Street Hopper RM-828B User manual

The Street Hopper Bluetooth Portable Speaker System with rechargeable battery will stream your
favorite music for hours, from any Bluetooth device, SD Card or USB.
Street Hopper gives you a full Multi-Color LED light show, with a variation of programmed light
displays. All controlled via the front panel, remote control or Discolor Dj App.
The Discolor Dj free app is available from Android/Apple App Stores. The Discolor DJ app gives you
full control of the Street Hopper features via bluetooth connection. Control the source, volume and
EQ levels. Change the LED lighting to any color and lignt profile to set the mood. Choose and
playback music from your music library, or the USB/SD. The Street Hopper portable design and go
anywhere with anything feature,like the Microphone input and Guitar input for those plug and play
times.

Interface Index
fig.6 fig.7
6
Song 1
Song 2
There is twodifferent ways to connect the Bluetooth feature for STREET HOPPER 8.
Bluetooth direct connect from theSTREET HOPPER 8, or Bluetooth connect via
the Discolor DjApp.
Note:The STREET HOPPER 8 can be connected to both Bluetooth direct and the
Discolor DjApp at thesame time. Bluetooth direct will be usedto playback any
music media andapps, such asPandora, You Tube,your music playeretc. All
control of themusic media willbe controlled throughtheir prospected appcontrols.
For Bluetooth connect from the DiscolorDj Appyou will havefull remote control
of the STREETHOPPER 8 features,playback controls, volume& EQ aswell as
lighting control.
1. Turn onBluetooth via your devicesettings,
locate and pair toSTREET HOPPER 8.
2. Verify thatyour device is connectedto
the STREET HOPPER 8device.
3. Download the FREEDiscolor DJ Appin
your App Storeand install it.
4. Now activate yourapplication and
select Bluetooth symbol.
5. Select STREET HOPPER8 APP
to connect via theapplicatiom.
NOTE: This is a sample interface, the interfacemay vary
depending on your certain device.
Conectividad App/Bluetooth
1
STREET HOPPER 8 APP
STREET HOPPER 8STREET HOPPER 8
STREET HOPPER 8
Song 1
Song 2
fig.8
FCC Statement
Changes or modifications not expressly approved by the party responsible for
compliance could voidthe user's authorityto operate theequipment.
This equipment hasbeen tested andfound to complywith the limits for a Class
B digital device,pursuant to Part15 of the FCC Rules. These limits are
designed to providereasonable protection againstharmful interference ina
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may causeharmful interference toradio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, theuser is encouragedto try to correct the interference byone or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect theequipment into anoutlet on acircuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions
(1)this device maynot cause harmfulinterference, and (2)this device must
accept any interferencereceived, including interferencethat may cause
undesired operation.

Note:
There should notbe an obstruction
between the unitand remote control
Remote Control Rangeof Operation
Remote Control Fuctions
2
Interface Index
fig.5.1
Rainbow
mixes colors of
a rainbow
Heartbeat rS
glows red to simulate
slow heartbeat
Alarm
simulates an alarm
with red & blue lights
Feel Green
mixes colors in different
green hues
Heartbeat
glows red simulating
a heartbeat
Heartbeat bS
glows blue to simulate
a slow heartbeat
Breathings
color mixing simulating slow
breathing
Music
combines different colors to
the rhythm of your music
Sunset
mixes color in
light tones
Flash
mixes colors to
simulate a strobe
light
Heartbeat gS
glows green to simulate
a slow heartbeat
Rainbow s
mixes colors of a rainbow
slowly
1. Active Illumination You can enable or disable
the illumination
2.Lumin controls the intensityof illumination
3.Color Wheel Here you canselect colors directly
and change thepitch by draggingit to any part
4. Fixed ColorsControl 6 different color tones
5. Profiles Access lightingprofiles fig.5.1
fig.5
5
TREBLE-9 to +9........controltreble levels
MICROPHONE VOLUME 0to 16........control microphone volume
GUITAR VOLUME 0 to 16...............control guitar volume
ECHO 0 to16............control echo levels
LIGHT MODE 1to 12.................control differentlighting levels
BASS -9 to+9.........control bass levels
+
-MENU
1.Stand By(Unit will beput in asleep mode)
2.Master Volume +Up / -Down
3.Function +/- (By clicking, youcan browse inmenu
functions. Increase/Decrease bass,treble, volume control
and microphone)
4. Mute Button
5. Previous
6. Play /Pause
7. Input(SD/USB/LINE IN/Bluetooth)
8. Menu(Use +/- toadjust menu selections)
9. Repeat Button
10. Next Button

- +
FUNCTION
-+
VOLUME
MIC GUITAR LINE IN DC 13.5V
POWER MENU
SD
USB
OUTPUT 5V 1A
SOURCE
APP:
Discolor DJ
Panel
* Note: For optimal performance, charge battery for a period of 8 hours
Control Panel Functions
3
1
234791112 13
14
568107
1. LED PanelFunction Display
2. Function -/+(Turning TheKnob You Can Browsethe Menu Functions,
Increase/Decrease Bass, Treble, Volume and MicrophoneLevel)
3. Mic Input
4. Guitar Input
5. Power/SOURCE: Switch
functions by pressingbutton, Holding this buttonfor 3 secondswill tum offthe
unit.
6. Menu change from onefunction to another
7. SD/USB(USB 5V 1A)
8. Previous Song
9. Play /Pause
10. Line In
11. ChargeIndicating LED
Red, indicates Charging
Green indicates charging iscomplete
12. DC 13.5V - ChargerInput
13. Next Song
14. Volume -/+: Adjusts main volume
POWER/USB/LINE IN/BLUETOOTH/FM:
TREBLE-9 to +9........controltreble levels
MICROPHONE VOLUME 0to 16........control microphone volume
GUITAR VOLUME 0 to 16...............control guitar volume
ECHO 0 to16............control echo levels
LIGHT MODE 1to 12.................control differentlighting levels
BASS -9 to+9.........control bass levels
fig.1
Interface Index
1
2
3
4
5
6
7
1. Music SelectionChoose from songsyou
have on yourdevice fig.1
2. Bluetooth Connect to theStreet Hopper unitvia
Bluetooth fig.2
3.L ine In/AUX Mute fig.3
4fig.4
5. Light ProfilesControl different lighting profiles
& customize yourStreet Hopper unitfig.5
6.Equalizer Control equalizer levels& microphone/
guitar volume fig.6
7. USB control music fromUSB Card fig.7
8.SD control music fromSD card fig.8
.FM Radio
fig.3
-Mute
fig.2
-Bluetooth
Synchronizing your app
with the Street Hopper
Unit
Mute line in/aux input
when connected
Press enter into FM
radio mode, press
SCAN to enterinto
radio programauto
matic scan.Press
for radio
program manual
scan, Top and
bottom trimming,
slide around to
adjust radio frequency
between 87.5MHz~
108.0MHz.
fig.4
4
8
STREET HOPPER 8 APP
