Sunred GH12 Series User manual

www.sunred.nl
Manual gasheater (UK)
Handleiding gasheater (NL)
Handbuch gasheizung (DU)
Manual chauffage au gaz (FR)
Инструкция по эксплуатации газового обогревателя (РУС)
Χειροκίνητη θερμάστρα αερίου (EL)
GH12 RVS
GH12 GREY
GH12 BLACK
GH12 WHITE
GH12 GREEN
GH12 RED
GH12 - RVS/GREY/WHITE/RED

www.sunred.nl
Patio gasheater UK
TECHNISCHE SPECIFICATIES
Wattage: 11700 Watt
Element type: Gas
Expected Life span elements 5000 hrs.
Weight: 18 kg
Certificates: CE, CSA, AGA
Dimensions: H221cm
All measurements are approximate
IMPORTANT –Carefully remove any packaging before use, but retain the safety instructions.
These instructions form part of the product.
Please take note of all the safety warning listed in these instructions.
Please read these instructions in their entirety and retain them for future reference.
These instructions should be stored with the product.
This product is for domestic use ONLY and should not be used commercially or for contract purposes.
User instructions - please keep for future references

www.sunred.nl
CAUTION
PLEASE READ CAREFULLY THE FOLLOWING SAFETY GUIDELINES BEFORE OPERATION
Installation and repair should bedone by a qualified service person.
Improper installation, adjustment, alteration can cause personal injury or property damage.
Do not attempt to alter the unit in any manner.
Thisappliance mustbe installedand thegas cylinderstored in accordance with the regulationsin force.
Do not move the appliance when in operation.
Shut off the valve at the gas cylinder or the regulator before moving the appliance.
The tubing or the flexible hose must be changed within the prescribed intervals.
In case of violent wind particular attention must be taken against tiltingof the appliance.
Do not store or use gasoline or other flammable vapors or liquids into the heater unit.
Thewholegassystem,hoseregulator,pilotorburnershouldbeinspectedfor leaksordamagesbeforeuse.
All leak tests should be done with a soap solution. Never use an open flame to check for leaks.
Do not use the heater until all connections have been leak tested.
Turn off immediately the gas valve if smell of gas is detected.
Do not transport heater while it’s operating.
Do not move the heater after it has been turned off until the temperature has cooled down.
Keep the ventilation opening of the cylinder enclosure free and clear of debris.
Do not paint radiant screen, control panel or top canopy reflector.
Control compartment, burner and circulation air passageways of the heater must be kept clean.
Frequent cleaning may be required as necessary.
The LP tank should be turned off when the heater is not in use.
Check the heater immediately if any of the following exists:
- The heater does not reach temperature.
- The burner makes popping noise during use (a slight noise is normal when the burner is extinguished).
- Smell of gas in conjunction with extreme yellow tipping of the burner flames.
The LP regulator/hose assembly must be located out of pathways where people may trip over it or in area where the hose will not subject
to accidental damage.
Any quard or other protective device removed for servicing the heater must be replaced before operating the heater.
Change the gas cylinder in a well ventilatedarea ,away from any inflammation source.
Check that the regulator seal is fitted and that it is in good condition.
Do not obstruct the ventilation holes of cylinder housing.
Adults and children should stay form high temperature surface to avoid burns or clothing ignition.
Children should be carefully supervised when they arein the area of the heater.
Clothingor otherflammable materials should not behungon theheaterorplaced on or near theheater.
Use may replacethe rubber hose by himselfandnote the lengthofthe hose is 60cm. Andthe hosemust be required by the national conditions.

www.sunred.nl
LP Characteristics - Flammable, explosive,heavier than air-settles in low areas.
In its natural state, propane has no odor. For your safety, an odorant is added that smells like rotten cabbage.
Contact with liquid LP can cause freeze burns to skin.
This heater is shipped from the factory for LP gas use only.
Use only EEC approved ”15KG.”Gas cylinders LP gas cylinders (same as commonly used on gas grills)
with safety valves. These valves can be quickly identified by their external and internal threads.
Never use a cylinder with a damaged body, valve, collar or foot ring.
When heater is not in use, turn Control Valve OFF. Close the valve of the gas cylinder or the regulator afteruse.
The use of this appliance in enclosed areas can be dangerous and is “PROHIBITED”.
1) For use outdoors or in amply ventilated areas.
2) An amply ventilated area must have a minimum of 25% of the surface area open.
3) The surface area is the sum of the walls surface.

www.sunred.nl
Wall
(18’’) 45cm
HEATER STAND AND LOCATION
●The heater is primarily for outdoor use only.Always ensure that adequate fresh air
ventilation is provided.
●Always maintain proper clearance to combustible materials, i.e. top 45cm(18”) and
sides 70cm (28”) minimum.
●Heater must be placed on level firm ground.
●Neveroperateheaterinanexplosiveatmospherelikeareaswhere gasoline or other
flammable liquids or vapors are stored.
●To protect heater from strong wind, anchor the base securely
to the ground with screws.
●Water tank should be full of water or sand. Otherwise heater wouldfilt.
(28’’)
70cm
Ceiling
GASREQUIREMENTS
●Use LPG gas mixtures .
●Maximum inlet pressure of propane regulator must not exceed 100 PSI.
●The pressure regulator and hose assembly to be used must conform to local standard codes.
●The installation must conform to local codes, or in the absence of codes, with standard codes.
●The installation must conform to local codes, or in the absence of codes, with the standard for storage and handling of liquid petroleum
gases.
●A dented, rusted or damaged propane tank may be hazardous and should be checked by your tank supplier.
Never use a propane tank with a damaged valve connection.
●The propane tank must be arranged to provide for vapor withdrawal from the operating cylinder.
●Never connect an unregulated propane tank to the heater.

www.sunred.nl
LEAKAGE TEST
Gas connections on the heater are leak tested at the factory prior to shipment. A complete gas tightness check must be performed
at the installation site due to possible mishandling in shipment or
excessive pressure being applied to the heater.
The heater must be checked with a full cylinder.
Make sure the safety control valve is in the OFF position.
Make a soap solution of one part liquid detergent and one part water.The soap solution can be applied with a spray
bottle, brush or rag.
Soap bubbles will appear in case of a leak.
Leakage test points. See pictures below.
Turn the gas supply ON.
In case of a leak,turn off the gas supply.Tighten any leaking fittings, then turn the gas supply on and recheck.
Contact your dealer for assistance if bubbles continue to appear.
Never leak test while smoking.
FUEL GAS ODOR
LP gas and natural gas have manmade odorants added specifically for detection of fuel gas leaks.
If a gas leak occurs you should be able to smell the fuel gas. Since Propane (LP)is heavier than air you should smell for the gas odor low
to the floor. ANY GAS ODOR IS YOUR SIGNAL TO GO INTO
IMMEDIATE ACTION!
Do not take any action that could ignite the fuel gas. Do not operate any electrical switches.Do not
pull any power supply or extension cords. Do not light matches or any other source of flame. Do not use your telephone.
Get everyone out of the building and away from the area immediately.
Propane (LP) gas is heavier than air and may settle in low areas. When you have reason to suspect a propane leak, keep out of all
low areas.
Use your neighbor’s phone and call your fuel gas supplier and your fire department. Do not reenter the buiding or area.
Stay out of the building and away from the area until declared safe by the firefighters and your fuel
gassupplier.
FINALLY, let the fuel gas service person and the firefighters check for escaped gas. Have them air out the building and area
before you return. Properly trained service people must repair any leaks, check for further leakages, and then relight the
appliance for you.

www.sunred.nl
OPERATION AND STORAGE
TO TURN ON THE HEATER
1. Turn on the valve on the gas supply cylinder completely.
2. Push the control knob in it and turn it the “pilot ” position
3. Press the "igniter " button several times to light the burner. Hold it for 30 seconds.
Release the Control Knob after the burner lights.
Note:
If a new tank has just been connected, please allows at least one minutefor the air in the gas pipeline to purge out through the
pilot hole.
When lighting the pilot flame make sure that the variable control knob is continuously pressed down while pressingthe igniter
button. Variable control knob can be released after the pilot flamelights.
Pilot flame can be watched and checked from the small round window with sliding lid located at the bottom of the flame screen
(to the left or right side of the controller).
If the pilot flame does not light or it goes out,REPEAT STEP 3.
A 5-minute complete shutoff period is necessary before relighting.
4. Turn the Control Knob to switch to desired temperature position.
TO TURN OFF THE HEATER
1. Turn the knob to “LOW”position for small flame . See picture of “ ”.
2. Turn the knob to “HI”position for big flame .See picture of “ ”.
3. Press and turn the variable control knob to OFF position.
4. Turn off the valve on the gas supply cylinder completely.
Variable control knob
lgniter
STORAGE
1. Always close the gas valve of the gas cylinder after use or in case of a disturbance.
2. Remove the pressure controller and the hose.
3. Check the tightness of the gas valve and for damage. If you suspect a damage, have it changed by your gas dealer.
4. Never store liquid gas cylinder in a sub-terrain, or at places without adequate air ventilation.
CLEANING AND CARE
Wipe off powder coated surfaces with soft, moist rag. For lacquer surface, use suitable cleaners. Do not clean heater with
cleaners that are combustible or corrosive.
Remove debris from the burner to keep it clean and safe for use.

www.sunred.nl

www.sunred.nl
A. Construction and characteristics:
Transportable terrace/garden heater with tank housing
Casing insteel with powder-coating orstainless steel
Soluble gas connections are equipped with metal clamp
Stainless steelflamescreen
Heat emission from reflector
B.Specifications
For outdoor use only
Uses propane or butane gas only
Max. wattage: 14 KW
Consumption: 870 g/hr
Weight: Stainless steel model G.W. 20 kgs
Powder coating model G.W. 22 kgs
Height: 2245 mm including stand
With CE certificate
C. Table of openings
Gas Pressure mmH 2 O
Main Opening
Opening of Pilot Burner
280/300
1.90mm
0.22mm
370
1.80mm
0.22mm
500
1.65mm
0.22mm
Assembly Procedures
STEP 1
1.1.To fill in the water tank with water of sandbeforeinstallation.
1-2. Put the three pcs post brackets on each position on the base as shown in the picture.
1-3. Use 3 pcs M8 x 16 mm bolts to join the post brackets and
stand.
STEP 2
water or sand tank
2-1. Put the post onto the top of 3 pcs post brackets.
2-2. Use 6 pcs M6 x 35 mm bolts and nuts to connect the post to the 3pcs post brackets. Tighten the
bolts and nuts.

www.sunred.nl
STEP 3
3.1. Put the tank housing through the post.
STEP 4
4-1. Fit the gas steel pipe nut into the burner gas inlet connector.
●Secure the reflector support bolts on the flame screen cap with
4 pcs 60 mm length pins & 4 pcs Ø8 mm washers.
●Connect the pins & washers to the flame screen.
●Tighten the pins.
4-2. Tighten the gas steel pipe nut and gas inlet thread.
●Put the burner with steel pipe onto the post.
●Fix the burner base to the post by 4 pcs M6 x 10 mm bolts.
STEP 5
5-1. Check whether the connection of vertical post and burner are assembled as
instruction, and all bolts and nuts are tightened.
5-2. Put the flat washer onto the top of each burner/reflector support bolts
(M8 thread).
