SISIL KR09 NF User manual

;
;
;
21
FEATURE CHART
CAUTION: 1. Be sure to check with your voltage, before inserting the power
supply cord into the socket.
2. Contact the earthing conductor to this unit with an attachment earthing
screw.
3. Don’t make it spill to this unit.
4. Don’t work with flammable spray, such as paining, near this unit.
5. Don’t put ignitable materials, such as benzine, L.P. Gas, alcohol, etc., into
this unit.
6. Be careful of the leakage of any gas equipment near this unit.
7. Be sure not to hold to the door of this unit by children.
8. Be sure not to reinsert the power supply cord within 5 minutes after release
it from socket. If not, a trouble may be occured to compressor.
Here are the features of your new refrigerator.
Take a moment to know all the features and convenience it was designed to
provide. Numbers match those in the illustration on page 1.
󱇲Ice tray
Fill tray 3/4 full to allow expansion of water during freezing. Place tray in freezer chest. To
release cubes, twist lid slightly.
󱇲Removable shelf
Shelves can be removed by pulling forward. The shelf can be placed at your desirable
position.
󱇲Crisper
May be used for fruit and vegetable storage. Both the crisper and its cover shelf are
removable for easy cleaning. Simply slide forward to remove.
󱇲Egg Pocket
Egg supporter in this pocket can be turned upside down.
May be used for small size goods.
󱇲Convertible Function
This refrigerator is designed to convert the function.
Refrigerator can be converted to refrigerator of ‘function off’
! ICE TRAY
@ FREEZER REMOVABLE
SHELF
# FREEZER TEMPERATURE
CONTROL KNOB
$ ICE BOX
% CHILLED CASE
^ REFRIGERATOR
TEMPERATURE
CONTROL KNOB
& LAMP COVER
* REMOVABLE SHELF
( GLASS SHELF
) VEGETABLE CASE
1 F POCKET (T)
2 F POCKET (U)
3 EGG CASE
4 EGG POCKET
5 R POCKET (MULT)
6 R POCKET (BG)
7 R POCKET (SM)
!
@
#
$
%
^
&
*
(
)
1
2
3
4
5
6
7

43
󱇲ECONOMIC FUNCTION
When you have small foods to stuff or the stuffed is already frozen enough, use this
function and you’ll save the electric power consumption.
󱇲OFF FUNCTION
When you want to use “FREEZER” only, set the “REFRIGERATOR CONTROL DIAL” at
“OFF”
Temperature is controlled automatically. The TEMPERATURE CONTROL at the inside of the
refrigerator and freezer section control the degree of cooling of each compartment.
Cleaners : Do not use harsh, abrasive cleaners, heavy-duty cleaners, or solvents on
any surface. These cleaners may cause cracking, discoloring or
scratching the surface.
Exterior : Wash with warm, soapy water, rinse and dry.
Use appliance polish or wax periodically to keep the exterior looking like new.
Door gasket : Clean at least twice a year with mild soap and water. Rinse and
dry. Apply a light film of petroleum jelly to the gaskets to keep
them soft.
Interior : Wash the liner with warm, soapy water, rinse and dry.
CAUTION
Location TEMPERATURE CONTROL
Leveling
To change temperature
Install refrigerator in a convenient location away from extreme heat and cold. Allow
sufficient clearance between the refrigerator and side wall so it is easy for refrigerator to
radiate heat. Refrigerator is not designed for recessed installation.
Level refrigerator so it rests solidly on the floor, without rocking. There are two
Adjustable foot, one at each front corner. Turn to the left to raise a corner, to the right to
lower it. Use shims under rear corners, if necessary.
󱇲If you want, the refrigerator door to close when not held open, adjust feets so that the
front of the refrigerator is raised. However, front corners must be level with each
other, and rear corners with each other.
NOTE: Make sure all packing meterial is removed. If the shipping tape has left a residue on
the door, clean it with isopropyl alcohol (most rubbing alcohol is this type).
Do not use a solvent, such as cleaning fluid, nor an abrasive cleanser.
1. Clean the refrigerator thoroughly: Wipe the outside with a soft dry cloth, the inside with
a damp cloth.
2. Set TEMPERATURE CONTROL at MED.
3. Connect the power supply cord.
You may want to adjust the control according to the season and your needs. When
adjusting the temperature:
󱇲Turn TEMPERATURE CONTROL toward MAX for colder temperature in refrigerator and
freezer sections, and toward MIN for warmer temperature in refrigerator and freezer
sections.
󱇲Allow approximately 2 hours for temperature to stabilize. Then check to see if further
adjustments are needed.
To Avoid The Risk of Electrical Shock or Death unplug the
power cord before replacing a burned out light bulb or
cleaning.
Freezer temperature control Refrigerator temperature control
MED.
MAX.
OFF
MIN.
MED.
MAX.
MIN.
;
;
;
HOW TO INSTALL
;
;
;
HOW TO CLEAN
;
;
;
HOW TO OPERATE
Starting your new refrigerator

MODEL NO
Before operating this
refrigerator, please
read this manual
carefully.
REFRIGERATOR
Instruction Manual
KR09 NF
5
When out of operating for a long time.
󱇲Remove the power supply cord.
󱇲Dry your refrigerator, opening the door for 2-3 days.
When you get ready to move
󱇲Securely fasten removable interior parts (or move and package them separately).
󱇲Do not lay your refrigerator horizontally, or compressor may be damaged.
If the refrigerator is not operating:
󱇲Is the power supply cord unplugged?
󱇲Is home fuse blown or circuit breaker off?
If refrigerator is warmer than usual:
󱇲Has the door been open frequently or for a long period?
󱇲Is refrigerator overcrowded preventing good air circulation?
󱇲Is the clearance between side and rear plate of the refrigerator and the wall allowed
sufficiently?
If there are unusual sounds:
󱇲Is refrigerator placed on the level?
󱇲Are foreign objects behind the refrigerator?
󱇲Are dishes on refrigerator shelves vibrating?
If so, re-arrange the dishes.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a simmilary qualified person in order to avoid a hazard.
When you need service; Before calling for service check
a few things noted below for yourself first.
;
;
;
WHAT TO DO...
