Serialio KeyBatch BR2 User manual

For complete KeyBatch™ BR2 documentation, visit serialio.com/support/Scanner/KeyBatch/index.php
1
1. Charge scanner
Connect KeyBatch™ BR2 scanner to a powered USB port for about 4 hours, or until LED shows
green.
2. Choose mode
The default setting of the KeyBatch™ BR2 scanner is USB SerialMagic mode.
USB SerialMagic Mode:
1. While the scanner is not connected,
scan the following barcode:
ÉÁC01mËÍ
USB SerialMagic
(You should hear some beeps.)
2. Install SerialMagic software for
Windows (File is available from
Serialio.com>Downloads>SerialMagic
Downloads)
3. Connect the KeyBatch™ BR2 to your
computer’s USB port.
4. Inside SerialMagic, click “Add.” Then,
select “Cabled connection,” select the
KeyBatch™ scanner, and click “Next.”
Select the COM port through which your
scanner is connected, and click “Next.”
Select “Like a keyboard…,” and click
“Next.”
5. You are now ready to use your
KeyBatch™ scanner with SerialMagic!
USB Keyboard Mode:
1. While the scanner is not connected, scan
the following barcode:
ÉÁSUQËÍ
USB Keyboard
(You should hear some beeps.)
2. KeyBatch™ BR2 scanner will beep when it is
plugged into a USB port. You are now ready
to scan to cursor location!
Your serial solution provider on
over 500 mobile device models
Quick Start Guide
715 Discovery Blvd. Ste. 510
Cedar Park, TX 78613
Tel: [phone]
Fax: [phone]
For sales inquiries:
[e-mail]
For technical support:
[e-mail]

For complete KeyBatch™ BR2 documentation, visit serialio.com/support/Scanner/KeyBatch/index.php
2
Device Specifications
Physical Characteristics
W x D x H: 30mm x 62mm x 16mm (1.18” x
2.44” x 0.63”)
Weight: 28.35g (1oz)
Power Source
Internal rechargeable Lithium-Polymer
battery 3.7VDC, 150mAH
Expected Battery Life: 1000 scans
Charges via standard USB port
Operating Temperature: 10 - 40°C (14 - 104° F)
Ambient Light Rejection
Fluorescent: 4,000 lx max
Direct Sunlight: 80,000 lx max
Incandescent: 4,000 lx max
Warranty: One year
Maximum Barcode Digits: At least 70 digits
Laser: JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA
CDRH Class II
Operating System Support
Android tablets that support USB
keyboards
Linux –USB keyboard
Mac OS X –USB keyboard
Windows7/2008/Vista/XP/2003/2000 –
USB keyboard, SerialMagic, and Scan List
Magic
Bar Code Symbologies Decoded
All standard 1D symbologies:
JAN/UPC/EAN incl. add on, Codabar/NW-
7, Code 11, Code 39, Code 93, Code 128,
GS1-128 (EAN-128), GS1 DataBar (RSS),
IATA, Industrial 2of5, Interleaved 2of5,
ISBN-ISSN, Matrix 2of5, MSI/Plessey, S-
Code, Telepen, Tri-Optic, UK/Plessey
Control Codes for Batch Mode
Enable batch mode (save
scans to scanner memory):
ÉÁ]DTME+P!ËÍ
Store Scans
Save scans and timestamp to
scanner memory:
ÉÁ]DTME+Q)ËÍ
Store Scans and Timestamp
Send scans from scanner
memory:
ÉÁ+-MDLD-+!ËÍ
Send Scans
Erase scans from scanner
memory:
ÉÁ+-MCLR-+~ËÍ
Erase Scans
Send scan followed by a new
line:
ÉÁRYRZ1MGËÍ
CR after Scan
Disable batch mode (do not
save scans to memory):
ÉÁ]DTMDQËÍ
Real-Time Only
Control Codes for Keyboard Mode
Send data only (no prefix, no
suffix):
ÉÁMGPR9ËÍ
Data Only
Send barcode value then CR
(Use for Safari iOS):
ÉÁRZ7QMG/ËÍ
Data then CR
Send barcode value then
ENTER (use for Safari OS X):
ÉÁRZ1MMGjËÍ
Data then Enter
Send barcode value then
TAB:
ÉÁRZ7HMGiËÍ
Data then Tab
Send barcode value then
COMMA:
ÉÁRZ5MMGzËÍ
Data then Comma
Send barcode value for Grid-
In-Hand® Mobile Grid:
ÉÁRY1BRZ7HMGYËÍ
Mobile Grid KB
