SERVICE MANUAL
SL 13600
Design and specifications are subject to change without notice.
VIDEO CASSETTE RECORDER
ORIGINAL
MFR'S VERSION A

SERVICING NOTICES ON CHECKING
As for the places which need special attentions,
they are indicated with the labels or seals on the
cabinet, chassis and parts. Make sure to keep the
indications and notices in the operation manual.
PERFORM A SAFETY CHECK AFTER
SERVICING
4.
Confirm that the screws, parts and wiring which
were removed in order to service are put in the
original positions, or whether there are the
portions which are deteriorated around the
serviced places serviced or not. Check the
insulation between the antenna terminal or
external metal and the AC cord plug blades.
And be sure the safety of that.
2. USE THE DESIGNATED PARTS
The parts in this equipment have the specific
characters of incombustibility and withstand
voltage for safety. Therefore, the part which is
replaced should be used the part which has
the same character.
Especially as to the important parts for safety
which is indicated in the circuit diagram or the
table of parts as a mark, the designated
parts must be used.
1. KEEP THE NOTICES 3. PUT PARTS AND WIRES IN THE
ORIGINAL POSITION AFTER
ASSEMBLING OR WIRING
There are parts which use the insulation
material such as a tube or tape for safety, or
which are assembled in the condition that
these do not contact with the printed board.
The inside wiring is designed not to get closer
to the pyrogenic parts and high voltage parts.
Therefore, put these parts in the original
positions.
!
A1-1
1.
2.
3.
4.
5.
Remove the Top Cabinet and Front Cabinet.
(Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.)
Remove the screw (1) of the Deck Chassis and remove the Loading Motor.
Rotate the Pinch Roller Cam in the direction of the arrow by hand to slacken the Video Tape.
Rotate the Clutch Ass'y either of the directions to wind the Video Tape in the Cassette Case.
Repeat the above step 3~4. Then take out the Video Cassette from the Deck Chassis. Be careful not to
scratch on the tape.
TAPE REMOVAL METHOD AT NO POWER SUPPLY
Pinch Roller Cam
Main Cam Clutch Ass'y
Main Chassis (Front Side)
Loading Motor
Screw (1)
Capstan DD Unit
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER
The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
You can find it in your SERVICE MANUAL.
HOWTO ORDER PARTS

CONTENTS
A1-1
A1-1
A1-1
A2-1
A3-1~A3-4
B1-1
B2-1~B2-6
B3-1, B3-2
C1-1, C1-2
C2-1
C2-1
C3-1, C3-2
C4-1
D1-1
D1-1
D2-1~D2-4
D3-1~D3-3
E-1, E-2
E-3, E-4
E-5, E-6
E-7, E-8
F-1, F-2
F-3, F-4
G-1, G-2
G-3, G-4
G-5, G-6
G-7, G-8
G-9, G-10
G-11, G-12
G-13, G-14
G-15, G-16
H-1
I1-1
I2-1, I2-2
J1-1
J2-1
J3-1, J3-2
A2-1
SERVICING NOTICES ON CHECKING......................................................................................
HOW TO ORDER PARTS............................................................................................................
TAPE REMOVAL METHOD AT NO POWER SUPPLY ............................................................
CONTENTS...................................................................................................................................
GENERAL SPECIFICATIONS.....................................................................................................
DISASSEMBLY INSTRUCTIONS
1. REMOVAL OF MECHANICAL PARTS AND P. C. BOARDS............................................
2. REMOVAL OF VCR DECK PARTS ....................................................................................
3. REMOVAL AND INSTALLATION OF FLAT PACKAGE IC...............................................
KEY TO ABBREVIATIONS .........................................................................................................
ERROR CODE LIST.....................................................................................................................
SERVICE MODE LIST .................................................................................................................
PREVENTIVE CHECKS AND SERVICE INTERVALS ..............................................................
WHEN REPLACING EEPROM (MEMORY) IC...........................................................................
SERVICING FIXTURES AND TOOLS ........................................................................................
PREPARATION FOR SERVICING..............................................................................................
MECHANICAL ADJUSTMENTS .................................................................................................
ELECTRICAL ADJUSTMENTS...................................................................................................
BLOCK DIAGRAMS
Y/C/AUDIO/HEAD AMP............................................................................................................
SYSTEM CONTROL/SERVO/TIMER ......................................................................................
HI-FI/DEMODULATOR/21PIN/VPS/TUNER ...........................................................................
DISPLAY/OPERATION/POWER .............................................................................................
PRINTED CIRCUIT BOARDS
SYSCON/AUDIO/OPERATION................................................................................................
SYSCON/AUDIO ......................................................................................................................
SCHEMATIC DIAGRAMS
Y/C/AUDIO/HEAD AMP............................................................................................................
SYSTEM CONTROL/SERVO/TIMER ......................................................................................
POWER .....................................................................................................................................
DISPLAY ...................................................................................................................................
HI-FI/DEMODULATOR .............................................................................................................
21PIN/VPS/TUNER ..................................................................................................................
OPERATION .............................................................................................................................
INTERCONNECTION DIAGRAM ................................................................................................
WAVEFORMS...............................................................................................................................
MECHANICAL EXPLODED VIEW ..............................................................................................
CHASSIS EXPLODED VIEWS ....................................................................................................
MECHANICAL REPLACEMENT PARTS LIST ..........................................................................
CHASSIS REPLACEMENT PARTS LIST...................................................................................
ELECTRICAL REPLACEMENT PARTS LIST............................................................................

GENERAL SPECIFICATIONS
G-1 VCR System VHS Player / Recorder
System Video System PAL
Hi-Fi STEREO Yes
NTSC PB(PAL60Hz) Yes
Deck DECK OVD-7
Loading System Front
Motor 3
Heads Video Head 4Head
FM Audio Head 2Head
Audio /Control Mono/Yes
Erase(Full Track Erase) Yes
Tape Rec PAL SP/LP
Speed NTSC -
Play PAL SP/LP
NTSC SP
F
as
t F
o
rw
a
r
d
/
R
e
win
d
Tim
e
(
Appr
o
x.
)
a
t +2
5C
oFF:1'12"/REW:1'12"
with Cassette E-180
Forward/Reverse NTSC or PAL-M SP=3x,5x
Picture Search PAL or SECAM SP/LP=5x,7x / 7x, 13x
Frame Advance Yes
Slow Speed Approx. 1/5, 1/10, 1/30
G-2 Tuning Broadcasting System CCIR+Italy System BG
System Tuner and System 1Tuner
Receive CH Destination Oscar (W/ HYPER)
Tuning System F-Synth
Input Impedance VHF/UHF 75 OHM
CH Coverage E2~E4, X~Z+2, S1~S10,
E5~E12,S11~S41,E21~E69
Intermediate Picture(FP) 38.9MHz
Frequency Sound(FS) 33.4MHz
FP-FS 5.5MHz
Auto Guide Ch Area -
Auto Tuning Method ALL Band (Not C.C.I.R. CH Plan)
Preset CH 80CH
RF Converter Output Yes
Channel 23~69 ch
Level/Impedance 73 dBu / 75 Ohm
Sound Selector No
Stereo/Dual TV Sound G-ST
Tuner Sound Muting Yes
G-3 Power Power Source AC 230V, 50Hz
DC -
Power Consumption (at AC) 11 W at 230 V 50Hz
Stand by (at AC) 3 W at 230 V 50Hz
Per Year -
Protector Power Fuse Yes
Dew Sensor No
G-4 Regulation Safety CE
Radiation CE
G-5 Temperature Operation
5
o
C
- 4
0
o
C
Storage -2
0
o
C
-
60
o
C
G-6 Operating Humidity Less than 80% RH
G-7 Signal Video Signal Input Level 1 V p-p/75 ohm
Output Level 1 V p-p/75 ohm
S/N Ratio (Weighted) 53 dB
Horizontal Resolution at SP Mode 240Line
Audio Signal Input Level -3.8dBm/50Kohm
(0dB=0.775Vrms) Output Level -3.8dBm/1 Kohm
S/N Ratio at SP (Weighted) 42 dB
Harmonic Distortion at SP (1KHz)
T
y
pical 1.5%
Frequency Response at SP 100Hz ~10kHz
at LP 100Hz ~5kHz
at SLP -
Hi-Fi Audio Signal Dynamic Range : More than 75 dB
Frequency Response 20Hz ~20kHz
Wow And Flutter : Less than 0.01 %Wrms
Channel Separation : More than 60 dB
Harmonic Distortion : Less than 1.0 %
G-8 On Screen Menu Yes
Display Menu Type Character
ATS No
Timer Rec Set Yes
Auto Repeat On/Off Yes
VCR Set-Up No
Color System No
A3-1

GENERAL SPECIFICATIONS
NICAM Auto/Off No
BBE On/Off No
CH Set-Up Yes
CH Tuning Yes
Auto Tuning Yes
CH Mapping Yes
Guide CH Set No
System Set-Up Yes
Clock Set Yes (Calendar , 24H)
Language Yes
AV2 DEC/AV Yes
RF Output G/K/I No
G-CODE(or SHOWVIEW or PLUSCODE)No. Entry No
NICAM 1/2,NICAM Off,Audio Output No
Stereo,Audio Output,Bilingual Yes
Play/Stop/FF/Rew/Rec/OTR (ITR) /T-Rec/Pause/Eject/Tape In
(S
y
mbol Mark) Yes
Others CH/AV (LINE) Yes
Clock Yes
Repeat No
Tape Counter Yes
Index Yes
Tape Speed Yes
Manual Tracking (Bar Setting) Yes
Hi-Fi Yes
Zero Return Yes
VPS No
PDC No
TEST Signal Yes
G-9 OSD Language Eng / Ger / Fre / Spa / Ita
G-10 Clock,Timer Calendar 1990/1/1 ~ 2081/12/31
and Timer Timer Events 8 prog/1 month
Back-up One Touch Recording Max Time SP/LP:6 Hours
OTPB Valid Time -
Timer Back-up (at Power Off Mode) 30 min.
G-11 Display Indicator Yes
Indicator Type LED Module (Green + Red)
Clock/Counter,CH,Timer Rec, Play, REC Yes
VCR Yes
PM No
Auto Tuning Yes
RF Output CH Yes
G-12 Remote Unit RC- ED
Control Glow in Dark Remocon No
Format type NEC
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Total Keys 33 Keys
Keys Power Yes
1 Yes
2 Yes
3 Yes
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
0 / AV Yes
CH / Tracking Up Yes
CH / Tracking Down Yes
Play / Up No
Play / Up / Slow Yes
Stop/Down Yes
F.Fwd / Right Yes
Rew / Left Yes
Pause No
Pause/Still Yes
Rec/OTR Yes
Eject Yes
Counter Reset Yes
Speed Yes
Timer Rec Yes
Index Yes
TV / VCR Yes
Program Yes
Program / Video Plus+ No
A3-2

GENERAL SPECIFICATIONS
Menu Yes
Enter Yes
Cancel/CH Skip Yes
Call Yes
Zero Return Yes
Clock/Counter Yes
Audio Select Yes
Auto Tracking No
No
G-13 Features Auto Head Cleaning Yes
Auto Tracking Yes
Index Search Yes
HQ (VHS Standard High Quality) Yes
Auto Power On, Auto Play, Auto Rewind, Auto Eject Yes
Auto Repeat Yes
Auto Power Off Yes
VIDEO PLUS+(SHOWVIEW,G-CODE) No
Auto Set Up (CH Auto Set-Up/Auto Clock) No
ATS No
PDC No
VPS No
BBE Audio No
Remote Control Code 1/2 No
RGB Through No
SQPB (PAL SP Mode) No
G-14 Accessories Owner's Manual Yes
Language Italian
w/Guarantee Card No
Remote Control Unit Yes
Dew Caution Sheet No
Video Cassette Tape No
Battery Yes
UM size x pcs UM-4 x 2 pcs
OEM Brand No
Safety Tip No
Toll Free Insert Sheet No
Quick Set-Up Sheet No
Information Sheet No
75 Ohm Coaxial Cable (0.9m) Yes
type Single shield
U/V Mixer No
DC Car Cord (Center+) No
Guarantee Card Yes
Warning Sheet No
Circuit Diagram No
Antenna Change Plug No
Service Facility List No
Important Safeguard No
Dew/AHC Caution Sheet No
AC Plug Adapter No
AC Cord No
AV Cord (1.2m) No
Registration Card No
PTB Sheet No
300 ohm to 75 ohm Antenna Adapter No
G-15 Interface Switch Power Yes
Play Yes
Channel Up Yes
Channel Down Yes
F.FWD/Cue Yes
Rew/Rev Yes
Eject/Stop Yes
Rec/OTR Yes
Main Power SW No
Indicator Power No
Stand by No
TV/VCR No
T-REC No
Rec/OTR No
Terminals Front Video Input RCA x1 (YELLOW)
Audio Input RCA x 2 (WHITE/RED)
Other Terminal No
Rear Video Input No
Audio Input No
Video Output No
Audio Output RCA x 2 (WHITE/RED)
Euro Scart 2-SCART
A3-3

GENERAL SPECIFICATIONS
VHF/UHF Antenna Input/Output DIN Type
G-16 Set Size Approx. W x D x H (mm) 360 x 229 x 95
G-17 Weight Net (Approx.) 3.2 Kg
Gross (Approx.) 3.8 Kg
G-18 Carton Master Carton No
Content -
Material -
Dimensions W x D x H(mm) -
Description of Origin -
Gift Box Yes
Material Single/Brown
Dimensions W x D x H(mm) 429 x 292 x 168
Pulp Package Yes
Design As Per BUYER 's
Description of Origin No
Drop Test Natural Dropping Quelle Dropping At 2 Edges / 4 Surfaces
Height (cm) 80
Container Stuffing(40' container) 2992 Sets
G-19 Material Cabinet Front PS 94HB
PCB Non-Halogen Demand No
Eyelet Demand No
A3-4

DISASSEMBLY INSTRUCTIONS
1.REMOVAL OF MECHANICAL PARTS
AND P.C. BOARDS
1-1: TOP CABINET, FRONT CABINET AND
OPERATION PCB (Refer to Fig. 1-1)
B1-1
1-3: DECK CHASSIS (Refer to Fig. 1-3)
Fig. 1-3
Deck Chassis
Bottom Plate
(2)
(2)
(1) (2)
FE Head
NOTE
Do not remove the cable at the FE Head section.The FE
Head may be damaged if you remove the cable by force.
1.
2.
3.
4.
5.
Remove the screw (1).
Remove the FE Head.
Remove the 3 screws (2).
Disconnect the following connectors:
(CP1001, CP4001, CP4002 and CP4003).
Remove the Deck Chassis in the direction of arrow.
1-2: FLAP (Refer to Fig. 1-2)
1.
2.
Open Flap to 90° and flex in direction of arrow (A), at
the same time slide in direction of arrow (B).
Then lift in direction of arrow (C).
Fig. 1-2
(A)
(C)
(B)
Flap
Upper side
Bottom side
Remove the 4 screws (1).
Remove the Top Cabinet in the direction of arrow (A).
Disconnect the following connector: (CP651).
Unlock the 7 supports (2).
Remove the Front Cabinet in the direction of arrow (B).
Remove the 3 screws (3) and remove the Operation PCB.
1.
2.
3.
4.
5.
6.
Fig. 1-1
(2) (2)
(1)
(2)
(B)
(A)
(1)
(1)
(1)
Top Cabinet
(2)
(2)
(2)
(2)
(3)
(3)
(3)
Operation PCB
Front Cabinet
1-4: SYSCON PCB (Refer to Fig. 1-4)
1.
2.
3.
4.
Remove the 2 screws (1).
Remove the screw (2).
Remove the Syscon PCB in the direction of arrow (A).
Remove the Audio PCB in the direction of arrow (B).
Fig. 1-4
(2)
Audio PCB
Syscon PCB (1)
Bottom Plate
(1)
(B)
(A)

DISASSEMBLY INSTRUCTIONS
B2-1
2. REMOVAL OF VCR DECK PARTS
2-1: TOP BRACKET (Refer to Fig. 2-1)
Extend the 2 supports (1).
Slide the 2 supports (2) and remove the Top Bracket.
1.
2.
2-2: CASSETTE HOLDER ASS'Y (Refer to Fig. 2-2)
Move the Cassette Holder Ass'y to the front side.
Push the Locker R to remove the Cassette Side R.
Remove the Cassette Side L.
1.
2.
3.
Fig. 2-1
Main Chassis
Main Chassis
Top Bracket
Top Bracket
Main Chassis
Main Chassis
Cassette Side L
Cassette Side R Locker R
Fig. 2-2
2-3: CASSETTE SIDE L/R (Refer to Fig. 2-3-A)
Remove the Locker Spring.
Unlock the 4 supports (1) and then remove the
Cassette Side L/R.
Unlock the support (2) and then remove the Locker R.
1.
2.
3.
Link Ass'y
NOTE
1.
2.
In case of the Locker R installation, check if the one
position of Fig.2-3-B is correctly locked.
When you install the Cassette Side R, be sure to move
the Locker R after installing.
2-4: LINK UNIT (Refer to Fig. 2-4)
Set the Link Unit to the Eject position.
Unlock the support (1).
Remove the (A) side of the Link Unit first, then remove
the (B) side.
1.
2.
3.
Fig. 2-4
Fig. 2-3-A
Cassette Side L
Cassette Side R
Locker R
Cassette Holder
Locker Spring
Fig. 2-3-B
Check if this
position is locked.
(A)
Link Unit
Main Chassis
Link Unit
(B)
Main Chassis
Cassette Side R
Locker R
(1)
NOTE
1. After the installation of the Top Bracket, bend the
support (1) so that the Top Bracket is fixed.
(1)
(2)
(2)
(2)
(1)
(1)
(1)
(1)
(1)
2-5: LINK LEVER/FLAP LEVER/BOT COVER
(Refer to Fig. 2-5)
Fig. 2-5
Unlock the support (1).
Remove the BOT Cover.
Extend the support (2).
Remove the Link Lever.
Remove the Flap Lever.
1.
2.
3.
4.
5.
LinkLever
FlapLever
(2)
(1) BOT Cover

DISASSEMBLY INSTRUCTIONS
B2-2
2-6: LOADING MOTOR/WORM (Refer to Fig. 2-6-A)
Remove the screw (1).
Remove the Loading Motor.
Remove the Worm.
1.
2.
3.
Fig. 2-6-A
• Screw Torque: 3 ± 0.5kgf•cm
Loading Motor
(1)
Main Chassis
Worm
2-7: TENSION ASS'Y (Refer to Fig. 2-7-B)
Turn the Pinch Roller Cam clockwise so that the
Tension Holder hook is set to the position of Fig. 2-7-A
to move the Tension Arm Ass'y.
Remove the Tension Spring.
Unlock the 2 supports (1) and remove the Tension
Band.
Unlock the support (2) and remove the Tension Arm
Ass'y.
Unlock the support (3) and remove the Tension
Connect.
Float the hook (4) and turn it clockwise then remove
the Tension Holder.
1.
2.
3.
4.
5.
6.
NOTE
1.
2.
3.
In case of the Worm installation, check if the value of
the Fig. 2-6-B is correct.
In case of the Loading Motor installation, hook the wire
on the Cassette Opener as shown Fig. 2-6-C.
When installing the wires between Capstan DD Unit
and Loading Motor, connect them correctly as shown
Fig. 2-6-D.
Loading Motor Capstan DD Unit
-
+
L2
L1
Pink
Fig. 2-6-D
White
Fig. 2-7-A
Tension Arm Ass'y
Fig. 2-7-B
Fig. 2-7-D
Tension Band
Tension Spring
(1)
(2)
(4)
Tension Band
Tension Arm Ass'y
(3)
(1)
Tension Holder
Tension Connect
NOTE
1.
2.
3.
In case of the Tension Band installation, note the
direction of the installation. (Refer to Fig. 2-7-C)
In case of the Tension Band installation, install
correctly as Fig. 2-7-D.
In case of the Tension Connect installation, install as
the circled section of Fig. 2-7-E.
Tension Band
Tension Connect
Tension Connect
[OK]
[NG]
Fig. 2-7-E
Tension Connect
Main Chassis
Fig. 2-7-C
Tension Band
Tension Connect
Fig. 2-6-B
19.2 ± 0.1mm
Safety surface for
pressing of the insert.
Fig. 2-6-C
Loading Motor
Cassette Opener

DISASSEMBLY INSTRUCTIONS
B2-3
Fig. 2-8-B
T Brake Band
NOTE
1. In case of the T Brake Band installation, install correctly
as Fig. 2-8-B.
T Brake Arm
[OK]
[NG] T Brake Band
T Brake Arm
2-9: S REEL/T REEL/IDLER ARM ASS'Y/IDLER GEAR
(Refer to Fig. 2-9-A)
Remove the S Reel and T Reel.
Remove the 2 Polyslider Washers (1).
Remove the Idler Arm Ass'y and Idler Gear.
1.
2.
3.
NOTE
Take care not to damage the gears of the S Reel and T
Reel.
The Polyslider Washer may be remained on the back of
the reel.
Take care not to damage the shaft.
Do not touch the section "A" of S Reel and T Reel. (Use
gloves.) (Refer to Fig. 2-9-A) Do not adhere the stains
on it.
When you install the reel, clean the shaft and grease it
(FG-84M). (If you do not grease, noise may be heard in
FF/REW mode.)
After installing the reel, adjust the height of the reel.
(Refer to MECHANICAL ADJUSTMENT)
1.
2.
3.
4.
5.
6.
Fig. 2-9-A
NOTE
1.
2.
In case of the S Reel and T Reel installation, check if the
correct parts are installed. (Refer to Fig. 2-9-B)
In case of the Idler Arm Ass'y installation, install correctly
as Fig. 2-9-C, And also set it so that the section "B" of
Fig. 2-9-A is placed under the Main Chassis tab.
2-8: T BRAKE ARM/T BRAKE BAND (Refer to Fig. 2-8-A)
Remove the T Brake Spring.
Turn the T Brake Arm clockwise and bend the hook
section to remove it.
Unlock the 2 supports (1) and remove the T Brake
Band.
1.
2.
3.
T Brake Band
Hook section
T Brake Spring
T Brake Arm
Fig. 2-8-A
(1)
(1)
S Reel
(A) T Reel
(A)
Idler Arm Ass'y
Idler Gear
(1)
(1)
Fig. 2-9-B
Big Hole
(S Reel) Small Hole (T Reel)
Fig. 2-9-C
Idler Arm Ass'y
[OK]
[NG]
Clutch Gear
Idler Arm Ass'y
Clutch Gear
(B)

DISASSEMBLY INSTRUCTIONS
B2-4
2-10: CASSETTE OPENER/PINCH ROLLER BLOCK/
P5 ARM ASS'Y (Refer to Fig. 2-10-A)
Unlock the support (1) and remove the Cassette
Opener.
Remove the Pinch Roller Block and P5 Arm Ass'y.
1.
2.
Fig. 2-10-A
Cassette Opener
P5 Arm Ass'y
Pinch Roller Block
Main Chassis
(1)
NOTE
Do not touch the Pinch Roller. (Use gloves.)
In case of the Pinch Roller Block and the Pinch Roller
Cam installation, install correctly as Fig. 2-10-B.
1.
2.
Fig. 2-10-B
Can be seen the hole of the
Main Cam.
Can be seen the hole of
the Pinch Roller Cam.
P5 Arm Ass'y
Pinch Roller Block
2-11: A/C HEAD (Refer to Fig. 2-11-A)
Remove the screw (1).
Remove the A/C Head Base.
Remove the 3 screws (2).
Remove the A/C Head and A/C Head Spring.
1.
2.
3.
4.
NOTE
Do not touch the A/C Head. (Use gloves.)
When you install the A/C Head Spring, install as shown
in Fig. 2-11-B.
When you install the A/C Head, tighten the screw (1) first,
then tighten the screw (2), finally tighten the screw (3).
1.
2.
3.
A/C Head
A/C Head Spring
(3)
(1)
(2)
A/C Head Base
Fig. 2-11-A
(2)
(1)
(2)
(2)
• Screw Torque: 5 ± 0.5kgf•cm
Spring Position Fig. 2-11-B
2-12: FE HEAD (RECORDER ONLY) (Refer to Fig. 2-12)
Remove the screw (1).
Remove the FE Head.
FE Head
• Screw Torque: 5 ± 0.5kgf•cm
• The FE Head is not installed on the Video Cassette Player. Fig. 2-12
(1)
1.
2.
2-13: AHC ASS'Y/CYLINDER UNIT ASS'Y
(Refer to Fig. 2-13)
Fig. 2-13
When you install the Cylinder Unit Ass'y, tighten the
screws from (1) to (3) in order while pulling the Ass'y
toward the left front direction.
NOTE
1.
• Screw Torque: 3 ± 0.5kgf•cm
Unlock the support (1) and remove the AHC Ass'y.
Disconnect the following connector: (CD2001)
Remove the 3 screws (2).
Remove the Cylinder Unit Ass'y.
1.
2.
3.
4.
Cylinder Unit Ass'y
(1)
(3)
(2)
(2) (2) (2)
(1)
AHC Ass'y

DISASSEMBLY INSTRUCTIONS
B2-5
Fig. 2-15-A
NOTE
In case of the Pinch Roller Cam and Main Cam
installation, install them as the circled section of Fig. 2-
15-B so that the each markers are met. (Refer to Fig.
2-15-B)
2-15:
Remove the E-Ring (1), then remove the Main Cam.
Remove the E-Ring (2), then remove the Pinch Roller
Cam and Joint Gear.
1.
2.
MAIN CAM/PINCH ROLLER CAM/JOINT GEAR
(Refer to Fig. 2-15-A)
Main Cam
Pinch Roller Cam
Joint Gear
1.
Pinch Roller Cam
Main Cam
Marker
2-16: LOADING GEAR S/T UNIT (Refer to Fig. 2-16-A)
1.
2.
Remove the E-Ring (1) and remove the Main Loading
Gear.
Remove the Main Rod, Tension Lever, Loading Arm S
Unit and Loading Arm T Unit.
Main Rod Main Loading Gear
Loading Arm T Unit
Loading Arm S Unit
Fig. 2-16-A
(1)
(1)
(2)
2-14: CAPSTAN DD UNIT (Refer to Fig. 2-14-A)
Remove the Capstan Belt.
Remove the 3 screws (1).
Remove the Capstan DD Unit.
1.
2.
3.
Fig. 2-14-A
• Screw Torque: 4 ± 0.5kgf•cm
Capstan DD Unit
Capstan Belt
(1)
(1)
(1)
In case of the Capstan DD Unit installation, apply the
silicon bond (TSE3843-W) on the position Fig. 2-14-B
correctly. (If no silicon bond applied, abnormal nosie
will be heard on the deck operation.)
(Refer to Fig. 2-14-B, C)
NOTE
1.
Fig. 2-15-B
Fig. 2-14-B
Fig. 2-14-C
Tension Lever
Main Chassis
Silicon Bond
Capstan DD Unit
Applied position of
silicon bond
Be careful not to apply the silicon
bond to the Pinch Roller.

DISASSEMBLY INSTRUCTIONS
B2-6
2-18:
Remove the P4 Cap.
Unlock the support (1) and remove the Cassette Guide
Post.
Remove the Inclined Base S/T Unit.
Remove the screw (2)
Remove the LED Reflector.
1.
2.
3.
4.
5.
Fig. 2-18-A
CASSETTE GUIDE POST/INCLINED BASE S/T
UNIT/P4 CAP/LED REFLECTOR
(Refer to Fig. 2-18-A)
NOTE
Do not touch the roller of Guide Roller.
In case of the P4 Cap installation, install it with parallel
for "A" and "B" of Fig. 2-18-B.
In case of the Cassette Guide Post installation, install
correctly as the circled section of Fig. 2-18-C.
1.
2.
3.
"A"
[OK]
[NG]
"B"
P4 Cap
Cassette Opener
Fig. 2-18-B
Fig. 2-18-C
Cassette Guide Post
Cassette Guide Post
2-17:
Remove the Polyslider Washer (1).
Remove the Clutch Ass'y and Ring Spring.
Remove the Clutch Lever.
Remove the Coupling Gear, Coupling Spring and
Clutch Gear.
1.
2.
3.
4.
Fig. 2-17-A
NOTE
1. When you install the Loading Arm S Unit, Loading Arm
T Unit and Main Loading Gear, align each marker.
(Refer to Fig. 2-16-B)
Fig. 2-16-B
Loading Arm T Unit
Main Loading Gear
Marker
Marker
Loading Arm S Unit
CLUTCH ASS'Y/RING SPRING/CLUTCH LEVER/
CLUTCH GEAR (Refer to Fig. 2-17-A)
NOTE
In case of the Clutch Ass'y installation, install it with
inserting the spring of the Clutch Ass'y into the dent of
the Coupling Gear. (Refer to Fig. 2-17-B)
1.
Clutch Ass'y
Fig. 2-17-B
Coupling Gear
Clutch Ass'y
Coupling Gear Clutch Lever
Ring Spring
Coupling Spring
Clutch Gear
(1)
•Screw Torque: 5 ± 0.5kgf•cm
P4 Cap
Cassette Guide Post
Inclined Base T
Unit
Inclined Base S
Unit
(1)
LEDReflector
(2)

Masking Tape
(Cotton Tape)
DISASSEMBLY INSTRUCTIONS
3.
REMOVAL
IC
Put the Masking Tape (cotton tape) around the Flat
Package IC to protect other parts from any damage.
(Refer to Fig. 3-1.)
1.
Fig. 3-1
NOTE
REMOVAL AND INSTALLATION OF
FLAT PACKAGE IC
Some ICs on the PCB are affixed with glue, so be
careful not to break or damage the foil of each IC
leads or solder lands under the IC when removing it.
NOTE
Masking is carried out on all the parts located within
10 mm distance from IC leads.
Blower type IC
desoldering machine
IC
Heat the IC leads using a blower type IC desoldering
machine. (Refer to Fig. 3-2.)
2.
Fig. 3-2
NOTE
Do not add the rotating and the back and forth
directions force on the IC, until IC can move back and
forth easily after desoldering the IC leads completely.
When IC starts moving back and forth easily after
desoldering completely, pickup the corner of the IC using
a tweezers and remove the IC by moving with the IC
desoldering machine. (Refer to Fig. 3-3.)
3.
Blower type IC
desoldering
machine
IC Fig. 3-3
Tweezers
Peel off the Masking Tape.4. Absorb the solder left on the pattern using the Braided
Shield Wire. (Refer to Fig. 3-4.)
5.
NOTE
Do not move the Braided Shield Wire in the vertical
direction towards the IC pattern.
Braided Shield Wire
Soldering Iron
Fig. 3-4
IC pattern
B3-1

DISASSEMBLY INSTRUCTIONS
Supply soldering
from upper position
to lower position
IC
Supply the solder from the upper position of IC leads
sliding to the lower position of the IC leads.
(Refer to Fig. 3-6.)
2.
Fig. 3-6
Soldering IronSolder
IC
Absorb the solder left on the lead using the Braided
Shield Wire. (Refer to Fig. 3-7.)
3.
Fig. 3-7
Soldering Iron
Braided Shield Wire
NOTE
Do not absorb the solder to excess.
IC
When bridge-soldering between terminals and/or the
soldering amount are not enough, resolder using a Thin-
tip Soldering Iron. (Refer to Fig. 3-8.)
4.
Fig. 3-8
Thin-tip Soldering Iron
NOTE
When the IC leads are bent during soldering and/or
repairing, do not repair the bending of leads. If the
bending of leads are repaired, the pattern may be
damaged. So, be always sure to replace the IC in this
case.
Finally, confirm the soldering status on four sides of the
IC using a magnifying glass.
Confirm that no abnormality is found on the soldering
position and installation position of the parts around the
IC. If some abnormality is found, correct by resoldering.
5.
Solder temporarily
Soldering Iron
INSTALLATION
Take care of the polarity of new IC and then install the
new IC fitting on the printed circuit pattern. Then solder
each lead on the diagonal positions of IC temporarily.
(Refer to Fig. 3-5.)
1.
Fig. 3-5
Solder temporarily
B3-2

KEY TO ABBREVIATIONS
A
B
C
D
E
F
G
H
A/C
ACC
AE
AFC
AFT
AFT DET
AGC
AMP
ANT
A.PB
APC
ASS'Y
AT
AUTO
A/V
BGP
BOT
BPF
BRAKE SOL
BUFF
B/W
C
CASE
CAP
CARR
CH
CLK
CLOCK (SY-SE)
COMB
CONV
CPM
CTL
CYL
CYL-M
CYL SENS
DATA (SY-CE)
dB
DC
DD Unit
DEMOD
DET
DEV
E
EF
EMPH
ENC
ENV
EOT
EQ
EXT
F
FBC
FE
FF
FG
FL SW
FM
FSC
FWD
GEN
GND
H.P.F
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Audio/Control
Automatic Color Control
Audio Erase
Automatic Frequency Control
Automatic Fine Tuning
Automatic Fine Tuning Detect
Automatic Gain Control
Amplifier
Antenna
Audio Playback
Automatic Phase Control
Assembly
All Time
Automatic
Audio/Video
Burst Gate Pulse
Beginning of Tape
Bandpass Filter
Brake Solenoid
Buffer
Black and White
Capacitance, Collector
Cassette
Capstan
Carrier
Channel
Clock
Clock (Syscon to Servo)
Combination, Comb Filter
Converter
Capstan Motor
Control
Cylinder
Cylinder-Motor
Cylinder-Sensor
Data (Syscon to Servo)
Decibel
Direct Current
Direct Drive Motor Unit
Demodulator
Detector
Deviation
Emitter
Emitter Follower
Emphasis
Encoder
Envelope
End of Tape
Equalizer
External
Fuse
Feed Back Clamp
Full Erase
Fast Forward, Flipflop
Frequency Generator
Front Loading Switch
Frequency Modulation
Frequency Sub Carrier
Forward
Generator
Ground
High Pass Filter
I
K
L
M
N
O
P
R
S
H.SW
Hz
IC
IF
IND
INV
KIL
L
LED
LIMIT AMP
LM, LDM
LP
L.P.F
LUMI.
M
MAX
MINI
MIX
MM
MOD
MPX
MS SW
NC
NR
OSC
OPE
PB
PB CTL
PB-C
PB-Y
PCB
P. CON
PD
PG
P-P
R
REC
REC-C
REC-Y
REEL BRK
REEL S
REF
REG
REW
REV, RVS
RF
RMC
RY
S. CLK
S. COM
S. DATA
SEG
SEL
SENS
SER
SI
SIF
SO
SOL
SP
STB
SW
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Head Switch
Hertz
Integrated Circuit
Intermediate Frequency
Indicator
Inverter
Killer
Left
Light Emitting Diode
Limiter Amplifier
Loading Motor
Long Play
Low Pass Filter
Luminance
Motor
Maximum
Minimum
Mixer, mixing
Monostable Multivibrator
Modulator, Modulation
Multiplexer, Multiplex
Mecha State Switch
Non Connection
Noise Reduction
Oscillator
Operation
Playback
Playback Control
Playback-Chrominance
Playback-Luminance
Printed Circuit Board
Power Control
Phase Detector
Pulse Generator
Peak-to Peak
Right
Recording
Recording-Chrominance
Recording-Luminance
Reel Brake
Reel Sensor
Reference
Regulated, Regulator
Rewind
Reverse
Radio Frequency
Remote Control
Relay
Serial Clock
Sensor Common
Serial Data
Segment
Select, Selector
Sensor
Search Mode
Serial Input
Sound Intermediate Frequency
Serial Output
Solenoid
Standard Play
Serial Strobe
Switch
C1-1

KEY TO ABBREVIATIONS
S
T
U
V
X
Y
SYNC
SYNC SEP
TR
TRAC
TRICK PB
TP
UNREG
V
VCO
VIF
VP
V.PB
VR
V.REC
VSF
VSR
VSS
V-SYNC
VT
X'TAL
Y/C
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Synchronization
Sync Separator, Separation
Transistor
Tracking
Trick Playback
Test Point
Unregulated
Volt
Voltage Controlled Oscillator
Video Intermediate Frequency
Vertical Pulse, Voltage Display
Video Playback
Variable Resistor
Video Recording
Visual Search Fast Forward
Visual Search Rewind
Voltage Super Source
Vertical-Synchronization
Voltage Tuning
Crystal
Luminance/Chrominance
C1-2

C2-1
SERVICE MODE LIST
This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily.
Method Operations
Press both PLAY button and
CH UP button on the set for
more than 2 seconds.
Initialization of the factory.
NOTE: Do not use this for the normal servicing.
If you set a factory initialization, the memories are reset such as the clock
setting, the channel setting, the POWER ON total hours, and PLAY/REC
total hours.
PLAY/REC total hours are displayed on the TV Monitor.
Refer to the "PREVENTIVE CHECKS AND SERVICE INTERVALS"
(CONFIRMATION OF HOURS USED).
Can be checked of the INITIAL DATA of MEMORY IC.
Refer to the "WHEN REPLACING EEPROM (MEMORY) IC".
Adjusting of the Tracking to the center position.
Refer to the "MECHANICAL ADJUSTMENT" (GUIDE ROLLER) and "ELECTRICAL
ADJUSTMENT" (PG SHIFTER).
Press the ATR button on the
remote control for more than
2 seconds during PLAY.
While pressing the CH UP
button on the set, press the
STOP button on the set for
more than 2 seconds during
PLAY.
While pressing the CH UP
key on the set, press the
FF key on the set for more
than 2 seconds.
Adjust the PG SHIFTER automatically.
Refer to the "ELECTRICAL ADJUSTMENT" (PG SHIFTER).
Make the short circuit between
the test point of SERVICE and
the GND.
The BOT, EOT, and the Reel Sensor do not work and the deck can be operated
without a cassette tape.
Refer to the "PREPARATION FOR SERVICING"
ERROR CODE LIST
If the error indications are appeared on the FIP, check the abnormal points by using the table below.
Indications Error contents
Error : 00 Remocon code error
Error : 01 Reel mecha error
Error : 02 Cylinder mecha error
Error : 03 Mecha state error
Error : 04 Capstan mecha error

C3-1
PREVENTIVE CHECKS AND SERVICE INTERVALS
The following standard table depends on environmental conditions and usage. Unless maintenance is properly
carried out, the following service intervals may be quite shortened as harmful effects may be had on other parts.
Also, long term storage or misuse may cause transformation and aging of rubber parts.
CONFIRMATION OF HOURS USED
PLAY/REC total hours can be checked on the display.
Total hours are displayed in 16 system of notation.
1.
2.
3.
4.
5.
Turn on the POWER.
While pressing the CH UP button on the set, press the FF button on the set for more than 2 seconds.
Adjust the ADDRESS to "FD" by FF or REW button and read the DATA.
(This DATA becomes the thousands digit and hundreds digit value of the following formula.)
Adjust the ADDRESS to "FE" by FF or REW button and read the DATA.
(This DATA becomes the tens digit and ones digit value of the following formula.)
After the confirmation of using hours, turn off the power.
(16 x 16 x 16 x thousands digit value) + (16 x 16 x hundreds digit value) + (16 x tens digit value) + (ones digit value)
Parts Name
Audio Control Head
Notes
Time 500
hours 1,000 hours 1,500 hours 2,000 hours 2,500 hours
Full Erase Head
(Recorder only)
Capstan Belt
Pinch Roller
Capstan DD Unit
Loading Motor
Tension Band
Clean those parts in
contact with the tape.
Clean the rubber, and parts
which the rubber touches.
: Clean
: Check it and if necessary, replace it.
TBrake Band
Capstan Shaft
Tape Running
Guide Post
Cylinder Unit
Replace when rolling
becomes abnormal.
Clean the Head
Clutch Ass'y
Idler Arm Ass'y
ADDRESS DATA
