Solt GGSFLW600 User manual

E S S E N T I A L S FOR LIFE
User
Manual
Front Load
Washing Machine
MODEL/S
GGSFLW600
GGSFLW700
V 1.1 | 0822

2
For future reference, please record the following information which can be found
on the rating plate and the date of purchase which can be found on your sales invoice.
STORE DETAILS
STORE NAME

ADDRESS

TELEPHONE

PURCHASE DATE

PRODUCT DETAILS
MODEL NO.

SERIAL NO.*

Purchase Details

Welcome Congratulations on purchasing
your new Front Loader!
The Sôlt brand is proudly
distributed within Australia
by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual
for information regarding your product’s parts and labour
warranty, or visit us online at www.residentia.group
At Residentia Group, we are customer obsessed and our
Support Team are there to ensure you get the most out
of your appliance. Should you want to learn more about
your front loader features, and importantly taking care
of your appliance when cleaning, our Support Team are
here to help.
You can use our online Support Centre at anytime by
visiting http://support.residentiagroup.com.au, or you can
contact us via calling us on 1300 11 HELP (4357).
It is important that you read through the following use and
care manual thoroughly to familiarise yourself with the
installation and operation requirements of your appliance
to ensure optimum performance.
Again, thank you for choosing an Sôlt appliance and we
look forward to being of service to you.
Kind Regards,
The Residentia Team
Residentia Group
—
Head Office.
165 Barkly Ave
Burnley
Victoria 3121
Australia
—
ACN.
600 546 656
—
Online.
residentia.group
Sôlt
—
Online.
www.solt.house
—
Instagram.
/solt.house
—
Facebook.
/solt.appliances

4
This page
is intentionally
left blank

Contents 2Purchase Details
3Welcome
6Safety Instructions
8Installation
10 Your Washing Machine
13 Quick Start Guide
14 Operating Instructions
20 Cleaning & Maintenance
22 Troubleshooting
24 Technical Specifications
25 Attach Your Receipt
26 Warranty Information
Sôlt recommends the use of original spare parts. When contacting our customer service team, please ensure
that you have the following information at hand (which can be found on your appliances’ rating plate).
— Model Number
— Serial Number
T . 1300 11 4357 | E. [e-mail]
Customer Care

6
Safety Instructions
CONDITIONS OF USE
• This appliance is intended to be used in household
and similar applications such as farm houses or by
customers in serviced apartments, holiday apartments
and other residential type of environments.
SAFETY INSTRUCTIONS
• Before the installation and use of the appliance,
carefully read the supplied instructions.
• The manufacturer is not responsible if an incorrect
installation and use causes injuries and damages.
• Always keep the instructions with your appliance for
future reference.
WARNING: To prevent any damages to your
and others’ life or property, you have to follow
the safety notes.
WARNING: Caution, risk of fire!
CHILDREN & VULNERABLE PEOPLE SAFETY
WARNING: Risk of suffocation, injury
or permanent disability.
• This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction for the operation of the appliance by a
person who is responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appliance door
when it is open. Check the machine before
every operation.
• Cleaning and user maintenance shall not be made by
children without supervision.
• Glass door may be very hot during the operation.
Keep kids and pets far away from the machine during
the operation very wet rooms as well as in the rooms
with explosive or caustic gas.
INSTALLATION
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the
appliance.
• Old hose-sets are not to be reused and the new
hose-sets supplied with the appliance are to be used.
• Before any maintenance the device, unplug the
appliance from the mains.
• Make sure that the water and electrical devices must
be connected by a qualified technician in accordance
with the manufacturer’s instructions and local safety
regulations.
• Plug must be accessible after installation.
• Make sure that the floor where you install the
appliance is flat, stable, heat resistant and clean.
• Always remove the plug and turn off the water supply
to the appliance after every use.
• This washing machine is for indoor use only.
• Sharp and rigid items such as coins, nails and screws
may cause serious damage to this appliance- always
ensure pockets of clothing are empty.
• Always ensure that the drum has drained all water
before opening the appliance door. If water is visible,
do not open the appliance door.
• Do not install the appliance behind a lockable door,
a sliding door or a door with a hinge on the opposite
side, where the appliance door cannot be fully opened.
• Always be careful when you move the appliance
because it is heavy. Always wear safety gloves.
• Always move the appliance vertically.
• The rear surface of the appliance must be put against
the wall.
• The openings must not be obstructed by a carpet.
• This appliance should not be installed in a bathroom
or similar wet rooms, as well as rooms with explosive or
caustic gases.
• Washing machines with a single water inlet and should
only be connected to the cold water supply outlet.
Models featuring two inlet valves should be correctly
connected to the hot and cold water outlets.
• The appliance can be installed as freestanding or
below the kitchen counter with correct space. This
washing machine is not intended to be built-in.
• When the appliance is put in its permanent position,
check if it is fully level with the aid of a spirit level. If it is
not, adjust the feet until it is.
• The max. inlet water pressure, in pascals. The min. inlet
water pressure, in pascals.
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
Maximum inlet pressure 1.0Mpa
Minimum inlet pressure 0.05Mpa

7
ELECTRICAL CONNECTION
WARNING: Caution, risk of fire and electrical shock!
• To ensure your safety, power plug must be inserted
into an earthed three-pole socket. Check carefully and
make sure that your socket is properly and reliably
earthed.
• Plug must be accessible after installation.
• Make sure that the electrical information on the rating
plate agrees with the power supply. If not, contact an
electrician.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and
to the mains cable. Should the appliance power supply
cable need to be replaced, this must be carried out by
our Service Centre.
• Connect the mains plug to the mains socket only at the
end of the installation. Make sure that there is access
to the mains plug after the installation. Do not connect
the appliance plug with a power connection board.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains plug with
wet hands.
• This appliance complies with the E.E.C. Directives.
CARE & CLEANING
WARNING: Risk of injury or damage to the appliance.
• Before maintenance, deactivate the appliance and
disconnect the mains plug.
• Do not use water spray and steam to clean the
appliance.
• Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
TRANSPORT
• Always move the appliance cautiously. Do not use the
machine door or the handle of the detergent dispenser,
to lift the appliance.
• Transportation bolts should be reinstalled within the
machine by a specialised person, prior to transporting
the appliance.
• Ensure that all accumulated water is drained from the
appliance before moving.
PRODUCT DISPOSAL
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children
and pets to get closed in the appliance.
APPLIANCE USE
WARNING: Risk of fire, explosion, electric shock or
damage to the appliance.
• Use this appliance in a household only.
• Before operating this appliance, ensure that all
packaging and transport bolts have been removed.
Otherwise, serious damage can occur to the appliance.
• Before washing any clothes for the first time, the
washing machine should be operated for one whole
cycle without any clothes inside.
• Always unplug the machine and turn off the water
supply after use. The max. inlet water pressure, in
pascals. The min. inlet water pressure, in pascals.
• Do not climb up or sit on top of the appliance.
• Do not change the specification of this appliance.
• If you use fabric softener or similar products, obey the
instructions on the packaging.
• Do not sit or stand on the open door.
• Obey the maximum load volume of 8.0 kg
(refer to the “Program chart” chapter).
• Ensure all objects are removed from clothing pockets
such as lighters and matches.
• Please only use front load washing machine
detergents. Flammable and explosive or toxic solvents
are forbidden for use with this appliance. Gasoline and
alcohol should not be used as a detergent.
• Do not wash or dry articles that have been cleaned in,
washed in, soaked in, or dabbed with combustible or
explosive substances( such as wax, oil, paint, gasoline,
degreasers, dry-cleaning solvents, kerosene, etc.)
This may result in fire or explosion. If they have been in
contact with any of the above, beforehand thoroughly
rinse items of washing by hand.
• Never wash carpets or rugs within the appliance.
• Never refill the water by hand during washing.
• Be careful to avoid burns when the machine drains hot
washing water.
• After a wash program completes, please wait two
minutes before opening the door.
• If a tumble dryer is installed on top of the washing
machine, use the suitable stacking kit. The stacking kit,
available from your authorised vendor, can be used
only with the appliance specified in the instructions,
supplied with the accessory. Read it carefully before
installation (Refer to the Installation leaflet).
• Never lean against the machine door.
• Please do not close the machine door with excessive
force and if you find it difficult to close the door, ensure
that the clothing load isn’t excessive.
• Glass door may become hot during operating.

8
Installation
INSTALLATION POSITIONING
• Ensure that your appliance is installed on solid and flat ground, in a level position.
• Please do not place the appliance on a slope, soft carpet or wooden floor.
• Avoid positioning the appliance in direct sunlight or where there is inadequate
ventilation.
• Your appliance should only be installed within an internal environment.
Do not install the appliance outdoors.
• Room temperature must be above 0°C.
UNPACKING THE WASHING MACHINE
WARNING:
• Packaging material (e.g. Films, Styrofoam) can be dangerous for children.
• There is a risk of suffocation! Keep all packaging well away from children.
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing. Make sure the small triangle
foam is removed with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
REMOVING THE TRANSPORTATION BOLTS
WARNING: Before using the appliance, the transport bolts must be removed from the
backside of this machine. Please take the following steps to remove the bolts:
• Loosen all 4 bolts with a spanner
• Remove the bolts including the rubber parts and keep them for future use.
• Close the holes using the cover caps.
• Keep the transport bolts for future use.
Note:
You’ll need the transport bolts again if you move the appliance,
so make sure you keep them in a safe place.
LEVELLING THE WASHING MACHINE
WARNING: The lock nuts on all four feet must be screwed tightly
against the housing.
• If the floor is obviously uneven, your appliance feet need to
be adjusted. If your appliance isn’t level, it will cause your
appliance to vibrate, and potentially move from its position.
• Once you’ve positioned your washing machine, press down
from the top in all four corners to ensure that it’s completely
stable (i.e. not rocking in any direction). Also use a spirit level
to ensure that it is completely level in all directions.
• Should you need to make adjustments, use a spanner to turn
the appliance legs until it makes contact with the floor.
Turn the leg using one hand and then fasten the nut up
against the appliance cabinet, to lock the leg in place.
• After making any adjustments to the appliance legs,
re-check to ensure it is level and no rocking occurring.
Installation
Before installing the machine, the location characterized
follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0℃
5.Keep far away from the heat resources such as coal or gas.
as
Unpacking the washing machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Make sure the small triangle
foam is removed with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
Please take the following steps to remove the bolts:
1.Loosen 4 bolts with spanner and then remove them.
2.Stop the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Remove transport bolts
•
•
Stability is important to prevent the product from
wandering!
Make sure that the product should not stand on
the power cord.
Warning!
•
•
Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
There is a risk of suffocation ! Keep all packaging
well away from children.
Warning!
•
• product
you
You must remove the transport bolts from the backside before using the product.
You’ll need the transport bolts again if you move the , so make sure
keep them in a safe place.
Warning!
INSTALLATION
w
w
W> 20mm
Installation area
9
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!

9
CONNECT THE WATER SUPPLY HOES PIPE
WARNING:
• To prevent leakage or water damage, follow the
instructions in this chapter
• Do not kink, crush, modify or sever the water inlet hose!
Connect the water supply hose to the water inlet valve and
a water tap with cold water as indicated.
Note: Connect manually, do not use tools.
Check if the connections are tight.
POSITION THE DRAIN HOSE
The outlet hose (used to drain the discharged water) is to
be ideally connected to the relevant waste pipe, although
it can also be positioned to drain into a sink/trough.
Note that the outlet hose has a minimum outlet
position of 60cm and a maximum position of 100cm
(as illustrated below).
WARNING:
• If you are positioning the outlet hose to drain into a
sink or trough, please ensure that it is fixed in place
and that the sink remains unblocked at all times.
• If drain hose is too long, do not force it into washing
machine as it will cause abnormal noises.
APPLYING THE ACOUSTIC SPONGE
Note: Please make sure to assemble the acoustic sponges,
which can effectively reduce the noise caused by
the machine while working, in order to provide you
with a more peaceful and quiet living environment.
1. Lie the machine laid on the floor, using some soft
material like foam or clothes between the machine
and floor for protection;
2. Stick the 2× longer sponges to the longer bottom
edges of machine, and the 2× shorter sponges to the
shorter bottom edges.
Warning!
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
Min.60cm
100cm
Max.
Warning!
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
11
Warning!
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
Min.60cm
100cm
Max.
Warning!
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
11
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
10
10
INSTALLATION
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
100cm
Max.
Warning!
！！Warning! ！
Min.60cm
• Please make sure to assemble the acoustic sponges, which can effectively
reduce the noise caused by the machine while working, in order to provide
you with a more peaceful and quiet living environment.
Note!
Acoustic Sponge
2x
2x
1. Get the machine laid on the floor, using some soft material like foam or clothes
between the machine and floor for a protection;
2. Stick the 2x longer sponges to the longer bottom edges of machine, and the 2x
shorter sponges to the shorter bottom edges.

10
CONTROL PANEL
Your Washing Machine
PRODUCT COMPONENTS
Water supply hose
Top cover
Control panel
Service panel
Power supply cord
Drain hose
Drum
Detergent dispenser
Door
Note: The images in this user manual are for explanatory purposes only.
Your Front Loader Washing Machine may appear slightly different, however the functions remain the same.
1
32 5
1Program selection dial:
Different washing cycles can be selected according to
the users need and the type of laundry to be washed.
2Display:
The display shows the setting, estimated program
time remaining, options and status messages of your
washer. This display will remain on through the cycle.
3 Additional function buttons:
These buttons are used for setting additional functions
to your cycle.
4 Drum Clean
Sprecially set in the machine to clean the drum
and tube.
5 Start/Pause button:
Press this button to start of pause the drying cycle.
Press for 3 seconds to use the Reload function.
4
Control Panel
OPERATIONS
Power
Product is on/off.
Start/Pause
Press the button to start or pause the
washing cycle.
Programmes
Available according to the laundry type.
Option
This allows you to select an additional
function and will light when selected.
1
1
3
1
2
4
Display
The display shows the settings, estimated time remaining, options, and status messages
for your washer. The display will remain on through the cycle.
5
3
2
1
1
4
5
Pre Wash
B
Child Lock
D
Display
A
Wash Time Delay Time
Speed Error
End Temp.
A
JC
Door Lock
C
Delay
E
H
Speed Wash
F
Night Wash
G
Extra Rinse
H
SpaCare
I
Pre Wash-Wash-Rinse-Spin
J
BD E F G
I
15

11
DISPLAY SCREEN
A F G
B C D E
H
ADisplay EDrum Clean
BChild lock FPre Wash
CDoor lock GExtra Rinse
DDelay HMute
ACCESSORIES
1Transport hole plug 2Supply hose cold water 3Owner’s manual 4Acoustic sponges 5Quick Start Guide
7
Accessories
Product Description
• The product line chart is for reference only, please refer to real product as
standard.
Note!
Drum
Power supply cord
Control panel
Detergent dispenser
Service filter
Door
Water supply hose
Top cover
Drain hose
INSTALLATION
4 x Cover caps 1 x Supply hose
cold water
1 x Owner’s manual Acoustic
sponge
(Optional)

12
DETERGENT DISPENSER
The detergent drawer of your washing machine
is split into three compartments:
I Pre-wash detergent compartment.
Refer to the Wash Programs Table
to see which programs utilise a pre-wash.
II Main detergent compartment.
This is the common detergent drawer.
Softener compartment.
WARNING: Liquid detergent is only required in compartment “I” after selecting the Pre-Wash function.
Program Pre Wash Main Detergent Softener
Steam Wash Optional Required Optional
Cotton Optional Required Optional
Synthetic Optional Required Optional
Mix Optional Required Optional
Jeans Optional Required Optional
ECO Wash —Required Optional
20° C —Required Optional
Spin — — —
Rinse & Spin — — Optional
Bulky Load Optional Required Optional
Baby Care Optional Required Optional
Wool —Required Optional
Sport Wear Optional Required Optional
Rapid 45’ —Required Optional
Quick 15’ —Required Optional
Your Washing Machine (Continued)
Caution!
• Detergent only need to be added in "case I “after selecting pre-washing
for machines with this function.
10
14
Detergent Dispenser
Pre wash detergent
Main wash detergent
Softener
II
I
Pull out the dispenser
Caution!
OPERATIONS
• As for the agglomerated or ropy detergent or additive, before they are
poured the detergent box, it is suggested to use some water for
dilution to prevent inlet of detergent box from being blocked and
overflowing while filling water.
•
into
the
Please choose suitable type of detergent for the various washing
temperature to get the best washing performance with less water and
energy consumption.
Note!
Mandatory ○ Optional
Programme
Cotton
Synthetic
Mix
Jeans
Spin Only
Rinse & Spin
ECO Wash
20
Programme
Bulky
Baby Care
Wool
Sport Wear
Rapid 45’
Quick 15’
Steam Wash
Note:
• When using granulated detergent or additive,
before they are poured into the detergent
box, it is suggested to mix water for dilution
and then to pour into the detergent box. This
prevents the inlet of the detergent box from
blockages and overflowing.
• Please choose a suitable type of detergent for
the various washing temperature to get the
best washing performance with less water and
energy consumption.

13
Quick Start Guide
QUICK START:
Follow the procedure below to operate your washing machine.
CAUTION:
• Before washing, please make sure it’s installed properly.
• Your appliance was thoroughly checked before it left the factory. To remove any residual water and to neutralise
potential odours, it’s recommended to clean your appliance before first use. For this reason, start the Cotton program
at 90°C without laundry and detergent
CALIBRATION
It’s recommended to calibrate the washing machine, so that provide the best performance.
The appliance is able to detect the amount of laundry loaded. This function is optimising the product performance by
minimising energy and water consumption, saving you money and time. For this reason it’s recommended to calibrate
the appliance for best use.
1. Remove all accessories from the drum and close the door;
2. Insert the mains plug to the socket;
3. Switch on the washing machine, and within 10 seconds, press “Delay” and “Temp.” simultaneously for approximately
3 seconds until “t19” is displayed on the screen.
4. Press the Start/Pause to start the appliance, initially“---” is displayed, and then “***” (such as “126”) is displayed to
indicate the real time drum speed. When the number reaches a certain value (and stop changing), it means the
washing machine is successfully calibrated.
BEFORE WASHING
1. Install your washing machine.
2. Plug in the power supply.
3. Turn on the water supply.
4. Open the door and load in the laundry.
5. Close the machine door.
6. Measure the detergent and pour in the appropriate amount
7. Power on the washing machine.
8. Select the desired program.
9. Select any additional functions if required.
10. Press the Start/Pause button to begin.
11. Completion of the washing cycle.
• At the completion of a wash program, the washing machine will make an audible tone and “End” will be
displayed on the screen.
12. Turn off the water supply
• Although the washing machine would be switched off, the power outlet should be switched off and the plug
should be pulled out for safety reasons.

14
Operating Instructions
PREPARATION BEFORE WASHING CLOTHES
Please follow these steps carefully to avoid trouble with your washing machine and damaging your clothing.
Washing Considerations
• The working condition of the washer should be
(0-40)°C. If used under 0°C,the inlet valve and draining
system may be damaged. If the machine is placed
under condition of 0°C or less, then it should be
transferred to normal ambient temperature to ensure
the water supply hose and drain hose are not frozen
before use.
• Please check the labels and the explanation of using
detergent before wash. Use non-foaming or less-
foaming detergent suitable for machine washing
properly.
• New clothes in particular, can leach colour onto other
clothing items, particularly whites.
Consider washing these and bright colours separately.
• Stained clothing should be treated with a stain
remover, prior to washing.
• Temperature sensitive clothes should be washed in
accordance with their care direction label. Otherwise
distortion and/or changes in colour could occur.
• Never allow washing to sit in the machine for a long
period of time- particularly when wet. Clothes can
become mouldy and develop an odour.
• Certain clothing cannot be washed in a washing
machine and their care directions may state dry
cleaning or hand washing required.
• Wrinkle style clothes, embossed clothes, resin clothes,
etc may become distorted when immersed in water.
• Avoid washing clothes without care direction labels
within the appliance, to be safe.
• Always remove all items from clothing pockets, as hard
items can cause damage to the appliance.
• Try to wash clothing colours and sizes in like loads,
as this will improve the effectiveness of the washing
and results.
• Close all clothing zips and ensure all buttons are
fastened securely.
• Delicate items such as bras, handkerchiefs and ties
should be washed within a special washing bag, to
prevent damage to themselves and other clothes.
• When washing a large single item that could become
heavy (i.e. a towel or jacket), it can cause the
appliance to become unbalance during its spin cycle.
Therefore it’s recommended to add one or two more
clothing items to help the machine balance.
• Try to remove any pet hair, dust and stains from
clothing prior to washing.
• Baby clothing should be washed separately.
• Clothing that gets easily “fuzzed” or loses fibres easily,
should be washed separately.
• Black clothing items should be washed separately.
• Do not wash waterproof materials within the
washing machine.
Pay Attention to Detergents
• Only use suitable front load washing machine
detergents with this appliance. Powders and liquid
detergents only.
• Only ever use the recommended quantity of detergent,
as per the manufacturer’s guidelines, as an excessive
quantity can cause excessive bubbles and overflow
to occur.
• It can also result in detergent residue remaining on the
clothing after completion of the wash cycle.
WARNING: Always keep detergents and additives
out of reach from children.
Clothing Classifications
The symbol types on care labels are typically classified
into the following textiles: Cotton, Blended Fibre, Synthetic
Fibre, Silk, Wool and Artificial Fibre.
Confirm the Washing Capacity
Never load the machine with excessive weights, as it will
affect your washing results.

15
WASHING CLOTHES FOR THE FIRST TIME
Before washing any clothes, please perform one cycle
without clothes inside as follows:
• Connect the power source and water.
• Insert a small amount of detergent into the detergent
drawer and close it.
• Select a Cotton program at 90°C.
• Press the “Start/Pause” button on the appliance.
• Allow the program to complete and your washing
machine is now ready for use.
SELECTING A PROCEDURE
You should select you washing program based on the type
of clothing, quantity and dirtiness level, in combination
with the following temperature table.
Temperature Mode Application
90º C Seriously soiled clothing, pure white cotton
(I.e. bed linen, towels, table cloths, etc)
60º C
Moderately soiled clothing, cotton and
synthetic articles with certain decolourising
degree (I.e. shirts, pajamas, etc)
40º C, 30º C,
20º C, Cold Water Lightly soiled clothing, synthetics and wool
To select a program:
• First turn the Program Selection Dial to the
corresponding wash program, according to the type
of textiles being washed.
• Secondly, select the desired temperature based on
the level of dirtiness.
Note: Generally the higher the temperature, the more
power that’s consumed.
• Finally, select your desired spin speed. The higher the
spin speed, the drier the textiles will be at completion,
however more delicate textiles will be more wrinkled.
Delicate textiles should be set with a lower spin speed.
Selecting the main washing program depend on the types
of clothing to be washed, as follows:
Steam Wash
Select this function for steam-assisted washing.
The higher temperature makes it easier to break down
stains more effectively, getting rid of allergens and
bacteria whilst also reducing the need to iron wrinkles
in clothing.
Cotton
Suitable for hard wearing and heat resistant textiles made
from cotton or linen. To increase the washing results the
main washing time is increased.
Synthetic
The procedure is shorter compared with that for cottons
and the washing intensity is relatively gentle. It is
recommended for washing synthetic articles, for example:
shirts, coats, etc.
Mix
You can select this procedure for washing durable clothes,
that typically require more wash time and intensity. It is
ideal for any “daily” clothing such as cotton, including
sheets, pillowcases, bathrobes and underwear.
Jeans
Suitable for durable garments such as denim.
ECO Wash
This procedure saves energy and limits the washing
temperatures between 20°C–60°C. The default set
temperature is 20°C. Use with a small quantity of clothes
which are only lightly dirty.
20° C
You can select this procedure for washing delicate
items where the care label suggests Cold Wash.
To be used with only a small quantity of clothing at
a time with light soiling only. The default temperature
of this washing procedure is 20° C.
Spin
This procedure provides a spin only option. Residual soapy
water shall be drained out before spinning.
Rinse & Spin
This procedure provides a short rinse cycle followed by a
spin cycle.

16
Operating Instructions (Continued)
Bulky Load
You can select this procedure for washing bulky items.
Baby Care
Washing the baby’s clothes, it can make the baby’s wear
cleaner and make the rinse performance better to protect
the baby skin.
Wool
You can select this procedure to wash wool textiles labeled
with “Machine Wash”. Please select the proper washing
temperature according to the clothings care label.
Furthermore, the proper detergent amount should be
used for wool textiles, which is generally less than normal
wash loads.
Sport Wear
You can select this procedure for washing sport and
active-wear clothing.
Rapid 45’
This procedure is suitable for washing a small quantity of
clothes without heavy soiling.
Quick 15’
You can select this procedure for washing a small quantity
of clothing, where items are only lightly soiled.
ADDITIONAL WASH OPTIONS
Delay Function
The Delay function can be set with this button, where the
delay is 0–24 Hrs.
To set the Delay function:
• Select a wash program;
• Press the Delay button to choose the time;
• Press Start/Pause to commence the delay operation.
To Cancel the Delay function:
• Press the Delay button until the display shows 0H.
It should be pressed prior to starting the program.
If the program has already started, press the On/Off
button to reset.
Spin Function
Select this button to manually set the spin speed of your
wash program.
GGSFLW600: 0–400–600–800–1000–1200
GGSFLW700: 0–400–600–800–1000–1200–1400
Temperature Function
Select this button to manually set the temperature of your
wash program.
Cold – 20°C — 40°C — 60°C — 90°C
Pre Wash Function
The Pre Wash function adds an additional wash prior to
the main wash. Extra detergent should be placed in the
detergent compartment when selected.
Extra Rinse Function
The laundry will undergo an extra rinse cycle at the
completion of the program.
Drum Clean
After 25 washes, the Drum Clean light will illuminate to
remind you to run this cycle. This program provides a 90°C
high temperature sterilisation cycle to clean the drum and
tube. When this procedure is performed, clothes or other
items should not be added. Use this program regularly
according to your needs.
To cancel the reminder for another 25 cycles, press and
hold the Drum Clean button for 3 seconds.

17
Reload (Add a Garment) Function
This function can be executed during operation of a
washing program. When the drum of the machine is still in
motion and/or there is a large amount of water inside, the
machine will not allow the door to be opened.
To use the Reload function:
• Press and hold the Start/Pause button for 3 seconds.
• Once the drum stops rotating, the door will unlock and
allow you to open.
• Add your additional clothing items and close the door.
• Press the Start/Pause button once again to continue
the wash program.
Child Lock
To avoid the washing procedure being altered by children,
you can activate the child lock function. All buttons and
dials won’t alter the machines settings, however the
On/Off button will still function. When Child Lock is
activated, “CL” will display alternating with the remaining
wash time on the screen. At the completion of your cycle,
“CL” and “END” will alternate on the display for 10 seconds,
then the indicator will flash for 3 seconds.
Note:
If the machine is switched off when Child Lock is active, it
will remain in Child Lock mode when switched back on.
To activate or deactivate the Child Lock:
• Press and hold the “Temp.” and “Function” buttons
together at the same time for 3 seconds, whilst the
machine is operating.
• The machine will make an audible tone to let you know
that the Child Lock is activated or deactivated.
Note:
At the completion of a wash program, the child lock will
become deactivated automatically.
Mute function
This function allows you to turn the audible tone on or off,
to indicate that your washing program is complete.
By default, the audible signal is set to On.
When the Mute function is on, your appliance will make an
audible tone when:
• The additional wash functions are pressed.
• If the washing machine is operating and the program
selector knob is turned, the appliance will make an
audible tone to alert the user that an invalid choice has
been made.
• At the completion of a washing program, an audible
tone will sound.
To activate or deactivate the Mute function:
• Press and hold the “Spin” buttons for 3 seconds.

18
Washing Program Table
GGSFLW600
Program Load
(kg)
Default Temp
(° C)
Default Speed
(RPM) Default Time
Steam Wash 3.0 40 1000 1:26
Cotton 6.0 40 1000 1:28
Synthetic 3.0 40 1000 1:25
Mix 6.0 40 1000 0:58
Jeans 6.0 40 800 1:40
ECO Wash 6.0 20 1000 0:59
20° C 3.0 20 1000 1:01
Spin 6.0 –1000 0:12
Rinse & Spin 6.0 –1000 0:20
Bulky Load 6.0 40 1000 1:48
Baby Care 6.0 60 1000 2:01
Wool 2.0 40 600 1:07
Sport Wear 3.0 20 800 0:47
Rapid 45’ 2.0 20 800 0:45
Quick 15’ 2.0 Cold 800 0:15
• Energy test program: ECO Wash, Temp: 60° C.
Speed: the highest speed; Other as the default.
Half load for 6.0kg machine: 3.0kg.
• “ECO Wash” is the standard washing programs to which the information in the label and the fiche
relates, and they are suitable to clean normally soiled cotton laundry and that they are the most efficient
programs in terms of combined energy and water consumptions for washing that type of cotton laundry,
that the actual water temperature may differ from the declared cycle temperature.
Note:
The parameters in this table are only for user’s reference.
The actual parameters maybe different with the parameters in above mentioned table.
Operating Instructions (Continued)

19
Washing Program Table
GGSFLW700
Program Load
(kg)
Default Temp
(° C)
Default Speed
(RPM) Default Time
Steam Wash 3.5 40 1000 1:26
Cotton 7.0 40 1000 1:28
Synthetic 3.5 40 1000 1:25
Mix 7.0 40 1000 0:58
Jeans 7.0 40 800 1:40
ECO Wash 7.0 20 1000 0:59
20° C 3.5 20 1000 1:01
Spin 7.0 –1000 0:12
Rinse & Spin 7.0 –1000 0:20
Bulky Load 7.0 40 1000 1:48
Baby Care 7.0 60 1000 2:01
Wool 2.0 40 600 1:07
Sport Wear 3.5 20 800 0:47
Rapid 45’ 2.0 20 800 0:45
Quick 15’ 2.0 Cold 800 0:15
• Energy test program: ECO Wash, Temp: 60° C.
Speed: the highest speed; Other as the default.
Half load for 7.0kg machine: 3.5kg.
• “ECO Wash” is the standard washing programs to which the information in the label and the fiche
relates, and they are suitable to clean normally soiled cotton laundry and that they are the most efficient
programs in terms of combined energy and water consumptions for washing that type of cotton laundry,
that the actual water temperature may differ from the declared cycle temperature.
Note:
The parameters in this table are only for user’s reference.
The actual parameters maybe different with the parameters in above mentioned table.

20
CLEANING PROCEDURES
WARNING: Before beginning any cleaning or
maintenance, always ensure the appliance is switched off,
the power plug is removed from the power outlet and the
water supply has been closed.
CLEANING THE WASHING MACHINE EXTERIOR
Proper maintenance of your washing machine will keep it
looking as new and extend its working life.
• The exterior surface can be cleaned with household
cleaners and a soft damp cleaning cloth.
• If there is any residual water at the completion of a
washing program, please use a cloth to wipe it off
immediately.
Note: Never use solvents or harsh cleaning chemicals on
your washing machine’s exterior.
CLEANING THE INTERNAL DRUM
Should any rust form on the inside drum (i.e. water was
left to sit for an extended period of time), please remove
immediately using a chlorine free detergent. Never use
steel wool or a harsh abrasive.
Note: Never place laundry in the washing machine when
performing the Drum Clean program.
CLEANING THE DOOR SEAL AND GLASS
Wipe the glass and seal after each wash to remove lint
and stains. If lint builds up it can cause leaks.
Remove any coins, buttons and other foreign objects
from the seal after each wash.
FROZEN WASHING MACHINE
Should the temperature drop below zero and your washing
machine becomes frozen, you should:
• Disconnect the power supply for the washing machine.
• Wash the tap connection with warm water, to help you
to disconnect the inlet pipe.
• Remove the inlet pipe and immerse in warm water
(i.e. within a bathtub).
• Pour some warm water into the washing machine
drum and wait for approximately 10 minutes.
• Reconnect the inlet pipe to the tap and washing
machine and open the water supply.
• Wait until the room’s ambient temperature returns
to above 0°C before trying to operate the washing
machine.
CLEANING THE DETERGENT DRAWER
You should periodically follow these steps to ensure
the detergent drawer remains clean.
• Press down on the arrow, located on the cover for the
fabric softener compartment of the detergent drawer
and remove the drawer out of the recess.
• Clean the inside of the recess with a brush.
• Lift the softener cover off the dispenser drawer and
wash both items with water.
• Re-install the fabric softener compartment cover
into the detergent drawer, and push the drawer back
into position.
Note:
• Do not use abrasive or caustic agents to clean the
plastic parts.
• Clean the detergent dispenser every 3 months to
ensure the normal operation of the appliance.
Cleaning & Maintenance
• Before your maintenance starts, please unplug the machine and close the tap.
Cleaning The Cabinet
Cleaning The Drum
Formic acid and its diluted solvents or equivalent are forbidden, such as
solvents or chemical products,etc.
•
alcohol,
• Don’t put laundry in the washing machine during the drum cleaning.
Cleaning The Door Seal And Glass
Warning!
Note!
Note!
Cleaning And Care
The rusts left inside the drum by the metal articles shall be removed immediately
with chlorine-free detergents.
Never use steel wool.
Proper maintenance on the washing machine can extend its
working life. The surface can be cleaned with diluted
non-abrasive neutral detergents when necessary. If there is
any water overflow, use the wet cloth to wipe it off immediately.
No sharp items are allowed.
Wipe the glass and seal after each wash
to remove lint and stains. If lint builds up it
can cause leaks.
Remove any coins, buttons and other objects
from the seal after each wash.
MAINTENANCES
22
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1234
Note!
Note!
Note!
10
23
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1234
Note!
Note!
Note!
10
23
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1234
Note!
Note!
Note!
10
23
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1234
Note!
Note!
Note!
10
23
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
