Squier Standard HSS Strat User manual

Squier Std. Black & Chrome HSS Strat
Rosewood- m/n 0321703506
Loc # Description Part Number
1 Standard Tuners (set of 6) 005-5426-000
2 Bone Nut (blank) (2) 099-4920-000
3 Vintage String Guides (pack of 2) 099-4910-000
4 Strap Buttons (2) 099-4915-000
5 Pickguard (mirror) 006-9880-000
5a Pickguard Screws (24) 099-4923-000
6 Standard Neck Pickup 005-5381-000
7 Standard Middle Pickup 005-5382-000
8 Standard Bridge Pickup 005-5384-000
9-11 500K Split Shaft Pot 006-2730-000
9-11a Volume/Tone Knob Set (chrome) 005-1793-000
12 5 Way Pickup Selector Switch 005-5412-000
12a Switch Tip (2) (black) 099-4939-000
13 Output Jack (2 pack) 004-7329-049
17 Jack Plate (chrome) 099-1940-100
18 Bridge Assembly 005-5408-000
18a Tremolo Arm 004-1359-000
Last Revision Date: 8/28/2008
Page 1 of 3

Wiring Diagram
Last Revision Date: 8/28/2008
Page 2 of 3

Control Function
Last Revision Date: 8/28/2008
Page 3 of 3
