Sky Control SC8100 Instruction sheet

IP Monitoring systems
SC8100, SC8110, SC2100, SC2110
Configuration manual

Content
9
6
8
12
Product description
Document Overview
Related Documents
Additional Options
Mounting
Rack mount
Wall mount
Power cable and network cable connec-
tion
General connection of sensors and devices
Analog sensors connection
Chain connection of SC541, SC560
CAN sensors and CAN modules connection
SC408 sensor extension unit
SC450 airow and temperature unit
installation
Connecting 1-Wire reader
Connecting I-Touch Button
Connecting Proximity reader
Connecting relays
Connecting the load to SC8100
Connecting the load to SC8110
Connecting the device
Default network settings
User access and permissions
Administrator account, username and
password
User access
Settings recovery
Password recovery
Interface overview
Network settings
Determination of IP-address
Setting up time
Time zone
Time synchronization
Creating oor map plan
Sensor conguration
Creating groups of elements
Creating notications
Notication via E-mail
Notication via SNMP Trap
Notication via SMS
Macros in the notication text
Front and back panels
Master modules
Extension modules
Inventory
Introduction
Physical Description
Comparison charts & specications
Inventory
Installation
3
3
3
3
15
16
16
17
18
20
26
26
28
30
30
31
31
32
32
Initial Conguration
Quick Conguration
Connecting dry contact module
Inventory
Installation
Connecting GSM modem
Inventory
Installation
Connecting backup battery
Connecting USB camera
List of USB cameras
21
23
25
25
01

Creating ping
Creating timer
Adding IP camera
Adding logic schemes
Example of adding a logic scheme
Access control
Adding a key
Managing keys
Setting up GSM modem
Conguring GSM modem
SMS notications
SMS commands
Sending SMS from PC
Setting up CAN
Setting up dynamic DNS
34
35
35
35
37
37
40
41
Description
HTTP upgrade
FTP upgrade
Upgrade via USB
Restoring an appliance
Disposal
Battery replacement
Fuse replacement
Cleaning
Upgrade and restore options
Warranty
Cleaning, battery & fuse disposal and
replacement
42
42
42
43
43
45
45
45
46
47 Warranty period
02

Introduction
Product description
Sky Control appliances - monitoring units
SC8100, SC8110, SC2100 and SC2110 - are
the main Sky Control modules for monitor-
ing and environmental control. SC8100 and
SC8110 are used for IP monitoring or as a video
server for different premises, whereas SC2100
and SC2110 are used for small premises.
Main monitoring systems cannot not be con-
nected to each other. Instead, to increase the
number of sensors and appliances, extension
units (SC408) and embedded modules (SC16,
SC920) can be used. Each module has embed-
ded software and provides access to a system
via a browser using the IP address. The systems
support SNMP protocols, if you need to collect
all master modules data in one interface, you
can use a third-party SNMP software.
Document overview
The Installation and Quick Conguration Manual
describe how to install Sky Control main mod-
ules SC8100, SC8110, SC2100, SC2110 as well
as how to connect the module and to congure
the network settings. It shows how to connect
and use extension module SC408 and how
to mount and use embedded modules SC16,
SC920. After performing conguration proce-
dures described in this manual, you can access
the system from Firefox, Safari and Chrome
browser, perform additional conguration tasks
and begin to monitor the environment.
Analog sensors
Current loop converter
4-20 mA (SC420)
Temperature sensor
(SC500)
Outdoor temperature
sensor (SC501)
Related documents
U
nless otherwise noted, the following documen
-
tation is available on the CD provided with the
device or on the web page:
www.skycontrol.com.
S
ky Control User Guide contains all the informa
-
tion on the operation, management, and system
setup for one of the following main modules and
units: SC8100, SC8110, SC2100, SC2110,
SC408, SC16, SC920.
For support please visit our forum at
forum.skycontrol.com. For SNMP, API manu-
als and latest version of current manual please
visit our wiki at wiki.skycontrol.com.
Additional options
T
he following options are available for the appli
-
ance. For more information on any of these op-
tions, contact your Sky Control distributor from
which you have purchased Sky Control product.
03
Introduction
Sky Control web-interface is based on
HTML5, which is not supported by Inter-
net Explorer.

Analog sensors
Humidity sensor
(SC510)
AC voltage monitor
(SC520)
Access sensor (SC530)
Vibration sensor
(SC540)
Vibration sensor
(SC541). Chain con-
nection possible.
Smoke sensor
(SC560). Chain con-
nection possible.
PIR sensor (SC570)
Analog sensors
Leak sensor (SC590)
Cable leak sensor
(SC591)
CAN modules
Airow and tempera-
ture unit (SC450)
Analogue sensor mod-
ule (SC408)
Analogue, CAN
04
Introduction

Embedded modules
Dry contacts unit
(SC16)
GSM modem (SC920)
CAN sensors
PIR, vibration, tem-
perature CAN sensor
(SC470)
Smoke, humidity and
temperature CAN sen-
sor (SC460)
05
Introduction

Comparison charts & specications
Master modules
S
C2100, SC2110, SC8100, SC8110 and SC1108 are master modules and cannot connect to each
other. For scalability please use extension modules and embedded modules.
Remote Control SC8100 SC8110 SC2100 SC2110 SC1108
Device Management: Web, SNMP, manually via SMS
■ ■ ■ ■ ■
Access to sensors: Three-tiered access with login
■ ■ ■ ■ ■
Interface & Protocol support SC8100 SC8110 SC2100 SC2110 SC1108
Interface: Access via Firefox, Chrome, Safari browsers. IE is not
supported.
■ ■ ■ ■ ■
LAN: Ethernet 10/100 Mbit
■ ■ ■ ■ ■
Network protocols: DHCP, HTTP, HTTPS, SNMP, SMTP, SSL, FTP,
Syslog, CAN
■ ■ ■ ■ ■
OS: Linux 2.6.38
■ ■ ■ ■ ■
RAM: 64Mb
■ ■ ■ ■ ■
ROM: 128Mb FLASH
■ ■ ■ ■ ■
Software: Built-in software for events processing
■ ■ ■ ■ ■
Alert types: FTP, Syslog, SMTP or SNMP, SMS (GSM modem is
ordered separately)
■ ■ ■ ■ ■
Pings: Built-in function for ping
■ ■ ■ ■ ■
LEDs: 4 green: ACT, CN1, CN2, ERR
■ ■ ■ ■ ■
LEDs: latching relais 4 4
□ □
8
Clock: Built-in clock with time synchronization
■ ■ ■ ■ ■
Watchdog: Built-in watchdog timer
■ ■ ■ ■ ■
Power SC8100 SC8110 SC2100 SC2110 SC1108
Power input: 12V. Fuse at the inlet
□ □ ■ □ □
Power input: 240V C14 C14
□
C14 C20
Fuse: Fuse at the inlet 0,315A 10A
□
0,315A 16A
Output voltage: 240V
□
4 * C13
□ □
8 * C13
Max. power consumption: 25W 25W 20W 20W 20W
Max. total load current:
□
10А
□ □
16А
The maximum load current on the relay: 5А 10А
□ □
10А
Power reservation: 12V, built-in voltage monitor, voltage range
9-12.6V
■ ■ ■ ■ ■
■
Built-in □ None ● Extension ○ Not extandable
06
Charts and specications

Inlets/Outlets SC8100 SC8110 SC2100 SC2110 SC1108
Ethernet: 100Mbit
■ ■ ■ ■ ■
USB: USB 2.0
■ ■ ■ ■ ■
Mini USB AB: USB 2.0 HS
■ ■ ■ ■ ■
Analog port: 6P4C for connection of any analog sensor 8 8 1 1 1
CAN BUS: 2 x 6P6C for connection of up to 8 CAN sensors on each
BUS. Fuse protection on each line.
■ ■ ■ ■ ■
Relay outputs: latching relays 240V*5A 4
□ □ □ □
Power output: latching relays 240V*10A
□
4
□ □
8
1-Wire: I-Touch button or proximity reader
■ ■ □ □ □
Environmental characteristics SC8100 SC8110 SC2100 SC2110 SC1108
Operating temperature: 0 to 70 °C
■ ■ ■ ■ ■
Storage temperature: –25 to 85 °C
■ ■ ■ ■ ■
Operating humidity: 0 to 90 %, non-condensing
■ ■ ■ ■ ■
Storage humidity: 0 to 95 %, non-condensing
■ ■ ■ ■ ■
Other Features SC8100 SC8110 SC2100 SC2110 SC1108
Installation: 19” 19” Desktop 19” 19”
Dimensions (L x W x H) in mm: 440*44*75 440*44*75 215*44*65 440*44*65 440*44*85
Weight: 1,5 kg 1,5 kg 1,2 kg 1,2 kg 1,8 kg
Scalability (modules are ordered separately) SC8100 SC8110 SC2100 SC2110 SC1108
Extension modules SC408, SC450: Allows to increase the number
of sensors in the system. It is possible to connect up to 8 CAN sen-
sors and / or 8 modules to one CAN bus.
● ● ● ● ●
Dry contacts module SC16: Built-in into the master module
● ● ● ● ○
GSM modem SC920: Built-in into the master module
● ● ● ● ●
External Memory SC8100 SC8110 SC2100 SC2110 SC1108
SD card: SD SD MicroSD MicroSD MicroSD
■ Built-in □ None ● Extension ○ Not extandable
07
Charts and specications

Power SC408 SC450
Power input: 12V. Recommended to use at all times.
■ ■
Power over CAN: Possible if module is the only one in a chain (or rst in a chain of 2 or 3 sensors) with
CAN cable length no longer than 2m.
■ ■
Inlets/Outlets SC408 SC450
Analog: 8*6P4C for connection of analog sensors
■ □
CAN: 2*6P6С for connection of up to 8 CAN sensors on each BUS. CAN sensors and modules connect in a
chain. Fuse protection on each line.
■ ■
Air ow heat sensors: Response time 2 min, recovery time 1 min; Temperature measurement range -40
... +100 ° C, accuracy 2 ° C
□ ■
Other Features SC408 SC450
Installation: At the bottom there are four mounting holes for mounting screws
■ ■
Dimensions (L x W x H) in mm: 110×68×40 86×48×25
Weight: 0.6 kg 0.6 kg
Extension modules
A
ll Sky Control main/master modules allow connection of extension units through CAN ports. It is
possible to connect up to 8 CAN sensors/units to one CAN bus.
08
Charts and specications
■ Built-in □ None

Physical description
1“LAN” - Ethernet 10/100 Base-T port,
provides Ethernet connection.
• LEDs - “yellow” (status) and “green”
(trafc) shows the network trafc.
The status LED: ashes green when
system starts up, shows the connec-
tion state (constant green light - the
connection is established, blinking
green - the connection attempt).
2“USB” - type A USB-port 2.0, is required
for USB ash drive to upgrade an appli-
ance.
3“HS” - type miniAB USB-port 2.0, required
to connect a USB camera or to restore an
appliance.
4“Reset” - resets the appliance.
5“SD” - SD card connector with ejector,
needed to store data.
6LEDs: “ACT” - indicates appliance status,
“CN1” - indicates CAN1 bus trafc, “CN2”
- indicates CAN2 bus trafc, “ERR»” -
indicates error and trafc.
7“CAN” - two equivalent digital connectors
RJ12 for the connection of CAN sensors
and CAN extensions on a CAN bus, with
auto-sensing.
8“TR” - CAN terminator, required for a con-
nection of a large amount of sensors or for
a long distance connection of CAN sensors.
Front panel SC8100 and SC8110
Front panel SC2100 and
SC2110
Front panel SC408
Front panel SC450
09
Physical description

9“A1..A8” - 8 RJ12 analog sensor inputs
with auto-sensing.
10 “SIM” - connector with an ejector, used
when GSM modem is installed inside of the
appliance to connect SIM card.
11 “Outputs 1..4” - 4 relays status indicators.
12 “1-Wire” - RJ9 connector for 1-Wire
Proximity type or I-touch readers with
auto-sensing.
13 “SMA” - connector, used when GSM mo-
dem is installed inside of the appliance to
connect GSM antenna.
14 “PWR” - for connection of external power
12V. Internal input “+”.
Back panel SC8100
Back panel SC8110
Back panel SC2110
10
Physical description

15 “AC line” - power input 240V. IEC C14
connector.
16 “Fuse” - type 5*20mm
17 “Output 1..4” - AC output voltages from
relays. Connector IEC C13. Maximum out-
put power for each relay - 10A*240V.
18 “RLY1...RLY4” - 4 relays output connec-
tors. The relays maximum power output
- 5A * 240V.
19 “DC 12V” - backup power socket, to con-
nect a battery or a battery backup.
Back panel SC450
Back panel SC2100
Back panel SC408
11
Physical description
20 “Dry contacts” - empty slot for dry con-
tacts module SC16, used to connect dry
contacts on doors, windows, etс.
21 “Fan sensors 1...6” - Inputs for airow
sensors.

Package content
Make sure that the contents of the delivery
meet the following conguration. Report a miss-
ing or damaged component to your supplier. If
damage occurred during transportation, contact
the appropriate delivery service.
Inventory
Inventory
Master module
SC8100, SC8110,
SC2100, SC2110
Extension module
SC408, SC450
19” rack brackets - 2 pcs.
SC8100, SC8110,
SC2110
M3 x 8 Phillips at-head
screws - 6 pcs.
SC8100, SC8110,
SC2110
Inventory
1.8-m EU-Schuko / C13
power cord
SC8100, SC8110,
SC2110
1.8-m IEC C13/C14
power cord
SC8110
RJ45 1m patch cable
SC8100, SC8110,
SC2100, SC2110
USB-miniUSB cable
SC8100, SC8110,
SC2100, SC2110
RJ11 6P4C 2m CAN cable
SC408, SC450
12
Package content

Inventory
Relay terminal plug 5.08
mm - 1 pc for 8 pins and
1 pc for 4 pins
SC8100
CD-ROM with documen-
tation and software
SC8100, SC8110,
SC2100, SC2110
Conguration manual
SC8100, SC8110,
SC2100, SC2110
Warranty card
SC8100, SC8110,
SC2100, SC2110
Self-adhesive rubber foot
- 4 pcs
SC8100, SC8110,
SC2100, SC2110, SC408,
SC450
Inventory
Backup battery 3.5mm
terminal plug
SC8100, SC8110,
SC2100, SC2110
12V adapter
SC2100, SC408, SC450
Dry contacts board
(embedded module)
SC16
M3*5mm bolts. 3pcs.
SC920, SC16
BH10 cable
SC16
GSM modem SC920
(embedded module)
SC920
13
Package content

Inventory
Antenna
SC920
Antenna wire with spac-
ers
SC920
BH16 cable
SC920
Airow sensor (TS1) - 2
pcs
SC450
Relay terminal plugs - 3
pcs
SC16
14
Package content

Installation
Mounting
The units (SC8100, SC8110, SC2110) can be
installed in the front or rear of the rack. It takes
up to 1U of 19” rack! Unit SC2100 is mounted
on the wall. All units can be put on the shelf us-
ing self-adhesive rubber feet.
When installing, consider the following condi-
tions:
When installing the unit in a 19” rack,
make sure that there is no uneven me-
chanical loading so as not to create a dangerous
situation. You should not use the unit as a shelf
or hang it uncommitted.
Rack mount
Select a place of unit installation inside the rack.
The system takes up 1U of rack. Set to the
desired location and tighten the bolts on the
spacer nuts.
Connect the unit only after checking the
grounding of the circuit.
You must install the unit in place, where
the ambient temperature corresponds to
the values listed under “Specications”. Keep in
mind that the temperature of the unit increases
in cramped conditions, please keep track of the
temperature on the internal temperature sensor.
Try to install the unit in such a way as to allow
for normal air circulation required for the normal
functionality of the unit.
To avoid equipment damage fasten all the
screws all the way!
Wall mount
Use the following diagrams for dimension refer-
ences for wall mount.
SC2100 mini-master module:
To avoid equipment damage fasten all the
screws all the way!
15
Installation
Do not connect homemade sensors and
devices with unknown functions to the
unit!
Do not connect the device to ungrounded
outlets! Check the outlet and make sure
they are grounded when using the extension
cords.
Before applying power to the device, read
its electrical characteristics in order to
avoid the power supply circuit overloading.
Power cable and Network cable
connection

1For SC8100, SC8110, SC2110, connect
the appropriate power cord to the unit AC
line input. For SC2100 plug in the power
adapter that was in the package content.
2Connect unit’s Ethernet port using network
cable to the switch.
3Plug the power cable into the power
source.
Analog sensors connection
Connect analog sensor by a supplied RJ-11
(6P4C) cable to any of 8 analog ports “A1 .. A8”
. Determination of the sensor type and connec-
tion will occur automatically.
This procedure applies to the following sensors,
which are supported by the appliance and are
connected to the analog ports:
Type Analog sensors
Current Loop transceiver (SC420)
Temperature sensor (SC500)
Outdoor temperature sensor
(SC501)
Humidity sensor (SC510)
AC voltage detector (SC520)
Access sensor (SC530)
General connection of sensors and devices
16
Installation

If strong electromagnetic interferences
are present, we recommend to use 3-pair
cable CAN FTP for sensor connection!
Sensors are shown on p.3-5
Type Analog sensors
Vibration sensor (SC540)
Vibration sensor (SC541).
Chain connection possible.
Smoke sensor (SC560).
Chain connection possible.
PIR sensor (SC570)
Leak sensor (SC590)
Cable leak sensor (SC591)
Chain connection of SC541, SC560
SC541 and SC560 are the only analog sensors
that allow chain connection. All the sensors in
such series are seen by the system as one sen-
sor. One chain can have up to 10 sensors.
CAN sensors and CAN
modules connection
Connect CAN sensors to any CAN port CN1 or
CN2 on the monitoring system using a CAN
FTP cable supplied. CAN sensors can also be
connected to the port of another CAN sensor or
CAN module which are connected on the CAN
bus. Determination of the module and its con-
nection is done through web-interface.
17
Installation
This procedure applies to the following sensors,
which are supported by the appliance and are
connected to the CAN ports:
You can connect maximum up to 8 CAN
sensors and CAN modules together
on one CAN bus!
Type CAN sensors
Smoke, temperature and hu-
midity sensor (SC460)
PIR, temperature and vibration
sensor (SC470)

Type CAN modules
Airow unit (SC450)
CAN and
Analogue Analog sensor unit (SC408)
Sensors are shown on p.3-4
SC408 sensor extension unit
installation
General connection diagram:
Dimensions for wall mounting:
Dimensions for wall mounting:
General connection diagram p.19
SC450 airow and temperature unit
installation
Connecting 1-Wire reader
I-Touch or 1-Wire Proximity readers can be con-
nected to the port “1-Wire” using RJ9 (4P4C)
connector. The reader is determined automati-
cally. Only SC8100 and SC8110 have “1-Wire”
port.
Check the PCB. DIP switch 2 should be in “ON”
position.
18
Installation
