SMAJAYU R26-V2 User manual

SMAJAYU(SHENZHEN) CO.,LTD
1/16
R26-V2 Operation Guide
SMAJAYU(SHENZHEN) CO.,LTD
China
Version 1.0

SMAJAYU(SHENZHEN) CO.,LTD
2/16
Table of Contents
1. Abstract.................................................................................................... 7
2. R26 Device.............................................................................................. 8
2.1 Device List.....................................................................................8
2.2 Device Hardware...........................................................................8
2.3 Mainly Hardware Introduce.......................................................... 9
3. Device Performance.............................................................................. 12
3.1 Tracking Satellite.........................................................................12
3.2 Positioning Accuracy.................................................................. 12
3.3 Electrical Characteristics.............................................................12
3.4 System Configuration..................................................................12
3.5 Data Port......................................................................................13
3.6 Physical Index............................................................................. 13
3.7 Environmental Performance....................................................... 13
4. Device Operation...................................................................................14
4.1 Charge..........................................................................................14
4.2 Data Obtain..................................................................................14
4.3 Data Export..................................................................................14

SMAJAYU(SHENZHEN) CO.,LTD
3/16
Figure List
Figure 1 R26-V2................................................................................ 8
Figure 2 Data Cable.............................................................................8
Figure 3 Power Adapter.......................................................................9
Figure 4 Radio Antenna.......................................................................9
Figure 5 Device Box............................................................................9
Figure 6 R26 Main Body...................................................................10
Figure 7 Ports.................................................................................... 10
Figure 8 Bottom.................................................................................11
Figure 9 Data Cable...........................................................................11
Figure 10 Hardware Connect for Charge..........................................14
Figure 11 Data Export....................................................................... 15
Figure 12 USB Identify.....................................................................15
Figure 13 Data Doc........................................................................... 16

SMAJAYU(SHENZHEN) CO.,LTD
4/16
Table List
Table 1 Device List..............................................................................8
Table 2 Tracking Satellite..................................................................12
Table 3 Positioning Accuracy............................................................12
Table 4 Electrical Characteristics......................................................12
Table 5 System Configuration...........................................................12
Table 6 Data Port...............................................................................13
Table 7 Physical Index...................................................................... 13
Table 8 Environmental Performance................................................ 13

SMAJAYU(SHENZHEN) CO.,LTD
5/16
Disclaimer
This document provides information about the products of
SMAJAYU(SHENZHEN) CO.,LTD This document does not transfer the company's
or any third party's patents, trademarks, copyrights or ownership or any rights or
licenses under it by implication, the prohibition of opposition or other forms.
Except for the responsibilities stated in the terms and conditions of the sale of its
products, the company does not assume any other responsibilities. SMAJAYU does
not make any express or implied guarantee of the sale and or use of its products,
including the suitability of the product for a specific purpose, the marketability, or the
infringement of any patent rights, copyrights or other intellectual property rights.
SMAJAYU may make changes in product specifications and product descriptions at
any time without prior notice.
The company will not be liable for any loss caused by your being able to use or not
using this system (product).
Copyright © 2015-2020, SMAJAYU(SHENZHEN) CO.,LTD All rights reserved.

SMAJAYU(SHENZHEN) CO.,LTD
6/16
Preface
Congratulations on the purchase of your new SMAJAYU R26-V2 Device. This
guide will help you to understand how SMAJAYU Device works.
SMAJAYU Support:
SMAJAYU(SHENZHEN) CO.,LTD will supply technical support and upgrade
service for client science from the date of purchase.
Headquarters
Room 213-214, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road,
Taoyuan Street, Nanshan District, Shenzhen, China,518055
Clients Feedback：
Please send your feedback to [e-mail]

SMAJAYU(SHENZHEN) CO.,LTD
7/16
1. Abstract
R26-V2 is a high precision positioning device using for static data processing.
research and development by SMAJAYU(SHENZHEN) CO.,LTD with features of
easy operation and easy curry.
This paper mainly introduces R26 device accessories, connect and operation step for
static data obtain.

SMAJAYU(SHENZHEN) CO.,LTD
8/16
2. R26 Device
2.1 Device List
Table 1 Device List
No.
Name
Quantity
Note
1
R26-V2
1
2
Data Cable
1
3
Power Adapter
1
4
Radio Antenna
1
Stick
5
Device Box
1
2.2 Device Hardware
Ⅰ. R26-V2
Height 139mm.
The maximum diameter 136mm.
Figure 1 R26
Ⅱ. Data Cable
Figure 2 Data Cable

SMAJAYU(SHENZHEN) CO.,LTD
9/16
Ⅲ. Power Adapter
Input: British Standard Plug.
Output: DC Plug.
Figure 3 Power Adapter
Ⅳ. Radio Antenna
Frequency: 450-470MHZ.
Dimension: 280mm.
Figure 4 Radio Antenna
Ⅴ. Device Box
Figure 5 Device Box
2.3 Mainly Hardware Introduce
Ⅰ. R26 Main Body

SMAJAYU(SHENZHEN) CO.,LTD
10 /16
Figure 6 R26 Main Body
：Still recording button: Press and hold for 4 seconds to turn on or off the still
recording mode.
：Recorder light: red, flashes when the static recording mode is turned on,
otherwise off.
：Satellite light: red, RTK Fix is always on.
：
Differential light: red, flashes once per second when the radio or 4G module
receives or sends data, and does not flash when there is no differential data.
：Power light: three-color light, light blue when charging, green when fully
charged, red when working, and red flashing when the battery is less than 5%.
：Power button: Press and hold for 2 seconds to turn on or off.
Figure 7 Ports
9 PIN aviation plug, including power supply, COM RS232, CONFIG
RS232.
UHF radio antenna interface

SMAJAYU(SHENZHEN) CO.,LTD
11 /16
Figure 8 Bottom
Fixed Thread: Five-eighth inch thread.
Ⅱ. Data Cable
Figure 9 Data Cable
POW/COM plug which connects to R26-V2.
DC power supply plug.
DB9 data configuration plug.
USBD raw data export and save plug.

SMAJAYU(SHENZHEN) CO.,LTD
12 /16
3. Device Performance
3.1 Tracking Satellite
Table 2 Tracking Satellite
Tracking
Characteristics
BDS B1I/B2I/B3I/B1C/B2a /B2b*
GPS L1C/A/L2P（Y）/L2C /L5
GLONASS G 1/G 2/G3
Galileo E1/E5a/E5b /E6*
QZSS L1, L2, L5
Data Update
Frequency
default 1Hz, the highest 20Hz
3.2 Positioning Accuracy
Table 3 Positioning Accuracy
RTK Accuracy
Flat: ±（8 + 1.0 × 10^-6 ×D）mm
Elevation: ±（ 15 + 1.0 × 10^-6 × D）mm
（D is the distance between measured points）
Point positioning Plane: 1. 5m
Elevation: 2. 5m
3.3 Electrical Characteristics
Table 4 Electrical Characteristics
Battery
Characteristics
Built-in battery，non-replaceable，7.2V/10000mAh.
Work Time
18h (mobile station), 11h (base station)
Input Voltage
9-36V DC
3.4 System Configuration
Table 5 System Configuration
Built-in
storage
8GB
Bluetooth
Bluetooth 4.0
Built-in Radio
0.5W / 1W，Maximum 2W power.
Radio Protocol
CSS (Lora)

SMAJAYU(SHENZHEN) CO.,LTD
13 /16
3.5 Data Port
Table 6 Data Port
1 Nine-pin Aviation
Plug
Direct charging, data transmission. (power supply +
double RS232)
1 RADIO TNC Plug
Use for Radio Antenna Connect.
3.6 Physical Index
Table 7 Physical Index
Dimension
140mm×141mm×88mm
Weight
1.03 KG
3.7 Environmental Performance
Table 8 Environmental Performance
Operating
Temperature
-45 ℃～ +75 ℃
Storage
Temperature
-55℃ ～ +85℃
Protection
IP67

SMAJAYU(SHENZHEN) CO.,LTD
14 /16
4. Device Operation
This chapter mainly introduces how to charge the device, data obtain and data export.
4.1 Charge
Hardware connect show as figure 10.
Figure 10 Hardware Connect for Charge
Note: POW indicator light flashes during charging and keep bright when finishing
charge.
4.2 Data Obtain
：Still recording button: Press and hold for 4 seconds to turn on or off the still
recording mode.
4.3 Data Export
Hardware connect show as figure 11.

SMAJAYU(SHENZHEN) CO.,LTD
15 /16
Figure 11 Data Export
Find identify USB from the computer when finish hardware connected. (Figure 12)
Figure 12 USB Identify

SMAJAYU(SHENZHEN) CO.,LTD
16 /16
Figure 13 Data Doc
Show as Figure 13, those three documents are the raw data when automatic record.
Data automatic record when changing to A5 mode.
