Tack life PCD04C User manual

User Manual
Cordless Impact Drill/Driver
Model: PCD04C
18V Li-ion
PCD04C

English
Deutsch
Français
Español
Italiano
01~15
16~32
33~48
49~65
66~81
Contents

Original Instructions
Description of Symbols
The rating plate on your tool may show symbols.These represent important informa-
tion about the product or instructions on its use.
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Read instruction manual
DO NOT incinerate batteries!
Caution!
For indoors use only !
Internal time lag fuse with a maximum current of 3.15A.
Class II construction
Environmental Protection Waste electrical products should not be
disposed of with household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling advice.
Conforms to relevant legislation and safety standards.
- 01 -

Li-ion battery cells are recyclable and should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
local authority or retailer for recycling advice
Specification
- 02 -
Rated Voltage
No-load Speed
Impacts per minute
Chuck Capacitiy
Max. Drilling Capacity
Battery pack Voltage
- Battery cell
Charger
-Rated Voltage
-Output Voltage
-Rated output current
-Charging Time
Protection class
Sound and Vibration Data
Sound pressure LPA
Sound power LWA
Uncertainty K:
Vibration (No load)
Vibration (Drilling metal)
Vibration(Drilling masonry)
Uncertainty K:
DC 18V (MAX 20V)
0-450/0-1600rpm
0-19200min
13mm
Steel: Ø 6 mm
Brick: Ø 8 mm
Wood: Ø20 mm
DC 18V (MAX 20V)
Li-Ion 2.0 Ah
100-240VAC 50-60HZ 15W
22.7VDC
380mA
6H
80.80dB(A)
91.80dB(A)
3 dB(A)
0.748m/s2
1.753 m/s2
13.83 m/s2
1.5m/s2

2 43 5 6
7
9
14
11
1
8
10
13
12
16
- 03 -
Product Features
1.huck Jaws 2.Chuck Collar
3.Torque Selector 4.Mode Selector
5.Gear Switch 6.Motor Vents
7.Forward/Reverse Switch 8.Trigger Switch
9.Hand Grip 10.Work Light
11.Battery Charge Indicator 12.Battery
13.Battery Release 14.Belt Clip
16.Charger base15.Charger
15

- 04 -
WARNING
Always wear ear protection where the sound level exceeds 85dB(A) and limit the
time of exposure if necessary. If sound levels are uncomfortable, even with ear
protection, stop using the tool immediately and check the ear protection is correctly
fitted and provides the correct level of sound attenuation for the level of sound
produced by your tool.
WARNING
User exposure to tool vibration can result in loss of sense of touch, numbness,
tingling and reduced ability to grip. Long term exposure can lead to a chronic
condition. If necessary, limit the length of time exposed to vibration and use
anti-vibration gloves. Do not operate the tool with hands below a normal comfortable
temperature, as vibration will have a greater effect. Use the figures provided in the
specification relating to vibration to calculate the duration and frequency of operating
the tool.
Sound and vibration levels in the specification are determined according to EN60745
or similar international standards. The figures represent normal use for the tool in
normal working conditions. A poorly maintained, incorrectly assembled, or misused
tool may produce increased levels of noise and vibration. www.osha.europa.eu
provides information on sound and vibration levels in the workplace that may be
useful to domestic users who use tools for long periods of time.
General Safety
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
WARNING
This appliance is not intended for use by persons (including children) with reduced,
physical or mental capabilities or lack of experience or knowledge unless they have
been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children must be supervised to ensure that they do not
play with the appliance.
Save all warnings and instructions for future reference
The term "power tool" in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
1. Work area safety
a.Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b.
c.
2. Electrical safety
a.
b.
c.
d.
e.
f.
3. Personal safety
a.
b.
c.
d.
e.
- 05 -
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body
is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations

f.
g.
4. Power tool use and care
a.
b.
c.
d.
e.
f.
g.
5. Battery tool use and care
a.
- 06 -
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.
Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.
WARNING: When used in Australia or New Zealand, it is recommended that this
tool is ALWAYS
supplied via Residual Current Device (RCD) with a rated residual current of 30mA
or less
Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with
another battery pack

b.
d.
e.
6. Service
a.
Additional Safety for Battery-Operated Drills
WARNING
Important: It is imperative to follow all national safety regulations concerning installa-
tion, operation and maintenance.
a.
b.
c.
d.
e.
f.
g.
h.
i.
- 07 -
Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects that can make a
connection from one terminal to another. Shorting the battery terminals together
may cause burns or a fire.
If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact occurs, flush with water. If liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause irritation or burns.
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
DO NOT allow anyone under the age of 18 years to use this tool, and ensure that
operators are qualified and familiar with the operating and safety instructions
Battery chargers are for indoors use only. Ensure that the power supply and
charger are protected against moisture at all times.
When using the drill, use safety equipment including safety glasses or shield, ear
defenders, and protective clothing including safety gloves. Wear respiratory
protection suitable for the work being undertaken. A minimum rating of FFP2 is
recommended. If operating the tool causes discomfort in any way, stop immedi-
ately and review your method of use.
Use metal and voltage detectors to locate concealed electric, water or gas lines.
Avoid touching live components or conductors.
Ensure that the lighting is adequate.
Ensure that the drill bit is securely fixed in the chuck. Insecure drill bits can be
ejected from the machine causing a hazard
Ensure that the drill bit is not in contact with the workpiece prior to starting up the tool.
Before drilling, check that there is sufficient clearance for the drill bit under the
workpiece.
DO NOT exert pressure on to the tool. To do so would shorten its service life.

j.
k.
l.
m.
n.
o.
p.
Battery Safety
WARNING
Li-Ion batteries, if incorrectly used, stored or charged are a fire, burn and
explosion hazard.
●
●
●
●
●
●
●
●
Battery Charger Safety
Use the battery charger correctly
●
●
- 08 -
Drill bits get hot during operation, allow to cool prior to handling them.
NEVER use your hands to remove sawdust, chips or waste close by the bit.
lIf you are interrupted when operating the drill, complete the process and switch
off before looking up.
Where possible, use clamps or a vice to hold your work.
Examine the chuck regularly for signs of wear or damage. Have damaged parts
repaired by a qualified service centrer) ALWAYS wait until the drill has com.
ALWAYS wait until the drill has come to a complete stop before putting it down.
Periodically check all nuts, bolts and other fixings and tighten where necessary.
Keep the battery out of reach of children.
ONLY charge Li-Ion batteries using the charger provided or designed specifically
for your product.
ONLY use Li-Ion batteries provided with a product or specifically designed to be
compatible.
Allow batteries to cool for 15 minutes after charging or heavy use. Failure to follow
these instructions may cause overheating or fire
When not in use batteries should be stored at room temperature (approximately 20°C).
Ensure that battery contacts cannot accidentally short in storage. Keep batteries
clean; foreign objects or dirt may cause a short. Keep away from other metal
objects, for example, paperclips, coins, keys, nails and screws.
Under abusive conditions, liquid may be ejected from the battery. This liquid may
cause skin irritation or burns. Avoid contact. If contact accidentally occurs, flush
with water. If liquid contacts eyes, seek medical help.
DO NOT open, disassemble, crush, heat above 60°C or incinerate. Do not
dispose of in fire or similar.
Refer to the section of this manual relating to use of the battery charger before
attempting to charge the battery.
Do not attempt to use the charger with any batteries other than those supplied.
Keep your battery charger clean; foreign objects or dirt may cause a short or block

●
WARNING
DO NOT attempt to recharge non-rechargeable batteries.
Before Use
Removing a battery
Remove the Battery from the tool by pressing the Battery Release, then slide the
Battery out of the Battery Slot.
WARNING
DO NOT try to remove the Battery without pressing the Battery Release button. The
tool or Battery could be damaged.
Fitting a battery
1.
Note
Make sure the Battery and tool are lined up correctly. If the Battery does not slide into
the tool easily, do not force it. Instead, slide the Battery out of the tool again, check
the top of Battery and the tool battery slot are clean and undamaged and that the
contacts are not bent.
Setting up the battery charger
1.
2.
Note
The RED LED on the Charger base will on to indicate that the charger is ready to
charge the battery.
WARNING
Use this charger ONLY to charge the supplied battery or additional purchased
batteries that are specifically designed for this tool.
WARNING
The charger is designed for indoor use only, and MUST NOT be used in damp or wet
conditions.
- 09 -
air vents. Failure to follow these instructions may cause overheating or fire.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Fit a battery by sliding it on to the Battery Slot of the tool until it clicks and locks
into position.
If fitted, remove any Battery from the Battery Charger.
Insert the Battery Charger mains plug into a suitable mains socket.

Charging the battery
WARNING
Failure to follow the correct procedure when charging batteries will result in
permanent damage.
Note
Normal charging time is approximately 6H for a recently discharged 2.0AH
capacity battery. However, if the Battery has been left in a discharged state for some
time, it may take additional time to charge.
1. Slide a fully or partially discharged Battery on to the Battery Charger .
Note
Make sure the Battery and Battery Charger are lined up correctly.
If the Battery does not slide on to the Battery Charger easily, don’t
force it. Instead, remove the Battery, check the top of Battery and
the Battery Charger slot are clean and undamaged and that the
contacts are not bent.
2. Once charging commences, the Red LED will be on When the battery pack is
not connected to the charger,only the green LED of the charger will be on.
- 10 -
3. When the Battery is fully charged, the Red LED will off and Green LED will on.
Battery Charge Level
The Battery has a built-in Battery Charge Indicator.
Pressing on the button to the right will indicate the charge level. The right LED
indicates a high charge level and the left a low charge level that will mean the battery
pack will require charging soon.
MPORTANT
When a low charge level is indicated, the tool may stop operating while in use, which
is dangerous when operating a circular saw. Always ensure the battery pack has a
good charge level.
Note
about battery charging:
●
●
●
●
●
The battery should be charged at ambient temperatures between 10 and 40°C
(ideally around 20°C).
After charging, allow 15 minutes for the battery to cool before use.
Ensure that the charger is disconnected from the mains supply after use, and is
stored correctly.
DO NOT leave batteries on charge for extended periods and NEVER store batteries
on charge.
The Battery Charger monitors battery temperature and voltage while charging.

●
●
●
Fitting drill bits and accessories
WARNING
ALWAYS remove the Battery from the drill before attaching, adjusting or removing
accessories.
WARNING
DO NOT attempt to tighten drill bits (or any other accessory) by gripping the front
part of the chuck and switching the tool on. This can lead to personal injury and can
cause damage to the chuck
WARNING
NEVER fit any accessory or bit with a maximum speed lower than the no load speed
of he power tool.
1.
2.
3.
4.
- 11 -
Remove the Battery once charging is complete to maximise charge cycles of the
battery and not waste power.
Batteries can become faulty over time, individual cells in the battery can fail and
the battery could short. The charger will not charge faulty batteries. Use another
battery, if possible, to check correct functionality of the charger and purchase a
replacement battery if a faulty battery is indicated.
DO NOT store lithium-ion battery packs in a discharged state over a long period
as this can damage the lithium-ion cells. For long-term storage, store batteries in
a high charge state disconnected from the power tool.
The capacity of batteries will reduce over time. After 100 charge cycles, the
battery’s operation time and the maximum torque performance of the driver will
slightly reduce. This decline will continue until the battery has minimal capacity
after 500 charge cycles. This is normal and not a fault with the battery pack.
Open the Chuck Jaws (1) by rotating the Chuck Collar (2) anti-clockwise.
Place the drill bit or accessory centrally into the chuck.
Tighten the Chuck Jaws by rotating the Chuck Collar clockwise.
When the drill bit or accessory is securely fastened, carefully run the machine to
test that it is running centrally, smoothly and evenly. If the bit is 'wobbling' or not
running centrally, release the chuck, check the accessory for damage, correct its
position, retighten and test again.

Operation
Direction control
WARNING
NEVER change the direction of rotation while the tool is running. This may cause
permanent damage to the tool.
●
●
●
Note
When the Forward/Reverse Switch is in the central position, the drill is locked and
cannot be switched on. Use this setting as a safety feature to prevent the drill from
being switched on accidentally.
Torque control
Note
This cordless drill is equipped with a torque control clutch allowing the machine to be
set to the correct torque for the individual application.
●
●
Gear selection
●
●
Note
ALWAYS read the documentation provided with drill bits and accessories for the
recommended or maximum speed setting and use the most appropriate gear. See
‘Specification’ for the maximum no load speed of each gear.
Switching on/off
WARNING
ALWAYS wear adequate personal protection equipment when setting up and operating
this machine.
- 12 -
The direction of rotation can be set using the Forward/Reverse Switch (6).
For anti-clockwise rotation, push the switch to the right.
For clockwise rotation, push the switch to the left.
The clutch settings are indicated by the symbols on the Torque Selector (3)
Rotate the Torque Selector to select the desired setting: the higher the number
displayed on the torque ring, the higher the torque produced by the too.
Select gear 1 on the Gear Switch (4) for the higher torque. A lower speed gear is
generally more suitable for driving screws and fasteners
Select gear 2 on the Gear Switch for the lower torque. A higher speed gear is for
drilling and must not be used for driving screws and fasteners.

1. To start the drill, squeeze the Trigger Switch (7).
2. The built-in Work Light (9) will illuminate when the Trigger Switch is squeezed.
Note
If the Trigger Switch cannot be pressed down, check that the Forward/Reverse
Switch (6) is not set to its middle position, which locks the device (see ‘Direction
control’).
3. The speed of the drill is controlled by the movement of the trigger: the further the
Trigger Switch is pressed down, the faster the drill will run.
4. Release the Trigger Switch to stop the machine.
Screwdriver use
Note
Always use a universal bit holder when working with screwdriver bits. Do not mount
screwdriver bits directly into the chuck.
1. Select gear 1 using the Gear Switch (5).
2. Rotate the Mode Selector (4) to Drive.
3. Adjust the drill to the appropriate torque setting (see ‘Torque control’).
● When driving screws NEVER use the machine in drill mode.
Note
If in doubt which torque setting best suits the application, start with a low setting and
increase, should more torque be required (e.g. if the screw is not being driven far
enough into the workpiece).
Drilling masonry and concrete
1.Select gear 1 using the Gear Switch (5)
2.Rotate the Mode Selector (4) to the hammer drill position
●Hammer drill mode should be used for drilling into masonry and concrete
●Apply moderate pressure to the rear of the drill, in line with the drill bit
●Use masonry drill bits only. Ensure that the bit size is within the maximum capacity
of the machine (see ‘Specification’)
●DO NOT apply too much pressure. If debris blocks the drill hole, run the drill slowly
and remove the bit from the hole. Repeat until hole is cleared
WARNING
The drill bit, especially the tip, will become very hot when drilling masonry and
concrete. DO NOT touch the bit and never allow it to come into contact with combus-
tible materials.
- 13 -

WARNING
DO NOT inhale masonry dust. Wear adequate breathing protection. Dust from
masonry, concrete and similar substances is harmful and may be toxic.
Drilling wood
1. Select the appropriate gear using the Gear Switch (4).
2. Rotate the Mode Selector (3) to the drill position.
● Ensure that drill bits are suitable for wood, and are within the maximum capacity of
this machine (see ‘Specification’)
WARNING
DO NOT inhale wood dust. Wear adequate breathing protection. Some wood dusts
may be toxic.
Drilling meta
1. Select the appropriate gear using the Gear Switch (4).
2. Rotate the Mode Selector (3) to the drill position.
● Ensure that drill bits are suitable for the grade of metal being drilled, and are within
the maximum capacity of the machine (see ‘Specification’)
●To ensure accuracy, mark the intended hole position using a hammer and centre punch.
WARNING
The drill bit and the workpiece will become very hot when drilling metal. DO NOT
touch the bit and never allow it to come into contact with combustible materials when
hot. Always use a suitable lubricant or cutting fluid, and drill at appropriate speeds.
●ONLY apply moderate pressure tothe drill bit, ensuring efficient cutting and
prolonged drill bit life.
●Use a countersink bit to remove sharp burrs from the hole, preventing cuts and
other kinds of injury.
WARNING
If the power tool gets excessively hot in use, stop using the tool immediately and
allow to cool before continuing work. The cooling period can be reduced by operating
the drill at maximum speed with no load. Always make sure the Motor Vents (5) are
not blocked and do not allow dust to enter the body of the tool through the Motor
Vents; dust, especially metallic dust, may damage or destroy the tool.
Maintenance
WARNING
ALWAYS disconnect from the mains power supply, before carrying out any mainte-
nance/ cleaning of the charger. Remove the battery before carrying out any mainte-
nance/cleaning of the drill.
- 14 -

- 15 -
Note
Both the drill and the charger contain no user-serviceable parts. If the device does
not perform as outlined in this manual, return it to an authorised GMC service centre
for repair
General inspection
●Regularly check that all the fixing screws are tight
●Inspect the supply cord of the tool, prior to each use, for damage or wear. Repairs
should be carried out by an authorised service centre. This advice also applies to
extension cords used with this too.
Cleaning
●Keep your tool clean at all times. Dirt and dust will cause internal parts to wear quickly,
and shorten the machine’s service life. Clean the body of your machine with a soft
brush, or dry cloth. If available, use clean, dry, compressed air to blow through the
ventilation holes
●Clean the tool casing with a soft damp cloth using a mild detergent. Do not use
alcohol, petrol or strong cleaning agents
●Never use caustic agents to clean plastic parts
Lubrication
Slightly lubricate all moving parts at regular intervals with a suitable spray lubricant
Storage
Store this tool carefully in a secure, dry place out of the reach of children
Disposal
Always adhere to national regulations when disposing of power tools that
are no longer functional and are not viable for repair.
Do not dispose of power tools, or other waste electrical and electronic
equipment (WEEE), with household waste
Contact your local waste disposal authority for information on the correct
way to dispose of power tools

Originalanweisungen
Beschreibung der Symbole
Das Typenschild auf Ihrem Werkzeug kann Symbole zeigen. Diese stellen wichtige
Informationen über das Produkt oder die Gebrauchsanweisung dar.
Gehörschutz tragen
Augenschutz tragen
Atemschutz tragen
Kopfschutz tragen
Handschutz tragen
Betriebsanleitung lesen
NICHT Batterien verbrennen!
Vorsicht!
Für den Innenbereich verwenden!
Interne Zeitverzögerung mit maximalem Strom von 3,15 A.
Klasse-II-Konstruktion
Umweltschutz Die Abfälle vomn der Elektroprodukte dürfen nicht mit
Hausmüll entsorgt werden. Bitte recyceln, wo Einrichtungen vorhanden
sind. Überprüfen Sie mit Ihrer örtlichen Behörde oder Händler für
Recycling Beratung.
Entspricht den einschlägigen Rechtsvorschriften und Sicherheitsnormen.
- 16 -

Li-Ionen-Batteriezellen sind recycelbar und sollten nicht mit Hausmüll
entsorgt werden. Bitte recyceln, wo Einrichtungen vorhanden sind.
Überprüfen Sie mit Ihrer örtlichen Behörde oder Händler für Recycling-
beratung
Spezifikation
- 17 -
Nennspannung
Leerlaufgeschwindigkeit
Schläge pro Minute
Futter -Kapazität
Max. Bohrleistung
Batteriespannung
- Batteriezelle
Ladegerät
-Nennspannung
-Ausgangsspannung
-Nennausgangsstrom
-Ladezeit
Schutzklasse
Schall- und Schwingungsdaten
Schalldruck LPA
Schallleistung LWA
Ungewissheit K
Vibration (keine Last)
Vibration (Bohren)
Vibration (Bohren Mauerwerk)
Ungewissheit K:
DC 18V
0-450/0-1600rpm
0-19200min
13mm
Stahl: Ø 6 mm
Ziegel: Ø 8 mm
Holz: Ø20 mm
DC 18V
Li-Ion 2.0 Ah
100-240VAC 50-60HZ 15W
22.7VDC
380mA
6H
80.80dB(A)
91.80dB(A)
3 dB(A)
0.748m/s2
1.753 m/s2
13.83 m/s2
1.5m/s2

- 18 -
2 43 5 6
7
9
14
11
1
8
10
13
12
- 18 -
Produkt-Eigenschaften
1.Die Spannbacken 2.Das Spannfutter
3.Drehmomentauswahl 4.Moduswahlschalter
5.Getriebeschalter 6.Motorentlüftung
7.Vorwärts- / Rückwärtsschalter 8.Trigger-Schalter
9.Handgriff 10.Arbeitslicht
11.Akku-Ladeanzeige 12.Batterie
13.Batteriefreigabe 14.Gürtelschnalle
15.Ladegerät 16.ladegerät:
