SWEEX LC000050 User manual

English version
Set up the page as in the example below:
Then click on the button to save the data in the Access Point.
For a standard wireless connection you do not need to set up anything else and your Access Point is ready to use.
Setting up Data Encryption (WEP) in the Access Point
It is advisable to use a secure wireless connection by making use of an encoded encryption. If you refrain from doing this, malicious users will be
able to log on to your network for free using a laptop + wireless PC Card + software. This cannot be prevented by using a firewall.
Select the Encryption option in
the main menu of the Access Point.
The following screen will appear:
example1:
In this example the 64 bit WEP encryption has been configured
with key number1: 1020304050.
English version
WWW.SWEEX.COM
LC000050 WIRELESS ACCESS POINT
Advantages
Configuration - WEB Based
Security - Support for 64/128 bits WEP encryption
Auto fallback - Auto fallback of data speed in case of obstacles
DHCP serverv - Automatically distributes IP addresses
Key Characteristics
• Data transmission speeds of 11Mbps, 5.5Mbps, 1Mbps
• Blocks unauthorised wireless clients based on MAC (Media Access Control) addresses.
• Network Protocol: TCP/IP
• Windows 98SE/2K/ and Windows XP compatible
Configuring the Wireless Access Point
In order to connect to the Access Point your network card must be put within the same range as the Access Point. Connecting is done with a stan-
dard patch cable. Because the AP works on the 192.168.2.1 IP address, you must put your network card on an IP address within this range (e.g.
with the IP address 192.168.2.101). Enter 255.255.255.0 as the subnet mask. You do not need to enter the other values of your network card.
Search for the Access Point using your Internet Browser (e.g. Internet Explorer) by entering the IP Number of the Access Point (192.168.2.1).
You will be prompted for the username= admin and password= 1234. After logging on you will be able to view the home page.
Configuring the Access Point for wireless connections
After you have logged on to the router,
select the “Wireless Setting” option.

English version English version
WWW.SWEEX.COM
example2:
In this example the 128 bit WEP encryption
has been configured with key number1:
10111213141516171819202122
Then click on the button to save the data in the Access Point.
Your Access Point will now only send encoded signals to wireless stations. NB: After configuring WEP in the Access Point, do not forget to enter
the same key in the wireless client or you will not be able to connect.
Setting up MAC Filtering
In addition to the WEP encryption security for your wireless connection, it is advisable to include the use of MAC Filtering.
When correctly set up, MAC Filtering ensures that only network cards with the MAC address specified by you will be given access to your Access Point.
To find the MAC address of your wireless card, follow this simple method:
Windows 98/SE
Go to Start -> Run and enter the command winipcfg followed by enter. The “IP Configuration” screen will appear. Select the wireless adapter and
click the 'More Settings' button. The adapter address is the MAC address of this particular (wireless) network card.
example ‘winipcfg’
for finding the MAC address
Windows 2000/XP
Go to Start -> Run and enter the command cmd followed by enter. A black MS-DOS window will appear. Enter the command ipconfig /all followed
by enter. The physical address of your wireless card is the MAC address we are searching for.
Once we have found the MAC address (for example 00-50-DA-66-AC-A7), it must be added to the Access Point as a secure connection.
Select “MAC-Filtering” from the
main menu of the Access Point
The following screen will appear. Select the “Enable Wireless Access Control” box and enter the MAC address together with a description of the PC.
Then click “Add” and the Mac address will be added to the list of allowed connections:
Tick the “Select” box to activate the Mac address of the relevant PC.

English version
WWW.SWEEX.COM
LED Indication at top of Access Point
LED Colour Status Description
Power Green On Supply voltage connected correctly
Off No supply voltage
Wireless Green Flashing Access Point is transmitting data
Green Flashing Access Point is receiving data
Off No data being transmitted or received
LAN Green On Connected to computer
Flashing Data packets are being received
Off Not connected to computer
On the back of the Access Point there is a reset button; should a problem occur you can press this button. Make sure you do not press the button
for longer than 4 seconds. This way the configuration of the Access Point will not be lost.
If you press the reset button for longer than 4 seconds, all the configuration settings will be deleted. You can do this if for example you have forgotten
your password.
