Model S-68Y
Headset Instructions
The S-68Y series headsets are adjusted at the factory for immediate use with all
current standard radio systems in general aviation aircraft. Headsets equipped
with two plugs are the standard conguration. The headphone plug is the larger
diameter plug and should be inserted into the headphone jack (.250” standard
monaural jack). The mic plug is the smaller diameter plug and should be inserted
into the microphone jack (.206” standard microphone jack).
The headband is adjustable through a full range of motion, or the locking nuts
may be tightened to allow you to custom t the headset. Place the headset over
your head, adjust the slides up until minimum pressure is felt on the top of your
head. The headset is now properly adjusted. For maximum noise attenuation, the
clamping pressure has been set at the factory. Releasing the clamping pressure
by bending the headband is not advised, because loss of attenuation will result.
Note: If an especially large headband is needed, it may be ordered from Sigtronics.
The microphone boom is fully adjustable and will rotate 180 degrees for use on
the left or right side of the head. Make sure you are speaking into the side of the
mic labeled “Talk” or substantial loss of gain will occur. Microphone placement
should be at the corner of the mouth, approximately ¼” from the lips.
When you rst connect the headset, turn the volume control on the headset up
to the full clockwise position, then adjust the listening volume with the audio
control of either your radio or intercom as appropriate. Passengers should also
turn their individual headset volumes up fully. Doing this allows for a full range of
adjustment for each passenger, since those with the most acute hearing can turn
their headset volume down, if necessary.
continued on back…
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in water
or any other liquid. Be especially careful not to allow the microphone to become
wet! Exposure to moisture may cause internal corrosion and failure and will void
your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thoroughly
and make sure it is completely dry before putting it back on.
To remove the windscreen, carefully grasp the windscreen lightly along its entire
length and remove from the microphone element being careful not to twist the
element itself.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited ve-year parts and labor warranty. Please see
the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: [phone]
E-mail: [e-mail]
Web Site: www.sigtronics.com

SIGTRONICS S-68Y HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1100049 GROMMET, 5/16 INCH, RUBBER 13 100366 WIRE, 2 CONDUCTOR, #24, BLACK, 28 INCHES 25 100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC
2100360 KNOB, BLACK, VOLUME 14 100515 YOKE, EAR CUP MOUNT, METAL, GOLD 26 100514 HEADBAND, METAL, GOLD, STANDARD
3100365 POTENTIOMETER, 2K 15 100597 NUT, HEX, 3/8-24, FLEX BOOM ADAPTER 27 100516 BRACKET, YOKE SUPPORT WITH TANG, GOLD
4100858 RECEIVER AND MOUNT, 300 OHM, MONO 16 100402 EAR SEAL, GEL FILLED 28 800192 PREAMP
5100108 SCREW, 4-40 X 1/4, THREAD FORMING 17 100610 CUSHION, HEADBAND, FOAM FILLED 29 800036 CABLE, HEADSET, MONAURAL
6800044 MICROPHONE & FLEX BOOM ASSEMBLY 18 900111 WINDSCREEN, MIC, 8 SERIES 30 100569 STRAIN RELIEF, CABLE
7100520 E-RING, EAR CUP TO YOKE RETAINER, GOLD 19 100373 SLIDE, YOKE BRACKET, LONG, NYLON 31 100579 CLIP, CLOTHING, HEADSET CABLE
8100524 NUT, HEX, 8-32, LOCKING, GOLD 20 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 32 100221 WIRE, JUMPER, #22, 4 INCHES
9100614 EAR CUP, PRINTED AND DRILLED, MIC & NON MIC SIDE 21 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH 33 100673 HEADBAND, METAL, GOLD, YOUTH
10 100362 CLIP, CROSS-OVER, WIRE, PLASTIC 22 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH 34 100674 OPTIONAL – HEADBAND, METAL, GOLD, LARGE
11 100522 SCREW, 8-32 X 1/2, PHILLIPS HEAD, GOLD 23 N/A HEAD BAND EXTRUSION, 6.25 IN., S-68Y 35 100369 OPTIONAL – EAR SEAL, FOAM FILLED
12 100521 SCREW, 8-32 X 3/8, PHILLIPS HEAD, GOLD 24 100258 CLIP, HEADBAND GUIDE, PLASTIC
