 10 14 131.5 150 200 NotReq'd 40"X32"X10"
60 77 0 0 15 21 138.5 150 200 NotReq'd 40"X32"X10"
60 77 0 0 20 27 144.5 150 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 0 0 118.6 125 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 3 4.8 123.4 125 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 5 7.6 126.2 125 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 7.5 11 129.6 125 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 10 14 132.6 150 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 15 21 139.6 150 200 NotReq'd 40"X32"X10"
60 77 0.5 1.1 20 27 145.6 150 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 0 0 119.1 125 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 3 4.8 123.9 125 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 5 7.6 126.7 125 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 7.5 11 130.1 150 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 10 14 133.1 150 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 15 21 140.1 150 200 NotReq'd 40"X32"X10"
60 77 0.75 1.6 20 27 146.1 150 200 NotReq'd 40"X32"X10"
60 77 1 2.1 0 0 119.6 125 200 NotReq'd 40"X32"X10"
60 77 1 2.1 3 4.8 124.4 125 200 NotReq'd 40"X32"X10"
60 77 1 2.1 5 7.6 127.2 125 200 NotReq'd 40"X32"X10"
60 77 1 2.1 7.5 11 130.6 150 200 NotReq'd 40"X32"X10"
60 77 1 2.1 10 14 133.6 150 200 NotReq'd 40"X32"X10"
60 77 1 2.1 15 21 140.6 150 200 NotReq'd 40"X32"X10"
60 77 1 2.1 20 27 146.6 150 200 NotReq'd 40"X32"X10"
60 77 1.5 3 0 0 120.5 125 200 NotReq'd 40"X32"X10"
60 77 1.5 3 3 4.8 125.3 125 200 NotReq'd 40"X32"X10"
60 77 1.5 3 5 7.6 128.1 125 200 NotReq'd 40"X32"X10"
60 77 1.5 3 7.5 11 131.5 150 200 NotReq'd 40"X32"X10"
60 77 1.5 3 10 14 134.5 150 200 NotReq'd 40"X32"X10"
60 77 1.5 3 15 21 141.5 150 200 NotReq'd 40"X32"X10"
60 77 1.5 3 20 27 147.5 150 200 NotReq'd 40"X32"X10"
60 77 2 3.4 0 0 120.9 125 200 NotReq'd 40"X32"X10"
60 77 2 3.4 3 4.8 125.7 125 200 NotReq'd 40"X32"X10"
Page20 SCCInc.
