SECURECOM V‑4022C User manual
V‑4022C INDOOR HD VIDEO
CAMERA
Installation Guide
DESCRIPTION
The V‑4022Cis a 2Megapixel
indoor video camera that allows
users to view live and recorded HD
video clips in Virtual Keypad™.
To activate the camera, you need an
active Dealer Admin account at
dealer.securecomwireless.com.
Compatibility
• Any active Virtual Keypad
account with SecureCom
Cameras & NVRs enabled
What is Included?
• One V‑4022C Camera with
Mounting Plate
• 12 VDC Power Supply
• Mounting Template
• Hardware Pack
1WIRE THE CAMERA
Refer to Figure 2 for the location of power and Ethernet
connectors.
Standard Power Connection
Connect the 12 VDC power supply to the camera power connector.
For wired network, connect a network cable to the camera
Ethernet connector.
PoE Connection
Connect a network cable to the camera Ethernet connector.
Connect the cable to a PoE switch or injector.
Figure 1: V-4022C Camera
Figure 2: Camera Details
Lens
LED
12 VDC
Power
Ethernet
WPS/Reset
Base
Pan
Adjustment
Knob
Access Panel
Mounting
Plate
Release
Tilt/Rotation
Adjustment
Knob
2 V‑4022C INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS
MOUNT THE CAMERA
2The V‑4022Cis suitable for stand, wall, and ceiling mounting applications. Refer to Figure 2 and Figure 3
during mounting and camera adjustment.
Wall or Ceiling Mount
Ceiling mounting will be covered as an example in this section. However, the same steps may be referenced for
wall mounting.
1. Using the included template, mark and drill the screw holes for the mounting plate.
2. Press the Release button to release the mounting plate from the camera.
3. Install the mounting plate with the supplied mounting screws.
4. Fasten the camera base to the mounting plate.
Adjust the Camera Angle
1. Loosen the pan adjustment knob.
2. Adjust the pan angle as needed, then re‑tighten the knob.
3. Loosen the tilt/rotation adjustment knob.
4. Adjust the tilt and camera rotation angles, then re‑tighten the adjustment knob.
Figure 3: Mounting and Adjusting the Camera
Tilt
0° - 90°
Rotate
0˚ - 360˚
Pan
0° - 360°
Mounting Plate
Top
latch
Mounting
hole
Top
latch
Mounting
hole
Bottom
catch
Camera Base
Top
catch
Top
catch
Bottom
latch
V‑4022C INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS 3
ACTIVATE THE CAMERA
After you’ve connected the camera to the network, activate it in Dealer Admin.
1. Log in to Dealer Admin.
2. Find the customer and select the relevant account number. Select Edit.
3. In Video, enable SecureCom Cameras & NVR, then press Save.
4. On the System Information page, press the Add Camera button and enter the camera’s serial number.
Press Next.
5. Enter a name for the camera.
6. Select the camera’s time zone.
7. If the camera image needs to be inverted due to mounting position, toggle Flip Image.
8. To configure clip recording options, select Clips.
a. If you don’t want this camera to record video clips any time it detects motion, choose Never Record
Motion.
b. If you want this camera to record video clips any time it detects motion, choose Always Record on
Motion.
c. If you want the camera to record motion‑triggered clips only when the system is armed, choose
Record Motion When Armed.
d. To record video clips continuously during the first minute after the system triggers an alarm, select
Record on Alarm.
9. Press Save.
3Select one of the following connection methods and complete the appropriate steps to configure the camera.
Note: SecureCom recommends marking the Ethernet cable from the customer’s router to the WAP to help
with network troubleshooting.
Connect to a SecureCom WAP
Auto Pair
Verify that the WAP is powered. Plug the camera’s 12 VDC power supply into a standard 120 V electrical outlet.
The camera starts auto‑pairing when powered.
Manual Connection
1. Plug the camera’s 12 VDC power supply into a standard 120 V electrical outlet.
2. Open the camera’s side access panel.
3. Press the WPS button on the back of the WAP for up to 1.5seconds. The Security LED will flash to
indicate that the WAP is in pairing mode.
4. Within 1minute of pressing the WPS button on the WAP, press and hold the camera’s WPS/RESET
button for three seconds. Once the camera and router are fully connected, the WPS LED on the WAP
turns on steady.
5. Close the access panel.
Connect to a Router with WPS
1. Plug the camera’s 12 VDC power supply into a standard 120 V electrical outlet.
2. Open the camera’s side access panel.
3. Refer to the router’s instruction manual to place the router in WPS mode. Within 1minute of pressing
the WPS button on the router, press and hold the camera’s WPS/RESET button for three seconds. Refer
to the router’s instructions to determine when the camera and router are connected.
4. Close the access panel.
Use a Wired Connection
Plug the camera’s 12 VDC power supply into a standard 120 V electrical outlet and ensure the Ethernet cable is
connected. For POE connections, power on the connected POE switch or injector.
CONNECT THE CAMERA
4
LT-2175 20224
V-4022C INDOOR HD
VIDEO CAMERA
Specifications
Sensor and Lens
Image Sensor 2MP, 1/3” CMOS
Network
LAN 802.3 compliant 10/100 LAN
Wireless IEEE 802.11b/g/n
WPA/WPA2
IP Protocol IPv4
Hardware
Power Consumption
12 VDC Max 7.0 W
PoE (802.3af) Max 7.0 W
Weight 0.28 lbs (0.13 kg)
Dimensions 4.0” x 2.6” x 1.3”
(10.28 cm x 6.52 cm x 3.26 cm)
Housing Material Plastic
Environmental
Operating Temperature 14 °F to 104 °F (-10 °C to 40 °C)
Operating Humidity 95% RH or less, non-condensing
Ordering Information
V-4022C 2MP Indoor HD Video Camera
Accessories
371-500B-W 12 VDC Power Supply
V-IP1006RR SecureCom Wireless Access Point
(WAP)
Compatibility
Any DMP system with an active Virtual Keypad™ account
INTRUSION • FIRE• ACCESS• NETWORKS
2500 North Partnership Boulevard
Springfield, Missouri 65803-8877
800.641.4282 | DMP.com
© 2020
ADDITIONAL INFORMATION
Enable Email Clips
If the user would like to be emailed video clips, enable Email Video Clips in Dealer Admin. When this feature is enabled,
video clips are emailed to the app user.
1. Find the customer and select their name.
2. In App Users, find the user’s row, select the More icon, then select Edit.
3. Select Email Video Clips, then press Save.
LED Operation
• Red—The camera is recording clips.
• Blue—The camera is not recording clips.
• Blinking Red and Blue—The camera is powered, but not connected to the network.
Other SECURECOM Camcorder manuals
