Sun Cobalt™
Control Station
Installation and Setup Guide

Copyright © 1997-2001 Sun Microsystems, Inc., 901 San Antonio Road, Palo Alto, California
94303-4900 U.S.A. All rights reserved.
Sun Microsystems, Inc. has intellectual property rights relating to technology embodied in the
product that is described in this document. In particular, and without limitation, these intellectual
property rights may include one or more of the U.S. patents listed at
http://www.sun.com/patents
and one or more additional patents or pending patent applications
in the U.S. and other countries.
This document and the product to which it pertains are distributed under licenses restricting their use,
copying, distribution and decompilation. No part of the product or of this document may be
reproduced in any form by any means without prior written authorization of Sun and its licensors, if
any.
Third-party software, including font technology, is copyrighted and licensed from Sun suppliers.
Parts of the product may be derived from Berkeley BSD systems, licensed from the University of
California. UNIX is a registered trademark in the U.S. and in other countries, exclusively licensed
through X/Open Company, Ltd.
Sun, Sun Microsystems, the Sun logo, Java, JavaScript, JDK, Sun Cobalt, Sun Cobalt RaQ, Sun
Cobalt CacheRaQ, Sun Cobalt Qube and the Sun Cobalt logo are trademarks or registered trademarks
of Sun Microsystems, Inc. in the United States and other countries.
Netscape and Netscape Navigator are trademarks or registered trademarks of Netscape
Communication Corporation in the United States and other countries.
Legato NetWorker is a registered trademark of Legato Systems, Inc. Linux is a trademark of Linus
Torvalds.
Federal Acquisitions: Commercial Software -- Government Users Subject to Standard License Terms
and Conditions.
DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESS OR IMPLIED CONDITIONS,
REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT,
ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO
BE LEGALLY INVALID.
Copyright © 1997-2001 Sun Microsystems, Inc., 901 San Antonio Road, Palo Alto, Californie
94303-4900 États-Unis. Tous droits réservés.
Sun Microsystems, Inc. détient des droits de propriété intellectuelle sur la technologie réunie dans le
produit qui est décrit par ce document. Ces droits de propriété intellectuelle peuvent s’appliquer en
particulier, sans toutefois s’y limiter, à un ou plusieurs des brevets américains répertoriés à l’adresse
http://www.sun.com/patents
et à un ou plusieurs brevets supplémentaires ou brevets en instance
aux Etats-Unis et dans d’autres pays.
Ce produit ou document est distribué avec des licences qui en restreignent l’utilisation, la copie, la
distribution et la décompilation. Aucune partie de ce produit ou document ne peut être reproduite sous
aucune forme, par quelque moyen que ce soit, sans l’autorisation préalable et écrite de Sun et de ses
bailleurs de licence, s'il y en a.
Le logiciel détenu par des tiers, et qui comprend la technologie relative aux polices de caractères, est
protégé par un copyright et licencié par des fournisseurs de Sun.
Des parties de ce produit pourront être dérivées des systèmes Berkeley BSD licenciés par l’Université
de Californie. UNIX est une marque déposée aux Etats-Unis et dans d’autres pays et licenciée
exclusivement par X/Open Company, Ltd.

Sun, Sun Microsystems, le logo Sun, Java, JavaScript, JDK, Sun Cobalt, Sun Cobalt RaQ, Sun Cobalt
CacheRaQ, Sun Cobalt Qube et le logo Sun Cobalt sont des marques de fabrique ou des marques
déposées de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays.
Netscape et Netscape Navigator sont des marques de fabrique ou des marques déposées de Netscape
Communication Corporation aux Etats-Unis et dans d’autres pays.
Legato NetWorker est une marque déposée de Legato Systems, Inc. Linux est une marque de fabrique
de Linus Torvalds.
LA DOCUMENTATION EST FOURNIE “EN L’ETAT” ET TOUTES AUTRES CONDITIONS,
DECLARATIONS ET GARANTIES EXPRESSES OU TACITES SONT FORMELLEMENT
EXCLUES, DANS LA MESURE AUTORISEE PAR LA LOI APPLICABLE, Y COMPRIS
NOTAMMENT TOUTE GARANTIE IMPLICITE RELATIVE A LA QUALITE MARCHANDE, A
L’APTITUDE A UNE UTILISATION PARTICULIERE OU A L’ABSENCE DE CONTREFAÇON.
Part Number / Numéro de pièce : 070-00357-01
Date : 11-2001

Installation Guide—Sun Cobalt Control Station v
Important Safeguards
For your protection, please read and understand all of the safety and operating
instructions regarding your Sun Cobalt™ Control Station and retain for future
reference.
1. Ventilation
The vents and fan openings on the Sun Cobalt Control Station protect it from
overheating. These openings must not be blocked or covered. This product
should not be placed in a built-in installation unless proper ventilation is
provided.
2. Lithium Battery
The lithium battery on the system board provides power for the real-time clock
and CMOS RAM. The battery has an estimated useful life expectancy of 5 to
10 years. If your system no longer keeps accurate time and date settings, it may
be time to change the battery. Contact Sun Microsystems™ for service
information.
Warning: There is a danger of explosion if the battery is incorrectly
replaced or replaced with the wrong type of battery. Replace only
with the same or equivalent type recommended by the equipment
manufacturer. Dispose of used batteries according to
manufacturer’s instructions.
Avertissement : Il y a danger d’explosion s’il y a remplacement
incorrect de la pile. Remplacer uniquement avec une pile du même
type ou d’un type équivalent recommandé par le fabricant. Mettre
au rebut les piles usagées conformément aux instructions du
fabricant.
Achtung: Explosionsgefahr wenn die Batterie in umgekehrter
Polarität eingesetzt wird. Nur mit einem gleichen oder ähnlichen,
vom Hersteller empfohlenen Typ, ersetzen. Verbrauchte Batterien
müssen gemäß den Anweisungen des Herstellers verwertet werden.

Important Safeguards
vi Installation Guide—Sun Cobalt Control Station
3. Power Cord
4. Electrical Shock
To reduce the risk of electrical shock, do not disassemble this product. Take it to
a qualified service person when service or repair work is required. Opening or
removing covers may expose you to dangerous voltage or other risks. Incorrect
reassembly can cause electric shock when this product is subsequently used.
5. Operating the unit in an equipment rack
If you plan to install the Sun Cobalt Control Station in an equipment rack, take
the following precautions:
a. Ensure the ambient temperature around the Sun Cobalt Control Station
(which may be higher than the room temperature) is within the specified
limits. Refer to the PDF Product Specifications .
b. Ensure there is sufficient air flow around the unit.
c. Ensure electrical circuits are not overloaded; consider the nameplate
ratings of all the connected equipment and ensure you have overcurrent
protection.
d. Ensure the equipment is properly grounded, particularly any equipment
connected to a power strip.
e. Do not place any objects on top of the Sun Cobalt Control Station.
!
Caution: The power-supply cord is used as the main disconnect
device. Ensure that the socket outlet is located or installed near the
equipment and is easily accessible.
!
Attention : Le cordon d’alimentation sert d’interrupteur général. La
prise de courant doit être située ou installée à proximité du matériel
et offrir un accès facile.
!
Achtung: Zur sicheren Trennung des Gerätes vom Netz ist der
Netzstecker zu ziehen. Vergewissern Sie sich, dass die Steckdose
leicht zugänglich ist.

Installation Guide—Sun Cobalt Control Station vii
6. Browsers
Both Netscape Navigator™ and Microsoft Internet Explorer can sometimes
suffer unexplained failures. When using a Web browser to interact with your Sun
Cobalt Control Station, you may occasionally experience a browser failure.
Released product versions of the browsers are usually more reliable than beta
versions and later versions typically work the most reliably. A browser program
failure, although annoying, does not adversely affect the data on your Sun Cobalt
Control Station.
To use the Sun Cobalt Control Station, you need a computer (attached to the
network) that uses a Web browser (for example, Netscape Navigator, version 4.7
or later, or Microsoft Internet Explorer, version 5.0 or later). To manage the
control station from the browser-based user interface (UI), known as the Server
Desktop, you must enable cookies, cascading style sheets and JavaScript™ on
your browser (these features are normally enabled by default).
Regulations and Information
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Re-orient or re-locate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
In order to maintain compliance with FCC regulations, shielded cables must be
used with this equipment. Operation with non-approved equipment or unshielded
cables is likely to result in interference to radio and TV reception. The user is
cautioned that changes and modifications made to the equipment without the
approval of manufacturer can void the user’s authority to operate this equipment.
This equipment is in compliance with Underwriters Laboratories (UL) and is
UL-listed.

Important Safeguards
viii Installation Guide—Sun Cobalt Control Station

Installation Guide—Sun Cobalt Control Station ix
Contents
Important Safeguards v
1 Introduction 1
Requirements for the Sun Cobalt™ Control Station 1
Documentation 2
2 Installation 3
Installing the Sun Cobalt™ Control Station 3
Front view of the Sun Cobalt Control Station 4
Rear view of the Sun Cobalt Control Station 5
Installing the Sun Cobalt Control Station 6
Connecting to the network 7
Connecting the power cord 8
Powering on the Sun Cobalt Control Station 8
Configuring the Sun Cobalt Control Station for the network 9
Using the LCD console to configure the network 10
Setting the configuration 11
3 Setup Wizard 15
Active Assist — Online Help 16
Configuring the Sun Cobalt™ Control Station with the Setup Wizard 16
Binary Code License Agreement 17
Administrator Settings 18
Password guidelines 19
Time Settings 20
Network Integration 21
Gateway on a LAN 23
Product Registration 25
Completing configuration with the Setup Wizard 26
Documentation 26

Contents
x Installation Guide—Sun Cobalt Control Station

Installation Guide—Sun Cobalt Control Station 1
Chapter 1
Introduction
The Installation Guide takes you through the process of connecting and
configuring the Sun Cobalt™ Control Station for your network. A typical setup
process takes less than 15 minutes, after which you can begin using all of the
services on the Sun Cobalt Control Station.
Requirements for the Sun Cobalt™
Control Station
To use the Sun Cobalt Control Station, you need:
• A 10/100BaseTX Transmission Control Protocol/Internet Protocol (TCP/IP)
-based local area network (LAN).
• A personal computer (attached to the network) that uses a Web browser (for
example, Netscape Navigator, version 4.7 or later, or Microsoft Internet
Explorer, version 5.0 or later).
To manage the Sun Cobalt Control Station from the browser-based user
interface (UI), known as the Server Desktop, you must enable cookies,
cascading style sheets and JavaScript™ on your browser (these features are
normally enabled by default).
• Network parameters, which you can obtain from your network
administrator; these include the Sun Cobalt Control Station’s assigned
IP address, the subnet mask of your network and, if communicating with
other networks, a gateway or router address.

Chapter 1: Introduction
2 Installation Guide—Sun Cobalt Control Station
Documentation
You can access the user manuals in PDF format from the Server
Desktop UI. If you have installed third-party software on the Sun
Cobalt Control Station, the relevant documentation is also available.
To access the PDF file for a user manual, click on the help icon in the top right
corner. A separate browser window opens displaying a list of PDF files available.
Click the link for a PDF file; you can open the PDF file in the browser window or
save it to your personal computer.

Installation Guide—Sun Cobalt Control Station 3
Chapter 2
Installation
This chapter guides you through the process of connecting and configuring the
Sun Cobalt™ Control Station for your network.
Installing the Sun Cobalt™ Control
Station
The installation process occurs in two phases.
• Chapter 2, “Installation”, explains the physical connection of the Sun Cobalt
Control Station to a power source and the network.
• Chapter 3, “Setup Wizard”, explains the process of network integration
through a browser-based Setup Wizard.
Figure 1 and Figure 2 show the controls, indicators and connectors on the Sun
Cobalt Control Station.

Chapter 2: Installation
4 Installation Guide—Sun Cobalt Control Station
Front view of the Sun Cobalt Control Station
Figure 1. Front view of the Sun Cobalt Control Station
1. The Status Indicators signal Ethernet and hard-disk-drive activity:
Tx/Rx (Transmit/Receive) blinks when there is network traffic on the
primary interface.
Link indicates an active network connection on the primary interface.
Col blinks when a collision is detected on the primary interface.
100 M indicates that 100 BaseT ethernet is being used on the primary
interface.
Disk indicates activity on the hard disk drive.
2. The Web indicator blinks to indicate Web activity.
3. The Logo Badge glows when the Sun Cobalt Control Station is powered on.
4. The LCD screen displays messages and values entered. Use the arrow
buttons to toggle between choices or to enter values.
5. You can use the recessed Reset Password button if you forget the password
for the Sun Cobalt Control Station administrator.
6. The LCD arrow buttons allow you to enter network configuration
information, configure a UPS unit, reboot the control station and power
down the control station.
S
E
123456

Installing the Sun Cobalt™ Control Station
Installation Guide—Sun Cobalt Control Station 5
Rear view of the Sun Cobalt Control Station
Figure 2. Rear view of the Sun Cobalt Control Station
1. The Security lock hole is used to lock the unit to a secure location.
2. The Cooling fans maintain proper operating temperature. Ensure that the
ventilation holes are not blocked.
3. The USB port provides a Universal Serial Bus (USB) connection.
4. The SCSI connector enables a Small Computer System Interface (SCSI)
connection for connecting such devices as hard disk drives.
5. The Network status indicators/OK to Power Off signal network activity
and information. The OK to Power Off light flashes when it is safe to turn
the power off.
6. The Serial console port allows you to connect serial devices.
7. The Serial connector allows you to connect an uniterruptible power supply
(UPS) to the serial port for Smart UPS support.
8. The PCI expansion slot provides space for adding a PCI card.
The Network connectors enable ethernet network connections and accept
the 10/100 BaseT network cables.
9. Network connection 2 .
10. Network connection 1 .
11. Cooling fan .
12. The Power switch toggles the power on or off.
13. The Power socket receives the AC cord that is provided.
100 - 240 VAC 50/60 Hz
1.4 A 60W max
Link Tx/Rx Link Tx/Rx
3467
2
8
9
5
1
10 11 12 13
Sun Cobalt and RaQ are trademarks
of Sun Microsystems, Inc.
www.cobalt.com
P/N 550-00282-01

Chapter 2: Installation
6 Installation Guide—Sun Cobalt Control Station
Installing the Sun Cobalt Control
Station
You can place the Sun Cobalt Control Station on a flat surface—for example, a
desk, shelf or table top—or mount it in a standard 19-inch equipment rack.
If you plan to use the control station on a flat surface, attach the rubber feet to the
five indentations in the bottom of the case; see Figure 3.
Figure 3. Rubber feet for the Sun Cobalt Control Station
✍
Caution: If you operate the Sun Cobalt Control Station in an
equipment rack, see the precautions described in “5. Operating the
unit in an equipment rack” on page vi.
Rubber feet
S
E

Installing the Sun Cobalt Control Station
Installation Guide—Sun Cobalt Control Station 7
If you plan to operate the control station in an equipment rack, you must first
attach the mounting ears included with the server.
Attach the ears to the chassis with the screws included with the control station
(see Figure 4), near either the front or the rear of the case. Now position the
control station in the equipment rack and attach the ears securely to the rack.
Figure 4. Mounting ears for the Sun Cobalt Control Station
Connecting to the network
Connect one end of a Category 5 Ethernet cable to the 10/100 BaseT Network 1
connector on the control station; see Figure 5. Connect the other end of the cable
to an existing network socket.
Figure 5. Network connectors
S
E
S
E
100 - 240 VAC 50/60 Hz
1.4 A 60W max
Sun Cobalt and RaQ are trademarks
of Sun Microsystems, Inc.
www.cobalt.com
P/N 550-00282-01
Link Tx/Rx Link Tx/Rx
Network connection 1
Network connection 2

Chapter 2: Installation
8 Installation Guide—Sun Cobalt Control Station
Connecting the power cord
Connect the power supply cord to the Sun Cobalt Control Station and to an
electrical outlet (100-240 volts AC, 50/60 Hz; refer to the PDF Product
Specifications ).
Powering on the Sun Cobalt Control Station
Turn on the power by pressing the On/Off switch on the back of the Sun Cobalt
Control Station.
The hard disk drive spins up, the fan turns on, and the LCD screen lights up. The
“C” logo scrolls across the screen.
A number of status messages are displayed on the LCD screen as the control
station completes its boot process. When complete, the LCD screen displays
PRIMARY IP ADDR:
✍
Caution: It is important to follow the proper power-down
procedure before turning off the Sun Cobalt Control Station. See
“Powering Down” in the PDF Using the LCD Console .

Installing the Sun Cobalt Control Station
Installation Guide—Sun Cobalt Control Station 9
Configuring the Sun Cobalt Control Station for
the network
Now that you have made the network and power connections, you can configure
the network settings.
The Sun Cobalt Control Station requires specific network information to function
properly.You must enter the necessary information using the LCD console on the
front panel.
Before you proceed, make sure you have the following information:
• the IP address assigned to the Sun Cobalt Control Station by you network
administrator
• the subnet mask of your network
• the gateway or router address (necessary only if communicating with other
networks)

Chapter 2: Installation
10 Installation Guide—Sun Cobalt Control Station
Using the LCD console to configure the network
Figure 6 shows the LCD console for the Sun Cobalt Control Station.
The LCD screen on the front of the control station displays two lines of text. The
top line of the LCD presents instructions on data to enter; the bottom line
displays the data already entered. Use the arrow buttons to the right of the LCD
screen to enter the required network information manually.
For more information about the LCD console, refer to the PDF Using the LCD
Console .
Figure 6. LCD console
During startup, the LCD screen displays status information about the boot
process. When setting up the Sun Cobalt Control Station, you use the LCD
console to enter network configuration information. Once the Sun Cobalt Control
Station is running, the LCD console is used to change network configuration
information, configure a UPS unit, reboot the control station and power down the
control station.
LCD screen LCD arrow buttons
S
E
