TW Audio ELLA6 Series Quick start guide
Rigging manual
ELLA6-series
Rigging manual ELLA6-series
2
Introduction
Thank you for choosing a high quality product TWAUDiO product - “MADEINGERMANY”.
ELLA is a ground-breaking, world first achievement for this size of enclosure. Combining the
slim form factor of a column with the flexibility of a line array, ELLA incorporates TWAUDiO’s
passive cardioid technology.
Behind the elegant design front panel, ELLA offers a highly engineered and specialised
waveguide.
The HF unit reproduces silky smooth and precise high frequencies up to 20kHz with mini-
mum distortion, even at very high sound pressure levels.
Should you loan your product to another party, it is your responsibility to inform that party
of the safety-related operating procedures and to present this rigging manual with the pro-
duct. If you require additional copies of this manual, you can obtain them free of charge from
TW AUDiO or download them from www.twaudio.de
Instructions in this user manual
Strictly adhere to the instructions contained in this operating manual that are marked as
follows:
This symbol in combination with the signal word “Caution” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to light or moderate injury.
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
CAUTION
WARNING
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation for persons with a pacemaker. Failure to comply with this safety instruction can lead
to serious injury or even death.
WARNING
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
WARNING
WARNING
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
Rigging manual ELLA6-series
3
This symbol in combination with the signal word “Note” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to product damage.
This symbol in combination with the signal word “Tip” identifies additional information or
notes that will simplify working with TWAUDiO products on the basis of practical experience.
NOTE
TIP
Notes on the products
Read manual
before use!
Before using all the rigging components, carefully read the rigging book and keep it with the
components.
General information
Rigging manual: Rm-ELLA6-series
Version 1.0 en, 06/2020
© by TW AUDiO 2020; all rights reserved.
All information contained in this rigging book was correct to the best of our knowledge at the
time of printing.
Quality warranties or assurance of suitability for a certain type of use based on the technical
specifications, dimensions and weights are not granted by TWAUDiO.
TW AUDiO also shall not assume liability for any secondary damage (property damage and/
or personal injury) nor for the failure to comply with this rigging manual!
TW AUDiO reserves the right to update this document based on recent developments.
TW AUDiO GmbH
Osterholzallee 140
71636 Ludwigsburg
Germany
Phone : + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
WWW: www.twaudio.de
Rigging manual ELLA6-series
4
Content
1. Safety | Intended use...................................................................................................... 6
2. System components .................................................................................................... 10
2.1 Rigging components ............................................................................................. 10
2.1.1 BPE6 Baseplate E6 ....................................................................................... 10
2.1.2 RPE6 Riggingplate E6 ................................................................................... 10
2.1.3 BMP150 Bumper 150 .................................................................................... 11
2.1.4 LA150 Loadadaptor 150 ............................................................................... 11
2.1.5 WAE6 Walladaptor E6 ................................................................................... 12
2.1.6 PME6 Polemount E6 ..................................................................................... 12
2.1.7 GPE6 Groundplate E6 ................................................................................... 13
2.1.8 BM40 Ballmount 40....................................................................................... 14
2.1.9 WHG Wall bracket large................................................................................. 14
2.1.10 DHST Doughty Halfcoupler Slimline............................................................. 14
2.1.11 HSA Pole mount adaptor............................................................................. 15
2.1.12 CaseE6 Case .............................................................................................. 15
2.2 Loudspeaker ......................................................................................................... 16
2.2.1 ELLA6 .............................................................................................................. 16
2.2.2 ELLA L18 .......................................................................................................... 16
2.2.3 VERA S32 ......................................................................................................... 17
3. Commissioning............................................................................................................. 18
3.1 Setup .................................................................................................................... 18
3.2 Wind load .............................................................................................................. 18
3.3 Underground ......................................................................................................... 19
3.4 Pitfalls.................................................................................................................... 19
3.5 Danger of tipping over ........................................................................................... 19
3.6 Rigging - general function...................................................................................... 20
3.6.1 Operating the front locking mechanism............................................................. 20
3.6.2 Operating the front rigging mechanism for ground stack operation ................... 21
3.6.3 Operating the front rigging mechanism for flying/suspended operation ............. 22
3.6.4 Actuation of the locking bolt in the rear rigging.................................................. 23
3.7 BPE6 - mounting holes.......................................................................................... 26
3.8 Down-tilt angles..................................................................................................... 26
3.9 BPE6 - bayonet mount .......................................................................................... 27
Rigging manual ELLA6-series
5
3.10 Ground stack mode............................................................................................. 28
3.10.1 Tripod / distance rod / design stand ............................................................... 28
a) BPE6 + HSA....................................................................................................... 29
b) BPE6 + PME6 .................................................................................................... 30
c) BPE6 + Design stand.......................................................................................... 31
3.10.2 Groundplate ................................................................................................... 32
a) BPE6 + GPE6..................................................................................................... 33
3.11 Placed wall mounting........................................................................................... 34
a) BPE6 + WAE6 .................................................................................................... 35
b) BPE6 + WHG + WAE6 ....................................................................................... 36
c) BM40 + WAE6 + BPE6....................................................................................... 37
3.12 RPE6 - mounting holes........................................................................................ 38
3.13 0°- axis ELLA6...................................................................................................... 38
3.14 RPE6 - bayonet mount ........................................................................................ 39
3.15 Rigging-mode with DHST and RSM10................................................................. 41
a) DHST + RPE6..................................................................................................... 42
b) RSM10 + RPE6 .................................................................................................. 43
3.16 Use LA150 Loadadaptor 150 in the flown system................................................ 44
3.17 Secondary safety component .............................................................................. 46
3.18 Rigging-mode with RPE6 and BMP150 and LA150............................................. 47
3.19 Hanged wall mounting......................................................................................... 49
a) RPE6 + WAE6 .................................................................................................... 50
b) RPE6 + WHG + WAE6 ....................................................................................... 51
c) RPE6 + BM40 + WAE6....................................................................................... 52
3.20 CaseE6 ............................................................................................................... 53
4. Transport and Storage.................................................................................................. 56
5. CE Conformity Declaration............................................................................................ 57
6. Disposal ....................................................................................................................... 57
Rigging manual ELLA6-series
6
Every rigging component has a certified payload / Safe Working Load (SWL). Do not exceed
this payload.
The respective maximum payload (SWL) can be found in the subchapters in chapter 2.1.
WARNING
1. Safety | Intended use
To avoid risks please observe the following safety instructions when using accessories.
The rigging components are developed for use in professional sound systems. The rigging
components may only be used by trained and qualified personnel.
Note the operating modes described in this operating manual. Other uses are not permis-
sible.
Damage caused by improper use is not covered by TW AUDiO.
This rigging manual describes how to use the rigging components correctly. Any other use
shall be deemed improper and may result in damage or even injury.
Modifications or alterations to individual parts of the rigging components are not permitted!
Danger to life!
WARNING
Before every operation, check the integrity of each rigging component(s) and ensure that all
parts are in perfect condition.
The scope of delivery includes specified components. Only use the recommended and cer-
tified components.
WARNING
The rigging components are designed both for indoor and outdoor use.
CAUTION
The rigging components may only be used by trained and qualified personnel. Personnel must
check the component(s) for suitability before each use.
WARNING
When visible damage to any part of the rigging components are detected, they must be
decommissioned immediately.
WARNING
Please keep all elements of the rigging components away from children! The small parts can
easily be swallowed and lead to suffocation!
WARNING
Rigging manual ELLA6-series
7
When moving (assembling, dismantling, maintaining) the rigging components, ensure sufficient
space to prevent collisions with other objects.
WARNING
Do not squeeze or twist the electrical cables of the loudspeakers during the installation of the
rigging components. The respective national electrotechnical rules and regulations are appli-
cable.
CAUTION
All screw connections should be checked each time the rigging components are installed.
Tighten all loose screws. If this is no longer possible, the screws must be replaced.
WARNING
Before mounting the rigging components check that walls, ceilings, tripods etc are capable
of carrying the payload of the components.
WARNING
Make sure that no water pipes, electrical lines or any other lines are behind the intended place
of mounting.
WARNING
Only use wall plugs and screws which are suitable for the intended mounting and structural
fabric. All screws must be set and tightened properly. Ensure that the fixing holes have the
correct depth and diameter. Always use all fixing holes.
WARNING
Every time you assemble and disassemble your system structures, ensure that you never
reach between the loudspeakers with your fingers, hands or other parts of the body.
There is a risk of crushing!
Always use the side recesses!
WARNING
Rigging manual ELLA6-series
8
Please adhere to the following safety instructions to avoid risks when operating loudspeakers.
The loudspeakers are developed for use in professional sound systems. The loudspeaker
may only be used by trained and qualified personnel.
Note the operating modes described in this operating manual. Other uses are not permis-
sible.
Damage caused by improper use is not covered under warranty by TW AUDiO.
Loudspeakers generate an electromagnetic field. Persons with pacemakers are not permit-
ted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields can
cause pacemakers to malfunction.
When working with heavy loads exceeding 20 kg (44 lbs.), use suitable aids (dollies, hoisting
slings, etc.). Multiple persons may be required depending on the situation.
Ensure that the units are in a stable position and are firmly attached. A falling loudspeaker can
result in serious personal injury and property damage.
When using and assembling TW AUDiO loudspeakers, only use materials specified by
TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the applicable
safety regulations.
WARNING
When setting up loudspeakers, ensure that they are not exposed to the following ambient
conditions:
• Direct sunlight
• Humidity
• Jolting
• Dust
Keep away from the immediate vicinity of loudspeakers that are operated at high sound pres-
sure levels. These loudspeaker systems are capable of endangering your health. Sound levels
beginning as low as approximately 90dBSPL can lead to long-term hearing impairment.
WARNING
Avoid:
• Feedback
• Distorted signals (clipping) and
• Peaks resulting from switching on devices, plugging in devices or unplugging devices during
operation.
Such signals can lead to loudspeaker overload and ultimately to loudspeaker failure.
WARNING
NOTE
NOTE
Rigging manual ELLA6-series
9
Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over-
loads may cause a fire and result in serious personal injury and property damage.
WARNING
Note that TW AUDiO does not provide a warranty for damage that can be attributed to this
type of overload and therefore cannot be held liable for any secondary damage.
A permanent magnetic field is present in the immediate vicinity of loudspeakers. Ensure that
objects which react sensitively to magnetic fields are not located in the immediate vicinity of
the loudspeaker. In particular, this applies to magnetic storage media, magnetic stripe cards
such as debit cards and CRT displays. A distance of approximately one meter is sufficient to
avoid damage.
Check loudspeakers and accessory parts regularly for visible wear. This is essential to ensure
continuing fault-free operation. Worn parts should be replaced immediately. Spare parts are
available from TWAUDiO.
NOTE
NOTE
Rigging manual ELLA6-series
10
2. System components
2.1 Rigging components
2.1.1 BPE6 Baseplate E6
Description
Baseplate for sta-
cking applications;
can be combined
with WAE6, GPE6,
PME6, or screwed
with M20 pole mount
flange (Subwoofer)
maximum payload
50 kg [110,2 lbs]
on tripod
75 kg [165,3 lbs]
on GPE6
Dimensions
(h x w x d)
196 x 253 x 72 mm
[77,2 x 99,6 x 28,4 in]
Weight 2,5 kg [5,5 lbs]
Surface powder-coated
Description
Riggingplate for
rigging applications;
can be combined
with BMP150, WAE6
oder BM40
maximum payload
150 kg [330,7 lbs]
This corresponds e.g.
24x ELLA6 or
8x ELLA L18
Dimensions
(h x w x d)
196 x 253 x 55 mm
[77,2 x 99,6 x 21,7 in]
Weight 2,4 kg [5,3 in]
Surface powder-coated
2.1.2 RPE6 Riggingplate E6
Rigging manual ELLA6-series
11
2.1.3 BMP150 Bumper 150
Description
Bumper for rigging
applications; inclu-
ded quick change
adaptor;
included 1x LA150;
RPE6 required
maximum payload
150 kg [330,7 lbs]
This corresponds
e.g. 24x ELLA6 or
8x ELLA L18
Dimensions
(h x w x d)
584 x 80 x 48 mm
[229,9 x 31,5 x 18,9 in]
Weight 4,2 kg [9,3 lbs]
Surface powder-coated
2.1.4 LA150 Loadadaptor 150
Description
Loadadaptor for BE6
with shackle and 2x
quick-lock pin
Weight 0,4 kg [5,5 lbs]
Surface powder-coated
Rigging manual ELLA6-series
12
Description
tripod adaptor with
quick change adap-
tor; BPE6 required
maximum payload 50 kg [110,2 in]
Dimensions
(h x w x d)
150 x 130 x 123 mm
[59,1 x 51,2 x 48,4 in]
Weight 1,35 kg [2,98 in]
Surface powder-coated
Description
Angle for wall
mounting; quick
change adaptor; can
be combined with
BPE6, RPE6, BM40
or WHG; alterna-
tively direct wall
screwed
maximum payload
50 kg [110,2 in]
This corresponds e.g.
8x ELLA6
Dimensions
(h x w x d)
226 x 300 x 100 mm
[88,98 x 118,1 x
39,4 in]
Weight 2,1 kg [4,6 in]
Surface powder-coated
2.1.5 WAE6 Walladaptor E6
2.1.6 PME6 Polemount E6
Rigging manual ELLA6-series
13
Description
Groundplate for
ground stacking;
quick change ad-
aptor or screwed
M12; BPE6 requi-
red, Rubber feet like
VERA S32
Dimensions
(h x w x d)
800 x 600 x 28 mm
[315 x 236,2 x 11 in]
Weight 7,3 kg [16,1 in]
Surface powder-coated
2.1.7 GPE6 Groundplate E6
Rigging manual ELLA6-series
14
2.1.8 BM40 Ballmount 40
Description
fixable ball joint
for wall and cei-
ling mounting; can
be combined with
WAE6 + BPE6/RPE6
(wall mounting or
RPE6 (ceiling moun-
ting)
maximum payload 40 kg [88,2 lbs]
Dimensions (h x ø)
95 x ø50 mm
[37,4 x ø19,7 in]
+ plate
Weight 0,4 kg [0,9 lbs]
Surface Eloxiert, Verzinkt
2.1.9 WHG Wall bracket large
Description WAE6 required
maximum payload 25 kg [55,1 lbs]
Tilt 0° to 30°
Swivel range 90°
Dimensions
(h x w x d)
220 x 120 x 110 mm
[8,7 x 4,7 x 4,3 in]
Weight 1,3 kg [2,9 lbs]
Surface powder-coated
2.1.10 DHST Doughty Halfcoupler Slimline
Description
Element for truss
assembly; RPE6
required
maximum payload 750 kg [1653,5 lbs]
Tube ø 48-51 mm
[1,9-2,0 in]
Dimensions (B) 30 mm [51,2 in]
Attachment M12
Weight 0,5 kg [1,1 lbs]
Rigging manual ELLA6-series
15
2.1.12 CaseE6 Case
Description
Case for 4x 3 ELLA6
or 4x ELLA L18,
2x BMP150,
2x BPE6, 2x RPE6,
Patch cable, LA150;
tools, Small material
Dimensions
(h x w x d)
800 x 600 x 600 mm
[31,5 x 23,6 x 23,6 in]
Weight 39 kg [85,98 lbs]
2.1.11 HSA Pole mount adaptor
Description Adaptor for moun-
ting on tripot
maximum payload 50 kg [110,2 lbs]
Dimensions (H x ø) 100 x 36 mm
[3,9 x 1,4 in]
Thread M12x15
Weight 0,4 kg [0,9 lbs]
Rigging manual ELLA6-series
16
2.2 Loudspeaker
2.2.1 ELLA6
Drivers 1x 6,5“ LF / 5x 1“ HF
Frequency respon-
se 90 - 20000 Hz
Power handling
(program/Peak) 400 / 800W
Impedance 24 Ω
Coverage (h x v) 120° x 10°
Max. SPL / 1m 129 dB
Dimensions
(h x w x d)
200 x 200 x 260 mm
[7,9 x 7,9 x 10,2 in]
Weight 5,5kg [12 lbs]
Surface Warnex textured paint
Drivers 3x 6,5“ LF
Frequency respon-
se 90 - 1000 Hz
Power handling
(program/Peak) 1200 / 2400W
Impedance 8 Ω
Max. SPL / 1m 128 dB
Dimensions
(h x w x d)
604 x 200 x 260 mm
[23,8 x 7,9 x 10,2 in]
Weight 14,2kg [31,3 lbs]
Surface Warnex textured paint
Please note that the ELLA L18 has the same height as three mounted ELLA6. It is therefore
possible to substitute an ELLA L18 in place of three ELLA6s.
NOTE
2.2.2 ELLA L18
Rigging manual ELLA6-series
17
2.2.3 VERA S32
Drivers 1x 18“ LF front /
1x 14“ LF rear
Frequency respon-
se 38 - 120 Hz
Power handling
(program/Peak)
2400 / 4800 W 18“ /
1400 / 2800 W 14“
Impedance 8 Ω 18“ /
8 Ω 14“
Max. SPL / 1m 134 dB
Dimensions
(h x w x d)
506 x 600 x 800 mm
[19,9 x 23,6 x 31,5 in]
Weight 54,2kg [119,5 lbs]
Surface Polyurea-coated
Rigging manual ELLA6-series
18
3. Commissioning
3.1 Setup
The rigging components BPE6, GPE6 and PME6 are only designed for standing operation.
The rigging components WAE6, BM40 and WHG are designed for wall mounting.
The rigging components RPE6, BMP150 and LA150 are designed for hanging operation.
There are various accessories for all rigging components at TWAUDiO to securely attach them.
TW AUDiO recommends using only the accessories specified by TWAUDiO for securing and
mounting loudspeakers.
NOTE
Please note that setting up all rigging components always requires two persons!
WARNING
Make sure that all system structures are located on a firm, level surface and that the surface
can bear the total weight!
WARNING
3.2 Wind load
Before setting up the system outdoors, consider unforeseeable wind conditions at the opera-
tion site!
Disassemble your system immediately when wind forces exceed 8 bft (34 to 40 kn – 38.5 to
46 mph) and also secure them!
Make sure that there are no persons in the immediate vicinity of the system structure!
WARNING
Make sure that your system structures are not operated over the audience at wind forces in
excess of 6 bft (22 to 27 kn – 24.2 to 30.45 mph!).
Make sure that there are no persons in the immediate vicinity of the system structure!
WARNING
Rigging manual ELLA6-series
19
3.3 Underground
When setting up a system on uneven surfaces, such as gravel or grass, always put a pressu-
re-resistant surface under all four spindle feet! Make sure that all four spindle feet rest com-
pletely on the pressure-resistant shims and that the surface can withstand the total weight.
Note that depending on the system design, either the front or rear spindle feet may be able
to carry more weight.
WARNING
3.4 Pitfalls
Make sure that no one can trip over your system structures, or over individual components!
This is especially true for all pressure-resistant shims, tripod legs, guy ropes and spindle feet!
WARNING
With every system setup, make sure that the centre of gravity of the system never extends
beyond the outer limits of the base area!
Secure every system setup against falling over!
WARNING
3.5 Danger of tipping over
Any influences on your system setup, such as leaning against objects (or people) and flying
objects around, be refrained from!
WARNING
The M20 pole mount flange, e.g. at VERA S32 loudspeaker is not designed for side forces
once mounted – do not apply any pressure from the sides.
Make sure that no external forces are applied to the system structures. No objects or persons
should lean against the structures, no objects should be thrown against them. If pressure is
applied on the flange the loudspeaker may be damaged or falling over.
WARNING
Rigging manual ELLA6-series
20
3.6 Rigging - general function
The front rigging mechanism is opened (unlocked/undone) and closed (locked/secured)
using push buttons on the side (see figure 3.6.1).
To open the front rigging mechanism, press the push button on both sides at the same time
and slide the slider locks upwards.
Note that a bright orange dot is visible when the front rigging is OPEN.
To close the front rigging, move the slider down until the push buttons snap outwards. Check
they have locked correctly in place.
WARNING
Figure 3.6.1 - Position front rigging
When assembling all system setups, make sure that all front rigging sliders are in the CLOSED
position after hooking together the ELLA6 speakers!
NOTE
open (orange) closed
3.6.1 Operating the front locking mechanism
