Seanix 42PSEA06 User manual

Page 0 of 83

Page 1 of 83
THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY REASONABLE
EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT
GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF PUBLICATION AND
DISCLAIMS RELIABILITY FOR CHANGES, ERRORS OR OMISSIONS.
Date：2006/06/20

Page 2 of 83
CONTENTS
1、SPECIFICATION
1-1 General Specification …................................................….....……........................………....…. 4
1-2 Feature Summary ........................... ...................... .............................……………...………….. 5
1-3 External Interface .......................... ...................... ...............................................................…. 6
1-4 User Interface …......................... ..................................….....……........................………....…. 12
1-5 External Mounting Requirements .......................................................……………...………….. 13
1-6 Environmental Requirements .............................. ...............................................................…. 13
2、Precautions and Notices
2-1 Precaution of assembly. ....................................................................................................... 13
2-2 Precaution of Operation....................................................................................................... 13
3、Operation
3-1 Operation of Remote Control Transmitter ...........................................................................… 14
3-2 Front panel controls .....................................................................................................……… 15
3-3 OSD MENU Description ..................................................................................................……. 16
4、Trouble Shooting Chart
4-1 PANEL Trouble shooting………………….........................................................................…… 20
4-2 Turn PDP on and Check .... .................... .................................................................................. 20
5、White-Balance Adjustment
5-1 Equipments list and prepare………………………………………………………………………… 25
5-2 Preparation and Adjustment process……………………………………………………………… 25
6、DDC program and test
6-1 The list of Instrument ………………………………………………………….. …………………… 27
6-2 Program and test process ……………………………………………...………..………………….. 27
7、Flash Update
7-1 The list of Instrument……………………………...………………………………………………….. 28
7-2 The Operation explaining Flash Update ……………..………...………………………………….. 28
8、Software Platform Reference TV application
8-1 Introduction …………………………………………………………………………………………... 31
8-2 The Phobos Reference TV application …………………………………………………………... 31
9、Block diagram & Explain
9-1 PDP Block diagram and functions…………………………………………….…….. ……………… 33
9-2 Image board block diagram and signal introduce/process……………………………………..… 34
10、Waveform of signal
10-1 Waveform of input signal…………………..….. ………..……. …..…. …. ………………..…… 37
10-2 Signal waveform in the Image board …..….. ………..……. …..…. ……. ………………..…… 40

Page 3 of 83
11、Check and Measure
11-1 Image board…………………..….. ……….. …. ……………..……... ……………………..…… 43
11-2 SIDE AV board……………….…..…..……..….. ………..…….. …. ……………………..…… 45
11-3 PDC board……………….…..…..……..….. ………..…….. . ……. ……………………..…… 45
12、Mechanical Introduction
12-1 PDP internal view..…..….. ………..………. ……..……….….. …. ……………..…… 46
12-2 Mechanical of cabinet front disassembly……. ……..……….….. …. ……………..…… 47
12-3 Disassembly and assembly..…..….. ………..……. ……. ……. …. ……………..…… 48
12-4 Block Wiring diagram..…..….. ………..……. ……. ……. ………… ……………..…… 56
13、PCB LAYOUT
13-1 Image board PCB LAYOUT.……………………………………………………………………….. 59
13-2 Key board PCB LAYOUT……………………..…..…..….. ………..…….. …. ……………..…… 59
13-3 Side AV board PCB LAYOUT………………..…..…..….. ………..…….. …. ……………..…… 59
13-3 PDC board PCB LAYOUT……………….…..…..….. ………..….. ….….. …. ……………..…… 59
14、Schematic diagram……………………………………………………...........................……………...… 61

Page 4 of 83
1、SPECIFICATION
1-1 General Specification
Item Specification
Screen size 42 inch plasma display panel
Aspect 16:9
Display pixels 1024 x 768
Effective display size 933.89mm x 532.22mm
Number of color 16.7 million colors（8 Bits）
Contrast Ratio 10000:1 (in dark room，NTSC)
Panel
Spec
Peak brightness 1100 cd/㎡（NTSC）
TV Tuning 1 Tuners, Air:2~69 channels Cable:2~135 channels
Sound system MTS+SAP
TV Mode
Color system ATSC / NTSC
Video RCA x 1 NTSC
AV1 ( S_Video/Video) S-Video1 x 1 NTSC Audio: L/R x 1
Video RCA x 1 NTSC
AV2 ( S_Video/Video) S-Video2 x 1 NTSC Audio: L/R x 1
480i
1080i
480P
Video Mode
AV3 / AV4
COMPONENT X 2
(YCbCr/YPbPr)
YCbCr/YPbPrx 2
720P
Audio: L/R x 2
Signal input Analog：D-Sub 15 pin
Plug and play DDC / 2B
Support Frequency FH:31KHz to 80KHz ，FV:50Hz to 85Hz
D-Sub Mode
VESA: 640 x 480
VESA: 800 x 600
VESA: 1024 x 768
VESA: 1280 x 1024
PC Mode
D-Sub Audio Earphone (3.5ø)
Signal input Digital：DVI-D 24 pin
Plug and play DDC / 2B
DVI Mode
720P
1080i
480P
DVI Mode
DVI Audio Earphone (3.5ø)
Power input sources AC 100-240V , 50/60Hz
Power Power consumption ≤450W
Operation Temperature + 0 °C ~ + 40 °C
Storage Temperature - 10 °C ~ + 50 °C
Environment
Humidity 10% -- 85%
Dimension Width x Height x Thickness 1038 x 726.5 x 240 (mm)
Net weight With Stand 34Kg
Accessory Remote Control Transmitter, Battery X 2, Power Cord, User’s Manual, RCA Cable,
D-SUB Cable, DVI Cable.

Page 5 of 83
1-2 Feature Summary
The following is the specification summary for the display:
z107 cm (42”) 16:9 Large Screen Flat Panel Plasma Display
zResolutions: 1024 (H) X 768(V) pixels, (1 pixel = 1 R, G, B cells)
z0.912 mm (H) X 0.693mm(V) pixel pitch.
zViewing Angle: 160° Vertically and Horizontally
zInternal TV Tuner, Air: 2~69 channels Cable: 2~135 channels
zTypical Maximum Contrast Ratio: 10000:1
zTypical Maximum Brightness: 1100 cd/m2
zATSC receiver, MPEG-2 decoder
zNTSC receiver, Video decoder
zDual Video, Dual S-Video
zDual Y Pb Pr (480i,480p,720p,1080i) HDTV Ready
zPC D-SUB 15Pin INPUT
zD-SUB analog video with rate 50Hz to 85 Hz vertical refresh rate and 31KHz to
80KHz horizontal frequency
zDVI-D Signal (TMDS) INPUT, Support HDTV, SDTV
zClosed Caption / V-chip
zComposite, S-Video, and component video receiver
zMIPS controller
zAuto Scan TV Channels
zField upgradable firmware
zUniversal Power Supply designed for worldwide application
zOperating power consumption less than 450 W
zStandby power consumption less than 1 W

Page 6 of 83
1-3 External interface
Most of these interfaces are located at the back-panel. There’s also a group of connectors located
on the side of this device for easier access. The following figures depict these A/V connectors.
Back Panel A/V Connectors
Side A/V Connectors
S-
V
ideo Video L R Earphone
AV2 Input

Page 7 of 83
1-3-1 Video/Audio Inputs
The following sections specify the video/audio inputs for 42PSEA06.
1-3-1-1 TV Antenna Interface
①. TV Antenna Connector
42PSEA06 shall provide a F-type cable connector with 75 ohms termination on its back
panel for reception of radio frequency signals.
②. TV Systems
42PSEA06 shall be capable of receiving the following broadcasting systems in the North
America region.
•Analog terrestrial and cable broadcasting in NTSC system and “M” sound system.
•All 18 formats specified for ATSC digital broadcasting
•Clear QAM digital cable broadcasting
③. TV Channel Coverage
The RF tuner shall be capable of covering 55.25 to 859.25 MHz and tuning to the following
channels:
•VHF: channel 2 through 13
•UHF: channel 14 through 69
•Mid band cable: A1 through A8, A through I
•Super band cable: J through W
•Hyper band cable: AA through ZZ, AAA, BBB
•Ultra band cable: channel 65 through 94, 100 through 125
④. Closed Caption
42PSEA06 shall support closed caption and text mode for both video and TV system. These
supports shall include channel ½ and field ½ selectable features.
⑤. V-Chip
42PSEA06 shall support MPAA grade for movie and TV Parental Guideline for TV. This
support shall include changeable password.
1-3-1-2 AV1
A standard definition (SD) analog video/audio source designated as AV1 shall be located on its
back panel. It comprises the following electrical connections. Only one of the two video inputs
shall be connected.
①. S-Video Input
42PSEA06 shall provide a 4-pin mini-DIN connector for connection to an external S-Video
source.
②. CVBS Video Input
42PSEA06 shall provide a RCA type receptacle for connection to an external CVBS source.

Page 8 of 83
③. Audio Inputs
42PSEA06 shall provide two RCA type receptacles for the stereo audio signal associated
with AV1 input.
1-3-1-3 AV2
A standard definition analog video/audio source designated as AV2 shall be located at the side
of 42PSEA06. It comprises the following electrical connections. Only one of the two video
inputs shall be connected.
①. S-Video Input
42PSEA06 shall provide a 4-pin mini-DIN connector for connection to an external S-Video
source.
②. CVBS Video Input
42PSEA06 shall provide a RCA type receptacle for connection to an external CVBS source.
③. Audio Inputs
42PSEA06 shall provide two RCA type receptacles for the stereo audio signal associated
with AV2 input.
1-3-1-4 AV3
A YPbPr/YcbCr type component video interface designated as AV3 shall be located on its back
panel. It comprises the following electrical connections.
①. Video Inputs
42PSEA06 shall provide three RCA type receptacles for connection to an external component
video source.
②. Audio Inputs
42PSEA06 shall provide two RCA type receptacles for the stereo audio signal associated
with Component1 input.
1-3-1-5 AV4
A YPbPr/YcbCr type component video interface designated as AV4 shall be located on its back
panel. It comprises the following electrical connections.
①. Video Inputs
42PSEA06 shall provide three RCA type receptacles for connection to an external component
video source.
②. Audio Inputs
42PSEA06 shall provide two RCA type receptacles for the stereo audio signal associated
with Component2 input.

Page 9 of 83
1-3-1-6 PC Input
42PSEA06 accommodates a VGA type computer connection as specified below.
①.Video Input connector
42PSEA06 shall provide a 15-pin D-Sub connector on its back panel for connection to a
VGA type video source. The VGA signal input on the display shall be capable of receiving
RGB analog video, H and V syncs, and DDC. The table below specifies pin-outs of this
connector.
Analog Connector Pin-outs
PIN MNEMONIC SIGNAL
1 RV Red Video
2 GV Green Video
3 BV Blue Video
4 NC None
5 GND Ground (DDC Return)
6 RG Red GND
7 GG Green GND
8 BG Blue GND
9 +5 V +5 V (from the PC)
10 SG Sync Ground
11 NC None
12 SDA DDC Data
13 HS Horizontal Sync
14 VS Vertical Sync
15 SCL DDC Clock
②. Audio Inputs
42PSEA06 shall provide a 3.5 mm jack for the stereo audio signal associated with VGA
input.
③. Input Formats
42PSEA06 shall support the following input format on its VGA input.
Horizontal Vertical
Mode Resolution Total Nominal
Frequency
(KHz)
Sync
Pola-rity
Nominal
Freq.
(Hz)
Sync
Pola-rity
Nominal
Pixel
Clock
(MHz)
VGA 640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
SVGA 800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
XGA 1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
WXGA 1280x1028@60Hz 1688x1066 64 N 60 P 108
1
6
11 15
5
10

Page 10 of 83
1-3-1-7 DVI
42PSEA06 shall accommodate a DVI type digital video source as specified in this section.
②.Video Inputs
42PSEA06 shall provide a 24 contact DVI-D receptacle on its back panel for receiving
TMDS digital video. The table below specifies pin assignments for the DVI-D connector.
DVI-D Digital connector pin assignments
PIN MNEMONIC SIGNAL
1 TX 2 - TMDS Data 2 -
2 TX 2 + TMDS Data 2 +
3 SHLD 2 / 4 TMDS Data 2 / 4 Shield
4 TX 4 - TMDS Data 4 -
5 TX 4 + TMDS Data 4 +
6 DDC Clk DDC Clock
7 DDC Data DDC Data
8 N/C No Connect
9 TX 1 - TMDS Data 1 -
10 TX 1 + TMDS Data 1 +
11 SHLD 1 / 3 TMDS Data 1 / 3 Shield
12 TX 3 - TMDS Data 3 -
13 TX 3 + TMDS Data 3 +
14 +5V +5V Power (from the PC)
15 GND Ground (Return for +5V)
16 HPD Hot Plug Detect
17 TX 0 - TMDS Data 0 -
18 TX 0 + TMDS Data 0 +
19 SHLD 0 / 5 TMDS Data 0 / 5 Shield
20 TX 5 - TMDS Data 5 -
21 TX 5 + TMDS Data 5 +
22 TX CLK SHLD TMDS Clock Shield
23 TX CLK + TMDS Clock +
24 TX CLK - TMDS Clock -
③.Audio Inputs
42PSEA06 shall provide a 3.5 mm jack for the stereo audio signal associated with DVI input.
④.HDCP support
HDCP must be supported on the DVI input. Refer to the High-bandwidth Digital Content
Protection System specification version 1.1 for details.

Page 11 of 83
④. Input Formats
42PSEA06 shall support the following input format on its DVI input.
Mode Resolution Total
Nominal
HFrequency
(KHz)
Nominal
Vertical
Frequency
(KHz)
Nominal Pixel
Clock Frequency
(MHz)
VGA 640x480@60Hz 800 x 525 31.469 59.940 25.175
SVGA 800x600@60Hz 1056 x 628 37.879 60.317 40.000
XGA 1024x768@60Hz 1344x806 48.363 60.004 65.000
720P 1280×720P 45.00 60 74.25
1080i 1920×1080i 33.75 60 74.25
480p 720×480p 31.54 60 27.00
1-3-2 Power Interface
1-3-2-1 Power Connector
42PSEA06 shall support an IEC C-13/C-14 (Standard) type male power receptacle for
connection to AC power source.
1-3-2-2 Power Input Range
The operating range shall be from 100 to 240 VAC sinusoidal. Input power frequency range shall
be from 50 to 60 Hz over the specified input voltage range.
1-3-2-3 Power Consumption
①. Operating Power
Power consumption for the display over the specified voltage and frequency ranges shall be
less than 450 W for the assemblies with speakers.
②. Standby Power
42PSEA06 power also below than one watt in the standby mode.
1-3-3 Service Interface
42PSEA06 shall provide a 9-pin D-sub connector on its back panel for firmware upgrading
purpose. This interface shall conform to RS-232 standard with the following pin-outs.
Pin Function
1 NC
2 TXD transmitted data
3 RXD received data
4 Shorted with pin 6
5 FG frame ground
6 Shorted with pin 4
7 Shorted with pin 8
8 Shorted with pin 7
9 NC
The method of firmware upgrading please see “Flash update process”chapter.

Page 12 of 83
1-4 User interface
1-4-1 Power Indicator
42PSEA06 shall make use of an LED type indicator located on the front of the display. The LED
color shall indicate the power states as given in the following table.
LED colors
Mode H-Sync V-Sync Video Pw-cons. Indicator
Power-On On On Active ＜450W Blue LED
Standby Off Off Off ＜1W Red LED
1-4-2 Remote Control Receiver
42PSEA06 shall provide an infra-red (IR) optical detector on its front panel for use as the
receiver for remote controller signal. The IR communication protocol shall conform to RC-5
standard. The minimum IR reception angles shall be +/- 30 degrees horizontally and vertically.
The required operating distance of the remote control shall be 7 m.
1-4-3 On-Screen Display
42PSEA06 shall provide an On Screen Display (OSD) system for customer setup. The
following table gives the structure of the OSD menus.
Main menu Sub menu Function Default Reset
Tuning Band To select between Air and Cable System Air —
DTV Signal To display the signal strength in order to aid the
antenna adjustment — —
Auto Ch Search To automatic scan and store all TV channels — —
Manual Ch Set To enable or disable channels — —
Channel Label To rename a channel — —
SETUP
Manu
Language
To select the language for OSD among English,
Spanish, French, and Portuguese English —
CONTRAST To adjust the contrast value between 0~100 50 Yes
BRIGHTNESS To adjust the brightness value between 0~100 50 Yes
SHARPNESS To adjust the sharpness value between 0~100 50 Yes
COLOR To adjust the color value between 0~100 50 Yes
TINT To adjust the tint value between 0~100 50 Yes
Aspect Ratio To select aspect ratio among Normal, Zoom,
Wide, and Cinema Normal Yes
VIDEO
Settings To restore all video settings to factory default — —
Audio
Language
To select audio language among English,
Spanish, French, and Portuguese English Yes
BASS Sets the bass value between 0~100 31 Yes
TREBLE Sets the treble value between 0~100 31 Yes
BALANCE Sets the left/right balance value between 0~100 31 Yes
AUDIO
Restore Default To restore all audio settings to factory default ——
Time Set To set current time ——
Sleep Timer To set the timer period to turn off the TV.
Selectable values are OFF,30,60 and 90 minutes OFF —
Password Set To set or change Parental Control password TBD —
Parental
Control To select V CHIP settings Un-lock ed —
FEATURE
White Screen To make a White screen by TV ifself. ——

Page 13 of 83
1-5 External Mounting Requirements
42PSEA06 shall be designed so that the display enclosure can be easily removed from the base
for external mounting applications. When the base is removed, there shall be no additional
non-removable parts that are visible from the front of the display
1-6 Environmental Requirements
1-6-1 Temperature Ranges
Operating Temperature (Independent of altitude) .................................................. 0°C to 40°C
Non-Operating Temperature (Independent of altitude) ................. ..................... -10°C to 70°C
1-6-2 Humidity
Operating (non-condensing) .................... ...............................................................20% to 85%
Non-Operating (38.7°C maximum wet bulb temperature........ ........... ....................5% to 85%
1-6-3 Altitude
Operating ............................................................... ...................... ...................... (0 to 2,000 m)
Non-Operating............................... .................................... ........ . ...................... (0 to 3,000 m)
1-6-4 Vibration and Shock
All testing shall be done in each of three mutually perpendicular axes, referenced to the position
of the system as it is in front of the user (i.e., front-to-back, side-to-side, and top-to-bottom).
2、Precautions and Notices：
2-1 Precaution of assembly
（1）Please do not press or scratch PDP panel surface with anything hard.
（2）Please wipe out PDP panel surface with absorbent cotton or soft cloth in case of it being soiled
（3）Please wipe out drops of adhesive like saliva and water in PDP panel surface immediately. They might
damage to cause panel surface variation and color change
（4）Do not apply any strong mechanical shock to the PDP panel
2-2 Precaution of Operation：
（1）Please be sure to unplug the power cord before remove the back-cover. (make sure the power is turn-off)
（2）Please do not change variable resistance settings in PDP MODULE; They are adjusted to the most
suitable value. If they are changed, it might happen LUMINANCE does not satisfy.
（3）Please consider that PDP MODULE takes longer time to become stable of radiation characteristic in
low temperature than in room temperature.
（4）Please pay attention to displaying the same pattern for very long-time. Image might stick on PDP.

Page 14 of 83
3、Operation
3-1 Operation of Remote Control Transmitter
42PSEA06 shall provide an IR remote controller as accessory.
123
456
897
POWER
Wide Mode
EPG
CC
SLEEP
Up
left right
Enter
Menu
Mute
EXIT
MTS
Down
TV Video Digital
Vol up
Vol down
CHup
CHdown
Pre-CH
“EPG”
Display the state, source
“Wide Mode”
Normal, Zoom ,Wide, Cinema
display select
“POWER”
The TV Set turn on /turn off ke
y
“MUTE”
Mute the sound
“MENU”
To enter Menu mode .
“SLEEP”
Select timer into power down state.
off→30→60→90→off
“Up▲/Down▼”
Move the cursor up and down on
the Menu
“left ◄/ right ►”
Use left ◄/ right ►to select or
adjust an item.
“CH up / CH down”
Press to select the next lower or
higher Program number.
“Vol up / Vol down”
Press Vol up/ Vol down
key to adjust volume .
“CC”
To select close caption
options(CC1,CC2……)
“ENTER”
To enter sub Menu or sub item .
“EXIT”
To exit Menu or other OSD .
“0~9 number”
To enter TV channel number
“Pre-CH”
TV channel return, see last TV
channel .
“Video”
AV1 CVBS Rear /AV1 S-Video
Rear/ AV2 CVBS Side/ AV2
S-Video Side / AV3 component 1/
AV4 component 2
“Digital”
VGA/DVI source input
“TV”
TV source select, into TV state
“ z”
To enter sub channel number
for digital channels .
“MTS ”
To select audio program
options
SEANIX

Page 15 of 83
3-2 Front panel controls
①IR: Remote Control Sensor.
②●LED: Power Indicator.
③Power switch: Press to power on or power off the TV set..
④ -CH+
Down: Press to select the next lower Programme number or move Down in
Menu operation.
Up: Press to select the next higher Programme number or move up in Menu
operation.
⑤ -VOL+ Left: Press to decrease the sound volume level or move Left in Menu operation.
Right: Press to increase the sound volume level or move Right in Menu operation.
⑥ MENU Menu: Press to enter Menu or exit Menu.
⑦ MODE Mode: Press to select input signal modes or use as Enter in Menu operation.
①
②
③
④
⑤
⑥
⑦
- CH + - VOL + MENU MODE

Page 16 of 83
3-3 OSD MENU Description
3-3-1 Main MENU
3-3-2 SETUP MENU
1. Press “MENU” key on remote control or
front panel controls to bring up Main Menu.
2. Press “” or “” to move the cursor up
and down the main menu item.
3. Press “” or “” to enter sub menu list.
4. Press “” or “” to move the cursor up
and down the sub-item list.
5. Press "Enter" to enter sub-item then use
“” or “” to adjust.
1. Tuning Band: Select TV signal source
between Air and Cable. Select Cable if you
are connecting to a cable box and select Air
if you are directly connecting to the antenna.
2. DTV Signal: Display signal strength to aid
antenna adjustment.
3. Auto Ch Search: Automatically scan and store
all TV channels.
4. Manual Ch Set: Enter channel setup table.
5. Channel Labels: Display and edit channel
names.
6. Menu Language: Select language for menu
(EnglishEspañolFançaisPortuguese).
yDTV signal menu indicates signal strength
in real-time.
yAuto channel scan menu displays channel
number being scanned.
yManual Channel Set Menu
Displays all the channel numbers that are
found.
Tune either to ATSC or NTSC channels.
Add or delete Channel number.
yChannel Labels Menu allows user labeling.

Page 17 of 83
3-3-3 Video MENU
3-3-4 Audio MENU
Contrast: Contrast adjustment, 0~100.
Brightness: Brightness adjustment, 0~100.
Color: Color chroma adjustment, 0~100.
Tint: Tint adjustment, 0~100.
Sharpness: Sharpness adjustment,0~100.
Aspect Ratio: Aspect Ratio selection.
NormalZoomWideCinema.
Settings: Restore default setting.
1. Press “” or “” to move the cursor up
or down the sub-item list.
2. Press "Enter" to enter the highlighted
sub-item menu.
3. Press “” or “ ” to adjust the value of
the sub-item.
4. Press "Enter" again to exit the sub-item.
Audio Language:
EnglishEspañolFrançaisPortuguese.
Bass: Bass adjustment, 0 ~ 100.
Treble: Treble adjustment, 0 ~ 100.
Balance: Balance adjustment, 0 ~ 100.
Restore Default: Restore Audio Language,
Treble, Base, and Balance setting to default.
1. Press “” or “” to move the cursor up
or down the sub-item list.
2. Press "Enter" to enter the highlighted
sub-item menu.
3. Press “” or “” to adjust the value of
the sub-item.
4. Press "Enter" again to exit the sub-item.

Page 18 of 83
3-3-5 Feature MENU
Time Set: Select minutes into standby
Off  30  60  90 .
Password Set: Enter and change Parental
Control Password.
Parental Control: Setup TV and Movie
rating controls.
White Screen: Select White Screen, and
press MODE front panel button (Enter on
the Remote control).The TV immediately
displays the white screen.
1. Press “” or “” to move the cursor up
or down the sub-item list.
2. Press "Enter" to enter the highlighted
sub-item menu.
3. Press “” or “” to adjust the value of
the sub-item.
4. Press "Enter" again to exit the sub-item.
Parental Control Menu: Controls
viewing of rated TV and Movie
programs.
Default password is: 0000.
Important : If you have forgotten your
Password. Use the code [0711] to enter
into the Password Set menu item to
change your password. You can also
use the code [0711] to change your
Parental Controls settings.

Page 19 of 83
3-3-6 Closed Captions
3-3-7 EPG
3-3-8 TV channel arrangement
1. Press “CC” key on remote control to select closed captions mode.
NTSC TV: Off CC1 CC2 …
ATSC TV: Off CS1 CS2 …
2. Select desired closed caption mode.
3.Closed captioning for analog NTSC channels is transmitted as CC1/CC2/CC3/ CC4. Closed
captioning for digital channels is transmitted as CS1/CS2/CS3/CS4/ CS5/CS6 or occasionally
CC1/CC2/CC3/CC4. You need to select the option you want for analog channels and digital
channels separately.
CC
1

NTSC TV
CS
1

AT
SC
T
V
Press the “EPG” key on the remote control
to display the Electronic Program Guide
(EPG). A message window will be
displayed on screen.
EPG Message Window
Each digital channel may comprise of
several sub-channels.
To select a digital channel using the remote
control:
1. Enter main channel number.
2. Press the “•” key.
3. Enter the sub-channel number.
Ch 5.4
