Philips BDS4241V/00 User manual

Published by MW 0669 BG CD Customer Service Printed in the Netherlands Subject to modification EN 3122 785 16680
©
Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Note: Repair of these products may only be performed by BDS authorised
workshops.
Colour Monitor Commercial Type Number
BDS4241V/00
BDH4241V/00
BDH5021V/00
G_16680_000.eps
150906
Contents Page
1 Specification 5
2 Engineering Specification 8
3 Block Diagram 32
4 Circuit 33
5 Exploded View 47
6 Calibration Methods 58
7 Inspection Methods 63
8 Firmware Upgrade Method 95
9 Serial Control Protocols 97
10 Trouble Shooting 101
11 PDP Module Service Manual 109
12 Spare Parts List 186

DISCLAIMER
WoosungNextier Corp. shall not be liable for technical or omissions contained
herein: nor for
incidental or consequential damages resulting from the furnishing, performance,
or use of this material.
WoosungNextier Corp. reserves the right to change any or all specifications
without notice.
Information in this document may change without notice.
CONFIDENTIALITY
All material contained within this document is proprietary information and the
sole
property of WoosungNextier Corp. #821~3, Byucksan Digital ValleyⅡ, 481-10,
gasan-dong, Geumcheon-Gu, Seoul-city, Korea.
No part of this document may be copied, reproduced, or transmitted by any
means, for any purpose without prior written permission from WoosungNextier
Corp.
RoHS :
1) PDP Module : RoHS is applied from the 1st delivery except panel of PDP
module which has not been defined as of 2006, June.
2) The Rest Material : It is possible to use together without distinguishing. 
2/185

Service Manual Revision
Date Description By Approved
2006.06.16 1st edit (for philips, EU)
2006.08.08 Exploded view modify (for philips, EU)
2006.09.15 Spare Parts BOM added incl. 12ncs
3/185

C O N T E N T S
◆SPECIFICATION----------------------------------------5
◆ENGINEERING SPECIFICATION------------------8
◆BLOCK DIAGRAM-------------------------------------32
◆CIRCUIT --------------------------------------------------33
◆BOM-------------------------See Separate Document
◆EXPLODED VIEW--------------------------------------47
◆CALIBRATION METHODS--------------------------58
◆INSPECTION METHODS-----------------------------63
◆FIRMWARE UPGRADE METHOD-----------------95
◆SERIAL CONTROL PROTOCOLS------------------97
◆TROUBLE SHOOTING-------------------------------101
◆PDP MODULE SERVICE MANUAL---------------109
4/185

Model : BDS4241V/00, BDH4241V/00, BDH5021V/00
● Multi-Standard Video System Supported : NTSC , PAL , SECAM
● HDMI(High Definition Multimedia Interface) Support Up to 720p,1080i,1280x1024/60 Hz(SXGA) (Option)
● DVI(Digital Visual Interface) Support Up to 720p , 1080i , 1280 x 1024 / 60 Hz (SXGA)
● HDCP(High-bandwidth Digital Content Protection) Supported
● Pixelworks DNX™ (Digital Natural Expression) technology including
Pixelworks DNX™ (Digital Natural Expression) technology
dramatically enhances the quality of video images
by combining multiple Pixelworks video processing technologies
to deliver clear,natural-looking standard and high-definition video images.
DNX technology combines sophisticated digital video processing techniques,
advanced scaling,motion-adaptive deinterlacing,noise reduction,
dynamic edge enhancement,and smoothing of moving lines to deliver a lifelike picture.
Main Features
● Multi-Standard Component Signal Compatibility : 480i , 576i , 480p , 576p , 720p , 1080i
● Multi-Standard RGB(PC) Monitor Support Up to 720p , 1080i , 1280 x 1024 / 60 Hz (SXGA)
● Audio Enhancement features including
• Automatic Volume Correction (AVC)
• Audio Delay for "Lip Sync" (Option)
• Spatial Effects
• Pseudo Stereo
● Deinterlacing features including
• Improved deinterlacer, supporting SDTV and HDTV, for standard NTSC/PAL/SECAM,1080i
• Per-pixel motion-compensated deinterlacing
• Improved Low-Angle Interpolation
• Film mode for 3:2/2:2 pull-down materials, including 1080i sources
● Still image function
● High Brightness and High Contrast Ratio
● Dual HDMI Input (Option)
● Built in Speakers (Option)
● Video Enhancement features including
• DCTI(Digital Chroma Transient) / DLTI(Digital Luminance Transient Improvement)
• Digital luminance peaking and Horizontal Peaking
• Enhanced sharpness controls
• Advanced Noise Reduction including progressive sources
• Flesh Tone Correction (FTC)
• Chroma Upsampling Error (CUE) correction
• Improved White and Black-level expansion
• Digital 3D Comb-filter (Option)
• Digital brightness, contrast, hue, and saturation control
• PixelBoost™(Pixelworks) overdrive technology for video format
• Improved scaler and filters for sharper images
• Improved multi-region, anamorphic scaling for 4:3<->16:9 aspect ratio conversion
• Independent vertical and horizontal scalers
• True 10-bit(1 billion color) processing (Option)
● Variable Picture control : Brightness , Contrast , Sharpness , Color , Tint
● Multi-screen display : Normal , PiP/PBP(Option)
● Variable Image size : Auto,Fill All(16:9),Fill Aspect,Zoom,Anamorphic,Wide
● Variable Audio control : Volume , Mute , Bass , Treble , Balance
● Ultra slim & light design
● Multi-Language On Screen Display (OSD)
● Sleep Timer
● Image Sticking Minimum Function
● TeleText support one thousands of pages (1K page)
● Quiet Fanless Operation
Specifications for PDP Monitor (Plilps Europe)
5/185

Internal Speaker
(Option)
External Speaker
(Option)
D-Sub Jack x 1
(
9
p
in
)
DVI Jack x 1
(24 pin)
RCA Jack x 1
RCA Jack x 1
Optical Jack x 1
Mini DIN Jack x1
(4 pin)
Scart Jack x 2
(21 pin)
[Full x 1, Half x 1]
or
RCA Jack x 2
O
p
erational
Stora
g
e
O
p
erational
Stora
g
e
O
p
erational
Storage
1500 cd/㎡1200 cd/㎡
Pixel Pitch
16:9
Aspect ratio 1024 (H) x 768 (V)
1.080(H) x 1.080(V) [mm] 0.900(H) x 0.676(V) [mm]
1000 cd/㎡
0.810(H) x 0.810(V) [mm]
Specifications BDH5012V/00
50" (1106.5(H) x 622.1(V)±0.5mm)
Analog RGB : 0.7V[p-p](75Ω), H/CS/V : TTL (2.2 kΩ), SOG : 1V[p-p](75Ω)
MAX : 720p , 1080i , 1280 x 1024 / 60 Hz (SXGA)
Item
PDP Monitor
BDS4241V/00 BDH4241V/00
In / Out
Terminals
Displayable Colors
RCA Jack x 1
10W(L) + 10W(R) [RMS] / 8 Ω
2 Way 2 Speaker(A,B,C,D) or 2 Way 4 Speaker (E)
10W(L) + 10W(R) [RMS] / 8 Ω
2 Way 4 Speaker System
Viewing Angle
Digital RGB : TMDS
MAX : 720p , 1080i , 1280 x 1024 / 60 Hz (SXGA)
TXD + RXD (1:1)
9500 K
1 billion (Option)
350W
1205 x 721 x 114.3 (C)
1205 x 721 x 114.3 (D)
800 ~ 1100 hPa (Altitude : 0 ~ 2,000 m)
Pressure
1028 x 625 x 89.8 (A)
1028 x 625 x 107.4 (B)
1194 x 655 x 105.3 (E)
General
Audio : 0.5V[rms](Normal) / 2 Channel (L+R)
8000:1
Speaker
Output
Audio : 0.5V[rms](Normal) / 2 Channel (L+R)
HDMI
Input
(Option)
HDMI Jack x 2
(Type A)
8000:1
RS-232C
DVI
Input
RGB
Input
Digital Audio
Output
(Option)
Color Temperature
Brightness
Contrast Ratio
D-Sub Jack x 1
(15 pin)
Component
Input
Humidity
Environment
Condition
Temperature
Weight (Without Stand)
S-Video
Input
Video
Input
Power Supply
Power Consumption (Typical)
RCA Jack x 1
Monitor
Output RCA Jack x 1
Dimensions (Without Stand)
[ W mm x H mm x D mm ]
* The specifications are subject to change without notice
Screen Size(Active Area)
Display
Number of Pixels 852 (H) x 480 (V)
10000:1
43 kg
Video : 1V[p-p] ( 75 Ω)
Y : 1V[p-p] ( 75 Ω) , C: 0.3V[p-p] ( 75 Ω)
RGB : 0.7V[p-p] ( 75 Ω)
Audio : 0.5V[rms](Normal) / 2 Channel (L+R)
AC 100V ~ 240V, 50/60Hz
42" (920.1(H) x 518.4(V)±0.5mm)
1366 (H) x 768 (V)
Over 160 degrees
Scart 1 , 2
290W
Digital RGB : TMDS (Video + Audio)
MAX : Video - 720p , 1080i , 1280 x 1024 / 60 Hz (SXGA)
Audio - 48kHz / 2 Channel (L + R)
Y:1V[p-p](75Ω) , Pb/Cb:0.7V[p-p](75Ω) , Pr/Cr:0.7V[p-p](75Ω)
480i , 576i , 480p , 576p , 720p , 1080i
Audio : 0.5V[rms](Normal) / 2 Channel (L+R)
3V[p-p] ( 75 Ω)
48kHz Sampling ( 4 Hz ~ 22 KHz)
Video : 1V[p-p] ( 75 Ω)
Audio : 0.5V[rms](Normal) / 2 Channel (L + R)
Video : 1V[p-p] ( 75 Ω) [ NTSC / PAL / SECAM]
Audio : 0.5V[rms](Normal) / 2 Channel (L + R)
Y: 1V[p-p] ( 75 Ω) , C: 0.286V[p-p] ( 75 Ω) [NTSC]
Y: 1V[p-p] ( 75 Ω) , C: 0.300V[p-p] ( 75 Ω) [PAL / SECAM]
1028 x 625 x 107.4 (B)
1194 x 655 x 105.3 (E)
450W
700 ~ 1100 hPa (Altitude : 0 ~ 3,000 m)
-20 ~ 60 ℃
31 kg(B) / 33 kg(E)
10 ~ 90% RH (NO condensation)
20 ~ 80% RH (No condensation)
29 kg(A,B) / 31 kg(E) 0 ~ 40 ℃
6/185

* The specifications are subject to change without notice
Output Sound Pressure
Frequency Response
* The specifications are subject to change without notice
Output Sound Pressure
Impedence
Input
Weight
Type
* The specifications are subject to change without notice
Standard
Option
Internal Speaker System , External Speaker System ,
DVI Cable , VGA(D-SUB) Cable , Audio Cable , Component Cable ,
Foot Stand , Table-Top stand , Wall-Mount Bracket , Ceiling-Mount Bracket ,
Owner's Instruction , Remote Controller/AAA Batteries , Power Cord
Internal Speaker (Option)
HDMI Cable , Optical Cable , Speaker Cable
Item
Type
RCA Video Cable , RCA Audio Cable , S-Video Cable , Scart Cable,
Impedence
Input
Accessories
Frequency Response
5 kg ( L + R )
Dimensions (W x H x D)
External Speaker (Option)
45 Hz ~ 20 KHz
Item Specifications BDH5021V/00
2 Way 4 Speaker System
8 Ω
87 dB/W/M
90 mm x 721 mm x 68 m
m
3 kg ( L + R )
113 mm x 626.6 mm x 82.2 mm
10 W ( RMS)
BDS4241V/00, BDH4241V/00
88 dB/W/M
140 Hz ~ 10 KHz
Specifications
2 Way 2 Speaker(A,B,C,D) or 2 Way 4 Speaker (E)
10 W ( RMS)
8 Ω
7/185

WoosungNextier Corp.
------------------------------------------------------------------------------------------------------------
Engineering Product Specification
MODEL
(BDS4241V/00, BDH4241V/00, BDH5021V/00)
PDP – MONITOR
Approved
WOOSUNG NEXTIER Corp.
DATE: DATE:
8/185

DISCLAIMER
WoosungNextier Corp. shall not be liable for technical or omissions contained
herein: nor for
incidental or consequential damages resulting from the furnishing, performance,
or use of this material.
WoosungNextier Corp. reserves the right to change any or all specifications without notice.
Information in this document may change without notice.
CONFIDENTIALITY
All material contained within this document is proprietary information and the sole
property of WoosungNextier Corp. #821~3, Byucksan Digital ValleyⅡ, 481-10, gasan-
dong, Geumcheon-Gu, Seoul-city, Korea. No part of this document may be copied,
reproduced, or transmitted by any means, for any purpose without prior written
permission from WoosungNextier Corp.
9/185

TABLE OF CONTENTS
1. SCOPE
1.1 Introduction.
1.2 Product Definition.
1.3 Mass Production Release.
1.4 Change Control.
1.5 Service.
2. GENERAL SPECIFICATION
2.1 General Spec.
2.2 Input / Output Terminal.
3. INPUT SIGNAL INTERFACE
3.1 DVI Signal Interface.
3.2 RGB Signal Interface.
3.3 DVI / RGB Mode Table.
3.4 Component Signal Interface.
3.5 Component Mode Table.
3.6 S-Video Signal Interface.
3.7 Composite Signal Interface.
3.8 SCART Signal Interface.
4. POWER
4.1 Power Supply.
5. CONTROLS AND INDICATORS
5.1 Hardware Control.
5.2 Remote control.
5.3 Menu Control
10/185

6. PLASMA DISPLAY PANEL(PDP) Specifications
6.1 42”SD Specifications
6.2 42”HD Specifications
6.3 50”HD Specifications
7. DISPLAY CELL DEFECT SPECIFICATION
7.1 42”SD Cell Defect Specifications
7.2 42”HD Cell Defect Specifications
7.3 50”HD Cell Defect Specifications
8. MECHANICAL
8.1 Fan.
8.2 Dimension.(without stand)
8.3 Weight.
9. ENVIRONMENTAL
9.1 42”SD Environmental Conditions.
9.2 42”HD Environmental Conditions.
9.3 50”HD Environmental Conditions.
10. PACKAGING
10.1 Packaging Specifications.
10.2 Vibration.
10.3 Drop.
11. AUDIO SYSTEM
11.1 Internal Speaker System.
11/185

1. SCOPE
1.1 Introduction
Product configuration
This specification defines the configuration and performance
requirements for the following Plasma Displays.
Plasma Displays
Product Name : PDP-MONITOR
Display Type : 42” SD / 42” HD / 50” HD
Model Name :
BDS4241V/00, BDH4241V/00, BDH5021V/00
1.2 Product Definition
Top Level Assembly
The top level assembly shall contain :
1. Plasma Display :
BDS4241V/00, BDH4241V/00, BDH5021V/00
2. Power Cord
3. Remote Control Unit
4. “AA” Batteries N=2
5. Owner’s Instructions
6. DVI & RGB(VGA) Cable
7. Foot Stand
8. Internal Speaker System
1.3 Mass Production Release
Mass Production Approval
Mass Production shall not begin until Woosung
Nextier Corp. has issued a Mass Production
Release.
Component Approvals
All exterior plastic components, screen printed components,
labels, shipping cartons, protective foam, and printed
materials require approvel by WoosungNextier Corp. prior to
Mass production Release.
12/185

1.4 Change Control
ECR/ECN
All Engineering changes to the product shall be made in
accordance with the WoosungNextier Corp. ECR/ECN
Procedure
1.5 Service
Documentation / Service Manual
Complete Spare Parts List, Schematic, Service Manual, and
Assembly Drawings shall be provided within one month of
Mass Production Release.
13/185

2. GENERAL SPECIFICATION
2.1 General Spec.
Display Type 42”SD 42”HD 50”HD
Model Name BDS4241V/00 BDH4241V/00 BDH5021V/00
Native Resolution & Frequency 852 X 480 @ 60Hz 1024 X 768 @ 60Hz 1366 X 768 @ 60Hz
Input Voltage AC100V ~ 240V,
50/60Hz
AC100V ~ 240V,
50/60Hz
AC100V ~ 240V,
50/60Hz
2.2 Input/Output Terminal
DVI Input DVI_D 24-pin Jack × 1
RCA Jack(L+R) × 1
RGB Input D-Sub 15-pin Jack ×1
RCA Jack(L+R) × 1
Component Input RCA(YPbPr/YCbCr) Jack × 1
RCA(L+R) Jack × 1
S-Video Input Mini DIN S-terminal × 1
Composite Input RCA Jack × 1
SCART Input/Output or Scart 21-pin Jack × 2 (Full×1, Half×1)
Monitor Output RCA Jack × 1
RS-232C D-Sub 9-pin Jack × 1
14/185

3. INPUT SIGNAL INTERFACE
3.1 DVI Interface
DVI Input Connector DVI-D Female Contacts
Audio Input Connector RCA (L+R) Jack
DVI Video Cable Connector Pin out Pin 1 TMDS Data 2-
Pin 2 TMDS Data 2+
Pin 3 TMDS Data 2/4 Shield
Pin 4 TMDS Data 4-
Pin 5 TMDS Data 4+
Pin 6 DDC Clock
Pin 7 DDC Data
Pin 8 NC
Pin 9 TMDS Data 1-
Pin 10 TMDS Data 1+
Pin 11 TMDS Data 1/3 Shield
Pin 12 TMDS Data 3-
Pin 13 TMDS Data 3+
Pin 14 +5V Power
Pin 15 Ground (+5V)
Pin 16 Hot Plug Detect
Pin 17 TMDS Data 0-
Pin 18 TMDS Data 0+
Pin 19 TMDS Data 0/5 Shield
Pin 20 TMDS Data 5-
Pin 21 TMDS Data 5+
Pin 22 TMDS Clock Shield
Pin 23 TMDS Clock -
Pin 24 TMDS Clock +
Sync Signals Digital, Differential type (TMDS)
DVI Audio Input Level 0.5V[rms] (L+R)
DVI Signal Impedance
DDC 1/2B Ver. 1.3
15/185

3.2 RGB Interface
RGB Input Connector D-Sub 15-Pin Jack (Female)
Audio Input Connector RCA (L+R) Jack
D-Sub 15-Pin Cable Connector Pin out Pin 1 Red analog Signal
Pin 2 Green analog Signal
Pin 3 Blue analog Signal
Pin 4 GND
Pin 5 GND
Pin 6 GND for Red signal
Pin 7 GND for Green signal
Pin 8 GND for Blue signal
Pin 9 NC
Pin 10 GND
Pin 11 GND
Pin 12 SDA (Input only)
Pin 13 H-Sync or composited H/V Sync Signal
Pin 14 V-Sync
Pin 15 SCL (Input only)
RGB Signals 700 mV full scale
RGB Signal Impedance 75 Ohms
RGB Audio Input Level 0.5V[rms] (L+R)
RGB Audio Output Level 0.5V[rms] (L+R)
RGB Sync Signals TTL 2.2k ohm internal pull-up resistors.
DDC 1/2B VER 1.3(Option)
16/185

3.3 DVI / RGB Mode Table
Mode Resolution Horizontal
Frequency(kHz)
Vertical
Frequency (Hz)
Pixel Clock Frequency
(MHz)
640 x 350 31.460 70.000 25.170
640 x 400 37.861 85.000 31.500
720 x 400 31.469 70.000 28.320
31.460 50.000 25.170
31.500 60.000 25.175
37.700 72.000 31.500
37.500 75.000 31.500
VGA
640 x 480
43.300 85.000 36.000
35.100 56.000 36.000
37.900 60.000 40.000
48.100 72.000 50.000
46.900 75.000 49.500
800 x 600
53.700 85.000 56.250
SVGA
832 x 624 49.720 75.000 57.280
48.400 60.000 65.000
56.500 70.000 75.000
60.000 75.000 78.750
64.000 80.000 85.500
1024 x 768
68.300 85.000 94.500
XGA
1152 x 870 68.680 75.000 100.000
SXGA 1280 x 1024 64.000 60.000 108.000
SDTV 480p 720 x 480 31.470 59.940 27.000
SDTV 575p 720 x 576 31.250 50.000 27.000
45.000 60.000 74.250
44.960 59.940 74.180
HDTV 720p 1280 x 720
37.500 50.000 74.250
33.750 30.000 74.250
33.720 29.970 74.180
31.250 25.000 74.250
HDTV 1080i 1920 x 1080
28.125 25.000 74.250
17/185

3.4 Component Interface
Component Input Connector RCA(YPbPr/YCbCr) Jack
Audio Input Connector RCA(L+R) Jack
Component Signal Y : 1V[p-p]
Pb/Cb : 0.7V[p-p]
Pr/Cr : 0.7V[p-p]
Component Signal Impedance 75 Ohms
Audio Input 0.5[rms] (L+R)
Audio Input Impedance 470K Ohms
Component Signal Type EDTV : 525i(480i), 625i(576i)
SDTV : 625p(576p), 525p(480p)
HDTV : 750p(720p), 1125i(1035i, 1080i)
3.5 Component Mode Table
Mode Resolution Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock Frequency
(MHz)
EDTV 480i 720 x 480 15.730 29.970 13.5000
EDTV 575i 720 x 576 15.630 25.000 13.5000
SDTV 480p 720 x 480 31.470 59.940 27.000
SDTV 575p 720 x 576 31.250 50.000 27.000
45.000 60.000 74.250
44.960 59.940 74.180
HDTV 720p 1280 x 720
37.500 50.000 74.250
33.750 30.000 74.250
33.720 29.970 74.180
31.250 25.000 74.250
HDTV 1080i 1920 x 1080
28.125 25.000 74.250
18/185

3.6 S-Video Interface
S-Video Input Connector Mini DIN4-pin
S-Video Signal Y : 1V[p-p]
C : 0.286V[p-p] (NTSC)
C : 0.3V[p-p] (PAL/SECAM)
S-Video Signal Impedance 75 Ohms
3.7 Composite Interface
Composite Input Connector RCA(Video) Jack
Composite Output Connector RCA(Video) Jack
Audio Input Connector RCA(L+R) Jack
Audio Output Connector RCA(L+R) Jack
Composite Input Signal V : 1V[p-p]
Composite Output Signal V : 1V[p-p]
Composite Audio Input Level 0.5[rms] (L+R)
Composite Audio Output Level 0.5[rms] (L+R)
Composite Input Signal Impedance 75 Ohms
Composite Output Signal Impedance 75 Ohms
Composite Audio Input Impedance 470K Ohms
Composite Audio Output Impedance 220K Ohms
19/185

3.8 Scart Interface
Scart Input Connector Scart 21-pin Jack
Scart1 21-Pin Cable Connector Pin out Pin 1 Audio R Out
Pin 2 Audio R In
Pin 3 Audio L (or Mono) Out
Pin 4 Audio Ground
Pin 5 RGB Ground Blue
Pin 6 Audio L (or Mono) In
Pin 7 RGB Blue In
Pin 8 FUNCTION SWITCHING
Pin 9 RGB Ground Green
Pin 10 N.C
Pin 11 RGB Green In
Pin 12 N.C
Pin 13 RGB Ground Red
Pin 14 Ground Data
Pin 15 RGB Red In / Chrominance In
Pin 16 Blanking Signal
Pin 17 Ground Composite signal
Pin 18 Ground Blanking Signal
Pin 19 Composite Video Out
Pin 20 Composite Video In / Luminance In
Pin 21 Ground / Shiled
Scart2 21-Pin Cable Connector Pin out Pin 1 Audio R Out
Pin 2 Audio R In
Pin 3 Audio L (or Mono) Out
Pin 4 Audio Ground
Pin 5 RGB Ground Blue
Pin 6 Audio L (or Mono) In
Pin 7 N.C
Pin 8 FUNCTION SWITCHING
Pin 9 RGB Ground Green
Pin 10 N.C
Pin 11 N.C
Pin 12 N.C
Pin 13 Chrominance Ground
20/185
