SECURECOM V-5012B User manual
V-5012B INDOOR/OUTDOOR HD
VIDEO CAMERA
Installation Guide
DESCRIPTION
The V‑5012Bis a 2.1Megapixel
indoor/outdoor video camera
that allows users to view live and
recorded HD video clips in Virtual
Keypad™.
To activate the camera, you need an
active Dealer Admin account at
dealer.securecomwireless.com.
Compatibility
• Any active Virtual Keypad
account with SecureCom
Cameras & NVRs enabled
What is Included?
• One V‑5012B Camera with
Mounting Plate
• Mounting Template
• Hardware Pack with Security
Torx L‑key
1WIRE THE CAMERA
Before connecting the Ethernet cable, install the waterproof
Ethernet cap if desired. Refer to Figure 2.
Standard Connection
Connect a 12 VDC power supply (not included) to the camera
power connector. Connect a network cable to the camera Ethernet
connector. For compatible power supplies, refer to “Accessories”.
PoE Connection
Connect a network cable to the camera Ethernet connector.
Connect the cable to a PoE switch or injector.
Figure 1: V-5012B Camera
Figure 2: Installing the Waterproof Ethernet Cap
1/4
Turn
Turn
until
tight
Wire
and
crimp,
then
plug in
to camera
Ethernet
connector
Seat
o-Ring
between
cover and
Ethernet
connector,
then slip
cover over
connector
O-Ring
Cover
End Cap
From router/switch
MOUNT THE CAMERA
2Standard Wall or Ceiling Mount
Refer to Figure 4 when mounting the camera. Use the included
screws and wall anchors to mount the camera base to a wall or
ceiling. The mounting surface must be capable of holding five
times the camera’s weight.
Adjust the Camera
Refer to Figure 5 when adjusting the camera.
1. Loosen the adjustment screw with the included L‑key.
2. Adjust the pan, tilt, and camera rotation angle as needed.
3. To lock the camera in place, tighten the adjustment screw
with the L‑key.
2 V-5012B INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS
Figure 4: Mounting the Camera Figure 5: Adjusting the Camera
Adjustment
Screw
Rotate
0° - 360°
Pan
0° - 360°
Tilt
0° - 90°
Figure 3: Camera Details
A
B
A
B
C
D
12 VDC Power Connector
Ethernet Connector
Mounting Base
Adjustment Screw
C
D
V-5012B INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS 3
ACTIVATE THE CAMERA
After you’ve connected the camera to the network, activate it in Dealer Admin.
1. Log in to Dealer Admin.
2. Find the customer and select the relevant account number. Select Edit.
3. In Video, enable SecureCom Cameras & NVR, then press Save.
4. On the System Information page, press the Add Camera button and enter the camera’s 12‑digit MAC
Address. Press Next.
5. Enter a name for the camera.
6. Select the camera’s time zone.
7. If the camera image needs to be inverted due to mounting position, toggle Flip Image.
8. To configure clip recording options, select Clips.
a. If you don’t want this camera to record video clips any time it detects motion, choose Never Record
Motion.
b. If you want this camera to record video clips any time it detects motion, choose Always Record on
Motion.
c. If you want the camera to record motion‑triggered clips only when the system is armed, choose
Record Motion When Armed.
d. To record video clips continuously during the first minute after the system triggers an alarm, select
Record on Alarm.
9. Press Save.
3
ADDITIONAL INFORMATION
Enable Email Clips
If the user would like to be emailed video clips, enable Email Video Clips in Dealer Admin. When this feature is enabled,
video clips are emailed to the app user.
1. Find the customer and select their name.
2. In App Users, find the user’s row, select the More icon, then select Edit.
3. Select Email Video Clips, then press Save.
Add the Camera to an NVR
1. Change the desired channel to Manual.
2. Enter the IP address.
3. Set the protocol to ONVIF.
4. Set the Management Port to 80. Leave Channel Port set to 1and the TransferProtocol set to Auto.
5. The default username is scwuser and the password is scw12345user.
LT-2157 20184
V-5012B INDOOR/
OUTDOOR HD VIDEO
CAMERA
Specifications
Sensor and Lens
Image Sensor 2.1MP, 1/2.7” CMOS
Network
LAN 802.3 compliant 10/100 LAN
IP Protocol IPv4
Hardware
Power Consumption
12 VDC Max 5.6 W
PoE (802.3af) Max 7.3 W
Weight 1.1 lbs (0.5 kg)
Dimensions 6.42” x 2.66” (16.3 cm x 6.75 cm)
Housing Material Aluminum
Environmental
Operating Temperature 14 °F to 122 °F (-10 °C to 50 °C)
Operating Humidity Less than 90% RH, non-condensing
Ordering Information
V-5012B 2.1MP Indoor/Outdoor HD Video Camera
Accessories
371-500B-W 12 VDC Power Supply
Compatibility
Any DMP system with an active Virtual Keypad™ account
INTRUSION • FIRE• ACCESS• NETWORKS
2500 North Partnership Boulevard
Springfield, Missouri 65803-8877
800.641.4282 | DMP.com
© 2020
