TILMOR Power Ox 240B User manual

Operator Manual
POWER OX 240B
Original Operator’s Manual 12-10007 Rev.00

Visit www.tilmor.com for the latest
version of this operator’s manual.
A downloadable parts manual is
also available.
Model# (A):
Serial# (B):
Engine Serial# (C):
XXXXX-XXXXXXX
CC
To the Owner
Contact Information and Product Identication
If contacting Tilmor for information about servicing your product please provide the product and
serial numbers.
Please complete the following information for future reference. See the pictures below to nd the
location of the identication numbers.
Date of Purchase:
Dealer / Distributor:
Dealer / Distributor Address:
Dealer / Distributor Phone Number:
295 Kurzen Rd. N
Dalton, OH 44618
www.tilmor.com
MODEL
SERIAL
AA
BB
Tilmor LLC. Reserves the right to make changes in
design or specications without obligations to make like
changes on previously manufactured products.

TABLE OF CONTENTS
4
INTRODUCTION PAGE 6
Product Description................................................................................................................................6
Using Your Manual.................................................................................................................................7
SAFETY PAGE 8
Safety Decals.........................................................................................................................................8
Training Required.................................................................................................................................10
Personal Protective Equipment Requirements ....................................................................................10
Operation Safety ..................................................................................................................................10
Preventing Accidents............................................................................................................................ 11
Keep Riders O󰀨.................................................................................................................................... 11
Truck or Trailer Transport..................................................................................................................... 11
Maintenance......................................................................................................................................... 11
Fuel Safety...........................................................................................................................................12
Power Ox 240B Tractor Safety Procedures .........................................................................................13
OPERATIONAL CONTROLS PAGE 14
Standard Operational Controls.............................................................................................................14
GENERAL OPERATION PAGE 15
Handlebar Adjustment..........................................................................................................................15
Track Width Adjustment .......................................................................................................................15
Receiver Hitch Use ..............................................................................................................................17
Pre-operations Inspection ....................................................................................................................18
Operating Procedure............................................................................................................................18
Starting the Engine...............................................................................................................................19
Stopping the Engine.............................................................................................................................19
Setting Engine Speed ..........................................................................................................................19
Storage.................................................................................................................................................20
SERVICE PAGE 21
Service and General Maintenance.......................................................................................................21
Engine Servicing ..................................................................................................................................21
Cleaning and Appearance Care...........................................................................................................21
Lubrication Locations ...........................................................................................................................21
Belt Inspection......................................................................................................................................21
Engine Drive Belt Replacement ...........................................................................................................22
Axle Drive Belt Replacement ...............................................................................................................22
Chain Tension Adjustment....................................................................................................................23
Drive Control Cable Adjustment...........................................................................................................25
SPECIFICATIONS PAGE 26
Engine..................................................................................................................................................26
Belts .....................................................................................................................................................26
Tires .....................................................................................................................................................26
Drive Chains.........................................................................................................................................26
Fluid Capacities & Specications.........................................................................................................26

TABLE OF CONTENTS
5
Track Width Dimensions ......................................................................................................................27
Overall Dimensions ..............................................................................................................................28
WARRANTY PAGE 29
Return Policy & Procedure...................................................................................................................29
Warranty...............................................................................................................................................29
Non-serialized Product - 1 year............................................................................................................29
Serialized Product - 2 year or 1000 hours............................................................................................29
Warranty Policy ....................................................................................................................................29
Warranty Procedure .............................................................................................................................29

Introduction - 6
INTRODUCTION
Product Description
The Power Ox 240B Two Wheel Tractor Is designed for planting, cultivation, and light hilling. The Power Ox
240B is powered by a Honda GX120 engine. It is a well balanced machine with 13” + of ground clearance.
The handle bar height is adjustable, making the tractor easy to use and comfortable for the operator. The
track width of the Power Ox 240B is adjustable to accommodate a variety of row spacing.
Why Do I Need an Operator’s Manual?
This manual has been created to help you gain the important knowledge of what is needed to safely
operate, maintain, and service your machine. It is divided into sections for convenient reference of the
appropriate section.
You must read and understand the operator’s manual for each piece of Tilmor equipment you own. Read-
ing the operator’s manual will help you become familiar with each specic piece of equipment. Under-
standing the operator’s manual will help you, as well as others, avoid personal injury and/or damage to the
equipment. Keep this manual with the machine at all times. The manual should remain with the machine
even if it is sold. If this manual becomes damaged or unreadable, it should be replaced immediately. This
manual is available on our website at www.tilmor.com
When using a Tilmor attachment, be sure to read and follow the safety and operating instructions of both
the power unit and the attachment being used to ensure the safest operation possible.
The information in this manual provides the operator with the safest procedures to operate the machine
while getting the maximum use out of the unit. Failure to follow the safety precautions listed in this manual
may result in personal injury and/or damage to the equipment.
Tilmor llc. is pleased to provide you with your new Tilmor
Power Ox 240B!
Please visit our website, www.tilmor.com for a complete list of
available Tilmor products, and resources.

INTRODUCTION
Introduction - 7
Using Your Manual
Throughout this manual, you will encounter special messages and symbols that identify potential safety
concerns to help you as well as others avoid personal injury or damage to the equipment.
Symbol Denitions
Attention
This symbol identies potential health and safety
hazards. It marks safety precautions. Your safety
and the safety of others is involved.
There are three signal words that describe the level of safety concern: Danger, Warning, and Caution.
Safety should always be the #1 priority when working on or operating equipment. Accidents are more likely
to occur when proper operating procedures are not followed or inexperienced operators are involved.
Note: Right-Hand and Left-Hand orientations may be referred to at di󰀨erent places throughout this manual.
Right-Hand and Left-Hand is determined as if facing forward from the operator station.
Signal Word Denitions
CAUTION
Indicates a potentially hazardous situation which
if not avoided, may result in minor or moderate
injury and/ or property damage. It may also be
used to alert against unsafe practices.
DANGER
Indicates an imminently hazardous situation
which, if not avoided, will result in death or seri-
ous injury. This signal word is limited to the most
extreme cases.
WARNING
Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious
injury.

Safety - 8
SAFETY
Safety Decals
The following safety decals must be maintained on your Tilmor Power Ox 240B. Keep all safety decals
legible. Remove all grease, dirt, and debris from safety decals and instructional labels. If any decals are
faded, illegible, or missing, visit www.tilmor.com or call 1-844-255-5864 for replacements. When replace-
ment or new components are installed, be sure that current safety decals are a󰀩xed to the replacement or
new part.
CCBB
AA
EE
AA
FF
FF
DD

SAFETY
Safety - 9
General Safety Procedures
for Tilmor Tractors, Attachments, & Accessories
Decal Description Part Number Quantity
A Warning, Moving Parts 00-0216 2
B Warning - Read Owners Manual 00-0217 1
C Warning - General Safety 00-0220 1
D Warning - Pinch Point 00-0218 1
E Danger Shield Missing 00-0492 1
F Warning - No Step 00-0502 2
WARNING
Pinch Points!
Moving parts can
crush or cut.
KEEP CLEAR!
00-0218
AABB
CCDD
EE
WARNING
Moving parts can
cause injury.
Keep hands, feet,
and objects clear
during operation.
00-0216
WARNING
Read and understand
operator’s manual before
using this machine.
00-0217
Failure to follow operating
instructions could result in
injury or death.
FF

SAFETY
Safety - 10
General Safety Procedures
for Tilmor Tractors, Attachments, & Accessories
Training Required
• The owner of this machine is solely responsible for properly training the operators.
• The owner/operator is solely responsible for the operation of this machine and prevention of accidents
or injuries occurring to him/herself, other people, or property.
• Do not allow operation or service by children or untrained personnel.
Local regulations may restrict the age of the operator.
• Before operating this machine, read the operator’s manual and under-
stand it’s contents.
• If the operator of the machine cannot understand this manual, then it
is the responsibility of this machine’s owner to fully explain the material
within this manual to the operator.
• Learn and understand the use of all of the controls.
• Know how to stop the power unit and all attachments quickly in the
event of an emergency.
Personal Protective Equipment Requirements
It is the responsibility of the owner to be sure that the operators use the proper personal protective equip-
ment while operating the machine. Required personal protective equipment includes but is not limited to
the following list.
• Wear a certied ear protection device to prevent the loss of hearing.
• Prevent eye injury by wearing safety glasses while operating the machine.
• Closed toe shoes must be worn at all times.
• Long pants must be worn at all times.
• When operating in dusty conditions, it is recommended that a dust mask be worn.
Operation Safety
• Inspect all equipment before operation. Repair or replace any damaged, worn, or missing parts. Be
sure all guards and shields are in proper working condition and are secured in place. Make all of the
necessary adjustments before operating the machine.
• Some pictures in this manual may show shields or covers opened or removed in order to clearly illus-
trate any instructions. Under no circumstance should the machine be operated without these devices
in place.
• Alterations or modications to this machine can reduce safety and could cause damage to the
machine. Do not alter safety devices or operate with shields or covers removed.
• Before each use, verify that all controls function properly and inspect all safety devices. Do not oper-
ate if controls or safety devices are not in proper working condition.
• Observe and follow all safety decals.
• Ensure all attachments or accessories are locked or fastened securely before operation.
• Ensure that all bystanders are clear of the machine before operation. Stop the machine if someone
enters your work area.
• Always be alert to what is happening around you, but do not lose focus to the task you are perform-
ing. Always look in the direction the machine is moving.
• If you hit an object, stop and inspect the machine. Make all necessary repairs before continuing
operation of the machine.
• Stop operation immediately at any sign of equipment failure. An unusual noise can be a warning of
equipment failure or a sign that maintenance may be required. Make all necessary repairs before
continuing operation of the machine again.
• Do not leave the machine unattended while it is running.
• Always park the machine on level ground.
• Always shut o󰀨 the engine when connecting the attachments to the power unit.

SAFETY
Safety - 11
General Safety Procedures
for Tilmor Tractors, Attachments, & Accessories
Operation Safety (continued)
• Never leave equipment unattended without shutting o󰀨 the engine.
• Only operate in well-lit conditions.
• Do not operate when there is a risk of lightning.
• Do not run the engine in a building without adequate ventilation.
• Do not touch the engine or the mu󰀪er while the engine is running or immediately after stopping the
engine. These areas may be hot enough to cause a burn.
• Do not change the engine governor settings or over-speed the engine. Operating the engine at
excessive speed may increase the hazard of personal injury.
• To reduce the hazard of re, keep the engine, and mu󰀪er areas free of grass, leaves, excessive
grease, and other ammable materials.
Preventing Accidents
• Clear working area of objects that might be hit or thrown from the machine.
• Keep people and pets out of working areas.
• Know the work area well before operation. Do not operate where traction or
stability is questionable.
• Reduce speed when you are operating over rough ground.
• Equipment can cause serious injury
and or death when improperly used.
• Before operating understand the
operation and safety of the power unit
and attachment being used.
• Do not operate the machine if you are not in good physi-
cal and mental health, if you will be distracted by personal
devices, or are under the inuence of any substance that
may impair decision, dexterity, or judgement.
• Children are attracted to machine activity. Be aware of children and do not allow them in the working
area. Turn o󰀨 the machine if a child enters the work area.
Keep Riders O󰀨
• The tractor is not designed to have riders of any kind on the tractor, attachments, or attached tools.
Truck or Trailer Transport
• Use full width ramps for loading the machine into a truck or trailer.
• Always secure the power unit and/or attachment to the transporting vehicle securely using straps ,
chains, cable, or ropes.
• Both front and rear straps should be directed down and outward from the machine.
• Shut o󰀨 fuel supply to the power unit during transport on a truck or trailer.
Maintenance
• Keep all safety decals legible. Remove all grease dirt, and debris from safety decals and instruc-
tional labels.
• If any decals are faded, illegible, or missing, visit www.tilmor.com.
• When new components are installed, be sure that current safety decals are a󰀩xed to the replacement
components.
• If any component requires replacement use only original Tilmor replacement parts.
• Keep all bolts, nuts screws and other fasteners properly tightened.
• Always ensure the kickstand is lowered or the power unit is supported, and shut o󰀨 engine. Make
sure all moving parts have come to a complete stop before cleaning, inspecting, adjusting, or repair-
ing.

SAFETY
Safety - 12
General Safety Procedures
for Tilmor Tractors, Attachments, & Accessories
• Never perform maintenance on the power unit and/or implement if someone is in the operator’s station.
• To reduce the hazard of re, keep the engine and mu󰀪er areas free of debris.
• Do not touch the engine, the mu󰀪er, or other exhaust components while the engine is running or
immediately after stopping the engine. These areas may be hot enough to cause a burn.
• Allow the engine to cool before storing and do not store near an open ame.
• Do not change the engine governor settings or over-speed the engine. Operating engine at excessive
speed may increase the hazard of personal injury.
• Springs may contain stored energy. Use caution when disengaging or removing springs and/or spring
loaded components.
• An obstruction or blockage in a drive system or moving/rotating parts may cause a build up of stored
energy. When the obstruction or blockage is removed, the drive system or moving/rotating parts may
move suddenly. Do not attempt to remove an obstruction or blockage with your hands. Keep hands,
feet, and clothing away from all power driven parts.
• Dispose of all uids in accordance with local laws.
Fuel Safety
• To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is
extremely ammable and the vapors are explosive.
• Do not refuel the machine while smoking or at a location near ames or sparks.
• Always refuel the machine outdoors.
• Do not store the machine or fuel container indoors where the fuel or fumes can reach an open ame,
spark, or pilot light.
• Only store fuel in an approved container. Keep out of reach of children.
• Never ll containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place con-
tainers on the ground away from your vehicle before lling.
• Remove the machine from the truck or trailer and refuel it on the ground. If this is not possible, refuel
the machine using a portable container, rather than from a fuel dispenser nozzle.
• Never remove the fuel cap or add fuel with the engine running. Allow the engine to cool before refueling.
• Never remove the fuel cap while on a slope. Only remove when parked on a level surface.
• Replace all fuel tank and container caps securely.
• Do not overll the fuel tank. Overlling of the fuel tank could result in engine ooding, fuel leakage
from the tank, or damage to the emissions control system.
• If fuel is spilled, do not attempt to start the engine. Move the power unit away from the fuel spill and
avoid creating any source of ignition until fuel vapors have dissipated.
• If the fuel tank must be drained, it should be drained outdoors into an approved container.
• Dispose of all uids in accordance with local laws.
• The fuel system is equipped with a shut-o󰀨 valve. Shut o󰀨 the fuel when transporting the machine to
and from the job, when parking the machine indoors, or when servicing the fuel system.
Maintenance (continued)

SAFETY
Safety - 13Safety - 13
Power Ox 240B Tractor Safety Procedures
• Do not remove any safety guards.
• Do not operate the Power Ox 240B without all shields properly installed.
• Do not operate the Power Ox 240B without a tool installed in the receiver hitch.
• Moving parts can cause injuries. Keep hands and feet clear of moving parts.
• Pinch points: some parts can pinch or crush. Keep clear of pinch points and use caution during opera-
tion of the Power Ox 240B.
• Clear the area of all obstacles, hazards, and personnel before operating the Power Ox 240B.
• Do not modify the Power Ox 240B in any way. Modifying the Power Ox 240B could cause injury or
damage to equipment. Any modication made to the Power Ox 240B will void any warranty.
WARNING
Operating, servicing and maintaining o󰀨-road
equipment can expose you to chemicals including
engine exhaust, carbon monoxide, phthalates, and
lead, which are known to the State of California to
cause cancer and birth defects or other reproduc-
tive harm. To minimize exposure, avoid breathing
exhaust, do not idle the engine except as neces-
sary, service equipment in a well-ventilated area
and wear gloves or wash your hands frequently
when servicing equipment.
For more information go to
www.P65Warnings.ca.gov.

Operation - 14Operation - 14
OPERATIONAL CONTROLS
Standard Operational Controls
Use the following images to help identify the loca-
tions of operational controls. The letter next to each
control can be referenced to the list that follows
these images.
CC
DDEE
AA
AA
BB
FF
GGGG
HH
A. Drive Control Handles
B. Throttle Control
C. Choke
D. Fuel Shuto󰀨
E. Starter Cord Handle
F. Stop Switch
G. Handlebar Height Adjustment Knob
H. Receiver Hitch

Operation - 15
GENERAL OPERATION
Handlebar Adjustment
The Power Ox 240B has a height adjustable handle-
bar to increase operator control and comfort. The
following steps describe how to adjust the handle-
bars.
1. Loosen the handlebar adjustment knobs (A).
2.
AA
Support the handle bars.
3. Lift one side of the locking mechanism (B)
ensure the mechanism is not engaged and
tighten the adjustment knob.
4.
BB
Lift the other side locking mechanism and lower
the handle bars to the lowest position.
5. Loosen the adjustment knob.
6. Standing in the operators position, lift the han-
dlebars to the desired location. The mechanism
will engage holding the handlebars in position.
7. Ensure the locking mechanisms are fully
engaged and tighten the adjustment knobs.
Track Width Adjustment
The wheels can be adjusted to three di󰀨erent loca-
tions (Narrow, Mid, Wide), in four inch increments to
accommodate di󰀨erent row spacing. Wheel spacing
dimensions are located in the specication section
of this manual.
1.
CAUTION
Ensure that the Power Ox 240B is securely sup-
ported. Failure to properly support the unit could
result in damage to equipment or injury.
Support the unit with jack stands, ensure that
the wheels are o󰀨 of the ground.
2. Remove the left and right axle covers by remov-
ing the eight 5/16” mounting bolts (A).
3.
AA
AA
AA
AA
Remove the belt and pulley cover by loosening
three 5/16” bolts (B).
BB
BB
GENERAL OPERATION

Operation - 16
GENERAL OPERATION
4. Remove the bearing adjustment mechanisms
(C). from both outer ange bearings.
5.
CC
Locate the master link on the wheel drive
chains. Disconnect the master link to remove
the drive chains.
6. Loosen the bearing and sprocket set screws (D)
7.
DDDD
Remove the 3/8” fender mounting bolts (E).
EE
EE
8. Remove the fender and wheel assembly from
the axle.
9. Adjust the snap rings, sprocket, and woodru󰀨
key (F) to the desired location. NOTE: When
adjusting the right side of the machine to the
narrow position the inner snap ring (G) will not
be used.
10.
FF
GG
Install the fender and wheel assembly onto the
axle.
11. Align the mounting holes and install the 3/8”
fender mounting bolts.
12. Tighten the bearing and sprocket set screws.
13. Install the drive chains.
14. Install the bearing adjustment mechanisms.
15. Adjust the chain tension in accordance with
the chain tension adjustment procedure in this
manual.
16. Install the belt and pulley cover.
17. Install the left and right axle covers.

Operation - 17
GENERAL OPERATION
Receiver Hitch Use
The Power Ox 240B has an adjustable receiver
hitch to easily connect and disconnect tools. The
following steps describe how the receiver hitch can
be installed.
1.
WARNING
Always shut o󰀨 the engine and ensure all moving
parts have come to a complete stop before
adjusting the hitch, installing, or removing an
implement.
Install the hitch in the standard elevated position
(A) for increased ground clearance.
2. The hitch can be installed in the lower position
(B) if needed by simply ipping the receiver over.
AA
BB
3. In both congurations the hitch receiver is
secured in position using a 5/8” hitch pin (C)
placed through the top of the frame secured in
place with a hair pin placed through the bottom
of the hitch pin.
4.
CC
Tighten the 1/2” bolt (D) located on the bottom of
the frame to hold the hitch receiver steady.
5.
DD
The connected tool is held in place using a 3/4”
hitch pin secured in place with a hair pin placed
through the bottom of the hitch pin.

Operation - 18
GENERAL OPERATION
Pre-operations Inspection
1.
WARNING
Failing to properly maintain the Power Ox 240B,
or failing to correct a problem before operation
could result in a signicant malfunction. Some
malfunctions can result in serious injury or death.
Always complete the pre-operation inspection
before operating and correct any problems.
Park the power unit on a level surface, with the
engine shut o󰀨 switch in the OFF position.
2. Refer to the power unit engine operator’s
manual. Check the power unit’s engine oil level,
clean the area around the mu󰀪er and controls,
and clean the nger guard. Add uid or service
as required.
3. Perform a visual inspection of the tractor and
any attachments. Look for loose or missing
hardware, damaged components, or signs of
wear.
4. Grease the unit as required.
5. Apply a chain lubricant to the chain.
6. Check the tire pressure. Ensure that each tire
is inated to the pressure marked on the tire.
7. Check the drive chain tension on both wheels.
Operating Procedure
Before operating the power unit for the rst time,
please review the Safety and Operational Controls
sections in this manual.
1.
WARNING
Before operating the Power Ox 240B for the rst
time, ensure that the engine has had oil added
in accordance with the Honda GX120 owner’s
manual. Failure to do so could result in signicant
damage to the engine.
Complete the pre-operations inspection.
2. Adjust the handlebars to the desired height.
Ensure that the handle bar adjustment mecha-
nism is locked in position and the adjustment
knob is tightened securely.
3.
Attention
Do not operate the tractor without a tool installed
in the receiver hitch.
Install the desired tool to the tractor hitch.
Ensure that the hitch pin is fully installed and
secured in place with the hair pin.
4. Start the engine in accordance with the starting
the engine procedure in this manual.
5. Adjust the throttle as required.
6. Engage the drive system and begin forward
movement. Firmly grasp the handle bar with one
hand. Using the other hand slowly apply upward
pressure to the drive control handle towards the
handlebar grip.
7. To stop forward movement release the drive
control handle.

Operation - 19
GENERAL OPERATION
Starting the Engine
1.
WARNING
Do not operate the Power Ox 240B in an
enclosed area. Exhaust gas contains carbon
monoxide gas that can build up to dangerous
levels in enclosed areas. Breathing carbon
monoxide can cause unconsciousness or death.
Ensure that the power unit is parked on a level
surface.
2. Ensure that a tool or implement is installed in
the hitch receiver.
3. Ensure that the drive control handles are disen-
gaged.
4. Move the fuel shuto󰀨 lever (A) to the on position.
5.
AA
BB
To start a cold engine move the choke control
lever (B) to the closed position. To restart a
warm engine, leave the choke in the open posi-
tion.
6. Move the throttle lever (C) about 1/3 of the way to
the MAX position.
CC
7. Turn the engine switch (D) to the ON position.
8.
DD
Firmly hold the starter cord handle. Pull the
starter grip lightly until resistance is felt, then pull
rapidly. Return the starter grip gently.
9. Gradually move the choke lever to the open
position as the engine warms up.
Stopping the Engine
1. Move the throttle lever to the MIN position.
2. Turn the engine switch to the OFF position.
3. Move the fuel valve lever to the OFF position.
Setting Engine Speed
1. Adjust the throttle lever to the desired engine
speed.

Operation - 20
GENERAL OPERATION
Storage
Preparing the Power Ox for Storage
1.
Attention
Fuel can become stale when stored over 30 days.
Stale fuel causes acid and gum deposits to form
in the fuel system or on essential carburetor parts.
CAUTION
Do not use high pressure water to clean the trac-
tor. High pressure water can force its way into
bearings and other components causing damage
to equipment.
Clean or wash the power ox to remove any accu-
mulated dirt and debris.
2. Store the unit in a well ventilated area to reduce
the hazard of gasoline vapor ignition.
3. With the engine cool cover the unit with a
breathable cover to keep out dust. Do not cover
the unit with a plastic sheet or other non-breath-
able material. Non-breathable material will trap
moisture and promote corrosion.
Removing the Power Ox from Storage
1. Complete the pre-operation check found in this
manual.
2. If the fuel was drained before storing the unit
add fresh fuel to the engine. Gasoline oxidizes
and deteriorates over time, causing hard start-
ing.
3. Grease and lubricate the lubrication locations
identied in the service section of this manual.
4. Check the tire pressure. Endure that each tire
is inated to the pressure marked on the tire.
