Sony CFD-EX35L User manual

CFD-EX35L
AEP Model
UK Model
SERVICE MANUAL
CD RADIO CASSETTE-CORDER
Sony Corporation
Personal Audio Company
Published by Sony Engineering Corporation
9-873-984-01
2002D1600-1
© 2002.04
SPECIFICATIONS
Ver 1.0 2002. 04
Model Name Using CD Section CFD-G35
Similar Mechanism Tape Section CFD-G35
CD Mechanism Type KSM-213RDP
Optical Pick-up Type KSS-213R
Tape Transport Mechanism Type MF-V5-117
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance
of about 200 mm from the objective lens surface
on the optical pick-up block with 7 mm
aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm)
(CLV)
Number of channels
2
Frequency response
20 - 20 000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM 87.5 - 108 MHz
MW 531 - 1 611 kHz (9 kHz step)
530 - 1 610 kHz (10 kHz step)
LW 153 - 279 kHz
IF FM: 10.7 MHz
AM/MW/LW: 450 kHz
Aerials
FM: Telescopic aerial
AM/MW/LW: Built-in ferrite bar aerial
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 115 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 70 - 13 000 Hz
General
Speaker
Main speaker: 10 cm (4
in.) dia., 3.2 Ω, cone
type (2)
Subwoofer: 8 cm (3
1
⁄
4
in.) dia., 4 Ω, cone type
(1)
Outputs
Headphones jack (stereo minijack)
For 16 - 68 Ωimpedance headphones
Maximum power output
Main speaker: 4 W
Subwoofer: 6 W
Power requirements
For CD radio cassette-corder:
230 V AC, 50 Hz
9 V DC, 6 R20 (size D) batteries
For remote control:
3 V DC, 2 R6 (size AA) batteries
Power consumption
AC 25 W
Battery life
For CD radio cassette-corder:
FM recording
Sony R20P: approx. 4 h
Sony alkaline LR20: approx. 19 h
Tape playback
Sony R20P: approx. 1.5 h
Sony alkaline LR20: approx. 7 h
CD playback
Sony R20P: approx. 1.5 h
Sony alkaline LR20: approx. 3.5 h
Dimensions
Approx. 456 ×195 ×330 mm (w/h/d)
(18 ×7
3
⁄
4
×13 inches) (incl. projecting parts)
Mass
Approx. 6.4 kg (14 lb. 2 oz) (incl. batteries)
Supplied accessory
Mains lead (1)
Remote control (1)
Design and specifications are subject to change
without notice.

2
CFD-EX35L
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of soldering iron around 270˚C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
TABLE OF CONTENTS
1. SERVICING NOTES ······················································ 3
2. GENERAL ·········································································· 4
3. DISASSEMBLY ································································ 5
3-1. Cabinet (Front) Assy- 1 ················································ 5
3-2. Cabinet (Front) Assy- 2 ················································ 6
3-3. CONTROL (POWER) , CONTROL (CD) ,
HEADPHONE Board ··················································· 6
3-4. Panel Assy····································································· 7
3-5. LCD Board, Panel (Upper) ··········································· 7
3-6. Panel (Upper)Assy- 1 ··················································· 8
3-7. Panel (Upper)Assy- 2 ··················································· 8
3-8. POWER, TRANS Board··············································· 9
3-9. TUNER Board, Duct (Upper, Lower)··························· 9
3-10. BATT COM, BATT Board·········································· 10
3-11. MAIN Board- 1··························································· 10
3-12. MAIN Board- 2··························································· 11
3-13. Mechanism Deck Section (MF-V5-117) ···················· 11
3-14. CD Block Section (KSM-213RDP) ···························· 12
3-15. PDW, L-R/REG Board················································ 12
4. ADJUSTMENTS ···························································· 13
4-1. Mechanical Adjustments ··············································· 13
4-2. Electrical Adjustments ·················································· 13
5. DIAGRAMS······································································ 17
5-1. Circuit Boards Location·············································· 17
5-2. Block Diagrams ·························································· 18
5-3. Printed Wiring Board – TUNER Section –················ 20
5-4. Schematic Diagram – TUNER Section – ··················· 21
5-5. Printed Wiring Board – CD Section – ························ 22
5-6. Schematic Diagram – CD Section – ··························· 23
5-7. Printed Wiring Board – TC Section – ························· 24
5-8. Schematic Diagram – TC Section –···························· 24
5-9. Printed Wiring Board – MAIN Section – ··················· 25
5-10. Schematic Diagram – MAIN Section (1/2) – ············· 26
5-11. Schematic Diagram – MAIN Section (2/2) – ············· 27
5-12. Printed Wiring Board – AMP Section – ····················· 28
5-13. Schematic Diagram –AMP Section – ························ 29
5-14. Printed Wiring Board – CONTROL Section – ··········· 30
5-15. Schematic Diagram – CONTROL Section – ·············· 31
5-16. Printed Wiring Board – POWER Section – ················ 32
5-17. Schematic Diagram – POWER Section – ··················· 33
5-18. IC Pin Function Description ······································· 36
6. EXPLODEDVIEWS ······················································ 38
6-1. Cabinet (Front) Section··············································· 38
6-2. Cabinet (Rear) Section················································ 39
6-3. Cabinet (Upper) Section ············································· 40
6-4. Mechanism Deck Section- 1 (MF-V5-117) ··············· 41
6-5. Mechanism Deck Section- 2 (MF-V5-117) ··············· 42
6-6. CD Mechanism Section (KSM-213RDP)··················· 43
7. ELECTRICAL PARTS LIST ······································· 44

3
CFD-EX35L
SECTION 1
SERVICING NOTES
NOTES ON HANDLINGTHE OPTICAL PICK-UP
BLOCK OR BASE UNIT
The laser diode in the optical pick-up block may suffer electrostatic
breakdown because of the potential difference generated by the
charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic breakdown and also use
the procedure in the printed matter which is included in the repair
parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused on
the disc reflective surface by the objective lens in the optical pick-
up block. Therefore, when checking the laser diode emission,
observe more than 30 cm away from the objective lens.
CHUCK PLATE JIG ON REPAIRING
On repairing CD section, playing a disc without the CD lid, use
Chuck Plate Jig.
• Code number of Chuck Plate Jig : X-4918-255-1
LASER DIODE AND FOCUS SEARCH OPERATION
CHECK
1. Press CD open knob.
2. Open the lid for CD.
3. Push on SWITCH (S801) as following figure.
4. Confirm the laser diode emission while observing the objecting
lens.When there is no emission,Auto Power Control circuit or
Optical Pick-up is broken.
Objective lens moves up and down once for the focus search.
Insert a precision
screw driver and push
SWITCH (S801)

4
CFD-EX35L SECTION 2
GENERAL This section is extracted
from instruction manual.
Location of controls/Ubicación de los controles
Total track number
Número total de pistas
Programmed track
Pista programada Playing order Orden de reproducción
Total playing time
Tiempo total de reproducción
Display/Visor
Remote Control
Mando a distancia
FUNCTION
BAND
OPERATE
(POWER)
VOL +*, –
x
.,>
ZPUSH
OPEN/CLOSE
VOLUME –, +*
TUNE –, +
DISPLAY
ENTER
MEMORY
MODE
i
Number buttons
Botones
numéricoss
xu*
SLEEP
OPR/BATT
Loading a CD
Carga de un CD
With the labeled side up
Con la cara etiquetada hacia arriba
Inserting a cassette
Inserción de casetes
With the side you want to play
facing upward
Con la cara que desee reproducir
mirando hacia arriba
BAND
AUTO PRESET
SOUND
Display
Visor
Remote sensor
Sensor de control remoto
*The button has a tactile dot.
*El botón tiene un punto táctil.
POWER DRIVE
WOOFER
., >
PRESET –, +
X
SLEEP
MODE
TUNE+, –
WOOFER
SOUND
OPERATE
(POWER)
N
About CD-Rs/CD-RWs
This player can play CD-Rs/CD-RWs
recorded in the CD-DA format*, but
playback capability may vary depending on
the quality of the disc and the condition of
the recording device.
* CD-DA is the abbreviation for Compact
Disc Digital Audio. It is a recording
standard used for Audio CDs.
If you have any questions or problems
concerning your player, please consult your
nearest Sony dealer.
D E

5
CFD-EX35L
SECTION 3
DISASSEMBLY
•The equipment can be removed using the following procedure.
3-1. Cabinet (Front) Assy- 1
Note : Follow the disassembly procedure in the numerical order given.
CABINET (FRONT) ASSY-1
(page 5)
CABINET (FRONT) ASSY-2
(page 6)
PANEL ASSY
(page 7) LCD BOARD, PANEL (UPPER)
(page 7)
CONTROL (POWER), CONTROL (CD), HEADPHONE BOARD
(page 6)
PANEL (UPPER) ASSY-1
(page 8)
PANEL (UPPER) ASSY-2
(page 8)
POWER, TRANS BOARD
(page 9)
TUNER BOARD, DUCT (UPPER, LOWER)
(page 9)
BATT COM, BATT BOARD
(page 10)
MAIN BOARD-1
(page 10) MAIN BOARD-2
(page 11) PDW, L-R/REG BOARD (page 12)
MECHANISM DECK SECTION (MF-V5-117)
(page 11)
CD BLOCK SECTION (KSM-213RDP)
(page 12)
Set
2 two screws
+BVTP 3 × 20
3 eight screws
+BVTP 3 × 14
5 screw
+BVTP 3 × 10
4 Open the CD lid in the
direction of the arrow.
1 Remove the battery case lid
in the direction of the arrow.
detal view

6
CFD-EX35L
3-3. CONTROL (POWER) , CONTROL (CD) , HEADPHONE Board
3-2. Cabinet (Front) Assy- 2
1 Remove the cabinet (front) assy
in the direction of the arrow.
4 CNP391
(from PWD board KH353)
5 CNP393
(from L-R/REG board KH374)
3 flexible flat cable
(from MAIN board CNP801)
2 flexible flat cable
(from MAIN board CNP804)
MAIN board
HEADPHONE board
1 two screws
+BVTP 2.6
× 10
3 screw
+BVTP 3
× 10
5 two screws
+BVTP 2.6
× 10
6 CONTROL (CD) board,
button (CD)
4 HEADPHONE board
2 CONTROL (POWER) board,
button (power)

7
CFD-EX35L
3-4. Panel Assy
3-5. LCD Board, Panel (Upper)
!™ panel (upper)
7 two screws
+BVTP 2.6 × 10
5 button (PDW)
8 two screws
+BVTP 2.6 × 10
3 flexible flat cable
(from MAIN board CNP804
)
2 CONTROL (VOL) board
0 flexible flat cable
(from MAIN board CNP801)
1 six screws
+BVTP 2.6 × 10
9 panel (front) section
!¡ LCD board
6 light guide plate
(PWD)
4 button (VOL)
5 panel assy
2 four screws
+BVTP 2.6
× 1
0
1 screw
+BVTP 3
× 10
4 flexible flat cable
(from MAIN board CNP801)
3 flexible flat cable
(from MAIN board CNP804)

8
CFD-EX35L
3-6. Panel (Upper) Assy- 1
7 Open the cassette holder assy
in the direction of the arrow.
5 Open the CD lid in the
direction of the arrow.
1 CNP1
(from MAIN board KH801)
2 CNP903
(from MAIN board KH301)
6 Push STOP/EJECT button.
3 Remove two harnesses
in the direction of the arrow.
4 Remove two harnesses
in the direction of the arrow.
3-7. Panel (Upper) Assy- 2
4 Remove the panel (upper) assy
in the direction of the arrow.
2 five screws
+BVTP 3
× 10
5 handle
1 four screws
+BVTP 3
× 10
3 Move the telescopic antenna in
the direction of the arrow.

9
CFD-EX35L
3-8. POWER,TRANS Board
5 four screws
+BVTP 3
× 10
3 screw
+BVTP 3
× 10
a
a
2
Remove harnesses in the direction
of the arrow.
7 chassis
(trans)
4 two screws
+BVTP 3
× 10
power transformer
(T901)
1 CNP902
(from BATT board KH951)
6 five screws
+BVTP 3
× 10
8 POWER board,
TRANS board
3-9. TUNER Board, Duct (Upper, Lower)
2 two screws
+BVTP 3 × 10
7 two screws
+BVTP 3 × 10
0 duct (upper)
9 duct (lower)
1 screw
+BVTP 3 × 10
4 TUNER board
8 seven screws
+BVTP 2.6
× 8
6 bracket (woofer)
3 chassis (TU)
5 two screws
+BVTP 3 × 10

10
CFD-EX35L
3-10. BATT COM, BATT Board
2 Remove harnesses in the direction
of the arrow.
1 CNP902
(from BATT board KH951)
5 screw
3
× 8 (DIA, 10),+W
H
6 BATT COM board
9 battery
terminal
8 battery termina
l
4 BATT board
7 four screws
+BVTP 3
× 10
3 screw
3
× 8 (DIA, 10),+WH
BATT board
3-11. MAIN Board- 1
0 four screws
+BVTP 3
× 10
3 CD door sw
(S801)
4 CNP351
!¡ MAIN board
8 CNP371
7 CNP37
2
6 CNP373
5 CNP352
9 CNP302
1 flexible flat cable
CNP805
2 flexible flat cable
CNP802
L-R/REG board
PDW board

11
CFD-EX35L
3-12. MAIN Board- 2
5 MAIN boar
d
CNP374
CNP353
chassis (CD)
L-R/REG board
1 from TUNER board CNP1
2 from HEADPHONE board CNP391
3 from HEADPHONE board CNP393
4 from POWER board CNP903
PDW board
3-13. Mechanism Deck Section (MF-V5-117)
4 three screws
+BVTP 3
× 10
1 flexible flat cable
(from MAIN board CNP805)
5 mechanism deck section
(MF-V5-117)
3 TC board
2 screw
+PTT 2 × 6

12
CFD-EX35L
3-14. CD Block Section (KSM-213RDP)
3-15. PDW, L-R/REG Board
5 three screws
+BVTP 3
× 10
1 screw
+BVTP 3
× 10
3 two screws
+BVTP 3
× 10
6 PDW board,
Chassis (HS, R)
4 L-R/REG board,
Chassis (HS, L)
2 clamp
5 CD board
4 flexible flat cable
CNP701
2 Remove solderings
from the four points.
1 flexible flat cable
(from MAIN board CNP802
)
7 CD block section
(KSM-213RDP)
6 four screws
2.6 × 10 (DIA, 10),+WH
3 screw
+P2 × 6

13
CFD-EX35L
4-1. Mechanical Adjustments
PRECAUTION
1. Clean the following parts with a denatured-alcohol-moistened
swab :
record/playback head pinch roller
erase head rubber belts
capstan
2. Demagnetize the record/playback head with a head demagne-
tizer. (Do not bring the head demagnetizer close to the erase
head.)
3. Do not use a magnetized screwdriver for the adjustments.
4. The adjustments should be performed with the rated power
supply voltage (9V) unless otherwise noted.
Torque Measurement
Torque Torque Meter Meter Reading
1.77 – 5.88 mN•m
Forward CQ-102C (18 – 60 g•cm)
(0.25 – 0.83 oz•inch)
Forward 0.1 – 0.49 mN•m
Back Tension CQ-102C (1.0 – 5.0 g•cm)
(0.014 – 0.069 oz•inch)
4.42 – 9.31 mN•m
Fast Forward CQ-201B (45 – 95 g•cm)
(0.62 – 1.32 oz•inch)
4.42 – 9.31 mN•m
Rewind CQ-201B (45 – 95 g•cm)
(0.62 – 1.32 oz•inch)
Tape Tension Measurement
Torque Meter Meter Reading
CQ-403A more than 60g
(more than 2.12 oz)
SECTION 4
ADJUSTMENTS
4-2. Electrical Adjustments
TAPE SECTION
Standard Output Level
Output terminal HP OUT
load impedance 32 Ω
output signal level 0.25V (–10dB)
TestTape
Type Signal Used for
WS-48A 3kHz, 0dB Tape Speed Adjustment
Tape Speed Adjustment
Procedure :
Mode : Playback
Adjustment so than the value on the digital frequency counter is
3,000 Hz.
Adjustment Value : 3,000Hz
Standard Value : 2,940 - 3,060Hz
Frequency difference between the beginning and the end of the tape
should be within 1.5% (45Hz).
set
test tape
WS-48A
(3kHz, 0dB) 32
Ω
digital frequenc
y
counter
J391
( i )
Tape speed adjustment
control inside motor
0dB = 0.775V
Adjustment Location : Mechanism deck

14
CFD-EX35L
AM IF ADJUSTMENT
Adjust for a maximum reading on level meter.
T1 450 kHz
MW FREQUENCY COVERAGE ADJUSTMENT
Frequency Display 531 kHz 1,611 kHz
Reading on Digital voltmeter 0.9 ± 0.5 V 5.2 ± 0.6 V
Adjustment Part <confirmation> <confirmation>
MW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L3-1 CT3
621 kHz 1,404 kHz
LW FREQUENCY COVERAGE ADJUSTMENT
Frequency Display 153 kHz 279 kHz
Reading on Digital voltmeter 0.6 ± 0.3 V 5.0 ± 0.15 V
Adjustment Part L4 <confirmation>
LW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L3-2 CT5
162 kHz 261 kHz
FM IF ADJUSTMENT
Adjust for a maximum reading on level meter.
T2 10.7 MHz
FM FREQUENCY COVERAGE ADJUSTMENT
Frequency Display 87.5 MHz 108 MHz
Reading on Digital voltmeter 1.3 ± 0.4 V 3.0 ± 0.3V
Adjustment Part <confirmation> L2
FM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L1 CT1
87.5 MHz 108 MHz
Adjustment Location : TUNER board (See page 16)
•Repeat the procedures in each adjustment several times, and the
frequency coverage and tracking adjustments should be finally
done by the trimmer capacitors.
TUNER SECTION
AM (MW/LW) Section
RADIO BAND : AM (MW or LW)
FM Section
RADIO BAND : FM
•Connecting Level Meter (FM and AM)
•Connecting DigitalVoltmeter (FM and AM)
AM RF signal
generator
30% amplitude modulation by 400Hz
signal.
Output level : as low as possible
Put the lead-wire
antenna close to
the set.
FM RF signal
generator
33.75kHz frequency deviation by
1kHz signal.
Output level : as low as possible
telescopi
c
antenna
terminal
0.01
µ F
0dB = 1 µV
digital
voltmeter
100 k
Ω
TP CV
J391 ( i )
set
32
Ω
level meter
(range: 0.5–5 V ac
)

15
CFD-EX35L
Focus Bias Check
1. Connect an oscilloscope between TP RF and TP VREF on
CD board.
2. Insert the test disc (YEDS-18).
3. Set the CD test mode.
4. Press the ubutton three times (LPC ON).
5. Confirmthatthe oscilloscopewaveform isasshowninthe figure
below. (eye pattern)
A good eye pattern means that the diamond shape (◊) in the
center of the waveform can be clearly distinguished.
6. Press the ubutton.(LPC OFF)
7. Perform confirmation in step 4 again.
• RF Signal Reference Waveform (eye pattern)
RF level
0.85
± 0.2 Vp-p (LPC ON)
0.95
± 0.4 Vp-p (LPC OFF)
VOLT/DIV : 200mV
TIME/DIV : 500 ns
CD SECTION
CDTest Mode
• How to put the set into CD test mode
1. Press the POWER button to turn the power on.
2. Insert the test disc (YEDS-18). (Part No. : 3-702-101-01)
(Function is set to CD.)
3. Set the CD test mode by momentary shorting both sides of
TEST- 1 on MAIN board.
4. Press the x button two times. The set is set to the CD test
mode.
(The message 80 is displayed.)
• How to release the CD test mode
Turn the power off.
[MAIN BOARD] (Conductor side)
TraverseWaveform Check
1. Connect an oscilloscope between TP TE and TP VREF on
CD board.
2. Set the CD test mode.
3. Press the ubotton to play the test disc (YEDS-18).
4. Confirm that the center of the traverse waveform will be at 0V.
5. Confirm that the peak-to-peak voltage value of the traverse
waveform meets the specification.
6. Release the CD test mode.
• Traverse waveform
A (DC voltage)
symmetry
0V
A = 0
± 220 mV
B = 0.95
± 0.55 Vp-p
B
VOLT/DIV : 200mV
TIME/DIV : 1 ms
IC803
IC802
IC805
IC321
IC801
TEST-1
IC701
TP VREF TP TE TP RF
[CD BOARD] (Conductor side)

16
CFD-EX35L
Adjustment Location :
[TUNER BOARD] (Component side)
(Conductor side)
CT1: FM Tracking Adjustment
L1: FM Tracking Adjustment L3-2: LW Tracking Adjustment L3-1: MW Tracking Adjustment
CT3: MW Tracking Adjustment
CT5: LW Tracking Adjustmen
t
CNP1
L4: LW Frequency Coverage Adjustment
T1: AM IF Adjustment
T2: FM IF Adjustment
L2: FM Frequency Coverage Adjustment
IC2
IC1
R12
R7
R18
R9
R16
R43
C93
C25
C40
C70
C72
C73
C48
C45
C46
C6
R64
C5
C71
C44
Q44
Q12
Q43
E
E
Q14
E
E
R42
R22
R17
R19
C3
R66
C64
JC22
C58
C2
E
Q42
E
Q41
E
Q61
R93
JC23
TP CV
MW/LW/FM Frequency Coverage Adjustment

1717
CFD-EX35L
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. p: pF.
50 WV or less are not indicated except for electrolytics
and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
•f: internal component.
•2: nonflammable resistor.
•C: panel designation.
•A: B+ Line.
•H: adjustment for repair.
•Total current is measured with no cassette installed.
•Power voltage is dc 9 V and fed with regulated dc power
supply from battery terminal.
•Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
•Voltages aretakenwithaVOM (Inputimpedance 10MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
•Circled numbers refer to waveforms.
•Signal path.
F: FM
f: MW/LW
E: PB
a: REC
J: CD
•WAVEFORMS
–TUNER Section –
SECTION 5
DIAGRAMS
5-1. Circuit Boards Location Note on Printed Wiring Boards:
•X: parts extracted from the component side.
•f: internal component.
•: Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
Note: The components identified by mark 0or dotted line
with mark 0are critical for safety.
Replace only with part number specified.
1 IC2 w; (XOUT)
1.4 Vp-p
13.3
µ s
500 mV/DIV, 4 µ s/DIV
–TC Section –
2 Q301 collector (TAPE REC)
3.1 Vp-p
18
µ s
1 V/DIV, 10 µ s/DIV
– CD Section –
3 IC701 rk (XOUT)
4.2 Vp-p
59 ns 1 V/DIV, 20 ns/DIV
– MAIN Section –
4 IC801 ua (XT2)
3.6 Vp-p
30.5
µ s
1 V/DIV, 10 µ s/DIV
5 IC801 ug (X2)
3.7 Vp-p
238 ns
1 V/DIV, 100 ns/DIV
BATT board
PDW boar
d
MAIN board
L-R/REG board
TRANS board
LCD board
BATT COM board
POWER board
TUNER board
HEADPHONE board
CONTROL (CD) board
CONTROL (POWER) board
CONTROL (VOL) board
CD board
TC board

1818
CFD-EX35L
5-2. Block Diagrams
MAIN Section
: FM
: CD
• Signal Path
• R-CH is omitted due to same as L-CH.
: PB
: REC
20
B
A
TUNER/CD
SECTION
L OUT
L-CH
R-CH
HEAD
R-CH
R-CH
(MAGNET)
L-CH
BIAS
OSC
Q301
ISS1
Q301
ISS2
Q301
PRE AMP
IC301
24
22
5
4
1521
REC TAPE
L IN
RADIO
PB AMP
26dB
L
TAPE
TAPE
T301
12
MUTE
Q171
AMP
Q321
INV
Q953
BASS AGC
Q351
3
8
STBY
POWER AMP
IC371
R-CH
R-CH
J391
SPEAKER (L-CH)
SPEAKER (R-CH)
FUNCTION
SWITCH
S409-416
LED DRIVE
Q810
64
V-CLOCK
65
V-DATA
34
A-MUTE
67
TAPE
393332
REC ISS2 ISS1
IC801(2/2)
SYSTEM CONTROL
70
71
74
75
X802
32.768kHz
X801
4.19MHz
XT1
XT2
X1
X2
S301
REC PB
REC AMP
AMP
BUFFER 7dB
17
LINE
51
TC-PLAY
M
VDD(SW)
M321
CAPSTAN/REEL
MOTOR
S322
MOTOR
S321
PLAY
TUNER/CD
SECTION
6
REF
66
P-CON
KEY-1
43
WP
50
KEY-2
44
W-LED1
79
S401,402
S404-408
SCL
35
SDA
36
65
EEP ROM
IC803
77
CD
VIN1
1
SOUND/VOLUME
IC321
SI
14
SC
13
17
OUT1
AGC
Q354
VDD(SW)
VDD(SW)
12
13 3
10
11 5
8
STBY
WOOFER
POWER AMP
IC351
30
WOOFER ON/OFF
LCD891
LIQUID CRYSTAL
DISPLAY PANEL
2710
SEG17SEG0
96
COM3COM0
SP391
SP392
SP393
WOOFER
T901
(AC IN)
RECT
D901-904
+6V REG
Q954
CD +6V REG
Q972
+3.3V REG
Q956
CD/RADIO +6V
CD +3.3V
VDD(SW) POWER
SWITCH
Q952
23 +3.3V
REG
IC802
21 RESET
IC805
µCOM VDD
D807
D806
1REMOTE
CONTROL
IC891
76
RESET
49REG CHK
AUDIO 6V
Q955
PB
REC
CD 3.3V
LPF
Q322
FUNCTION
SWITCH
FUNCTION
SWITCH
KEY-3
45
VDD(SW)
2
AU +6V
CNJ901
48RMC
DRY BATTERY
SIZE "D"
(IEC DESIGNATION R20)
6PCS, 9V
POWER AMP +9V
D893
OPR/BATT
D401
POWER DRIVE
WOOFER
TEST-1
SW
Q951

1919
CFD-EX35L
TUNER/CD Section
: FM
:MW/LW
: CD
• Signal Path
• R-CH is omitted due to same as L-CH.
R-CE
63
R-CLK
61
R-DATA
62
R-COUNT
60
SYSTEM CONTROL
IC801(1/2)
OPTICAL PICK-UP
BLOCK
A
B
C
D
E
F
LD
VC
VCC
GND
PD
VR
LD
DRIVE
FOCUS
COIL
TRACKING
COIL
Q701
RF AMP,D/A CONV
IC701
VREF
11
FIN2
8
FIN1
7
TIN1
9
TIN2
10
LD
80
PD
79
MOTOR/COIL DRIVE
IC702
F+
17
F-
18
T+
12
T-
11
SL+
26
SL-
27
M
M702
SLED
MOTOR
SP+
2
SP-
1
M
M701
SPINDLE
MOTOR
F+
F-
T+
T-
19
9
25
3SPDO
22
SLDO
23
TDO
20
FDO
21
42
L OUT
45
R OUT
63DI
MAIN
SECTION
R-CH
L OUT
62CL
61CE
4
DRF
31
FSEQ
65
WRQ
66
RES
72
CONT1
49
XIN
48
XOUT
S701
LIMIT
IN SW
X701
16.93MHz
C-DI
54
C-CLK
55
C-CE
56
C-DRF
58
WRQ
52
C-RES
59 40
C-DOOR
S801
19
L1
L3
L3-1
L3-2
Q42
Q14
Q41Q43Q44
FERRITE-ROD
ANTENNA
D1
2
24
21
22
20
FM
MIX
FM RF-IN
FM RF-OUT
FM OSC
AM RF-IN
AM OSC
FM
OSC
AM
MIX
AM
OSC
OSC-OUT
4
MIX-OUT
16
IF
BUFFER
CF2
CF4
7
6
FM IF-IN
AM IF-IN
FM
MPX
FM/AM
BUFFER
FM
DET
AM
DET
15 A
DET-OUT
17
MUTE 12
11 R-CH
10
FRONT-END
IF AMP,DET,FM MPX 23 5
RADIO 6V
QUAD VCC1 VCC2
MAIN
SECTION
T2
CE
12
11
14
13
14 13
MO-ST
BAND
10
4
2
3
1
20
19
VDD(SW)
PLL
IC2
FM IN
AM IN
VDD
XOUT
XIN
CL
DI
DO
IF IN
MO/ST
6V
X1
75kHz
L-CH
RADIO 6V
CT1
L2
D2
RADIO 6V
CT5
CT3
RADIO 6V
D3
L4
ANTENNA
FM
TELESCOPIC IC1
T1
18 LP-OUT
6MW/LW
16 PD
LPF
18
ST-IND
8
ST-IND
7
BAND
9
BAND
IF-OUT
MPX-IN
R-MUTE
57
C-FSEQ
46
SP IN
SL IN
T IN
F IN
B
RADIO 6V
ANT1
64DO C-DO
53
7 CONT4
25
MUTE
17 LP-IN
L1, CT1
FM
TRACKING
L2
FM
FREQUENCY
COVERAGE
L3-1, CT3
MW
TRACKING
L4
LW
FREQUENCY
COVERAGE
L3-2, CT5
LW
TRACKING
T1
AM IF
T2
FM IF
ZPUSH
OPEN/CLOSE
Q61
CURRENT
REG
Q12
MW/LW
HIGH-CUT
SWITCH

2020
CFD-EX35L
5-3. PrintedWiring Board –TUNER Section – • See page 17 for Circuit Boards Location.
IC2
IC1
25
25
R12
R7
R18
R9
R16
R43
C93
C25
C40
C70
C72
C73
C48
C45
C46
C6
R64
C5
C71
C44
Q44
Q12
Q43
E
E
Q14
E
E
R42
R22
R17
R19
C3
R66
C64
JC22
C58
C2
E
Q42
E
Q41
E
Q61
R93
JC23
Ref. No. Location
D1 B-2
D2 B-3
D3 B-3
D10 B-1
D11 B-1
IC1 A-2
IC2 A-4
Q12 A-3
Q14 B-4
Q41 B-4
Q42 B-2
Q43 B-3
Q44 B-3
• Semiconductor
Location
