Selecline 600082784 User manual

600082784
MFE60-S1206/C31-EU(NE)
USER MANUAL
Front Washing Machine 6KG
(P.03)
MANUAL DE UTILIZACIÓN
Lavadora de carga frontal 6KG
(P.53)
INSTRUKCJA OBSŁUGI
Pralka ładowana od przodu
6KG (S.105)
MANUAL DE UTILIZARE
Mașină de spălat cu încărcare
frontală 6KG (P.157)
ІНСТРУКЦІЯ З ЕКСПЛУАТАЦІЇ
Передня пральна машина
6кг (C.209)
MANUEL D’UTILISATION
Lave-linge à chargement
avant 6KG (P.27)
MANUAL DE UTILIZAÇÃO
Máquina de lavar frontal 6KG
(P.79)
HASZNÁLATI ÚTMUTATÓ
Elöltöltős mosógép 6KG
(131.o.)
РУКОВОДСТВО
ПОЛЬЗОВАТЕЛЯ
Стиральная машина с
фронтальной загрузкой
6кг (C.182)
шина

OFF
9
7
8
1
5
2
6
4
3
10 11 12 13
14
15
16
17
2

1/ SAFETY INSTRUCTIONS
Before using this electrical appliance, read the instructions
below carefully and keep them for future reference:
1. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons
in order to avoid a hazard.
2. Before connecting the appliance to a wall socket, ensure
that the local electrical current matches the current specied
on the appliance’s nameplate. This appliance should only be
connected to a grounded socket.
3. Unplug the mains cable from the mains when you are
not using the appliance and before performing any cleaning
or maintenance work.
4. Use the new hose sets supplied with the appliance. Do
not reuse old hose sets.
5. Unplug the appliance from the mains before performing
any maintenance work.
6. Always unplug the machine and turn o the water
supply after use.
7. Ensure that the water pressure of your water supply is
between the stated min. inlet water pressure and the max.
inlet water pressure.
TABLE OF CONTENTS:
1/SAFETY INSTRUCTIONS ______________________________ P. 3
2/TECHNICAL DATA ___________________________________ P. 7
3/PRODUCT DESCRIPTION_____________________________ P. 12
4/INSTALLATION _____________________________________ P. 16
5/USE _______________________________________________ P. 19
6/MAINTENANCE AND CLEANING ______________________ P. 22
7/WARRANTY AND LIMITATION OF LIABILITY ____________ P. 26
3

8. For your safety, the power plug must be inserted into
an earthed three-pole socket. Make sure that your socket is
properly and reliably earthed.
9. The water connections and electrical cables must be
connected by a qualied technician in accordance with the
manufacturer's instructions and local safety regulations.
10. Child safety hazard!
11. This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
useoftheapplianceinasafewayandunderstandthehazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance must not be done by children without
supervision.
12. Children of less than 3 years should be kept away unless
continuously supervised. Children shall not play with the
appliance.
13. Pets and children may climb into the machine. Check the
machine carefully before use.
14. The glass door may become very hot during use. Keep
children and pets away from the machine during use.
15. To prevent damage to the product, remove all packaging
and transport bolts before use.
16. The mains plug must be accessible after installation.
17. Risk of explosion!
18. Do not wash or dry items that have been dabbed with
or cleaned, washed or soaked in combustible or explosive
substances (such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents and kerosene) This may cause a re or
explosion.
19. The maximum mass of dry clothes to be used in the
appliance is 6.0 kg.
4

Installation
1. This washing machine is for indoor use only.
2. This washing machine is not designed for use as a built-
in appliance.
3. The openings must not be obstructed by carpet.
4. Thewashingmachinemustnotbe installed in bathrooms
or very wet rooms or rooms containing explosive or caustic
gases.
5. Models with a single inlet valve should be connected
to the cold water supply. Models with double inlet valves
should be correctly connected to the hot water and cold
water supply.
6. The mains plug must be accessible after installation.
7. To prevent damage to the product, remove all packaging
and transport bolts before use.
8. This product is for home use only and is only designed
for washing machine-washable textiles.
9. This appliance is intended to be used in household and
similar applications such as:
- sta kitchen areas in shops, oces and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments;
- areas for communal use in blocks of ats.
10. Do not climb or sit on top of the machine.
11. Do not lean against the machine door.
12. Handling precautions:
13. Transport bolts must be reinstalled by a technician.
14. Accumulated water must be drained out of the machine.
15. Handle the machine carefully. Never hold any protruding
parts of the machine while lifting. Do not use the machine
door as a handle when moving the appliance.
5

16. This appliance is heavy. Exercise care during transport.
17. Do not close the door with excessive force. If it is dicult
to close the door, check if the clothes are fully inserted into
the drum and evenly distributed.
18. Do not use the machine to wash carpets.
19. Before washing clothes for the rst time, the washing
machine should be run for one full cycle with no clothes
inside.
20. Do not place ammable, explosive or toxic solvents
into the machine (e.g. gasoline or alcohol) or use them as
detergents. Only use detergents which are suitable for
machine washing.
21. Make sure that all pockets are emptied. Sharp and rigid
items such as coins, jewelry, nails, screws or stones may cause
serious damage to the machine.
22. Check whether the water inside the drum has been
drained before opening the door. Do not open the door if
there is any water visible.
23. Take care not to burn yourself when the product is
draining hot water.
24. Never rell the water by hand during a washing cycle.
25. After the program has nished, wait for two minutes
before opening the door.
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the
collection systems or contact the retailer where the product
was purchased. They return and can take this product for
environmental safe recycling.
6

2/ TECHNICAL DATA
2.1 Technical Specications
Power supply 220-240 V~, 50 Hz
Rated power 2050 W
Max. current 10 A
Standard water pressure 0.05 MPa~1 MPa
Model 600082784
Washing capacity 6.0 kg
Dimensions (W x D x H in mm) 595 x 470 x 850
Net weight 57 kg
2.2 Product che
Concerning Regulation (EU) No 1061/2010
Trade mark
Model identier 600082784
Rated capacity in kg of cotton laundry 6
Energy eciency class on a scale from A+++ (most
ecient) to D (least ecient) A+++
Energy consumption of 153 kWh per year, based on 220 standard washing
cycles for the standard cotton programmes at 60 °C and 40 °C at full and
partial load, and the consumption of the low-power modes. Actual energy
consumption will depend on how the appliance is used.
Energy consumption of the standard 60°C cotton
programme at full load 0.76 kwh
Energy consumption of the standard 60°C cotton
programme at partial load 0.59 kwh
Energy consumption of the standard 40°C cotton
programme at partial load 0.60 kwh
Weighted power consumption of standby mode 0.50 W
Weighted power consumption of power-on mode 1.00 W
7

Water consumption of 9240 litres per year, based on 220 standard washing
cycles for the standard cotton programmes at 60 °C and 40 °C at full and partial
load. Actual water consumption will depend on how the appliance is used.
Spin-drying eciency of class B on a scale from G (least ecient) to A (most
ecient)
Maximum spin speed 1200
Remaining moisture content 53%
The“Intensive 60°C programme” and “Intensive 40°C programme”are the
standard washing programmes to which the information in the label and the
che relates. These programmes are suitable for cleaning normally soiled cotton
laundry and are the most ecient programmes in terms of combined energy
and water consumption.
Programme time of the standard 60°C cotton
programme at full load 270 min
Programme time of the standard 60°C cotton
programme at half load 260 min
Programme time of the standard 40°C cotton
programme at half load 260 min
Duration time of power-on mode -
Airborne acoustical noise emissions during washing
phase 64 dB
Airborne acoustical noise emissions during spinning
phase 77 dB
“Built-in” washing machine No
Energy test program: Intensive 60/40°C. Speed: Maximum speed; Other
specications as default.
8

Supplier's name or trade mark: Selecline
Supplier's address (b): 200, rue de la Recherche, Le Colibri BP 169,
59650 Villeneuve d¡¯Ascq, France
Model identier: 600082784 MFE60-S1206/C31-EU(NE)
General product parameters:
Parameter Value Parameter Value
Rated capacity (a)
(kg) 6.0 Dimensions in cm Height 85
Width 60
Depth 47
EEIW(a) 91.0 Energy eciency
class (a)E
Washing eciency
index (a)1.04 Rinsing
eectiveness (g/
kg) (a)
5.0
Energy
consumption in
kWh per cycle,
based on the eco
40-60 programme.
Actual energy
consumption will
depend on how
the appliance is
used.
0.737 Water
consumption in
litre per cycle,
based on the eco
40-60 programme.
Actual water
consumption will
depend on how
the appliance is
used and on the
hardness of the
water.
43
Maximum
temperature inside
the treated textile
ft (°C)
Rated
capacity
41 Remaining
moisture content
0 (%)
Rated
capacity
62
Half 37 Half 62
Quarter 23 Quarter 62
Spin speed ft (rpm) Rated
capacity
1200 Spin-drying
eciency class (a)D
Half 1200
Quarter 1200
Programme
duration O (h:min) Rated
capacity
3:18 Type Free-standing
Half 2:36
Quarter 2:36
9

Airborne acoustical
noise emissions in
the spinning phase
(a) (dB(A) re 1 pW)
80 Airborne acoustical
noise emission
class (a) (spinning
phase)
C
O-mode (W) 0.50 Standby mode (W) 1.00
Delay start (W) (if
applicable) 4.00 Networked standby (W) (if
applicable)
N/A
Minimum duration of the guarantee oered by the supplier (b).
This product has been designed to
release silver ions during the washing
cycle No
Additional information:
Link to the supplier's website, where the information in point 9 of Annex II to
Commission Regulation (EU) 2019/2023 (1) (b) can be found:
(a) for the eco 40-60 programme.
(b) changes to these items shall not be considered relevant for the purposes of
paragraph 4 of Article 4 of Regulation (EU) 2017/1369.
(c) if the product database automatically generates the denitive content of this
cell, the supplier shall not enter these data.
2.3 Programmes
You can choose from the following programmes according to the laundry type.
Programmes
Synthetic
For washing synthetic articles (e.g. shirts, coats, blended
fabrics). When washing knitwear, the detergent quantity
should be reduced to prevent an excessive amount of bubbles
from forming.
Delicate For delicate, washable fabrics, e.g. silk, satin, synthetic bres or
blended fabrics.
Drum Clean
Special programme for cleaning the drum. The drum is
sterilised at 90°C. Do not use this programme for washing
garments. Add the correct amount of bleach to increase the
cleaning eect. Use this programme as needed.
Spin Only Spin only with a selectable spin speed.
Rinse & Spin Rinse and spin only
Drain Only For draining o the water.
Quick
Wash 15'
For quickly washing a small load of lightly soiled garments
within 15 minutes.
Cotton
Intensive The washing time is increased for more intensive cleaning.
10

ECO 40-60 Default 40°C (not selectable), suitable for laundry washing at
40°C-60°C.
Cold Wash Uses cold water to wash clothes.
Cotton For hard-wearing garments and heat-resistant fabrics made of
cotton or linen.
Ends in Timer function – the total time including the washing time
and timer can be set to 3h, 6h or 9h.
Washing Programme Table
Cycle Nominal capacity
in kg
Cycle
duration
in hours
and
minutes
Energy
consumption
in kWh /
operation
cycle
Water
consumption
in liter/
operation
cycle
Highest
temperature
°C
Residual
moisture
in % /
spin
speed
Quick Wash 15' 2.0 0:15 0.035 32 15 75%
Quick Wash 30' 2.0 0:30 0.228 32 30 70%
Quick Wash 45' 2.0 0:45 0.368 32 40 70%
Cold Wash 3.0 1:00 0.140 37 15 60%
Cold Wash
20 °C 3.0 1:01 0.207 37 20 60%
Cotton 30 °C 6.0 2:40 0.672 58 30 60%
Cotton/
Cotton 40 °C 6.0 2:40 0.871 58 40 60%
Cotton60 °C 6.0 2:45 1.280 58 60 60%
Cotton 90 °C 6.0 2:50 1.888 58 90 60%
Cotton
Intensive 40 °C 6.0 3:58 1.053 58 40 60%
Cotton
Intensive 60 °C 6.0 4:00 1.455 58 60 60%
Delicate 2.0 0:48 0.112 32 15 80%
Delicate 30 °C 2.0 0:50 0.275 32 30 80%
Drain Only 6.0 0:01 0.010 58 - -
Drum Clean 0.0 1:18 0.928 18 90 -
Ends in
3H/6H/9H 6.0 0:59 0.635 58 40 60%
Rinse & Spin 6.0 0:20 0.055 58 - 60%
Spin Only 6.0 0:12 0.045 58 - 60%
Synthetic 3.0 2:20 0.327 55 30 60%
Synthetic/
Synthetic 40 °C 3.0 2:20 0.648 37 40 60%
EC040-60 6.0 3:18 1.000 50 41 62% 3.0 2:36 0.622 39 37 62%
1.5 2:36 0.390 36 23 62%
11

The new EU energy eciency class is E
Energy test program: ECO 40-60. Speed: Maximum speed; Other specications as
default.
Half load for 6.0 kg machines: 3.0 kg.
The old EU energy eciency class is A+
Energy test program: Cotton Intensive 60°C/40°C. Speed: Maximum speed; Other
specications as default. Half load for 6.0 kg machine: 3.0 kg.
Note!
ŶThe parameters in this table are for the user’s reference only. The actual
parameters may vary from the parameters in the above table.
1. The highest temperature reached by the laundry in the wash cycle for at least
5 minutes.
2. Residual moisture after the wash cycle in water content percent and the spin
speed at which this was achieved.
3. The ECO 40-60 programme is able to clean normally soiled cotton laundry
declared to be washable at 40°C or 60°C, together in the same cycle. This
programme is used to assess the compliance with the regulation (EU)
2019/2023.
The most ecient programmes in terms of energy consumption are generally those
that perform at lower temperatures and longer duration.
Loading the household washer-dryer up to the capacity indicated for the respective
programmes will contribute to energy and water savings.
Noise and remaining moisture content are inuenced by the spinning speed: the
higher the spinning speed in the spinning phase, the higher the noise and the
lower the remaining moisture content.
3/ PRODUCT DESCRIPTION
3.1 Front view
1- Top cover
2- Control panel
3- Power supply cord
4- Drum
5- Service lter
6- Drain hose
7- Door
8- Detergent dispenser
9- Water supply hose
3.2 Accessories
10- Transport hole plug
11- Supply hose cold water 12- Supply hose (hot water, optional) 13- Owner's manual
12

3.3 Control Panel
14- O: Switches the product on or o.
15- Start/Pause: Press this button to start or pause the washing cycle.
16- Option: This allows you to select an additional function; it will light up
when selected.
17- Programmes: Choose a suitable programme according to the laundry
type. When the program has nished, the Pause/Start and Door Lock
lights will ash.
3.4 Detergent Dispenser
Pre wash detergent
Main wash detergent
Softener
Note: Detergent only needs to be added in
“compartment I” if you have selected the“pre-washing”
function (not available on all machines).
Programme Programme
Cotton 30 °C żƔż
Delicate 30 °C Ɣż
Cotton 40 °C żƔż Delicate Ɣż
Cotton 60 °C żƔż Ends in 9H Ɣż
Cotton 90 °C żƔż Ends in 6H Ɣż
Synthetic żƔż Ends in 3H Ɣż
Synthetic 40 °C żƔż Quick Wash 45' Ɣż
Drum Clean Quick Wash 30' Ɣż
Cold Wash żƔż Quick Wash 15’ Ɣż
Cold Wash 20 °C żƔż ECO 40-60 Ɣż
Spin Only Cotton Intensive 40 °C Ɣż
Drain Only Cotton Intensive 60 °C Ɣż
Rinse & Spin ż
Ɣ0XVWż2SWLRQDO
13

The table shows which cycle oers which options for adjustment. If an adjustment
is not possible for a cycle, the symbol will ash in the display.
Figures in bold correspond to the factory setting.
Cycle Adjust the temperature in °C Additional functions
Synthetic Cold ,
Synthetic 40°C 40 ,
Cold Wash Cold ,
Cold Wash 20"C 20 ,
Cotton 30"C 30 ,
Cotton 40 "C 40 ,
Cotton 60'C 60 ,
Cotton 90“C 90 ,
ECO 40-60 60
Cotton Intensive 40"C 40
Cotton Intensive 60"C 60
Drum Clean 90
Spin Only -
Drain Only -
Rinse & Spin -
Delicate 30"C 30
Delicate Cold
Ends in 3H/6H/9H 40
Quick Wash 45’ 40
Quick Wash 30’ 30
Quick Wash 15’ Cold
Note!
ŶWhen using powdered detergent, it is recommended to add some water to the
detergent box to prevent the inlet of the detergent box from becoming blocked
and overowing when the machine is lling with water.
ŶFor optimal washing results and to reduce water and energy consumption,
choose a suitable type of detergent for the selected washing temperature.
14

3.5 Detergent Recommendation
Recommended
washing detergent Washing temp Type of laundry and textile
Heavy -duty detergent with
bleaching agents and optical
brighteners. 40/60/90 White laundry made from boil-
proof cotton or linen
Colour detergent without
bleaching agent and optical
brighteners. 20/30/40 Coloured laundry made from
cotton or linen
Colour or mild detergent
without optical brighteners 20/30/40 Coloured laundry made from
easy care bres or synthetic
material
Mild washing detergent 20/30 Delicate textiles, silk, viscose
Special wool detergent 20/30/40 Wool
Note
Agglomerating or ropy detergent or additive can be diluted in some water before
pouring it into the detergent dispenser, to avoid its inlet to get blocked and thus
cause a water overow.
Please choose the suitable type of detergent to get a maximum of washing
performance and a minimum of water and energy consumption.
To achieve the best cleaning result a proper detergent dosing is important.
Use a reduced detergent amount if the drum is not lled completely.
Always adjust the amount of detergent to the water hardness, if your tap water is
soft, use less detergent.
Dose according to how dirty your laundry is, less dirty clothes require less
detergent.
Highly concentrated (compact detergent) requires particularly accurate dosing.
Following symptoms are a sign of detergent overdosing:
Ŷheavy foam formation
Ŷpoor washing and rinsing result
Following symptoms are a sign of detergent underdosing:
Ŷlaundry turns grey
Ŷbuilt-up of limescale deposits on the drum, the heating element and/or the
laundry
15

4/ INSTALLATION
4.1 Installation area
Warning!
ŶThe product must be placed in a stable location to prevent
it from moving during use.
ŶEnsure that the appliance is not standing on the power
cord.
Before installing the machine, follow the steps below to select a
suitable location:
1. Choose a stable, dry, and level surface.
2. Avoid direct sunlight.
3. Ensure that there is sucient ventilation.
4. Ensure that the room temperature is above 0°C.
5. The installation location must be far away from ammable
materials such as coal or gas.
4.2 Unpacking the washing machine
Warning!
ŶPackaging material (e.g. lm, polystyrene foam) can be
dangerous for children.
ŶRisk of suocation! Keep all packaging materials out of the
reach of children.
1. Remove the cardboard box and polystyrene foam.
2. Lift the washing machine and remove the base packaging.
Make sure the small triangular foam is removed together
with the bottom piece. If not, lay the unit down on its side,
and then remove the small piece of foam from the bottom
of the unit.
3. Remove the tape securing the power supply cord and drain
hose.
4. Remove the inlet hose from the drum.
4.2.1 Removing the transport bolts
Warning!
ŶBefore using the product, the transport bolts must be
removed from the rear side of the appliance.
ŶKeep the transport bolts in a safe place for future use (you
will require these if you need to transport the appliance to a
new location).
Follow the steps below to remove the bolts:
1. Loosen the 4 bolts with a spanner and then remove them.
2. Stop the holes with the transport hole plugs.
3. Store the transport bolts in a safe place for future use.
16

4.3 Levelling the washing machine
Warning!
ŶThe lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are securely attached to the housing. If not, turn them to their
original positions and tighten the nuts.
2. Loosen the lock nut and turn the foot until it is in close contact with the oor.
3. Adjust the legs and lock them with a spanner, making sure that the machine is
steady.
Raise Lower
Lock nut
foot
4.4 Connecting the washing machine
4.4.1 Connecting the water supply hose
Warning!
ŶTo prevent leakage or water damage, follow the instructions in this chapter!
ŶDo not bend, crush, modify or sever the water inlet hose.
ŶIf the model is equipped with a hot valve, connect it to the hot water tap with
the hot water supply hose. Energy consumption will decrease automatically for
some programs.
Connect the inlet pipe as indicated. There are two ways to connect the inlet pipe:
4.4.1.1 Connection between ordinary tap and inlet hose.
clamp out
slide bushing
Loosen the clamp
nut and four bolts
Tighten the clamp
nut
Press the slide
bushing and insert
the inlet hose into
the connecting
base
Connection
complete
17

4.4.1.2 Connection between screw tap and inlet hose.
slide bushing
Tap with threads and inlet hose Special tap for washing machine
Connect the other end of inlet pipe to the inlet valve on the rear of the product and
fasten the pipe tightly in a clockwise direction.
water supply hosewater Inlet valve
4.4.2 Drain hose
Warning!
ŶDo not bend or stretch the drain hose.
ŶPosition the drain hose properly, otherwise damage may be caused due to
water leakage.
There are two ways to position the end of the drain hose:
1. Place it directly into the water
trough. 2. Connect it to the branch drain pipe of the trough.
Water
trough
18

Note!
ŶIf the machine has a drain hose support, install the drain hose as follows.
Hose
Retainer
Trough
Bind
Warning!
ŶWhen installing the drain hose, x it properly with a hose tie.
ŶIf the drain hose is too long, do not force it into the washing machine, as this will
result in abnormal noises.
5/ USE
5.1 Quick Start
Caution!
ŶBefore washing, make sure the washing machine is installed properly.
ŶBefore washing for the rst time, the washing machine should be run for a full
cycle without clothes as follows.
5.1.1. Before washing
Softener
Prewash
Main
wash
Plug in Open tap Load Close door Add detergent
Note: Detergent only needs to be added in“compartment I”if you have selected the
pre-washing function (not available on all machines).
5.1.2 Washing
Select programme Select function or
default Start
19

Note:
ŶIf default is selected, step 2 can be skipped.
ŶThe function button chart is for reference only. Actual functions may vary
depending on the product.
ŶThe washing machine should be used at ambient temperatures of 0-40°C. If
used below 0°C, the inlet valve and draining system may be damaged due to
frost.
ŶCheck the clothing labels and detergent instructions before washing. Use non-
foaming detergent suitable for washing machines.
Check the label Empty the pockets Knot long strips, zip or
button
Put small clothes into a
wash bag
Turn easy-pilling and
long-pile fabric inside out
Separate clothes with
dierent textures
Warning!
ŶWhen washing single items of clothing, it may cause the washing machine to
become unbalanced. To ensure optimal draining, wash several items of clothing
together.
ŶDo not wash clothes which have come into contact with kerosene, gasoline,
alcohol or other ammable materials.
5.1.2.1 Options
Prewash: The Prewash function completes an extra wash before the main wash.
This function is designed to wash away the dust that rises to surface of the clothes.
When selecting this mode, you need to add detergent to compartment (I).
Extra Rinse: The laundry will undergo an extra rinse.
No Spin: If you select this function, the clothes will not be spun.
20
