Two-Rock CLASSIC REVERB SIGNATURE User manual

OWNER'S MANUAL

Dear Customer,
Thank you for your purchase of a !
As a discerning guitarist, you know the road to great tone begins with
great components.
Our Classic Design, carefully selected parts and hand-built approach
combine to make an extremely versatile instrument.
Please take the time to read this manual. We hope it will answer any
questions that you may have.
We extend a warm welcome to you as a member of a select group of
musicians who have chosen a amplifier.
Important Safety Instructions
1. Read these instructions
2. Keep these instructions
3. Heed all warnings
4. Follow all instructions
5. Do not use this apparatus near water
6. Clean only with dry cloth
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions
8. Do not install near any heat sources such as radiators, heat registers, plugs, and the point
where they exit from the apparatus
9. Protect the power cord from being walked on or pinched particularly at plugs and the point
where they exit from the apparatus
10. Only use attachments/accessories specified by the manufacturer
11. Unplug this apparatus during lightning storms or when unused for long periods of time
12. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped
13. CAUTION: To disconnect the unit completely from the MAINS, unplug the unit. Turning the power
switch off does not disconnect the unit completely from the MAINS.

Front Panel Functions
1. Input Jack- High impedance input to the amplifier. Plug in your instrument here.
2. FET Gain- The FET (Field Effect Transistor) feature consists of a single stage high impedance
preamp/buffer. This feature can be switched in and out via the front panel switch (“ON” is “up”
position) or footswitch. This mode offers an additional buffered gain stage, and can be used to
buffer the input from high output pickups or increase the signal of low output pickups. The FET
GAIN control controls the amount of signal fed to the following stage(s) {gain control}
3. FET Switch- Enables or defeats the FET feature. (“ON” is “up” position)
4. Treble Control- Adjusts the high frequency response. In the full counter-clockwise position,
high frequencies are bypassed to ground. In the full clockwise position, high frequencies are
allowed to pass to the next gain stage.
5. Bright Switch- Boosts the high frequency response. This is most effective when the input gain
is set at 12 o’clock or lower. The effect is less dramatic as the input gain control is adjusted past
the 12 o’clock position.
6. Middle Control- Adjusts the mid-range response. In the full counter-clockwise position, the
tone will be somewhat “scooped” of mid-range response, emphasizing the highs and lows. In the
full clockwise position, mid-range frequencies are allowed to pass to the next gain stage.
7. Mid Switch- Boosts the mid range frequency response.
8. Bass Control- Adjusts the bass response. In the full counter-clockwise position, low
frequencies are cut. In addition, the response of the treble and mid-range controls is greatly
reduced. In the full clockwise position, low frequencies are allowed to pass to the next gain stage.
9. Deep Switch- Boosts the low and low-mid frequencies. This is a low frequency contour switch,
changing the low and low-mid response.
10. Gain- Adjusts the overall gain of the amplifier. Start with this control in the 12 o’clock
position.
11. Master- Adjusts the output level of the amplifier.

12. EQ1/EQ2- This switch allows you to choose between 2 completely different equalization
settings. EQ1 is a lower gain setting, with extended midrange and bass available when used in
conjunction with the middle and bass controls as well as the deep switch. This setting is suitable
for any style requiring a pure clean tone with a nice round bottom and plenty of headroom.
EQ2 is a higher gain setting. This setting is suitable for any style requiring a clean to slightly
distorted tone in clean mode, and more gain in the lead mode.
13. Reverb Send- The reverb drive control determines the amount of signal applied to the reverb
tank. Low settings will create a very open, small room reverb effect with a short decay time.
Advancing the control clockwise increases the signal applied to the driver, and a very saturated
effect with a sharp attack and a long decay can be obtained.
14. Reverb Return- The reverb return control mixes the reverb effect signal with the dry signal. At
full counterclockwise rotation, the reverb effect is defeated. Using the return control in conjunction
with the reverb drive control, a wide range of natural reverb effects can be produced.
15. Gain Structure- The 3 position gain structure switch changes the sensitivity and overall feel of
the preamp. In the down position, the amp feels similar to a vintage blackface, the middle position
is much like the Two-Rock Matt Schofield Signature front end with a hotter input stage, and the full
up position is our traditional Two-Rock frontend.
16. Bypass Switch- This switch bypasses the tone controls, increasing both level and mid-range
response. To enable footswitch control of this function, switch must be in the down position.
17. Contour Control- The contour control is an active wide band sweep. In the 12 o’clock
position, the amps’ frequency response is flat. Counterclockwise rotation reduces high end
response and increases low frequencies. Counterclockwise rotation decreases low end and
increases the high frequency response. This control is very useful for maintaining preamp tone
control settings, while allowing a global adjustment to compensate for differences in room
acoustics, speaker cabinets, or bright to dark guitars (PRS Humbucker to Strat, for example). This
control also actively reduces the articulation available, allowing a softer setting, or extremely open
and revealing, depending on your individual style and requirements.
18. Stand-by Switch- Should be in the “down” or “stand-by” position when you apply power to the
unit. After a few seconds, place the switch in the “up” position to use the amplifier. You may leave
the unit “powered up” and place this switch in the “stand-by” position to mute the output.
19. Indicator Lamp- This lamp will illuminate when the power switch is in the “up” position,
indicating the unit is receiving A/C power.
NOTE: All switches are ON in the “up” position (except reverb switch, see description)

Rear Panel Functions
1. A/C Input- Connects the amplifier to A/C power via the power cord supplied. Unless otherwise
specified, your amplifier is designed to operate on 120 volts A/C, 60 cycles, ONLY.
2. Fuse- See Fuse Chart
3. Power Switch-Turns power on.
5. Power Selector - On 50 Watt Models, the HIGH power mode is fixed-bias and the LOW power
is cathode biased. While the Low setting may sound louder, you’ll notice a significant headroom
decrease. On 100 watt (4x6L6) models, the HIGH power mode is100 watts, the LOW power mode
is 50 watts. With the 100 watt Classic Reverb Signature’s output transformer, when switching
from 100 to 50 watts, the transformer will compensate for impedance differences so you will not
have to change impedances.
6. Speaker Output Jacks-There are 3 speaker output jacks; 4, 8, and 16 ohms. NEVER
OPERATE YOUR AMPLIFIER WITHOUT A PROPER SPEAKER LOAD CONNECTED. Be sure
to match the impedance of your cabinet with the impedance (output) of the amplifier.
7. Footswitch Jack-The footswitch connects here. The FET function, tone bypass, and Reverb
defeat functions can be activated via the footswitch. The respective front panel switches (FET and
bypass) must be in the “off,” or down position, to enable the footswitch functions.
8. Effects Send-Use this jack to send the amplifiers signal to outboard effects.
9. Effects Return-Use this jack to connect the output of your effects to the amplifier.
10. S/N- Your serial number is located here. We strongly suggest that you record this number and
have it handy in case you need service, or in the event that your amp is lost, stolen, or damaged.
Fuse Chart
All Fuses are 3AG Type 250 Volt, SLO-BLO
Export 100 Volt Domestic Fuses: Export 220, 230, 240
Fuses:
3.5 - 100 Watt 4x6L6 3.25 - 100 Watt 4x6L6 1.6 - 100 Watt 4x6L6
2.8 - 50 Watt 2x6L6 2.5 -50 Watt 2x6L6 1.25 - 50 Watt 2x6L6

FOOTSWITCH
FET -Blue LED
BYPASS -Red LED
REVERB DEFEAT -Green LED
TUBE COMPLIMENT
V1- Preamp 12AX7
V2- Reverb send, reverb return 12AX7
V3- Reverb drive 12AT7
V4- Reverb /clean mix 12AX7
V5- Phase inverter 12AX7
V6, V7- 6L6WGC, Output
V8, V9- 6L6WGC, Output (100 Watt)
Each fine production tube is tested and matched to our exacting specifications. External bias
adjustment and test points are located on the chassis near the output tube sockets. A digital
voltmeter and small screwdriver are required for bias adjustment.
BIAS ADJUSTMENTS:
1. Power up unit and connect proper speaker load.
2. Set master volumes and effects return controls to zero.
3. DO NOT apply any signal to the input during the biasing procedure!
4. Take unit off standby and allow a few seconds for the circuit to stabilize.
5. Set voltmeter to Millivolt scale (or lowest volt scale 60 millivolts=.060 volts.)
6. With meter grounded to chassis and + probe at test point, measure voltage. A reading of
0.055 to 0.060 volts is normal for 50 Watt amplifiers with (2) 6L6’s. A reading of 0.115 to
0.120 volts is normal for 100 Watt amplifiers with (4) 6L6’s. If not in this range, adjust by
turning bias screw SLOWLY a small amount. Do not set above .070!
For other tube types (5881, 6550, EL34) check with the manufacturer or contact us for
recommendations.
Settings higher than .065 with 6L6 tubes may cause premature tube wear and possibly damage
the amplifier.
Keep in mind that tubes vary in quality, and some tubes can handle upwards of 40 ma each (a
reading at the test point of .080!) However, to be on the safe side, use the above as a guide.
WARNING! No user serviceable parts inside! Refer to qualified service person only.
LINE CORD- For your safety, connect to grounded A/C receptacle only.
.

We know your new amplifier will provide many hours of enjoyment and
inspiration in the years to come. This manual is a resource for some of your
questions. Please contact us with any other questions or comments that you may
have. We look forward to hearing from you!
PHONE: [phone]-TONE (8663) (M-F 9am-5pm PST)
FAX: [phone]
ADDRESS: Two-Rock
619 Martin Avenue, Suite 6
Rohnert Park, CA 94928
SERVICE: [e-mail]
WEB: www.two-rock.com
PRECAUTIONS:
DO NOT expose to rain or any other moisture.
DO NOT use cleaning solvents. Wipe exterior with a clean, dry
cloth only.
Refer servicing to a qualified service technician.

619 MARTIN AVENUE, SUITE 6
ROHNERT PARK, CA 94928
707-584-8663
www.two-rock.com
SERIAL NUMBER: _____________________________
