The Sphinx Myth 9 design
This service manual will help you to optimally
service and repair the Sphinx Myth 9 CD player.
The heart of this very special CD player is formed
by the newest Philips CDM-12.4 transport
mechanism.
Two independent Bitstream D/A converters will
guarantee unsurpassed detailed audio
reproduction.
A unique feature is that the output sections are of a
totally discrete Class A design.
The “O core” power transformer uses completely
separated sections for the digital and analogue
supply. Combined with the integrated power line
suppression filter this ensures an extremely high
S/N ratio.
Almost all functions are accessible with the supplied
Sphinx Remote Control.
To obtain the maximum quality from this CD player
it is necessary to use it with top quality audio
components, preferably with other Sphinx
components.
1. UNPACKING
Before leaving the factory every Myth 9 is subjected
to stringent and extensive technical and exterior
quality inspection.
This ensures you will enjoy many years of high
quality audio performance from a perfect-looking
product.
After unpacking your Myth 9 we therefore
recommend you carefully check it for any transport
damage.
Even if the component is in perfect condition you
should still keep the packing materials. If you need
to transport your Myth 9 at a later time it will be best
protected by the original packing materials.
2. CONTACTING THE MANUFACTURER
In case of any problem not covered in this manual
or if you have other questions you may contact the
Sphinx International Service Department in The
Netherlands (local time: GMT +1h) during office
hours at the following numbers:
Telephone [phone]
Fax [phone]
E-mail [email protected]
It is always very helpful and efficient if you have all
relevant information about the specific product and
the problem ready.
Please also refer to the User Manual of the
Myth 9 for information about functions not
described in this manual.
It is important to familiarise yourself with the
special functions, operation and possibilities
of the Sphinx Myth 9.

SPHINX Myth 9 Service Manual
4
3. THE CD PLAYER AT A GLANCE
Front panel
1. CD tray: To be opened with the OPEN button.
Place the CD here.
To close: press the OPEN button or the PLAY
button or softly push against the front of the tray.
2. STOP: To stop CD playback.
3. PREV: To select a lower number track.
If you hold the button depressed it will activate a
fast reverse search in the current track.
4. TIME: This button selects the timer mode (right-
hand side of display):
lRemaining Track Time,
lTotal Remaining Time,
lTrack Time.
5. SHUF: To select the Shuffle Play mode, which
plays the tracks in random order. The SHUFFLE
indication will light.
6. REPEAT:To activate the Repeat Play mode. The
Play, Shuffle Play and Program Play modes will
be repeated until you deactivate the function.
The REPEAT indication will light.
7. STBY:To switch the CD player on and off. The
LED next to the button indicates the selected
function:
on LED is off
off LED is red
8. Receptor window for the IR signals from the
Remote Control.
9. Display: This will show all important data (more
information can be found on page 6)
10.PLAY: To start playback of the track indicated in
the left-hand side of the display
Note: If the CD tray is still open, it will close
automatically.
11.NEXT:To select a higher number track.
If you hold the button depressed it will activate a
fast forward search in the current track.
12.PAUSE: To temporarily interrupt the CD
playback. The display will show the PAUSE
indication. Pressing this button again (or PLAY)
will resume playback.
13.PROG: To select the Program mode: this enables
you to play only certain selected tracks. The
display will show »PROGR« and the PROGRAM
indication will blink.
14.PEAK: Pressing this button during STOP
activates the Peak Search mode. The PEAK
indication will light.
Pressing this button during Play mode activates
the Fade mode.
15.OPEN: To open and close the CD tray.
STOP PREVTIMESHUFREPEATSTBY
PLAYNEXTPAUSEPROG PEAKOPEN
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
1
5

SPHINX Myth 9 Service Manual
5
Rear panel
1. OUTPUT L and R: Connect this to the CD input
of the amplifier.
2. Control IN and OUT: To connect the optical
cable from the pre-amplifier and to the next
Sphinx component (e.g. tuner).
3. Manufacturer’s label: This shows important
data for the component, such as serial number
and mains power voltage.
4. Warning!: This shows important information
about the safety regulations for the Myth 9.
5. AC Power: Connect the mains cable to a mains
power outlet (100 - 240 VAC). Mains power
switch for the CD player.
The mains fuse is placed behind the cover.
Warning!
!
Donotopen!
Highvoltageinside!
Donotexposethisunit
torainormoisture.
ACVoltage:230V/60Hz.
Max.Power:40W
MadeinTheNetherlands
Manufactured by:
SphinxLaboratories
Fuse:0,5AT
OUTPUT
CONTROL
INOUT
L
R
1
2
3
4
5

SPHINX Myth 9 Service Manual
6
4. OPERATION
Connect the mains cable to a mains outlet.
Once you have finished connecting all components,
you can power on the Myth 9 with the mains switch
O / I (23).
The STBY LED (13) will light. The CD player is now
in standby mode.
From now on you should switch the CD player on or
off with the m STBY button (13).
That way, all circuits will remain at optimum
operating temperatures and the audio quality will be
100% immediately after switching on. Additionally it
significantly increases the life span of the
component.
Power on
Switch the Myth 9 on with the m STBY button.
It automatically checks whether there is a CD in de
tray (the display shows »READ«). If there is no CD
the display will show »noDISC«.
Playing a CD
Press the m OPEN button (12): the tray opens.
Place a CD in the tray and close it with the m OPEN
button (or the m PLAY button or by gently pushing
the tray inwards).
When the tray is closed the display shows »READ«
after which you will see the total number of tracks
(max. 99, left) and the total playing time of the CD
(right) in minutes:seconds. The lower horizontal row
of numbers indicates all tracks that have not been
played (in this case all of them).
With a press on m PLAY you start the playback of
Track 1. The display now shows the track number
(left) and the track’s playing time from the start
(right). This last indication will increase as long as
the CD is playing.
All tracks will be played sequentially in the normal
order.
Different time display
With the m TIME button you may select between
three different time displays. TRACK TIME is the
default. With each press on the button you then
select in this order:
REM TRACK TIME: remaining track time or
TOTAL REM TIME: remaining CD time or
TRACK TIME: track time from start of play.
Playing a different track
If you would like to play another track then you may
select it in a number of ways.
lEach press on the m NEXT button will select the
next (higher number) track.
Example: To select track 5 while track 1 is playing
depress the m NEXT button 4 times. The display
shows the new track number (left) and in the 1-15+
line the numbers from track 5 to the last will be lit.
lEach press on the m PREV button will select the
previous (lower number) track.
From track 1 you select the last track on the CD with
one button push.
The display shows the new track number (left) and
in the 1-15+ line the numbers from the current track
to the last will be lit.
lFrom the Remote you may directly select the
track number with the m 1-0 buttons (for more
information, see page 10).
Playing tracks in a different order
Normally the tracks are played in the order of the
CD. There are however three modes that allow you
to change the playing order and even can prevent
tracks from playing altogether.
The three modes are Program Play (PROG), Shuffle
Play (SHUF) and Repeat Play (REPEAT).

SPHINX Myth 9 Service Manual
7
Program Play (PROG)
With Program Play you can change the playback of
a CD:
Only play the tracks you want to hear (and thus
skip the others).
Play certain tracks a number of times.
Change the complete playing order.
Select those tracks that exactly fill one side of a
tape.
To do this you first have to select the wanted tracks
and program them into memory. Then you can start
Program Play mode.
Note: Tracks will be played in the order of
programming.
Programming is only possible when the CD has
stopped (STOP). If you press the m PROG button
during Play mode the display will show » GO TO
STOP «, while nothing further will happen.
Programming tracks
lPress the m PROG button.
The display shows »PROGR« and the PROGRAM
indication (right) blinks.
lSelect the first track with the m NEXT or m PREV
button.
The display shows under TRACK the track number.
lPress the m PROG button to store the track in
memory.
The display will show:
Under TRACK: the programmed tracks (in this
case 1…).
Under TOTAL TIME the total playing time of the
program.
In the 1-15 line all the selected tracks.
Note: To play the selected track more than once,
press the m PROG button the required number of
times.
lSelect all other tracks with the same method.
After each selection the display will be updated.
Note: You can program up to 30 tracks. If you try to
program more the display will show » FULL «.
Note: If you have selected a wrong track you can
not delete it from the program. You then have to
press the m STOP button twice and redo the whole
Programming procedure.
Playing the programmed tracks
After you have finished programming the tracks you
can start playing the program.
lPress the m PLAY button. The PROGRAM
indication (right) will light and playing starts with the
track that has been programmed first. All selected
tracks will then be played in the order of
programming.
lYou may also press the m PAUSE button. The
CD player first locates the start position of the first
programmed track and then selects Pause mode.
This might be handy when recording a tape. You
first can select the recorder to record-ready and
position the tape at the correct position. You may
start Program Play with another press on the
m PAUSE button.
Note: If you select the TOTAL REM TIME display
with the m TIME button the display will show the
remaining time for the program.
To stop Program Play
To temporarily stop Program Play: press the
m STOP button once. Pressing the m PLAY button
will resume Program Play.
To stop Program Play completely: press the
m STOP button twice.
The display then will show the same CD data as
right after placing a new CD in the tray.
Shuffle Play (SHUF)
The Shuffle Play mode lets you play the tracks in
random order during Play and Program Play modes.
The m SHUF button activates this mode (the
SHUFFLE indication will light) and random play will
start immediately.
At any time you may de-activate this mode with
another press on the m SHUF button. The playback
will continue and after the current track the next
track will now be played and not a random track.
Repeat Play (REPEAT)
The Repeat mode will repeat the selected Play
mode: Play, Program Play and Shuffle Play. There
are two options.
Repeat 1: Play will be repeated once.
Repeat: Play will be repeated continuously.
You may select the Repeat 1 mode by pressing the
m REPEAT button once: the REPEAT1 indication
will light.
With a second press you select the Repeat mode:
the REPEAT indication will now be lit.
Another press de-activates the mode.

SPHINX Myth 9 Service Manual
8
To temporarily halt Play (PAUSE)
All Play modes can be temporarily interrupted with
the m PAUSE button. Another press on this button
(or on the m PLAY button) will resume Play mode.
To stop Play (STOP)
Pressing the m STOP button during any mode will
de-activate this mode completely, the CD will stop
and the display will show the same CD data as right
after placing a new CD in the tray.
At any time you can also press the m OPEN button:
all modes will stop immediately and the tray will
open.
Power off
You switch the Myth 9 off (to stand-by) with the
m STBY button (13).
Special modes for recording CD’s
Recording a CD is highly simplified with two special
modes: Peak and Fade. The first will automatically
find the loudest signal level on the CD, the second
enables you to fade tracks in and out.
The m PEAK button (10) activates the:
Peak mode when the CD has stopped (STOP)
Fade mode when the CD is playing.
The PEAK mode
In Peak mode the CD player scans and analyses
the CD (the PEAK indication will blink). Finally the
display will show under TRACK the track number
and under TRACK TIME the time code of the
loudest part on the CD.
About 3 sec of this part will then continuously be
repeated (the time display will fallback to the starting
point) and the signal is sent to the output.
You can now simply adjust the recording level of the
recorder to the maximum value. So you don’t have
to worry about sudden signal peaks causing
distortion or noise caused by too low a recording
level!
You may de-activate the Peak mode by pressing the
m PLAY, m STOP or m OPEN button.
The FADE mode
With the Fade mode you can fade-out a track
(slowly decrease the level to 0), create a longer
space between two tracks and fade-in a track.
During Play mode (with the correct track and at the
correct moment!) press the m PEAK button. The
display will show sequentially (this will take some 5
seconds): » FADE ≡≡ «
» FADE =«
» FADE −«
At the same time the signal level is slowly reduced
to 0 (fade-out) and the Pause mode is selected. The
display shows the PAUSE indication (left), the track
number and the time at which the track has been
halted.
To resume playback you have two options:
1. Pressing the m PEAK button resumes playback
and the display will show (this takes some 5
seconds): » FADE −«
» FADE =«
» FADE ≡≡ «
At the same time the signal level is slowly increased
from 0 to the previous level (fade-in).
2. Pressing the m PAUSE or m PLAY button will
extinguish the PAUSE indication and the track will
resume playback, only now with the level
immediately at maximum: there is no fade-in!

SPHINX Myth 9 Service Manual
9
5. THE SPHINX REMOTE CONTROL
This single Sphinx Remote Control lets you control
all functions: not only of the Myth 9 but also of all
other Sphinx equipment.
Only the following buttons on the Remote apply to
the Myth 9 CD player (when pressed the »(((O« will
light in the lower left-hand side of the display), the
other buttons will not function:
Buttons
1. CD: To select the CD player. All buttons pressed
hereafter will control only the CD player
functions.
Note: The TUNER and PRE-AMP buttons will
not function.
2. STANDBY: Only works if you use a Sphinx
(pre-)amp and the Myth 9 is connected via the
optical cable
3. MUTE: Only works if you use a Sphinx (pre-)
amp, you don’t have to pre-select PRE-AMP.
4. 1 - 0: With these numbered buttons you may
select each CD track directly. To input a two digit
number (e.g. 16): shortly depress the button for
the first digit (the display shows »1—«) and
immediately select the second digit (6). If you
wait to long the player will select track 1.
Example: To select track 16 press 1and 6.
5. ññ/òò VOLUME: Only work if you use a Sphinx
(pre-)amp, you don’t have to pre-select PRE-
AMP.
6. BAND: This button has the same function as the
OPEN button on the front panel (12).
7. STOP: This button has the same function as the
STOP button on the front panel (3).
8. PAUSE: This button has the same function as
the PAUSE button on the front panel (6).
9. PLAY: This button has the same function as the
PAUSE button on the front panel (6).
10. PREV. TRACK: This button has the same
function as the PREV button on the front panel
(5).
11. REV. SEARCH: This button has the same
function as when you hold the PREV button (5)
depressed.
12. FWD. SEARCH: This button has the same
function as when you hold the NEXT button (4)
depressed.
13. NEXT TRACK: This button has the same
function as the NEXT button on the front panel
(4).
2
3
1
4
5
6
9
13
12
8
7
10
11

SPHINX Myth 9 Service Manual
10
Operation
The Sphinx Remote is used with several different
models and can therefore transmit different control
codes, depending on which model has been
selected with the select buttons (1).
Important: Always press the m CD button before you
send a command (even if you only have one Sphinx
component).
Otherwise it is possible that, although the Remote
sends a signal, nothing happens because the
transmitted signal is not 'recognised' by the
component.
You may check this yourself: if you press a button
and the symbol »(((O« in the display does not light,
the signal is not recognised.
Indoor the Remote may be used up to a distance of
7 meter, provided there is no strong sunlight in the
room and if you aim the Remote at the component.
Always aim the Remote straight at the front panel of
the component, the maximum offset angle is 30°.
Selecting without switching
Suppose, for instance, that you would like to select
the tuner to Radio 4 without interrupting CD
playback.
In that case you momentarily depress (not longer
than 0.5 sec) the m TUNER button and the m '4'
button. The same procedure is used for the other
system components.
If you depress the select button longer than 0.5 sec,
the system will select a different signal source (in our
example you will then hear the tuner playback).
Batteries
The two batteries have a life span of approximately
one year during normal use, but shorter when used
more intensely.
Replacement batteries: 1.5 V, model micro or penlite
or LR03 or AAA or AM4 (one of these codes is
indicated on the packaging and the batteries). You
may also use rechargeable 1.5 V batteries.
Note: Position the new batteries exactly as shown in
the illustration at the bottom of the battery
compartment, otherwise Remote will not work!
Encountering problems...
Remote Control does not work
Wrong component selected Select the correct one
Distance to component
exceeds 7 m Use Remote at closer range
Angle between Remote and
component exceeds ±30° Decrease angle
Sensor window on front dirty Clean window
Batteries empty or incorrectly
placed Use new batteries or replace the old ones
correctly
Strong (sun)light in room Shade off light source
Component is not switched on
(!) Switch it on
Component reacts differently than expected or
not at all
Wrong component selected Select the correct one
Component or Remote does
not function Check component with its original remote
Batteries in Remote empty Use new batteries

SPHINX Myth 9 Service Manual
11
6. TECHNICAL SPECIFICATIONS
Transport Philips CDM-12.4
D/A converter 1-Bitstream, TDA 1315 H + 2x TDA 1305 DAC
Completely independent for each channel
Bandwidth 0 – 20,000 Hz (+0/-0.2 dB)
Phase response error <0.5°
THD+N (IHF-A) <0.006% (2nd harm., 10 – 20,000 Hz)
IMD <0.01%
S/N ratio (IHF-A) >100 dB
Channel separation >94 dB
Output section Class AB, discrete throughout
Outputs 2x cinch (gold-plated)
Impedance <10 ohm
Sphinx Control 1x optical IN, 1x optical OUT
Remote Control Sphinx System full function
Power supply Internal, completely separate sections for digital
and analogue with integrated power line
suppression filter
Supply capacitance 16.280 µF total
Power consumption 11 W (9 W stand-by)
Dimensions (h x w x d) 75 x 434 x 330 mm
Weight 7 kg
This unit conforms to the EMC interference regulations issued by the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and therefore with international safety regulation IEC 65.
Technical specifications may be changed by SPHINX without prior notice if technical developments make this
necessary.
© 1999 Audioscript BV

SPHINX Myth 9 Service Manual
12
7. ADJUSTMENT PROCEDURES
The Myth 9 has no parameters needing adjustment!
Any specific and particular serviceable items may
be found in the ensuing Problems and Solutions
table on the next page.

SPHINX Myth 9 Service Manual
13
8. PROBLEMS AND SOLUTIONS
At the moment of writing the Myth 9 has no known
specific problems.
If in the future you encounter any problem(s) you
may enter the info in this table. This table can then
be used for future reference.
Please also send (by fax or e-mail) the specific
information to the Sphinx International Service
Department (see page 3): this info can then be
added to the general database to aid others.
Problem Cause Solution Refer to
page…

SPHINX Myth 9 Service Manual
14
9. DIAGRAMS AND PARTS LIST
The next pages contain a complete set of schematic
drawings including the associated parts list (if
applicable).

SPHINX Myth 9 Service Manual
15
General Overview Myth 9
DAC
dac.sch Display front.sch Power supply supply.sch
In- and output
io.sch

SPHINX Myth 9 Service Manual
16
Power Supply
C1
100n C4 100n
C3
100n
C2
100n
D1
BYD17 D2 BYD17
D3
BYD17 D4 BYD17
R1
1R
R2
1R
+C5
4700u/25V
C6
100n
Vout Vin
GND
U1
7805
C7
100n
+C8
10u/16V
C1_2
C1_3
C9
100n C12 100n
C11
100n
C10
100n
D5
BYD17 D6 BYD17
D7
BYD17 D8 BYD17
R3
1R
R4
1R
+C13
4700u/25V
C14
100n
Vout Vin
GND
U2
7805
C15
100n
+C16
10u/16V
C1_4
C1_5
C17
100n C20 100n
C19
100n
C18
100n
D9
BYD17 D10 BYD17
D11
BYD17 D12 BYD17
R5
1R
R6
1R
+C21
4700u/25V
C22
100n
Vout Vin
GND
U3
7050-12
C23
100n
+C24
10u/16V
C1_6
C1_7
C25
100n C28 100n
C27
100n
C26
100n
D13
BYD17 D14 BYD17
D15
BYD17 D16 BYD17
R7
1R
R8
1R
+C29
4700u/25V
C30
100n
Vout Vin
GND
U4
7050-12
C31
100n
+C32
10u/16V
C1_8
C1_9
AC1
AC2
AC3
AC4
AC5
AC6
AC7
AC8
GNDA
SW1.1
115_230
SW1.2
115_230 AC21
AC11
AC10
AC20
ACP2
ACP3
ACP4
ACP1
230
115
230
115
F1
1AT
F2
1AT
C2_1
C2_2
C2_3
C2_1
REL1B
COM1
REL1C
COM2
NO1
NC1
NO2
NC2
REL1A
NEC62R
D18
BYD17
C1_14
C1_15
C1_16
D17
AMP_PHDIOD
TR1
AMP_PHTRAN
C1_10
C1_11
C1_12
C1_13
C1_1

SPHINX Myth 9 Service Manual
17
D/A converter
SCK
37 WS
36
SD
35
SDAUX
34
DEEM 31 MUTE 32
I2SOEN 38
I2SSEL 33
VDD2
17
VDD1
42
IECOEN
9
IECO
8
IECIN0
6
IECIN1
5
INUAL 30
VSSD1 41 VSSD2 18
CHMODE 16
UNLOCK 12
FS32 13 FS44 14 FS48 15
COPY 29
PD 20
TESTA 28
TESTB 10
TESTC 11
RESET 19
CTRLM 21
STROBE 26
LDATA 25
LCLK 24
LMODE 23
IECSEL
7
RCint
44
Vref
2
VSSA
4
SYSCLO
40
SYSCLI
39
LADDR
22
UDAV
27
CLKSEL
43
RCfil
1
VDDA
3
IC4
TDA1315
LRCK
5
SCLK
4
SDATA
6
SCLKO
16
DEEM1 17
CLKS2 8 CLKS1 7
MUSB 19
SCLKI
12
DEEM2 18
DSMB 20
ATSB 21
TEST1 3 TEST2 11
VREF 26
CFR 24
VOR 25
VOL 23
CFL 23
DGND1
15
DGND2
9
VD+
10
DGND
27
AGND
2
VA+
1
VO+
28
IC5
TDA1305T
1
24
IC2A
7400
147
IC2E
7400
C7
100n
C6
10n
R16
3R9
R8
75R
DIG_IN
CN1
CN3
+5VD
DGND
DGND
SCLK
SDATA
LRCK
DGND
DEEM
D28
LED
D27
LED
D26
LED
D25
LED
D29
LED
R10
1k
R9
1k
+5VD
D9
1N4148
D8
1N4148
R3
4k7 R4 4k7
PLL PROF FS32 FS44 FS48
DEEM
DGND C15
100n
+5VD
C11
2n2 C10 100n C14 100n
+C12
6u8/35V
+C13
68u/6V3
R11
470R
R12
3R9 +5VD
DGND
LRCK
SCLK
SDATA
256FS
C29
100n C37 100n
C34
100n
+C30
10u/16V
+C31
470u/25V
R31
3R9
R1
4k7
DGND
DGND
+5VD
+C36
470u/25V
+C35
10u/16V
+C39
470u/25V
+C38
10u/16V
R33
3R9
+5VA
R32
3R9
+5VA
C32
100n
+C33
10u/16V
C48
1n
C41
1n
DGND
LRCK
5
SCLK
4
SDATA
6
SCLKO
16
DEEM1 17
CLKS2 8 CLKS1 7
MUSB 19
SCLKI
12
DEEM2 18
DSMB 20
ATSB 21
TEST1 3 TEST2 11
VREF 26
CFR 24
VOR 25
VOL 23
CFL 23
DGND1
15
DGND2
9
VD+
10
DGND
27
AGND
2
VA+
1
VO+
28
IC6
TDA1305T
LRCK
SCLK
/SDATA
C1
100n C18 100n
C8
100n
+C2
10u/16V
+C3
470u/25V
R17
3R9
R2
4k7
DGND
DGND
+5VD
+C17
470u/25V
+C16
10u/16V
+C20
470u/25V
+C19
10u/16V
R52
3R9
+5VA
R51
3R9
+5VA
C4
100n
+C5
10u/16V
C21
1n
C65
1n
DGND
SDATA
R5
3R9
C76
100n
DGND
+5VD
DEEM2
DEEM1
DEEM1
DEEM2
-
2
+
3
6
U2A
AD711N
C46
100p_pol
C45
100p_pol
R35
120R
R37
3k3
R36
3k3
DCADJL
R68
10k
R69
120R
C70
100p_pol
C83
33p
R66
10k
R67
OPT
Q3
BC807
Q2
BC807
Q6
2SA1668
Q7
2SC4382
Q5
BC817
Q4
BC817
R56
560R R57 560R
R58
10R
R59
10R
R54
560R R55 560R
R53
4k7
D11
LED
C66
100n
DCL-
DCL+
-2
+3
6
U1A
TL071P
R65
100k
C67
1u/50V
R63
100k
R64
100k
C68
100n
DCADJL
R6
49R9 C51
470p_pol
-
2
+
3
6
U4A
AD711N
C44
100p_pol
C43
100p_pol
R38
120R
R41
3k3
R86
3k3
DCADJR
R84
10k
R85
120R
C75
100p_pol
C84
33p
R82
10k
R83
OPT
Q9
BC807
Q8
BC807
Q12
2SA1668
Q13
2SC4382
Q11
BC817
Q4
BC817
R74
560R R75 560R
R76
10R
R77
10R
R72
560R R73 560R
R71
4k7
D12
LED
C71
100n
DCR-
DCR+
-2
+3
6
U5A
TL071P
R81
100k
C72
1u/50V
R79
100k
R80
100k
C73
100n
DCADJR
R7
49R9 C52
470p_pol
256FS
74
U2B
AD711N
74
U1B
TL071P
C53
100n
C54
100n
+C57
10u/16V
+C58
10u/16V
+C62
470u/25V
+C61
470u/25V
DCL+
DCL-
+15V
-15V
R61
3R9
R60
3R9
74
U4B
AD711N
74
U5B
TL071P
C55
100n
C56
100n
+C60
10u/16V
+C59
10u/16V
+C63
470u/25V
+C64
470u/25V
DCR+
DCR-
+15V
-15V
R61
3R9
R60
3R9
CN4
REL1B REL1C
RIGHT LEFT
LEFT
RIGHT

SPHINX Myth 9 Service Manual
18
Input / Output
21 IC1A
7404
43 U1B
7404
65 U1C
7404
89 U1D
7404
1011 U1E
7404
1213 U1F
7404
147
U1G
7404
R20
47k
R48
47k C9
100n
DGND
C2_2
C2_1
+5VD
C1_1
R23
1K
R22
100K
D1
1N4148
D3
6V2 +C27
220u/25V
Q14
BCV47
R28
1K
R18
4K7
R19
1K
D6
1N4148
D4
1N4148 +C26
1u/16V R24
47K
R25
4K7 D5
6V2
R26
1K
D7
1N4148
R27
47K
R30
1K
R29
4K7
Q1
BCV47
C28
100n
D10
BYD77
REL1A
6V/150mW
+5VD
R21
3R9
+C25
10u/16V C24
100n
DGND
+5VD
DGND
S
6
D
5
CLK
3
R
4Q2
Q1
IC3A
4013
S
8
D
9
CLK
11
R
10 Q12
Q13
IC3B
4013
147
IC3C
4013
C22
100n
R93
47k
DGND
+5VD
R94
4k7
R87
1k
R88
4k7
Q16
BCV47
DGND
R50
390R
frontpr
C1_12 C1_10
C1_13 C1_11
R92
4k7 R95 390R
Q17
BCV47
R91
100k
DGND
+5VD
D14
1N4148
R89
1k
R90
4k7
Q15
BCV47
DGND
C1_15
C1_14
+5VD
POWER_RELAYS
DGND
D13
BYD17
D2
BYD17
R15
4k7
+5VD +5VA
C1_2
C1_3
C1_4
C1_5
C1_6
C1_7
C1_8
C1_9
C1_16
+C23
470u/25V
+5VD
+C42
470u/25V
+5VA R14
3R9
+C77
470u/25V
R98
0R
R96
0R
+15V
+C78
470u/25V
R97
0R
-15v
C82
100n C81 100n C80 100n C79 100n
C2_3
DGND DGND
opto_in opto_out
frontpr
AC1

SPHINX Myth 9 Service Manual
19
Display
V+ 2
D1
GND 3
IR
IR1
SFH506-38 DGND
IR
IR+
1-8
1-7
1-6
1-5
1-4
1-3
1-2
1-1
4-3
4-2
4-1
1-7 1-8 3-4 1-6 1-5 1-4 1-3 1-2 1-1 3-5 4-3 4-2 4-1 3-1 3-2 3-3 3-6 3-7
PAUSE TRACK PEAK TOTAL REM TTIME
SPACE
12345678910 11 12 13 14
DISPLAY_BOARD
SHUFFLE TIME
REPEAT STOP
PLAY OPEN/CL
PAUSE PREVIOUS
PEAK
NEXT
PROGRAM
STANDBY
D1
1N4148 D2 1N4148 D3 1N4148
D4
LED
C2-2
C2-3C2-1
DGND

SPHINX Myth 9 Service Manual
20
Parts List
Designator Part Type Description
C1 100n MKT capacitor
C1 100n MKT capacitor
C10 100n MKT capacitor
C10 100n MKT capacitor
C11 100n MKT capacitor
C11 2n2 MKT capacitor
C12 100n MKT capacitor
C12 6u8/35V Electrolytic capacitor
C13 4700u/25V Electrolytic capacitor
C13 68u/6V3 Electrolytic capacitor
C14 100n MKT capacitor
C14 100n MKT capacitor
C15 100n MKT capacitor
C15 100n MKT capacitor
C16 10u/16V Electrolytic capacitor
C16 10u/16V Electrolytic capacitor
C17 100n MKT capacitor
C17 470u/25V Electrolytic capacitor
C18 100n MKT capacitor
C18 100n MKT capacitor
C19 100n MKT capacitor
C19 10u/16V Electrolytic capacitor
C2 100n MKT capacitor
C2 10u/16V Electrolytic capacitor
C20 100n MKT capacitor
C20 470u/25V Electrolytic capacitor
C21 1n MKT capacitor
C21 4700u/25V Electrolytic capacitor
C22 100n MKT capacitor
C22 100n MKT capacitor
C23 100n MKT capacitor
C23 470u/25V Electrolytic capacitor
C24 100n MKT capacitor
C24 10u/16V Electrolytic capacitor
C25 100n MKT capacitor
C25 10u/16V Electrolytic capacitor
C26 100n MKT capacitor
C26 1u/16V Electrolytic capacitor
C27 100n MKT capacitor
C27 220u/25V Electrolytic capacitor
C28 100n MKT capacitor
C28 100n MKT capacitor
C29 100n MKT capacitor
C29 4700u/25V Electrolytic capacitor
C3 100n MKT capacitor
C3 470u/25V Electrolytic capacitor
C30 100n MKT capacitor
C30 10u/16V Electrolytic capacitor
