20V SV20 SERIES CORDLESS STRIMMER -
BODY ONLY
MODEL NO: CS20V
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Always wear appropriate eye protection, ear protection, substantial footwear, gloves, long trousers
whilst operating.
9Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long
hair.
9Inspect and ensure equipment is in good working order before use.
9Maintain and clean tool and battery pack, regularly. Check air holes are clear.
9Must be serviced by an authorised agent. Use genuine parts only. Non authorised parts will
invalidate the warranty.
WARNING! Remove battery before: performing maintenance, carrying out adjustments,
inspecting the machine after striking an object, before clearing a blockage, before leaving the tool
unattended, before moving to the next job location.
9WARNING! Risk assess the work area. Keep bystanders away from the work area.
8DO NOT operate with anyone or pets nearby. Check intended work area for wildlife.
8DO NOT use in bad weather conditions, especially when there is a risk of lightning. DO NOT
expose to rain. Only use in good light.
8DO NOT use if tool vibrates abnormally, switch off, remove battery and then inspect.
8DO NOT touch hazardous moving parts. Allow to come to a complete stop first.
8DO NOT operate whilst tired, ill under the inuence of alcohol or other intoxicating drugs.
8DO NOT overreach and keep balance at all times.
8DO NOT use if damaged. DO NOT operate with defective guards or shields or without safety device.
8DO NOT use for a task it was not designed to perform.
9Store with the battery removed and separate from the machine, in a dry, childproof location.
WARNING! Never allow children, persons with reduced physical sensory or mental capabilities or lack of experience and knowledge or
people unfamiliar with these instructions to use the machine, local regulations may restrict the age of the operator.
1.1. HAND ARM VIBRATION
WARNING! – RISK OF HAND ARM VIBRATION INJURY
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): 5.8/s²
Uncertainty value (k): 2.3m/s²
Please note that the application of the tool to a sole specialist task may produce a di󰀨erent average vibration emission. We recommend
that a specic evaluation of the vibration emission is conducted prior to commencing with a specialist task. A health and safety
assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is su󰀩cient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm
Vibration Syndrome.
1.2. HEALTH SURVEILLANCE
We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management procedures can
be modied accordingly.
1.3. PERSONAL PROTECTIVE EQUIPMENT
We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury that may result from the
Uncontrolled use of this tool. We recommend a su󰀩cient supply of clothing (including gloves) to enable the operator to remain warm
and dry and maintain good blood circulation in ngers etc. Please note that the most e󰀨ective protection is prevention, please refer
to the correct use and maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be
found on the HSE website www.hse.gov.uk - Hand-Arm Vibration at Work.
Refer to
instructions Wear eye protection Wear protective gloves Wear ear protection
Wear safety
footwear Wear protective clothing Keep in dry area protect from rain
Original Language Version
© Jack Sealey Limited CS20V Issue 3 (H,1,3,F) 04/10/23

2. INTRODUCTION
Lightweight cordless strimmer makes gardening easy, clean and e󰀨ective. Fully adjustable in height and cutting angles. Head can be
adjusted vertically between 0°-50° (four settings available). Head can also be rotated between 0°-90° both ways for applications such
as lawn edge cutting. Works in conjunction with our one-battery-ts-all program. Body only. (Includes 10 x plastic blades). Requires
compatible 20V battery and mains charger, sold separately.
3. SPECIFICATION
Model No:............................................................CS20V
Battery: ...........20V 2Ah - 6Ah Lithium-ion (not included)
Cutting Mechanism: ................................... Plastic Blade
Cutting Width: .....................................................260mm
No-Load Speed:................................................8000rpm
Voltage:.................................................. 20V Lithium-ion
Vibration Value:...................................................5.8m/s2
Uncertainty:.........................................................2.3m/s2
Noise Power:................................................88dB(A) LWA
Noise Pressure: ........................................... 78 dB(A)LPA
4. ASSEMBLY
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
FIG.1 FIG.2 FIG.3 FIG.4
4.1. FIT SAFETY HOOD
4.1.1. Push the guard hood in the direction of the arrow onto the motor housing as shown in (g.1).
4.1.2. Make sure it latches in place correctly.
4.2. FIT EDGE GUIDE
4.2.1. Fit both ends of the edge guide into the lashing eye as shown in (g.2).
4.3. ADJUSTING ADDITIONAL HANDLE
4.3.1. Undo the securing screw on the additional handle to adjust angle (g.3).
4.3.2. Set the required position and tighten the securing screw (g.3).
4.4. ADJUSTING THE HEIGHT
4.4.1. Undo the union nut until the grass trimmer handle can be moved in and out freely. Now set the required working height (g.4) and
secure the handle in this position by tightening the union nut again.
5. OPERATION
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
FIG.5
1
Original operating instructions
Instruction Manual
Cordless Grass trimmer
N1F-260E/18
Suzhou Jinshan Power Tools Co., Ltd.
Building 4, No.2 Tianedang Road Wuzhong District
Suzhou, CHINA
SAFETY
LOCK
ON/OFF
SWITCH
FIG.6 FIG.7
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
FIG.8
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
3
Fig. 2 Fig. 3 Fig. 4
Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9 Fig. 10
Fig. 11 Fig. 12 Fig. 13
12
1
Original operating instructions
Instruction Manual
Cordless Grass trimmer
N1F-260E/18
Suzhou Jinshan Power Tools Co., Ltd.
Building 4, No.2 Tianedang Road Wuzhong District
Suzhou, CHINA
FIG.9 FIG.10 FIG.11 FIG.12
Consumable Parts:.................. CP20VBP2 - 2Ah Battery
................................................ CP20VBP4 - 4Ah Battery
................................................ CP20VBP6 - 6Ah Battery
Replacement Parts:.........................................................
...................... CP20VMC - Mains Charger (not included)
Original Language Version
© Jack Sealey Limited CS20V Issue 3 (H,1,3,F) 04/10/23

WARNING! Only use this machine for its intended use.
8DO NOT use the grass trimmer without the guard.
8DO NOT cut grass when it is wet. The best results are achieved with dry grass.
9Always wear appropriate eye protection, ear protection, substantial footwear, gloves, long trousers whilst operating.
5.1. Push the battery pack into the mount provided (fig.5).
5.2. To remove the battery pack, press the battery pack button and pull the battery out.
5.3. ADJUSTING THE ANGLE OF TILT OF THE GUIDE HANDLE
5.3.1. Press the button for the angle of tilt adjustment (fig.9). Now set the long handle to the required tilt. Release the button and allow the
handle to lock into position to fix the angle of tilt. Four different locking angles are possible.
5.4. To switch on your grass trimmer press the safety lock-off (fig.6) and then press the On/Off switch (fig.6).
5.5. To switch off your grass trimmer, let go of the On/Off switch.
WARNING! The blade will continue to spin for a few seconds after the ON/OFF switch is released.
8DO NOT allow the grass trimmer near the grass until the switch is pressed and the grass trimmer is in operation.
5.6. To cut properly, swing the machine sideways while moving forwards. Keep the grass trimmer inclined at an angle of approx. 30° while you
do so (fig.7 & 8).
5.6.1. If the grass is long, the grass must be cut shorter in stages, starting from the tip (fig.10 & 11).
5.6.2. Use the guard hood to prevent unnecessary wear.
5.6.3. To avoid unnecessary wear, keep the grass trimmer away from hard objects.
5.7. USING THE GRASS TRIMMER AS AN EDGE TRIMMER
5.8. To cut the edges of lawns and flower beds, the grass trimmer can be converted as follows:
IMPORTANT: Remove the battery pack.
5.8.1. Push and turn the motor head through 90° in the required direction until it latches in place (fig.12).
5.8.2. Now the grass trimmer has been converted to an edge trimmer that cuts vertically.
6. MAINTENANCE
WARNING! Before cleaning or performing any maintenance, pull out the battery pack.
6.1. CLEANING
6.1.1. Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it down with compressed air at low pressure.
6.1.2. Always clean the equipment immediately after use.
6.1.3. Clean the equipment regularly with a damp cloth and some mild soap. DO NOT use cleaning
agents or solvents, these may be aggressive to the plastic parts in the equipment. Ensure that no
water can get into the interior of the equipment. The ingress of water into an electric tool increases
the risk of an electric shock.
6.1.4. Use a brush to remove deposits from the safety guard.
6.2. REPLACING THE BLADE
WARNING! Be sure to remove the battery pack before replacing.
6.2.1. To remove the blade, push the blade inwards and remove it through the larger opening as shown
(g.13).
6.2.2. To t the new blade, proceed in reverse order. Make sure the blade locks into place correctly
(g.14).
6.3. STORAGE
6.3.1. Remove battery. Store carefully in a secure, dry place, out of the reach of children.
4
Fig. 14 Fig. 15
Fig. 16
Warning! Read these instructions carefully, be familiar with the controls and the proper
use of the trimmer. Please keep the instructions safe for later use.
Explanation of symbols on the trimmer (Fig.16)
General hazard safety alert.
Read instruction manual.
Wear eye protection.
FIG.14
Original Language Version
© Jack Sealey Limited CS20V Issue 3 (H,1,3,F) 04/10/23
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations. REGISTER YOUR
