Toro TX 525 User manual

FormNo.3437-919RevB
TX525CompactToolCarrier
ModelNo.22323—SerialNo.405700000andUp
ModelNo.22323G—SerialNo.405700000andUp
ModelNo.22324—SerialNo.405700000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3437-919*B

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.
WARNING
CALIFORNIA
Proposition65Warning
Dieselengineexhaustandsomeofits
constituentsareknowntotheStateof
Californiatocausecancer,birthdefects,
andotherreproductiveharm.
Batteryposts,terminals,andrelated
accessoriescontainleadandlead
compounds,chemicalsknownto
theStateofCaliforniatocause
cancerandreproductiveharm.Wash
handsafterhandling.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
Thismachineisacompacttoolcarrierintendedfor
useinvariousearthandmaterialsmovingactivitiesfor
landscapingandconstructionwork.Itisdesignedto
operateawidevarietyofattachmentseachofwhich
performaspecializedfunction.Usingthisproduct
forpurposesotherthanitsintendedusecouldprove
dangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.Toro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.
g243442
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
©2020—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................4
GeneralSafety...................................................4
SafetyandInstructionalDecals..........................5
ProductOverview.....................................................9
Controls.............................................................9
Specications..................................................13
Attachments/Accessories.................................13
BeforeOperation.................................................13
BeforeOperationSafety...................................13
AddingFuel......................................................14
PerformingDailyMaintenance..........................15
DuringOperation.................................................15
DuringOperationSafety...................................15
StartingtheEngine...........................................16
DrivingtheMachine..........................................16
ShuttingOfftheEngine.....................................17
UsingAttachments...........................................17
AfterOperation....................................................19
AfterOperationSafety......................................19
MovingaNon-FunctioningMachine..................19
HaulingtheMachine.........................................19
LiftingtheMachine...........................................21
Maintenance...........................................................22
MaintenanceSafety..........................................22
RecommendedMaintenanceSchedule(s)...........22
Pre-MaintenanceProcedures..............................23
UsingtheCylinderLock....................................23
AccessingInternalComponents.......................24
Lubrication..........................................................26
GreasingtheMachine.......................................26
EngineMaintenance...........................................26
EngineSafety...................................................26
ServicingtheAirCleaner..................................26
ServicingtheEngineOil....................................27
FuelSystemMaintenance...................................29
CheckingtheFuelLinesand
Connections..................................................29
DrainingtheFuelFilter/WaterSeparator...........29
ReplacingtheFuelFilterCanisterand
In-LineFilter..................................................30
BleedingtheFuelSystem.................................30
DrainingtheFuelTank(s)..................................31
ElectricalSystemMaintenance...........................31
ElectricalSystemSafety...................................31
ServicingtheBattery.........................................31
ServicingtheFuses..........................................33
DriveSystemMaintenance..................................34
ServicingtheTracks.........................................34
CoolingSystemMaintenance..............................38
CoolingSystemSafety.....................................38
ServicingtheCoolingSystem...........................38
BrakeMaintenance.............................................39
TestingtheParkingBrake.................................39
BeltMaintenance................................................40
CheckingtheConditionoftheHydraulic
PumpBelt.....................................................40
ControlsSystemMaintenance.............................40
AdjustingtheControls.......................................40
HydraulicSystemMaintenance...........................42
HydraulicSystemSafety...................................42
RelievingHydraulicPressure............................42
HydraulicFluidSpecications...........................43
CheckingtheHydraulic-FluidLevel...................43
ReplacingtheHydraulicFilter...........................44
ChangingtheHydraulicFluid............................45
Cleaning..............................................................46
RemovingDebris..............................................46
CleaningtheChassis........................................46
Storage...................................................................46
StorageSafety..................................................46
Storage.............................................................46
Troubleshooting......................................................47
3

Safety
DANGER
Theremaybeburiedutilitylinesinthework
area.Diggingintothemmaycauseashock
oranexplosion.
Havethepropertyorworkareamarkedfor
buriedlinesanddonotdiginmarkedareas.
Contactyourlocalmarkingserviceorutility
companytohavethepropertymarked(for
example,intheUS,call811orinAustralia,
call1100forthenationwidemarkingservice).
GeneralSafety
DANGER
Theremaybeburiedutilitylinesinthework
area.Diggingintothemmaycauseashock
oranexplosion.
Havethepropertyorworkareamarkedfor
buriedlinesanddonotdiginmarkedareas.
Contactyourlocalmarkingserviceorutility
companytohavethepropertymarked(for
example,intheUS,call811orinAustralia,
call1100forthenationwidemarkingservice).
Alwaysfollowallsafetyinstructionstoavoidserious
injuryordeath.
•Donotcarryaloadwiththearmsraised;always
carryloadsclosetotheground.
•Slopesareamajorfactorrelatedtoloss-of-control
andtip-overaccidents,whichcanresultinsevere
injuryordeath.Operatingthemachineonany
slopeoruneventerrainrequiresextracaution.
•Operatethemachineupanddownslopeswith
theheavyendofthemachineuphillandtheload
closetotheground.Weightdistributionchanges
withattachments.Anemptybucketmakesthe
rearofthemachinetheheavyend,andafull
bucketmakesthefrontofthemachinetheheavy
end.Mostotherattachmentsmakethefrontofthe
machinetheheavyend.
•Havethepropertyorworkareamarkedforburied
linesandotherobjects,anddonotdiginmarked
areas.
•ReadandunderstandthecontentofthisOperator’s
Manualbeforestartingtheengine.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Neverallowchildrenoruntrainedpeopleto
operatethemachine.
•Keepyourhandsandfeetawayfromthemoving
componentsandattachments.
•Donotoperatethemachinewithouttheguards
andothersafetyprotectivedevicesinplaceand
workingonthemachine.
•Keepbystandersandchildrenoutoftheoperating
area.
•Stopthemachine,shutofftheengine,andremove
thekeybeforeservicing,fueling,orunclogging
themachine.
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol,which
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
4

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decalbatterysymbols
BatterySymbols
Someorallofthesesymbolsareonyourbattery.
1.Explosionhazard6.Keepbystandersaway
fromthebattery.
2.Nore,opename,or
smoking
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection.9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator's
Manual.
10.Containslead;donot
discard
decal93-6680
93-6680
decal93-6681
93-6681
1.Cutting/dismembermenthazard,fan—stayawayfrom
movingparts.
decal93-6686
93-6686
1.Hydraulicuid2.ReadtheOperator's
Manual.
decal93-7814
93-7814
1.Entanglementhazard,belt—stayawayfrommovingparts;
keepallguardsandshieldsinplace.
decal93-9084
93-9084
1.Liftpoint/Tie-downpoint
decal100-4650
100-4650
1.Crushinghazardofhand—keepbystandersaway.
2.Crushinghazardoffoot—keepbystandersaway.
decal100-8821
100-8821
1.Crushinghazardfromabove;cuttinghazardofhand—stay
awayfromthefrontofthetractionunitwhentheloader
armsareraised.
5

decal100-8822
100-8822
1.Warning—donotcarrypassengers.
decal106-6755
106-6755
1.Enginecoolantunder
pressure.
3.Warning—donottouchthe
hotsurface.
2.Explosionhazard—read
theOperator'sManual.
4.Warning—readthe
Operator'sManual.
decal115-4020
115-4020
1.Turnright3.Reverse
2.Forward4.Turnleft
decal115-4855
115-4855
1.Hotsurface/burnhazard—wearprotectivegloveswhen
handlingthehydrauliccouplersandreadtheOperator's
Manualforinformationonhandlinghydrauliccomponents.
decal115-4857
115-4857
1.Lowertheloaderarms.4.Curlthebucket.
2.Dumpthebucket.5.Floatthebucketonthe
ground.
3.Raisetheloaderarms.
decal115-4858
115-4858
1.Crushinghazardofhandsorfeet—installthecylinderlock.
decal115-4859
115-4859
1.Disengaged3.Engaged
2.Parkingbrake
6

decal115-4861
115-4861
1.Auxiliaryhydraulics3.Forward
2.Lockedreverse(detent)4.Neutral(off)
decal115-4862
115-4862
1.Loader-valve
lock—unlocked
2.Loader-valvelock—locked
decal115-4865
115-4865
1.Enginecoolant2.ReadtheOperator's
Manual.
decal115-4882
115-4882
1.Warning—donottouchthehotsurface.
decal115-4860
115-4860
1.Warning—readtheOperator'sManual.
2.Warning—lowertheloaderarms,engagetheparkingbrake,shutofftheengine,andremovethekeybeforeleavingthemachine.
3.Crushinghazardfromabove—installthecylinderlockandreadtheOperator’sManualbeforeperformingmaintenance.
4.Cuttinghazardofhandsorfeet—waitforallmovingpartstostop;stayawayfrommovingparts;keepallguardsandshieldsin
place.
5.Crushing/dismembermenthazardofbystanders—keepbystandersaway.
6.Explosionhazard;electricalshockhazard—donotoperateifpowerlinesmaybepresent;callyourlocalutilitycompany.
7

decal138-0800
138-0800
1.ReadtheOperator’sManualstoredinyourmachine.9.Battery
2.Engine—start10.Glowplug
3.Engine—run11.Fast
4.Engine—shutoff12.Slow
5.Hourmeter13.Warning—donotoperatethismachineunlessyouaretrained.
6.Fuel14.Electricalshockhazard,overheadpowerlines—watchfor
overheadpowerlines.
7.Enginecoolanttemperature15.Tippinghazard—movethetractionunitwiththeheavyend
uphill;carryloadslow;donotdrivethemachinewiththeload
raised.
8.Engineoilpressure16.Tippinghazard—driveslowlywhenturning;donotturn
sharplywhiletravelingfast;lookbehindanddownwhen
movinginreverse.
decal139-8813
139-8813
1.ReadtheOperator’sManual.2.Greasepoints
8

ProductOverview
g313997
g313998
Figure3
1.Roadwheels8.Mountplate
2.Track9.Reverse-safetyplate
3.Liftcylinder10.Controlpanel
4.Cylinderlock11.Tie-down/liftloop
5.Loaderarms12.Rear-accesscover
6.Hood13.Sidepanelscreen
7.Auxiliaryhydraulic
couplers
Controls
Becomefamiliarwithallthecontrols(Figure4)before
youstarttheengineandoperatethetractionunit.
ControlPanel
g013016
Figure4
1.Auxiliaryhydraulicslever7.Loader-arm/attachment-tilt
lever
2.Keyswitch8.Parking-brakelever
3.Hourmeter9.Tractioncontrol
4.Fuelgauge10.Referencebar
5.Indicatorlightsand
glow-plugswitch
11.Loader-control-reference
bar
6.Throttlelever12.Loader-valvelock
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page16).
ThrottleLever
Movethecontrolforwardtoincreasetheenginespeed
andrearwardtodecreasespeed.
ReferenceBar
Whendrivingthetractionunit,usethereferencebar
asahandleandaleveragepointforcontrollingthe
tractioncontrolandtheauxiliary-hydraulicslever.T o
ensuresmooth,controlledoperation,donottake
bothhandsoffthereferencebarwhileoperatingthe
machine.
9

TractionControl
g008128
Figure5
1.Referencebar
2.Tractioncontrol
•Tomoveforward,movethetractioncontrolforward
(Figure6).
g008129
Figure6
•Tomoverearward,movethetractioncontrol
rearward(Figure7).
Important:Whenreversing,lookbehindyou
forobstructionsandkeepyourhandsonthe
referencebar.
g008130
Figure7
•Toturnright,rotatethetractioncontrolclockwise
(Figure8).
g008131
Figure8
•Toturnleft,rotatethetractioncontrol
counterclockwise(Figure9).
g008132
Figure9
•Tostopthemachine,releasethetractioncontrol
(Figure5).
Note:Thefartheryoumovethetractioncontrolin
anydirection,thefasterthemachinemovesinthat
direction.
10

LoaderArm/Attachment-TiltLever
•Totilttheattachmentforward,slowlymovethe
levertotheright(Figure10).
•Totilttheattachmentrearward,slowlymovethe
levertotheleft(Figure10).
•Tolowertheloaderarms,slowlymovethelever
forward(Figure10).
•Toraisetheloaderarms,slowlymovethelever
rearward(Figure10).
•Tolowertheloaderarmstoadetent(oat)
position,pushtheleverfullyforward(Figure10).
Note:Thisallowsattachmentssuchastheleveler
andthehydraulicbladetofollowthecontoursof
theground(i.e.,oat)whengrading.
g029293
Figure10
1.Detent(oat)position4.Tilttheattachment
rearward.
2.Lowertheloaderarms.5.Tilttheattachment
forward.
3.Raisetheloaderarms.
Bymovingthelevertoanintermediateposition(e.g.,
forwardandleft),youcanmovetheloaderarmsand
tilttheattachmentatthesametime.
Loader-ValveLock
Theloader-valvelocksecurestheloader
arm/attachment-tiltleversothatyoucannotpushit
forward.Thishelpstoensurethatnooneaccidentally
lowerstheloaderarmsduringmaintenance.Secure
theloadervalvewiththelock,inadditiontothe
cylinderlocks,anytimeyouneedtoshutoffthe
machinewiththeloaderarmsraised.RefertoUsing
theCylinderLock(page23).
Tosetthelock,liftuponitsothatitclearstheholein
thecontrolpanelandswingittotheleft,infrontof
theloader-armlever,pushingitdownintothelocked
position(Figure11).
g029981
Figure11
1.Loaderarm/attachment-tilt
lever
2.Loader-valvelock
Loader-Control-ReferenceBar
Theloader-control-referencebarhelpsstabilizeyour
handwhileoperatingtheloaderarm/attachment-tilt
lever(Figure3).
Auxiliary-HydraulicsLever
•Tooperateahydraulicattachmentintheforward
direction,rotatetheauxiliary-hydraulicslever
rearwardandpullitdowntothereferencebar
(Figure12,number1).
•Tooperateahydraulicattachmentinthereverse
direction,rotatetheauxiliary-hydraulicslever
rearward,thenmoveitleftintotheupperslot
(Figure12,number2).
Note:IfyoureleasetheleverwhileintheFORWARD
position,theleverautomaticallyreturnstothe
NEUTRALposition(Figure12,number3).Ifitisinthe
REVERSEposition,itremainsthereuntilyoupullitout
oftheslot.
g004179
Figure12
1.Forward-owhydraulics3.Neutral
2.Reverse-owhydraulics
HourMeter
Thehourmeterdisplaysthenumberofhoursof
operationthathavebeenloggedonthemachine.
11

Parking-BrakeLever
•Toengagetheparkingbrake,pushthelever
forwardandtotheleftandthenpullitrearward
(Figure13).
Note:Thetractionunitmayrollslightlybeforethe
brakesengageinthedrivesprocket.
•Toreleasethebrake,pushtheleverforwardand
thenright,intothenotch(Figure13).
g005552
Figure13
FuelGauge
Thisgaugemeasurestheamountoffuelinthefuel
tank(s).
Engine-OilPressureLight
Iftheengine-oilpressuregetstoolow,thislight
illuminatesandanaudiblealarmsounds.Ifthis
happens,shutofftheengineimmediatelyandcheck
theoillevel.Ifitislow,addoilandlookforpossible
leaks.
g004350
Figure14
1.Engine-oilpressurelight4.Battery-chargeindicator
light
2.Engine-coolant
temperaturelight
5.Glow-pluglight
3.Glow-plugswitch
Battery-ChargeIndicatorLight
Ifthebatterychargebecomestoolow,thislight
illuminatesandanaudiblealarmsounds.Ifthis
happens,shutofftheengineandchargeorreplace
thebattery.Checkthetensionofthealternatorbelt;
refertoyourengineowner’smanual.
Engine-CoolantTemperatureLight
Iftheenginecoolantgetstoohot,thislightilluminates
andanaudiblealarmsounds.Ifthishappens,shutoff
theengineandallowthetractionunittocool.Check
thecoolantlevelwhentheenginehasfullycooled.
Glow-PlugLight
Thislightilluminateswhiletheglowplugsarecharged
andwarmingtheengine.
Glow-PlugSwitch
Pressandholdthisswitchfor10secondstoactivate
theglowplugsbeforestartingtheengine.
12

Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Model22323
Width86cm(34inches)
Length180cm(71inches)
Height117cm(46inches)
Weight864kg(1,904lb)
Operatingcapacity(withstandard
bucket)
251kg(553lb)
Tippingcapacity(withstandardbucket)717kg(1,580lb)
Wheelbase79cm(31inches)
Dumpheight(withnarrowbucket)119cm(47inches)
Reach—fullyraised(withnarrowbucket)55cm(22inches)
Heighttohingepin(narrowbucketin
highestposition)
168cm(66inches)
Model22324
Width104cm(41inches)
Length180cm(71inches)
Height109cm(43inches)
Weight913kg(2,013lb)
Operatingcapacity(withstandard
bucket)
251kg(553lb)
Tippingcapacity(withstandardbucket)717kg(1,580lb)
Wheelbase79cm(31inches)
Dumpheight(withnarrowbucket)119cm(47inches)
Reach—fullyraised(withnarrowbucket)55cm(22inches)
Heighttohingepin(narrowbucketin
highestposition)
168cm(66inches)
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedT oro
distributororgotowww.T oro.comforalistofall
approvedattachmentsandaccessories.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineToro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
BeforeOperation
BeforeOperationSafety
GeneralSafety
•Neverallowchildrenoruntrainedpeopleto
operateorservicethemachine.Localregulations
mayrestricttheageorrequirecertiedtrainingof
theoperator.Theownerisresponsiblefortraining
alloperatorsandmechanics.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetydecals.
•Alwaysengagetheparkingbrake(ifequipped),
shutofftheengine,removethekey,waitforall
movingpartstostop,andallowthemachine
tocoolbeforeadjusting,servicing,cleaning,or
storingthemachine.
•Knowhowtostopthemachineandshutoffthe
enginequickly.
•Checkthattheoperator'spresencecontrols,safety
switches,andshieldsareattachedandfunctioning
properly.Donotoperatethemachineunlessthey
arefunctioningproperly.
•Locatethepinch-pointareasmarkedonthe
machineandattachments;keepyourhandsand
feetawayfromtheseareas.
•Beforeoperatingthemachinewithanattachment,
ensurethattheattachmentisproperlyinstalled
andthatitisagenuineToroattachment.Readall
theattachmentmanuals.
•Evaluatetheterraintodeterminewhataccessories
andattachmentsyouneedtoproperlyandsafely
performthejob.
•Havethepropertyorworkareamarkedforburied
linesandotherobjects,anddonotdiginmarked
areas;notethelocationofunmarkedobjectsand
structures,suchasundergroundstoragetanks,
wells,andsepticsystems.
•Inspecttheareawhereyouwillusetheequipment
andremovealldebris.
•Ensurethattheareaisclearofbystandersbefore
operatingthemachine.Stopthemachineif
anyoneentersthearea.
13

FuelSafety
•Useextremecarewhenhandlingfuel.Itis
ammableanditsvaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporllthefueltank
whiletheengineisrunningorhot.
•Donotaddordrainfuelinanenclosedspace.
•Donotstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheaterorotherappliance.
•Ifyouspillfuel,donotattempttostarttheengine;
avoidcreatinganysourceofignitionuntilthefuel
vaporshavedissipated.
•Donotllcontainersinsideavehicleoronatruck
ortrailerbedwithaplasticliner.Alwaysplace
containersontheground,awayfromyourvehicle
beforelling.
•Removetheequipmentfromthetruckortrailer
andrefuelitwhileitisontheground.Ifthisisnot
possible,thenrefuelfromaportablecontainer
ratherthanafuel-dispensernozzle.
•Keepthefuel-dispensernozzleincontactwith
therimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.Donotusea
nozzlelock-opendevice.
AddingFuel
RecommendedFuel
Useonlyclean,freshdieselfuelorbiodieselfuelswith
low(<500ppm)orultralow(<15ppm)sulfurcontent.
Theminimumcetaneratingshouldbe40.Purchase
fuelinquantitiesthatyoucanusewithin180daysto
ensurefuelfreshness.
Usesummer-gradedieselfuel(No.2-D)at
temperaturesabove-7°C(20°F)andwintergrade
(No.1-DorNo.1-D/2-Dblend)belowthat
temperature.Usingwinter-gradefuelatlower
temperaturesprovideslowerashpointandcoldow
characteristics,whicheasesstartingandreducesfuel
lterplugging.
Usingsummer-gradefuelabove-7°C(20°F)
contributestowardlongerfuelpumplifeandincreased
powercomparedtowinter-gradefuel.
Important:Donotusekeroseneorgasoline
insteadofdieselfuel.Failuretoobservethis
cautionwilldamagetheengine.
BiodieselReady
Thismachinecanalsouseabiodieselblendedfuel
ofuptoB20(20%biodiesel,80%petrodiesel).The
petrodieselportionshouldbeloworultralowsulfur.
Observethefollowingprecautions:
•Thebiodieselportionofthefuelmustmeet
specicationASTMD6751orEN14214.
•TheblendedfuelcompositionshouldmeetASTM
D975orEN590.
•Paintedsurfacesmaybedamagedbybiodiesel
blends.
•UseB5(biodieselcontentof5%)orlesserblends
incoldweather.
•Monitorseals,hoses,gasketsincontactwithfuel
astheymaydegradeovertime.
•Fuellterpluggingmayoccurforatimeafter
convertingtobiodieselblends.
•Contactyourdistributorformoreinformationon
biodiesel.
FillingtheFuelTank(s)
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifequipped),andlowerthe
loaderarms.
2.Shutofftheengine,removethekey,andallow
theenginetocool.
3.Cleanaroundthefuel-tankcapandremoveit
(Figure15).
g004231
Figure15
1.Fuel-tankcap
14

4.Fillthetanktoabout2.5cm(1inch)belowthe
topofthetank,notthellerneck,withfuel.
Important:Thisspaceinthetankallows
fueltoexpand.Donotllthefueltank
completelyfull.
5.Installthefuel-tankcapsecurely,turningituntil
itclicks.
6.Wipeupanyspilledfuel.
PerformingDaily
Maintenance
Beforestartingthemachineeachday,performthe
EachUse/DailyprocedureslistedintheMaintenance
(page22).
Important:Checkthehydraulic-uidlevel
andbleedthefuelsystembeforestartingthe
engineforthersttime;refertoCheckingthe
Hydraulic-FluidLevel(page43)andBleedingthe
FuelSystem(page30).
DuringOperation
DuringOperationSafety
GeneralSafety
•Donotcarryaloadwiththearmsraised.Always
carryloadsclosetotheground.
•Donotexceedtheratedoperatingcapacity,asthe
machinemaybecomeunstable,whichmayresult
inlossofcontrol.
•UseonlyToro-approvedattachmentsand
accessories.Attachmentscanchangethestability
andtheoperatingcharacteristicsofthemachine.
•Formachineswithaplatform:
–Lowertheloaderarmsbeforesteppingoffthe
platform.
–Donottrytostabilizethemachinebyputting
yourfootontheground.Ifyoulosecontrolof
themachine,stepofftheplatformandaway
fromthemachine.
–Donotplaceyourfeetundertheplatform.
–Donotmovethemachineunlessyouare
standingwithbothfeetontheplatformandyour
handsareholdingontothereferencebars.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Lookbehindanddownbeforebackingupto
ensurethatthepathisclear.
•Neverjerkthecontrols;useasteadymotion.
•Theowner/usercanpreventandisresponsible
foraccidentsthatmaycausepersonalinjuryor
propertydamage.
•Wearappropriateclothingincludinggloves,eye
protection,longpants,substantialslip-resistant
footwear,andhearingprotection.Tiebacklong
hairanddonotwearlooseclothingorloose
jewelry.
•Donotoperatethemachinewhenyouaretired,ill,
orundertheinuenceofalcoholordrugs.
•Nevercarrypassengersandkeeppetsand
bystandersawayfromthemachine.
•Operatethemachineonlyingoodlight,keeping
awayfromholesandhiddenhazards.
•Ensurethatallthedrivesareinneutralandengage
theparkingbrake(ifequipped)beforestartingthe
engine.Starttheengineonlyfromtheoperator's
position.
•Usecarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayobscurevision.
•Slowdownandusecautionwhenmakingturns
andcrossingroadsandsidewalks.Watchfor
trafc.
•Stoptheattachmentwhenyouarenotworking.
•Stopthemachine,shutofftheengine,remove
thekey,andinspectthemachineifyoustrike
anobject.Makeanynecessaryrepairsbefore
resumingoperation.
•Neverrunanengineinanenclosedarea.
•Neverleavearunningmachineunattended.
•Beforeleavingtheoperatingposition,dothe
following:
–Parkthemachineonalevelsurface.
–Lowertheloaderarmsanddisengagethe
auxiliaryhydraulics.
–Engagetheparkingbrake(ifequipped).
–Shutofftheengineandremovethekey.
•Donotoperatethemachinewhenthereistherisk
oflightning.
•Operatethemachineonlyinareaswherethereis
sufcientclearanceforyoutosafelymaneuver.
Beawareofobstaclesincloseproximitytoyou.
Failuretomaintainadequatedistancefromtrees,
walls,andotherbarriersmayresultininjuryasthe
machinebacksupduringoperationifyouarenot
attentivetothesurroundings.
•Checkforoverheadclearance(i.e.,electrical
wires,branches,anddoorways)beforedriving
underanyobjectsanddonotcontactthem.
•Donotoverlltheattachmentandalwayskeepthe
loadlevelwhenraisingtheloaderarms.Itemsin
theattachmentcouldfallandcauseinjury.
15

SlopeSafety
•Operatethemachineupanddownslopeswith
theheavyendofthemachineuphill.Weight
distributionchangeswithattachments.Anempty
bucketmakestherearofthemachinetheheavy
end,andafullbucketmakesthefrontofthe
machinetheheavyend.Mostotherattachments
makethefrontofmachinetheheavyend.
•Raisingtheloaderarmsonaslopeaffectsthe
stabilityofthemachine.Keeptheloaderarmsin
theloweredpositionwhenonslopes.
•Slopesareamajorfactorrelatedtolossofcontrol
andtip-overaccidents,whichcanresultinsevere
injuryordeath.Operatingthemachineonany
slopeoruneventerrainrequiresextracaution.
•Establishyourownproceduresandrulesfor
operatingonslopes.Theseproceduresmust
includesurveyingthesitetodeterminewhich
slopesaresafeformachineoperation.Always
usecommonsenseandgoodjudgmentwhen
performingthissurvey.
•Slowdownanduseextracareonhillsides.Ground
conditionscanaffectthestabilityofthemachine.
•Avoidstartingorstoppingonaslope.Ifthe
machinelosestraction,proceedslowly,straight
downtheslope.
•Avoidturningonslopes.Ifyoumustturn,turn
slowlyandkeeptheheavyendofthemachine
uphill.
•Keepallmovementsonslopesslowandgradual.
Donotmakesuddenchangesinspeedor
direction.
•Ifyoufeeluneasyoperatingthemachineona
slope,donotdoit.
•Watchforholes,ruts,orbumps,asuneventerrain
couldoverturnthemachine.T allgrasscanhide
obstacles.
•Usecautionwhenoperatingonwetsurfaces.
Reducedtractioncouldcausesliding.
•Evaluatetheareatoensurethatthegroundis
stableenoughtosupportthemachine.
•Usecautionwhenoperatingthemachinenearthe
following:
–Drop-offs
–Ditches
–Embankments
–Bodiesofwater
Themachinecouldsuddenlyrolloverifatrack
goesovertheedgeortheedgecavesin.Maintain
asafedistancebetweenthemachineandany
hazard.
•Donotremoveoraddattachmentsonaslope.
•Donotparkthemachineonahillsideorslope.
StartingtheEngine
1.Ensurethattheauxiliaryhydraulicsleverisin
theNEUTRALposition.
2.MovethethrottlelevermidwaybetweenSLOW
andFASTpositions.
3.Insertthekeyintothekeyswitchandturnitto
theRUNposition.
4.Presstheglow-plugswitchandholditfor10
seconds.
5.TurnthekeytotheSTARTposition.Whenthe
enginesstarts,releasethekey.
Important:Donotengagethestarterfor
morethan10secondsatatime.Iftheengine
failstostart,wait30secondsforthestarter
tocooldownbetweenattempts.Failureto
followtheseinstructionscouldburnoutthe
startermotor.
6.MovethethrottlelevertotheFASTposition.
Important:Runningtheengineathigh
speedswhenthehydraulicsystemiscold
(i.e.,whentheairtemperatureisator
belowfreezing)coulddamagethehydraulic
system.Whenstartingtheengineincold
conditions,allowittoruninthemiddle
throttlepositionfor2to5minutesbefore
movingthethrottletotheFASTposition.
Note:Ifoutdoortemperatureisbelowfreezing,
storethetractionunitinagaragetokeepit
warmerandtoaidinstarting.
DrivingtheMachine
Usethetractioncontroltomovethemachine.The
fartheryoumovethetractioncontrolinanydirection,
thefasterthemachinemovesinthatdirection.
Releasethetractioncontroltostopthemachine.
Thethrottlecontrolregulatestheenginespeedas
measuredinrpm(revolutionsperminute).Placethe
throttleleverintheFASTpositionforbestperformance.
Youcan,however,usethethrottlepositiontooperate
atslowerspeeds.
16

ShuttingOfftheEngine
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifequipped),andlowerthe
loaderarms.
2.Ensurethattheauxiliaryhydraulicsleverisin
theNEUTRALposition.
3.MovethethrottlelevertotheSLOWposition.
4.Iftheenginehasbeenworkinghardorishot,let
itidleforaminutebeforeturningthekeyswitch
totheOFFposition.
Note:Thishelpstocooltheenginebeforeyou
shutitoff.Inanemergency,youcanshutoff
theengineimmediately.
5.TurnthekeyswitchtotheOFFpositionand
removethekey.
CAUTION
Achildoruntrainedbystandercouldattempt
tooperatethetractionunitandbeinjured.
Removethekeyfromthekeyswitchwhen
leavingthetractionunit,evenifjustforafew
seconds.
UsingAttachments
InstallinganAttachment
Important:UseonlyToro-approvedattachments.
Attachmentscanchangethestabilityandthe
operatingcharacteristicsofthemachine.The
warrantyofthemachinemaybevoidedifyouuse
themachinewithunapprovedattachments.
Important:Beforeinstallingtheattachment,
ensurethatthemountplatesarefreeofanydirtor
debrisandthatthepinsrotatefreely.Ifthepins
donotrotatefreely,greasethem.
1.Positiontheattachmentonalevelsurfacewith
enoughspacebehindittoaccommodatethe
machine.
2.Starttheengine.
3.Tilttheattachmentmountplateforward.
4.Positionthemountplateintotheupperlipofthe
attachmentreceiverplate(Figure16).
g003710
Figure16
1.Mountplate2.Receiverplate
5.Raisetheloaderarmswhiletiltingbackthe
mountplateatthesametime.
Important:Raisetheattachmentenoughto
clearthegroundandtiltthemountplateall
thewayback.
6.Shutofftheengineandremovethekey.
7.Engagethequick-attachpins,ensuringthatthey
arefullyseatedinthemountplate(Figure17).
Important:Ifthepinsdonotrotatetothe
engagedposition,themountplateisnot
fullyalignedwiththeholesintheattachment
receiverplate.Checkthereceiverplateand
cleanitifnecessary.
17

g003711
Figure17
1.Quick-attachpins
(engagedposition)
3.Engagedposition
2.Disengagedposition
WARNING
Ifyoudonotfullyseatthequick-attach
pinsthroughtheattachmentmountplate,
theattachmentcouldfalloffthemachine,
crushingyouorbystanders.
Ensurethatthequick-attachpinsarefully
seatedintheattachmentmountplate.
ConnectingtheHydraulicHoses
WARNING
Hydraulicuidescapingunderpressurecan
penetrateskinandcauseinjury.Fluidinjected
intotheskinmustbesurgicallyremoved
withinafewhoursbyadoctorfamiliarwith
thisformofinjury;otherwise,gangrenemay
result.
•Ensurethatallhydraulic-uidhoses
andlinesareingoodconditionandall
hydraulicconnectionsandttingsaretight
beforeapplyingpressuretothehydraulic
system.
•Keepyourbodyandhandsawayfrom
pinholeleaksornozzlesthateject
high-pressurehydraulicuid.
•Usecardboardorpapertondhydraulic
leaks;neveruseyourhands.
CAUTION
Hydrauliccouplers,hydrauliclines/valves,
andhydraulicuidmaybehot.Ifyoucontact
hotcomponents,youmaybeburned.
•Weargloveswhenoperatingthehydraulic
couplers.
•Allowthemachinetocoolbeforetouching
hydrauliccomponents.
•Donottouchhydraulicuidspills.
Iftheattachmentrequireshydraulicsforoperation,
connectthehydraulichosesasfollows:
1.Shutofftheengineandremovethekey.
2.Movetheauxiliary-hydraulicsleverforward,
backward,andbacktotheNEUTRALpositionto
relievepressureatthehydrauliccouplers.
3.Removetheprotectivecoversfromthehydraulic
connectorsonthemachine.
4.Ensurethatallforeignmatteriscleanedfrom
thehydraulicconnectors.
5.Pushtheattachmentmaleconnectorintothe
femaleconnectoronthemachine.
Note:Whenyouconnecttheattachmentmale
connectorrst,yourelieveanypressurebuilt
upintheattachment.
6.Pushtheattachmentfemaleconnectorontothe
maleconnectoronthemachine.
7.Conrmthattheconnectionissecurebypulling
onthehoses.
18

RemovinganAttachment
1.Parkthemachineonalevelsurface.
2.Lowertheattachmenttotheground.
3.Shutofftheengineandremovethekey.
4.Disengagethequick-attachpinsbyturningthem
totheoutside.
5.Iftheattachmentuseshydraulics,movethe
auxiliary-hydraulicsleverforward,backward,
andbacktotheNEUTRALpositiontorelieve
pressureatthehydrauliccouplers.
6.Iftheattachmentuseshydraulics,slidethe
collarsbackonthehydrauliccouplersand
disconnectthem.
Important:Connecttheattachmenthoses
togethertopreventhydraulicsystem
contaminationduringstorage.
7.Installtheprotectivecoversontothehydraulic
couplersonthemachine.
8.Starttheengine,tiltthemountplateforward,and
backthemachineawayfromtheattachment.
AfterOperation
AfterOperationSafety
GeneralSafety
•Shutofftheengine,removethekey,waitforall
movementtostop,andallowthemachinetocool
beforeadjusting,cleaning,storing,orservicingit.
•Cleandebrisfromtheattachments,drives,
mufers,andenginetohelppreventres.Clean
upoilorfuelspills.
•Keepallpartsingoodworkingconditionandall
hardwaretightened.
•Donottouchpartsthatmaybehotfromoperation.
Allowthemtocoolbeforeattemptingtomaintain,
adjust,orservicethemachine.
•Usecarewhenloadingorunloadingthemachine
intoatrailerortruck.
MovingaNon-Functioning
Machine
Important:Donottoworpullthemachine
withoutrstopeningthetowvalves,oryouwill
damagethehydraulicsystem.
1.Shutofftheengineandremovethekey.
2.Opentherear-accesscover.
3.Usingawrench,turnthetowvalvesonthe
hydraulicpumpstwicecounter-clockwise(Figure
18).
g004181
Figure18
1.Lefttowvalve(righttrack)2.Righttowvalve(lefttrack)
4.Towthemachineasrequired.
5.Afterrepairingthemachine,closethetowvalves
beforeoperatingit.
HaulingtheMachine
Useaheavy-dutytrailerortrucktohaulthemachine.
Useafull-widthramp.Ensurethatthetrailerortruck
hasallthenecessarybrakes,lighting,andmarkingas
requiredbylaw.Pleasecarefullyreadallthesafety
instructions.Knowingthisinformationcouldhelp
youorbystandersavoidinjury.Refertoyourlocal
ordinancesfortrailerandtie-downrequirements.
WARNING
Drivingonthestreetorroadwaywithout
turnsignals,lights,reectivemarkings,ora
slow-moving-vehicleemblemisdangerous
andcanleadtoaccidentscausingpersonal
injury.
Donotdrivethemachineonapublicstreet
orroadway.
19

SelectingaTrailer
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath(Figure19).
•Useonlyfull-widthramps.
•Ensurethatthelengthoframpisatleast4
timesaslongastheheightofthetraileror
truckbedtotheground.Thisensuresthat
rampangledoesnotexceed15degreeson
atground.
g229507
Figure19
1.Full-widthramp(s)in
stowedposition
3.H=heightofthetraileror
truckbedtotheground
2.Rampisatleast4times
aslongastheheightof
thetrailerortruckbedto
theground
4.Trailer
LoadingtheMachine
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath.
•Useextremecautionwhenoperatinga
machineonaramp.
•Loadandunloadthemachinewiththe
heavyenduptheramp.
•Avoidsuddenaccelerationordeceleration
whiledrivingthemachineonarampas
thiscouldcausealossofcontrolora
tip-oversituation.
1.Ifusingatrailer,connectittothetowingvehicle
andconnectthesafetychains.
2.Ifapplicable,connectthetrailerbrakes.
3.Lowertheramp(s).
4.Lowertheloaderarms.
5.Loadthemachineontothetrailerwiththeheavy
enduptheramp,carryingloadslow(Figure20).
•Ifthemachinehasafullload-bearing
attachment(e.g.,bucket)ora
non-load-bearingattachment(e.g.,
trencher),drivethemachineforwardupthe
ramp.
•Ifthemachinehasanemptyload-bearing
attachmentornoattachment,backthe
machineuptheramp.
g317099
Figure20
1.Machinewithfull
attachmentor
non-load-bearing
attachment—drivethe
machineforwardupthe
ramp(s).
2.Machinewithemptyor
noattachment—backthe
machineuptheramp(s).
6.Lowertheloaderarmsallthewaydown.
7.Engagetheparkingbrake(ifequipped),shutoff
theengine,andremovethekey.
8.Usethemetaltie-downloopsonthemachine
tosecurelyfastenthemachinetothetraileror
truckwithstraps,chains,cable,orropes(Figure
21).Refertolocalregulationsfortie-down
requirements.
20
