Model ST-6RF
Owner's Manual
Safety tips
Do not use electrical appliances such as hair dryer or heater to defrost your
freezer.
Do not store inflammable gases or liquids inside your DC refrigerator.
Disposal
Old appliances still have some residual value. An environmentally friendly
method of disposal will ensure that valuable raw materials can be recovered
and used again. The refrigerant used in your appliance and insulation
materials requires special disposal procedures. Ensure that none of the pipes
on the back of the appliance are damaged prior to disposal. Up-to-date
information concerning options for disposing of your old appliance and
packaging from the new one can be obtained from your local council office.
This symbol on the product or in the instructions means that your electrical
and electronic equipment should be disposed at the end of its life separately
from your household waste.
Contact Information
SUNSTAR TECH SUPPORT: 260-214-0949
FAX: 260-499-4984
Table of Contents
Dear Customer: Please follow the user manual to achieve the best
service performance and the longest service of life for your machine.
TOPIC DESCRIPTION PAGE
NUMBER
1 Location of Parts 1
2 Major Technical Parameters 2
3 Installation Instructions 2
4 Safety Precautions 3
5 Cable Requirements 4
6 Operating Refrigerator/Freezer 4
7 Care and Maintenance 5
8 Reversing the Door Swing 6
9 Notices and Routine Maintenance 8
10 Troubleshooting Guide 9
11 Safety Tips 11
12 Contact Information 11
Page 11
Location of Parts
Before use
Please read these instructions carefully before using your DC
Refrigerator. The appliance is for indoor/domestic use only.
The following are NOT results of faulty equipment:
1) The intermitting noise heard in the cabinet during operation of
the unit some time after shut-off is caused by the circulating
flow of coolant in the condensing pipes.
2) The surface temperature of compressor may rise to a range
between 66°C /150°F and 90°C/194°F.
3) The condensed water beads on the external side of the unit or
door during the rainy seasons will not affect the operation of
the unit. The water beads may be wiped off with a dry cloth.
Start Up and Compressor Signal Lighting:
There is a light bulb located near the module of the compressor. It will
flash a number of times if a fault occurs. Count the number of flashes
and compare with the chart below:
Flash Number
Fault Occurring
1
Battery Protection Cut Out
2
Fan Over-Current Cut Out
3
Motor Start Error
4
Minimum Motor Speed Error
5
Thermal Cut Out of Module
1) The module will run too hot if the unit system has been too heavily
loaded or if the ambient temperature higher than 45°C/113°F
2) The unit will not run if there is t connecting the anode and cathode
of the voltage compressor.
Thermostat control knob
Light
Crisper box
Refrigerator shelf
Upper and middle
freezer drawers
Lower freezer
drawer
Door balcony
Ice cube tray
(inside of drawer)
Leveling feet
Page 1
Page 10
General Faults and Trouble-shooting
In case of an abnormal operation, please refer to the table below for
inspection and possible solutions. If the faults cannot be solved, please
contact the service department of our company and our local institutions
with special engagement.
Fault
Cause
Solution
Faulty indicators and /
or non operation of the
compressor
1. Loose contact
2. Loose cables
1. Make it tight
2. Make it tight
The compressor is
running abnormally or
with unusual noise
The supply voltage is 85%
lower than the rated value.
1. Switch the unit off
immediately until
the recovery of the voltage
supply is normal. A voltage
regulator with an input power
five (5) times larger is required
if the voltage fluctuation
exceeds that which is specified.
2. Check the input voltage on
the module and power supply
battery if it is out of operating
voltage.
3. Check the cable length
between the battery and
module. Please refer to “Cable
Requirements” on page 1 of the
User Manual.
The successive
automatic shut-off of
the compressor several
minutes after start up
The supply voltage is 110%
higher than the rated value.
The storage
temperature rises while
the compressor is
running properly
1. Frequent opening of the
doors.
2. The cabinet is overloaded
with tightly packed food.
3. Too much frost
accumulation.
4. Door leakage.
5. Gasket failure.
Try to open the doors less
frequently. Arrange the food
orderly with enough space for
smooth air circulation. Take out
frozen food and remove the
frost. Adjust the door sealing.
Abnormal noise in
general is being
produced
1. The unit is not leveled
2. Loose fastening parts
3. Unwanted contact between
pipes
1. Adjust the unit to a stable
and leveled floor.
2. Tighten the loose parts.
3. Keep the parts away from
each other.
Major Technical Parameters
Product Model
Input Voltage
Available capacity
ST-6RF DC 12V/24V
170L
6 cu. ft.
Working
Temperature
Input Power
(W)
Power
Consumption
(KW/h)
Fridge: 0°C ~ 10°C (32°F ~ 50°F)
Freezer: 22°C ~ 15°C (7.6°F ~ 5°F)
60
0.45
Refrigerant (R134A)
Amount
Net Weight
Exterior
Dimension
110 g
0.25 lbs
44 kg
97 lbs
50 x 52 x 143 (cm)
19.7” x 20.5” x 56.3”
Installation Instructions
Location
When selecting a position for your appliance you should make sure that the
floor is flat and firm, and the room is well ventilated with an average room
temperature of between 16°C and 35 °C. Locate the appliance away from
direct sunlight and source of heat (stove, heater, radiator, etc.) Direct sunlight
may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the
appliance not to perform properly. This unit is not designed for use in a
garage or any other outside installation. Avoid locating the appliance in moist
areas. It must therefore be installed so that the appliance has at least 15cm/6
inches from the wall at the back and side. The appliance door can either open
to the right or the left, depending on whichever suits you. See page 5-7 if you
want to reverse the door swing. Do not drape your appliance with any
covering.
Moving the appliance
Position your appliance in front of its final operating position and gently slide
the appliance into position. A minimum of two persons must be used to move
the appliance.
Page 9
Page 2
Leveling the DC Refrigerator
Remove the packaging support from the base of the appliance and replace
with the 2 leveling feet. Make sure the appliance is level. Use the leveling feet
at the front. If the appliance is not level, the doors and magnetic seal
alignments will be affected.
Cleaning before use
Wipe the inside of the appliance with a weak solution of bicarbonate soda.
Then rinse with warm water using a damp sponge or cloth. Wash the baskets
and shelves in warm soapy water and dry completely before replacing in the
fridge. The external parts of the fridge can be cleaned with wax polish.
Before plugging in YOU MUST notice below Safety Precautions:
SAFETY PRECAUTIONS
1) Use an independent 12V or 24DC outlet with a capacity of no less
than 30A.
2) This DC Refrigerator is only allowed to connect to a 12V or 24V DC
system. It is forbidden to connect it directly with an AC power supply.
3) Do not immediately switch the DC Refrigerator on and off. It will
damage the compressor module. The normal time interval is ten (10)
minutes.
4) Disconnect the plug from the outlet if the unit is to be left unused for
a long period of time. Check if the connection is okay before it is put
to use again.
5) DO NOT store inflammable gases or liquids in your DC refrigerator
6) The supplier is not responsible for any accidents or losses incurred
from the unit
Before switching on!
DO NOT SWITCH ON UNTIL TWO HOURS AFTER MOVING THE APPLIANCE
The coolant fluid needs time to settle
Please Note: The ice cube tray is for ice only and not for freezing food
Notices & Routine Maintenance
1) Do not switch on the DC Refrigerator within 2 hours after
transportation. After the appliance has been placed it needs to be left
for 2 hours. This allows time for the coolant to settle.
2) DO NOT switch on the DC Refrigerator within ten (10) minutes after a
sudden power failure.
3) The unit cannot be re-started until after a half an hour on the leveled
floor that it is moved to. The unit should be left to run for two (2) full
hours before food is put into it for storage.
4) The temperature of the food in the unit should not exceed the
ambient temperature.
5) Acids, alkaline, corrosive substances, volatile or inflammable materials
cannot be stored in case of damages to the cabinet of the unit.
6) How to clean your SUN STAR unit:
a) Wipe down the interior walls and shelves with a soft cloth dipped in
a neutral detergent.
b) Exhaust the condensed water or wipe it off with a dry clean cloth.
c) The outside of the unit can be cleaned with a thin soda water or
alcohol and then wiped clean with a damp cloth.
7) After the unit has been in use for half a year, wipe off the dust that has
been accumulated on the condenser, fan, and compressor.
8) Leveling the DC Refrigerator. Make sure the appliance is level. Use the
rotating leveling feet at the front. If the appliance is not level, the door
and magnetic seal alignments will be affected and may cause your
appliance to work incorrectly.
9) Locate the unit to be no less than fifteen (15) cm / six (6) inches from
the wall at the back and side.
10) Do not attempt to repair your appliance yourself as it might endanger
you and others.
11) Do not place your appliance near a heat source, e.g. cooker, boiler, or
radiator. Also avoid direct sunlight in outbuildings or sun lounges
Page 3
Page 8
Note: to take the door off it is necessary to tilt the appliance backward.
You should rest the DC Refrigerator on something solid.
DO NOT lay the appliance completely flat as this may damage the
coolant system
1. Remove the screw cover. Undo the screws and remove the top
cover and hinge bracket
2. Slide the fridge door up and lift away from the appliance
3. Undo the screws of the middle hinge. Slide the freezer door up
and lift away from the appliance.
4. Undo the screws and remove the bottom hinge. Screw it into
place on the new side and replace the adjustable feet.
5. Remove the pin from the fridge and freezer doors. On the
opposite bracket, insert the replacement hinge pin. Ensure the
pin is secure.
6. Place the freezer door first and screw the hinge on the opposite
side.
Note: Ensure the door is aligned horizontally and vertically and that
the seals are closed on all sides before finally tightening the middle
hinge.
7. Place the fridge door first and screw the top hinge on the
opposite side. Note: Ensure the door is aligned horizontally and
vertically and that the seals are closed on all sides before finally
tightening the top hinge.
Important: Double check that the door is aligned correctly and all the
seals are closed on all sides. If necessary, re-adjust the leveling feet.
CABLE REQUIREMENTS
To ensure the correct start and operating conditions for the DC Refrigerator,
the following cable dimensions must be observed:
Wire Sizing Chart
(Gauge)
Max. length between battery and
compressor (ft)
12V/DC
24V/DC
# 10
15 ft
30 ft
# 8
20 ft
45 ft
# 6
30 ft
60 ft
# 4
45 ft
100 ft
Operating Your Refrigerator/Freezer
Switching on your DC Refrigerator
1. Before connecting the appliance to the DC power supply, make sure
that the thermostat control dial is set at position 0. This is located on
the right part of the fridge.
2. Turn the thermostat knob clockwise to set it to the desired position.
Bear in mind that the higher the number, the colder the temperature.
3. To ensure that the appliance is cool enough to sufficiently chill your
food wait 24 hours before filling with food.
Adjusting the temperature
The internal temperature of your appliance is controlled by a thermostat.
Position 7 makes the appliance coldest and position 1 makes it warmest and 0
turns the appliance off. The recommended setting for the appliance is
between 1-4 for colder working environment (i.e. during winter) and 4-6 for
hotter environments. The temperature of the appliance may not operate at
the correct temperature if it is in a particularly hot or cold room or if you open
the appliance door often.
Page 7
Page 4
Care and Maintenance
Defrosting
Your DC Refrigerator is frost free, and the ice build in will normally
defrost automatically. However, if the freezer door is left open for a
period of time, ice may build in the freezer compartment. Temporarily
this can be scraped away using a plastic scraper. NEVER use a metal or
sharp instrument. Complete defrosting will however become necessary
if the frost layer exceeds 5cm (2”) to maintain the efficiency. This should
be carried out if the frost build up cannot be scrapped away, or if it
begins to interfere with the food storage. Choose a time when the
stock of food is low and proceed as follows:
1. Take out the chilled food, turn the DC refrigerator off at the
power supply and leave the door open. Ideally the chilled food
should be put into another refrigerator. If this is not possible,
wrap the food in several sheets of newspaper or large towels
and keep it in a cool place.
2. Scrape away as much frost build up as possible using a plastic
scraper. Thawing off the remainder can be sped up by placing
bowls of hot water inside the fridge cabinet and closing the
door. As the solid frost loosens, pry it away with the plastic
scraper and remove.
3. When defrosting is completed, clean the DC refrigerator as
described in the previous column.
Noises inside the DC Refrigerator
If you have not owned this type of appliance before, you may notice it
makes some rather unusual noises. Most of these are perfectly normal,
but you should be aware of them.
Humming, purring or pulsating
This is the compressor motor working, as it pumps the refrigerant
around the system.
Gurgling, whooshing
These noises are caused by the circulation of the refrigerant liquid in
the cooling system. It has become more pronounced since the
introduction of CFC free gases. This is not a fault and will not affect the
performance of your appliance.
Shut the door!
To prevent cold air escaping, try to limit the limit the number of times
you open the door. When returning from shopping, sort foods to be
kept in your appliance while the door is closed and only open it to put
food in or take food out.
NOTE:
ALWAYS WRAP AND STORE RAW MEAT, POULTRY AND FISH ON THE LOWEST
SHELF AT THE BOTTOM OF THE APPLIANCE. THIS WILL STOP THEM FROM
DRIPPING ONTO, OR TOUCHING OTHER FOODS. DO NOT STORE
INFLAMMABLE GASES OR LIQUIDS IN THE APPLIANCE.
Replacing the bulb
1. Ensure the appliance is unplugged and disconnect from the
power supply.
2. Remove the bulb cover and unscrew the bulb in counter-
clockwise direction.
3. Replace the bulb with a new one.
4. Replace the cover and reconnect the appliance to the power
supply.
Reversing the Door Swing:
Ensure the appliance is unplugged and empty. Adjust the two leveling
feet to their highest position. We recommend you have someone assist
you.
Tools required:
Phillips style screwdriver
Flat bladed screwdriver
Page 5
Page 6
Table of contents
Other SunStar Refrigerator manuals
