Sunpin PD151 User manual
Important safety instructions
Troubleshooting/warranty
Overview over the device
Use your DVD player
What's in the box
Adjust the settings
Product’s information
2
Thank you for purchasing SUNPIN PD151 Portable DVD Player. This is the Quick Start Guide, which provides
you with basic operations’ instructions. Please read it carefully before using the product. We do provide 12
months warranty. If you have any problems or suggestions, please feel free to contact us by amazon
message, or send an email to our ocial E-mailbox. sunpin oers 24/7 online support service
Ocial E-mail: service@sunpinpro.com
1
Contents
3
5
9
9
12
2
Important safety instructions
1. Read all instructions before start using the unit.
2. Use this unit only for its intended use as described in the manual.
3. The temperature of accessible surface may increase when the unit is operating.
4. If smoke is emitted, switch o and unplug the unit immediately.
5. Ventilation slots in the cabinet are provided for ventilation to ensure reliable operation of the product to
protect it from overheating, the slots should not be blocked by placing the product on a bed, sofa, rug,
or any other similar surface.
6. Never attempt to disassemble the unit by yourself, it is very dangerous and may cause an electric shock
and/or harm from exposure to the laser beam. Please refer all servicing and maintenance to an authorized
service center.
Please read through this manual before operating the unit. Please retain this manual for further use.
Troubleshooting / warranty
SunPin oers 12 months warranty card (included in the box) and 24/7 customer support.
ACTIVATE YOUR 12-MONTH WARRANTY. Register within 7 days after receiving your new product by
visiting this link: www.sunpinpro.com/warranty
If you face any trouble operating the DVD player or if there is any broken item, please don’t hesitate to
contact us and we will guide you through the process of fixing your problem.
E-mail: [email protected]
2
1 8
9
10
14
17
12
13
11
7
2
5
6
3
4
16
15
18
2019 21 22 23 24 25
Overview over the device
DVD picture
1. MUTE
2. DVD / USB / CARD SELECT KEY
3. TFT SCREEN ON / OFF
4. MODE
5. DISPLAY
6. LANGUAGE
7. OPEN
8. VOLUME UP
9. VOLUME DOWN
10. STOP
11. PLAY / PAUSE
12. MENU
13. SETUP
14. PREVIOUS / UP
15. FAST FORWARD / RIGHT
16. ENTER / OK KEY
17. NEXT / DOWN
18. FAST REWIND / LEFT
19. USB PORT
20. SD / MMC CARD SLOT
21. AUX OUT
22. AV OUTPUT JACK
23. AV IN JACK
24. ON / OFF SWITCH
25. DC IN 9~12V INPUT
3
USB
SD CARD
MODE
TFT
OFF/ON
MUTE
DISPLAY
LANGUAGE
OPEN
SETUP
MENU
PLAY
PAUSE
VOL-
VOL+
STOP
SD/MMC CARD AUX OUT AV OUT AV IN OFF/ON DC 9-12V
DISPLAY
SLOW
SUBTITLE
RETURN
ZOOM
REPEAT
A-B
MENU
SETUP
1
7
10
12
14
15
3
6
9
16
19
11
4
2
8
17
18
5
13
Remote picture
1. MAIN POWER
2. USB/CARD
3. MUTE
4. VOLUME -/+
5. ENTER
6. DIRECTION BUTTONS
7. SETUP
8. RETURN
9. MENU
10. PLAY/PAUSE
11. FAST FORWARD / FAST REWIND
12. STOP
13. PREVIOUS/ NEXT
14. A-B LOOP REPEAT
15. ZOOM IN/OUT
16. SLOW
17. TRACK REPEAT
18. SUBTITLE
19. DISPLAY
4
Use your DVD player
Turn on/o the player
Slide the Power switch on the right side of the player to the "ON" position to turn on the player.
Slide the Power switch on the right side of the player to the "OFF" position to completely turn o the player.
Note: If you won’t use the player for a long period of time, slide the Power switch to the "OFF" position and
unplug the power source.
Choosing the Input Source (DVD/USB/SD)
Click the (USB/CARD) on the remote control or the unit to switch between DVD or USB or SD input sources,
if the corresponding device is inserted,
When you insert a DVD or USB ash drive, or SD card while the DVD Player is not connected to any
multimedia devices, the input source would be selected automatically
Playing Discs
1. Slide the Power switch on the player to "ON" position to turn on the player.
2. Open the disc cover and insert a playable DVD or CD disc, make sure the label side is facing up, and then
close disc cover.
3. The player will scan the disc, and then playback will start automatically. If a disc menu appears on the
screen, you can choose your desired track or video.
5. During the playback, press the STOP button to stop playback.
6. Sliding the Power Switch on the player to the "OFF" position will turn o the player.
7. Press the MENU button on the remote control to activate or deactivate the PBC function, if the disk
supports PBC function.
PBC playback allows you to play Video CDs(VCD version 2.0 only)interactively.
8. Press the MUTE button on the remote control to turn on or o the sound.
9. Press the Display button on the remote control to select the playtime.
10. Press the REPEAT/PROG on the remote control button to re-setup the playing order.
5
Volume Control
Press the VOL+/-button on the player or the remote control to increase or decrease the volume level. To
switch o the volume temporarily press the MUTE button on the DVD player or on the remote control.
Playback will continue without sound. Press it again or press the volume button to activate the sound.
Repeat A-B(DVD / VCD / CD / MP3)Playback
Using this feature to repeat the playback of a specic section of a track/chapter (loop). Press the Repeat
A-B button on the remote to set the desired start point of the section to be repeated.
Press the Repeat A-B button on the remote again to set the desired endpoint of the section to be repeated.
The section "A-B" will now be played repeatedly as a loop.
Press the Repeat A-B button a third time to cancel the repeat A-B feature and resume normal playback.
Selecting Subtitle Languages(DVD)
While playing a DVD disc that has been mastered with multiple subtitles, press the Subtitle button
repeatedly to select the desired language of the viewable subtitle.
Information Display
During playback, press the DISPLAY button repeatedly to show the disc playback information on the screen
(video format, time, title and chapter, etc.)
Note: Depending on the type of disc(DVD, VCD, CD or Data discs), dierent information will be shown on
display.
Connect to USB
You can play or view the supported song les, such as the MP3/WMA, Video les such as AVI and JPEG for
photos. Insert the USB device into the USB port on the right side of your portable DVD player. The portable
DVD player supports USB devices up to 32 GB.
(Note: Not all USB devices can be read well, which may result in playback issues.)
6
All functions are the same as playing a disc.
Note: The USB IN port is compatible with ash drives. Some MP3 players using proprietary software may
not be compatible.
Connect SD/MMC Memory Card
1. insert an SD or MMC card into the SD/MMC Memory Slot.
2. Switch unit to Card Mode by pressing the USB/CARD button.
3. Use the Directional buttons to select videos or image. Press the Enter button to play.
4. The portable DVD player supports Memory Cards up to 32 GB.
Note: Please be sure you don't insert the card incorrectly or it may become damaged. Always stop the
playback or change to another mode before removing the USB/memory card.
Battery Operation
The unit has a built-in rechargeable battery. Fully charge the built-in battery before using it for the rst time.
It takes about seven hours to fully charge the battery when the player is not in use. Once charged,
disconnect the AC adapter, and then switch on the player.
The unit will operate on Battery Pack.
The unit oers approximately six-hour playback time on a full charge.
The playback time may vary depending on discs and the volume level.
Note: The player will operate on battery power when the AC/car adapter is not connected
7
Rotate the screen
8
Connect to TV
Connecting power supply
L
R
AV OUT
AUDIO IN
VIDEO IN
TV
Car adaptor
180
Clockwise
SD/MMCCARD AUX OUT AV OUT AV IN OFF/ON DC 9-12V
What’s in the box
1. Dvd player machine
2. Ac adaptor
3. Remote control
4. Av cable
5. Car adaptor
6. Instructions manual
7. Warranty card
Adjust settings
1.GENERAL SETUP PAGE
There are ve items in the GENERAL SETUP PAGE. They are TV DISPLAY, OSD LANGUAGE, CAPTIONS,
SCREEN SAVER, and LAST MEMORY
1.1 TV DISPLAY
4:3 PAN SCAN
If the unit is connected to a conventional TV set, the wide-screen image displayed on the screen in its native
aspect ratio with some part on the left and right cut o.
4:3 LETTERBOX
If the unit is connected to a conventional TV set, the wide-screen image will be displayed in its native aspect
ratio with black borders on the top and the bottom side.
16:9 wide:
Select this option if the unit is connected to a wide-screen TV set. The wide-screen image will be displayed
in full screen in its native aspect ratio while the 4: 3 image will be stretched out horizontally to t in the
screen.
9
1.2 OSD(on-screen display)language
Set this on-screen display language in this item.
1.3 CAPTIONS
Set this item to ON. When a disc encoded with closed captions, the closed captions will be shown on the
screen. Set this item to OFF to hide it. You can also press [SUBTITLE] on the remote control to show or hide
the closed captions. NOTE: this function only works with those discs encoded with closed captions.
1.4 screensaver
ON: If the image remains motionless on the screen, for example, the disc is paused, stopped, etc. for several
minutes, a screen saver will appear on the screen. You can press any key or button to wake it up.
OFF: Disable the screen saver function.
1.5 LAST MEMORY
ON: Each time you turn o the unit or stop the disc, it will memorize the last playtime. Next time you turn
on the unit and play the same disc, the unit will play from that memorized point.
OFF: Disable the last memory function.
10
2. Audio
The Audio menu allows you to change the audio setup of the DVD.
Speaker
Downmix: Set down mix to LT/RT, Stereo
3. Video
The video menu allows you to change the display properties of the DVD.
Quality
Sharpness: Adjusts the screen sharpness
Brightness: Adjusts the screen brightness
Contrast: Adjusts the screen contrast
Gamma: Adjusts the screen gamma
Hue: Adjusts the screen hue
Saturation: Adjusts the screen saturation
11
4. Preference Page
The preference menu option allows you to adjust the default DVD disc settings. (The setting is only
available when there is no DVD/USB ash drive/SD card is inserted into the unit.)
Product’s information
TV Type Set TV Type to PAL, AUTO, or NTSC
Audio: Set the default audio language
Subtitle: Set the subtitle language
Disc Menu: Set the disc menu language
Default: Return the portable DVD to factory default settings.
Compatible DISC DVD/VCD/CD/MP3/MPEG4
12
Frequency response 20HZ to 20KHZ
Video output 1 Vp-p75 Ohm unbalanced
Audio output 1.4 Vrms/10 kohm
Dynamic range Better than 85dB
Laser Semiconductor laser, Waver length: 650
Power source DC 9-12V 1A
Operation temperature 5-40
Battery type Li polymer
