INSTRUCTION MANUAL
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Mighty Mouser
Fishing Systems
999 8297.8 © 2005 Greenlee Textron Inc. IM 997 REV 8 1/05
Greenlee / A Textron Company 24455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
All specifications are nominal and may change as design improve-
ments occur. Greenlee Textron Inc. shall not be liable for damages
resulting from misapplication or misuse of its products.
Mighty Mouser is a registered trademark of Greenlee Textron.
KEEP THIS MANUAL
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose .......................................................................... 2
Important Safety Information .......................................... 3
Grounding Instructions ................................................... 4
Specifications ................................................................. 4
Operation ....................................................................... 5
Illustrations and Parts Lists ........................................ 6–9
Description
The Greenlee Mighty Mouser®Fishing Systems are
intended to “fish” or install pulling line or measuring tape
in up to 4" conduit.
Safety
Safety is essential in the use and maintenance of
Greenlee tools and equipment. This instruction manual
and any decals on the tool provide information for
avoiding hazards and unsafe practices related to the
use of this tool. Observe all of the safety information
provided.
Purpose
This instruction manual is intended to familiarize all
personnel with the safe operation procedures for the
following Greenlee tools:
•590 Portable Blower
• 591 Portable Blower Power Fishing System
•592 Mighty Mouser Blow Gun Kit
•691 Mighty Mouser Blow Gun
Keep this manual available to all personnel.
Replacement manuals are available upon request at
no charge.
Greenlee / A Textron Company 34455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
Read and understand all of the
instructions and safety information in
this manual before operating or
servicing this tool.
Failure to observe this warning could
result in severe injury or death.
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury
or property damage. The signal word, defined
below, indicates the severity of the hazard. The
message after the signal word provides information
for preventing or avoiding the hazard.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Hazards which, if not avoided, COULD result in
severe injury or death.
Immediate hazards which, if not avoided, WILL
result in severe injury or death.
SAFETY
ALERT
SYMBOL
IMPORTANT SAFETY INFORMATION
Use this tool for the manufacturer’s intended pur-
pose only. Use other than that which is described in
this manual could result in injury or property damage.
Wear eye protection and a dust
mask when operating the unit. Piston
and debris will exit the conduit at
high speed.
Failure to observe this warning could
result in serious injury from flying
debris.
Electric shock hazard:
•Do not leave unit unattended when
plugged in. Unplug from outlet
when not in use.
•Do not expose to rain. Store
indoors.
•Do not handle plug or blower with
wet hands.
•Do not use with a damaged cord
or plug. If the blower is not working
as it should, if it has been dropped,
damaged, left outdoors or dropped
into water, send it to an authorized
Greenlee service center.
•Do not pull or carry by cord, use
the cord as a handle, close a door
on the cord, or pull cord around
sharp edges or corners. Keep cord
away from heated surfaces.
•Do not unplug by pulling on cord.
To unplug, grasp and pull the
plug — not the cord.
•Connect to a properly grounded
outlet only. See Grounding
Instructions.
Greenlee / A Textron Company 44455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
Grounding Instructions
Electric shock hazard:
•Do not modify the plug provided
with the tool.
•Connect this tool to a grounded
receptacle on a 15–amp GFCI
protected circuit.
Failure to observe these warnings
could result in severe injury or death.
This tool must be grounded. In the event of a malfunc-
tion or breakdown, an electrical ground provides a path
of least resistance for the electric current. This path of
least resistance is intended to reduce the risk of electric
shock.
This tool’s electric cord has a grounding conductor and
a grounding plug as shown. Do not modify the plug.
Connect the plug to a corresponding GFCI protected
receptacle that is properly installed and grounded in
accordance with all national and local codes and
ordinances.
Do not use an adapter.
Specifications
590 Portable Blower
Power .................................. 120 VAC, 50/60 Hz, 10 amp
Airflow (unrestricted) ....................... 2.8 m3/min (100 cfm)
Lift Pressure ....................... 2540 mm of water (0.25 bar)
100 inches of water (3.6 psi)
ReceptaclePlug
Greenlee / A Textron Company 54455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
Operation
Loading Mighty Mouser Blow Gun
Note: Use only Greenlee 595 fish line.
1. Make approximately a 6 mm
(1/4") hole in the center of the
595 fish line.
2. Pull out at least 600 mm (24")
of fish line.
3. Put the fish line spool
into the canister.
4. Feed the fish line through
the round hole in the
drag line insert.
5. Thread the fish line
under the bar on the
drag line insert.
6. Screw the line drag insert into the nose cone,
and screw the nose cone onto the canister
handle section.
Blowing Line
1. Load the fish line into the canister. Refer to “Loading
Mighty Mouser Blow Gun.”
2. Insert hose couplings into the canister handle.
Clamp the hose coupling over the blower exhaust
nozzle securely.
3. Install the appropriate adapter cone on the canister
exhaust nozzle with the fish line inserted through the
cone.
Note: Install the 1' hose between the blow gun and
adapter when the unit is used in tight quarters.
Attach the hose to the blow gun with the clamp
provided.
4. Tie the fish line to the proper size piston loop.
5. Hang the blower from your shoulder by the carry
strap, place the piston in the conduit, and then press
the cone adapter squarely and firmly into the conduit
opening.
6. Turn the blower switch on. When the piston exits the
conduit, turn the power switch off.
LINE TIED
TO PISTON
PISTON
ADAPTER CONE
NOSE
CONE
LINE DRAG INSERT
FISH LINE CANISTER
1' HOSE
ROUND HOLE
600 mm
(24")
BAR
Greenlee / A Textron Company 64455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
Exploded View of 590 Portable Blower and 691 Mighty Mouser Blow Gun
Exploded View of 590 Portable Blower Motor (5)
2 3 4 51
6
14
7
8
11
12
13
9 10
11
10
19 17 16
18
15
21 22 23
20 (includes 21–23)
47 46 43 45 44 43 42 41 40
39
38 37 35 34 33
32
31
3048 36
Greenlee / A Textron Company 74455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
Parts List for 590 Portable Blower and 691 Mighty Mouser Blow Gun
Key Part No. Description Qty
1905 3968.0 Self-tapping screw, #12 x .75 Plastite .............................. 8
2503 2424.1 Intake cover plate ............................................................. 1
3503 2425.0 Intake plate ....................................................................... 1
4503 2428.4 Motor gasket..................................................................... 1
5918 6186.1 Motor (includes items 30–48) ........................................... 1
6503 2423.3 Blower housing ................................................................. 1
7503 2427.6 Cord and switch unit ......................................................... 1
8918 6264.7 Strain relief ....................................................................... 1
9905 3450.6 Washer, #10 plain, type B wide ........................................ 1
10 905 3399.2 Washer, #10 helical, spring lock....................................... 2
11 905 3402.6 Self-tapping screw, #10–32 x 1/2, pan head .................... 2
12 918 6263.9 Strain relief lock nut .......................................................... 1
13 918 6261.2 Power switch .................................................................... 1
14 503 5022.6 Ground wire unit ............................................................... 1
15 918 6070.9 Switch plate ...................................................................... 1
16 905 3969.9 Self-tapping screw, #12 x .50 Plastite .............................. 2
17 503 2426.8 Handle .............................................................................. 1
18 503 2429.2 Strap ................................................................................. 1
19 905 3397.6 Self-tapping screw, #10 x 3/8, type F, pan head .............. 2
20 691 Blow gun (includes items 21–23) ..................................... 1
21 503 2097.1 Nose cone ........................................................................ 1
22 503 2098.0 Line drag insert................................................................. 1
23 503 2096.3 Handle section.................................................................. 1
30 905 3488.3 Screw ............................................................................... 4
31 918 6213.2 Clamp ............................................................................... 2
32 918 6203.5 Brush mechanism............................................................. 2
33 905 3489.1 Screw and washer ............................................................ 2
34 918 6204.3 Comm. end bracket .......................................................... 1
35 918 6205.1 Field.................................................................................. 1
36 905 3490.5 Fibre washer..................................................................... 1
37 918 6207.8 Armature........................................................................... 1
38 918 6119.5 Ball bearing ...................................................................... 1
39 905 3491.3 Clamp washer .................................................................. 1
40 905 3492.1 Felt washer ....................................................................... 1
41 918 6208.6 Shell and bracket.............................................................. 1
42 918 5642.6 Spacer .............................................................................. 1
43 918 6209.4 Rotating fan ...................................................................... 2
44 918 6210.8 Stationary fan ................................................................... 1
45 918 5645.0 Spacer .............................................................................. 1
46 918 6211.6 Fan shell ........................................................................... 1
47 905 3328.3 Washer ............................................................................. 1
48 905 0301.5 Nut .................................................................................... 1
Greenlee / A Textron Company 84455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
591 Portable Blower Power Fishing System and
592 Mighty Mouser Blow Gun Kit
A
B
C
LM
F
E
G
D
P
H
J
K
N
Greenlee / A Textron Company 94455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Mighty Mouser®Fishing Systems
Product Components List
KEY 392 590 591 592 CAT. NO. DESCRIPTION
A11 691 Mighty Mouser Blow Gun
B111595 85 lb tensile strength nylon fish line
C1608 Piston for 1/2" rigid, IMC, EMT
C1609 Piston for 3/4" rigid, IMC, EMT
C1610 Piston for 1" rigid, IMC, EMT
C1611 Piston for 1-1/4" rigid, IMC, EMT
C1612 Piston for 1-1/2" rigid, IMC, EMT
C1613 Piston for 2" rigid, IMC, EMT
C614 Piston for 2-1/2" rigid, IMC
C621 Piston for 2-1/2" EMT
C615 Piston for 3" rigid, IMC
C622 Piston for 3" EMT
C616 Piston for 3-1/2" rigid, IMC
C646 Piston for 3-1/2" EMT
C617 Piston for 4" rigid, IMC
C623 Piston for 4" EMT
D11125646 Adapter cone, 1/2" to 1"
E11125644 Adapter cone, 1-1/4" to 2-1/2"
F11 25645 Adapter cone, 3" to 4"
G11 23360 Adapter nozzle for tape and line
H11 32662 Storage box
J132431 Flexible hose, 1-1/2" dia. x 4'
K133451 Hose clamp
L11132104 Flexible hose, 1-1/2" dia. x 1'
M11153633 Hose clamp (to secure item L to A)
N11 590 Portable blower
P10 10 37907 1/2" conduit x 46 m (150') line package
P55 37908 3/4" conduit x 61 m (200') line package
P55 37910 3/4" conduit x 137 m (450') line package
P55 37911 1" conduit x 61 m (200') line package
P55 37913 1" conduit x 137 m (450') line package
154284 Accessory container (not shown)
139063 Lid (not shown)
139052 Decal (not shown)
USA 800-435-0786 Fax: 800-451-2632
815-397-7070 Fax: 815-397-1865
Canada 800-435-0786 Fax: 800-524-2853
International +1-815-397-7070 Fax: +1-815-397-9247
4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070
An ISO 9001 Company
•
Greenlee Textron Inc. is a subsidiary of Textron Inc.
www.greenlee.com Printed in USA
Table of contents
