Trianco Aztec User manual

1
Aztec Instant Water Heater
INSTALLATION AND OPERATION
INSTRUCTIONS
Please read these instructions carefully before installing
and operating this appliance
TO BE RETAINED BY HOUSEHOLDER

2
CONTENTS
Health and Safety 3
Pre-Install Notes 4
After Sales Service 4
Safety Notes 5
User Instructions 6
Fault Finding 6
Installation 7
Technical Details 8

3
HEALTH AND SAFETY
INFORMATION FOR THE USER, INSTALLER AND SERVICE ENGINEER
Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is a requirement to provide information
on substances hazardous to health (COSHH Regulations 1998).
TR Engineering takes every reasonable care to ensure that its products are designed and constructed to meet these safety
requirements when the products are properly installed and used. To fulfil the requirements, products are comprehensively tested
and examined before despatch.
When working on the appliance, it is the responsibility of the user or engineer to ensure that personal protective clothing or
equipment appropriate to parts that could be considered hazardous or harmful is worn.
This appliance may contain some of the items below:
Insulation and Seals
Glass rope, mineral wool, insulation pads, ceramic fibre and glass insulation.
When handling, avoid inhalation and contact with eyes. These may be harmful and cause irritation to the skin, eyes, nose or throat.
Use disposable gloves, facemasks and eye protection.
After handling, wash hands and other exposed areas. When disposing of materials, limit dust and the risk of inhalation by using
water spray. Ensure materials are securely wrapped.
Seek urgent medical attention if inhaled or ingested. Exposure to eyes and skin should be followed by immediate cleansing of the
affected areas and medical attention if necessary.
Glues, Sealants and Paints
The glues, sealants and paints used present no known hazards when the appliance is used in the manner for which it is intended.
Notes:
Electrical safety checks should be carried out by a competent person.
Installation Engineers Signature
Company Name (if applicable)
Company Address
Company Tel. No.
Please read these instructions fully before installing this appliance.
If in doubt seek expert advice
These instructions should be kept in a place close to the appliance for easy reference.

4
IMPORTANT PRE-INSTALLATION NOTES
Before installation, it is imperative that the following guidelines are heeded to ensure the trouble-free and efficient operation of
the boiler:
Siting
The water heater should not be installed in a shower compartment or bathroom.
When siting the boiler, consider the potential requirement for future access to the cold-water inlet. The supplied in line filter
should be cleaned either on an annual basis or when a reduction in water flow is noticed.
The cold supply should have an isolation valve close to the appliance.
Power Supply and Wiring
The power supply to the premises must meet the minimum requirements of the unit being installed, with special attention paid
to the supply current, cable size, and RCD recommendation. The supply voltage to the appliance must never drop below 207
Volts.
To keep the casing clean, switch ‘OFF’ the water heater at the electrical supply, and simply wipe with a damp cloth. DO NOT use
abrasive cleaning fluids as this may damage the stove enamel paintwork.
TR ENGINEERING LTD CUSTOMER AFTER SALES SERVICE INFORMATION
What to do in the event of an appliance fault or breakdown:
Step 1: Always contact your installer in the first instance, who must thoroughly check all his work PRIOR to contacting TR
Engineering LTD.
Step 2: If your appliance has developed an in-warranty fault your installer should contact TR Engineering LTD for assistance
from site.
We offer a Return-to-Base Warranty, please contact the service department for more details.
PLEASE NOTE: UNAUTHORISED INVOICES FOR ATTENDANCE AND REPAIR WORK CARRIED OUT ON THIS APPLIANCE BY ANY
THIRD PARTY WILL NOT BE ACCEPTED BY TR ENGINEERING LTD
SERVICE CENTRE AND TECHNICAL SUPPORT
Tel: [phone] Fax: [phone]
Hours of Business
Monday to Thursday 8.30am - 5pm
Friday 8.30am - 2.30pm

5
IMPORTANT SAFETY NOTES
INTRODUCTION
The Aztec Instant Water Heater is a wall mounted instantaneous electric water heater. Once the water heater is switched on it is
fully controlled by an automatic management system which monitors the safety and running functions. Designed to provide
instantaneous hot water. The water heater produces hot water by passing water over electric heating elements housed in an
insulated heat exchanger.
The boilers incorporate inverter constant temperature technology which automatically adjusts output to match demand.
Read these instructions before installing your boiler.
The electrical wiring must comply with the latest edition of the Electrical Wiring Regulations BS 7671.
1. Always switch OFF the electrical supply before working on the hot water system.
2. If any part of the water heater is modified, then the warranty will be invalidated.
3. This appliance must be earthed
We recommend that you keep these instructions in a place near your appliance for easy reference.
The Trianco Aztec Instant Water Heater has been designed to conform to
European Directive/Standards EN60335-1:2002 +A15:2011, EN60335-2-35:2002 inc Amd 1,
EN55014-1:2006 +A1:2009, EN55014-2:1997 +A2:2008.
THE PERSON(S) WHO INSTALLS THIS APPLIANCE, SERVICES OR CARRIES OUT ANY REMEDIAL WORK, I.E.
ELECTRICAL FAULT FINDING, MUST HAVE SUITABLE ENGINEERING QUALIFICATIONS.
WARNING: DO NOT SWITCH ON THIS APPLIANCE IF THERE IS ANY POSSIBILITY THAT THE WATER MAY BE
FROZEN.
THE INSTALLATION OF THIS APPLIANCE MUST MEET THE REQUIREMENTS OF THE CURRENT ISSUE FOR
ELECTRICAL INSTALLATIONS IEE WIRING.

6
INSTRUCTIONS
The Trianco Aztec Instant Water Heater has been designed and constructed to give years of trouble-free service and these
instructions are provided to assist you in obtaining the best performance with the least trouble and cost.
The water heater is fully automatic in operation and requires little attention other than the setting of the hot water
temperature.
Do not use the appliance if there is any possibility of the water supply being frozen.
Make sure the inlet valve is turned on before turning on the main power supply.
When the power supply is turned on the water heater will display the water temperature and sound an audible tone.
Once the heater detects flow the heater will heat to the set temperature.
It might be necessary to descale any out lets from time to time if a reduction in water flow is noticed.
Functions and Display
Press after the water inlet valve is turned on.
Use ▼ and ▲ to set the outlet water to the desired temperature.
FAULT FINDING
Problem Possible Cause Corrective Action
LED Displays E1 Over Temperature Protection Automatic reset
LED Displays E2 System current leakage value is
too high.
Contact your engineer
LED Displays E3 Water temperature sensor
failure
Contact your engineer
Water Too Hot A: Too high temperature set
B: Water flow to low
A: Set a lower temperature
B: Increase flow
Water Too Cold A: Low temperature set
B: Water flow too high
A: Set a higher temperature
B: Reduce water flow
Decreased outlet flow Inlet strainer clogged Clean inlet strainer
Do not attempt to repair the heater, contact Trianco for assistance.
The water heater does not require any regular maintenance however the water inlet has a built-in filter which should be cleaned
when a reduction in water flow is noticed.

7
INSTALLATION
INSTALLATION
Installation of the water heater must comply with the following British Standards and Regulations:
Current I.E.E. Regulations
Local water undertaking By-laws.
Health and Safety at Work Act
The installer should be aware of his responsibilities under the Act and provide where necessary, appropriate protection for
persons carrying out the installation. In the interests of safety, a competent engineer should install the boiler and all wiring must
be carried out in accordance with current IEE regulations.
IMPORTANT
ALL ELECTRICAL WORK MUST BE CARRIED OUT BY A QUALIFIED ELECTRICAL ENGINEER TO CURRENT IEE WIRING
REGULATIONS.
NOT TO BE INSTALLED IN A SHOWER COMPARTMENT OR BATHROOM.
DO NOT INSTALL IN AREAS WHERE THERE IS A RISK OF FREEZING.
It is advised the water heater is located as close to the outlet as possible to avoid long draw offs and heat loss.
The appliance must be permanently connected to the electrical supply through an isolating switch with a contact separation of
no less than 3mm in all poles.
Isolate electrical and water supply before installation.
The appliance must be earthed.
Wall Mounting
Attach the wall bracket to a suitable wall able to hold the weight of the water heater when filled
with water.
Be careful to avoid concealed electrical cables and water pipes.
Once the bracket is secure slide the water heater on to the bracket.
The water heater should be mounted horizontally with the inlet and outlet connections at the
bottom of the heater.
Pipe Work Connection
Before connecting the pipe work, it is important to flush the pipes to remove any debris and flux residue.
The inlet supply pipe work MUST incorporate an isolation valve and inline anti scale device.
It might be necessary to obtain the best performance from the heater to restrict the flow rate at the outlet or fit a flow control
valve on the inlet pipe to the heater.

8
TECHNICAL DETAILS
Power 8KW 12KW
Phase 1
Voltage 220V-240V ,50Hz/60Hz
Current(A) 36.4 54.6
Circuit Breaker Requirement(A) ≥40 ≥60
Minimum Cable Size 6m ㎡ 10m ㎡
Temperature Range 30℃-55℃
Water Pressure 0.02-0.6Mpa
Overheat Protection 60℃
Thermal cut-off 90℃
Pipe Connection G 1/2‘’
IP Rating IPX4
Safety level IPX25

9
TR ENGINEERING LTD
UNIT 7, NEWTON CHAMBERS WAY
THORNCLIFFE INDUSTRIAL ESTATE
CHAPELTOWN
SHEFFIELD
S35 2PH
Tel: [phone]
Fax: [phone]
www.trianco.co.uk
© TR Engineering Limited
