SSV Works WP3-DF04 User manual

SSVWORKS , 201 N. Rice Ave Unit A, Oxnard , CA 93030
www.SSVworks . com I Phone : 818 - 991 - 1778 I Fax :[phone]
WARRANTY INFORMATION:
All SSV Works enclosures are covered by alimited lifetime warranty against defects in
material or workmanship . All SSV Works Electronics are covered by alimited 1 year warranty
against defects in material or workmanship . All SSV Works Speakers are covered by a
limited 1 year warranty against defects in material or workmanship . Labor for replacement of
defective components is not covered . Contact SSV Works forfurther warranty information.
WP3-DF04
Can-Am Defender
Overhead 4-Speaker Stereo System
A
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
TOOLS FOR INSTALLATION
- 10mm Deep Socket & Wrench - Ratchet
- T27 . T30 , T40 Tone - Wire Cutters & Crimpers
PARTS LIST IMAGES
4. MG Nut(6)
1. WP3-DF04 Stereo
To
5. MG x 1.0 Screws and
Washer(14)
a?
6. 10 " Zip Ties (5)
A. Fasten the driver and passenger brackets to the driver and passenger
side of the unit with (4) MG screws & washers using a T30 Tone per side .
Passenger side shown.
Always disconnect the battery when installing electronic devices .
2. Mounting Brackets 3. Fuse Holder & Ring Terminal
B. If the Defender is equipped with the factory plastic roof, it must be
removed prior to installing the overhead stereo. For installation
with the plastic roof follow steps C to N. Follow steps C to G and
then K to Nif not installing with a roof .

C. Guide the harness over the top of the enclosure and out the driver
side .
E. From the top of ROP visor , place (3) MG T30 tonc screws per side
through the visor and stereo mounting brackets.
G. Using a T30 tonc driver and 10mm socket , tighten all (6) MG screws
to secure the stereo to the ROP visor. If you are not installinga roof ,
skip to Step K.
llll:IRKS
• WP3-DF04
E. To safely install the overhead ,it is necessary to have a seco~d
person to help liftthe enclosure into place.
With the roof removed ,lift the overhead stereo into place .
F. From the inside the cab fasten a MG washer and nut onto each MG
screw.
H. To reinstall the roof, remove all (8) MG screws with a T30 tonc to
lower the stereo from the mounting brackets.

I. With the stereo removed, reinstall the roof.
K. Guide the harness out the driver side . Fasten the stereo back to the
mounting brackets with the (8) MG T30 Torx screws .
M. Cut the power/ground wire to your desired length. Strip the end of
the wire about¼". Crimp the fuse holder onto the power wire and ring
terminal to the ground wire .
© 2019 SSV Works , Oxnard , CA 93030 WP3 - DF04 Rev. A 8-26- 19
II
J. Guide the harness out the driver side. Lift the enclosure back into
place and fasten the stereo back to the mounting brackets with the
(8) MG t30 Torx screws.
L. Route the power/ground and ext. amp trigger output into the dash cavity.
Once in the dash cavity , pull the power/ground and ext. amp trigger output
across the dash cavity along the factory harnesses to the bus bar.
N. Pull guard away from bus bar , remove the 10mm nut on the 2nd position
terminal for 12v constant power or the 1st position for accessory power
and attach the red POWER wire. Refasten on the nut. Remove the 10mm
nut on the 3rd position terminal and attach the black GROUND wire . Re-
fasten on the nut.
WP3-DF04 J
IIIDRKS
•

RADIO FUNCTIONS
Selecting FM/ AM Band: Press MODE until the FM or AM band shows on the display.
Automatic Station Search: Press ::::=:::: or ¥ to start automatic station search. The search
stops when astation is found.
Manual Station Search: Press and hold ::::=:::: or ¥ until M- SEEK. Press the ::::=:::: or ¥
brieflyto change the frequency until the desired frequency is set. Change to Automatic
search (A - SEEK) mode afterastation is found.
BLUETOOTH AUDIO STREAMING
1. Open the Bluetooth setup program on the mobile device and activate the Bluetooth feature
2. The device will show up as "SSV". Select this device and enter passkey: 0000
3. After successfully pairing, a Bluetooth logo will appear on the phone menu screen and
show "CONNECT" "BT MUSIC" on the device LCD display.
Stop Playback: Press ► II briefly to pause music. Press ► II button again to continue playback.
Skip Track: Press ::::=:::: or ¥ to play previous/ next song.
CONNECTING AN EXTERNAL AUDIO DEVICE (OPTIONAL)
- Press MODE until AUX shows on the display.
~-
WARRANTY INFORMATION:
(@\
~
Add 3.5mm AUX-in
and USB Charging with
SSV Works 3PUSB35A
(sold separately)
All SSV Works enclosures are covered by alimited lifetime warranty against defects in material or workmanship . All
SSV Works Electronics are covered by alimited 1 year warranty against defects in material or workmanship . Labor for
replacement of defective components is not covered. All SSV Works Speakers are covered by alimited 1 year warranty
against defects in material or workmanship. Contact SSV Works for further warranty information.
!/!i!/!iV.--i.=_ Corporate: SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
llll::JRK!!!!!ill§IE Web: www.SSVworks.com I Phone: [phone] I Fax: [phone]
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,lnc. and any use of such
marks by SSV Works is under license. © 2016 SSVWorks, Oxnard, CA 93030 MRB3 Rev .B 3-22-16
~lf-4.-2
User Guide
ssv
MRB3
lllt:IRK!!!i
@ &
VOL
@)
TRACK
@
9~8
&oa~
~
MRB3
Bluetooth Media Controller
SAFETY INFORMATION
Do not attemptto disassemble or repair the MRB3 yourself. Please call SSV Works for
technical assistance or repair information. Changes or modifications to the MRB3 not
authorized by SSV Works will void the warranty.
A SSV Works recommends disconnecting the negative battery terminal before
.. beginning any installation.

AMPLIFIER WIRING DIAGRAM
12v + Yell o w-@Black
-Power
connector
Yellow
Black
Re ar left (+) Gr ee n
12A
a
Rear left ( -) Green/Black
Rear left(+) Gr een Rear right (- ) Purple / Black ~ Rear right( -) Purple / Bla ck
Re ar r ight( +) Purple Rear speaker Rear right (+) Purple
Rear left (-) Gree n/ Black
•
Front left( -) White / Black
Front left(+) White F ont right( -) Grey / Black ~ Front right (+) Gre y k
Front right(+) Grey r Front speaker Front right (-) Grey / Blac
Front left( +) White
Front left (- ) White/Black
USB 1Ac harg e input []]
does not read
USBdata
-
Si gnal ground~Righ t ( Red )
( Black )
AMP turn on Left (White )
( Blu e)
~-
C)
@J Ill
©-
,____ _ __mt__ _jj
Signal ground ( Black )
Right (Red )
Left ( White ) ._.
0
0
USB charge
Line out/Ext. amp_!ri_gger
Wire control p_anel
Antenna
Line in
0
0
BUTTON LOCATIONS AND FUNCTIONS
•
-~~-v --=1~------"'" 1
@r~I I©,@
\=J~~ ~ ~
• • • •
GENERAL OPERATIONS
1. Play/Pause
Power On/Off
Mute
2. Volume Up/Down
3. Mode
4. Track Forward/Back
Station Forward/Back
Menu Settings Up/Down
5. LCD Display
Power On/Off: Press ► II to power on. Press and hold ► II to power off.
Volume: Press the VOL(+) or(·) button to increase or decrease the volume.
Mute On/Off: Press ► II briefly to mute the sound. Press ► II again to un-mute the sound.
Mode Sources: Press the MODE button to switch between AUX, FM, AM, Bluetooth (BT MUSIC).
Mode Settings (Bass/Treble/Balance/Fader/EQ/Loudness): Press the MODE button for
2 seconds and then press the ~ button until the function you want is shown on the display.
Press VOL(+)(·) to change the settings of the menu item displayed.
Bass (BAS)/Treble (TRE): Press the VOL(+) or(·) button to adjust Bass & Treble.
Balance (BAL): Press VOL(+) or(·) to adjust balance (sound distribution between the right and
left speakers).
Fader (FAD): Press VOL(+)or(·) to adjust sound distribution between the front and rear speakers.
Equalizer (EQ): Press VOL(+) or (·) to select one of the EQ options: OFF, FLAT, CLASS, POP,
ROCK, JAZZ, METAL. The equalizer will be disabled if EQ OFF is set. The equalizer setting is shown
at the bottom of the display.
Loudness (LOUD): Press VOL(+) or(·) (LOUD ON) or to disable the function (LOUD OFF). When
the loudness function is on, LOUD is shown on the right of the display.
Select USA/Europe Area Frequencies (AREA): Press VOL(+} or(·) to select Radio Region
(USA/ Europe Frequencies).
