SNAP LF-35M User manual
Version 1-22.10.21
USER MANUAL
Page 2of 10
CONTENTS
MANUAL
Camera specifications ……………………………………….. 3
Camera parts…………………………………………………………….. 3
Loading film …………………………………………………………………. 4
Inserting battery……………………………………………………….. 5
Using the flash……………………………………………………………. 5
Rewinding film……………………………………………………………. 6
Shooting & handling tips…………………………………….. 6 - 7
User safety & Compliance ………………………………… 8-9
Limited warranty………………………………………………………. 10
Page 3of 10
CAMERA SPECIFICATIONS
Optical lens:
28mm ƒ8, 1 element
Focusing:
Focus free, 1.2m - ∞
Shutter speed:
1/120s
Film transport
Manual wind and rewind
View finder:
Field = 70%
Flash:
Built in Flash, 1 – 3m flash range
Power source:
1 x AA Alkaline battery
Camera weight:
110g
Camera size:
118(w) x 66(H) x 42(D) mm
Material:
ABS (recycling number 7)
CAMERA PARTS
Page 4of 10
LOADING FILM
Loading film is super easy when you know how! Follow these simple steps and
you’ll be a pro in no time! If you’d prefer to follow along to a video, then head over
to www.lensfayre.com/snapmanual
Press the latch (N) in the direction of the arrow and open the
camera’s back door (C). Lift the film rewind crank (L) and
place a new roll of film in the film chamber (H)
Step 1
Step 2
Ensure that the film lays flat against the centre of the camera
and close the camera’s back door
Continue to advance the film by turning the film advance
wheel (B) until it stops. Press the shutter button. Repeat
this procedure one more time. The Film counter (I) will
now show the number ‘1’ and the camera is ready for
taking pictures
Step 4
Step 3
Push the rewind crank (L) back into place. Pull the film tip
from the film canister and hook the second hole onto the
film take up spool (D). Slightly advance the film by turning
the film advance wheel (B).
Page 5of 10
This camera can be used without a battery, but if you would like to use the flash
then you’ll need to load 1X AA battery, as shown below:
USING THE FLASH
We recommend using the flash in low light situations (i.e.: indoors / outside at
night / on cloudy days etc).
INSERTING BATTERY
Open the battery cover (G) in the direction of the arrow. Insert one ‘AA’ alkaline
battery into the battery chamber (O).
Make sure the battery is inserted according to the correct polarity. The correct
polarity (the ‘+’ and the ‘-‘ ends of the battery) is indicated on the outside of the
battery cover.
Switch the flash button (0) to the ‘’ position and wait for the flash ready Light (K) to
glow red.
The flash has a recycling time of up to 15 seconds. This simply means that you may
have to wait up to 15 seconds for the flash to fully charge between shots.
TIP:
We recommend turning the flash back to the off position when not in use to preserve both
battery power and the longevity of the flash bulb.
Page 6of 10
REWINDING FILM
SHOOTING & HANDLING TIPS
Step 1
Step 2
After all the pictures are taken, press the rewind button (F)
located at the bottom of the camera. Turn the film rewind crank
(L) clockwise until all film is rewound back into the film canister
Open the camera’s back door (C), Lift up the film rewind
crank (L) and remove the film for processing!
For the best results, stand at least 1 Metre (3 feet) from the subject and
take photos in sunny or partly sunny weather. When taking pictures,
keep the sun at your back
Page 7of 10
The Snap LF-35M is a fun easy to use camera that is designed for casual,
everyday photography.
In order to get the most out of your Snap and ensure that it’s running smoothly for
as long as possible, we have 5 top tips for optimum use:
TIP 1:
Ensure the flash is switched to the off position when not in use.
TIP 2:
Remove the battery from the camera when not in use. This is to
preserve battery life and prevent potential battery leakage.
TIP 3:
Do not use the Snap in rainy, wet and / or highly humid conditions.
Excess moisture may cause damage to the circuit board.
TIP 4:
When winding on film on do not force the wind-on dial. If you find
there is resistance, then it is likely that you have come to the end of
your film roll and you should rewind the film using the method
outlined on
page 6
of the Snap Camera Manual
TIP 5:
When rewinding film, please ensure that you hold the rewind release
button in for the duration. Do not force the rewind lever. If you force it,
you will risk snapping your Snap
If you follow these tips, then the Snap should have a long and healthy life and
produce tons of awesome photos for you!
Page 8of 10
USER SAFETY & COMPLIANCE
Warning
This symbol indicates that ignoring this safety
guideline could cause serious personal injury
Caution
This symbol indicates that ignoring this safety
guideline could cause minor or medium personal
injury or loss of property
Warning:
Do not disassemble or modify this camera. This camera contains high voltage
elements, with a risk of electrical shock.
If the internal elements of the camera become exposed due to dropping or
otherwise damaging the camera, do not touch the exposed elements due to
risk of electrical shock.
Do not aim the camera directly at the sun or other strong light sources during
use. Doing so may cause loss of eyesight or cause vision to become impaired.
Caution:
Do not place your finger over the flash when discharging the flash. There is a
risk of burning yourself.
Do not cover the flash with fabric or clothing when discharging the flash.
Discolouration may occur.
Page 9of 10
Keep wires and other metal objects away from the + (plus) and – (minus)
contacts of the battery compartment.
COMPLIANCE
Statement(s) of compliance
UK:
This product is in conformity with the following EU directives and standards:
Electromagnetic
Compatibility
Regulations 2016
EN 55032: 2015+A11:2020
EN 55035: 2017
The UKCA symbol is a directive of
conformity mark of the United Kingdom
EU:
This product is in conformity with the following EU directives and standards:
EN 55032: 2015+A11:2020
EN 55032: 2015+A11:2020
EN 55035: 2017
The CE symbol is a directive of
conformity mark of the European Union
UK / EU Importer:
LensFayre ltd, Unit 107, 1 Hanley Street, Nottingham, NG1 5BL
The full Declaration of conformity can be made available upon request, by
contacting: hello@lensfayre.com
Page 10 of 10
LIMITED WARRANTY
The Snap LF-35M camera is not designed to be repaired or refurbished. If you
believe you have a functional issue, please contact hello@lensfayre.com, within
30 calendar days of purchase with a description of the issue and proof of
purchase to request a replacement. LensFayre will issue replacements at their
sole discretion upon assessment of the issue presented. This warranty does not
affect your statutory rights.
Copyright © LensFayre Ltd 2021. LensFayre®Ltd, registered in England and Wales |
Company number: 12355203.
