Siemens SIMATIC Field PG P4 User manual

Preface, Contents
Important Notes 1
Getting Familiarized with the
SIMATIC Field PG P4 2
Configuring And Operating The
SIMATIC Field PG P4 3
SIMATIC Field PG P4 Expansions 4
Configuring the SIMATIC
Field PG P4 5
Error Diagnostics 6
Hardware Information 7
Reinstallation of the Software 8
Appendices
ESD Guidelines
A
Technical Specifications
B
Glossary, Index
Field PG P4
Manual
Edition 08/2004
A5E00180080-04
SIMATIC

AChapterChapterOChapter
Index-2 FieldPG P4
EWA4NEB 780 6023-01
!Danger
indicates that death, severe personal injury or substantial property damage will result if proper precautions
are not taken.
!Warning
indicates that death, severe personal injury or substantial property damage can result if proper
precautions are not taken.
!Caution
indicates that minor personal injury can result if proper precautions are not taken.
Caution
indicates that property damage can result if proper precautions are not taken.
Notice
draws your attention to particularly important information on the product, handling the product, or to a
particular part of the documentation.
Qualified Personnel
Repair, maintenance and servicing of device only to be carried out by qualified personnel. Qualified
persons are defined as persons who are authorized to commission, to ground and to tag circuits,
equipment, and systems in accordance with established safety practices and standards.
Correct Usage
Note the following:
!Warning
This device and its components may only be used for the applications described in the catalog or the
technical description, and only in connection with devices or components from other manufacturers which
have been approved or recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set up, and installed
correctly, and operated and maintained as recommended.
Trademarks SIMATIC, SIMATIC HMIand SIMATIC NETare registered trademarks of SIEMENS AG.
Third parties using for their own purposes any other names in this document which refer to trademarks
might infringe upon the rights of the trademark owners.
Safety Guidelines
This manual contains notices intended to ensure personal safety, as well as to protect the products and
connected equipment against damage. These notices are highlighted by the symbols shown below and
graded according to severity by the following texts:
We have checked the contents of this manual for agreement
with the hardware and software described. Since deviations
cannot be precluded entirely, we cannot guarantee full
agreement. However, the data in this manual are reviewed
regularly and any necessary corrections included in
subsequent editions. Suggestions for improvement are
welcomed.
Disclaimof LiabilityCopyright WSiemens AG 2004 All rights reserved
The reproduction, transmission or use of this document or its
contents is not permitted without express written authority.
Offenderswill be liable for damages. All rights, including rights
created by patent grant or registration of a utility model or
design,are reserved.
Siemens AG
Organization Group Automation and Drives
Division Industrial Automation Systems
P.O. Box 4848, D- 90327 Nuernberg SiemensAG 2004
Technical data subject to change.
Siemens Aktiengesellschaft A5E00180080-04

iii
SIMATIC Field PG P4 Manual
A5E00180080-04
Preface
Purpose of the Manual
This manual contains all the information you need for commissioning and using the
SIMATIC Field PG P4 programming device.
It is intended both for programming and testing/debugging personnel who
commission the device itself and connect it with other units (automation systems,
further programming devices) as well as for service and maintenance personnel
who install expansions or carry out fault/error analyses.
Where is this Manual Valid?
This manual is valid for all supplied variations of the SIMATIC Field PG P4 and
describes the state of delivery as of August 2004.
Certifications, Standards and Approvals
Certifications
The device fulfils the following guidelines and certifications:
•EU guideline 73/23/EEC on low voltages
•EU guideline 89/336/EEC on electromagnetic compatibility
•Underwriters Laboratories (UL) to Standard UL 60950, 3rd Edition
•Canadian Standard Association (CSA) to Standard C22.2 No. 60950
Standards and Approvals
The device fulfils the requirements for the CE approval. Approvals for UL and CSA
are available.
Further information on the approvals, certificates, and licenses for your device is
provided in Chapter 1.
Incorporation into the Communications Environment
This manual forms part of the supplied DVD “Backup PG”.
For supplementary instructions on how to handle the software please refer to the
corresponding manuals.

Preface
iv SIMATIC Field PG P4 Manual
A5E00180080-04
Structure of the Manual
Chapters 1 to 5 of the manual contain the most important instructions for
commissioning and using the Field PG P4. Chapters 6 to 8 are reference sections
required in special situations.
Important Notes
This chapter contains information on security, certificates, guidelines and
approbations.
Familiarizing Yourself
Before you initially start using the Field PG P4, you should inform yourself about its
components and their functions in Chapter 2.
Configuration and Operation
Before you start to use your programming device, you should read about the
components and functions of the SIMATIC Field PG P4 in Chapter 3.
Installation
Chapter 4 describes the basic steps necessary for commissioning the Field PG P4.
This chapter also contains instructions for working with submodules and memory
cards for programmable logic controllers and additional interfaces.
Expansion
Chapter 4 describes how to expand your SIMATIC Field PG P4 (for example,
installation of memory expansions). Please observe the safety instructions in this
section.
Configuration
Modifications made to the system hardware may make it necessary for you to
adapt the original hardware configuration. This is described in Chapter 5.
Error/fault diagnostics
Chapter 6 explains how to deal with simple faults and problems that you can
diagnose and, in some cases, eliminate yourself.
Reference data
Chapter 7 contains information about hardware addresses, interrupt assignments,
and connecting cables.
Reinstalling the Software
If it does happen that you need to reinstall the software you can find the
procedures in Chapter 8.
ESD guidelines
The guidelines on the handling of electrostatic-sensitive devices are particularly
important for service and maintenance technicians who are installing expansion
units or carrying out error analysis with the SIMATIC Field PG P4.

Preface
v
SIMATIC Field PG P4 Manual
A5E00180080-04
Glossary
The glossary defines and explains important terms.
Alphabetical index
The alphabetical index will help you to find passages in the text relating to
important terms and keywords quickly and reliably.
Conventions
The abbreviation PG oder device is also used within this manual for the product
designation SIMATIC Field PG P4 P4.
Further Support
If you have questions related to the use of the products which are not answered in
this manual, please consult your Siemens representative in your local agency. You
will also find your representatives for repairs and spare parts at
http://www.siemens.com/automation/partner
Trainingscenter
Siemens offers a number of training courses to familiarize you with the SIMATIC
S7 automation system. Please contact your regional training center or our central
training center in D 90327 Nuremberg, Germany for details.
Telephone: [phone].
Internet: http://www.sitrain.com

Preface
vi SIMATIC Field PG P4 Manual
A5E00180080-04
A&D Technical Support
Worldwide, available 24 hours a day:
Johnson City
Nuernberg
Beijing
Technical Support
Worldwide (Nuernberg)
Technical Support
24 hours a day, 365 days a year
Phone: [phone]
Fax: [phone]
E-Mail: adsupport@
siemens.com
GMT: +1:00
Europe / Africa (Nuernberg)
Authorization
Local time: Mon.-Fri. 7:00 to 17:00
Phone: [phone]
Fax: [phone]
E-Mail: adsupport@
siemens.com
GMT: +1:00
United States (Johnson City)
Technical Support and
Authorization
Local time: Mon.-Fri. 8:00 to 17:00
Phone: [phone]
Fax: [phone]
E-Mail: simatic.hotline@
sea.siemens.com
GMT: –5:00
Asia / Australia (Beijing)
Technical Support and
Authorization
Local time: Mon.-Fri. 8:00 to 17:00
Phone: [phone]
Fax: [phone]
E-Mail: adsupport.asia@
siemens.com
GMT: +8:00
The languages of the SIMATIC Hotlines and the authorization hotline are generally German and English.

Preface
vii
SIMATIC Field PG P4 Manual
A5E00180080-04
Service & Support on the Internet
In addition to our documentation, we offer our Know-how online on the internet at:
http://www.siemens.com/automation/service&support
where you will find the following:
•The newsletter, which constantly provides you with up–to–date information on
your products.
•The right documents via our Search function in Service & Support.
•A forum, where users and experts from all over the world exchange their
experiences.
•Your local representative for Automation & Drives via our representatives
database.
•Information on field service, repairs, spare parts and more under “Services”.

Preface
viii SIMATIC Field PG P4 Manual
A5E00180080-04

ix
SIMATIC Field PG P4 Manual
A5E00180080-04
Contents
Preface iii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Important Notes 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Safety Instructions 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Certificates, Directives and Declarations 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Certification for the USA, Canada and Australia 1-3. . . . . . . . . . . . . . . . . . . . .
1.4 Cleaning and Transporting the Field PG 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Getting Familiarized with the SIMATIC Field PG P4 2-1. . . . . . . . . . . . . . . . . . . . . . . .
2.1 Components of the SIMATIC Field PG P4 2-2. . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Keyboard 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Touchpad 2-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 LED displays 2-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 On/Off Pushbutton (Power Button) 2-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Drives 2-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6.1 Floppy Disk Drive 2-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6.2 Hard Disk Drive 2-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6.3 Optical Drive 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 External Power Unit and Battery 2-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Configuring And Operating The SIMATIC Field PG P4 3-1. . . . . . . . . . . . . . . . . . . . .
3.1 Unpacking and Setting Up the SIMATIC Field PG P4 3-2. . . . . . . . . . . . . . . . .
3.2 Connecting to the Power Supply 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Battery Operation 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Commissioning 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1 Cold Start of the SIMATIC Field PG P4 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.2 Restart of the SIMATIC Field PG P4 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Panel “Field PG” 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6 Connecting Peripheral Devices 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.7 Working with SIMATIC S5 Memory Submodules 3-16. . . . . . . . . . . . . . . . . . . . .
3.8 Working with SIMATIC Memory Cards 3-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.9 Working with Micro Memory Cards 3-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.10 Working with PC Cards 3-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.11 Connecting the Field PG P4 to a SIMATIC S5 Network 3-20. . . . . . . . . . . . . . .

Contents
xSIMATIC Field PG P4 Manual
A5E00180080-04
3.12 Connecting the Field PG P4 to a SIMATIC S7 Network (MPI/DP) 3-21. . . . . .
3.13 Networking the Field PG P4 with Other Stations on PROFIBUS 3-23. . . . . . .
3.14 Ethernet (RJ45 Ethernet Interface) 3-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 SIMATIC Field PG P4 Expansions 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Installing Memory Expansion Submodules 4-2. . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Processor Upgrade 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Replacing Backup Battery 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Configuring the SIMATIC Field PG P4 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Changing the Device Configuration with SETUP 5-2. . . . . . . . . . . . . . . . . . . . .
5.2 The Main Menu 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 The Advanced Menu 5-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 The Security Menu 5-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5 The Power Menu 5-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.6 The Boot Menu 5-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7 The Version Menu 5-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.8 The Exit Menu 5-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Error Diagnostics 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Hardware Information 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.1 System Resources 7-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2 Interface Pinout 7-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3 Patch Cords 7-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Reinstallation of the Software 8-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.1 Cause / Remedy 8-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2 Restoring the Hard Disk (Data Deleted) 8-3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2.1 Restoring the Software to Delivery Condition Using the Restore CD 8-3. . . .
8.2.2 Creating Partitions under Windows NT 8-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2.3 Creating Partitions under Windows 2000/XP Professional 8-5. . . . . . . . . . . . .
8.3 Installing Drivers and Software 8-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.4 Installing the Recovery CD for Microsoft Windows NT 8-6. . . . . . . . . . . . . . . .
8.5 Installing the Recovery CD for Microsoft Windows 2000 8-8. . . . . . . . . . . . . .
8.5.1 Installing Drivers under Windows 2000 8-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.6 Installing the Recovery CD for Microsoft Windows XP 8-10. . . . . . . . . . . . . . . .
8.7 Installing the SIMATIC Software 8-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
xi
SIMATIC Field PG P4 Manual
A5E00180080-04
A Guidelines for Handling Electrostatically-Sensitive Devices (ESD) A-1. . . . . . . . .
A.1 What is ESD? A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2 Electrostatic Charging of Persons A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.3 General Protective Measures Against Electrostatic
Discharge Damage A-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B Technical Specifications B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glossary Glossary-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index Index-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
xii SIMATIC Field PG P4 Manual
A5E00180080-04

1-1
SIMATIC Field PG P4 Manual
A5E00180080-04
Important Notes
1.1 Safety Instructions
!Caution
The safety instructions given on the backside of the title page of this manual must
be observed. Before adding to the Field PG P4’s functionality by expanding the
hardware configuration (see Chapter 4) observe the relevant safety instructions.
Notes on Inserting and Removing Modules
Modules containing electrostatically sensitive devices (ESDs) can be identified by
the following label:
Please observe and carefully follow the guidelines mentioned below when handling
modules equipped with electrostatically sensitive devices:
•Always discharge your body’s static electricity before handling modules
equipped with ESDs (for example by touching a grounded object).
•Devices and tools must be free of static electricity.
•Always pull the power plug and disconnect the battery before connecting or
disconnecting modules (containing ESDs).
•Touch modules fitted with ESDs by their edges only.
•Never touch wiring posts or printed conductors on modules (containg ESDs).
1

Important Notes
1-2 SIMATIC Field PG P4 Manual
A5E00180080-04
1.2 Certificates, Directives and Declarations
Notes on the CE Symbol
The following applies to the SIMATIC product described in this operating
instruction:
EMC Directive
This product fulfils the requirements for the EC directive 89/336/EEC on
“electromagnetic compatibility” and the following fields of application apply
according to this CE symbol:
Field of Application Requirement for
Emitted Interference Noise Immunity
Residential and commercial areas and
small businesses. EN 61000-6-3: 2001 EN 61000-6-1: 2001
Industry EN 61000-6-4: 2001 EN 61000-6-2: 2001
The product is also compliant with the Standards EN 61000-3-2:2000 (Harmonic
currents) and EN 61000-3-3:1995 (Voltage fluctuation and flicker).
Low Voltage Directive
This product fulfils the requirements for the EC directive 73/23/EEC on
“low voltage” and was tested to EN60950.
Declaration of Conformity
The EC declarations of conformity and the documentation relating to this are
available to the authorities concerned, according to the above EC directive, from:
Siemens AG
Bereich Automation and Drives
A&D AS RD4
Postfach 1963
D-92209 Amberg
Tel.: [phone]
Fax: [phone]
Observing the Setup Guidelines
The setup guidelines and notes on safety given in the manual must be observed
on startup and during operation.

Important Notes
1-3
SIMATIC Field PG P4 Manual
A5E00180080-04
Connecting peripheral devices
Noise immunity when connected to industrial standard peripheral devices conforms
with the requirements of EN 61000-6-2:2001.
ISO 9001 Certificate
The quality assurance system for the whole product process (development,
production, and marketing) fulfills the requirements of ISO 9001 (corresponds to
EN29001: 1987).
This has been certified by the German society for the certification of quality
management systems (DQS).
EQ-Net certificate no.: 1323-01
Software License Agreement
The PG is shipped with the software already installed. Please observe the relevant
license agreements.
1.3 Certification for the USA, Canada and Australia
Security
One of the following markings on a device is indicative of the corresponding
approval:
Underwriters Laboratories (UL) to the UL 60950 standard, 3rd Edition.
Canadian Standard Association (CSA) to Standard C22.2. No. 60950

Important Notes
1-4 SIMATIC Field PG P4 Manual
A5E00180080-04
EMC
USA
Federal Communications Commission
Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Shielded Cables
Shielded cables must be used with this equipment to maintain compliance with
FCC regulations.
Modifications
Changes or modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
Conditions of Operations
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Canada
Canadian Notice
This Class B digital apparatus complies with Canadian ICES-003.
Avis Canadien
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Australia
This product meets the requirements of the AS/NZS 3548 Standard.

Important Notes
1-5
SIMATIC Field PG P4 Manual
A5E00180080-04
1.4 Cleaning and Transporting the Field PG
Cleaning
To prolong the lifetime of your Field PG and use it free of trouble, do not expose it
without cause to dust nor use aggressive cleaning agents to clean it.
•You can clean the display and the keyboard with customary screen cleaning
tissues.
•The other case parts can be cleaned with a common household detergent.
Caution
Never spray cleaning liquids directly onto the device and prevent ingress of liquid.
Transportation
Despite of the rugged structure of the Field PG, its installed components are
sensitive against severe vibration and impact. You can contribute to trouble-free
operation by taking a few precautions for the transportation.
•Ensure that the computer does not access anymore drives before you prepare
it for transportation.
•Remove all floppy disks or CD-ROMs from the respective drive.
•Switch off the PG (refer to Chapter 2.5).
•Disconnect all external devices from your PG.
•Close the display and the interface covers on the rear side of the device.
•Use the handle and for short transports.
•Pack the Field PG and all accessories into the supplied rucksack case if you
are going to transport it over greater distances.
You should use the original package for the shipment of the programming device.

Important Notes
1-6 SIMATIC Field PG P4 Manual
A5E00180080-04

2-1
SIMATIC Field PG P4 Manual
A5E00180080-04
Getting Familiarized with the SIMATIC
Field PG P4
What do you find in this Chapter?
This chapter briefly presents the most important components of the SIMATIC
Field PG P4. Get familiarized with these elements before you start to commission
the PG.
Chapter Overview
Section Description Page
2.1 Components of the SIMATIC Field PG P4 2-2
2.2 Keyboard 2-9
2.3 Touchpad 2-13
2.4 LED displays 2-14
2.5 On/Off Pushbutton (Power Button) 2-15
2.6 Drives 2-17
2.7 External Power Supply and Battery 2-20
2

Getting Familiarized with the SIMATIC Field PG P4
2-2 SIMATIC Field PG P4 Manual
A5E00180080-04
2.1 Componentsof the SIMATIC Field PG P4
View with closed display
123
1 SystemĆLEDs
The system LEDs (battery status , device On , drives , MPI/DP MPI/D
P
and Memory Card ) indicate the status of the battery, unit, drives, MPI/DP and
Memory Card interface.
These LEDs are also visible when the display is closed. The drive access displays
are arranged on the right hand side of the corresponding drives.
For detailed information on these LED displays refer to Chapter 2.4 of the
electronic manual.
2 KeyboardĆLEDs
The keyboard LEDs display the current status of the shift keys Num Lock 1,
Caps Lock Aand Scroll Lock =O . When the unit is booting, the displays of
these keys flicker briefly. The keyboard is ready for operation.
3 Device Handle
Folding handle for transporting the device.
!Caution
Always stand the PG on its base. If you place it down on the interface side there is
a risk that it will fall over and that sensitive components of the unit get damaged.
