Swift E137CD User manual

40V LITHIUM-ION CORDLESS LAWN MOWER
Model: E137CD
Operations Manual

TABLE OF CONTENTS
•Symbols……………………..........2
•Safety Instructions
and Warnings…………………….3
•Technical Specifications………...6
•Assembly and Operation………..7
•Charging the Battery…..……......10
•Part List………………….……..…11
•Maintenance and Care………… 12
•Disposal……………………….....13
•Guarantee/Warranty…………….13
.
SYMBOLS
General Safety Warnings.
1. After release the On/Off
switch, the cutter bar
continues running briefly.
Risk of injury!
2. To protect against injury from
the cutter blade, have a
specialist garage perform all
work such as replacing or
regrinding the cutter blade
(special tools required).
3. Before performing any
maintenance and cleaning
work on the garden tool,
remove the battery.
4. Protect the battery contacts
when the battery is not being
used. Loose metal parts may
short-circuit the contacts –
Explosion and fire hazard!
Before using the tool, read the
operating manual. Read all safety
warnings and all instructions
including the currently valid site
rules and regulations for the
prevention of accidents. Failure to
follow the warnings and
instructions may result in electric
shock, fire and/or serious injury.
Remove the safety key before
carrying out any work on the unit
and before leaving the unit.
Sharp cutting tool! Keep hands
and feet away from the cutter bar!
Wear protective gloves if possible.
Do not throw batteries and other
electrical products into the
household waste, fire, or water.
Recycle to protect the
environment.
Do not expose to rain or wet
conditions.
Protective goggles/visor, protective
helmet & hearing protection.
Safety Instructions
User
This garden tool is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the machine by a person responsible
for their safety.
Never allow children or people unfamiliar with these
instructions to use the garden tool. Supervise children.
This will ensure that children do not play with the unit.
Intended Use
This garden tool is intended exclusively to mow lawns
according to the descriptions and safety instructions
indicated in this operating manual.
Any other use is not as intended. Improper use is not
covered by the warranty and the manufacturer will reject
any liability. The user is liable for all injuries to third parties
and damage to their property.
Operate the unit only in the technical condition as
stipulated and delivered by the manufacturer. Arbitrary
changes to the unit will exclude the manufacturer from any
liability for resulting injury and/or damage.
Preparation
1. Familiarize yourself with the unit and its functions as
well as its controls.
2. Inspect the lawnmower before switching it on and check
for signs of wear and damage. Never use the lawnmower
with damaged or missing guards, e.g. dis-charge flap and/or
grass catcher, housing, etc.
3. Have damage repaired by a qualified technician or the
service centre.
4. Do not use a unit which has a defective switch and can no
longer be switched on or off.
5. When working with or on the unit, always wear sturdy
footwear and long trousers. Do not operate the unit when
barefoot or wearing sandals.
6. Check the terrain on which the unit will be used and
remove any stones, sticks, wires, bones and other foreign
objects, which could be picked up by the unit, to avoid
endangering people.
During Operation
1. Do not switch on the unit if there are persons (particularly
children) or animals in the immediate vicinity.
2. Ensure that children do not play with the unit.
3. Interrupt working if you notice that persons (particularly
children) or pets are nearby.
4. Working on steep slopes can be dangerous.
5. Ensure that you have a firm footing and mow slowly.
6. Always mow across the slope and not up and down.
7. Be particularly careful when changing direction. There
is a risk of tripping!

8. Do not mow on steep slopes.
9. Be particularly careful when mowing backwards and
pulling the lawnmower towards yourself.
10. Do not tilt the lawnmower when switching on the motor.
11. Maintain a safe distance as provided by the handle
frame.
12. Do not switch on the motor until your feet are at a safe
distance from the cutter bar.
13. Be careful and do not reach into the rotating cutter bar.
14. Switch the lawnmower off before tilting or transporting it,
e.g. from/to lawn or over paths.
15. Never run over gravel while the motor is running. There is
a risk of being hit by stones!
16. Before lifting or transporting the lawn-mower, switch the
motoroff, pull out thesafety key and wait until the cutter bar
has come to a standstill.
17. Do not adjust the cutting height until the motor has been
switched off and the cutter bar has come to a standstill.
18. Never open the discharge flap while the motor is running.
19. Before removing the grass catcher, switch the motor off
and wait until the cutter bar has come to a standstill. After
emptying the grass catcher, carefully re-attach it and ensure
that the grass catcher is attached securely to the lawnmower.
20. If possible, do not mow wet grass.
21. Do not work with the garden tool in a potentially explosive
environment in which there are flammable liquids, gases or
dust.
22. When interrupting work, never leave the unit unattended
and keep it in a safe place.
For The Battery Charger
1. Do not place any objects on the battery charger and do
not place the battery charger on soft surfaces.
2. Please read safety instructions for Li-ion batteries. There
is a risk of explosion.
3. Liquid ejected from the battery may cause irritation or
burns.
4. If other batteries are used, e.g. imitations, reconditioned
batteries or third-party products, there is a risk of injuries as
well as damage caused by exploding batteries.
5. A charger that is suitable for one type of battery pack may
create a risk of fire when used with another battery pack.
This may cause an internal short-circuit and the battery to
burn, smoke, explode or overheat.
General Power Tool Safety
Warnings
The term "power tool" in the warnings refers to your main-
operated (corded) power tool or battery-operated (cordless)
power tool.
Work Area Safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce the risk of electric
shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.There is an increased risk of electric shock
if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase the
risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
the cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol, or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce the
risk of injury.
3. Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to the power
source and/or battery pack, picking up, or carrying
the tool. Carrying power tools with your finger on the
switch or power tools that have been turned on invites
accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may increase
the risk of injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair
can be caught by moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure that these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
Power Tool Use And Care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it is
designed.
2. Do not use the power tool if it can’t be turned on
and off by its switch. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making

any adjustments, changing accessories, or before
storing the power tool. Such preventive safety measure
reduces the risk of starting the power tool accidentally.
4. Store idle power tools out of reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate it. Power tools are
dangerous in the hands of untrained users.
5. Maintain the power tools. Check for misalignment
or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean.Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Battery Tool Use And Care
1. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
2. Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury and fire.
3. When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or fire.
4. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If you accidentally contact the
battery liquid, flush it with water. If the battery liquid contacts
the eyes, seek medical help as soon as possible. Liquid
ejected from the battery may cause irritation or burns.
Service
Have your power tool serviced by a qualified repair
professional using only the identical replacement
parts.This will ensure that the safety of the power tool is
maintained.
PRODUCT SPECIFICATIONS
Type
E137C
Nominal voltage
V
40
Cutting Width
inch
15
Cutting height
inch
0.98-2.95
Capacity grass catcher
gal.
10.5
Idle speed
r.p.m.
4000
Sound power level LwA
dB(A)
96
Weight (without battery)
Lbs
34.17
Battery (EB20)
Ah
2.0
Charger (EBC05)
V
40
ASSEMBLY AND OPERATION
Before Initial Operation
Unpack the garden tool and accessories and check that no
parts are missing or damaged.
NOTE: The batteries (optional; depending on delivery
scope) are not fully charged on delivery. Prior to initial
operation, charge the batteries fully. See user manual of
the battery charger.
Safety Key
The unit has a security key. The key is located
under the battery cover. By removing the key,
the power supply to the motor is interrupted.
Remove the safety key:
a.) if the unit is left unattended;
b.) before checking, cleaning or performing other work
on the unit;
c.) before removing blockages;
d.) if a foreign object is hit;
e.) if the unit starts vibrating excessively.
Check the lawnmower for damage, and have any damage
repaired at a qualified technician or a service centre.
To remove the key, press the lock (1) and pull out the
safety key (2).
To insert the safety key, press down the key until it clicks.
Assembly
Attaching The Handle Bar
CAUTION: When collapsing or unfolding the handlebar,
the cable may be damaged. Ensure that the cable is not
kinked
1. Unfold the upper handlebar upwards (1). And
tighten the knobs between the upper and lower
handlebars as illustrated.

2. Insert the lower handle into the slot (2).
3. Align the holes on the handlebar and the machine.
Insert the bolts through the holes and tighten up
(3&4).
Assembling the Grass Catcher
1. Insert the two lower parts together until it clicks (1).
2. Turn in the two screws at the bottom (2).
3. Put on the upper part and press it together until it
clicks. (3).
Attaching the Grass Catcher
1. Lift the discharge flap (1).
2. Hook the grass catcher bag into the lawnmower (2).\
3. Fold the discharge flap down (3).
Adjusting the Cutting Height
The cutting height can be adjusted from 0.98” to 2.95”.
1. Pull the handle outwards slightly.
2. Set the required cutting height.
3. Release the lever again.
Inserting/Replacing the Battery
Ensure that the battery is fully charged before inserting it
into the tool.
1. Open the battery cover (1).
2. Press the charged battery into the power tool until it
clicks into place (2).
3. Close the battery cover (3).
Removing the Battery
1. Press the release button (1).
2. Pull out the battery (2).
GENERAL SAFETY WARNING #4!
CAUTION: Protect the battery contacts when the battery
is not being used. Loose metal parts may short-circuit the
contacts – Explosion and fire hazard!
Switching the Power Tool On
1. Press the switch interlock and hold down (1).
2. Pull back On/Off switch towards the handle (2).
3. The motor runs.
Switching the Power Tool Off
1. Release the On /Off switch (2).
GENERAL SAFETY WARNING #1!
Removing and Emptying the Grass
Catcher
1. If the grass catcher bag is full and should be emptied
immediately.

2. Switch the motor off.
3. Wait until the cutter bar stops.
4. Lift the discharge flap.
5. Remove the grass catcher.
6. Lower the discharge flap down again.
7. Empty the grass catcher.
8. Before hooking, remove any obstructions from the
cutting area.
Working Without the Grass Catcher
When working without the grass catcher, the mowed
grass is ejected directly downwards.
Charging the Battery
1. Plug the charger into an AC outlet 100-250V (normal
household voltage).
2. Insert the battery into the slots of the charger and slide
into place until the battery locks into place
3. The LED will flash green while the battery is charging.
- Once the battery is fully charged, the LED indicator will
show a steady green light.
- Remove the battery by pressing and holding the latch
button and sliding out of the charger. Lithium Ion batteries
have no memory effect – a partial charge will not damage
your battery.
TIPS ON LAWN CARE
Here are some tips to help you keep your lawn looking
healthy and ensure uniform growth:
Lawns consist of various grass types. Frequent mowing
promotes the growth of grass, resulting in strong roots and a
firm sward. If you seldom cut the grass, you will enhance the
development of high-growing types of grass and other weeds,
such as clover, daisies). The normal height of a lawn is
approx. 4–5 cm. Only one third of the total height should be
mown; therefore cut 7–8 cm long grass to normal height.
PARTS LIST
1. Upper Handle
2. Fasten Screw
3. Lower Handle
4. Grass Catcher
5. Battery
6. Wheels
7. Switch Interlock
8. Foam Pipe
9. On/Off Switch
10. Plastic Stopper
11. Safety Key

MAINTENANCE AND CARE
1. Switch the unit off, remove the safety key and remove the
battery from the mower then place the unit in a safe
location.
2. Do not keep the unit within the reach of children.
3. Ensure that the ventilation slots in the unit are clean.
4. Keep all nuts, bolts and screws tight to be sure that the
lawnmower is in safe working condition.
5. Check the grass catcher frequently for wear or damages.
6. Use only the cutter bar, which are intended for this
lawnmower.
7. Please follow the supplied installation instructions and
remove the battery beforehand.
8. Have repairs carriedout exclusively by a qualified
technician or at a service center.
Cleaning
Lawn Mower
1. Do not use water or liquid detergents.
2. Whenever possible, always clean the unit directly
after mowing.
3. Remove the battery.
4. Remove the grass catcher.
5. After mowing, always clean the lawnmower with a
hand brush.
6. Remove grass residues carefully out of the cutting
area. Remove stuck clipping deposits using a stick.
7. Keep the ventilation slits clean and dust-free.
Grass Catcher
For thorough cleaning, the grass catcher can be cleaned
with a hose
Storage
1. Remove the safety key and remove the battery from the
mower before storing
2. Store the unit in a dry and frost-free place (50-77 °F).
3. Store the battery and the unit separately.
4. Charge the battery before storing the unit in winter.
5. Keep the unit, in particular its plastic components, away
from brake fluids, petrol, petroleum products, penetrating
oil, etc. They contain chemical substances which may
damage, attack or destroy the plastic components of the
unit.
Folding the Lawn Mower
The handle bar can be folded down to facilitate storage and
transport. Loosen the screws of triangle knob on the upper
handle and move the handle backwards .
Replacing/Regrinding The Cutter Blade
GENERAL SAFETY WARNING #2!
Spare parts must conform with the requirements
specified by the manufacturer. Therefore use original
spare parts only or spare parts authorized by the
manufacturer.
Repair
Check the unit for damage. Repairs may be earned out by
an authorized customer service centre only.
DISPOSAL INFORMATION
Recycle raw materials instead of disposing the wastes.
Device, accessories and packaging should be recycled in
an environmentally friendly manner. Plastic parts are
identified for recycling according to material type.
For EU countries only:
Do not throw electric powertools into the householdwaste!
In accordance with the European Directive 2012/19/EC on
Waste Electrical and Electronic Equipment and
transposition into national law, used electric power tools
must be collected separately and recycled in an
environmentally friendly manner.
GUARANTEE/WARRANTY
This product has been manufactured to the highest
quality standards. When a new product is purchased, it is
guaranteed a 24-month (lawnmower) and 12-month
(battery) manufacturer’s warranty which comes into force
on the date the product was purchased.
The guarantee covers only the defects which can be
attributed to a material and/or production fault as well as
nonperformance of warranted characteristics.
When making a claim under the guarantee, enclose the
original sales receipt with purchase date. Repairs under
the guarantee may be carried out only by workshops or
service centres authorised by the manufacturer.
A claim may be made under the guarantee only if the
power tool has been used as intended.
This warranty is invalid where defects are caused by or
result from:
- misuse, abuse or neglect;
- commercial use (industry, craft, rental)
- repairs attempted by unauthorized repair centers
- damage caused by external effects, foreign objects,
substances or accidents.
