Sheyenne tooling & Mfg 600CT User manual

COMPACT TRACTOR
SNOWBLOWER
Owner / Operator Manual
& Parts Book
Sheyenne Tooling & Mfg.
PO Box 647
701 Lenham Ave. SW
Cooperstown ND 58425
www.sheyennemfg.com
[phone] Fax [phone]
[phone]

COMPACT TRACTOR
SNOWBLOWER
_________________________________
MODELS
500CT
600CT
5 And 6 Foot Width
1

ATTENTION DEALER
The dealer has primary responsibility for warranty registration of the
Compact Tractor Snowblower. The dealer and the purchaser should
jointly record the information on page 3 and the warranty pages that
follow that page. Both parties need to keep their respective copies. It
is advisable for the purchaser to share the name of the insurance
company that is covering his or her e uipment. This is helpful in the
event of loss or theft.
Be sure the OWNERS MANUAL remains
with the snowblower when sold. It ontains
important pro edures for safe operation
of the snowblower.
2

SERIAL NUMBER LOCATION
Always give your dealer the serial number of your Compact Tractor Snowblower when ordering
parts or requesting service or other information.
The serial number plate is located as indicated. For future reference, please write the model and
serial number in the space provided below and complete the warranty pages which follow.
SE IAL NUMBE LOCATION
It is the responsibility of the purchaser and all operator's to read and understand this
manual. It has been prepared to assist in the safe operation and suitable maintenance of
this implement. The information is applicable to the product at the time of manufacture
and does not include modifications or updates made thereafter.
Model Number__________________________
Serial Number________________________
3

Please enter information below and SAVE FOR FUTURE REFERENCE
SNOWBLOWER WARRANTY
SHEYENNE TOOLIN & MANUFACTURIN warrants each new product to be free from defects in material
and workmanship. This warranty is applicable only for the normal service life expectancy of the machine or
components, not to exceed twelve consecutive months from the date of delivery of the new SHEYENNE
TOOLIN & MANUFACTURIN product to the original purchaser.
enuine SHEYENNE TOOLIN & MANUFACTURIN replacement parts and components will be warranted
for 90 days from date of purchase, or the remainder of the original equipment warranty period, whichever is
longer.
Under no circumstances will it cover any merchandise or components thereof, which in the opinion of the
company, has been subject to negligent handling, misuse, alteration, an accident, or if repairs have been made
with parts other than those obtainable through SHEYENNE TOOLIN & MANUFACURIN .
Our obligation under this warranty shall be limited to repairing or replacing, free of charge to the original
purchaser, any part that in our judgment shall show evidence of such defect, provided further that such part shall
be returned within thirty (30) days from date of failure to SHEYENNE TOOLIN & MANUFACTURIN .
This warranty shall not be interpreted to render us liable for injury or damages of any kind or nature to person or
property.
Except as set forth above, SHEYENNE TOOLING & MANUFACTURING shall have no obliga ion of
liabili y of any kind on accoun of any of i s equipmen and shall no be liable for special or consequen ial
damage. SHEYENNE TOOLING & MANUFACTURING makes no o her warran y, express or implied,
and, specifically, SHEYENNE TOOLING & MANUFACTURING disclaims any implied warran y of
merchan abili y of fi ness for a par icular purpose. Some s a es or provinces do no permi limi a ions or
exclusions of implied warran ies of inciden al or consequen ial damages, so he limi a ions or exclusions in
his warran y may no apply.
This warranty is subject to any existing conditions of supply, which may directly affect our ability to obtain
materials or manufacture replacement parts.
SHEYENNE TOOLIN & MANUFACTURIN reserves the right to make improvements in design or changes
in specifications at any time, without incurring any obligations to owners of units previously sold.
No one is authorized to alter, modify or enlarge neither this warranty nor the exclusions, limitations and
reservations.
I have read and understand the above instructions and warranty. Warranty is invalid until all three copies are
completed and signed. Customer copy retained, dealer copy in dealer's possession and manufacturer's copy
returned.
Date Purchased _________________ Dealership ________________________
Model Number _________________ Serial Number _____________________
Customer Signature ______________________________ Date _____________________________
Dealer Signature _________________________________ Date _____________________________
Customer Copy

Please enter information below and SAVE FOR FUTURE REFERENCE
SNOWBLOWER WARRANTY
SHEYENNE TOOLIN & MANUFACTURIN warrants each new product to be free from defects in material and
workmanship. This warranty is applicable only for the normal service life expectancy of the machine or components, not to
exceed twelve consecutive months from the date of delivery of the new SHEYENNE TOOLIN & MANUFACTURIN
product to the original purchaser.
enuine SHEYENNE TOOLIN & MANUFACTURIN replacement parts and components will be warranted for 90 days
from date of purchase, or the remainder of the original equipment warranty period, whichever is longer.
Under no circumstances will it cover any merchandise or components thereof, which in the opinion of the company, has
been subject to negligent handling, misuse, alteration, an accident, or if repairs have been made with parts other than those
obtainable through SHEYENNE TOOLIN & MANUFACURIN .
Our obligation under this warranty shall be limited to repairing or replacing, free of charge to the original purchaser, any
part that in our judgment shall show evidence of such defect, provided further that such part shall be returned within thirty
(30) days from date of failure to SHEYENNE TOOLIN & MANUFACTURIN .
This warranty shall not be interpreted to render us liable for injury or damages of any kind or nature to person or property.
Except as set forth above, SHEYENNE TOOLING & MANUFACTURING shall have no obliga ion of liabili y of any
kind on accoun of any of i s equipmen and shall no be liable for special or consequen ial damage. SHEYENNE
TOOLING & MANUFACTURING makes no o her warran y, express or implied, and, specifically, SHEYENNE
TOOLING & MANUFACTURING disclaims any implied warran y of merchan abili y of fi ness for a par icular
purpose. Some s a es or provinces do no permi limi a ions or exclusions of implied warran ies of inciden al or
consequen ial damages, so he limi a ions or exclusions in his warran y may no apply.
This warranty is subject to any existing conditions of supply, which may directly affect our ability to obtain materials or
manufacture replacement parts.
SHEYENNE TOOLIN & MANUFACTURIN reserves the right to make improvements in design or changes in
specifications at any time, without incurring any obligations to owners of units previously sold.
No one is authorized to alter, modify or enlarge neither this warranty nor the exclusions, limitations and reservations.
I have read and understand the above instructions and warranty. Warranty is invalid until all three copies are
completed and signed. Customer copy retained, dealer copy in dealer's possession and manufacturer's copy
returned.
Date Purchased _________________ Dealership ________________________
Model Number _________________ Serial Number _____________________
Customer Signature ______________________________ Date _____________________________
Dealer Signature _________________________________ Date _____________________________
Dealer Copy

SNOWBLOWER WARRANTY
SHEYENNE TOOLING & MANUFACTURING warran s each new produc o be free from defec s in ma erial and
workmanship. This warran y is applicable only for he normal service life expec ancy of he machine or componen s, no o
exceed welve consecu ive mon hs from he da e of delivery of he new SHEYENNE TOOLING & MANUFACTURING produc
o he original purchaser.
enuine SHEYENNE TOOLIN & MANUFACTURIN replacement parts and components will be warranted for 90 days from date of
purchase, or the remainder of the original equipment warranty period, whichever is longer. Warranty is not applicable for normal wear
and usage.
Under no circumstances will it cover any merchandise or components thereof, which in the opinion of the company, has been subject to
negligent handling, misuse, alteration, an accident, or if repairs have been made with parts other than those obtainable through
SHEYENNE TOOLIN & MANUFACTURIN .
Our obligation under this warranty shall be limited to repairing or replacing, free of charge to the original purchaser, any part that in our
judgement shall show evidence of such defect, provided further that such part shall be returned within thirty (30) days from date of failure
to SHEYENNE TOOLIN & MANUFACTURIN .
This warranty shall not be interpreted to render us liable for injury or damages of any kind or nature to person or property.
Except as set forth above, SHEYENNE TOOLIN & MANUFACTURIN shall have no obligation of liability of any kind on account of
any of its equipment and shall not be liable for special or consequential damage. SHEYENNE TOOLIN & MANUFACTURIN
makes no other warranty, express or implied, and, specifically, SHEYENNE TOOLIN & MANUFACTURIN disclaims any implied
warranty of merchantability of fitness for a particular purpose. Some states or provinces do not permit limitations or exclusions of
implied warranties of incidental or consequential damages, so the limitations or exclusions in this warranty may not apply.
This warranty is subject to any existing conditions of supply, which may directly affect our ability to obtain materials or manufacture
replacement parts.
SHEYENNE TOOLIN & MANUFACTURIN reserves the right to make improvements in design or changes in specifications at any
time, without incurring any obligations to owners of units previously sold.
No one is authorized to alter, modify or enlarge neither this warranty nor the exclusions, limitations and reservations.
I have read and understand the above instructions and warranty. I have also read the owner’s manual and understand all safety
precautions. Warran y is invalid un il all hree copies are comple ed and signed. Cus omer copy re ained, dealer copy in he
dealer's possession and he manufac urer's copy re urned.
______________________________________________________________________________________________________________
Date Purchased _________________________________ Dealership ___________________________________
Model Number _________________________________ Serial Number ________________________________
Customer Information: Name (Please Print) ___________________________________________________________
Address _____________________________________________________________________
City ____________________________, State ________________, Zip Code _____________
E-Mail (If Applicable) _________________________________________________________
Signature _____________________________________________, Date _________________
Dealer Signature _________________________________ Date ____________________________________
Manufacturer Copy
PLEASE ENTER INFORMATION BELOW AND RETURN TO SHEYENNE TOOLING AND MANUFACTURING
Please return via; fax, regular mail or e-mail; to:
fax number – [phone]
address --
Sheyenne Tooling and Manufac uring
PO Box 647
Coopers own, ND 58425
e-mail – warran [email protected]

TABLE OF CONTENTS
DESCRIPTION PAGE
Model Number(s) 1
Dealer Information 2
Serial Number Location 3
Warranty Pages
Table of Contents 4
Introduction 5
Safety Symbol 6
Safety Reasons 7
Safety 8
Safe Operating 9, 10 & 11
Safety Sign off Form 12
Machine Components for Earlier Design Models 13
Machine Components for Current, Redesigned Models 500 & 600 14
Electrical Diagram 15
Hookup, Physical – Hydraulic Electrical 16
Compact Tractor Hydraulic System – Common to 500 & 600 17
Hydraulic System 18
Installation Instructions for Hydraulic Pump 19
Operating, General – Deflector – Chute Rotation – Ground Speed 20
Mechanical Specification 21
Maintenance 22
Shear Protection & Bolt Torque Specifications 23
Lubricating & Trouble Shooting 24
Hydraulic System Trouble Shootng Guide 25
Parts & Index Section / (See this section for pages 27 through 44) 26
4

1 INTRODUCTION
Congratulations on your choice of a Sheyenne Manufacturing, Compact Tractor(CT Snowblower.
This equipment has been designed and manufactured to meet the needs of a wide variety of
discerning users.
Safe, efficient and trouble free operation of your snowblower requires that you and anyone else who
will be operating or maintaining it, read and understand the Safety, Operation, Maintenance and
Trouble Shooting information contained within the Operator's Manual.
COMPACT TRACTOR SNOWBLOWER
This manual covers the models 500 CT and 600 CT Snowblower made by Sheyenne Manufacturing.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your
Sheyenne/Westgo dealer if you need assistance, information or additional copies of this manual.
OPERATOR ORIENTATION - The directions left and right, as mentioned in the manual, are seen
from the tractor driver's seat.
5

THE SYMBOL SHOWN BELOW IS USED TO
CALL YOUR ATTENTION TO INSTRUCTIONS
CONCERNING YOUR PERSONAL SAFETY
BE ALERT! Your Safety i involved
6
