SONIQ PN141CW User manual

User Manual
Model No: PN141CW

1
Precautions before Use
1. This production is suitable for use in non-tropic areas below 2,000 meters.
2. Prevent the device from falling to the ground or being strongly impacted
otherwise.
3. Do not use it in the long term in any environment where the air is too cold, too hot
(<35℃),
too humid or with too much dust. Do not expose the Device to sunlight.
4. Avoid using it in the strong magnetic and strong static environment as much as
possible.
5. Once any water or other liquid splashes onto the Device, close it immediately and
do not use
it until it dries out.
6. Do not clean the Device with any detergent containing chemical element or other
liquid to
avoid causing damage due to corrosion and becoming damp. If cleaning is really
necessary,
clean it with dry soft cloth tissue paper.
7. Our company shall not bear any and all responsibilities for loss or deletion of
material inside
the machine caused due to abnormal software and hardware operation,
maintenance or any other accident.
8. Please back up your important material at any time to avoid loss.
9. Please do not disassemble the Device by yourself; otherwise you will lose the
right to warranty.

1. Power button: Press it down to start or close the screen panel.
You can also let the computer to enter dormancy through this button or wake
from the dormancy mode.
2. Front camera: take pictures, shoot video.
3. Touchpad: The device can be operated directly.
4. Keyboard board: the device can be operated directly.
5. Indicators: 1 work light, bright green when the machine starts to work.
2 is the green light when turns on the Caps Lock
3 is the green light when turns on the Num Lock
6. Microphone: it can transmit audio signals to a device at work.
7. Charge indicator: red light when plug adapter
8. DC charging base: use the 12V / 2A charger.
9. USB Interface: You can insert U disk, mouse, keyboard directly.
10. Mini-HDMI Interface: High-Definition Multimedia Interface.
11. Headphone jack: This jack device can transmit audio signals to the speakers
or headphones.
12. USB Interface: You can insert U disk, mouse, keyboard directly.
13. Micro SD card slot: built-in memory card reader slot that supports Micro SD format.
14. Speakers: the built-in speaker lets you hear the sound of work without additional
connected devices.
1
2
3
4
5 6 6
7
10
9812
11
13
14 14
2
Unit at a Glance

Applications Introduction
In addition to already fixed on the start screen of the application, you can open all
applications in the.homepage.
If you want to add multiple applications on the Start screen, refer to the operation as
shown below
（1）Right-click on the Properties icon
（2）Select fixed at the beginning of the page
3
Interface Introduction
Windows 10 start image: On the start screen, you can see many programs fixed in
the image. These application programs are displayed in the form of “magnet”. As
long as you click them, you can easily visit them. You need to log on your Microsoft
account before the application program completely runs.

Conversely, if you want to cancel or delete startup screen a certain application,
(1) Right-click
(2) Select the undocked from the start page.
4
Applications Introduction

5
Menu bar
Touch or USB mouse to click with windows home button appears on the
menu bar
Expand the menu bar from the screen, usually: a file manager, settings, power
supply and all applications, you can sleep / shutdown / restart the device
You can manage your files and applications in the device.
You can set up your device.

6
After Huna can login account can be set up after the language or text dialogue, if
not logged on account only for text searches.
Device menu Click on the notification menu
Search menu

7
Click the Desktop task view to operating a multi-tasking and multi-desktop window
Basic Operations
Sleep, restart, power off
Short press the power button Hibernation
Multitasking operating interface

8
Specifications
Display
14.1” 1920*1080 IPS
Wi-Fi Networking IEEE 802.11 b/g/n/ac
Audio Output 3.5mm headphone
USB Host 1xUSB3.0, 1xUSB2.0
WINDOWS 10 PRO
Rechargeable Li-poly battery
P Adapter(DC IN 12V,2A)ower
Processor
Storage
Operating
System
Power
Camera
RAM
ROM
4 GB
64 GB
2.0 MP
Speakers 2x1W speakers
Bluetooth 4.2
HDMI MINI HDMI x1
Intel Celeron N3350
